1 - AIR CLEANER BODY
HIT-6684856.A4
6684856
|
-
|
|
|
|
2 - CHOKE VALVE
HIT-6684857.A0
6684857
|
£5.70
|
£6.84
|
|
|
3 - COLLAR
HIT-6684858.A8
6684858
|
-
|
|
|
|
4 - SPACER
HIT-6684859.A2
6684859
|
-
|
|
|
|
5 - BLOW OVER CHECK BOARD
HIT-6684860.A8
6684860
|
£3.42
|
£4.10
|
|
|
6 - CLEANER SPONGE
HIT-6684861.A2
6684861
|
£6.18
|
£7.41
|
|
|
7 - CLEANER CAP
HIT-6684862.A4
6684862
|
£8.58
|
£10.29
|
|
|
8 - AIR CLEANER ASS'Y INCLUD.7
HIT-6684863.A0
6684863
|
£18.38
|
£22.05
|
|
|
9 - SMALL WASHER 5
HIT-6684864.A98
6684864
|
-
|
|
|
|
10 - S.WASHER 5
HIT-6684662.A61
6684662
|
£1.67
|
£2.00
|
|
|
11 - SCREW M5X60
HIT-6684660.A16
6684660
|
-
|
|
|
|
12 - INSULATOR GASKET
HIT-6684865.A6
6684865
|
£1.67
|
£2.00
|
|
|
13 - PARTITION PLATE
HIT-6684866.A1
6684866
|
-
|
|
|
|
14 - INSULATOR ASS'Y INCLUD.12
HIT-6684867.A0
6684867
|
£6.42
|
£7.70
|
|
|
15 - HEX. HOLE BOLT 5X25/WS
HIT-6684617.A1
6684617
|
-
|
|
|
|
16 - CARBURETOR GASKET
HIT-6684868.A1
6684868
|
£2.81
|
£3.37
|
|
|
17 - CARBURETOR SET WYJ470 INCLUD.16
HIT-6684869.A0
6684869
|
£85.50
|
£102.60
|
|
|
18 - THROTTLE SET SCREW FOR EUROPE
HIT-6684870.A42
6684870
|
-
|
|
|
|
19 - CABLE ADJUSTER
HIT-6684871.A31
6684871
|
-
|
|
|
|
20 - LOCK NUT M6
HIT-6684872.A44
6684872
|
-
|
|
|
|
21 - CABLE ADJUSTER STAY FOR EUROPE
HIT-6684873.A35
6684873
|
-
|
|
|
|
22 - SWIVEL
HIT-6684697.A110
6684697
|
-
|
|
|
|
23 - THRUST WASHER FOR EUROPE
HIT-6684874.A43
6684874
|
-
|
|
|
|
24 - STOP RING
HIT-6684696.A58
6684696
|
-
|
|
|
|
25 - CLEANER PACKING FOR EUROPE
HIT-6684875.A35
6684875
|
-
|
|
|
|
26 - O-RING
HIT-6684695.A139
6684695
|
£1.67
|
£2.00
|
|
|
27 - MAIN JET #37 FOR EUROPE
HIT-6684876.A1
6684876
|
-
|
|
|
|
28 - PUMP GASKET
HIT-6684692.A89
6684692
|
£17.28
|
£20.73
|
|
|
29 - DIAPHRAGM GASKET
HIT-6684691.A21
6684691
|
£5.70
|
£6.84
|
|
|
30 - PRIMING PUMP COMP. FOR EUROPE
HIT-6684687.A23
6684687
|
£9.27
|
£11.12
|
|
|
31 - PRIMING BODY
HIT-6684689.A23
6684689
|
£5.87
|
£7.04
|
|
|
32 - DIAPHRAGM COVER
HIT-6684688.A76
6684688
|
£5.70
|
£6.84
|
|
|
33 - PUMP DIAPHRAGM
HIT-6684693.A54
6684693
|
£5.70
|
£6.84
|
|
|
34 - INLET SCREEN
HIT-6684700.A63
6684700
|
-
|
|
|
|
35 - PUMP BODY COMP.
