1 - CYLINDER SET
HIT-6685453.A2
6685453
|
£82.78
|
£99.34
|
|
|
2 - SPARK PLUG ASS'Y BM6A
HIT-6699313.A1
6699313
|
-
|
|
|
|
3 - SPARK PLUG CAP ASS'Y
HIT-6687468.A77
6687468
|
£3.64
|
£4.37
|
|
|
4 - CYLINDER GASKET
HIT-6685720.A1
6685720
|
-
|
|
|
|
5 - PISTON RING
HIT-6684588.A18
6684588
|
£6.38
|
£7.66
|
|
|
6 - PISTON SET
HIT-6685876.A1
6685876
|
£33.90
|
£40.68
|
|
|
7 - PISTON PIN
HIT-6686016.A8
6686016
|
-
|
|
|
|
8 - CIRCLIP
HIT-6685078.A14
6685078
|
-
|
|
|
|
9 - CRANK SHAFT COMP.
HIT-6686165.A0
6686165
|
-
|
|
|
|
10 - NEEDLE BEARING KTV91313 2X7.8
HIT-6695595.A0
6695595
|
-
|
|
|
|
11 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A56
6684899
|
-
|
|
|
|
12 - HEX. HOLE BOLT M5X16/S
HIT-6684903.A15
6684903
|
-
|
|
|
|
*21 - CRANK SHAFT SHIM 0.10
HIT-6686470.A13
6686470
|
-
|
|
|
|
*21 - CRANK SHAFT SHIM 0.20
HIT-6686472.A3
6686472
|
£1.67
|
£2.00
|
|
|
*21 - CRANK SHAFT SHIM 0.30
HIT-6686473.A28
6686473
|
£1.67
|
£2.00
|
|
|
22 - BALL BEARING 6002 C3
HIT-6697745.A10
6697745
|
-
|
|
|
|
23 - BALL BEARING 6001 C3
HIT-6684608.A178
6684608
|
£5.70
|
£6.84
|
|
|
24 - OIL SEAL UD15257
HIT-6695637.A10
6695637
|
£3.66
|
£4.39
|
|
|
25 - OIL SEAL TB 12227
HIT-6684607.A16
6684607
|
£4.07
|
£4.88
|
|
|
26 - CRANK CASE GASKET
HIT-6686687.A0
6686687
|
-
|
|
|
|
27 - CRANK CASE ASS'Y
HIT-6686514.A2
6686514
|
-
|
|
|
|
28 - CLUTCH WASHER B
HIT-6689645.A46
6689645
|
£1.67
|
£2.00
|
|
|
29 - STARTER PULLEY
HIT-6693393.A0
6693393
|
£16.36
|
£19.63
|
|
|
30 - MAGNETO ROTOR COMP.
HIT-6687409.A0
6687409
|
-
|
|
|
|
31 - IGNITION COIL BRACKET
HIT-6687622.A1
6687622
|
-
|
|
|
|
32 - IGNITION COIL ASS'Y
HIT-6687661.A1
6687661
|
-
|
|
|
|
33 - HEX. NUT M8
HIT-6684612.A23
6684612
|
-
|
|
|
|
34 - SMALL WASHER 8
HIT-6695184.A3
6695184
|
-
|
|
|
|
35 - HEX. NUT M8
HIT-6684612.A24
6684612
|
-
|
|
|
|
36 - HEX. SOCKET HD. BOLT M5X30 S
HIT-6684786.A79
6684786
|
£1.67
|
£2.00
|
|
|
37 - SCREW 5X16/S
HIT-6695337.A5
6695337
|
-
|
|
|
|
38 - HIGH TENSION SCREW 4X18WS
HIT-6695407.A60
6695407
|
-
|
|
|
|
39 - STOP CORD COMP. TILL V028010
HIT-6687826.A3
6687826
|
-
|
|
|
|
40 - RUBBER CAP SINCE V028011
