1 - HOUSING SECTION
BSD-2605104560.A7
2605104560
|
£14.72
|
£17.67
|
|
|
2 - FIELD 220-240V
BSD-2604220688.A112
2604220688
|
£27.23
|
£32.68
|
|
|
3 - ARMATURE 220-240V
BSD-2604011154.A38
2604011154
|
£30.28
|
£36.33
|
|
|
3/50 - FAN
BSD-2606610029.A277
2606610029
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-2607200556.A62
2607200556
|
£27.23
|
£32.68
|
|
|
5 - POWER SUPPLY CORD I/BR 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460283.A14
2604460283
|
£12.04
|
£14.45
|
|
|
6 - GROMMET dia6.2-dia6.9x90 MM
BSD-2600707066.A191
2600707066
|
£2.48
|
£2.97
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601119308.A7
2601119308
|
-
|
|
|
|
22 - TAPPING SCREW DIN 7981-ST2.2x9.5-C-H
BSD-2910611002.A43
2910611002
|
£1.75
|
£2.10
|
|
|
24 - O-RING 5.0x1.5 MM
BSD-1900210000.A349
1900210000
|
£1.75
|
£2.10
|
|
|
25 - CHANGE-OVER SWITCH
BSD-2602098008.A31
2602098008
|
£1.75
|
£2.10
|
|
|
35 - NEEDLE BEARING
BSD-2600914019.A134
2600914019
|
£5.30
|
£6.36
|
|
|
37 - POROUS BEARING
BSD-2600301052.A83
2600301052
|
-
|
|
|
|
38 - INDEXING DISK
BSD-2601990010.A89
2601990010
|
-
|
|
|
|
39 - PRESSURE PLATE
BSD-2601074004.A75
2601074004
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5 G28
BSD-1903230009.A752
1903230009
|
£1.75
|
£2.10
|
|
|
41 - COMPRESSION SPRING
BSD-2604616006.A302
2604616006
|
£1.75
|
£2.10
|
|
|
42 - SHIM 0.3 MM
BSD-2600101047.A269
2600101047
|
£1.75
|
£2.10
|
|
|
45 - COMPRESSION SPRING
BSD-2604610047.A14
2604610047
|
£1.75
|
£2.10
|
|
|
46 - KEY CHUCK
BSD-2608571053.A2
2608571053
|
-
|
|
|
|
46/7 - CHUCK WRENCH SG2
BSD-2607950007.A301
2607950007
|
£6.52
|
£7.83
|
|
|
47 - FRAME
BSD-2608040120.A131
2608040120
|
£2.61
|
£3.13
|
|
|
48 - SLEEVE
BSD-2600390031.A71
2600390031
|
-
|
|
|
|
53 - CONTACT STRAP
BSD-2601329043.A170
2601329043
|
£1.32
|
£1.58
|
|
|
54 - REFERENCE PLATE
BSD-2601119602.A35
2601119602
|
£3.72
|
£4.47
|
|
|
55 - PVC-INSULATED CABLE L=95 MM
BSD-1614431025.A142
1614431025
|
£2.61
|
£3.13
|
|
|
56 - PVC-INSULATED CABLE L=120 MM
BSD-2604448228.A50
2604448228
|
£2.16
|
£2.59
|
|
|
654 - AUXILIARY HANDLE
BSD-2602025094.A39
2602025094
|
£7.36
|
£8.83
|
|
|
655 - DEPTH-GAUGE
BSD-2609005615.A279
2609005615
|
£4.26
|
£5.11
|
|
|
808 - NAMEPLATE
BSD-2601119631.A0
2601119631
|
-
|
|
|
|
813 - BALL BEARING 7x19x6
BSD-2600905032.A1900
2600905032
|
£5.30
|
£6.36
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2607014017.A57
2607014017
|
-
|
|
|
|
819 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A374
2910611006
|
£1.75
|
£2.10
|
|
|
826 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A375
2910611006
|
£1.75
|
£2.10
|
|
|
831 - DRILLING SPINDLE 1/2
BSD-2606135929.A46
2606135929
|
-
|
|
|
|
833 - BEARING BRACKET
BSD-2605807932.A46
2605807932
|
-
|
|
|
|
834 - PUSH-BUTTON
BSD-2603231040.A73
2603231040
|
-
|
|
|
|
836 - GEAR COVER
BSD-2605808922.A75
2605808922
|
£10.82
|
£12.99
|
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A234
2607001305
|
£4.26
|
£5.11
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A54
2603410046
|
£2.16
|
£2.59
|
|
