1 - SPARK PLUG CAP ASS'Y
HIT-6687468.A16
6687468
|
£3.64
|
£4.37
|
|
|
2 - SPARK PLUG ASS'Y CJ8Y
HIT-6699325.A0
6699325
|
-
|
|
|
|
3 - CYLINDER SET
HIT-6685461.A1
6685461
|
-
|
|
|
|
4 - HEX. HOLE BOLT 4X15/PS
HIT-6684682.A28
6684682
|
£1.67
|
£2.00
|
|
|
5 - CYLINDER GASKET
HIT-6685726.A2
6685726
|
-
|
|
|
|
6 - PISTON RING
HIT-6686119.A4
6686119
|
-
|
|
|
|
7 - PISTON SET
HIT-6685881.A2
6685881
|
-
|
|
|
|
8 - PISTON PIN
HIT-6684591.A33
6684591
|
£3.29
|
£3.95
|
|
|
9 - CIR CLIP
HIT-6684590.A85
6684590
|
£1.67
|
£2.00
|
|
|
10 - CRANK SHAFT COMP.
HIT-6686173.A3
6686173
|
-
|
|
|
|
11 - CORD INSULATOR TUBE
HIT-6692900.A10
6692900
|
-
|
|
|
|
12A - IGNITION COIL ASS'Y SINCE TL076511
HIT-6601174.A1
6601174
|
-
|
|
|
|
15 - IGNITION COIL SET PN TILL TL076510
HIT-6601179.A2
6601179
|
-
|
|
|
|
*20 - SHIM 0.1
HIT-6686474.A17
6686474
|
-
|
|
|
|
*20 - SHIM S T0.2
HIT-6685098.A33
6685098
|
-
|
|
|
|
*20 - SHIM S T0.3
HIT-6685099.A1
6685099
|
-
|
|
|
|
*20 - SHIM 0.4
HIT-6686475.A0
6686475
|
-
|
|
|
|
21 - FLYWHEEL NUT
HIT-6685104.A24
6685104
|
-
|
|
|
|
22 - BOLT WASHER M7
HIT-6685103.A2
6685103
|
-
|
|
|
|
23 - MAGNETO ROTOR SET
HIT-6687378.A2
6687378
|
-
|
|
|
|
24 - STARTER PAWL
HIT-6693305.A2
6693305
|
-
|
|
|
|
25 - STARTER PAWL SPRING
HIT-6685105.A1
6685105
|
£1.67
|
£2.00
|
|
|
26 - D4E RETAINING RING
HIT-6685101.A130
6685101
|
-
|
|
|
|
27 - CLIP 4.5
HIT-6692304.A2
6692304
|
-
|
|
|
|
28 - FUEL PIPE 2.5X4.5X175
HIT-6692412.A3
6692412
|
£2.81
|
£3.37
|
|
|
29 - INSULATOR TUBE 50L
HIT-6684597.A14
6684597
|
-
|
|
|
|
30 - HEX. HOLE BOLT 5X16 TILL E122400
HIT-6695046.A22
6695046
|
£1.67
|
£2.00
|
|
|
30A - HEX. HOLE BOLT 5X16 SINCE E122401
HIT-6695046.A23
6695046
|
£1.67
|
£2.00
|
|
|
31 - WASHER M5 (BLACK)
HIT-6685226.A14
6685226
|
-
|
|
|
|
32 - HEX. HOLE BOLT 5X30 SINCE E122401
HIT-6695052.A3
6695052
|
-
|
|
|
|
33 - FLUNGE NUT 5 SINCE E122401
HIT-6695169.A12
6695169
|
£1.67
|
£2.00
|
|
|
34 - CRANK CASE ASSY
HIT-6686526.A4
6686526
|
-
|
|
|
|
35 - OIL SEAL TB 12227
HIT-6684607.A176
6684607
|
£4.07
|
£4.88
|
|
|
36 - CRANK CASE GASKET
HIT-6686703.A4
6686703
|
-
|
|
|
|
37 - BALL BEARING 6001 C3
HIT-6684608.A27
6684608
|
£5.70
|
£6.84
|
|
|
38 - NEEDLE ROLLER 2.5X9.8
HIT-6685095.A20
6685095
|
-
|
|
|
|
39 - HEX.HOLE BOLT 5X22/WS
HIT-6695514.A13
6695514
|
-
|
|
|
|
50 - AIR DEFLECTOR ASS'Y
HIT-6687328.A1
6687328
|
-
|
|
|
|
51 - PIPE HOLDING GROMMET
HIT-6691466.A3
6691466
|
-
|
|
|
|
52 - INLETMANIFOLD GASKET
HIT-6689872.A3
6689872
|
£1.67
|
£2.00
|
|
|
53 - INLETMANIFOLD SPACER
HIT-6689819.A1
6689819
|
-
|
|
|
|
54 - INLETMANIFOLD COMP.
