Hitachi / Hikoki TPH-270S Engine Pole Hedge Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TPH-270S Engine Pole Hedge Trimmer

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A6 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A18 6699319	-
3 - CYLINDER SET HIT-6685493.A1 6685493	£72.13	£86.56
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A72 6684586	-
5 - CYLINDER GASKET T=1.0 HIT-6685750.A8 6685750	£2.81	£3.37
6 - PISTON RING HIT-6686121.A38 6686121	£6.47	£7.76
7 - PISTON SET HIT-6685902.A2 6685902	£30.58	£36.70
8 - CIR CLIP HIT-6684590.A35 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A62 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A19 6686219	£121.07	£145.28
12 - LEAD WIRE ASS'Y HIT-6687965.A6 6687965	£4.26	£5.11
13 - HEX. HOLE BOLT M4X18/WS TILL H124450 HIT-6684599.A20 6684599	-
13A - HIGH TENSION SCREW 4X18WS SINCE H124451 HIT-6695407.A46 6695407	-
14 - IGNITION COIL ASS'Y MB-55 HIT-6687684.A0 6687684	£35.79	£42.95
*21 - GEAR SHAFT SHIM 0.10 HIT-6689177.A32 6689177	-
*21 - GEAR SHAFT SHIM 0.15 HIT-6689178.A3 6689178	-
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A70 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A11 6684605	-
22 - MAGNETO ROTOR COMP. HIT-6687384.A1 6687384	-
23 - HEX. NUT M8 HIT-6684612.A31 6684612	-
24 - BOLT WASHER M8 HIT-6684611.A86 6684611	-
25 - CRANK CASE ASS'Y SPARE TILL D242450 HIT-6695886.A0 6695886	-
25A - CRANK CASE ASS'Y SINCE D242451 HIT-6684905.A3 6684905	£30.92	£37.11
26 - OIL SEAL TB 12227 HIT-6684607.A94 6684607	£4.07	£4.88
27 - BALL BEARING 6001 C3 HIT-6684608.A107 6684608	£5.70	£6.84
28A - CRANK CASE GASKET HIT-6684904.A19 6684904	£1.67	£2.00
29 - HEX. HOLE BOLT M5X16/S HIT-6684903.A23 6684903	-
41 - INLET MANIFOLD GASKET HIT-6689895.A6 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A7 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT M5X25WS HIT-6695515.A13 6695515	£1.67	£2.00
44 - CARBURETOR GASKET HIT-6684615.A34 6684615	£1.67	£2.00
45 - CABURETOR SET WYJ-431 HIT-6690519.A7 6690519	£113.54	£136.25
46 - CLEANER BODY COMP. HIT-6690120.A31 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A39 6690365	£1.67	£2.00
48 - CLEANER COVER ASS'Y HIT-6690421.A17 6690421	£14.48	£17.38
49A - COVER FIXING BOLT COMP. HIT-6698730.A33 6698730	£5.52	£6.63
50 - SCREW 5X57/S HIT-6695353.A27 6695353	£1.67	£2.00
51 - SMALL WASHER 5 HIT-6684864.A37 6684864	-
52 - CHOKE LEVER 1.5 HIT-6691281.A8 6691281	£1.67	£2.00
53 - CHOKE CONTROL LEVER HIT-6691239.A24 6691239	£2.98	£3.57
54 - TANK WHT HIT-6691602.A3 6691602	£13.82	£16.59
55 - COLLAR C HIT-6684623.A4 6684623	£1.67	£2.00
56 - RETURN GROMMET HIT-6697846.A28 6697846	£1.68	£2.01
57 - FUEL PIPE 3X5X65 HIT-6684626.A3 6684626	£1.67	£2.00
58A - PUMP FILTER BODY COMP HIT-66A3864.A21 66A3864	-
59 - CLIP D6 HIT-6685198.A27 6685198	-
60 - SHIELD TUBE 3X5X180 HIT-6684618.A10 6684618	£6.12	£7.35
61 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A64 6684634	£1.67	£2.00
