1 - SPARK PLUG CAP ASS'Y
HIT-6687468.A6
6687468
|
£3.64
|
£4.37
|
|
|
*2A - SPARK PLUG ASS'Y BMR6A FOR EUROPE
HIT-6699315.A11
6699315
|
-
|
|
|
|
*2A - SPARK PLUG ASS'Y BM6A FOR USA
HIT-6699313.A3
6699313
|
-
|
|
|
|
3 - SCREW 5X10/P
HIT-6695319.A11
6695319
|
-
|
|
|
|
4 - CORD CLAMP L
HIT-6688009.A1
6688009
|
-
|
|
|
|
5 - CYLINDER COVER
HIT-6685695.A0
6685695
|
-
|
|
|
|
7 - CYLINDER SET
HIT-6685498.A1
6685498
|
-
|
|
|
|
8 - STUD BOLT 6X22
HIT-6686771.A7
6686771
|
-
|
|
|
|
10 - HEX. HOLE BOLT 6X18/S
HIT-6695495.A29
6695495
|
-
|
|
|
|
12 - CYLINDER GASKET
HIT-6685752.A2
6685752
|
-
|
|
|
|
13 - PISTON RING
HIT-6686051.A2
6686051
|
-
|
|
|
|
14 - PISTON RING
HIT-6686133.A1
6686133
|
-
|
|
|
|
15 - PISTON SET PN
HIT-6685904.A1
6685904
|
-
|
|
|
|
16 - PISTON PIN 10X35
HIT-6686019.A7
6686019
|
£4.12
|
£4.94
|
|
|
17 - PISTON PIN CIRCLIP
HIT-6686029.A3
6686029
|
-
|
|
|
|
18 - CRANK SHAFT COMP.
HIT-6686224.A1
6686224
|
-
|
|
|
|
20 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A33
6684899
|
-
|
|
|
|
21 - WOOD-RUFF KEY 3X13X5
HIT-6686457.A14
6686457
|
£1.67
|
£2.00
|
|
|
*41 - CRANK SHAFT SHIM 0.20
HIT-6686472.A26
6686472
|
£1.67
|
£2.00
|
|
|
*41 - CRANK SHAFT SHIM 0.30
HIT-6686473.A5
6686473
|
£1.67
|
£2.00
|
|
|
42 - SMALL NUT 10
HIT-6695139.A7
6695139
|
-
|
|
|
|
43 - PULLEY WASHER
HIT-6684820.A9
6684820
|
-
|
|
|
|
44 - STARTER PULLEY
HIT-6693409.A1
6693409
|
-
|
|
|
|
47 - CRANK CASE ASS'Y
HIT-6686595.A1
6686595
|
-
|
|
|
|
49 - CRANK CASE GASKET
HIT-6686727.A1
6686727
|
-
|
|
|
|
50 - OIL SEAL 15307
HIT-6695641.A1
6695641
|
-
|
|
|
|
51 - BALL BEARING #6202 1
HIT-6695557.A25
6695557
|
-
|
|
|
|
52 - NO LONGER AVAILABLE
HIT-6695562.A2
6695562
|
-
|
|
|
|
53 - OIL SEAL UE17307
HIT-6695648.A10
6695648
|
-
|
|
|
|
54 - HEX.HOLE BOLT 6X30/S
HIT-6695499.A1
6695499
|
-
|
|
|
|
55 - DRAIN GASKET
HIT-6692685.A1
6692685
|
-
|
|
|
|
56 - SCREW 6X10
HIT-6694926.A1
6694926
|
-
|
|
|
|
57 - GOVERNOR SHAFT
HIT-6689682.A0
6689682
|
-
|
|
|
|
59 - GOVERNOR SHAFT ARM
HIT-6689679.A4
6689679
|
-
|
|
|
|
60 - SCREW 3X6
HIT-6694855.A1
6694855
|
-
|
|
|
|
61 - OIL PARTITION
HIT-6689175.A1
6689175
|
-
|
|
|
|
62 - SCREW 4X8
HIT-6694861.A0
6694861
|
-
|
|
|
|
63 - GOVERNOR ASS'Y
HIT-6687057.A1
6687057
|
-
|
|
|
|
65 - GOVERNOR PLATE
HIT-6689780.A1
6689780
|
-
|
|
|
|
67 - GOVERNOR SLEEVE
HIT-6689782.A0
