1 - SPARK PLUG CAP ASS'Y
HIT-6687468.A87
6687468
|
£3.64
|
£4.37
|
|
|
*2 - SPARK PLUG ASS'Y RCJ6Y FOR EUROPE
HIT-6699326.A1
6699326
|
£5.70
|
£6.84
|
|
|
*2 - SPARK PLUG ASS'Y CJ6Y FOR USA
HIT-6699323.A9
6699323
|
-
|
|
|
|
3 - CYLINDER SET
HIT-6685491.A4
6685491
|
-
|
|
|
|
4 - HEX. HOLE BOLT M5X16/S
HIT-6684903.A17
6684903
|
-
|
|
|
|
5 - CYLINDER GASKET
HIT-6685749.A0
6685749
|
-
|
|
|
|
6 - PISTON RING (XR1-1856)
HIT-6685331.A15
6685331
|
£12.57
|
£15.08
|
|
|
7 - PISTON SET
HIT-6685898.A2
6685898
|
£37.49
|
£44.99
|
|
|
8 - CIRCLIP
HIT-6685078.A17
6685078
|
-
|
|
|
|
9 - PISTON PIN
HIT-6686008.A5
6686008
|
£3.64
|
£4.37
|
|
|
10 - CRANK SHAFT COMP
HIT-6696499.A1
6696499
|
-
|
|
|
|
11 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A74
6684899
|
-
|
|
|
|
13 - STOP CORD B160M
HIT-6687874.A0
6687874
|
-
|
|
|
|
14A - HIGH TENSION SCREW 4X18WS
HIT-6695407.A63
6695407
|
-
|
|
|
|
15 - WASHER T1.6
HIT-6684600.A68
6684600
|
-
|
|
|
|
16 - IGNITION COIL ASS'Y
HIT-6687719.A1
6687719
|
-
|
|
|
|
17 - HIGH TENSION CORD
HIT-6687891.A0
6687891
|
-
|
|
|
|
18 - RUBBER CAP
HIT-6684602.A0
6684602
|
-
|
|
|
|
*31 - GEAR SHAFT SHIM 0.20
HIT-6684604.A81
6684604
|
-
|
|
|
|
*31 - GEAR SHAFT SHIM 0.30
HIT-6684605.A0
6684605
|
-
|
|
|
|
32 - MAGNETO ROTOR COMP.
HIT-6687375.A8
6687375
|
-
|
|
|
|
33 - HEX. NUT M8
HIT-6684612.A9
6684612
|
-
|
|
|
|
34 - SMALL WASHER 8
HIT-6695184.A4
6695184
|
-
|
|
|
|
35 - CRANK CASE ASS'Y TILL J014620
HIT-6686586.A1
6686586
|
-
|
|
|
|
35A - CRANK CASE ASS'Y SINCE J014621
HIT-6699279.A4
6699279
|
-
|
|
|
|
36 - OIL SEAL TB 12227
HIT-6684607.A26
6684607
|
£4.07
|
£4.88
|
|
|
37 - BALL BEARING 6001 C3
HIT-6684608.A171
6684608
|
£5.70
|
£6.84
|
|
|
38 - CRANK CASE GASKET TILL J014620
HIT-6686723.A2
6686723
|
-
|
|
|
|
38A - CRANK CASE GASKET SINCE J014621
HIT-6699280.A0
6699280
|
-
|
|
|
|
39 - HEX. HOLE BOLT M5X16/S TILL J014620
HIT-6684903.A18
6684903
|
-
|
|
|
|
39A - HEX. HOLE BOLT M5X16/S SINCE J014621
HIT-6684903.A19
6684903
|
-
|
|
|
|
40 - BOLT WASHER M8
HIT-6684611.A106
6684611
|
-
|
|
|
|
61 - INLET MANIFOLD GASKET
HIT-6689895.A11
6689895
|
£1.67
|
£2.00
|
|
|
62 - INSULATOR SET
HIT-6689972.A11
6689972
|
£6.59
|
£7.91
|
|
|
63 - HEX. HOLE BOLT M5X25WS
HIT-6695515.A2
6695515
|
£1.67
|
£2.00
|
|
|
64 - WIRE RETURN SPRING
HIT-6694055.A2
6694055
|
-
|
|
|
|
65 - CARBURETOR PACKING
HIT-6684616.A10
6684616
|
£1.67
|
£2.00
|
|
|
66 - CHOKE PLATE 2.0
HIT-6691276.A7
6691276
|
£1.67
|
£2.00
|
|
|
67 - CLEANER BODY COMP.
