Hitachi / Hikoki TPS-270S Engine Pole Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TPS-270S Engine Pole Saw

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A16 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A19 6699319	-
3 - CYLINDER SET HIT-6685493.A6 6685493	£72.13	£86.56
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A22 6684586	-
5 - CYLINDER GASKET T=1.0 HIT-6685750.A3 6685750	£2.81	£3.37
6 - PISTON RING HIT-6686121.A18 6686121	£6.47	£7.76
7 - PISTON SET HIT-6685902.A10 6685902	£30.58	£36.70
8 - CIR CLIP HIT-6684590.A119 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A18 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A5 6686219	£121.07	£145.28
12 - LEAD WIRE ASS'Y HIT-6687965.A1 6687965	£4.26	£5.11
13 - HEX. HOLE BOLT M4X18/WS TILL H124040 HIT-6684599.A61 6684599	-
13A - HIGH TENSION SCREW 4X18WS SINCE H124041 HIT-6695407.A17 6695407	-
14 - IGNITION COIL ASS'Y MB-55 HIT-6687684.A1 6687684	£35.79	£42.95
*21 - GEAR SHAFT SHIM 0.10 HIT-6689177.A17 6689177	-
*21 - GEAR SHAFT SHIM 0.15 HIT-6689178.A18 6689178	-
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A21 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A60 6684605	-
22 - MAGNETO ROTOR COMP. HIT-6687384.A12 6687384	-
23 - HEX. NUT M8 HIT-6684612.A90 6684612	-
24 - BOLT WASHER M8 HIT-6684611.A35 6684611	-
25 - CRANK CASE ASS'Y SPARE TILL D038600 HIT-6695886.A1 6695886	-
25A - CRANK CASE ASS'Y SINCE D038601 HIT-6684905.A17 6684905	£30.92	£37.11
26 - OIL SEAL TB 12227 HIT-6684607.A111 6684607	£4.07	£4.88
27 - BALL BEARING 6001 C3 HIT-6684608.A89 6684608	£5.70	£6.84
28A - CRANK CASE GASKET HIT-6684904.A5 6684904	£1.67	£2.00
29 - HEX. HOLE BOLT M5X16/S HIT-6684903.A65 6684903	-
41 - INLET MANIFOLD GASKET HIT-6689895.A19 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A18 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT M5X25WS HIT-6695515.A50 6695515	£1.67	£2.00
44 - CARBURETOR GASKET HIT-6684615.A11 6684615	£1.67	£2.00
45 - CABURETOR SET WYJ-431 HIT-6690519.A5 6690519	£113.54	£136.25
46 - CLEANER BODY COMP. HIT-6690120.A9 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A16 6690365	£1.67	£2.00
48 - CLEANER COVER ASS'Y HIT-6690421.A0 6690421	£14.48	£17.38
49A - COVER FIXING BOLT COMP. HIT-6698730.A2 6698730	£5.52	£6.63
50 - SCREW 5X57/S HIT-6695353.A19 6695353	£1.67	£2.00
51 - SMALL WASHER 5 HIT-6684864.A112 6684864	-
52 - CHOKE LEVER 1.5 HIT-6691281.A3 6691281	£1.67	£2.00
53 - CHOKE CONTROL LEVER HIT-6691239.A9 6691239	£2.98	£3.57
54 - TANK WHT HIT-6691602.A6 6691602	£13.82	£16.59
55 - COLLAR C HIT-6684623.A18 6684623	£1.67	£2.00
56 - RETURN GROMMET HIT-6697846.A131 6697846	£1.68	£2.01
57 - FUEL PIPE 3X5X65 HIT-6684626.A19 6684626	£1.67	£2.00
58A - PUMP FILTER BODY COMP HIT-66A3864.A68 66A3864	-
59 - CLIP D6 HIT-6685198.A60 6685198	-
60 - SHIELD TUBE 3X5X180 HIT-6684618.A28 6684618	£6.12	£7.35
61 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A22 6684634	£1.67	£2.00
