1 - AIR CLEANER BASE
HIT-6685225.A3
6685225
|
-
|
|
|
|
2 - HEX. SOCKET HD. BOLT M5X45 (10 PCS.)
HIT-949824.A4
949824
|
-
|
|
|
|
3 - CLEANER SPONGE (B)
HIT-6696826.A1
6696826
|
-
|
|
|
|
4 - CLEANER ELEMENT A COMP.
HIT-6685230.A3
6685230
|
£4.26
|
£5.11
|
|
|
5 - CLEANER ELEMENT B COMP.
HIT-6685231.A1
6685231
|
£4.26
|
£5.11
|
|
|
6 - CLEANER SPONGE (A)
HIT-6696825.A2
6696825
|
£1.67
|
£2.00
|
|
|
7 - CLEANER COVER
HIT-6696785.A2
6696785
|
£7.03
|
£8.44
|
|
|
8 - CLEANER KNOB
HIT-6696786.A1
6696786
|
£1.67
|
£2.00
|
|
|
9 - TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
HIT-305812.A107
305812
|
£1.67
|
£2.00
|
|
|
10 - MUFFLER COVER
HIT-6696821.A4
6696821
|
-
|
|
|
|
11A - CLUTCH
HIT-6600316.A7
6600316
|
-
|
|
|
|
12 - CLUTCH HOUSING
HIT-6698856.A3
6698856
|
-
|
|
|
|
13 - NEEDLE BEARING (D)
HIT-6685361.A1
6685361
|
£12.57
|
£15.08
|
|
|
14 - CLUTCH WASHER
HIT-6685414.A7
6685414
|
£3.49
|
£4.19
|
|
|
15 - CRANK SHAFT COLLAR
HIT-6685360.A10
6685360
|
£6.75
|
£8.10
|
|
|
16A - OIL PUMP COVER
HIT-6699610.A6
6699610
|
-
|
|
|
|
17 - NEEDLE ROLLER 2.5X19.8
HIT-6685356.A8
6685356
|
£3.49
|
£4.19
|
|
|
18 - PUMP GEAR
HIT-6685354.A5
6685354
|
£6.75
|
£8.10
|
|
|
19 - PUMP GEAR SPRING
HIT-6685355.A0
6685355
|
£3.49
|
£4.19
|
|
|
20A - PUMP CASE
HIT-6699119.A7
6699119
|
-
|
|
|
|
21A - PUMP ASS'Y INCLUD.17-20
HIT-6699120.A0
6699120
|
-
|
|
|
|
22 - SEAL LOCK BOLT M5X15
HIT-6685136.A7
6685136
|
-
|
|
|
|
23A - INTAKE PACKING
HIT-6699952.A6
6699952
|
-
|
|
|
|
24 - INTAKE
HIT-6696794.A1
6696794
|
-
|
|
|
|
25A - HEX. SOCKET BOLT M4
HIT-6698792.A7
6698792
|
-
|
|
|
|
26 - PULSE GUIDE
HIT-6685203.A3
6685203
|
-
|
|
|
|
27 - ENGINE CASE COVER
HIT-6696812.A1
6696812
|
-
|
|
|
|
28 - CLEANER BODY
HIT-6696792.A2
6696792
|
-
|
|
|
|
30 - CARBURETOR ASS'Y INCLUD.32-47
HIT-6696795.A1
6696795
|
-
|
|
|
|
31 - INLET SPACER
HIT-6698857.A0
6698857
|
-
|
|
|
|
32 - SCREW
HIT-6685210.A12
6685210
|
-
|
|
|
|
33 - PUMP BODY
HIT-6685211.A11
6685211
|
-
|
|
|
|
34 - PUMP GASKET
HIT-6685212.A12
6685212
|
£3.29
|
£3.95
|
|
|
35 - PUMP DIAPHRAGM
HIT-6685213.A44
6685213
|
£8.44
|
£10.13
|
|
|
36 - INLET SCREEN