HIT-6690120.A23
6690120
|
£12.32
|
£14.78
|
|
|
68 - CLEANER SPONGE
HIT-6690365.A33
6690365
|
£1.67
|
£2.00
|
|
|
69 - CLEANER COVER ASS'Y
HIT-6690402.A1
6690402
|
£12.16
|
£14.59
|
|
|
70 - COVER FIXING BOLT COMP.
HIT-6698730.A43
6698730
|
£5.52
|
£6.63
|
|
|
71 - SCREW 5X57/S
HIT-6695353.A34
6695353
|
£1.67
|
£2.00
|
|
|
72 - SMALL WASHER 5
HIT-6684864.A60
6684864
|
-
|
|
|
|
73 - CARBURETOR SET WYJ464
HIT-6690516.A0
6690516
|
-
|
|
|
|
74 - CHOKE CONTROL LEVER
HIT-6691239.A22
6691239
|
£2.98
|
£3.57
|
|
|
75 - TANK F T
HIT-6699336.A1
6699336
|
£31.02
|
£37.23
|
|
|
76 - COLLAR 5.8
HIT-6692244.A70
6692244
|
£1.67
|
£2.00
|
|
|
77 - RETURN GROMMET
HIT-6697846.A69
6697846
|
£2.08
|
£2.50
|
|
|
78 - FUEL PIPE 3X5X85
HIT-6684880.A6
6684880
|
-
|
|
|
|
79A - PUMP FILTER BODY COMP
HIT-66A3864.A29
66A3864
|
-
|
|
|
|
80 - CLIP D6
HIT-6685198.A10
6685198
|
-
|
|
|
|
*81A - SHIELD TUBE 3X5X180 FOR EUROPE
HIT-6684618.A3
6684618
|
£6.12
|
£7.35
|
|
|
*81A - SHIELD TUBE SET FOR USA
HIT-6698970.A2
6698970
|
-
|
|
|
|
82 - HEX. HOLE BOLT M5X25/S
HIT-6684709.A44
6684709
|
£1.67
|
£2.00
|
|
|
83 - HEX. HOLE BOLT 5X16/PS
HIT-6695504.A8
6695504
|
£1.67
|
£2.00
|
|
|
84 - TANK CAP ASS'Y FOR EUROPE
HIT-6685049.A33
6685049
|
£9.94
|
£11.93
|
|
|
85 - TAP SCREW 4X14 P
HIT-6695280.A54
6695280
|
£1.67
|
£2.00
|
|
|
86 - BOLT WASHER M4
HIT-6685070.A21
6685070
|
£1.67
|
£2.00
|
|
|
87 - WASHER M5 (BLACK)
HIT-6684918.A22
6684918
|
£1.67
|
£2.00
|
|
|
88 - TANK FIXING COLLAR
HIT-6692183.A1
6692183
|
-
|
|
|
|
89 - S.WASHER 5 TILL J091800
HIT-6684662.A2
6684662
|
£1.67
|
£2.00
|
|
|
90 - TANK CAP CHAIN FOR EUROPE
HIT-6684625.A93
6684625
|
-
|
|
|
|
91 - TANK CAP D ASS'Y FOR USA
HIT-6691748.A18
6691748
|
£6.04
|
£7.25
|
|
|
101 - CYLINDER COVER BLK
HIT-6685689.A1
6685689
|
-
|
|
|
|
102A - SCREW 5X16/PS
HIT-6695386.A11
6695386
|
£1.67
|
£2.00
|
|
|
103 - HEX. HOLE BOLT M6X65
HIT-6695067.A42
6695067
|
£1.67
|
£2.00
|
|
|
104 - BOLT WASHER 6
HIT-6684639.A191
6684639
|
£1.67
|
£2.00
|
|
|
*105 - MUFFLER COMP FOR EUROPE
HIT-6699602.A3
6699602
|
-
|
|
|
|
*105 - MUFFLER COMP. FOR USA
HIT-6692575.A4
6692575
|
-
|
|
|
|
106 - TAIL PIPE SET
HIT-6692716.A0
6692716
|
-
|
|
|
|
107 - SCREW M4X8/WS
HIT-6684651.A2
6684651
|
-
|
|
|
|
108 - SPARK ARRESTER
HIT-6692702.A9
6692702
|
-
|
|
|
|
109 - MUFFLER SPECIAL GASKET
HIT-6692886.A10
6692886
|
-
|
|
|
|
110 - MUFFLER PROTECTOR BLK
HIT-6692812.A1
6692812
|
£12.48
|
£14.97
|
|
|
111A - SCREW 4X14/PS
HIT-6695372.A1
6695372
|
-
|
|
|
|
112 - CLUTCH ARM COMP.