HIT-6684879.A15
6684879
|
£35.37
|
£42.44
|
|
|
36 - METERING DIAPHRAGM
HIT-6684690.A94
6684690
|
£24.05
|
£28.86
|
|
|
37 - SET SCREW
HIT-6684699.A78
6684699
|
-
|
|
|
|
38 - SHIELD TUBE 3X5X180
HIT-6684618.A30
6684618
|
£6.12
|
£7.35
|
|
|
39 - FUEL PIPE 3X5X85
HIT-6684880.A47
6684880
|
£1.67
|
£2.00
|
|
|
40A - RETURN GROMMET
HIT-6684627.A170
6684627
|
£1.67
|
£2.00
|
|
|
41 - CLIP 1
HIT-6684619.A5
6684619
|
£1.67
|
£2.00
|
|
|
42B - PUMP FILTER BODY COMP
HIT-66A3864.A46
66A3864
|
-
|
|
|
|
*43 - CARBURETOR SET WYL260 INCLUD.16
HIT-6684881.A0
6684881
|
-
|
|
|
|
*43 - CARBURETOR SET WYL266 INCLUD.16
HIT-6684882.A2
6684882
|
-
|
|
|
|
44 - SWIVEL CAP FOR ASIA
HIT-6691337.A40
6691337
|
£1.67
|
£2.00
|
|
|
45 - THROTTLE VALVE FOR ASIA
HIT-6684883.A0
6684883
|
£32.24
|
£38.69
|
|
|
46 - THROTTLE SET SCREW FOR ASIA
HIT-6684698.A21
6684698
|
-
|
|
|
|
47 - WIRE SET PLATE FOR ASIA
HIT-6684884.A1
6684884
|
-
|
|
|
|
48 - CLEANER GASKET FOR ASIA
HIT-6684885.A0
6684885
|
-
|
|
|
|
49 - HEX. HOLE BOLT M6X55
HIT-6684638.A36
6684638
|
£1.67
|
£2.00
|
|
|
50 - BOLT WASHER 6
HIT-6684639.A0
6684639
|
£1.67
|
£2.00
|
|
|
*51 - MUFFLER COMP. FOR EUROPE
HIT-6684886.A1
6684886
|
-
|
|
|
|
*51 - MUFFLER COMP. FOR ASIA
HIT-6684887.A0
6684887
|
-
|
|
|
|
52 - INSULATOR
HIT-6684888.A1
6684888
|
-
|
|
|
|
53 - SCREW M4X8/WS
HIT-6684651.A20
6684651
|
-
|
|
|
|
54 - SPARK ARRESTER
HIT-6684889.A0
6684889
|
-
|
|
|
|
55 - MUFFLER SPECIAL GASKET
HIT-6684890.A1
6684890
|
-
|
|
|
|
56 - TAIL PIPE SET INCLUD.54
HIT-6684891.A0
6684891
|
£9.18
|
£11.02
|
|
|
57 - HEX. HOLE BOLT M4X18/WS
HIT-6684599.A74
6684599
|
-
|
|
|
|
58 - EARTH CORD 120L
HIT-6684892.A1
6684892
|
-
|
|
|
|
59 - STOP CORD 145L
HIT-6684893.A0
6684893
|
-
|
|
|
|
60 - PLUG CAP
HIT-6684894.A9
6684894
|
£7.75
|
£9.30
|
|
|
61A - IGNITION COIL ASS'Y INCLUD.60
HIT-6697896.A0
6697896
|
£27.21
|
£32.65
|
|
|
62 - WASHER T1.6
HIT-6684600.A0
6684600
|
-
|
|
|
|
63 - HEX.HOLE BOLT M5X18/S
HIT-6684586.A18
6684586
|
-
|
|
|
|
64A - SPARK PLUG ASS'Y BMR7A
HIT-6699316.A37
