An exploded diagram and spare parts listing for the Hitachi / Hikoki THT-2540 Engine Hedge Trimmer
Ex VAT Inc VAT
1 - SPARK PLUG CAP HIT-6687476.A14 6687476 -
2 - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A27 6699328 £5.70 £6.84
3 - CYLINDER ASS'Y HIT-6685481.A1 6685481 £68.00 £81.60
4 - HEX.HOLE BOLT M5X18/S TILL G146930 HIT-6684586.A26 6684586 -
4A - HEX.HOLE BOLT M5X20/S SINCE G146931 HIT-6684668.A67 6684668 -
5 - CYLINDER GASKET HIT-6685744.A15 6685744 £1.67 £2.00
6 - PISTON RING HIT-6684588.A7 6684588 £6.38 £7.66
7 - PISTON ASS'Y HIT-6685893.A4 6685893 £34.72 £41.67
8 - PISTON PIN HIT-6684591.A23 6684591 £3.29 £3.95
9 - PISTON PIN CIRCLIP HIT-6686028.A4 6686028 -
10 - CRANK SHAFT COMP. HIT-6686205.A7 6686205 £145.70 £174.84
11 - IGNITION COIL ASS'Y HIT-6695927.A5 6695927 £30.92 £37.11
12 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A59 6684599 -
13 - INSULATOR TUBE 50L HIT-6684597.A7 6684597 -
14 - CORD HIT-6687866.A5 6687866 -
15 - IGNITION COIL COMP HIT-6695939.A3 6695939 £34.64 £41.57
16 - CORD HIT-6688477.A6 6688477 £8.18 £9.81
21 - CRANK CASE ASS'Y HIT-6601159.A1 6601159 -
22 - CRANK CASE GASKET HIT-6686720.A7 6686720 -
23 - OIL SEAL TB 12227 HIT-6684607.A115 6684607 £4.07 £4.88
24 - BALL BEARING 6001 C3 HIT-6684608.A85 6684608 £5.70 £6.84
*25 - GEAR SHAFT SHIM 0.10 HIT-6689177.A15 6689177 -
*25 - GEAR SHAFT SHIM 0.15 HIT-6689178.A20 6689178 -
*25 - GEAR SHAFT SHIM 0.20 HIT-6684604.A25 6684604 -
*25 - GEAR SHAFT SHIM 0.30 HIT-6684605.A56 6684605 -
27 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A26 6684786 £1.67 £2.00
28 - MAGNETO ROTOR COMP. HIT-6687389.A11 6687389 -
29 - BOLT WASHER M8 HIT-6684611.A40 6684611 -
30 - S.WASHER 8 HIT-6684971.A2 6684971 -
31 - HEX. NUT M8 HIT-6684612.A85 6684612 -
32 - STUD BOLT 6X22 HIT-6686771.A3 6686771 -
41 - INTAKE PIPE GASKET HIT-6689891.A19 6689891 £3.38 £4.06
42 - CARB. INSULATOR SET 1 HIT-6689966.A15 6689966 £13.22 £15.87
43 - HEX. HOLE BOLT M5X25WS HIT-6695515.A51 6695515 £1.67 £2.00
44 - CARBURETOR GASKET HIT-6689839.A5 6689839 £2.98 £3.57
45 - O-RING P-15 HIT-6698966.A18 6698966 £1.67 £2.00
46 - CLEANER BODY COMP. HIT-6690119.A14 6690119 £8.95 £10.74
47 - COLLAR 7.5 HIT-6690804.A4 6690804 £1.67 £2.00
48 - CHOKE VALVE TILL B028600 HIT-6691272.A11 6691272 £1.67 £2.00
48A - CHOKE VALVE SINCE B028601 HIT-6691274.A1 6691274 -
49 - WAVE WASHER 8 HIT-6684658.A48 6684658 £1.67 £2.00