HIT-6684700.A165
6684700
|
-
|
|
|
|
37 - NEEDLE VALVE
HIT-6685215.A11
6685215
|
£6.79
|
£8.15
|
|
|
38 - VALVE SPRING
HIT-6685216.A6
6685216
|
-
|
|
|
|
39 - CONTROL LEVER
HIT-6685217.A12
6685217
|
-
|
|
|
|
40 - IDLE ADJUST SPRING
HIT-6685297.A9
6685297
|
-
|
|
|
|
41 - IDLE ADJUST SCREW
HIT-6685298.A33
6685298
|
£1.67
|
£2.00
|
|
|
42 - HINGE PIN SET SCREW
HIT-6685218.A55
6685218
|
-
|
|
|
|
43 - HINGE PIN
HIT-6685219.A15
6685219
|
-
|
|
|
|
44 - DIAPHRAGM PACKING-METERING
HIT-6685220.A143
6685220
|
£2.81
|
£3.37
|
|
|
45 - METERING DIAPHRAGM
HIT-6684690.A37
6684690
|
£24.05
|
£28.86
|
|
|
46 - DIAPHRAGM COVER-METERING
HIT-6685222.A32
6685222
|
£5.70
|
£6.84
|
|
|
47 - SET SCREW
HIT-6685223.A56
6685223
|
-
|
|
|
|
48 - IDOL SPONGE
HIT-6696793.A1
6696793
|
-
|
|
|
|
49 - CHOKE LEVER
HIT-6685206.A3
6685206
|
-
|
|
|
|
50 - PROTECTIVE COIL
HIT-6698699.A1
6698699
|
-
|
|
|
|
51 - FUEL PIPE 2.5X4X47
HIT-6698850.A2
6698850
|
-
|
|
|
|
52 - PRIMING PUMP COMP.
HIT-6685139.A40
6685139
|
£10.67
|
£12.80
|
|
|
53 - AIR VENT SPONGE
HIT-6685371.A13
6685371
|
£3.49
|
£4.19
|
|
|
54 - AIR VENT VALVE (B)
HIT-6685370.A2
6685370
|
£6.75
|
£8.10
|
|
|
55 - OIL PIPE
HIT-6696811.A3
6696811
|
-
|
|
|
|
56 - PIPE JOINT
HIT-6685358.A5
6685358
|
£3.49
|
£4.19
|
|
|
57 - FLANGED TAPPING SCREW D5X15
HIT-6698456.A3
6698456
|
-
|
|
|
|
58A - CHAIN CATCHER
HIT-6699950.A2
6699950
|
-
|
|
|
|
59A - ENGINE CASE ASS'Y INCLUD.54
HIT-6696807.A2
6696807
|
-
|
|
|
|
60 - MACHINE SCREW (W/WASHERS) M4X12 (BLACK)
HIT-935196.A15
935196
|
£1.67
|
£2.00
|
|
|
61 - EXHAUST PIPE
HIT-6696816.A4
6696816
|
-
|
|
|
|
62 - MUFFLER SPECIAL PACKING
HIT-6696818.A4
6696818
|
-
|
|
|
|
63 - GAUZE FIXING PLATE
HIT-6696817.A3
6696817
|
-
|
|
|
|
64 - MUFFLER GAUZE
HIT-6696815.A3
6696815
|
-
|
|
|
|
65 - MUFFLER
HIT-6696814.A0
6696814
|
-
|
|
|
|
66B - MUFFLER PACKING
HIT-6600445.A3
6600445
|
-
|
|
|
|
67 - HEX. SOCKET HD. BOLT M4X10 (10 PCS.)
HIT-949812.A5
949812
|
£2.98
|
£3.57
|
|
|
68 - SCAVENGING COVER (B)
HIT-6696766.A2
6696766
|
-
|
|
|
|
70 - HEX. SOCKET HD. BOLT M6X55
HIT-6696819.A7
6696819
|
-
|
|
|
|
71 - BOLT WASHER M6 (10 PCS.)
