1 - HOUSING SECTION
BSD-2605104506.A7
2605104506
|
-
|
|
|
|
2 - FIELD 230V
BSD-2604220647.A6
2604220647
|
£21.52
|
£25.83
|
|
|
3 - ARMATURE 230-240V
BSD-2604011090.A6
2604011090
|
-
|
|
|
|
3/60 - FAN
BSD-2606610029.A338
2606610029
|
£2.61
|
£3.13
|
|
|
4 - ON-OFF SWITCH
BSD-2607200224.A30
2607200224
|
-
|
|
|
|
4 - SWITCH
BSD-2607200190.A27
2607200190
|
£54.42
|
£65.30
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460147.A102
2604460147
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A236
2600707059
|
£3.72
|
£4.47
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2022
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118844.A3
2601118844
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A256
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1905
2600905032
|
£5.30
|
£6.36
|
|
|
14 - NEEDLE BEARING
BSD-2600914019.A122
2600914019
|
£5.30
|
£6.36
|
|
|
16 - BRUSH PLATE
BSD-2605807060.A55
2605807060
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1551
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1884
2603490022
|
£1.75
|
£2.10
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-2601118563.A3
2601118563
|
-
|
|
|
|
27 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A797
2603490017
|
£2.16
|
£2.59
|
|
|
28 - OVAL-HEAD SCREW
BSD-2603429006.A44
2603429006
|
£1.32
|
£1.58
|
|
|
29 - DAMPING PLATE
BSD-2601022000.A394
2601022000
|
£1.75
|
£2.10
|
|
|
30 - DRILLING SPINDLE 1/2
BSD-2606135072.A3
2606135072
|
-
|
|
|
|
31 - LOCKING WASHER 0.6 MM
BSD-2600118001.A220
2600118001
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.8 MM
BSD-2600118002.A27
2600118002
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.3 MM
BSD-2600118006.A141
2600118006
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-2604616006.A247
2604616006
|
£1.75
|
£2.10
|
|
|
33 - SINTERED-METAL BUSHING 14.7-0.15
BSD-2600301031.A0
2600301031
|
£4.26
|
£5.11
|
|
|
34 - CYLINDRICAL GEAR
BSD-2606317082.A43
2606317082
|
£13.12
|
£15.75
|
|
|
35 - CYLINDRICAL GEAR
BSD-2606317083.A13
2606317083
|
£11.30
|
£13.56
|
|
|
36 - SHIM 1.0 MM
BSD-2600101515.A139
2600101515
|
£1.95
|
£2.34
|
|
|
37 - SHIM 0.3 MM
BSD-2600101047.A300
2600101047
|
£1.75
|
£2.10
|
|
|
39 - RETAINING WASHER
BSD-2600101084.A20
2600101084
|
£1.75
|
£2.10
|
|
|
40 - FLAT KEY
BSD-2602300034.A22
2602300034
|
-
|
|
|
|
41 - GUIDING PLATE
BSD-2601098031.A4
2601098031
|
£1.75
|
£2.10
|
|
|
42 - CATCH DISK
BSD-2600190070.A52
2600190070
|
£5.58
|
£6.70
|
|
|
44 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A141
1903230010
|
£1.75
|
£2.10
|
|
|
45 - INDEXING DISK
BSD-2601990001.A157
2601990001
|
£1.32
|
£1.58
|
|
|
46 - PRESSURE PLATE
BSD-2601074003.A121
2601074003
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.3 MM
BSD-2600100607.A18