50 - BLOW OVER CHECK BOARD HIT-6690843.A7 6690843 £1.67 £2.00
51 - S.WASHER 5 HIT-6684662.A87 6684662 £1.67 £2.00
52 - SCREW M5X60 HIT-6684660.A26 6684660 -
53 - CLEANER SPONGE HIT-6690364.A16 6690364 £1.67 £2.00
54 - CLEANER COVER ASS'Y HIT-6690417.A6 6690417 £11.15 £13.38
55 - SPECIAL SCREW HIT-6689737.A18 6689737 -
56 - CARBURETOR SET WYL112 TILL B028600 HIT-6690482.A0 6690482 £73.85 £88.62
56A - CARBURETOR SET 1 HIT-6690487.A3 6690487 £69.98 £83.97
57 - SHIELD TUBE HIT-6685247.A8 6685247 £4.32 £5.19
58 - CLIP D6 HIT-6685198.A57 6685198 -
59A - PUMP FILTER BODY COMP HIT-66A3864.A72 66A3864 -
60 - TANK WHT HIT-6691582.A5 6691582 £11.71 £14.05
61 - COLLAR 5.8 HIT-6692244.A29 6692244 £1.67 £2.00
62 - HEX. HOLE BOLT 5X18PS HIT-6695505.A6 6695505 -
63 - SWIVEL CAP SINCE A138351 HIT-6691337.A24 6691337 £1.67 £2.00
64 - TANK CAP D ASS'Y 1 HIT-6691763.A4 6691763 £13.46 £16.15
65 - PRIMING PUMP COMP. HIT-6685139.A102 6685139 £10.67 £12.80
66 - FUEL PIPE 2.5X4X80 HIT-6692347.A22 6692347 £1.67 £2.00
67 - FUEL PIPE 2.5X4X70 HIT-6692346.A5 6692346 £1.67 £2.00
68 - RETURN GROMMET HIT-6697846.A139 6697846 £1.68 £2.01
69 - TANK CAP CHAIN HIT-6684625.A28 6684625 -
81 - MUFFLER PROTECTOR HIT-6692799.A3 6692799 £10.64 £12.77
82 - MUFFLER GASKET HIT-6692744.A2 6692744 £1.67 £2.00
83 - HEAT SHIELD HIT-6687252.A5 6687252 £2.82 £3.39
84 - MUFFLER ASS'Y HIT-6692477.A2 6692477 £38.70 £46.44
85 - WASHER 5 HIT-6684661.A11 6684661 £1.67 £2.00
86 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A34 6685114 £1.67 £2.00
87 - FAN CASE COMP. 1 HIT-6687010.A1 6687010 £20.73 £24.88
88 - RECOIL SPRING HIT-6684675.A15 6684675 £8.82 £10.58
89 - STARTER ROPE REEL HIT-6693066.A4 6693066 £5.17 £6.20
90 - SET SCREW HIT-6693633.A11 6693633 £1.67 £2.00
91 - STARTER PULLEY ASS'Y HIT-6693405.A8 6693405 £7.75 £9.30
92 - GROMMET HIT-6688050.A12 6688050 £1.67 £2.00
93 - ROPE HIT-6693168.A42 6693168 £2.82 £3.39
94 - STARTER HANDLE HIT-6693237.A25 6693237 £4.55 £5.46
95 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A5 6684682 £1.67 £2.00
96 - CLUTCH HIT-6688494.A20 6688494 £14.82 £17.78
97 - TAPPING SCREW D4.5X16 HIT-6684636.A36 6684636 £1.67 £2.00
98 - BOLT 4X12PS HIT-6695441.A22 6695441 -
99 - STARTER PAWL SPRING HIT-6684684.A5 6684684 £3.29 £3.95
100 - STARTER PAWL HIT-6693319.A4 6693319 £3.29 £3.95
111 - THROTTLE SET SCREW HIT-6684698.A11 6684698 -
112 - SWIVEL HIT-6684697.A143 6684697 -