HIT-6689788.A4
6689788
|
-
|
|
|
|
55 - CARB. FIXING PLATE
HIT-6689997.A4
6689997
|
-
|
|
|
|
56 - DUST COVER TILL H009550
HIT-6690811.A2
6690811
|
-
|
|
|
|
57 - CHOKE ROD HOLDING RUBBER
HIT-6692587.A6
6692587
|
-
|
|
|
|
58 - CHOKE BUTTOM COMP.
HIT-6692515.A3
6692515
|
-
|
|
|
|
59 - CARUB. SUPPORT PLATE
HIT-6690679.A3
6690679
|
-
|
|
|
|
60 - ADJUSTER CAP
HIT-6687960.A2
6687960
|
-
|
|
|
|
61 - IDLE GROMMET
HIT-6687980.A2
6687980
|
-
|
|
|
|
62 - U-NUT 5
HIT-6695157.A3
6695157
|
£1.67
|
£2.00
|
|
|
63 - HEX. HOLE BOLT 4X10S
HIT-6695484.A24
6695484
|
£1.67
|
£2.00
|
|
|
64 - SMALL WASHER 5
HIT-6684864.A141
6684864
|
-
|
|
|
|
65 - SCREW 5X45
HIT-6694908.A3
6694908
|
-
|
|
|
|
70 - SHIELD TUBE
HIT-6685247.A1
6685247
|
£4.32
|
£5.19
|
|
|
71 - CLIP D6
HIT-6685198.A72
6685198
|
-
|
|
|
|
72 - WASHER 5
HIT-6684661.A51
6684661
|
£1.67
|
£2.00
|
|
|
73 - OIL FILTER
HIT-6690919.A13
6690919
|
-
|
|
|
|
74 - OIL FILTER BODY ASS'Y
HIT-6685249.A19
6685249
|
£1.67
|
£2.00
|
|
|
75 - PROTECTIVE COIL
HIT-6685246.A3
6685246
|
-
|
|
|
|
76 - PUMP FIXING PLATE
HIT-6692126.A1
6692126
|
-
|
|
|
|
77 - PRIMING PUMP COMP.
HIT-6685139.A116
6685139
|
£10.67
|
£12.80
|
|
|
78 - FUEL PIPE
HIT-6692413.A1
6692413
|
-
|
|
|
|
79 - FUIL PIPE 2.5X4.5X140
HIT-6692350.A3
6692350
|
-
|
|
|
|
80 - FUEL GROMMET
HIT-6692422.A3
6692422
|
-
|
|
|
|
81 - PUMP FILTER BODY
HIT-6685199.A3
6685199
|
£6.38
|
£7.66
|
|
|
82 - RETURN GROMMET
HIT-6691286.A2
6691286
|
-
|
|
|
|
83 - STOP SWITCH COMP.
HIT-6687504.A3
6687504
|
-
|
|
|
|
84 - TANK CAP ASS'Y
HIT-6685180.A0
6685180
|
£6.69
|
£8.03
|
|
|
85 - TANK CAP PACKING
HIT-6685179.A35
6685179
|
£1.67
|
£2.00
|
|
|
86 - SEAL LOCK BOLT M5X15
HIT-6685136.A10
6685136
|
-
|
|
|
|
87 - ENGINE CASE ASS'Y
HIT-6691368.A4
6691368
|
-
|
|
|
|
88 - AIR VENT VALVE (B)
HIT-6685173.A24
6685173
|
-
|
|
|
|
89 - AIR VENT ASS'Y
HIT-6692086.A4
6692086
|
-
|
|
|
|
90 - ENGINE CASE COVER
HIT-6691380.A2
6691380
|
-
|
|
|
|
91 - OIL TANK CAP ASS'Y
HIT-6697756.A1
6697756
|
£5.87
|
£7.04
|
|
|
92 - OIL TANK CAP PACKING
HIT-6697888.A5
6697888
|
£1.67
|
£2.00
|
|
|
100 - RECOIL STARTER ASS'Y
HIT-6692912.A4
6692912
|
-
|
|
|
|
101 - SET SCREW
HIT-6684679.A112
6684679
|
£2.98
|
£3.57
|
|
|
102 - DAMPER SPRING
HIT-6685183.A9
6685183
|
£5.70
|
£6.84
|
|
|
103 - STARTER PULLEY
HIT-6685184.A12
6685184
|
£6.18
|
£7.41
|
|
|
104 - ROPE
HIT-6685186.A12
6685186
|
-
|
|
|
|
105 - SPRING CASE SET
HIT-6685185.A1
6685185
|
£11.12
|
£13.35
|
|
|
106 - STARTER HANDLE
HIT-6685188.A6
6685188
|
-
|
|
|
|
107 - FAN CASE COMP.