62 - TANK CAP ASS'Y HIT-6685049.A10 6685049	£9.94	£11.93
63 - TANK CAP CHAIN HIT-6684625.A20 6684625	-
64 - STAND HIT-6694787.A33 6694787	£3.56	£4.27
65 - TAP SCREW 4X14 P HIT-6695280.A12 6695280	£1.67	£2.00
66 - BOLT WASHER M4 HIT-6685070.A49 6685070	£1.67	£2.00
71 - CYLINDER COVER HIT-6685690.A6 6685690	£5.70	£6.84
72 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A51 6695504	£1.67	£2.00
73 - HEX. HOLE BOLT M6X55 HIT-6684638.A28 6684638	£1.67	£2.00
74 - BOLT WASHER 6 HIT-6684639.A36 6684639	£1.67	£2.00
75 - MUFFLER SET HIT-6692498.A5 6692498	£25.72	£30.86
76 - MUFFLER GASKET HIT-6692732.A13 6692732	£1.67	£2.00
77 - MUFFLER PROTECTOR HIT-6692813.A6 6692813	£8.89	£10.67
78 - HEX. HOLE BOLT 4X18WS TILL H124040 HIT-6695508.A63 6695508	£1.67	£2.00
78A - SCREW 4X18/PS SINCE H124041 HIT-6695375.A28 6695375	-
79 - PLUG CAP HIT-6688345.A1 6688345	£4.99	£5.99
80 - CLUTCH WASHER B HIT-6684642.A34 6684642	£1.67	£2.00
81 - CLUTCH SHOE COMP. HIT-6684643.A4 6684643	£12.01	£14.41
82 - CLUTCH SPRING HIT-6684644.A20 6684644	£3.12	£3.74
83 - CLUTCH PLATE A 0.5 HIT-6684645.A5 6684645	£1.67	£2.00
84 - STEP BOLT HIT-6684646.A30 6684646	£3.72	£4.46
85 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A23 6684634	£1.67	£2.00
86 - BENT WASHER 8 HIT-6684648.A81 6684648	£1.67	£2.00
87 - CLUTCH ASS'Y HIT-6688496.A0 6688496	-
88 - TAPPING SCREW D4.5X16 HIT-6684636.A31 6684636	£1.67	£2.00
89 - HEAT SHIELD HIT-6687264.A2 6687264	-
90 - MUFFLER SET FOR AUS HIT-6692500.A0 6692500	-
91 - MUFFLER WIRE NET SET FOR AUS HIT-6692688.A8 6692688	-
92 - MUFFLER SPECIAL GASKET FOR AUS HIT-6692887.A14 6692887	-
93 - SPARK ARRESTOR FOR AUS HIT-6692699.A2 6692699	-
94 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR AUS HIT-6685109.A26 6685109	-
101B - RECOIL STARTER BODY ASS'Y INCLUD.103-109 HIT-6601570.A28 6601570	£23.15	£27.78
103 - STARTER ROPE 3.5X860 HIT-6684674.A88 6684674	£5.70	£6.84
104 - RECOIL SPRING HIT-6684675.A10 6684675	£8.82	£10.58
105A - STARTER ROPE REEL SINCE TL026141 HIT-6699997.A4 6699997	-
106 - DAMPER SPRING HIT-6684677.A109 6684677	£5.70	£6.84
107A - CAM PLATE SINCE TL026141 HIT-6699996.A85 6699996	£4.28	£5.13
108 - SET SCREW HIT-6684679.A153 6684679	£2.98	£3.57
109 - STARTER HANDLE HIT-6684680.A5 6684680	£5.87	£7.04
110 - STARTER PULLEY ASS'Y HIT-6684681.A110 6684681	£18.16	£21.79
111 - D4E RETAINING RING HIT-6685101.A115 6685101	-
112 - STARTER PAWL SPRING HIT-6684684.A13 6684684	£3.29	£3.95
113 - STARTER PAWL HIT-6684685.A94 6684685	£5.07	£6.08
114 - HEX. HOLE BOLT 4X18WS TILL H124040 HIT-6695508.A64 6695508	£1.67	£2.00
114A - SCREW 4X18/PS SINCE H124041 HIT-6695375.A27 6695375	-
115 - CAMPLATE ASS'Y TILL TL026140 HIT-6699691.A35 6699691	£7.75	£9.30
121 - PUMP BODY COMP. HIT-6684879.A32 6684879	£35.37	£42.44
122 - PRIMING PUMP COMP. HIT-6684687.A4 6684687	£9.27	£11.12
123 - DIAPHRAGM COVER HIT-6684688.A96 6684688	£5.70	£6.84
124 - PRIMING BODY HIT-6684689.A3 6684689	£5.87	£7.04
