Hitachi / Hikoki TED270RS Engine Drill Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TED270RS Engine Drill

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A14 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A22 6699319	-
3 - CYLINDER SET HIT-6685493.A4 6685493	£72.13	£86.56
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A14 6684586	-
5 - CYLINDER GASKET T=1.0 HIT-6685750.A5 6685750	£2.81	£3.37
6 - PISTON RING HIT-6686121.A12 6686121	£6.47	£7.76
7 - PISTON SET HIT-6685902.A7 6685902	£30.58	£36.70
8 - CIR CLIP HIT-6684590.A151 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A0 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A3 6686219	£121.07	£145.28
12 - STOP CORD B 190M HIT-6687836.A1 6687836	-
13 - HEX. HOLE BOLT M4X18/WS TILL H126520 HIT-6684599.A69 6684599	-
13A - HIGH TENSION SCREW 4X18WS SINCE H126521 HIT-6695407.A13 6695407	-
14 - IGNITION COIL ASS'Y HIT-6687686.A0 6687686	-
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A13 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A68 6684605	-
22 - MAGNETO ROTOR COMP. HIT-6687384.A9 6687384	-
23 - HEX. NUT M8 HIT-6684612.A116 6684612	-
24 - BOLT WASHER M8 HIT-6684611.A2 6684611	-
25 - CRANK CASE ASS'Y HIT-6684905.A20 6684905	£30.92	£37.11
26 - OIL SEAL TB 12227 HIT-6684607.A130 6684607	£4.07	£4.88
27 - BALL BEARING 6001 C3 HIT-6684608.A73 6684608	£5.70	£6.84
28 - CRANK CASE GASKET HIT-6684904.A2 6684904	£1.67	£2.00
29 - HEX. HOLE BOLT M5X16/S HIT-6684903.A86 6684903	-
41 - INLET MANIFOLD GASKET HIT-6689895.A15 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A16 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT M5X25WS HIT-6695515.A57 6695515	£1.67	£2.00
44 - CARBURETOR GASKET HIT-6684615.A0 6684615	£1.67	£2.00
45 - CABURETOR SET WYJ-431 HIT-6690519.A4 6690519	£113.54	£136.25
46 - CLEANER BODY COMP. HIT-6690120.A18 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A27 6690365	£1.67	£2.00
48 - CLEANER COVER ASS'Y HIT-6690421.A6 6690421	£14.48	£17.38
49 - COVER FIXING BOLT COMP. HIT-6698730.A7 6698730	£5.52	£6.63
50 - SCREW 5X57/S HIT-6695353.A7 6695353	£1.67	£2.00
51 - SMALL WASHER 5 HIT-6684864.A90 6684864	-
52 - CHOKE LEVER 1.5 HIT-6691281.A1 6691281	£1.67	£2.00
53 - CHOKE CONTROL LEVER HIT-6691239.A0 6691239	£2.98	£3.57
54 - TANK WHT TILL TL043340 HIT-6691602.A10 6691602	£13.82	£16.59
54A - TANK SINCE TL043341 HIT-6601167.A2 6601167	-
55 - COLLAR 5.8 TILL J035530 HIT-6692244.A23 6692244	£1.67	£2.00
56 - RETURN GROMMET TILL TL043340 HIT-6697846.A162 6697846	£2.08	£2.50
56A - FUEL GROMMET SINCE TL043341 HIT-6600358.A33 6600358	£1.67	£2.00
57 - FUEL PIPE 3X5X65 HIT-6684626.A23 6684626	£1.67	£2.00
