1 - HOUSING SECTION
BSD-2605104334.A7
2605104334
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-1604220254.A151
1604220254
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 230-240V
BSD-2604010862.A11
2604010862
|
-
|
|
|
|
3/60 - FAN
BSD-2606610029.A350
2606610029
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-2607200190.A38
2607200190
|
£54.42
|
£65.30
|
|
|
4 - ON-OFF SWITCH
BSD-2607200224.A37
2607200224
|
-
|
|
|
|
5 - POWER SUPPLY CORD I/BR 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460283.A21
2604460283
|
£12.04
|
£14.45
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A417
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2019
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118562.A1
2601118562
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A270
2607329114
|
-
|
|
|
|
16 - BRUSH PLATE
BSD-2609992618.A19
2609992618
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1562
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1896
2603490022
|
£1.75
|
£2.10
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-2601118563.A13
2601118563
|
-
|
|
|
|
25 - TORX OVAL-HEAD SCREW 3x30
BSD-2603490019.A32
2603490019
|
£1.75
|
£2.10
|
|
|
27 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A437
2603490018
|
£1.75
|
£2.10
|
|
|
28 - SOCKET HEAD CAP SCREW
BSD-2603429005.A8
2603429005
|
£1.75
|
£2.10
|
|
|
29 - DAMPING PLATE
BSD-2601022000.A397
2601022000
|
£1.75
|
£2.10
|
|
|
30 - DRILLING SPINDLE 1/2. SW 17
BSD-2606135044.A8
2606135044
|
-
|
|
|
|
31 - LOCKING WASHER 0.6 MM
BSD-2600118001.A232
2600118001
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.8 MM
BSD-2600118002.A15
2600118002
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.3 MM
BSD-2600118006.A153
2600118006
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-2604616002.A173
2604616002
|
£1.75
|
£2.10
|
|
|
33 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A208
1900905163
|
£11.30
|
£13.56
|
|
|
34 - CYLINDRICAL GEAR Z=48
BSD-2606317045.A95
2606317045
|
£14.72
|
£17.67
|
|
|
35 - CYLINDRICAL GEAR Z=36
BSD-2606317037.A121
2606317037
|
-
|
|
|
|
36 - SHIM 1.0 MM
BSD-2600101515.A154
2600101515
|
£1.95
|
£2.34
|
|
|
37 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A160
2916650006
|
£1.75
|
£2.10
|
|
|
39 - RETAINING WASHER
BSD-2600101671.A124
2600101671
|
£1.75
|
£2.10
|
|
|
40 - FLAT KEY
BSD-2602300028.A101
2602300028
|
-
|
|
|
|
42 - CATCH DISK
BSD-2600190052.A57
2600190052
|
£7.78
|
£9.33
|
|
|
44 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A147
1903230010
|
£1.75
|
£2.10
|
|
|
45 - INDEXING DISK
BSD-2601990001.A174
2601990001
|
£1.32
|
£1.58
|
|
|
46 - PRESSURE PLATE
BSD-2601074003.A130
2601074003
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.3 MM
BSD-2600100607.A24
2600100607
|
£1.75
|
£2.10
|
|
|
53 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A31
2600914010
|
£2.80
|
£3.36
|
|
|
54 - BEARING SLEEVE
BSD-2600400027.A52
2600400027
|
£4.26
|
£5.11
|
|
|
56 - CONTROL FORK
BSD-2602033005.A26
2602033005
|
-
|
|
|
|
57 - ROTARY HEAD
