Hitachi / Hikoki TED-262HS Engine Drill Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TED-262HS Engine Drill

	Ex VAT	Inc VAT
1 - CYLINDER SET HIT-6685453.A0 6685453	£82.78	£99.34
2 - SPARK PLUG ASS'Y BM6A HIT-6699313.A0 6699313	-
3 - SPARK PLUG CAP ASS'Y HIT-6687468.A44 6687468	£3.64	£4.37
4 - CYLINDER GASKET HIT-6685720.A2 6685720	-
5 - PISTON RING HIT-6684588.A15 6684588	£6.38	£7.66
6 - PISTON SET HIT-6685876.A2 6685876	£33.90	£40.68
7 - PISTON PIN HIT-6686016.A5 6686016	-
8 - CIRCLIP HIT-6685078.A12 6685078	-
9 - CRANK SHAFT COMP. HIT-6686165.A2 6686165	-
10 - NEEDLE BEARING KTV91313 2X7.8 HIT-6695595.A2 6695595	-
11 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A58 6684899	-
12 - HEX. HOLE BOLT M5X16/S HIT-6684903.A13 6684903	-
*21 - CRANK SHAFT SHIM 0.10 HIT-6686470.A15 6686470	-
*21 - CRANK SHAFT SHIM 0.20 HIT-6686472.A1 6686472	£1.67	£2.00
*21 - CRANK SHAFT SHIM 0.30 HIT-6686473.A30 6686473	£1.67	£2.00
22 - BALL BEARING 6002 C3 HIT-6697745.A12 6697745	-
23 - BALL BEARING 6001 C3 HIT-6684608.A175 6684608	£5.70	£6.84
24 - OIL SEAL UD15257 HIT-6695637.A8 6695637	£3.66	£4.39
25 - OIL SEAL TB 12227 HIT-6684607.A18 6684607	£4.07	£4.88
26 - CRANK CASE GASKET HIT-6686687.A2 6686687	-
27 - CRANK CASE ASS'Y HIT-6686514.A0 6686514	-
28 - CLUTCH WASHER B HIT-6689645.A45 6689645	£1.67	£2.00
29 - STARTER PULLEY HIT-6693393.A2 6693393	£16.36	£19.63
30 - MAGNETO ROTOR COMP. HIT-6687409.A2 6687409	-
31 - IGNITION COIL BRACKET HIT-6687622.A2 6687622	-
32 - IGNITION COIL ASS'Y HIT-6687661.A2 6687661	-
33 - HEX. NUT M8 HIT-6684612.A27 6684612	-
34 - SMALL WASHER 8 HIT-6695184.A1 6695184	-
35 - HEX. NUT M8 HIT-6684612.A28 6684612	-
36 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A80 6684786	£1.67	£2.00
37 - SCREW 5X16/S HIT-6695337.A7 6695337	-
38 - HIGH TENSION SCREW 4X18WS HIT-6695407.A58 6695407	-
40 - RUBBER CAP HIT-6684602.A12 6684602	-
41 - HIGHTENSION CORD 120L HIT-6687886.A0 6687886	-
51 - TANK BRACKET HIT-6692204.A2 6692204	-
52 - FUEL TANK CUSHION RUBBER HIT-6692227.A6 6692227	£1.67	£2.00
55 - CARBURETOR GASKET HIT-6684615.A35 6684615	£1.67	£2.00
56 - CARBURETOR SET WYJ197 TILL Z207350 HIT-6690455.A2 6690455	£75.79	£90.95
57 - SHIELD TUBE HIT-6685247.A13 6685247	£4.32	£5.19
58 - PUMP FILTER BODY ASS'Y HIT-6692279.A3 6692279	£9.30	£11.16
59 - CLIP 1 HIT-6684619.A53 6684619	£1.67	£2.00
60A - TANK CAP D ASS'Y 1 HIT-6691715.A11 6691715	£8.55	£10.26