6689782
|
-
|
|
|
|
68 - STOP RING C-15 1
HIT-6695285.A20
6695285
|
£1.67
|
£2.00
|
|
|
81 - GOVERNOR COVER GASKET
HIT-6689775.A1
6689775
|
-
|
|
|
|
82 - GOVERNOR COVER ASS'Y
HIT-6689771.A4
6689771
|
-
|
|
|
|
83 - OIL SEAL UD15257
HIT-6695637.A29
6695637
|
£3.66
|
£4.39
|
|
|
84 - SCREW 4X10
HIT-6694863.A4
6694863
|
-
|
|
|
|
85 - MAGNETO ROTOR COMP
HIT-6699709.A1
6699709
|
-
|
|
|
|
86 - WASHER 10
HIT-6695198.A14
6695198
|
-
|
|
|
|
87 - NUT 10 (L.H. THREAD)
HIT-6695134.A0
6695134
|
-
|
|
|
|
89 - SCREW 4X22/WS
HIT-6695410.A8
6695410
|
-
|
|
|
|
93 - IGNITION COIL ASS'Y
HIT-6695943.A1
6695943
|
-
|
|
|
|
95 - FAN CASE
HIT-6687046.A0
6687046
|
-
|
|
|
|
96 - GROMMET
HIT-6688040.A9
6688040
|
-
|
|
|
|
97 - CORD CLAMP COMP.
HIT-6688004.A10
6688004
|
-
|
|
|
|
98 - SCREW 6X25/S
HIT-6695363.A4
6695363
|
-
|
|
|
|
103 - STUD BOLT 6X36
HIT-6686772.A3
6686772
|
-
|
|
|
|
104 - STOP CORD COMP. TILL F026562
HIT-6687826.A7
6687826
|
-
|
|
|
|
104A - CORD B135M SINCE F026563
HIT-6696371.A0
6696371
|
-
|
|
|
|
121 - INLET MANIFOLD GASKET
HIT-6689899.A0
6689899
|
-
|
|
|
|
122 - CARBURETOR INSULATOR SET
HIT-6689980.A0
6689980
|
-
|
|
|
|
123 - CARBURETOR GASKET
HIT-6689826.A7
6689826
|
£1.67
|
£2.00
|
|
|
124 - SCREW 5X24WS
HIT-6695423.A3
6695423
|
-
|
|
|
|
125 - CHOKE LEVER
HIT-6691004.A2
6691004
|
£2.98
|
£3.57
|
|
|
126 - CLEANER BODY BLK
HIT-6696027.A0
6696027
|
-
|
|
|
|
127 - COLLAR 5.8
HIT-6692244.A0
6692244
|
£1.67
|
£2.00
|
|
|
128 - SCREW 5X55S
HIT-6695352.A2
6695352
|
-
|
|
|
|
130 - SMALL WASHER 5
HIT-6684864.A131
6684864
|
-
|
|
|
|
131 - SPONGE
HIT-6690366.A2
6690366
|
£3.62
|
£4.35
|
|
|
132 - CLEANER CAP
HIT-6690158.A0
6690158
|
-
|
|
|
|
133 - CARBURETOR SET HDA178 FOR USA
HIT-6690523.A1
6690523
|
-
|
|
|
|
134 - THROTTLE ROD
HIT-6690964.A1
6690964
|
-
|
|
|
|
135 - GOVERNOR ROD SPRING
HIT-6689714.A2
6689714
|
-
|
|
|
|
136 - GOVERNOR OUTER LEVER
HIT-6689719.A0
6689719
|
-
|
|
|
|
137 - GOVERNOR SPRING LEVER
HIT-6689687.A2
6689687
|
-
|
|
|
|
138 - S.WASHER 6
HIT-6695219.A39
6695219
|
£1.67
|
£2.00
|
|
|
139 - LOCK NUT M6
HIT-6684872.A77
6684872
|
-
|
|
|
|
140 - SCREW 4X8/PS
HIT-6695368.A1
6695368
|
-
|
|
|
|
141 - GOVERNOR SPRING
HIT-6689697.A3
6689697
|
-
|
|
|
|
142 - CONTROL LEVER ASS'Y
HIT-6693590.A0
6693590
|
-
|
|
|
|
143 - SCREW 5X10 WS
HIT-6695413.A0
6695413
|
-
|
|