62 - TANK CAP ASS'Y HIT-6685049.A42 6685049	£9.94	£11.93
63 - TANK CAP CHAIN HIT-6684625.A71 6684625	-
64 - STAND HIT-6694787.A14 6694787	£3.56	£4.27
65 - TAP SCREW 4X14 P HIT-6695280.A40 6695280	£1.67	£2.00
66 - BOLT WASHER M4 HIT-6685070.A11 6685070	£1.67	£2.00
71 - CYLINDER COVER HIT-6685690.A8 6685690	£5.70	£6.84
72 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A23 6695504	£1.67	£2.00
73 - HEX. HOLE BOLT M6X55 HIT-6684638.A9 6684638	£1.67	£2.00
74 - BOLT WASHER 6 HIT-6684639.A134 6684639	£1.67	£2.00
75 - MUFFLER SET HIT-6692498.A6 6692498	£25.72	£30.86
76 - MUFFLER GASKET HIT-6692732.A2 6692732	£1.67	£2.00
77 - MUFFLER PROTECTOR HIT-6692813.A0 6692813	£8.89	£10.67
78 - HEX. HOLE BOLT 4X18WS TILL H124450 HIT-6695508.A31 6695508	£1.67	£2.00
78A - SCREW 4X18/PS SINCE H124451 HIT-6695375.A0 6695375	-
79 - PLUG CAP HIT-6688345.A0 6688345	£4.99	£5.99
80 - CLUTCH WASHER B HIT-6684642.A27 6684642	£1.67	£2.00
81 - CLUTCH SHOE COMP. HIT-6684643.A9 6684643	£12.01	£14.41
82 - CLUTCH SPRING HIT-6684644.A15 6684644	£3.12	£3.74
83 - CLUTCH PLATE A 0.5 HIT-6684645.A10 6684645	£1.67	£2.00
84 - STEP BOLT HIT-6684646.A25 6684646	£3.72	£4.46
85 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A40 6684634	£1.67	£2.00
86 - BENT WASHER 8 HIT-6684648.A60 6684648	£1.67	£2.00
87 - CLUTCH SET ASS'Y HIT-6699640.A2 6699640	£15.92	£19.10
88 - TAPPING SCREW D4.5X16 HIT-6684636.A18 6684636	£1.67	£2.00
89 - HEAT SHIELD HIT-6687264.A9 6687264	-
101B - RECOIL STARTER BODY ASS'Y INCLUD.103-109 HIT-6601570.A1 6601570	£23.15	£27.78
103 - STARTER ROPE 3.5X860 HIT-6684674.A49 6684674	£5.70	£6.84
104 - RECOIL SPRING HIT-6684675.A70 6684675	£8.82	£10.58
105A - STARTER ROPE REEL SINCE TL026141 HIT-6699997.A25 6699997	-
106 - DAMPER SPRING HIT-6684677.A64 6684677	£5.70	£6.84
107A - CAM PLATE SINCE TL026141 HIT-6699996.A64 6699996	£4.28	£5.13
108 - SET SCREW HIT-6684679.A89 6684679	£2.98	£3.57
109 - STARTER HANDLE HIT-6684680.A53 6684680	£5.87	£7.04
110 - STARTER PULLEY ASS'Y HIT-6684681.A62 6684681	£18.16	£21.79
111 - D4E RETAINING RING HIT-6685101.A144 6685101	-
112 - STARTER PAWL SPRING HIT-6684684.A51 6684684	£3.29	£3.95
113 - STARTER PAWL HIT-6684685.A60 6684685	£5.07	£6.08
114 - HEX. HOLE BOLT 4X18WS TILL H124450 HIT-6695508.A43 6695508	£1.67	£2.00
114A - SCREW 4X18/PS SINCE H124451 HIT-6695375.A15 6695375	-
115 - CAMPLATE ASS'Y TILL TL026140 HIT-6699691.A47 6699691	£7.75	£9.30
121 - PUMP BODY COMP. HIT-6684879.A3 6684879	£35.37	£42.44
122 - PRIMING PUMP COMP. HIT-6684687.A40 6684687	£9.27	£11.12
123 - DIAPHRAGM COVER HIT-6684688.A59 6684688	£5.70	£6.84
124 - PRIMING BODY HIT-6684689.A39 6684689	£5.87	£7.04
125 - METERING DIAPHRAGM COMP. HIT-6690830.A8 6690830	£14.58	£17.50
126 - DIAPHRAGM GASKET HIT-6684691.A38 6684691	£5.70	£6.84
127 - PUMP DIAPHRAGM HIT-6684693.A91 6684693	£5.70	£6.84
128 - PUMP GASKET HIT-6684692.A64 6684692	£17.28	£20.73
129 - MAIN JET #43 HIT-6691848.A12 6691848	£8.77	£10.52
130 - O-RING HIT-6684695.A108 6684695	£1.67	£2.00