60A - TANK CAP D ASS'Y SINCE Z207351 HIT-6691748.A14 6691748	£6.04	£7.25
61 - FUEL TANK TILL Z207350 HIT-6691500.A0 6691500	-
61A - TANK TILL C230350 HIT-6691504.A0 6691504	-
61B - TANK COMP. WHITE SINCE C230351 HIT-6691501.A2 6691501	-
62 - SCREW 4X18/PS HIT-6695375.A11 6695375	-
63 - PLUS SCREW 5X60WS HIT-6695431.A2 6695431	-
64 - FUEL PIPE 3X5X75 SINCE Z207351 HIT-6692357.A0 6692357	£1.67	£2.00
65 - RETURN GROMMET SINCE Z207351 HIT-6697846.A46 6697846	£2.08	£2.50
66 - SCREW 4X14/PS HIT-6695372.A5 6695372	-
67 - SCREW 5X24WS HIT-6695423.A14 6695423	-
68 - AIR VENT ASS'Y TILL Z207350 HIT-6691389.A7 6691389	£16.64	£19.97
70 - AIR VENT VALVE ASS'Y TILL Z207350 HIT-6692171.A7 6692171	-
81 - MUFFLER PROTECTOR HIT-6692770.A0 6692770	-
82 - PRIMARY CORD GROMMET HIT-6688051.A2 6688051	-
83 - CLUTCH WASHER B HIT-6684642.A5 6684642	£1.67	£2.00
84 - CLUTCH SHOE COMP. HIT-6684643.A20 6684643	£12.01	£14.41
85 - CLUTCH SPRING HIT-6684644.A3 6684644	£3.12	£3.74
86 - WASHER HIT-6689637.A0 6689637	-
87 - STEP BOLT HIT-6684646.A3 6684646	£3.72	£4.46
88 - FAN CASE COMP. HIT-6686939.A0 6686939	-
89 - HEAT SHIELD HIT-6687234.A2 6687234	-
90 - MUFFLER GASKET HIT-6692731.A0 6692731	-
93 - MUFFLER BODY B COMP. HIT-6692622.A0 6692622	-
95 - SCREW 5X12/PS TILL C034950 HIT-6695383.A4 6695383	£1.67	£2.00
95A - SCREW 5X12/WS SINCE C034951 HIT-6695415.A0 6695415	-
96 - SCREW 5X16/PS SINCE C034951 HIT-6695386.A6 6695386	£1.67	£2.00
97 - SCREW 4X12/P HIT-6695317.A2 6695317	-
98 - HEX. HOLE BOLT 5X45 HIT-6695055.A19 6695055	£1.67	£2.00
99 - WASHER M5 (BLACK) HIT-6684918.A21 6684918	£1.67	£2.00
100 - SCREW 5X16/S HIT-6695337.A6 6695337	-
101 - SCREW 5X10/P HIT-6695319.A0 6695319	-
121 - AIR CLEANER ASS'Y HIT-6690025.A0 6690025	-
122 - AIR CLEANER CAP HIT-6690142.A4 6690142	£9.10	£10.92
123 - CLEANER ELEMENT HIT-6690350.A2 6690350	£7.15	£8.58
124 - SPACER HIT-6684859.A12 6684859	-
125 - COLLAR HIT-6690801.A14 6690801	-
126 - CHOKE PLATE 1 HIT-6691267.A5 6691267	-
127 - CLEANER BODY COMP. HIT-6690091.A3 6690091	£9.67	£11.60
142 - STARTER HANDLE HIT-6693224.A0 6693224	-
143 - RECOIL STARTER BODY COMP. HIT-6693019.A0 6693019	-
144 - RECOIL SPRING HIT-6693129.A0 6693129	-
145 - STARTER ROPE HIT-6693152.A0 6693152	-
146 - STARTER PULLEY HIT-6693058.A2 6693058	-
147 - STARTER PAWL HIT-6693303.A0 6693303	£4.26	£5.11
148 - STARTER REEL WASHER HIT-6693420.A0 6693420	-