|
|
144 - WIRE RETURN SPRING
HIT-6694056.A0
6694056
|
-
|
|
|
|
145 - THROTTLE SHAFT GUIDE
HIT-6694037.A0
6694037
|
-
|
|
|
|
146 - STEP BOLT
HIT-6689627.A12
6689627
|
£1.67
|
£2.00
|
|
|
147 - WIRE CLAMP
HIT-6694057.A1
6694057
|
-
|
|
|
|
148 - SCREW 5X10 WS
HIT-6695413.A1
6695413
|
-
|
|
|
|
149 - U-NUT 6
HIT-6695159.A1
6695159
|
-
|
|
|
|
150 - CARBURETOR ASS'Y 1
HIT-6690590.A0
6690590
|
-
|
|
|
|
150A - CARBURETOR SET HDA178 SINCE B001001 FOR EUROPE
HIT-6690523.A2
6690523
|
-
|
|
|
|
161 - SCREW 6X8/S
HIT-6695356.A0
6695356
|
-
|
|
|
|
162 - BOLT WASHER 6
HIT-6684639.A100
6684639
|
£1.67
|
£2.00
|
|
|
163 - MUFFLER PROTECTOR
HIT-6692820.A1
6692820
|
-
|
|
|
|
164 - MUFFLER STAY
HIT-6692706.A0
6692706
|
-
|
|
|
|
165 - SCREW 6X12/PS
HIT-6695399.A10
6695399
|
-
|
|
|
|
166 - MUFFLER SET FOR USA
HIT-6697637.A0
6697637
|
-
|
|
|
|
167 - NUT M6
HIT-6684792.A35
6684792
|
-
|
|
|
|
168 - S.WASHER 6
HIT-6695219.A40
6695219
|
£1.67
|
£2.00
|
|
|
169 - MUFFLER GASKET 1.5T
HIT-6692746.A2
6692746
|
-
|
|
|
|
170 - SCREW 5X18/PS
HIT-6695388.A1
6695388
|
-
|
|
|
|
171 - FUEL TANK BAND COMP.
HIT-6691926.A1
6691926
|
-
|
|
|
|
172A - TANK F.T. SINCE TL000001 FOR USA
HIT-6699758.A0
6699758
|
-
|
|
|
|
172B - TANK TILL F202200 FOR USA
HIT-6601173.A0
6601173
|
£16.28
|
£19.54
|
|
|
173 - TANK TILL TL025381 FOR EUROPE
HIT-6601173.A1
6601173
|
£16.28
|
£19.54
|
|
|
173A - TANK SINCE TL025382 FOR EUROPE
HIT-6601177.A2
6601177
|
-
|
|
|
|
174A - PUMP FILTER BODY COMP
HIT-66A3864.A88
66A3864
|
-
|
|
|
|
*175 - HOSE CLIP ASS'Y TILL F202200 FOR USA
HIT-6692316.A2
6692316
|
-
|
|
|
|
*176 - RETAINING RING E-TYPE D6 TILL F202200 FOR USA
HIT-6695310.A0
6695310
|
£1.67
|
£2.00
|
|
|
*177 - SMALL WASHER 8 TILL F202200 FOR USA
HIT-6695184.A13
6695184
|
-
|
|
|
|
*178 - PET-COCK HOLDING RUBBER TILL F202200 FOR USA
HIT-6691333.A2
6691333
|
£1.67
|
£2.00
|
|
|
*179 - PET-COCK ASS'Y TILL F202200 FOR USA
HIT-6691653.A2
6691653
|
-
|
|
|
|
*180 - FUEL PIPE 3X5X230 TILL F202200 FOR USA
HIT-6692366.A1
6692366
|
-
|
|
|
|
*181 - CLIP 7 TILL F202200 FOR USA
HIT-6692312.A28
6692312
|
-
|
|
|
|
*181A - CLIP D6 SINCE TL000001 FOR USA
HIT-6685198.A70
6685198
|
-
|
|
|
|
*182 - RUBBER PIPE TILL F202200 FOR USA
HIT-6692297.A2
6692297
|
-
|
|
|
|
183 - CUSHION RUBBER
HIT-6692232.A2
6692232
|
-
|
|
|
|
184 - TANK HOLDING METAL COMP.