HIT-949432.A68
949432
|
£1.67
|
£2.00
|
|
|
72 - CRANK WORM ASS'Y INCLUD.73-76
HIT-6698853.A1
6698853
|
-
|
|
|
|
73 - WORM
HIT-6685330.A6
6685330
|
-
|
|
|
|
74 - OIL SEAL
HIT-6685329.A3
6685329
|
£5.87
|
£7.04
|
|
|
75 - BALL BEARING
HIT-6685328.A9
6685328
|
-
|
|
|
|
76 - CRANK SHAFT
HIT-6696762.A5
6696762
|
-
|
|
|
|
77 - CRANK CASE
HIT-6696767.A5
6696767
|
-
|
|
|
|
78 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X18
HIT-6698386.A56
6698386
|
-
|
|
|
|
79 - CIRCLIP
HIT-6685326.A8
6685326
|
-
|
|
|
|
80 - PISTON (M)
HIT-6698806.A3
6698806
|
-
|
|
|
|
81 - PISTON RING (XR1-1856)
HIT-6685331.A7
6685331
|
£12.57
|
£15.08
|
|
|
82 - PISTON PIN
HIT-6696764.A3
6696764
|
-
|
|
|
|
83 - BOLT WASHER M7
HIT-6685103.A38
6685103
|
-
|
|
|
|
84 - FLYWHEEL NUT
HIT-6685104.A0
6685104
|
-
|
|
|
|
85 - RETAINING RING D4
HIT-6685336.A31
6685336
|
£3.49
|
£4.19
|
|
|
86A - MAGNETO ROTOR COMP.
HIT-6600053.A14
6600053
|
-
|
|
|
|
87 - STARTER PAWL SPRING
HIT-6685335.A4
6685335
|
£2.84
|
£3.41
|
|
|
88 - STARTER PAWL
HIT-6685334.A26
6685334
|
£2.84
|
£3.41
|
|
|
89A - MAGNETO SUB ASS'Y INCLUD.85-88
HIT-6600090.A6
6600090
|
-
|
|
|
|
90A - INNER CAP
HIT-6685351.A0
6685351
|
-
|
|
|
|
91 - TANK CAP PACKING
HIT-6685179.A20
6685179
|
£1.67
|
£2.00
|
|
|
92 - FUEL TANK CAP ASS'Y (VERMILION) INCLUD.91
HIT-6698854.A15
6698854
|
£7.03
|
£8.44
|
|
|
93A - CYLINDER
HIT-6601440.A0
6601440
|
-
|
|
|
|
94A - SPARK PLUG ASS'Y BPMR7A
HIT-6699320.A26
6699320
|
-
|
|
|
|
95A - IGNITION COIL
HIT-6699999.A2
6699999
|
-
|
|
|
|
96 - GLASS WASHER
HIT-6698700.A21
6698700
|
£1.67
|
£2.00
|
|
|
98 - SCAVENGING COVER (A)
HIT-6696765.A5
6696765
|
-
|
|
|
|
99 - METAL FITTING OF PLUG CAP (A)
HIT-6696772.A5
6696772
|
-
|
|
|
|
100A - CORD (A)
HIT-6696787.A1
6696787
|
-
|
|
|
|
101 - SPARK PLUG CAP
HIT-6696771.A2
6696771
|
-
|
|
|
|
102A - CORD (B)
HIT-6696791.A1
6696791
|
-
|
|
|
|
103A - HEX. SOCKET HD. BOLT (W/FLANGE) M4X18
HIT-6696326.A8
6696326
|
-
|
|
|
|
104 - WASHER M5 (BLACK)
HIT-6685226.A0
6685226
|
-
|
|
|
|
105 - CAUTION LABEL (HOT)
HIT-6698864.A4
6698864
|
-
|
|
|
|
106 - GROMMET
HIT-6698787.A14
6698787
|
-
|
|
|
|
107 - PROTECTION SHEET
HIT-6698860.A3
6698860
|
-
|
|
|
|
108 - PACKING PLATE
HIT-6698861.A0
6698861
|
-
|
|
|
|
109 - MUFFLER SPECIAL PACKING (S)
HIT-6698862.A7
6698862
|
-
|
|
|
|
110 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A83
6684899
|
-
|
|
|
|