58A - PUMP FILTER BODY COMP HIT-66A3864.A49 66A3864	-
59 - CLIP D6 HIT-6685198.A47 6685198	-
60 - SHIELD TUBE 3X5X180 TILL TL043340 HIT-6684618.A33 6684618	£6.12	£7.35
60A - FUEL PIPE SINCE TL043341 HIT-6601181.A1 6601181	-
61 - BRAKE SHAFT WASHER TILL J035530 HIT-6689681.A34 6689681	£1.67	£2.00
62 - TANK CAP ASS'Y HIT-6685049.A18 6685049	£9.94	£11.93
63 - TANK CAP CHAIN HIT-6684625.A15 6684625	-
64 - HEX.HOLE BOLT 5X20/PS TILL J035530 HIT-6684634.A13 6684634	£1.67	£2.00
64A - BOLT (W/FLANGE) L17.8 SINCE J035531 HIT-6696574.A47 6696574	£1.67	£2.00
65 - TAP SCREW 4X14 P HIT-6695280.A8 6695280	£1.67	£2.00
66 - BOLT WASHER M4 HIT-6685070.A44 6685070	£1.67	£2.00
67 - HEX. HOLE BOLT 5X16/PS TILL J035530 HIT-6695504.A46 6695504	£1.67	£2.00
67A - BOLT (W/FLANGE) L17.8 SINCE J035531 HIT-6696574.A46 6696574	£1.67	£2.00
71 - CYLINDER COVER HIT-6685690.A4 6685690	£5.70	£6.84
72 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A45 6695504	£1.67	£2.00
73 - HEX. HOLE BOLT M6X55 HIT-6684638.A34 6684638	£1.67	£2.00
74 - BOLT WASHER 6 HIT-6684639.A8 6684639	£1.67	£2.00
75 - MUFFLER SET HIT-6692501.A0 6692501	-
76 - MUFFLER GASKET HIT-6692732.A7 6692732	£1.67	£2.00
77 - MUFFLER PROTECTOR OR HIT-6692815.A0 6692815	£3.56	£4.27
78 - HEX. HOLE BOLT 4X18WS TILL H126520 HIT-6695508.A61 6695508	£1.67	£2.00
78A - SCREW 4X18/PS SINCE H126521 HIT-6695375.A39 6695375	-
79 - DEFLECTOR HIT-6687214.A0 6687214	£3.56	£4.27
80 - CLUTCH WASHER B TILL J038100 HIT-6684642.A38 6684642	£1.67	£2.00
80A - CLUTCH WASHER B SINCE J038101 HIT-6697619.A25 6697619	£1.67	£2.00
81 - CLUTCH SHOE COMP. TILL J038100 HIT-6684643.A1 6684643	£12.01	£14.41
81A - CLUTCH SHOE SINCE J038101 HIT-6697656.A13 6697656	-
82 - CLUTCH SPRING TILL J038100 HIT-6684644.A23 6684644	£3.12	£3.74
82A - CLUTCH SPRING SINCE J038101 HIT-6697657.A0 6697657	-
83 - CLUTCH PLATE A 0.5 TILL J038100 HIT-6684645.A1 6684645	£1.67	£2.00
83A - CLUTCH PLATE (A) SINCE J038101 HIT-6689528.A4 6689528	£1.67	£2.00
84 - STEP BOLT TILL J038100 HIT-6684646.A35 6684646	£3.72	£4.46
84A - STEP BOLT SINCE J038101 HIT-6689627.A6 6689627	£1.67	£2.00
85 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A1 6684647	£1.67	£2.00
86 - BENT WASHER 8 HIT-6684648.A98 6684648	£1.67	£2.00
87 - CLUTCH SET SINCE J038101 HIT-6697655.A0 6697655	£9.68	£11.62
88 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A19 6684682	£1.67	£2.00
89 - HEAT SHIELD HIT-6687264.A4 6687264	-
90 - TAPPING SCREW 4X14 HIT-6684751.A67 6684751	£1.67	£2.00
91 - FAN CASE HIT-6687036.A0 6687036	-
92 - PRIMARY CORD GROMMET HIT-6688057.A20 6688057	-
101B - RECOIL STARTER BODY ASS'Y INCLUD.103-109 HIT-6601570.A33 6601570	£23.15	£27.78