HIT-6684602.A11
6684602
|
-
|
|
|
|
41 - HIGHTENSION CORD 120L SINCE V028011
HIT-6687886.A2
6687886
|
-
|
|
|
|
51 - TANK BRACKET
HIT-6692204.A0
6692204
|
-
|
|
|
|
52 - FUEL TANK CUSHION RUBBER
HIT-6692227.A8
6692227
|
£1.67
|
£2.00
|
|
|
55 - CARBURETOR GASKET
HIT-6684615.A37
6684615
|
£1.67
|
£2.00
|
|
|
56 - CARBURETOR SET WYJ197 TILL Z315900
HIT-6690455.A1
6690455
|
£75.79
|
£90.95
|
|
|
57 - SHIELD TUBE
HIT-6685247.A14
6685247
|
£4.32
|
£5.19
|
|
|
58 - PUMP FILTER BODY ASS'Y
HIT-6692279.A1
6692279
|
£9.30
|
£11.16
|
|
|
59 - CLIP 1
HIT-6684619.A51
6684619
|
£1.67
|
£2.00
|
|
|
60A - TANK CAP D ASS'Y 1
HIT-6691715.A10
6691715
|
£8.55
|
£10.26
|
|
|
60A - TANK CAP D ASS'Y SINCE Z315901
HIT-6691748.A15
6691748
|
£6.04
|
£7.25
|
|
|
61 - FUEL TANK TILL Z315900
HIT-6691500.A1
6691500
|
-
|
|
|
|
61A - TANK TILL C275400
HIT-6691504.A1
6691504
|
-
|
|
|
|
61B - TANK COMP. WHITE SINCE C275401
HIT-6691501.A1
6691501
|
-
|
|
|
|
62 - SCREW 4X18/PS TILL Z315900
HIT-6695375.A12
6695375
|
-
|
|
|
|
63 - PLUS SCREW 5X60WS TILL Z315900
HIT-6695431.A1
6695431
|
-
|
|
|
|
64 - FUEL PIPE 3X5X75 SINCE Z315901
HIT-6692357.A2
6692357
|
£1.67
|
£2.00
|
|
|
65 - RETURN GROMMET SINCE Z315901
HIT-6697846.A48
6697846
|
£2.08
|
£2.50
|
|
|
66 - SCREW 4X14/PS
HIT-6695372.A4
6695372
|
-
|
|
|
|
67 - SCREW 5X24WS
HIT-6695423.A15
6695423
|
-
|
|
|
|
68 - AIR VENT ASS'Y TILL Z315900
HIT-6691389.A8
6691389
|
£16.64
|
£19.97
|
|
|
70 - AIR VENT VALVE ASS'Y TILL Z315900
HIT-6692171.A9
6692171
|
-
|
|
|
|
81 - MUFFLER PROTECTOR
HIT-6692770.A1
6692770
|
-
|
|
|
|
82 - PRIMARY CORD GROMMET
HIT-6688051.A1
6688051
|
-
|
|
|
|
83 - CLUTCH WASHER B
HIT-6684642.A4
6684642
|
£1.67
|
£2.00
|
|
|
84 - CLUTCH SHOE COMP.
HIT-6684643.A21
6684643
|
£12.01
|
£14.41
|
|
|
85 - CLUTCH SPRING
HIT-6684644.A2
6684644
|
£3.12
|
£3.74
|
|
|
86 - WASHER
HIT-6689637.A2
6689637
|
-
|
|
|
|
87 - STEP BOLT
HIT-6684646.A1
6684646
|
£3.72
|
£4.46
|
|
|
88 - FAN CASE COMP.
HIT-6686939.A1
6686939
|
-
|
|
|
|
89 - HEAT SHIELD
HIT-6687234.A1
6687234
|
-
|
|
|
|
90 - MUFFLER GASKET
HIT-6692731.A2
6692731
|
-
|
|
|
|
93 - MUFFLER BODY B COMP.