2600100607
|
£1.75
|
£2.10
|
|
|
53 - SPACER RING
BSD-2600209012.A2
2600209012
|
£1.32
|
£1.58
|
|
|
54 - BEARING SLEEVE
BSD-2600400027.A65
2600400027
|
£4.26
|
£5.11
|
|
|
56 - FORK LEVER
BSD-2601990009.A22
2601990009
|
£2.29
|
£2.75
|
|
|
57 - ROTARY HEAD
BSD-2602026091.A61
2602026091
|
-
|
|
|
|
58 - RATCHET CAP
BSD-2600590006.A219
2600590006
|
£1.75
|
£2.10
|
|
|
62 - DRIVER PIN
BSD-2601335001.A79
2601335001
|
£2.16
|
£2.59
|
|
|
64 - SHIM WASHER
BSD-2600100618.A61
2600100618
|
£1.75
|
£2.10
|
|
|
66 - BEARING BRACKET
BSD-2605807073.A7
2605807073
|
-
|
|
|
|
67 - CATCH DISK
BSD-2600190071.A13
2600190071
|
£6.52
|
£7.83
|
|
|
68 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A13
2600914010
|
£2.80
|
£3.36
|
|
|
75 - O-RING 5.0x1.5 MM
BSD-1900210000.A283
1900210000
|
£1.75
|
£2.10
|
|
|
76 - FELT STRIP
BSD-2601005011.A103
2601005011
|
-
|
|
|
|
77 - FELT STRIP
BSD-2601005016.A56
2601005016
|
£1.32
|
£1.58
|
|
|
82 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A401
2603421226
|
£1.75
|
£2.10
|
|
|
85 - STICKER
BSD-2601110117.A45
2601110117
|
-
|
|
|
|
90 - CABLE L=173 MM
BSD-2604448060.A250
2604448060
|
-
|
|
|
|
91 - CABLE L=98 MM
BSD-2604448045.A149
2604448045
|
-
|
|
|
|
92 - CONNECTING CABLE L=88 MM
BSD-2604448034.A94
2604448034
|
£1.75
|
£2.10
|
|
|
93 - CONNECTING CABLE L=103 MM
BSD-2604448132.A57
2604448132
|
£1.75
|
£2.10
|
|
|
94 - CONNECTING CABLE L=73 MM
BSD-2604448115.A60
2604448115
|
£1.75
|
£2.10
|
|
|
95 - EARTH CONDUCTOR
BSD-2604448170.A98
2604448170
|
-
|
|
|
|
96 - PLAIN WASHER
BSD-2600100066.A8
2600100066
|
£1.75
|
£2.10
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A216
1619P10682
|
£12.49
|
£14.99
|
|
|
753/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A509
2915011007
|
-
|
|
|
|
753/30 - WING SCREW M6x(15)55
BSD-1613480007.A139
1613480007
|
£1.75
|
£2.10
|
|
|
753/50 - CLAMPING PLATE M6
BSD-2608040014.A139
2608040014
|
-
|
|
|
|
753/60 - WING SCREW M6x20 MM
BSD-1613480008.A295
1613480008
|
£1.75
|
£2.10
|
|
|
754 - DRILL HOLDER
BSD-2607000122.A20
2607000122
|
-
|
|
|
|
755 - DEPTH-GAUGE
BSD-2603001019.A57
2603001019
|
£2.63
|
£3.16
|
|
|
780 - KEY CHUCK dia 1.5-13 MM
BSD-2608571046.A0
2608571046
|
-
|
|
|
|
780/800 - CHUCK WRENCH SG2
BSD-2607950007.A263
2607950007
|
£6.52
|
£7.83
|
|
|
816/040 - CARBON-BRUSH SET
BSD-2604321905.A0
2604321905
|
£11.30
|
£13.56
|
|
|
816/060 - RATCHET CAP
BSD-2601322017.A22
2601322017
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A4583
160111A3H3
|
£2.61
|
£3.13
|
|
|
822 - CHANGE-OVER SWITCH
BSD-2607200231.A12
2607200231
|
£16.41
|
£19.69
|
|
|
849 - TOOTHED SHAFT Z= 10/29/22
BSD-2606309931.A10
2606309931
|
£16.74
|
£20.09
|
|
|
863 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A456
2916080007
|
£2.61
|
£3.13
|
|