149 - FRICTION PLATE HIT-6693623.A2 6693623	-
150 - STARTER PAWL SHIM HIT-6693564.A0 6693564	-
151 - SET BOLT HIT-6693635.A0 6693635	-
161 - THROTTLE SET SCREW TILL Z207350 HIT-6684870.A13 6684870	-
162 - CABLE ADJUSTER STAY TILL Z207350 HIT-6684873.A60 6684873	-
163 - SWIVEL TILL Z207350 HIT-6684697.A15 6684697	-
164 - STOP RING TILL Z207350 HIT-6684696.A200 6684696	-
165 - O-RING TILL Z207350 HIT-6684695.A17 6684695	£1.67	£2.00
166 - MAIN JET #37.5 TILL Z207350 HIT-6691882.A2 6691882	-
167 - PUMP GASKET TILL Z207350 HIT-6691457.A81 6691457	£8.48	£10.18
168 - PUMP DIAPHRAGM TILL Z207350 HIT-6684693.A187 6684693	£5.70	£6.84
169 - INLET SCREEN TILL Z207350 HIT-6684700.A191 6684700	-
170 - PUMP BODY COMP. TILL Z207350 HIT-6691432.A3 6691432	-
171 - DIAPHRAGM GASKET TILL Z207350 HIT-6690837.A2 6690837	£3.29	£3.95
172 - METERING DIAPHRAGM COMP. TILL Z207350 HIT-6690827.A6 6690827	£14.02	£16.83
173 - DIAPHRAGM COVER-METERING TILL Z207350 HIT-6685222.A69 6685222	£5.70	£6.84
174 - SET SCREW TILL Z207350 HIT-6691312.A34 6691312	-
175 - CABLE ADJUSTER TILL Z207350 HIT-6684871.A51 6684871	-
176 - LOCK NUT M6 TILL Z207350 HIT-6684872.A15 6684872	-
177 - CLEANER PACKING TILL Z207350 HIT-6684875.A62 6684875	-
178 - THRUST WASHER TILL Z207350 HIT-6684874.A13 6684874	-
181 - THROTTLE SET SCREW SINCE Z207351 HIT-6684870.A14 6684870	-
182 - CABLE ADJUSTER STAY SINCE Z207351 HIT-6684873.A59 6684873	-
183 - SWIVEL SINCE Z207351 HIT-6684697.A16 6684697	-
184 - STOP RING SINCE Z207351 HIT-6684696.A198 6684696	-
185 - O-RING SINCE Z207351 HIT-6684695.A18 6684695	£1.67	£2.00
186 - MAIN JET #37 SINCE Z207351 HIT-6684877.A4 6684877	£8.18	£9.81
187 - PUMP GASKET SINCE Z207351 HIT-6691457.A82 6691457	£8.48	£10.18
188 - PUMP DIAPHRAGM SINCE Z207351 HIT-6684693.A186 6684693	£5.70	£6.84
189 - INLET SCREEN SINCE Z207351 HIT-6684700.A190 6684700	-
190 - PUMP BODY COMP. SINCE Z207351 HIT-6684879.A67 6684879	£35.37	£42.44
191 - DIAPHRAGM GASKET SINCE Z207351 HIT-6684691.A90 6684691	£5.70	£6.84
192 - METERING DIAPHRAGM COMP. SINCE Z207351 HIT-6690830.A58 6690830	£14.58	£17.50
193 - DIAPHRAGM COVER SINCE Z207351 HIT-6684688.A7 6684688	£5.70	£6.84
194 - SET SCREW SINCE Z207351 HIT-6684699.A21 6684699	-
195 - CABLE ADJUSTER SINCE Z207351 HIT-6684871.A50 6684871	-
196 - LOCK NUT M6 SINCE Z207351 HIT-6684872.A16 6684872	-
197 - CLEANER PACKING SINCE Z207351 HIT-6684875.A61 6684875	-
