2 - FIELD 230-240V
BSD-1614220136.A11
1614220136
|
£19.45
|
£23.34
|
|
|
3 - ARMATURE WITH FAN 230-240V
BSD-2604011242.A3
2604011242
|
£41.62
|
£49.95
|
|
|
4 - SWITCH
BSD-2607200544.A11
2607200544
|
£33.22
|
£39.87
|
|
|
5 - POWER SUPPLY CORD I/BR 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460287.A16
2604460287
|
£22.60
|
£27.12
|
|
|
6 - GROMMET dia7.0-dia8.1x90MM
BSD-2600707067.A3
2600707067
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116658.A3
2601116658
|
£1.95
|
£2.34
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A2151
2600905032
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905017.A23
1610905017
|
£13.12
|
£15.75
|
|
|
19 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A720
2603490017
|
£2.27
|
£2.72
|
|
|
20 - REFERENCE PLATE
BSD-2601117956.A4
2601117956
|
£3.51
|
£4.21
|
|
|
24 - DRILLING SPINDLE
BSD-2606135099.A5
2606135099
|
£14.08
|
£16.89
|
|
|
26 - COMPRESSION SPRING
BSD-2604616013.A14
2604616013
|
£2.74
|
£3.29
|
|
|
27 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A299
1900905163
|
£11.30
|
£13.56
|
|
|
28 - SHIM 0.5 MM
BSD-2600100695.A130
2600100695
|
£1.84
|
£2.21
|
|
|
29 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A161
2916650008
|
£1.84
|
£2.21
|
|
|
30 - FLAT KEY
BSD-2602300032.A61
2602300032
|
£3.72
|
£4.47
|
|
|
31 - RETAINING WASHER
BSD-2600101671.A150
2600101671
|
£1.84
|
£2.21
|
|
|
32 - SHIM
BSD-2600101056.A7
2600101056
|
£1.75
|
£2.10
|
|
|
33 - CYLINDRICAL GEAR
BSD-2606317084.A61
2606317084
|
£13.78
|
£16.54
|
|
|
34 - CYLINDRICAL GEAR
BSD-2606317098.A74
2606317098
|
£12.64
|
£15.17
|
|
|
35 - SHIM 0.3 MM
BSD-2600101047.A179
2600101047
|
£1.84
|
£2.21
|
|
|
36 - CATCH DISK
BSD-2600190090.A14
2600190090
|
£2.64
|
£3.17
|
|
|
37 - CATCH DISK
BSD-2600190078.A36
2600190078
|
£6.16
|
£7.39
|
|
|
38 - SHIM WASHER 0.2 MM
BSD-2600000012.A192
2600000012
|
£1.75
|
£2.10
|
|
|
38 - SHIM WASHER 0.5 MM
BSD-2600000014.A220
2600000014
|
£1.84
|
£2.21
|
|
|
38 - SHIM WASHER 1.0 MM
BSD-2600000021.A121
2600000021
|
£1.84
|
£2.21
|
|
|
39 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A24
2603410048
|
£1.84
|
£2.21
|
|
|
40 - BALL 5.25 MM
BSD-2603230007.A45
2603230007
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5 G28
BSD-1903230009.A838
1903230009
|
£1.84
|
£2.21
|
|
|
40 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A74
1903230010
|
£1.84
|
£2.21
|
|
|
41 - CHANGEOVER LEVER
BSD-2602098014.A6
2602098014
|
£1.95
|
£2.34
|
|
|
42 - PRESSURE PLATE
BSD-2600114016.A4
2600114016
|
£2.45
|
£2.94
|
|
|
44 - GASKET
BSD-2601073014.A4
2601073014
|
£1.38
|
£1.66
|
|
|
45 - AIR GUIDE PLATE
BSD-2600148007.A17
2600148007
|