HIT-6688610.A8
6688610
|
£13.94
|
£16.73
|
|
|
113 - CLUTCH SPRING
HIT-6689420.A3
6689420
|
£2.81
|
£3.37
|
|
|
114 - CLUTCH WASHER B
HIT-6689645.A57
6689645
|
£1.67
|
£2.00
|
|
|
115 - WAVE WASHER 10
HIT-6695203.A18
6695203
|
£1.67
|
£2.00
|
|
|
116 - CLUTCH STEP BOLT
HIT-6689628.A3
6689628
|
£3.29
|
£3.95
|
|
|
117A - SCREW 5X20/WS
HIT-6695421.A3
6695421
|
-
|
|
|
|
*118 - FAN CASE TILL J014620
HIT-6687021.A1
6687021
|
-
|
|
|
|
*118 - FAN CASE SINCE J014621
HIT-6687033.A0
6687033
|
-
|
|
|
|
119 - STUD BOLT 6X36
HIT-6686772.A1
6686772
|
-
|
|
|
|
120 - PRIMARY CORD GROMMET
HIT-6688057.A6
6688057
|
-
|
|
|
|
121 - HEAT SHIELD
HIT-6687263.A4
6687263
|
-
|
|
|
|
122 - AIR DEFLECTOR
HIT-6687213.A0
6687213
|
-
|
|
|
|
123 - TAPPING SCREW 4X14
HIT-6684751.A31
6684751
|
£1.67
|
£2.00
|
|
|
124 - CLUTCH SET ASS'Y
HIT-6688482.A2
6688482
|
-
|
|
|
|
141 - RECOIL STARTER BODY ASS'Y
HIT-6692991.A7
6692991
|
£33.01
|
£39.61
|
|
|
142 - RECOIL STARTER BODY COMP.
HIT-6693040.A6
6693040
|
£11.14
|
£13.37
|
|
|
143 - STARTER ROPE 3.5X860
HIT-6684674.A18
6684674
|
£5.70
|
£6.84
|
|
|
144 - RECOIL SPRING
HIT-6684675.A123
6684675
|
£8.82
|
£10.58
|
|
|
145 - STARTER PULLEY
HIT-6693081.A2
6693081
|
-
|
|
|
|
146 - DAMPER SPRING
HIT-6684677.A23
6684677
|
£6.66
|
£7.99
|
|
|
147 - CAM PLATE
HIT-6692937.A0
6692937
|
-
|
|
|
|
148 - SET SCREW
HIT-6684679.A14
6684679
|
£2.98
|
£3.57
|
|
|
149 - STARTER HANDLE
HIT-6684680.A103
6684680
|
£5.87
|
£7.04
|
|
|
151 - STARTER PULLEY ASS'Y
HIT-6684681.A12
6684681
|
£18.16
|
£21.79
|
|
|
152 - SCREW 4X18/PS
HIT-6695375.A14
6695375
|
-
|
|
|
|
153 - D4E RETAINING RING
HIT-6685101.A63
6685101
|
-
|
|
|
|
154 - STARTER PAWL SPRING
HIT-6684684.A105
6684684
|
£3.29
|
£3.95
|
|
|
155 - STARTER PAWL
HIT-6684685.A12
6684685
|
£5.07
|
£6.08
|
|
|
171 - PUMP BODY COMP.
