2 - FIELD 220-240V
BSD-2604220515.A1
2604220515
|
£22.76
|
£27.31
|
|
|
3 - ARMATURE 220-240V
BSD-2604010707.A14
2604010707
|
-
|
|
|
|
3/50 - FAN
BSD-1606610116.A152
1606610116
|
£2.64
|
£3.17
|
|
|
4 - SWITCH
BSD-2607200404.A9
2607200404
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460432.A55
1604460432
|
£11.87
|
£14.24
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A37
2600707059
|
£3.91
|
£4.69
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2722
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118765.A3
2601118765
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A467
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1486
2600905032
|
£5.57
|
£6.68
|
|
|
14 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A11
2600917003
|
£2.94
|
£3.53
|
|
|
16 - BRUSH PLATE
BSD-2605807060.A36
2605807060
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2043
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A2607
2603490022
|
£1.84
|
£2.21
|
|
|
20 - REFERENCE PLATE
BSD-2601118672.A1
2601118672
|
£2.52
|
£3.02
|
|
|
26 - DAMPING PLATE
BSD-2601022000.A72
2601022000
|
£1.75
|
£2.10
|
|
|
29 - O-RING 5.0x1.5 MM
BSD-1900210000.A50
1900210000
|
£1.84
|
£2.21
|
|
|
30 - INDEXING DISK
BSD-2601990000.A8
2601990000
|
£1.84
|
£2.21
|
|
|
31 - SUPPORTING DISC
BSD-2600100034.A3
2600100034
|
£1.75
|
£2.10
|
|
|
32 - PRESSURE PLATE
BSD-2600025005.A60
2600025005
|
£1.75
|
£2.10
|
|
|
33 - BALL DIN 5401-6 G28
BSD-1903230011.A274
1903230011
|
£2.74
|
£3.29
|
|
|
35 - OVAL-HEAD SCREW DIN 7985-M4x25-8.8
BSD-2910951132.A64
2910951132
|
-
|
|
|
|
38 - SINTERED-METAL BUSHING
BSD-2600301013.A47
2600301013
|
-
|
|
|
|
41 - DISC SPRING
BSD-2601290014.A73
2601290014
|
£1.84
|
£2.21
|
|
|
42 - SPACER RING
BSD-2600209004.A112
2600209004
|
-
|
|
|
|
45 - EARTH CONDUCTOR
BSD-2604448103.A51
2604448103
|
-
|
|
|
|
46 - CABLE L=173 MM
BSD-2604448060.A181
2604448060
|
-
|
|
|
|
47 - CABLE L=98 MM
BSD-2604448045.A248
2604448045
|
-
|
|
|
|
48 - CONNECTING CABLE L=88 MM
BSD-2604448034.A56
2604448034
|
£1.75
|
£2.10
|
|
|
50 - CONNECTING CABLE L=73 MM
BSD-2604448115.A9
2604448115
|
£1.75
|
£2.10
|
|
|
51 - CONNECTING CABLE L=103 MM
BSD-2604448132.A36
2604448132
|
£1.84
|
£2.21
|
|
|
62 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A114
2603421226
|
£1.84
|
£2.21
|
|
|
64 - TAPPING SCREW DIN 7981-B2.9x16-C-H
BSD-2910611007.A36
2910611007
|
£1.84
|
£2.21
|
|
|
739 - KEY CHUCK R/L dia13 MM. 1/2-20 UNF
BSD-1608571062.A17
1608571062
|
£18.37
|
£22.04
|
|
|
739/7 - CHUCK WRENCH SG2
BSD-2607950007.A915
2607950007
|
£6.85
|
£8.22
|
|
|
780 - AUXILIARY HANDLE
BSD-2602025057.A2
2602025057
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-2605104837.A6
2605104837
|
£14.72
|
£17.67
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3398
160111A3H3
|
£2.74
|
£3.29
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321905.A176
2604321905
|
£11.87
|
£14.24
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A384
2601322013
|
£1.84
|
£2.21
|
|
|
825 - CHANGE-OVER SWITCH
BSD-2607200231.A92
2607200231
|
£17.22
|
£20.67
|
|
|
828 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A27
2912401020
|
£2.16
|
£2.59
|
|
|
834 - BEARING BRACKET
BSD-2605807917.A3
2605807917
|
-
|
|
|
|
836 - DRILLING SPINDLE 1/2-24 UNF-2A
BSD-2606135923.A11
2606135923
|
£21.42
|
£25.71
|
|
|
843 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A430
2910611006
|
£1.84
|
£2.21
|
|