6699316
|
£12.43
|
£14.92
|
|
|
65 - CYLINDER GASKET
HIT-6684896.A16
6684896
|
£1.67
|
£2.00
|
|
|
66 - CYLINDER ASS'Y INCLUD.65
HIT-6684897.A0
6684897
|
£79.58
|
£95.50
|
|
|
67 - PISTON RING
HIT-6684588.A2
6684588
|
£6.38
|
£7.66
|
|
|
68 - CIR CLIP
HIT-6684590.A130
6684590
|
£1.67
|
£2.00
|
|
|
69 - PISTON ASS'Y INCLUD.67
HIT-6684898.A4
6684898
|
£40.45
|
£48.54
|
|
|
70 - PISTON PIN
HIT-6684591.A13
6684591
|
£3.29
|
£3.95
|
|
|
71 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A0
6684899
|
-
|
|
|
|
72A - CRANK SHAFT SET
HIT-6601584.A1
6601584
|
-
|
|
|
|
73 - SPECIAL BOLT
HIT-6695852.A0
6695852
|
-
|
|
|
|
74 - BOLT WASHER M8
HIT-6684611.A20
6684611
|
-
|
|
|
|
75A - MAGNETO ROTOR
HIT-6600925.A0
6600925
|
-
|
|
|
|
76 - HEX. HOLE BOLT M5X16/S
HIT-6684903.A87
6684903
|
-
|
|
|
|
77 - CRANK CASE GASKET
HIT-6684904.A1
6684904
|
£1.67
|
£2.00
|
|
|
78 - OIL SEAL TB 12227
HIT-6684607.A153
6684607
|
£4.07
|
£4.88
|
|
|
79 - BALL BEARING 6001 C3
HIT-6684608.A52
6684608
|
£5.70
|
£6.84
|
|
|
80 - GEAR SHAFT SHIM 0.20
HIT-6684604.A1
6684604
|
-
|
|
|
|
80 - GEAR SHAFT SHIM 0.30
HIT-6684605.A80
6684605
|
-
|
|
|
|
*82 - MAIN JET #37 FOR ASIA
HIT-6684877.A0
6684877
|
£8.18
|
£9.81
|
|
|
*82 - MAIN JET #39 FOR AUS
HIT-6684878.A4
6684878
|
-
|
|
|
|
84 - CLEANER BODY ASS'Y INCLUD.1-6
HIT-6697054.A0
6697054
|
-
|
|
|
|
86 - FUEL PIPE L180 FOR USA
HIT-6698932.A1
6698932
|
-
|
|
|
|
87 - FUEL GROMMET FOR USA
HIT-6698931.A67
6698931
|
£5.54
|
£6.65
|
|
|
88 - Part Name Not Listed
HIT-66A0466.A0
66A0466
|
-
|
|
|
|
89 - Part Name Not Listed
HIT-66A0475.A0
66A0475
|
-
|
|
|
|
90 - FOR AUS
HIT-000000.A2002
000000
|
-
|
|
|
|
121 - FAN-HEADED PIPE
HIT-6684906.A0
6684906
|
£20.98
|
£25.18
|
|
|
122 - STRAIGHT PIPE
HIT-6684907.A1
6684907
|
£22.42
|
£26.91
|
|
|
*123 - THROTTLE WIRE 235+92 FOR EUROPE
HIT-6684908.A0
6684908
|
-
|
|
|
|
*123 - THROTTLE WIRE 245+93 FOR ASIA
HIT-6684909.A1
6684909
|
-
|
|
|
|
124 - THROTTLE LEVER
HIT-6684910.A0
6684910
|
£1.67
|
£2.00
|
|
|
125 - STOP SWITCH COMP.