HIT-6692622.A1
6692622
|
-
|
|
|
|
*95 - SCREW 5X12/WS TILL A078000
HIT-6695415.A3
6695415
|
-
|
|
|
|
*95 - SCREW 5X12/WS SINCE A078001
HIT-6695415.A4
6695415
|
-
|
|
|
|
96 - SCREW 5X16/PS SINCE A078001
HIT-6695386.A8
6695386
|
£1.67
|
£2.00
|
|
|
97 - SCREW 4X12/P
HIT-6695317.A1
6695317
|
-
|
|
|
|
98 - HEX. HOLE BOLT 5X45
HIT-6695055.A20
6695055
|
£1.67
|
£2.00
|
|
|
99 - WASHER M5 (BLACK)
HIT-6684918.A20
6684918
|
£1.67
|
£2.00
|
|
|
100 - SCREW 5X16/S
HIT-6695337.A2
6695337
|
-
|
|
|
|
101 - SCREW 5X10/P
HIT-6695319.A2
6695319
|
-
|
|
|
|
121 - AIR CLEANER ASS'Y
HIT-6690025.A1
6690025
|
-
|
|
|
|
122 - AIR CLEANER CAP
HIT-6690142.A2
6690142
|
£9.10
|
£10.92
|
|
|
123 - CLEANER ELEMENT
HIT-6690350.A4
6690350
|
£7.15
|
£8.58
|
|
|
124 - SPACER
HIT-6684859.A10
6684859
|
-
|
|
|
|
125 - COLLAR
HIT-6690801.A15
6690801
|
-
|
|
|
|
126 - CHOKE PLATE 1
HIT-6691267.A3
6691267
|
-
|
|
|
|
127 - CLEANER BODY COMP.
HIT-6690091.A5
6690091
|
£9.67
|
£11.60
|
|
|
142 - STARTER HANDLE
HIT-6693224.A1
6693224
|
-
|
|
|
|
143 - RECOIL STARTER BODY COMP.
HIT-6693019.A1
6693019
|
-
|
|
|
|
144 - RECOIL SPRING
HIT-6693129.A1
6693129
|
-
|
|
|
|
145 - STARTER ROPE
HIT-6693152.A2
6693152
|
-
|
|
|
|
146 - STARTER PULLEY
HIT-6693058.A1
6693058
|
-
|
|
|
|
147 - STARTER PAWL
HIT-6693303.A2
6693303
|
£4.26
|
£5.11
|
|
|
148 - STARTER REEL WASHER
HIT-6693420.A2
6693420
|
-
|
|
|
|
149 - FRICTION PLATE
HIT-6693623.A1
6693623
|
-
|
|
|
|
150 - STARTER PAWL SHIM
HIT-6693564.A1
6693564
|
-
|
|
|
|
151 - SET BOLT
HIT-6693635.A1
6693635
|
-
|
|
|
|
161 - THROTTLE SET SCREW TILL Z315900
HIT-6684870.A9
6684870
|
-
|
|
|
|
162 - CABLE ADJUSTER STAY TILL Z315900
HIT-6684873.A64
6684873
|
-
|
|
|
|
163 - SWIVEL TILL Z315900
HIT-6684697.A19
6684697
|
-
|
|
|
|
164 - STOP RING TILL Z315900
HIT-6684696.A196
6684696
|
-
|
|
|
|
165 - O-RING TILL Z315900
HIT-6684695.A21
6684695
|
£1.67
|
£2.00
|
|
|
166 - MAIN JET #37.5 TILL Z315900
HIT-6691882.A0
6691882
|
-
|
|
|
|
167 - PUMP GASKET TILL Z315900
HIT-6691457.A83
6691457
|
£8.48
|
£10.18
|
|
|
168 - PUMP DIAPHRAGM TILL Z315900
HIT-6684693.A183
6684693
|
£5.70
|
£6.84
|
|
|
169 - INLET SCREEN TILL Z315900
HIT-6684700.A198
6684700
|
-
|
|
|
|
170 - PUMP BODY COMP. TILL Z315900
HIT-6691432.A5
6691432
|
-
|
|