113 - STOP RING HIT-6684696.A18 6684696 -
114 - THROTTLE VALVE TILL B028600 HIT-6684883.A6 6684883 £32.24 £38.69
115 - O-RING HIT-6684695.A176 6684695 £1.67 £2.00
116 - MAIN JET #40 TILL B028600 HIT-6691845.A5 6691845 -
116A - MAIN JET #34.5 SINCE B028601 HIT-6691888.A4 6691888 -
117 - PUMP GASKET HIT-6691457.A36 6691457 £8.48 £10.18
118 - PUMP DIAPHRAGM HIT-6684693.A17 6684693 £5.70 £6.84
119 - INLET SCREEN HIT-6684700.A10 6684700 -
120 - PUMP BODY COMP. HIT-6691430.A2 6691430 -
121 - DIAPHRAGM PACKING-METERING HIT-6685220.A59 6685220 £2.81 £3.37
122 - METERING DIAPHRAGM COMP. HIT-6690827.A67 6690827 £14.02 £16.83
123 - DIAPHRAGM COVER-METERING HIT-6685222.A120 6685222 £5.70 £6.84
124 - SET SCREW HIT-6691312.A65 6691312 -
131 - NO LONGER AVAILABLE HIT-6688672.A1 6688672 -
132 - RETAINING RING C-TYPE D26 HIT-6695294.A45 6695294 -
133 - BALL BEARING #6000 1 HIT-6695524.A32 6695524 -
134 - BALL BEARING #6000Z 1 HIT-6695526.A9 6695526 -
135 - CLUTCH HOUSING COMP. HIT-6688571.A3 6688571 -
136 - GEAR 1 TILL C024000 HIT-6688967.A0 6688967 -
136A - GEAR 1 SINCE C024001 HIT-6688968.A3 6688968 -
137A - GEAR 2 SINCE C024001 HIT-6688978.A4 6688978 £29.02 £34.82
138 - CAM-ROD COMP. HIT-6686810.A2 6686810 £31.02 £37.23
139 - CAM SHAFT HIT-6686791.A0 6686791 -
140 - GEAR CASE GASKET HIT-6688910.A1 6688910 -
141 - BALL BEARING #608 2 HIT-6684738.A4 6684738 -
142 - GREASE SEAL A HIT-6686655.A3 6686655 -
143 - COLLAR HIT-6688293.A2 6688293 -
144 - HEX. HOLE BOLT M5X25/S HIT-6684709.A195 6684709 £1.67 £2.00
145 - GREASE NIPPLE COMP. HIT-6688643.A70 6688643 £1.67 £2.00
146 - HEX. HOLE BOLT 6X18/S HIT-6695495.A28 6695495 -
147 - HEX HOLE BUTTON SCREW 6X15 HIT-6695079.A18 6695079 £1.67 £2.00
148 - SMALL WASHER 6 HIT-6695183.A7 6695183 -
149 - FIXING PLATE HIT-6686467.A0 6686467 -
150 - SUPPORT PLATE HIT-6690758.A0 6690758 -
151 - HEX. SOCKET HD. BOLT M4X10 HIT-6685093.A4 6685093 £1.67 £2.00
152 - SPRING NUT 6 HIT-6695475.A11 6695475 -
154 - S.WASHER 6 TILL A138350 HIT-6695219.A25 6695219 £1.67 £2.00
155 - SPRING NUT 6 HIT-6695475.A10 6695475 -
171 - CUTTER GUIDE TILL A138350 HIT-6687140.A0 6687140 -
171A - CUTER GUIDE 1105L M6 SINCE A138351 HIT-6687141.A0 6687141 -
172 - PROTECTION PLATE TILL B028600 HIT-6687288.A2 6687288 -
173 - HEX. HOLE SCREW 6X25 HIT-6695074.A1 6695074 -
174 - SPECIAL WASHER B SINCE B028601 HIT-6684822.A50 6684822 £1.67 £2.00