HIT-6684911.A1
6684911
|
£7.62
|
£9.15
|
|
|
126 - PROTECTION SHEET
HIT-6684912.A0
6684912
|
-
|
|
|
|
127 - SCREW 3X10
HIT-6684913.A30
6684913
|
£1.67
|
£2.00
|
|
|
128A - STOP BUTTON (RED)
HIT-6698995.A0
6698995
|
-
|
|
|
|
129 - STOP SWITCH MARK
HIT-6684915.A0
6684915
|
-
|
|
|
|
130 - MUFFLER PROTECTOR
HIT-6684916.A1
6684916
|
-
|
|
|
|
131 - TAPPING SCREW (W/FLANGE) D5X20 (BLACK)
HIT-302089.A20
302089
|
£1.67
|
£2.00
|
|
|
132 - MACHINE SCREW (W/WASHERS) M5X25
HIT-317751.A1
317751
|
-
|
|
|
|
133 - CRUISE LEVER
HIT-6684917.A0
6684917
|
-
|
|
|
|
134 - WASHER M5 (BLACK)
HIT-6684918.A55
6684918
|
£1.67
|
£2.00
|
|
|
135 - NYLON NUT M5
HIT-305491.A0
305491
|
-
|
|
|
|
136 - PILLAR TERMINAL
HIT-938307.A15
938307
|
£3.28
|
£3.93
|
|
|
137 - SUPPORT HANDLE
HIT-6684919.A0
6684919
|
-
|
|
|
|
138 - TAPPING SCREW (W/FLANGE) D5X20 (BLACK)
HIT-302089.A21
302089
|
£1.67
|
£2.00
|
|
|
139 - COVER SETTING BOLT
HIT-6684920.A1
6684920
|
-
|
|
|
|
140 - GUARD NET
HIT-6684921.A0
6684921
|
-
|
|
|
|
141 - MICRO SWITCH
HIT-6684922.A1
6684922
|
-
|
|
|
|
142 - VOLUTE CASE
HIT-6696390.A1
6696390
|
£37.57
|
£45.08
|
|
|
143 - LOCK NUT M5 (10 PCS.)
HIT-949566.A0
949566
|
£1.67
|
£2.00
|
|
|
145 - WASHER 8.1X30
HIT-6684924.A0
6684924
|
-
|
|
|
|
146 - FAN
HIT-6684925.A1
6684925
|
-
|
|
|
|
147 - WASHER 10.1X30
HIT-6684926.A0
6684926
|
-
|
|
|
|
149 - TAPPING SCREW (W/FLANGE) D5X20 (BLACK)
HIT-302089.A22
302089
|
£1.67
|
£2.00
|
|
|
150A - PIN CLIP
HIT-66A5660.A0
66A5660
|
-
|
|
|
|
151 - COVER SPRING ASS'Y
HIT-6684928.A1
6684928
|
-
|
|
|
|
152 - SWITCH COVER
HIT-6684929.A3
6684929
|
-
|
|
|
|
153 - SPRING
HIT-6684930.A1
6684930
|
£1.67
|
£2.00
|
|
|
154 - PIN
HIT-6684931.A3
6684931
|
-
|
|
|
|
155 - TAPPING SCREW (W/FLANGE) D5X20 (BLACK)
HIT-302089.A19
302089
|
£1.67
|
£2.00
|
|
|
156 - U-NUT M8
HIT-6684932.A2
6684932
|
£1.67
|
£2.00
|
|
|
157 - SHREDDER
HIT-6684933.A0
6684933
|
-
|
|
|
|
158 - HEX.HOLE BOLT M5X35
HIT-6684934.A8
6684934
|
-
|
|
|
|
159 - SPRING WASHER 5
HIT-6684834.A63
6684834
|
£1.67
|
£2.00
|
|
|
160 - FAN CASE E COMP.