|
|
171 - DIAPHRAGM GASKET TILL Z315900
HIT-6690837.A1
6690837
|
£3.29
|
£3.95
|
|
|
172 - METERING DIAPHRAGM COMP. TILL Z315900
HIT-6690827.A9
6690827
|
£14.02
|
£16.83
|
|
|
173 - DIAPHRAGM COVER-METERING TILL Z315900
HIT-6685222.A71
6685222
|
£5.70
|
£6.84
|
|
|
174 - SET SCREW TILL Z315900
HIT-6691312.A35
6691312
|
-
|
|
|
|
175 - CABLE ADJUSTER TILL Z315900
HIT-6684871.A55
6684871
|
-
|
|
|
|
176 - LOCK NUT M6 TILL Z315900
HIT-6684872.A11
6684872
|
-
|
|
|
|
177 - CLEANER PACKING TILL Z315900
HIT-6684875.A66
6684875
|
-
|
|
|
|
178 - THRUST WASHER TILL Z315900
HIT-6684874.A9
6684874
|
-
|
|
|
|
181 - THROTTLE SET SCREW SINCE Z315901
HIT-6684870.A10
6684870
|
-
|
|
|
|
182 - CABLE ADJUSTER STAY SINCE Z315901
HIT-6684873.A63
6684873
|
-
|
|
|
|
183 - SWIVEL SINCE Z315901
HIT-6684697.A20
6684697
|
-
|
|
|
|
184 - STOP RING SINCE Z315901
HIT-6684696.A195
6684696
|
-
|
|
|
|
185 - O-RING SINCE Z315901
HIT-6684695.A22
6684695
|
£1.67
|
£2.00
|
|
|
186 - MAIN JET #37 SINCE Z315901
HIT-6684877.A2
6684877
|
£8.18
|
£9.81
|
|
|
187 - PUMP GASKET SINCE Z315901
HIT-6691457.A84
6691457
|
£8.48
|
£10.18
|
|
|
188 - PUMP DIAPHRAGM SINCE Z315901
HIT-6684693.A182
6684693
|
£5.70
|
£6.84
|
|
|
189 - INLET SCREEN SINCE Z315901
HIT-6684700.A197
6684700
|
-
|
|
|
|
190 - PUMP BODY COMP. SINCE Z315901
HIT-6684879.A69
6684879
|
£35.37
|
£42.44
|
|
|
191 - DIAPHRAGM GASKET SINCE Z315901
HIT-6684691.A91
6684691
|
£5.70
|
£6.84
|
|
|
192 - METERING DIAPHRAGM COMP. SINCE Z315901
HIT-6690830.A55
6690830
|
£14.58
|
£17.50
|
|
|
193 - DIAPHRAGM COVER SINCE Z315901
HIT-6684688.A9
6684688
|
£5.70
|
£6.84
|
|
|
194 - SET SCREW SINCE Z315901
HIT-6684699.A19
6684699
|
-
|
|
|
|
195 - CABLE ADJUSTER SINCE Z315901
HIT-6684871.A54
6684871
|
-
|
|
|
|
196 - LOCK NUT M6 SINCE Z315901
HIT-6684872.A12
6684872
|
-
|
|
|
|
197 - CLEANER PACKING SINCE Z315901
HIT-6684875.A65
6684875
|
-
|
|
|
|
198 - PRIMING PUMP COMP. SINCE Z315901
HIT-6684687.A90
6684687
|
£9.27
|
£11.12
|
|
|
199 - PRIMING BODY SINCE Z315901
HIT-6684689.A92
6684689
|
£5.87
|
£7.04
|
|
|
200 - THRUST WASHER SINCE Z315901
HIT-6684874.A10
6684874
|
-
|
|
|
|
211 - GEAR CASE A
HIT-6685576.A0
6685576
|
-
|
|
|
|
212 - NO LONGER AVAILABLE
HIT-6685593.A8
6685593
|
-
|
|
|
|
213 - SHIFT FORK COMP.