HIT-6684879.A71
6684879
|
£35.37
|
£42.44
|
|
|
172 - PRIMING PUMP COMP.
HIT-6684687.A93
6684687
|
£9.27
|
£11.12
|
|
|
173 - DIAPHRAGM COVER
HIT-6684688.A6
6684688
|
£5.70
|
£6.84
|
|
|
174 - PRIMING BODY
HIT-6684689.A95
6684689
|
£5.87
|
£7.04
|
|
|
175 - METERING DIAPHRAGM COMP.
HIT-6690830.A59
6690830
|
£14.58
|
£17.50
|
|
|
176 - DIAPHRAGM GASKET
HIT-6684691.A93
6684691
|
£5.70
|
£6.84
|
|
|
177 - PUMP DIAPHRAGM
HIT-6684693.A192
6684693
|
£5.70
|
£6.84
|
|
|
178 - PUMP GASKET
HIT-6691457.A71
6691457
|
£8.48
|
£10.18
|
|
|
179 - MAIN JET #38.5
HIT-6696130.A1
6696130
|
-
|
|
|
|
180 - O-RING
HIT-6684695.A12
6684695
|
£1.67
|
£2.00
|
|
|
181 - STOP RING
HIT-6684696.A205
6684696
|
-
|
|
|
|
182 - SWIVEL
HIT-6684697.A14
6684697
|
-
|
|
|
|
183 - THROTTLE SET SCREW
HIT-6684870.A15
6684870
|
-
|
|
|
|
184 - CABLE ADJUSTER STAY
HIT-6684873.A58
6684873
|
-
|
|
|
|
185 - CLEANER PACKING
HIT-6684875.A60
6684875
|
-
|
|
|
|
186 - SET SCREW
HIT-6684699.A6
6684699
|
-
|
|
|
|
187 - THRUST WASHER
HIT-6684874.A15
6684874
|
-
|
|
|
|
188 - INLET SCREEN
HIT-6684700.A226
6684700
|
-
|
|
|
|
211 - CLUTCH HOUSING COMP.
HIT-6688203.A1
6688203
|
-
|
|
|
|
212 - GEAR CASE A
HIT-6688029.A1
6688029
|
-
|
|
|
|
213 - GEAR CASE GASKET B
HIT-6688059.A1
6688059
|
-
|
|
|
|
214 - SPRING NUT 6
HIT-6695475.A30
6695475
|
-
|
|
|
|
215 - GEAR 2
HIT-6688136.A1
6688136
|
-
|
|
|
|
216 - BALL BEARING #6202Z 1
HIT-6695559.A17
6695559
|
£12.76
|
£15.31
|
|
|
217 - BALL BEARING #6202 1
HIT-6695557.A14
6695557
|
-
|
|
|
|
218 - STOP RING C-15 1
HIT-6695285.A51
6695285
|
£1.67
|
£2.00
|
|
|
220 - GEAR CASE B
HIT-6688035.A1
6688035
|
-
|
|
|
|
221 - GEAR CASE GASKET C
HIT-6688063.A2
6688063
|
-
|
|
|
|
222 - SCREW 5X30/S
HIT-6695345.A3
6695345
|
-
|
|
|
|
223 - WOOD-RUFF KEY 3X13X5.0
HIT-6686459.A2
6686459
|
-
|
|
|
|
224 - BALL BEARING #6000 3
HIT-6695524.A46
6695524
|
-
|
|
|
|
225 - BOLT WASHER 6
HIT-6684639.A190
6684639
|
£1.67
|
£2.00
|
|
|
226 - SCREW 6X8
HIT-6694923.A0
6694923
|
-
|
|
|
|
227 - STOP RING C-17 1
HIT-6695286.A0
6695286
|
-
|
|
|
|
228 - GEAR 3
HIT-6688162.A0
6688162
|
-
|
|
|
|
241 - GEAR 4
HIT-6688179.A1
6688179
|
-
|
|
|
|
242 - DRIVE SHAFT
HIT-6688189.A1