125 - METERING DIAPHRAGM COMP. HIT-6690830.A28 6690830	£14.58	£17.50
126 - DIAPHRAGM GASKET HIT-6684691.A3 6684691	£5.70	£6.84
127 - PUMP DIAPHRAGM HIT-6684693.A14 6684693	£5.70	£6.84
128 - PUMP GASKET HIT-6684692.A103 6684692	£17.28	£20.73
129 - MAIN JET #43 HIT-6691848.A6 6691848	£8.77	£10.52
130 - O-RING HIT-6684695.A179 6684695	£1.67	£2.00
131 - STOP RING HIT-6684696.A15 6684696	-
132 - SWIVEL HIT-6684697.A146 6684697	-
133 - THROTTLE SET SCREW HIT-6684870.A57 6684870	-
134 - CABLE ADJUSTER STAY HIT-6684873.A20 6684873	-
135 - LOCK NUT M6 HIT-6684872.A62 6684872	-
136 - CABLE ADJUSTER HIT-6684871.A18 6684871	-
137 - CLEANER PACKING HIT-6684875.A21 6684875	-
138 - SET SCREW HIT-6684699.A97 6684699	-
139 - THRUST WASHER HIT-6684874.A59 6684874	-
140 - INLET SCREEN HIT-6684700.A6 6684700	-
151 - CLUTCH DRUM COMP. HIT-6688580.A0 6688580	£16.79	£20.15
152 - STOP RING C-12 OUTER HIT-6684664.A50 6684664	£1.67	£2.00
153 - CUSHION RUBBER HIT-6691823.A3 6691823	£3.56	£4.27
154 - HEX. HOLE BOLT 5X16 HIT-6695046.A27 6695046	£1.67	£2.00
155 - HEX. HOLE BOLT M5X25/S HIT-6684709.A199 6684709	£1.67	£2.00
156 - FAN CASE COMP. HIT-6686959.A1 6686959	£25.96	£31.15
157 - PIPE HOLDER 1 HIT-6689651.A10 6689651	£8.88	£10.66
158 - WASHER M5 (BLACK) HIT-6684918.A84 6684918	£1.67	£2.00
159 - GEAR CASE WASHER HIT-6689159.A37 6689159	-
160 - METAL FITTING HIT-6689664.A11 6689664	£6.12	£7.35
181 - DRIVE SHAFT 1829L HIT-6689443.A2 6689443	-
182 - MAIN PIPE COMP HIT-6699653.A2 6699653	£41.18	£49.42
183 - BUSH ASS'Y HIT-6697839.A7 6697839	-
184 - HEX.NUT 6 HIT-6684835.A11 6684835	£1.67	£2.00
185 - LOOP HANDLE BLACK HIT-6691046.A11 6691046	£16.30	£19.56
186 - HANDLE BRACKET A HIT-6691134.A8 6691134	£3.10	£3.72
187 - HANDLE GRIP HIT-6691098.A30 6691098	£10.90	£13.08
188 - BOLT 6X43/P (BLACK) HIT-6684838.A35 6684838	£1.67	£2.00
189 - TAPPING SCREW 5X20 HIT-6695255.A17 6695255	-
190 - BRAKE SHAFT WASHER HIT-6689681.A23 6689681	£1.67	£2.00
191 - HANGER D24 HIT-6689277.A6 6689277	-
196 - THROTTLE LEVER ASS'Y 24 DIA. HIT-6693767.A1 6693767	-
197 - THROTTLE WIRE COMP. HIT-6693978.A9 6693978	£22.29	£26.75
198 - THROTTLE WIRE HIT-6694022.A5 6694022	-
199 - STOP SWITCH COMP. HIT-6687459.A6 6687459	£17.33	£20.80
200 - PROTECTION TUBE 7X175 HIT-6687526.A0 6687526	-
201 - TRIGGER LOCK OUT HIT-6684721.A13 6684721	£5.17	£6.20
202 - RETURN SPRING HIT-6684722.A35 6684722	£1.67	£2.00
203 - BLIND PLUG HIT-6684724.A35 6684724	-
204 - SCREW M5X20 HIT-6684803.A21 6684803	-
205 - CONTAL NUT 5 HIT-6684727.A12 6684727	£1.67	£2.00
206 - SCREW M4X20 (BLACK) HIT-6684725.A0 6684725	-
207 - THROTTLE LEVER HIT-6684804.A9 6684804	£6.86	£8.23
221 - OIL TANK COVER HIT-6686138.A4 6686138	£2.81	£3.37
222 - COLLAR 3 TILL J093879 HIT-6685961.A0 6685961	£1.67	£2.00
222A - COLLAR 3 SINCE J093880 HIT-6699273.A4 6699273	-
223A - OIL TANK PACKING SINCE J093880 HIT-6699567.A7 6699567	£2.77	£3.32
224 - O-RING P-5 HIT-6695661.A22 6695661	£1.67	£2.00
225 - STEP BOLT A HIT-6689757.A9 6689757	-