175 - CUTTER B 1132L HIT-6687111.A0 6687111 -
176 - CUTTER A 1132L HIT-6687089.A0 6687089 -
177 - WASHER 7 BLACK HIT-6687187.A40 6687187 £1.67 £2.00
178 - CUTTER FIXING BOLT A TILL A138350 HIT-6687160.A0 6687160 £1.67 £2.00
178A - FIXING BOLT A M6 SINCE A138351 HIT-6687158.A23 6687158 £1.67 £2.00
179 - BLADE HOLDER HIT-6687180.A4 6687180 -
180 - CUTTER FIXING BOLT B TILL A138350 HIT-6687167.A1 6687167 £1.67 £2.00
180A - FIXING BOLT B M6 SINCE A138351 HIT-6687168.A1 6687168 £1.67 £2.00
181 - HANDLE B COMP. HIT-6686311.A4 6686311 £24.92 £29.91
182 - HANDLE GRIP HIT-6684708.A22 6684708 £3.56 £4.27
183 - CUTTER FIXING NUT TILL A138350 HIT-6687156.A2 6687156 £1.67 £2.00
183A - FLANGE NUT 6 SINCE A138351 HIT-6695170.A67 6695170 £1.67 £2.00
184 - BOLT WASHER 6 HIT-6684639.A169 6684639 £1.67 £2.00
185 - S.WASHER 6 HIT-6695219.A84 6695219 £1.67 £2.00
186 - BOLT WASHER 6 TILL A138350 HIT-6684639.A170 6684639 £1.67 £2.00
187 - CUTTER COVER TILL B028600 HIT-6687303.A0 6687303 -
187A - BLADE COVER SINCE B028601 HIT-6687304.A0 6687304 -
188 - GATHERING PLATE 1 HIT-6689539.A4 6689539 £32.99 £39.59
189 - SPECIAL WASHER B TILL B028600 HIT-6684822.A7 6684822 £1.67 £2.00
201 - HANDLE GRIP A HIT-6686338.A6 6686338 -
202 - HANDLE GRIP B HIT-6686349.A5 6686349 -
203 - THROTTLE LEVER HIT-6688229.A0 6688229 £4.12 £4.94
204 - SAFETY LEVER HIT-6688238.A5 6688238 -
205 - THROTTLE LEVER SPRING HIT-6686414.A6 6686414 -
206 - STOP SWITCH COMP. HIT-6687758.A2 6687758 -
207 - STOP BUTTON MARK HIT-6694585.A0 6694585 -
208 - CAP HIT-6693002.A2 6693002 £1.67 £2.00
209 - SCREW 4X30/WS HIT-6695412.A0 6695412 -
210 - SCREW 4X25/WS HIT-6695411.A9 6695411 -
211 - HANDLE GRIP ASS'Y HIT-6686354.A2 6686354 -
212 - HANDLE A COMP. HIT-6686275.A0 6686275 -
213 - THROTTLE WIRE 270+49 HIT-6693877.A4 6693877 £6.61 £7.93
214 - PROTECTION TUBE 10X150L HIT-6687558.A4 6687558 -
215 - SCREW 4X16WS HIT-6695404.A6 6695404 -
216 - NYLON LOCK NUT 4 HIT-6695163.A14 6695163 -
217 - SCREW 3X10 HIT-6684913.A7 6684913 £1.67 £2.00
218 - BUTTON STOP HIT-6688366.A25 6688366 £1.67 £2.00
219 - CORD CLAMP HIT-6688015.A15 6688015 -
220 - HEX.HOLE BOLT M5X12/S HIT-6684667.A58 6684667 £1.67 £2.00
221 - HANDLE BRACKET HIT-6686370.A1 6686370 -
222 - HANDLE DUMPER RUBBER HIT-6686396.A3 6686396 -
501 - COMBI BOX SPANNER 10/19MM HIT-6685257.A20 6685257 -
502 - HEX. BAR WRENCH 4MM HIT-6684813.A86 6684813 -
601 - NAME PLATE HIT-6699688.A0 6699688 -
