Hitachi / Hikoki TPS-270PFS Engine Pole Saw Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TPS-270PFS Engine Pole Saw

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A15 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y BMR6A HIT-6699315.A10 6699315	-
3 - CYLINDER SET HIT-6685495.A5 6685495	£87.22	£104.66
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A25 6684586	-
5 - CYLINDER GASKET HIT-6684896.A13 6684896	£1.67	£2.00
6 - PISTON RING HIT-6686121.A19 6686121	£6.47	£7.76
7 - PISTON SET HIT-6685902.A11 6685902	£30.58	£36.70
8 - CIR CLIP HIT-6684590.A115 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A21 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A4 6686219	£121.07	£145.28
11 - LEAD WIRE ASS'Y HIT-6687965.A2 6687965	£4.26	£5.11
12 - HIGH TENSION SCREW 4X18WS HIT-6695407.A18 6695407	-
13 - IGNITION COIL ASS'Y MB-65 HIT-6687688.A0 6687688	£48.01	£57.61
14 - WASHER T1.6 HIT-6684600.A17 6684600	-
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A20 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A61 6684605	-
22 - MAGNETO ROTOR COMP. HIT-6687385.A0 6687385	-
23 - HEX. NUT M8 HIT-6684612.A93 6684612	-
24 - BOLT WASHER M8 HIT-6684611.A32 6684611	-
25 - CRANK CASE ASS'Y HIT-6684905.A16 6684905	£30.92	£37.11
26 - OIL SEAL TB 12227 HIT-6684607.A108 6684607	£4.07	£4.88
27 - BALL BEARING 6001 C3 HIT-6684608.A92 6684608	£5.70	£6.84
28 - CRANK CASE GASKET HIT-6684904.A6 6684904	£1.67	£2.00
29 - HEX. HOLE BOLT M5X16/S HIT-6684903.A64 6684903	-
41 - INLET MANIFOLD GASKET HIT-6689895.A20 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A19 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT 5X25/WS HIT-6684617.A2 6684617	-
44 - CARBURETOR PACKING HIT-6684616.A36 6684616	£1.67	£2.00
45 - CHOKE PLATE 2.0 HIT-6691276.A14 6691276	£1.67	£2.00
46 - CLEANER BODY COMP. HIT-6690120.A10 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A15 6690365	£1.67	£2.00
48 - CLEANER COVER ASS'Y HIT-6690402.A10 6690402	£12.16	£14.59
49 - COVER FIXING BOLT COMP. HIT-6698730.A1 6698730	£5.52	£6.63
50 - SCREW M5X55 HIT-6694914.A13 6694914	-
51 - S.WASHER 5 HIT-6684662.A88 6684662	£1.67	£2.00
52 - SMALL WASHER 5 HIT-6684864.A111 6684864	-
53 - CABURETOR SET WYJ-463 HIT-6690522.A1 6690522	£84.48	£101.37
54 - CHOKE CONTROL LEVER HIT-6691239.A8 6691239	£2.98	£3.57
55 - TANK WHT HIT-6691602.A7 6691602	£13.82	£16.59
56 - COLLAR C HIT-6684623.A19 6684623	£1.67	£2.00
57 - RETURN GROMMET HIT-6697846.A132 6697846	£2.08	£2.50
58 - FUEL PIPE 3X5X65 HIT-6684626.A20 6684626	£1.67	£2.00
59A - PUMP FILTER BODY COMP HIT-66A3864.A67 66A3864	-
60 - CLIP D6 HIT-6685198.A61 6685198	-
61 - SHIELD TUBE 3X5X180 HIT-6684618.A27 6684618	£6.12	£7.35
62 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A20 6684634	£1.67	£2.00