226 - OIL PUMP COMP. HIT-6686487.A5 6686487	£39.35	£47.22
227 - O-RING P-5 HIT-6695661.A21 6695661	£1.67	£2.00
228 - OIL PUMP SPRING HIT-6690381.A6 6690381	-
229 - OIL PUMP PISTON COMP. HIT-6686608.A5 6686608	-
230 - TANK PACKING ASS'Y SINCE J093880 HIT-6699566.A0 6699566	£3.48	£4.17
231 - FUEL PIPE 3X5X60 HIT-6692414.A3 6692414	-
232 - SMALL SCREW 4X12WS HIT-6695403.A19 6695403	-
233 - WASHER 5 HIT-6684661.A7 6684661	£1.67	£2.00
234 - OIL FILTER HIT-6690917.A2 6690917	£1.67	£2.00
235 - FILTER ASS'Y HIT-6690913.A6 6690913	-
236 - FUEL PIPE 3X5X75 HIT-6692415.A8 6692415	-
237 - OIL PUMP ADJUSTER HIT-6691066.A8 6691066	£8.79	£10.55
238 - O-RING P-5 HIT-6695661.A20 6695661	£1.67	£2.00
239 - STOP RING E-6 HIT-6695311.A9 6695311	£1.67	£2.00
240 - OIL TANK CAP ASS'Y HIT-6692050.A4 6692050	£15.87	£19.04
241 - BANJO 1 HIT-6686637.A4 6686637	-
242 - O-RING P-15 HIT-6698966.A15 6698966	£1.67	£2.00
243 - 8 PUSH NUT HIT-6695239.A8 6695239	-
244 - WASHER 2 HIT-6695187.A10 6695187	-
245 - O-RING 1.4 HIT-6695656.A7 6695656	-
261 - HEX. HOLE BOLT 5X22/S HIT-6695492.A22 6695492	-
262 - HEX. HOLE BOLT 5X10 HIT-6695042.A5 6695042	£1.67	£2.00
263 - SCREW 6X8 HIT-6695458.A0 6695458	-
264 - CASE HIT-6685793.A5 6685793	£12.52	£15.03
265 - GEAR PINION SET SPARE HIT-6688836.A4 6688836	-
266 - BALL BEARING 609 HIT-6684734.A31 6684734	-
267 - BALL BEARING 609Z ST HIT-6684735.A9 6684735	£15.48	£18.57
268 - STOP RING C-9 1 HIT-6695281.A21 6695281	-
269 - STOP RING C-24 1 HIT-6684732.A37 6684732	£1.67	£2.00
271 - BALL BEARING 627 C3 HIT-6695568.A11 6695568	£8.95	£10.74
272 - BALL BEARING 638Z HIT-6697603.A3 6697603	-
273 - STOP RING C-28 1 HIT-6684741.A5 6684741	-
274 - SPROCKET COMP. 1 HIT-6689117.A4 6689117	£47.37	£56.84
275 - FLANGE NUT 6 HIT-6695170.A40 6695170	£1.67	£2.00
276 - SIDE COVER COMP. HIT-6686038.A9 6686038	£9.67	£11.60
277 - CHAIN BAR CLAMP NUT HIT-6687105.A25 6687105	£1.67	£2.00
278 - CHAIN BAR KNOCK PIN HIT-6687130.A10 6687130	-
279 - GUIDE PLATE HIT-6697596.A8 6697596	£4.38	£5.26
280 - CHAIN BAR TIGHTENING BOLT HIT-6686803.A5 6686803	£8.53	£10.24
281 - CHAIN TENSIONER HIT-6687063.A2 6687063	£5.70	£6.84
282 - CAM HIT-6690428.A8 6690428	-
283 - COLLAR HIT-6685962.A6 6685962	-
284 - SAW CHAIN HIT-6699679.A5 6699679	£20.67	£24.80
285 - GUIDE BAR S/N HIT-6686875.A4 6686875	£33.19	£39.83
501 - COMBI. BOX SPANNER 13X19 MINUS HIT-6693809.A33 6693809	-
502 - WRENCH 8X10 HIT-6684766.A19 6684766	-
503 - GUIDE BAR COVER 1 HIT-6694796.A8 6694796	£11.79	£14.15
504 - HEX. BAR WRENCH 4MM HIT-6684813.A14 6684813	-
505 - SHOULDER BELT HIT-6692867.A1 6692867	£8.37	£10.04
601 - CYMBOL MARK TPS-270S HIT-6694663.A0 6694663	-
602 - S?START MARK HIT-6694472.A2 6694472	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TPS-270S Engine Pole Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TPS-270S Engine Pole Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TPS-270S Engine Pole Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