HIT-6686684.A2
6686684
|
-
|
|
|
|
214 - SHIFT GUIDE SPRING
HIT-6686837.A2
6686837
|
£1.67
|
£2.00
|
|
|
215 - SHIFT LEVER
HIT-6686862.A2
6686862
|
£5.17
|
£6.20
|
|
|
216 - GREASE NIPPLE COMP.
HIT-6688643.A31
6688643
|
£1.67
|
£2.00
|
|
|
217 - STEEL BALL
HIT-6692271.A9
6692271
|
£1.67
|
£2.00
|
|
|
218 - HEX. HOLE BOLT 4X8
HIT-6695034.A4
6695034
|
£1.67
|
£2.00
|
|
|
219 - BOLT WASHER M4
HIT-6685070.A17
6685070
|
£1.67
|
£2.00
|
|
|
220 - KNOCK PIN 4X12
HIT-6695521.A21
6695521
|
-
|
|
|
|
221 - NEEDLE BRG TLA912 1.5X5.8
HIT-6695591.A6
6695591
|
-
|
|
|
|
222 - GEAR 4 TILL C070050
HIT-6685787.A1
6685787
|
£40.30
|
£48.36
|
|
|
222A - GEAR 4 SINCE C070051
HIT-6685788.A6
6685788
|
£20.91
|
£25.09
|
|
|
223 - BALL BEARING #7202B 1
HIT-6695587.A7
6695587
|
£26.15
|
£31.38
|
|
|
224 - WASHAER C 5.0
HIT-6686065.A10
6686065
|
-
|
|
|
|
225 - BALL BEARING #6202Z 1
HIT-6695559.A14
6695559
|
£12.76
|
£15.31
|
|
|
226 - STOP RING C-35 1
HIT-6695296.A13
6695296
|
-
|
|
|
|
227 - WOOD-RUFF KEY 3X13X5
HIT-6686455.A3
6686455
|
£1.67
|
£2.00
|
|
|
228 - DRIVE SHAFT
HIT-6685824.A14
6685824
|
£26.42
|
£31.70
|
|
|
229 - SCREW 5X18/S
HIT-6695339.A16
6695339
|
-
|
|
|
|
230 - FORWARD GEAR
HIT-6686378.A2
6686378
|
-
|
|
|
|
231 - THRUST WASHER 2
HIT-6687314.A4
6687314
|
-
|
|
|
|
232 - STOP RING 20 1
HIT-6695316.A2
6695316
|
-
|
|
|
|
233 - NEEDLE ROLLER 6X18
HIT-6695522.A2
6695522
|
-
|
|
|
|
234 - WAVE WASHER B.B 35
HIT-6695206.A10
6695206
|
-
|
|
|
|
235 - THRUST WASHER 0.8
HIT-6687320.A1
6687320
|
-
|
|
|
|
236 - IDLE GEAR
HIT-6686373.A2
6686373
|
-
|
|
|
|
237 - NEEDLE BRG TLA912 1.5X5.8
HIT-6695591.A7
6695591
|
-
|
|
|
|
238 - NO LONGER AVAILABLE
HIT-6686423.A2
6686423
|
-
|
|
|
|
239 - THRUST WASHER 0.8
HIT-6687320.A0
6687320
|
-
|
|
|
|
240 - STOP RING C-24 1
HIT-6684732.A15
6684732
|
£1.67
|
£2.00
|
|
|
241A - RETAINING RING (E-TYPE) FOR D8 SHAFT
HIT-942827.A15
942827
|
£1.67
|
£2.00
|
|
|
242 - BALL BEARING 609Z ST
HIT-6684735.A23
6684735
|
£15.48
|
£18.57
|
|
|
243 - IDLE SHAFT
HIT-6686365.A2
6686365
|
-
|
|
|
|
244 - REVERSE GEAR
HIT-6686411.A2
6686411
|
-
|
|
|
|
245 - NEEDLE BRG TLA912 1.5X5.8
HIT-6695591.A8
6695591
|
-
|
|
|
|
246 - COUNTER SHAFT TILL C070050
HIT-6686426.A0
6686426
|
-
|
|
|
|
246A - COUNTER SHAFT SINCE C070051
HIT-6686427.A0
6686427
|
-
|
|
|
|
247 - STOP RING C-13 1
HIT-6695283.A1
6695283
|
-
|
|
|
|
261 - CLUTCH HOUSING COMP.