111 - CORD INSULATION TUBE
HIT-6698863.A0
6698863
|
-
|
|
|
|
112 - FUEL TANK CAP ASS'Y (BLACK) INCLUD.91
HIT-6698358.A2
6698358
|
£3.56
|
£4.27
|
|
|
113 - IGNITION COIL ASS'Y INCLUD.95A
HIT-6601441.A3
6601441
|
-
|
|
|
|
121A - TAPPING SCREW (W/FLANGE) D5X40
HIT-6699403.A0
6699403
|
-
|
|
|
|
122 - WASHER 1.0
HIT-6698858.A3
6698858
|
-
|
|
|
|
123 - COLLAR 28.2
HIT-6696800.A4
6696800
|
£3.02
|
£3.63
|
|
|
124 - DAMPER
HIT-6696775.A1
6696775
|
-
|
|
|
|
125 - REAR HANDLE (B)
HIT-6696774.A2
6696774
|
-
|
|
|
|
126A - TRIGGER LOCKOUT
HIT-6685244.A2
6685244
|
-
|
|
|
|
127 - THROTTLE WIRE
HIT-6696797.A2
6696797
|
-
|
|
|
|
128A - STOP SWITCH
HIT-6601275.A53
6601275
|
£1.67
|
£2.00
|
|
|
129 - NUT M6
HIT-6698449.A5
6698449
|
£1.67
|
£2.00
|
|
|
130 - THROTTLE LEVER SPRING
HIT-6698691.A3
6698691
|
-
|
|
|
|
131 - THROTTLE LEVER
HIT-6685242.A2
6685242
|
-
|
|
|
|
132 - SPRING HOLDER
HIT-6698409.A3
6698409
|
-
|
|
|
|
133 - DAMPER SET BOLT
HIT-6698859.A0
6698859
|
-
|
|
|
|
134 - ANTIVIBRATION SPRING
HIT-6698428.A11
6698428
|
-
|
|
|
|
135 - NAME PLATE
HIT-000000.A3311
000000
|
-
|
|
|
|
136 - FLANGE NUT M8
HIT-6698581.A3
6698581
|
£1.67
|
£2.00
|
|
|
137A - SIDE CASE (VERMILION)
HIT-6696776.A2
6696776
|
-
|
|
|
|
138 - BRAKE SUPPORT PLATE
HIT-6696782.A7
6696782
|
-
|
|
|
|
139 - BRAKE LEVER SPRING
HIT-6696783.A2
6696783
|
-
|
|
|
|
140 - BRAKE LINK
HIT-6685388.A8
6685388
|
£12.57
|
£15.08
|
|
|
141 - BRAKE BAND
HIT-6685140.A3
6685140
|
£22.02
|
£26.43
|
|
|
142 - NEEDLE ROLLER D3
HIT-6685391.A22
6685391
|
£3.49
|
£4.19
|
|
|
143 - BRAKE SPRING
HIT-6685389.A9
6685389
|
£3.49
|
£4.19
|
|
|
144A - CHAIN PULLER
HIT-6698986.A13
6698986
|
£18.88
|
£22.66
|
|
|
145 - GUIDE PLATE (B)
HIT-6696784.A7
6696784
|
£3.02
|
£3.63
|
|
|
146 - TAPPING SCREW D3X6
HIT-696352.A5
696352
|
-
|
|
|
|
147 - TAPPING SCREW D4X10
HIT-958715.A7
958715
|
£1.67
|
£2.00
|
|
|
*148A - SAW CHAIN (3/8X12) 91PX-45XJ
HIT-781122.A5
781122
|
£12.41
|
£14.89
|
|
|
*148A - SAW CHAIN (3/8X14) 91PX-52XJ
HIT-781124.A10
781124
|
£13.99
|
£16.79
|
|
|
*149 - CHAIN BAR 12 INCH 3/8 SPROCKET PRC
HIT-6696993.A3
6696993
|
-
|
|
|
|
*149 - CHAIN BAR 14 INCH 3/8 SPROCKET PRC
HIT-6696994.A0
6696994
|
-
|
|
|
|
150 - FUEL PIPE
HIT-6698715.A3
6698715
|
£17.16
|
£20.59
|
|
|
151 - SPIKE SET
HIT-6696827.A1
6696827
|
-
|
|
|
|
152 - FUEL PIPE (FKM) L240
HIT-6698851.A1
6698851
|
-
|
|
|
|
154 - FUEL PIPE (FKM) L260