HIT-6691985.A1
6691985
|
-
|
|
|
|
185 - SCREW 6X12/PS
HIT-6695399.A11
6695399
|
-
|
|
|
|
186A - TANK CAP D ASS'Y BLACK
HIT-6691740.A2
6691740
|
£9.00
|
£10.80
|
|
|
187 - TANK CAP CHAIN
HIT-6684625.A39
6684625
|
-
|
|
|
|
188 - CLUTCH WASHER B
HIT-6689645.A9
6689645
|
£1.67
|
£2.00
|
|
|
189 - CLUTCH ARM COMP.
HIT-6688617.A1
6688617
|
£16.11
|
£19.33
|
|
|
190 - CLUTCH WASHER A
HIT-6689638.A6
6689638
|
£1.67
|
£2.00
|
|
|
191 - CLUTCH STEP BOLT
HIT-6689633.A2
6689633
|
£4.07
|
£4.88
|
|
|
192 - CLUTCH SPRING
HIT-6689434.A2
6689434
|
£3.38
|
£4.06
|
|
|
193 - SPARK ARRESTER COMP. FOR USA
HIT-6692693.A0
6692693
|
-
|
|
|
|
*194 - SHIELD TUBE ASS'Y SINCE TL000001 FOR USA
HIT-6699759.A0
6699759
|
-
|
|
|
|
*194 - SHIELD TUBE ASS'Y SINCE TL025382 FOR EUROPE
HIT-6601178.A0
6601178
|
-
|
|
|
|
*195 - FUEL PIPE COIL SINCE TL000001 FOR USA
HIT-6692428.A1
6692428
|
-
|
|
|
|
*196 - CORD CLAMP COMP. SINCE TL000001 FOR USA
HIT-6688008.A8
6688008
|
-
|
|
|
|
197 - MUFFLER COMP. FOR EUROPE
HIT-6692580.A0
6692580
|
-
|
|
|
|
198 - CLUTCH SET ASS'Y
HIT-6601109.A1
6601109
|
-
|
|
|
|
211 - RECOIL STARTER BODY ASS'Y
HIT-6692995.A0
6692995
|
-
|
|
|
|
212 - RECOIL STARTER BODY
HIT-6693044.A2
6693044
|
-
|
|
|
|
213 - RECOIL SPRING
HIT-6693123.A3
6693123
|
-
|
|
|
|
214 - STARTER ROPE REEL COMP.
HIT-6693085.A1
6693085
|
-
|
|
|
|
215 - STARTER ROPE
HIT-6693176.A1
6693176
|
-
|
|
|
|
216 - STARTER PAWL
HIT-6693322.A1
6693322
|
-
|
|
|
|
217 - FRICTION SPRING
HIT-6693617.A3
6693617
|
-
|
|
|
|
218 - FRICTION PLATE
HIT-6693630.A3
6693630
|
-
|
|
|
|
219 - BOLT 6X12
HIT-6694982.A5
6694982
|
-
|
|
|
|
220 - STARTER HANDLE CAP
HIT-6693610.A1
6693610
|
-
|
|
|
|
221 - ROPE STOPPER
HIT-6693383.A0
6693383
|
-
|
|
|
|
222 - STARTER HANDLE
HIT-6693241.A2
6693241
|
-
|
|
|
|
223 - ROPE GUIDE
HIT-6693140.A3
6693140
|
-
|
|
|
|
281 - SCREW
HIT-6685210.A72
6685210
|
-
|
|
|
|
282 - PUMP BODY
HIT-6691420.A5
6691420
|
-
|
|
|
|
283 - PUMP GASKET
HIT-6691455.A13
6691455
|
-
|
|
|
|
284 - PUMP DIAPHRAGM
HIT-6691446.A6
6691446
|
-
|
|
|
|
285 - INLET SCREEN
HIT-6684700.A85
6684700
|
-
|
|
|
|
286 - IDLE ADJUST SCREW
HIT-6690736.A22
6690736
|
-
|
|
|
|
287 - IDLE ADJUST SPRING
HIT-6690766.A31
6690766
|
-
|
|
|
|
288 - VALVE SPRING FOR USA
HIT-6690873.A27
6690873
|
-
|
|
|
|
289 - CONTROL LEVER
HIT-6690819.A2
6690819
|
-
|
|
|
|
290 - HINGE PIN
HIT-6685219.A70
6685219
|
-
|
|
|
|
291 - HINGE PIN SET SCREW
HIT-6685218.A17
6685218
|
-
|
|
|
|
292 - NEEDLE VALVE
HIT-6685215.A88
6685215
|
£6.79
|
£8.15
|
|
|
293 - DIAPHRAGM GASKET
HIT-6690838.A3
6690838
|
-
|
|
|
|
294 - METERING DIAPHRAGM COMP.