198 - PRIMING PUMP COMP. SINCE Z207351 HIT-6684687.A92 6684687	£9.27	£11.12
199 - PRIMING BODY SINCE Z207351 HIT-6684689.A94 6684689	£5.87	£7.04
200 - THRUST WASHER SINCE Z207351 HIT-6684874.A14 6684874	-
211 - GEAR CASE A COMP. HIT-6685578.A11 6685578	£62.67	£75.20
212 - NO LONGER AVAILABLE HIT-6685593.A5 6685593	-
213 - CLUTCH HOUSING COMP. HIT-6688198.A1 6688198	-
214 - BALL BEARING #6001Z 1 HIT-6695532.A24 6695532	£15.01	£18.01
215 - BALL BEARING 6001 C3 HIT-6684608.A177 6684608	£5.70	£6.84
216 - STOP RING C-12 OUTER HIT-6684664.A16 6684664	-
217 - BALL BEARING #7202B 1 HIT-6695587.A5 6695587	£26.15	£31.38
218 - WASHAER C 5.0 HIT-6686065.A8 6686065	-
219 - BALL BEARING #6202Z 1 HIT-6695559.A16 6695559	£12.76	£15.31
220 - STOP RING C-35 1 HIT-6695296.A12 6695296	-
221 - WOOD-RUFF KEY 3X13X5 HIT-6686455.A0 6686455	£1.67	£2.00
222 - PLUS BOLT 6X30 HIT-6695022.A11 6695022	£1.67	£2.00
223 - NUT M6 HIT-6684792.A17 6684792	-
224 - S.WASHER 6 HIT-6695219.A76 6695219	£1.67	£2.00
225 - SCREW 5X18/S HIT-6695339.A15 6695339	-
226 - WAVE WASHER B.B 35 HIT-6695206.A9 6695206	-
227 - GREASE NIPPLE COMP. HIT-6688643.A34 6688643	£1.67	£2.00
228 - STOP RING C-13 1 HIT-6695283.A2 6695283	-
229 - GEAR 4 HIT-6685786.A1 6685786	-
230 - DRIVE SHAFT HIT-6685824.A12 6685824	£26.42	£31.70
231 - GEAR 2 HIT-6685655.A3 6685655	-
232 - GEAR 3 HIT-6685703.A0 6685703	-
233 - WOOD-RUFF KEY 3X10X3.7 HIT-6686454.A10 6686454	-
251 - HANDLE COMP.A HIT-6688369.A2 6688369	-
252 - HANDLE GRIP A HIT-6687624.A7 6687624	£7.34	£8.81
253 - THROTTLE LEVER HIT-6686799.A0 6686799	-
254 - SCREW 5X25 HIT-6694896.A5 6694896	-
255 - NUT M5 HIT-6684965.A18 6684965	£1.67	£2.00
256 - CORD CLAMP HIT-6688015.A13 6688015	-
257 - PLUS BOLT 6X16 HIT-6695019.A11 6695019	£1.67	£2.00
258 - S.WASHER 6 HIT-6695219.A75 6695219	£1.67	£2.00
259 - HANDLE COMP. B HIT-6688373.A2 6688373	£20.01	£24.01
260 - S.WASHER 10 HIT-6695225.A1 6695225	£1.67	£2.00
261 - STOP SWITCH COMP. HIT-6687431.A5 6687431	£12.76	£15.31
262 - PROTECTION TUBE 10X340L HIT-6687574.A1 6687574	-
263 - CHUCK HANDLE HOLDER HIT-6687420.A6 6687420	-
264 - BUTTON STOP HIT-6688366.A18 6688366	£1.67	£2.00
265 - SCREW 3X10 HIT-6684913.A4 6684913	£1.67	£2.00
266 - STOP BUTTON MARK HIT-6694589.A1 6694589	£3.37	£4.04
267 - THROTTLE WIRE COMP. HIT-6693862.A1 6693862	-
268 - HANDLE SUPPORT COMP. HIT-6688402.A0 6688402	-
501 - COMBI BOX SPANNER 13X19 PLUS HIT-6684979.A20 6684979	-