131 - STOP RING HIT-6684696.A97 6684696	-
132 - SWIVEL HIT-6684697.A88 6684697	-
133 - THROTTLE SET SCREW HIT-6684870.A77 6684870	-
134 - CABLE ADJUSTER STAY HIT-6684873.A1 6684873	-
135 - LOCK NUT M6 HIT-6684872.A89 6684872	-
136 - CABLE ADJUSTER HIT-6684871.A1 6684871	-
137 - CLEANER PACKING HIT-6684875.A2 6684875	-
138 - SET SCREW HIT-6684699.A57 6684699	-
139 - THRUST WASHER HIT-6684874.A78 6684874	-
140 - INLET SCREEN HIT-6684700.A115 6684700	-
151 - CLUTCH DRUM COMP. HIT-6688580.A6 6688580	£16.79	£20.15
152 - STOP RING C-12 OUTER HIT-6684664.A32 6684664	£1.67	£2.00
153 - CUSHION RUBBER HIT-6691823.A9 6691823	£3.56	£4.27
154 - HEX. HOLE BOLT 5X16 HIT-6695046.A17 6695046	£1.67	£2.00
155 - HEX. HOLE BOLT M5X25/S HIT-6684709.A142 6684709	£1.67	£2.00
156 - FAN CASE COMP. HIT-6686959.A6 6686959	£25.96	£31.15
157 - PIPE HOLDER 1 HIT-6689651.A22 6689651	£8.88	£10.66
158 - WASHER M5 (BLACK) HIT-6684918.A94 6684918	£1.67	£2.00
159 - GEAR CASE WASHER HIT-6689159.A54 6689159	-
160 - METAL FITTING HIT-6689664.A7 6689664	£6.12	£7.35
181 - DRIVE SHAFT 1483L HIT-6697879.A5 6697879	£17.94	£21.53
182 - DRIVE SHAFT PIPE COMP. HIT-6689386.A1 6689386	£52.12	£62.54
183 - BUSH ASS'Y HIT-6684831.A15 6684831	-
184 - HEX.NUT 6 HIT-6684835.A18 6684835	£1.67	£2.00
185 - LOOP HANDLE BLACK HIT-6691046.A8 6691046	£16.30	£19.56
186 - HANDLE BRACKET A HIT-6691134.A5 6691134	£3.10	£3.72
187 - HANDLE GRIP HIT-6691098.A17 6691098	£10.90	£13.08
188 - BOLT 6X43/P (BLACK) HIT-6684838.A24 6684838	£1.67	£2.00
189 - TAPPING SCREW 5X20 HIT-6695255.A2 6695255	-
190 - BRAKE SHAFT WASHER HIT-6689681.A39 6689681	£1.67	£2.00
191 - HANGER D24 HIT-6689277.A0 6689277	-
192 - SHOULDER BELT HIT-6692867.A7 6692867	£8.37	£10.04
196 - THROTTLE LEVER ASS'Y 1 HIT-6693764.A1 6693764	£45.00	£54.00
197 - THROTTLE WIRE COMP. HIT-6693978.A3 6693978	£22.29	£26.75
198 - THROTTLE WIRE HIT-6694022.A9 6694022	-
199 - STOP SWITCH COMP. HIT-6687459.A10 6687459	£17.33	£20.80
200 - PROTECTION TUBE 7X175 HIT-6687526.A10 6687526	-
201 - TRIGGER LOCK OUT HIT-6684721.A23 6684721	£5.17	£6.20
202 - RETURN SPRING HIT-6684722.A26 6684722	£1.67	£2.00
203 - THROTTLE STOPPER COMP. HIT-6693807.A2 6693807	-
204 - SCREW M5X20 HIT-6684803.A26 6684803	-
205 - CONTAL NUT 5 HIT-6684727.A22 6684727	£1.67	£2.00
206 - SCREW M4X20 (BLACK) HIT-6684725.A18 6684725	-
207 - THROTTLE LEVER HIT-6684804.A4 6684804	£6.86	£8.23
221 - GEAR CASE A 1 HIT-6688653.A3 6688653	£38.36	£46.03
222 - BALL BEARING 6901ZZ 2 HIT-6695582.A12 6695582	£15.31	£18.37
223 - STOP RING S-12 1 HIT-6695302.A3 6695302	£1.67	£2.00
224 - STOP RING C-24 1 HIT-6684732.A24 6684732	£1.67	£2.00
225 - BALL BEARING 608ZZC3 HIT-6698772.A25 6698772	£2.84	£3.41
226 - RETAINING RING C-TYPE D22 HIT-6695293.A12 6695293	£1.67	£2.00
227 - GREASE NIPPLE COMP. HIT-6688643.A47 6688643	£1.67	£2.00
228 - HEX. HOLE BOLT 5X10 HIT-6695042.A32 6695042	£1.67	£2.00
229 - HEX. HOLE BOLT M5X25/S HIT-6684709.A143 6684709	£1.67	£2.00