HIT-6698852.A2
6698852
|
-
|
|
|
|
155 - FUEL GROMMET
HIT-6696167.A2
6696167
|
-
|
|
|
|
156 - REAR HANDLE (A)
HIT-6696773.A1
6696773
|
-
|
|
|
|
157A - D5 TAPPING SCREW W/F
HIT-6600026.A3
6600026
|
-
|
|
|
|
158A - FRONT HANDLE
HIT-6696798.A1
6696798
|
-
|
|
|
|
159 - BRAKE HANDLE
HIT-6698866.A3
6698866
|
-
|
|
|
|
160 - CAUTION LABEL (B)
HIT-000000.A3312
000000
|
-
|
|
|
|
160 - CAUTION LABEL (C)
HIT-000000.A3313
000000
|
-
|
|
|
|
160 - CAUTION LABEL (D)
HIT-000000.A3315
000000
|
-
|
|
|
|
161 - BRAKE LINK COVER
HIT-6696779.A1
6696779
|
-
|
|
|
|
162A - PUMP FILTER
HIT-6600351.A57
6600351
|
£4.45
|
£5.34
|
|
|
163 - CLIP
HIT-6685311.A20
6685311
|
£1.67
|
£2.00
|
|
|
164 - OIL FILTER BODY
HIT-6685310.A5
6685310
|
£1.67
|
£2.00
|
|
|
165 - OIL FILTER
HIT-6696804.A2
6696804
|
-
|
|
|
|
166 - BOLT WASHER D5
HIT-6685407.A3
6685407
|
-
|
|
|
|
167 - AIR DEFLECTOR
HIT-6696790.A2
6696790
|
-
|
|
|
|
168B - RECOIL STARTER (S) (VERMILION) INCLUD.177-181
HIT-6699417.A1
6699417
|
£25.68
|
£30.81
|
|
|
169 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-302086.A24
302086
|
£1.67
|
£2.00
|
|
|
170 - TANAKA LABEL
HIT-6696339.A11
6696339
|
-
|
|
|
|
171 - CORD INSULATION TUBE
HIT-6698457.A4
6698457
|
-
|
|
|
|
172 - SPRING COVER
HIT-6698865.A2
6698865
|
-
|
|
|
|
173 - FUEL GROMMET (A)
HIT-6685308.A8
6685308
|
£3.49
|
£4.19
|
|
|
174 - GROMMET (A)
HIT-6699404.A3
6699404
|
-
|
|
|
|
175 - SET SCREW TILL 3.2015 EXCEPT FOR AUS
HIT-6699475.A2
6699475
|
-
|
|
|
|
176 - REEL TILL 3.2015 EXCEPT FOR AUS
HIT-6699483.A1
6699483
|
-
|
|
|
|
177 - SPIRAL SPRING CASE
HIT-6699480.A10
6699480
|
£9.34
|
£11.21
|
|
|
178 - SET SCREW
HIT-6699476.A5
6699476
|
£1.67
|
£2.00
|
|
|
179 - CAM PLATE
HIT-6699478.A6
6699478
|
-
|
|
|
|
180 - DAMPER SPRING
HIT-6699479.A1
6699479
|
£2.77
|
£3.32
|
|
|
181 - REEL
HIT-6699484.A2
6699484
|
£4.10
|
£4.92
|
|
|
182 - STARTER ROPE
HIT-6699469.A6
6699469
|
-
|
|
|
|
183 - ROPE STOPPER
HIT-6699465.A4
6699465
|
-
|
|
|
|
184 - STARTER KNOB
HIT-6699467.A2
6699467
|
-
|
|
|
|
185 - STARTER HANDLE ASS'Y INCLUD.182-184
HIT-6699473.A1
6699473
|
-
|
|
|
|
186 - FAN CASE
HIT-6699490.A1
6699490
|
-
|
|
|
|
187 - TAPPING SCREW (W/FLANGE) D4
HIT-6699947.A2
6699947
|
-
|
|
|
|
*501 - CHAIN COVER 12
HIT-6685401.A1
6685401
|
-
|
|
|
|
*501 - CHAIN COVER 14
HIT-6685439.A13
6685439
|
-
|
|
|
|
502 - COMBI BOX SPANNER 13X19
HIT-6698582.A8
6698582
|
£6.50
|
£7.80
|
|