63 - TANK CAP ASS'Y HIT-6685049.A9 6685049	£9.94	£11.93
64 - TAP SCREW 4X14 P HIT-6695280.A11 6695280	£1.67	£2.00
65 - BOLT WASHER M4 HIT-6685070.A50 6685070	£1.67	£2.00
66 - STAND HIT-6694787.A32 6694787	£3.56	£4.27
67 - TANK CAP CHAIN HIT-6684625.A19 6684625	-
81 - CYLINDER COVER (BLK) HIT-6685693.A6 6685693	-
82 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A52 6695504	£1.67	£2.00
83 - HEX. HOLE BOLT M6X65 HIT-6695067.A9 6695067	£1.67	£2.00
84 - BOLT WASHER 6 HIT-6684639.A37 6684639	£1.67	£2.00
85 - MUFFLER COMP HIT-6699282.A1 6699282	-
86 - TAIL PIPE GASKET HIT-6692888.A0 6692888	-
87 - TAIL PIPE SET HIT-6692715.A0 6692715	-
88 - SCREW M4X8/WS HIT-6684651.A17 6684651	-
89 - SPARK ARRESTER HIT-6692701.A6 6692701	-
90 - MUFFLER PROTECTOR BLK HIT-6692818.A4 6692818	£16.09	£19.31
91 - SCREW 4X18/PS HIT-6695375.A29 6695375	-
92 - PLUG COVER HIT-6688344.A4 6688344	-
93 - CLUTCH WASHER B HIT-6684642.A33 6684642	£1.67	£2.00
94 - CLUTCH SHOE COMP. HIT-6684643.A5 6684643	£12.01	£14.41
95 - CLUTCH SPRING HIT-6684644.A19 6684644	£3.12	£3.74
96 - CLUTCH PLATE A 0.5 HIT-6684645.A6 6684645	£1.67	£2.00
97 - STEP BOLT HIT-6684646.A29 6684646	£3.72	£4.46
98 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A21 6684634	£1.67	£2.00
99 - CLUTCH SET ASS'Y HIT-6699640.A5 6699640	£15.92	£19.10
100 - BENT WASHER 8 HIT-6684648.A82 6684648	£1.67	£2.00
101 - TAPPING SCREW D4.5X16 HIT-6684636.A32 6684636	£1.67	£2.00
102 - HEAT SHIELD HIT-6687265.A7 6687265	£5.70	£6.84
103 - STARTER ROPE 3.5X860 HIT-6684674.A87 6684674	£5.70	£6.84
104 - RECOIL SPRING HIT-6684675.A11 6684675	£8.82	£10.58
105A - STARTER ROPE REEL SINCE TL034071 HIT-6699997.A5 6699997	-
106 - DAMPER SPRING HIT-6684677.A108 6684677	£5.70	£6.84
107A - CAM PLATE HIT-6699996.A84 6699996	£4.28	£5.13
108 - SET SCREW HIT-6684679.A154 6684679	£2.98	£3.57
109 - STARTER HANDLE HIT-6684680.A4 6684680	£5.87	£7.04
110 - STARTER PULLEY ASS'Y HIT-6684681.A111 6684681	£18.16	£21.79
111 - SCREW 4X18/PS HIT-6695375.A30 6695375	-
112 - D4E RETAINING RING HIT-6685101.A114 6685101	-
113 - STARTER PAWL SPRING HIT-6684684.A12 6684684	£3.29	£3.95
114 - STARTER PAWL HIT-6684685.A95 6684685	£5.07	£6.08
115 - CAMPLATE ASS'Y TILL TL034070 HIT-6699691.A36 6699691	£7.75	£9.30
117 - RECOIL STARTER BODY COMP. HIT-6684673.A0 6684673	£12.98	£15.58
121 - PUMP BODY COMP. HIT-6684879.A31 6684879	£35.37	£42.44
122 - PRIMING PUMP COMP. HIT-6684687.A3 6684687	£9.27	£11.12
123 - DIAPHRAGM COVER HIT-6684688.A97 6684688	£5.70	£6.84
124 - PRIMING BODY HIT-6684689.A2 6684689	£5.87	£7.04
125 - METERING DIAPHRAGM HIT-6684690.A109 6684690	£24.05	£28.86
126 - DIAPHRAGM GASKET HIT-6684691.A2 6684691	£5.70	£6.84
127 - PUMP DIAPHRAGM HIT-6684693.A13 6684693	£5.70	£6.84