£1.75
|
£2.10
|
|
|
46 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A689
2603490024
|
£1.84
|
£2.21
|
|
|
47 - HOUSING COVER
BSD-2605132053.A2
2605132053
|
£9.97
|
£11.96
|
|
|
48 - CONTACT SPRING
BSD-2601324046.A4
2601324046
|
-
|
|
|
|
53 - DISC SPRING
BSD-2600550008.A118
2600550008
|
£1.84
|
£2.21
|
|
|
61 - SHIM 0.3 MM
BSD-2600100607.A213
2600100607
|
£1.75
|
£2.10
|
|
|
62 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A105
2600914010
|
£2.94
|
£3.53
|
|
|
63 - HEADLESS SCREW
BSD-2603435070.A47
2603435070
|
£2.16
|
£2.59
|
|
|
64 - HEADLESS SCREW
BSD-2603435077.A17
2603435077
|
£1.84
|
£2.21
|
|
|
70 - HOLDING-DOWN-APPLIANCE
BSD-2601328068.A10
2601328068
|
£1.84
|
£2.21
|
|
|
71 - RATCHET CAP
BSD-2600590006.A24
2600590006
|
£1.84
|
£2.21
|
|
|
72 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A72
2603490025
|
£1.84
|
£2.21
|
|
|
73 - SCREW 4x16
BSD-2603490022.A2091
2603490022
|
£1.84
|
£2.21
|
|
|
74 - CONTACT BAR
BSD-2601324045.A19
2601324045
|
-
|
|
|
|
75 - BLADE TERMINAL
BSD-2604477005.A12
2604477005
|
£1.84
|
£2.21
|
|
|
76 - BRUSH PLATE
BSD-2604337096.A7
2604337096
|
£15.65
|
£18.78
|
|
|
78 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A173
2916660014
|
£1.75
|
£2.10
|
|
|
80 - CHANGE-OVER SWITCH
BSD-2602099016.A8
2602099016
|
£2.45
|
£2.94
|
|
|
81 - CARRIER BRACKET
BSD-2602319024.A17
2602319024
|
£1.75
|
£2.10
|
|
|
82 - END STOP
BSD-2602319025.A6
2602319025
|
£1.32
|
£1.58
|
|
|
84 - RETAINING WASHER
BSD-2601098067.A19
2601098067
|
£2.45
|
£2.94
|
|
|
85 - KEY CHUCK
BSD-2608571060.A15
2608571060
|
£54.76
|
£65.71
|
|
|
88 - HOLDING PLATE
BSD-2601328070.A13
2601328070
|
£1.84
|
£2.21
|
|
|
653 - AUXILIARY HANDLE dia43 MM
BSD-2602025118.A113
2602025118
|
£14.91
|
£17.89
|
|
|
655 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A479
1613001009
|
£3.91
|
£4.69
|
|
|
801 - MOTOR HOUSING
BSD-2605104784.A14
2605104784
|
£25.68
|
£30.81
|
|
|
808 - NAMEPLATE
BSD-2601117686.A0
2601117686
|
-
|
|
|
|
825 - GEAR HOUSING
BSD-2605806894.A12
2605806894
|
£35.42
|
£42.51
|
|
|
843 - INTERMEDIATE FLANGE
BSD-2605700942.A3
2605700942
|
£35.12
|
£42.15
|
|
|
859 - TRANSMISSION
BSD-2606309933.A2
2606309933
|
£31.64
|
£37.97
|
|
|
865 - BULB SHIELD
BSD-2605510901.A9
2605510901
|
£12.37
|
£14.84
|
|
|
867 - TOOTHED RACK
BSD-2606308923.A12
2606308923
|
£3.34
|
£4.01
|
|
|
876 - CARBON-BRUSH SET
BSD-2604321927.A11
2604321927
|
£11.37
|
£13.64
|
|
|
879 - SPEED GOVERNOR 230-240V
BSD-2607230900.A1
2607230900
|
-
|
|
|
|
885 - CHUCK WRENCH SG2
BSD-2607950007.A9
2607950007
|
£6.85
|
£8.22
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A63
2603410046
|
£2.27
|
£2.72
|
|