HIT-6696391.A0
6696391
|
-
|
|
|
|
161A - FUEL TANK CAP ASS'Y INCLUD.162A
HIT-6698402.A85
6698402
|
£6.94
|
£8.33
|
|
|
162A - TANK CAP CHAIN
HIT-6698732.A13
6698732
|
-
|
|
|
|
164 - LEAD WIRE ASS'Y
HIT-6684936.A0
6684936
|
-
|
|
|
|
181 - STARTER PULLEY TILL EO99999
HIT-6684937.A7
6684937
|
£3.56
|
£4.27
|
|
|
182 - RECOIL STARTER BODY ASS'Y INCLUD.183-190 TILL EO99999
HIT-6684938.A8
6684938
|
£18.59
|
£22.31
|
|
|
183 - SET SCREW TILL EO99999(SINCE 11.2012 FOR AUS)
HIT-6684679.A129
6684679
|
£2.98
|
£3.57
|
|
|
184 - PULLEY STAY TILL EO99999
HIT-6684939.A7
6684939
|
-
|
|
|
|
185 - SWING ARM TILL EO99999
HIT-6684940.A8
6684940
|
£1.67
|
£2.00
|
|
|
186 - STARTER ROPE REEL TILL EO99999
HIT-6684941.A7
6684941
|
£7.41
|
£8.89
|
|
|
187 - RECOIL SPRING TILL EO99999
HIT-6684942.A8
6684942
|
£5.17
|
£6.20
|
|
|
188 - ROPE 3.0X800 TILL EO99999
HIT-6684943.A7
6684943
|
-
|
|
|
|
189 - RECOIL STARTER BODY COMP. TILL E099999
HIT-6684944.A8
6684944
|
-
|
|
|
|
190 - STARTER HANDLE TILL E099999(SINCE 11.2012 FOR AUS)
HIT-6684680.A22
6684680
|
£5.87
|
£7.04
|
|
|
191 - HEX. HOLE BOLT 4X15/PS
HIT-6684682.A22
6684682
|
£1.67
|
£2.00
|
|
|
193A - STARTER PULLEY ASS'Y SINCE EN90001(TILL 10.2012 FOR AUS)
HIT-6696471.A4
6696471
|
£8.35
|
£10.02
|
|
|
194 - RECOIL STARTER BODY ASS'Y INCLUD.195-200 SINCE EN90001
HIT-6696572.A7
6696572
|
£13.43
|
£16.12
|
|
|
195 - SET SCREW SINCE EN90001(TILL 10.2012 FOR AUS)
HIT-6693633.A20
6693633
|
£1.67
|
£2.00
|
|
|
196 - STARTER ROPE REEL SINCE EN90001(TILL 10.2012 FOR AUS)
HIT-6684941.A8
6684941
|
£7.41
|
£8.89
|
|
|
197 - RECOIL SPRING SINCE EN90001
HIT-6684675.A37
6684675
|
£8.82
|
£10.58
|
|
|
198 - RECOIL STARTER BODY COMP. SINCE EN90001(TILL 10.2012 FOR AUS)
HIT-6684944.A9
6684944
|
-
|
|
|
|
199 - ROPE SINCE EN90001(TILL 10.2012 FOR AUS)
HIT-6693168.A56
6693168
|
£2.82
|
£3.39
|
|
|
200 - STARTER HANDLE SINCE EN90001(TILL 10.2012 FOR AUS)
HIT-6693227.A13
6693227
|
-
|
|
|
|
201 - STARTER PULLEY ASS'Y SINCE 11.2012 FOR AUS
HIT-6684681.A93
6684681
|
£18.16
|
£21.79
|
|
|
202B - RECOIL STARTER ASS'Y INCLUD.183
HIT-6601590.A0
6601590
|
-
|
|
|
|
203A - CAM PLATE SINCE 11.2012 FOR AUS
HIT-6699996.A81
6699996
|
£4.28
|
£5.13
|
|
|
204 - DAMPER SPRING SINCE 11.2012 FOR AUS
HIT-6684677.A91
6684677
|
£5.70
|
£6.84
|
|
|
205A - STARTER ROPE REEL SINCE 11.2012 FOR AUS
HIT-6699997.A8
6699997
|
-
|
|
|
|
207 - STARTER ROPE 3.5X860 SINCE 11.2012 FOR AUS
HIT-6684674.A73
6684674
|
£5.70
|
£6.84
|
|
|
209 - CAMPLATE ASS'Y INCLUD.203A
HIT-6699691.A44
6699691
|
£7.75
|
£9.30
|
|
|
501 - COMBI BOX SPANNER 13X19 PLUS
HIT-6684979.A1
6684979
|
-
|
|
|