6688189
|
-
|
|
|
|
243 - KNOCK PIN 4X12
HIT-6695521.A28
6695521
|
-
|
|
|
|
244 - GEAR CASE C
HIT-6688043.A1
6688043
|
-
|
|
|
|
245 - SCREW 5X50
HIT-6694910.A1
6694910
|
-
|
|
|
|
246 - S.WASHER 5
HIT-6684662.A3
6684662
|
£1.67
|
£2.00
|
|
|
247 - SCREW 5X30/S
HIT-6695345.A2
6695345
|
-
|
|
|
|
248 - THRUST BEARING 2035
HIT-6695617.A2
6695617
|
-
|
|
|
|
249 - GEAR SHAFT COLLAR A
HIT-6688223.A1
6688223
|
-
|
|
|
|
250 - BALL BEARING 6904ZZ C3
HIT-6695584.A1
6695584
|
-
|
|
|
|
251 - STOP RING C-37 1
HIT-6695297.A2
6695297
|
-
|
|
|
|
252 - GEAR SHAFT COLLAR B
HIT-6688234.A1
6688234
|
-
|
|
|
|
*253 - PIN FOR EUROPE
HIT-6693553.A1
6693553
|
-
|
|
|
|
*253 - PIN FOR USA
HIT-6693554.A4
6693554
|
-
|
|
|
|
254 - SNAP PIN 8
HIT-6693558.A10
6693558
|
-
|
|
|
|
255 - BOLT WASHER M8
HIT-6684611.A105
6684611
|
-
|
|
|
|
271 - HANDLE ASS'Y
HIT-6686254.A2
6686254
|
-
|
|
|
|
272 - S.WASHER 6
HIT-6695219.A82
6695219
|
£1.67
|
£2.00
|
|
|
273 - PLUS BOLT 6X18
HIT-6695020.A2
6695020
|
-
|
|
|
|
274 - CORD CLAMP
HIT-6688015.A14
6688015
|
-
|
|
|
|
275 - THROTTLE LEVER ASS'Y
HIT-6693695.A1
6693695
|
£20.08
|
£24.09
|
|
|
276 - STOP SWITCH ASS'Y
HIT-6687434.A1
6687434
|
-
|
|
|
|
277 - STOP BUTTON BRACKET
HIT-6692138.A2
6692138
|
-
|
|
|
|
278 - STOP BUTTON MARK
HIT-6694589.A5
6694589
|
£3.37
|
£4.04
|
|
|
279 - PLUS BOLT 6X30
HIT-6695022.A7
6695022
|
£1.67
|
£2.00
|
|
|
280 - NUT M6
HIT-6684792.A20
6684792
|
-
|
|
|
|
281 - SPECIAL WASHER B
HIT-6684822.A4
6684822
|
£1.67
|
£2.00
|
|
|
282 - THROTTLE LEVER BAND
HIT-6693808.A1
6693808
|
-
|
|
|
|
283 - SQUARE NUT 6
HIT-6696512.A2
6696512
|
-
|
|
|
|
284 - THROTTLE ARM
HIT-6693801.A2
6693801
|
-
|
|
|
|
285 - PROTECTION TUBE 10X42
HIT-6687578.A1
6687578
|
-
|
|
|
|
286 - SPLIT PROTECTION TUBE 13X150L
HIT-6687602.A1
6687602
|
-
|
|
|
|
287 - THROTTLE WIRE 640+45
HIT-6693927.A1
6693927
|
-
|
|
|
|
288 - BUTTON STOP
HIT-6688366.A21
6688366
|
£1.67
|
£2.00
|
|
|
289 - SCREW 3X10
HIT-6684913.A6
6684913
|
£1.67
|
£2.00
|
|
|
501 - SPANNER 10X13 TILL K050860
HIT-6693479.A2
6693479
|
-
|
|
|
|
502 - COMBI. BOX SPANNER 10X19 1
HIT-6685997.A1
6685997
|
-
|
|
|
|
601 - NAME PLATE TIA-350PFS
HIT-6694234.A0
6694234
|
-
|
|
|