103 - STARTER ROPE 3.5X860 HIT-6684674.A83 6684674	£5.70	£6.84
104 - RECOIL SPRING HIT-6684675.A24 6684675	£8.82	£10.58
105A - STARTER ROPE REEL SINCE TL031471 HIT-6699997.A18 6699997	-
106 - DAMPER SPRING HIT-6684677.A101 6684677	£5.70	£6.84
107A - CAM PLATE SINCE TL031471 HIT-6699996.A71 6699996	£4.28	£5.13
108 - SET SCREW HIT-6684679.A136 6684679	£2.98	£3.57
109 - STARTER HANDLE HIT-6684680.A18 6684680	£5.87	£7.04
110 - STARTER PULLEY ASS'Y HIT-6684681.A97 6684681	£18.16	£21.79
111 - D4E RETAINING RING HIT-6685101.A79 6685101	-
112 - STARTER PAWL SPRING HIT-6684684.A27 6684684	£3.29	£3.95
113 - STARTER PAWL HIT-6684685.A84 6684685	£5.07	£6.08
114 - SCREW 4X18/PS HIT-6695375.A40 6695375	-
115 - CAMPLATE ASS'Y TILL TL031470 HIT-6699691.A41 6699691	£7.75	£9.30
121 - PUMP BODY COMP. HIT-6684879.A28 6684879	£35.37	£42.44
122 - PRIMING PUMP COMP. HIT-6684687.A20 6684687	£9.27	£11.12
123 - DIAPHRAGM COVER HIT-6684688.A80 6684688	£5.70	£6.84
124 - PRIMING BODY HIT-6684689.A19 6684689	£5.87	£7.04
125 - METERING DIAPHRAGM COMP. HIT-6690830.A22 6690830	£14.58	£17.50
126 - DIAPHRAGM GASKET HIT-6684691.A19 6684691	£5.70	£6.84
127 - PUMP DIAPHRAGM HIT-6684693.A51 6684693	£5.70	£6.84
128 - PUMP GASKET HIT-6684692.A91 6684692	£17.28	£20.73
129 - MAIN JET #43 HIT-6691848.A10 6691848	£8.77	£10.52
130 - O-RING HIT-6684695.A142 6684695	£1.67	£2.00
131 - STOP RING HIT-6684696.A55 6684696	-
132 - SWIVEL HIT-6684697.A113 6684697	-
133 - THROTTLE SET SCREW HIT-6684870.A55 6684870	-
134 - CABLE ADJUSTER STAY HIT-6684873.A23 6684873	-
135 - LOCK NUT M6 HIT-6684872.A59 6684872	-
136 - CABLE ADJUSTER HIT-6684871.A20 6684871	-
137 - CLEANER PACKING HIT-6684875.A24 6684875	-
138 - SET SCREW HIT-6684699.A93 6684699	-
139 - THRUST WASHER HIT-6684874.A56 6684874	-
140 - INLET SCREEN HIT-6684700.A31 6684700	-
151 - GEAR CASE A HIT-6685576.A3 6685576	-
152 - NO LONGER AVAILABLE HIT-6685593.A1 6685593	-
153 - SHIFT FORK COMP. HIT-6686684.A0 6686684	-
154 - SHIFT GUIDE SPRING HIT-6686837.A1 6686837	£1.67	£2.00
155 - SHIFT LEVER HIT-6686862.A1 6686862	£5.17	£6.20
156 - GREASE NIPPLE COMP. HIT-6688643.A80 6688643	£1.67	£2.00
157 - STEEL BALL HIT-6692271.A1 6692271	£1.67	£2.00
158 - HEX. HOLE BOLT 4X8 HIT-6695034.A0 6695034	£1.67	£2.00
159 - BOLT WASHER M4 HIT-6685070.A45 6685070	£1.67	£2.00
161 - NEEDLE BRG TLA912 1.5X5.8 HIT-6695591.A3 6695591	-
162 - GEAR 4 HIT-6685788.A12 6685788	£20.91	£25.09
163 - BALL BEARING #7202B 1 HIT-6695587.A3 6695587	£26.15	£31.38
164 - WASHAER C 5.0 HIT-6686065.A12 6686065	-
165 - BALL BEARING #6202Z 1 HIT-6695559.A28 6695559	£12.76	£15.31
166 - WAVE WASHER B.B 35 HIT-6695206.A15 6695206	-
167 - STOP RING C-35 1 HIT-6695296.A25 6695296	-