HIT-6690828.A1
6690828
|
-
|
|
|
|
295 - DIAPHRAGM COVER
HIT-6690858.A12
6690858
|
-
|
|
|
|
296 - SET SCREW
HIT-6685223.A15
6685223
|
-
|
|
|
|
297 - LOW ADJUST SCREW TILL B001000 FOR EUROPE
HIT-6690715.A1
6690715
|
-
|
|
|
|
298 - HIGH/LOW ADJUST SPRING TILL B001000 FOR EUROPE
HIT-6692048.A18
6692048
|
-
|
|
|
|
299 - HIGH ADJUST SCREW TILL B001000 FOR EUROPE
HIT-6690692.A1
6690692
|
-
|
|
|
|
300 - VALVE SPRING TILL B001000 FOR EUROPE
HIT-6690867.A1
6690867
|
-
|
|
|
|
300A - VALVE SPRING SINCE B001001 FOR EUROPE
HIT-6690873.A26
6690873
|
-
|
|
|
|
311 - CLUTCH SHAFT COMP.
HIT-6685911.A0
6685911
|
-
|
|
|
|
312 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A34
6684899
|
-
|
|
|
|
313 - GEAR CASE C
HIT-6685596.A0
6685596
|
-
|
|
|
|
314 - SPRING NUT 6
HIT-6695475.A22
6695475
|
-
|
|
|
|
315 - STOP RING C-32 1
HIT-6695295.A26
6695295
|
£1.67
|
£2.00
|
|
|
316 - BALL BEARING #6002Z 2
HIT-6695538.A1
6695538
|
£12.57
|
£15.08
|
|
|
317 - STOP RING C-15 1
HIT-6695285.A21
6695285
|
£1.67
|
£2.00
|
|
|
318 - GEAR CASE A COMP.
HIT-6696365.A1
6696365
|
-
|
|
|
|
319 - S.WASHER 6
HIT-6695219.A38
6695219
|
£1.67
|
£2.00
|
|
|
320 - HEX. HOLE BOLT 6X18
HIT-6695059.A0
6695059
|
-
|
|
|
|
321 - GREASE NIPPLE COMP.
HIT-6688643.A57
6688643
|
£1.67
|
£2.00
|
|
|
322 - LOCK COMP.
HIT-6689987.A0
6689987
|
-
|
|
|
|
323 - LOCK PIN SPRING
HIT-6689905.A0
6689905
|
-
|
|
|
|
324 - WASHER
HIT-6692944.A1
6692944
|
-
|
|
|
|
325 - O-RING P-7
HIT-6695665.A0
6695665
|
-
|
|
|
|
326 - SCREW 5X16/WS
HIT-6695417.A0
6695417
|
-
|
|
|
|
327 - GEAR 1
HIT-6685606.A2
6685606
|
-
|
|
|
|
328 - STOP RING C-10 1
HIT-6684821.A15
6684821
|
£1.67
|
£2.00
|
|
|
329 - STOP RING C-22 1
HIT-6695288.A1
6695288
|
-
|
|
|
|
330 - GEAR 4
HIT-6685789.A1
6685789
|
-
|
|
|
|
331 - BALL BEARING #6202 1
HIT-6695557.A24
6695557
|
-
|
|
|
|
332 - GEAR 2
HIT-6685658.A1
6685658
|
-
|
|
|
|
333 - GEAR 3
HIT-6685704.A1
6685704
|
-
|
|
|
|
334 - WOOD-RUFF KEY 4X16X5
HIT-6686460.A1
6686460
|
-
|
|
|
|
335 - BALL BEARING #6200 1
HIT-6695551.A2
6695551
|
-
|
|
|
|
336 - GEAR CASE B
HIT-6685594.A0
6685594
|
-
|
|
|
|
337 - S.WASHER 6
HIT-6695219.A37
6695219
|
£1.67
|
£2.00
|
|
|
338 - PLUS BOLT 6X22
HIT-6695021.A3
6695021
|
-
|
|
|
|
339 - ROLLER BRG #30205J 6.5X10.5
HIT-6695523.A1
6695523
|
-
|
|
|
|
340 - BEARING STOPPER
HIT-6686066.A0
6686066
|
-
|
|
|
|
341 - BALL BEARING #6205Z 1
HIT-6695565.A0
6695565
|
-
|
|
|
|
342 - WAVE WASHER B.B.
