1 - TAPPING SCREW (W/FLANGE) D2X8
HIT-338364.A0
338364
|
-
|
|
|
|
2 - ADAPTER STORAGE CASE
HIT-338392.A1
338392
|
-
|
|
|
|
3 - TAPPING SCREW (W/FLANGE) D2.3X8
HIT-338399.A2
338399
|
-
|
|
|
|
4 - SQUARE WASHER
HIT-338409.A1
338409
|
-
|
|
|
|
5 - BATTERY COMPARTMENT SET
HIT-338365.A1
338365
|
-
|
|
|
|
6 - MACHINE SCREW (W/FLANGE) M3X8
HIT-338398.A0
338398
|
-
|
|
|
|
7 - CONNECTOR A
HIT-338374.A0
338374
|
-
|
|
|
|
8 - TAPPING SCREW D4X18
HIT-338397.A1
338397
|
£4.45
|
£5.34
|
|
|
9 - RUBBER ANTENNA
HIT-338390.A1
338390
|
£16.49
|
£19.79
|
|
|
10 - LOWER BACK COVER BUTTON
HIT-338363.A1
338363
|
£1.67
|
£2.00
|
|
|
11 - UPPER BACK COVER BUTTON
HIT-338362.A0
338362
|
£1.67
|
£2.00
|
|
|
12 - BACK COVER LATCHING B
HIT-338361.A1
338361
|
£1.67
|
£2.00
|
|
|
13 - NAME PLATE
HIT-000000.A5041
000000
|
-
|
|
|
|
14 - BACK CABINET SET INCLUD.1
HIT-338360.A0
338360
|
£64.82
|
£77.78
|
|
|
15 - UPPER CONTACT BRACKET
HIT-338388.A2
338388
|
-
|
|
|
|
16 - BATTERY TERMINAL
HIT-339154.A1
339154
|
-
|
|
|
|
17 - LOWER CONTACT BRACKET
HIT-338389.A0
338389
|
-
|
|
|
|
18 - INTERNAL WIRE (B)
HIT-338407.A2
338407
|
-
|
|
|
|
19 - CONNECTOR C
HIT-338405.A2
338405
|
£3.21
|
£3.85
|
|
|
20 - BATTERY COVER
HIT-338387.A0
338387
|
-
|
|
|
|
21 - SCREW M3
HIT-338410.A0
338410
|
-
|
|
|
|
22 - DC JACK BRACKET
HIT-338394.A0
338394
|
-
|
|
|
|
23 - RUBBER SHEET (DC JACK)
HIT-339155.A0
339155
|
-
|
|
|
|
24 - DC JACK
HIT-338396.A0
338396
|
£1.67
|
£2.00
|
|
|
25 - CONNECTOR B
HIT-338404.A0
338404
|
-
|
|
|
|
26 - CABLE HOLDER (ANDROID)
HIT-338372.A0
338372
|
£3.02
|
£3.63
|
|
|
27 - SUPPORT
HIT-338385.A0
338385
|
-
|
|
|
|
28 - BRACKET SET INCLUD.29
HIT-338366.A0
338366
|
-
|
|
|
|
29 - TAPPING SCREW D2X6
HIT-338400.A0
338400
|
-
|
|
|
|
30 - LEFT LATCHING
HIT-338383.A0
338383
|
-
|
|
|
|
31 - LEFT LATCH MOUNTING
HIT-338378.A1
338378
|
-
|
|
|
|
32 - RIGHT LATCHING
HIT-338384.A1
338384
|
-
|
|
|
|
33 - RIGHT LATCH MOUNTING
HIT-338379.A0
338379
|
-
|
|
|
|
34 - LATCHING PLATE
HIT-338386.A1
338386
|
-
|
|
|
|
35 - PCB ASS'Y (USB)
HIT-338408.A0
338408
|
£7.75
|
£9.30
|
|
|
36 - PCB PLATE
HIT-338403.A1
338403
|
-
|
|
|
|
37 - TAPPING SCREW D1.7X10
HIT-339113.A1
339113
|
-
|
|
|
|
38 - PCB ASS'Y (AUX)
HIT-338391.A0
338391
|
£8.19
|
£9.83
|
|
|
39 - CABLE HOLDER (APPLE)
HIT-338371.A1
338371
|
£2.84
|
£3.41
|
|
|
40 - PCB ASS'Y (A)
HIT-338376.A0
338376
|
£97.94
|
£117.53
|
|
|
41 - SPEAKER RESISTANCE STRIP
HIT-338402.A0
338402
|
-
|
|
|
|
42 - SPEAKER (DSDL)
HIT-338395.A1
338395
|
-
|
|
|
|
43 - WATER RESISTANCE STRIP E
HIT-339115.A1
339115
|
-
|
|
|
|
44 - TAPPING SCREW D2X8
HIT-338401.A1
338401
|
-
|
|
|
|
45 - SIDE PLATE
HIT-338377.A0
338377
|
-
|
|
|
|
46A - SPEAKER GRILL SET
HIT-338370.A0
338370
|
-
|
|
|
|
47 - NUT M3 (10 PCS.)
HIT-949553.A9
949553
|
£1.67
|
£2.00
|
|
|
48 - HEX. SOCKET HD. BOLT M4X8 (10 PCS.)
HIT-949811.A5
949811
|
£2.86
|
£3.43
|
|
|
49 - FRONT COVER SET
HIT-338367.A1
338367
|
£34.30
|
£41.16
|
|
|
50 - BLUETOOTH LABEL
HIT-000000.A5042
000000
|
-
|
|
|
|
51A - FRONT CABINET SET A
HIT-338359.A0
338359
|
£41.92
|
£50.30
|
|
|
52 - CONNECTOR D
HIT-338406.A0
338406
|
-
|
|
|
|
71 - HEX. SOCKET HD. BOLT M5X18 (10 PCS.)
HIT-949658.A6
949658
|
£3.28
|
£3.93
|
|
|
72 - HEX. SOCKET HD. BOLT M5X10 (10 PCS.)
HIT-949819.A0
949819
|
£6.66
|
£7.99
|
|
|
73 - BOLT WASHER M5 (10 PCS.)
HIT-949431.A5
949431
|
£1.67
|
£2.00
|
|
|
74 - UPPER PROTECTOR
HIT-338380.A0
338380
|
-
|
|
|
|
75 - SHORT LAVER SET
HIT-338369.A0
338369
|
-
|
|
|
|
76 - LOWER PROTECTOR
HIT-338381.A0
338381
|
-
|
|
|
|
77 - NUT M5 (BLACK)
HIT-302012.A4
302012
|
£1.67
|
£2.00
|
|
|
78 - LONG LEVER SET
HIT-338368.A0
338368
|
-
|
|
|
|
79 - ABSORBER SET
HIT-338373.A0
338373
|
-
|
|
|
|
80 - RUBBER WASHER
HIT-339114.A0
339114
|
-
|
|
|
|
81 - BRAND LABEL
HIT-000000.A5043
000000
|
-
|
|
|
|
*501 - AC-ADAPTER (UK) FOR GBR
HIT-338413.A1
338413
|
£37.92
|
£45.50
|
|
|
502 - AA BATTERY
HIT-000000.A5045
000000
|
-
|
|
|