128 - PUMP GASKET HIT-6684692.A104 6684692	£17.28	£20.73
129 - MAIN JET #38.5 HIT-6696130.A16 6696130	-
130 - O-RING HIT-6684695.A180 6684695	£1.67	£2.00
131 - STOP RING HIT-6684696.A14 6684696	-
132 - SWIVEL HIT-6684697.A147 6684697	-
133 - THROTTLE SET SCREW HIT-6684870.A58 6684870	-
134 - CABLE ADJUSTER STAY HIT-6684873.A21 6684873	-
135 - CLEANER PACKING HIT-6684875.A22 6684875	-
136 - SET SCREW HIT-6684699.A96 6684699	-
137 - THRUST WASHER HIT-6684874.A58 6684874	-
138 - INLET SCREEN HIT-6684700.A7 6684700	-
151 - CLUTCH DRUM COMP. HIT-6688580.A1 6688580	£16.79	£20.15
152 - STOP RING C-12 OUTER HIT-6684664.A49 6684664	£1.67	£2.00
153 - CUSHION RUBBER HIT-6691823.A2 6691823	£3.56	£4.27
154 - HEX. HOLE BOLT 5X16 HIT-6695046.A26 6695046	£1.67	£2.00
155 - HEX. HOLE BOLT M5X25/S HIT-6684709.A198 6684709	£1.67	£2.00
156 - FAN CASE COMP. HIT-6686959.A2 6686959	£25.96	£31.15
157 - PIPE HOLDER 1 HIT-6689651.A11 6689651	£8.88	£10.66
158 - WASHER M5 (BLACK) HIT-6684918.A85 6684918	£1.67	£2.00
159 - GEAR CASE WASHER HIT-6689159.A38 6689159	-
160 - METAL FITTING HIT-6689664.A10 6689664	£6.12	£7.35
181 - DRIVE SHAFT 1829L HIT-6689443.A1 6689443	-
182 - MAIN PIPE COMP HIT-6699653.A1 6699653	£41.18	£49.42
183 - BUSH ASS'Y HIT-6697839.A6 6697839	-
184 - HEX.NUT 6 HIT-6684835.A10 6684835	£1.67	£2.00
185 - LOOP HANDLE BLACK HIT-6691046.A12 6691046	£16.30	£19.56
186 - HANDLE BRACKET A HIT-6691134.A7 6691134	£3.10	£3.72
187 - HANDLE GRIP HIT-6691098.A31 6691098	£10.90	£13.08
188 - BOLT 6X43/P (BLACK) HIT-6684838.A36 6684838	£1.67	£2.00
189 - TAPPING SCREW 5X20 HIT-6695255.A18 6695255	-
190 - BRAKE SHAFT WASHER HIT-6689681.A22 6689681	£1.67	£2.00
191 - HANGER D24 HIT-6689277.A7 6689277	-
192 - THROTTLE LEVER ASS'Y 24 HIT-6693773.A0 6693773	-
193 - THROTTLE WIRE COMP HIT-6693984.A0 6693984	£30.57	£36.68
194 - THROTTLE WIRE 4T HIT-6694026.A2 6694026	£16.77	£20.12
195 - STOP SWITCH COMP HIT-6687463.A1 6687463	-
196 - PROTECTION TUBE 7X175 HIT-6687526.A1 6687526	-
197 - TRIGGER LOCK OUT HIT-6684721.A12 6684721	£5.17	£6.20
198 - RETURN SPRING HIT-6684722.A36 6684722	£1.67	£2.00
199 - SCREW M5X20 HIT-6684803.A22 6684803	-
200 - CONTAL NUT 5 HIT-6684727.A11 6684727	£1.67	£2.00
201 - SCREW M4X20 (BLACK) HIT-6684725.A1 6684725	-
202 - THROTTLE LEVER HIT-6684804.A8 6684804	£6.86	£8.23
221 - OIL TANK COVER HIT-6686138.A3 6686138	£2.81	£3.37
222 - COLLAR 3 HIT-6699273.A5 6699273	-
223 - OIL TANK PACKING HIT-6699567.A6 6699567	£2.77	£3.32
224 - O-RING P-5 HIT-6695661.A18 6695661	£1.67	£2.00
225 - STEP BOLT A HIT-6689757.A10 6689757	-
226 - OIL PUMP COMP. HIT-6686487.A6 6686487	£39.35	£47.22
227 - O-RING P-5 HIT-6695661.A19 6695661	£1.67	£2.00
228 - OIL PUMP SPRING HIT-6690381.A5 6690381	-