HIT-6695208.A2
6695208
|
-
|
|
|
|
343 - STOP RING C-52 1
HIT-6695300.A3
6695300
|
-
|
|
|
|
344 - DRIVE SHAFT FOR USA
HIT-6685825.A1
6685825
|
-
|
|
|
|
345 - PIN
HIT-6693554.A1
6693554
|
-
|
|
|
|
346 - SNAP PIN 8
HIT-6693558.A5
6693558
|
-
|
|
|
|
347 - DRIVE SHAFT TILL J033370 FOR EUROPE
HIT-6685825.A2
6685825
|
-
|
|
|
|
347A - DRIVE SHAFT SINCE J033371 FOR EUROPE
HIT-6685826.A0
6685826
|
-
|
|
|
|
361 - HANDLE
HIT-6688342.A1
6688342
|
-
|
|
|
|
362 - HANDLE GRIP
HIT-6686351.A0
6686351
|
-
|
|
|
|
364 - HANDLE BRACKET
HIT-6696373.A0
6696373
|
£42.70
|
£51.24
|
|
|
365 - NUT 10
HIT-6695132.A1
6695132
|
-
|
|
|
|
366A - HANDLE KNOB COMP
HIT-6699394.A1
6699394
|
-
|
|
|
|
367 - THROTTLE WIRE COMP.
HIT-6693930.A0
6693930
|
-
|
|
|
|
368 - STOP CORD COMP.
HIT-6687880.A1
6687880
|
-
|
|
|
|
369 - BOLT 6X35
HIT-6694992.A3
6694992
|
-
|
|
|
|
370 - BOLT WASHER 6
HIT-6684639.A101
6684639
|
£1.67
|
£2.00
|
|
|
371 - THROTTLE LEVER COMP.
HIT-6686801.A1
6686801
|
-
|
|
|
|
372 - U-NUT 6
HIT-6695159.A2
6695159
|
-
|
|
|
|
373 - PUSH PIN COMP.
HIT-6686434.A1
6686434
|
-
|
|
|
|
374 - STOP SWITCH BRACKET
HIT-6696370.A0
6696370
|
-
|
|
|
|
375A - STOP SWITCH ASS'Y
HIT-6601374.A10
6601374
|
£16.45
|
£19.74
|
|
|
376 - SWITCH NAME PLATE
HIT-6687949.A13
6687949
|
£1.67
|
£2.00
|
|
|
378 - CORD CLAMP
HIT-6688022.A0
6688022
|
-
|
|
|
|
380 - PROTECTION TUBE 13X680L
HIT-6687616.A0
6687616
|
-
|
|
|
|
381 - PROTECTION TUBE 13X500L
HIT-6687614.A1
6687614
|
-
|
|
|
|
501 - COMBI BOX SPANNER 10/19MM
HIT-6685257.A19
6685257
|
-
|
|
|
|
502 - SPANNER 10X13 TILL K022330
HIT-6693479.A1
6693479
|
-
|
|
|
|
503 - PLUS DRIVER 4 TILL K022330
HIT-6693665.A0
6693665
|
-
|
|
|
|
504 - SPANNER 13X17 TILL K022330
HIT-6693498.A0
6693498
|
-
|
|
|
|
601 - NAME PLATE TEA-500
HIT-6694259.A0
6694259
|
-
|
|
|