HIT-6688199.A0
6688199
|
£19.89
|
£23.87
|
|
|
262 - PLUS BOLT 6X30
HIT-6695022.A10
6695022
|
£1.67
|
£2.00
|
|
|
263 - NUT M6
HIT-6684792.A18
6684792
|
-
|
|
|
|
264 - S.WASHER 6
HIT-6695219.A73
6695219
|
£1.67
|
£2.00
|
|
|
265 - HANDLE COMP.A
HIT-6688369.A4
6688369
|
-
|
|
|
|
266 - HANDLE GRIP A
HIT-6687624.A8
6687624
|
£7.34
|
£8.81
|
|
|
267 - THROTTLE LEVER
HIT-6686799.A2
6686799
|
-
|
|
|
|
268 - CORD CLAMP
HIT-6688015.A11
6688015
|
-
|
|
|
|
269 - PLUS BOLT 6X16
HIT-6695019.A12
6695019
|
£1.67
|
£2.00
|
|
|
270 - S.WASHER 6
HIT-6695219.A74
6695219
|
£1.67
|
£2.00
|
|
|
271 - HANDLE COMP. B
HIT-6688373.A0
6688373
|
£20.01
|
£24.01
|
|
|
272 - CHUCK HANDLE HOLDER
HIT-6687420.A8
6687420
|
-
|
|
|
|
273 - S.WASHER 10
HIT-6695225.A2
6695225
|
£1.67
|
£2.00
|
|
|
274 - CLUTCH CASE COMP.
HIT-6687336.A2
6687336
|
£55.25
|
£66.30
|
|
|
275 - KNOCK PIN 4X12
HIT-6695521.A20
6695521
|
-
|
|
|
|
276 - PROTECTION TUBE 10X340L
HIT-6687574.A2
6687574
|
-
|
|
|
|
277 - SCREW 5X25
HIT-6694896.A4
6694896
|
-
|
|
|
|
278 - NUT M5
HIT-6684965.A16
6684965
|
£1.67
|
£2.00
|
|
|
279 - SCREW 5X18/S
HIT-6695339.A17
6695339
|
-
|
|
|
|
280 - BUTTON STOP
HIT-6688366.A16
6688366
|
£1.67
|
£2.00
|
|
|
281 - SCREW 3X10
HIT-6684913.A2
6684913
|
£1.67
|
£2.00
|
|
|
282 - STOP SWITCH COMP.
HIT-6687431.A2
6687431
|
£12.76
|
£15.31
|
|
|
283 - STOP BUTTON MARK
HIT-6694589.A2
6694589
|
£3.37
|
£4.04
|
|
|
284 - THROTTLE WIRE COMP.
HIT-6693862.A0
6693862
|
-
|
|
|
|
285 - HANDLE SUPPORT COMP.
HIT-6688402.A2
6688402
|
-
|
|
|
|
501 - CHUCK HANDLE SET
HIT-6686372.A5
6686372
|
£45.98
|
£55.17
|
|
|
502 - DRILL CHUCK ASS'Y
HIT-6686377.A2
6686377
|
£64.09
|
£76.91
|
|
|
503 - CHUCK HANDLE COMP.
HIT-6686410.A2
6686410
|
£11.25
|
£13.50
|
|
|
504 - COMBI BOX SPANNER 13X19 PLUS
HIT-6684979.A21
6684979
|
-
|
|
|
|
505 - SPECIAL WRENCH 31
HIT-6693647.A0
6693647
|
-
|
|
|