229 - OIL PUMP PISTON COMP. HIT-6686608.A6 6686608	-
230 - TANK PACKING ASS'Y HIT-6699566.A1 6699566	£3.48	£4.17
231 - FUEL PIPE 3X5X60 HIT-6692414.A4 6692414	-
232 - SMALL SCREW 4X12WS HIT-6695403.A18 6695403	-
233 - WASHER 5 HIT-6684661.A9 6684661	£1.67	£2.00
234 - OIL FILTER HIT-6690917.A1 6690917	£1.67	£2.00
235 - FILTER ASS'Y HIT-6690913.A7 6690913	-
236 - FUEL PIPE 3X5X75 HIT-6692415.A7 6692415	-
237 - OIL PUMP ADJUSTER HIT-6691066.A7 6691066	£8.79	£10.55
238 - O-RING P-5 HIT-6695661.A17 6695661	£1.67	£2.00
239 - STOP RING E-6 HIT-6695311.A10 6695311	£1.67	£2.00
240 - OIL TANK CAP ASS'Y HIT-6692050.A5 6692050	£15.87	£19.04
241 - BANJO 1 HIT-6686637.A5 6686637	-
242 - O-RING P-15 HIT-6698966.A14 6698966	£1.67	£2.00
243 - 8 PUSH NUT HIT-6695239.A7 6695239	-
244 - WASHER 2 HIT-6695187.A11 6695187	-
245 - O-RING 1.4 HIT-6695656.A8 6695656	-
261 - HEX. HOLE BOLT 5X22/S HIT-6695492.A23 6695492	-
262 - HEX. HOLE BOLT 5X10 HIT-6695042.A6 6695042	£1.67	£2.00
263 - SCREW 6X8 HIT-6695458.A1 6695458	-
264 - CASE HIT-6685793.A4 6685793	£12.52	£15.03
265 - GEAR PINION SET SPARE HIT-6688836.A5 6688836	-
266 - BALL BEARING 609 HIT-6684734.A30 6684734	-
267 - BALL BEARING 609Z ST HIT-6684735.A10 6684735	£15.48	£18.57
268 - STOP RING C-9 1 HIT-6695281.A20 6695281	-
269 - STOP RING C-24 1 HIT-6684732.A38 6684732	£1.67	£2.00
271 - BALL BEARING 627 C3 HIT-6695568.A10 6695568	£8.95	£10.74
272 - BALL BEARING 638Z HIT-6697603.A2 6697603	-
273 - STOP RING C-28 1 HIT-6684741.A4 6684741	-
274 - SPROCKET COMP. 1 HIT-6689117.A5 6689117	£47.37	£56.84
275 - FLANGE NUT 6 HIT-6695170.A39 6695170	£1.67	£2.00
276 - SIDE COVER COMP. HIT-6686038.A10 6686038	£9.67	£11.60
277 - CHAIN BAR CLAMP NUT HIT-6687105.A24 6687105	£1.67	£2.00
278 - CHAIN BAR KNOCK PIN HIT-6687130.A11 6687130	-
279 - GUIDE PLATE HIT-6697596.A9 6697596	£4.38	£5.26
280 - CHAIN BAR TIGHTENING BOLT HIT-6686803.A6 6686803	£8.53	£10.24
281 - CHAIN TENSIONER HIT-6687063.A3 6687063	£5.70	£6.84
282 - CAM HIT-6690428.A7 6690428	-
283 - COLLAR HIT-6685962.A7 6685962	-
501 - COMBI. BOX SPANNER 13X19 MINUS HIT-6693809.A32 6693809	-
502 - WRENCH 8X10 HIT-6684766.A20 6684766	-
503 - GUIDE BAR COVER 1 HIT-6694796.A7 6694796	£11.79	£14.15
504 - HEX. BAR WRENCH 4MM HIT-6684813.A15 6684813	-
505 - SHOULDER BELT HIT-6692867.A0 6692867	£8.37	£10.04
506 - SAW CHAIN HIT-6699679.A4 6699679	£20.67	£24.80
507 - CHAIN BAR 10 HIT-6686882.A2 6686882	£28.68	£34.41
601 - SYMBOL MARK TPS-270PFS HIT-6699682.A0 6699682	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TPS-270PFS Engine Pole Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TPS-270PFS Engine Pole Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TPS-270PFS Engine Pole Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