168 - WOOD-RUFF KEY 3X13X5 HIT-6686455.A16 6686455	£1.67	£2.00
169 - DRIVE SHAFT HIT-6685824.A2 6685824	£26.42	£31.70
170 - SCREW 5X18/S HIT-6695339.A27 6695339	-
171 - FORWARD GEAR HIT-6686378.A0 6686378	-
172 - THRUST WASHER 2 HIT-6687314.A1 6687314	-
173 - STOP RING 20 1 HIT-6695316.A4 6695316	-
174 - NEEDLE ROLLER 6X18 HIT-6695522.A3 6695522	-
175A - RETAINING RING (E-TYPE) FOR D8 SHAFT HIT-942827.A6 942827	£1.67	£2.00
176 - THRUST WASHER 0.8 HIT-6687320.A6 6687320	-
177 - IDLE GEAR HIT-6686373.A4 6686373	-
178 - NEEDLE BRG TLA912 1.5X5.8 HIT-6695591.A5 6695591	-
179 - IDLE SHAFT HIT-6686365.A3 6686365	-
180 - NO LONGER AVAILABLE HIT-6686423.A3 6686423	-
181 - STOP RING C-24 1 HIT-6684732.A47 6684732	£1.67	£2.00
182 - BALL BEARING 609Z ST HIT-6684735.A18 6684735	£15.48	£18.57
183 - THRUST WASHER 0.8 HIT-6687320.A7 6687320	-
184 - REVERSE GEAR HIT-6686411.A0 6686411	-
185 - NEEDLE BRG TLA912 1.5X5.8 HIT-6695591.A4 6695591	-
186 - COUNTER SHAFT HIT-6686427.A4 6686427	-
187 - STOP RING C-13 1 HIT-6695283.A14 6695283	-
201 - CLUTCH HOUSING COMP. HIT-6688199.A4 6688199	£19.89	£23.87
203 - PLUS BOLT 6X30 HIT-6695022.A6 6695022	£1.67	£2.00
204 - S.WASHER 6 HIT-6695219.A3 6695219	£1.67	£2.00
205 - HANDLE COMP.A HIT-6688369.A1 6688369	-
206 - HANDLE GRIP A HIT-6687624.A1 6687624	£7.34	£8.81
207 - THROTTLE LEVER HIT-6686799.A8 6686799	-
208 - SCREW 5X25 HIT-6694896.A7 6694896	-
209 - NUT M5 HIT-6684965.A45 6684965	£1.67	£2.00
210 - CORD CLAMP HIT-6688015.A22 6688015	-
211 - PLUS BOLT 6X16 HIT-6695019.A6 6695019	£1.67	£2.00
212 - S.WASHER 6 HIT-6695219.A4 6695219	£1.67	£2.00
213 - HANDLE COMP. B HIT-6688372.A5 6688372	£23.41	£28.09
214 - HANDLE GRIP HIT-6686350.A6 6686350	£8.64	£10.37
215 - S.WASHER 10 HIT-6695225.A15 6695225	£1.67	£2.00
216 - STOP SWITCH COMP. HIT-6687431.A0 6687431	£12.76	£15.31
217 - STOP BUTTON MARK HIT-6694589.A10 6694589	£3.37	£4.04
218 - BUTTON STOP HIT-6688366.A28 6688366	£1.67	£2.00
219 - SCREW 3X10 HIT-6684913.A32 6684913	£1.67	£2.00
220 - THROTTLE WIRE 370+45.5 HIT-6693987.A0 6693987	-
221 - CORRUGATED TUBE 7X290L HIT-6687532.A0 6687532	-
222 - CHUCK HANDLE HOLDER HIT-6687420.A1 6687420	-
223 - HANDLE SUPPORT COMP. HIT-6688404.A3 6688404	£25.49	£30.59
224 - S.WASHER 6 HIT-6695219.A5 6695219	£1.67	£2.00
225 - NUT M6 HIT-6684792.A27 6684792	-
226 - CLUTCH CASE COMP. HIT-6687336.A1 6687336	£55.25	£66.30
227 - SCREW 5X18/S HIT-6695339.A28 6695339	-
501 - COMBI BOX SPANNER 10X19 HIT-6685999.A2 6685999	-
502 - KEYLESS CHUCK HIT-6686379.A2 6686379	-
503 - LOCKING BAR HIT-6686780.A0 6686780	-
601 - NAME PLATE TED270RS HIT-6694238.A0 6694238	-

Attribute Name	Value
Brand	Hikoki