230 - HEX. HOLE BOLT 6X12 HIT-6695078.A6 6695078	£1.67	£2.00
231 - SPECIAL WASHER B HIT-6684822.A36 6684822	£1.67	£2.00
232 - GEAR CASE B HIT-6695981.A2 6695981	£40.62	£48.75
233 - BALL BEARING #6000DD 1 HIT-6695528.A0 6695528	-
234 - RETAINING RING C-TYPE D26 HIT-6695294.A27 6695294	-
236 - RETAINING RING E-TYPE D6 HIT-6695310.A5 6695310	£1.67	£2.00
237 - GEAR CASE COVER (A) HIT-6689167.A7 6689167	-
238 - HEX HOLE BOLT 4X8 HIT-6695035.A8 6695035	-
239 - BALL BEARING 608ZZC3 HIT-6698772.A24 6698772	£2.84	£3.41
240 - RETAINING RING C-TYPE D22 HIT-6695293.A11 6695293	£1.67	£2.00
241 - HANDLE HIT-6688089.A1 6688089	£7.75	£9.30
242 - HEX HOLE BUTTON SCREW 6X15 HIT-6695079.A14 6695079	£1.67	£2.00
243 - GREASE STOP (D) HIT-6686669.A2 6686669	£1.67	£2.00
244 - GEAR SET PN HIT-6696411.A2 6696411	£97.03	£116.44
245 - HANDLE KNOB A COMP. HIT-6691200.A8 6691200	£12.10	£14.52
246 - PLUS BOLT 6X14 HIT-6695016.A17 6695016	-
247 - LOCK NUT 6 UPS-P HIT-6695175.A17 6695175	£1.67	£2.00
248 - SUPPORT PLATE HIT-6690744.A5 6690744	£17.82	£21.39
249 - GREASE STOP (B) HIT-6686659.A1 6686659	£1.67	£2.00
251 - BOLT WASHER 6 HIT-6684639.A68 6684639	£1.67	£2.00
261 - CAM SHAFT COMP. HIT-6686790.A12 6686790	£62.78	£75.33
262 - CAM ROD HIT-6686809.A4 6686809	£11.92	£14.30
263 - CAM-ROD GUIDE PLATE HIT-6686611.A3 6686611	£2.98	£3.57
264 - CUTTER GUIDE 625.5MM HIT-6687125.A14 6687125	£37.68	£45.21
265 - CUTTER (A) HIT-6687079.A10 6687079	£46.75	£56.10
266 - FIXING BOLT A M6 HIT-6687158.A44 6687158	£1.67	£2.00
267 - WASHER 7 BLACK HIT-6687187.A33 6687187	£1.67	£2.00
268 - FLANGE NUT 6 HIT-6695170.A16 6695170	£1.67	£2.00
269 - HEX HOLE FLUSH SCREW 6X16 HIT-6695073.A8 6695073	£1.67	£2.00
270 - GREASE STOP (A) HIT-6686647.A9 6686647	£1.67	£2.00
271 - CAM ROD PLATE HIT-6686826.A7 6686826	£1.67	£2.00
272 - GEAR CASE COVER B HIT-6689172.A3 6689172	£15.41	£18.49
273 - BALL BEARING 608 ZZ C3 HIT-6695547.A20 6695547	£10.17	£12.20
274 - HEX. HOLE BOLT 4X10S HIT-6695484.A33 6695484	£1.67	£2.00
275 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A32 6684595	£1.67	£2.00
276 - CUTTER COVER HIT-6687301.A13 6687301	-
277 - CUTTER FIXING BOLT B HIT-6687162.A17 6687162	£1.67	£2.00
278 - HEX. HOLE FLUSH BOLT 6X25 HIT-6695075.A12 6695075	£1.67	£2.00
279 - GREASE STOP (C) HIT-6686666.A3 6686666	-
280 - SPACER HIT-6688633.A6 6688633	-
282 - LOCK NUT 6 UPS-P HIT-6695175.A18 6695175	£1.67	£2.00
283 - BOLT WASHER 6 HIT-6684639.A67 6684639	£1.67	£2.00
501 - COMBI. BOX SPANNER 10X19 1 HIT-6685997.A16 6685997	-
502 - HEX. BAR WRENCH 4MM HIT-6684813.A38 6684813	-
601 - SYMBOL MARK TPH-270S HIT-6696265.A0 6696265	-
602 - S?START MARK HIT-6694472.A5 6694472	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TPH-270S Engine Pole Hedge Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TPH-270S Engine Pole Hedge Trimmer Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TPH-270S Engine Pole Hedge Trimmer Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