BSD-2602026091.A71
2602026091
|
-
|
|
|
|
58 - RATCHET CAP
BSD-2600590006.A211
2600590006
|
£1.75
|
£2.10
|
|
|
62 - DRIVER PIN
BSD-2601335001.A62
2601335001
|
£2.16
|
£2.59
|
|
|
64 - SHIM WASHER
BSD-2600100618.A55
2600100618
|
£1.75
|
£2.10
|
|
|
67 - CATCH DISK
BSD-2600190057.A14
2600190057
|
-
|
|
|
|
70 - CUPPED WASHER
BSD-2600500014.A47
2600500014
|
-
|
|
|
|
71 - O-RING 18x3 MM
BSD-1900210117.A121
1900210117
|
£3.72
|
£4.47
|
|
|
72 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A290
2916660008
|
£2.16
|
£2.59
|
|
|
73 - RECEPTACLE
BSD-2600400008.A595
2600400008
|
£1.75
|
£2.10
|
|
|
74 - BEARING SLEEVE
BSD-2600222002.A60
2600222002
|
-
|
|
|
|
75 - O-RING 5.0x1.5 MM
BSD-1900210000.A279
1900210000
|
£1.75
|
£2.10
|
|
|
76 - FELT STRIP
BSD-2601005011.A111
2601005011
|
-
|
|
|
|
77 - FELT STRIP
BSD-2601005016.A48
2601005016
|
£1.32
|
£1.58
|
|
|
81 - RETAINING RING
BSD-2604601004.A318
2604601004
|
£1.75
|
£2.10
|
|
|
82 - COUNTERSUNK-HEAD SCREW M 6x34 MM
BSD-2603421213.A59
2603421213
|
£2.61
|
£3.13
|
|
|
85 - STICKER
BSD-2601110117.A47
2601110117
|
-
|
|
|
|
90 - CABLE L=173 MM
BSD-2604448060.A255
2604448060
|
-
|
|
|
|
91 - CABLE L=98 MM
BSD-2604448045.A144
2604448045
|
-
|
|
|
|
92 - CONNECTING CABLE L=88 MM
BSD-2604448034.A103
2604448034
|
£1.75
|
£2.10
|
|
|
93 - CONNECTING CABLE L=103 MM
BSD-2604448132.A68
2604448132
|
£1.75
|
£2.10
|
|
|
94 - CONNECTING CABLE L=73 MM
BSD-2604448115.A49
2604448115
|
£1.75
|
£2.10
|
|
|
95 - EARTH CONDUCTOR
BSD-2604448170.A87
2604448170
|
-
|
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A228
1619P10682
|
£12.49
|
£14.99
|
|
|
753/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A495
2915011007
|
-
|
|
|
|
753/30 - WING SCREW M6x(15)55
BSD-1613480007.A136
1613480007
|
£1.75
|
£2.10
|
|
|
753/50 - CLAMPING PLATE M6
BSD-2608040014.A145
2608040014
|
-
|
|
|
|
753/60 - WING SCREW M6x20 MM
BSD-1613480008.A298
1613480008
|
£1.75
|
£2.10
|
|
|
754 - DRILL HOLDER
BSD-2607000122.A30
2607000122
|
-
|
|
|
|
755 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001005.A169
1613001005
|
-
|
|
|
|
780 - KEYLESS CHUCK dia 2-13 MM.1/2
BSD-2608572034.A27
2608572034
|
£30.62
|
£36.74
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A4567
160111A3H3
|
£2.61
|
£3.13
|
|
|
813 - NEEDLE BEARING
BSD-2600917902.A36
2600917902
|
-
|
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A380
2600905039
|
£12.04
|
£14.45
|
|
|
816/01/40 - CARBON-BRUSH SET
BSD-2604321905.A3
2604321905
|
£11.30
|
£13.56
|
|
|
816/02/60 - RATCHET CAP
BSD-2601322013.A553
2601322013
|
£1.75
|
£2.10
|
|
|
822 - CHANGE-OVER SWITCH
BSD-2607200231.A0
2607200231
|
£16.41
|
£19.69
|
|
|
823 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A243
2912401020
|
£2.16
|
£2.59
|
|
|
849 - TOOTHED SHAFT Z= 10/29/22
BSD-2606309913.A10
2606309913
|
-
|
|
|
|
863 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A469
2916080007
|
£2.61
|
£3.13
|
|
|
866 - BEARING BRACKET
BSD-2605807928.A35
2605807928
|
-
|
|
|
|
869 - FELT DISC
BSD-2600108000.A124
2600108000
|
-
|
|
|