HIT-6686953.A4
6686953
|
-
|
|
|
|
108 - TAPPING SCREW D4.5X20
HIT-6685191.A25
6685191
|
-
|
|
|
|
109 - CAM PLATE
HIT-6692936.A2
6692936
|
-
|
|
|
|
110 - PLATE
HIT-6685189.A13
6685189
|
-
|
|
|
|
111 - CLEANER ELEMENT
HIT-6690065.A2
6690065
|
£3.29
|
£3.95
|
|
|
112 - CLEANER COVER
HIT-6686315.A2
6686315
|
£9.42
|
£11.30
|
|
|
113 - CLEANER KNOB
HIT-6685228.A6
6685228
|
£3.89
|
£4.67
|
|
|
120 - CARBURETOR ASS'Y
HIT-6690654.A0
6690654
|
-
|
|
|
|
121 - INLET SCREEN
HIT-6684700.A81
6684700
|
-
|
|
|
|
122 - PUMP COVER
HIT-6691438.A4
6691438
|
-
|
|
|
|
123 - SCREW
HIT-6685210.A64
6685210
|
-
|
|
|
|
124 - PUMP GASKET
HIT-6685212.A55
6685212
|
£3.29
|
£3.95
|
|
|
125 - PUMP DIAPHRAGM
HIT-6685213.A2
6685213
|
£8.44
|
£10.13
|
|
|
126 - CONTROL LEVER
HIT-6685217.A57
6685217
|
-
|
|
|
|
127 - HINGE PIN SET SCREW
HIT-6685218.A7
6685218
|
-
|
|
|
|
128 - VALVE SPRING
HIT-6690873.A22
6690873
|
-
|
|
|
|
129 - HINGE PIN
HIT-6685219.A81
6685219
|
-
|
|
|
|
130 - DIAPHRAGM COVER-METERING
HIT-6685222.A158
6685222
|
£5.70
|
£6.84
|
|
|
131 - METERING DIAPHRAGM COMP.
HIT-6690827.A76
6690827
|
£14.02
|
£16.83
|
|
|
132 - DIAPHRAGM PACKING-METERING
HIT-6685220.A21
6685220
|
£2.81
|
£3.37
|
|
|
133 - NEEDLE VALVE
HIT-6685215.A85
6685215
|
£6.79
|
£8.15
|
|
|
134 - IDLE ADJUST SPRING
HIT-6690766.A23
6690766
|
-
|
|
|
|
135 - IDLE ADJUST SCREW
HIT-6690736.A18
6690736
|
-
|
|
|
|
136 - SET SCREW
HIT-6685223.A7
6685223
|
-
|
|
|
|
137 - LOW ADJUST SCREW
HIT-6690724.A0
6690724
|
-
|
|
|
|
138 - HIGH/LOW ADJUST SPRING
HIT-6692048.A16
6692048
|
-
|
|
|
|
139 - HIGH ADJUST SCREW
HIT-6690694.A0
6690694
|
-
|
|
|
|
140 - HIGH ADJUSTMENT SPRING
HIT-6690897.A7
6690897
|
-
|
|
|
|
150 - TAPPING SCREW D4.5X14
HIT-6685152.A36
6685152
|
-
|
|
|
|
151 - OIL PUMP COVER
HIT-6686765.A2
6686765
|
-
|
|
|
|
152 - OIL PIPE (A)
HIT-6685150.A6
6685150
|
-
|
|
|
|
153 - SCREW GEAR
HIT-6685151.A0
6685151
|
-
|
|
|
|
154 - AIR VENT SPONGE
HIT-6691401.A4
6691401
|
-
|
|
|
|
155 - OIL PUMP CASE ASS'Y
HIT-6685135.A0
6685135
|
£27.85
|
£33.42
|
|
|
156 - PUMP GEAR COMP.
HIT-6685132.A6
6685132
|
-
|
|
|
|
157 - PUMP GEAR SPRING
HIT-6685131.A0
6685131
|
-
|
|
|
|
158 - OIL PUMP ADJUST CAP
HIT-6685130.A6
6685130
|
-
|
|
|
|
159 - OIL PUMP CASE COMP.
HIT-6685134.A6
6685134
|
-
|
|
|
|
160 - ADJUSTER SPRING
HIT-6685129.A0
6685129
|
-
|
|
|
|
161 - BOLT WASHER M4
HIT-6685070.A29
6685070
|
£1.67
|
£2.00
|
|
|
162 - OIL PUMP ADJUSTER
HIT-6685128.A6
6685128
|
£1.67
|
£2.00
|
|
|
163 - MACHINE SCREW M3X8
HIT-6685133.A0
6685133
|
-
|
|
|
|
164 - MUFFLER SET
HIT-6692450.A2
6692450
|
-
|
|
|
|
165 - OIL ADJUST GROMMET
HIT-6690959.A4
6690959
|
-
|
|
|
|
166 - MACHINE SCREW (W/SP. WASHER) M4X14
HIT-6685149.A0
6685149
|
-
|
|
|
|
167 - MUFFLER GASKET
HIT-6692734.A3
6692734
|
-
|
|
|
|
168 - HEX. HOLE BOLT 5X40
HIT-6695054.A19
6695054
|
£1.67
|
£2.00
|
|
|
169 - WASHER 5
HIT-6684661.A52
6684661
|
£1.67
|
£2.00
|
|
|
170 - FUEL PIPE
HIT-6685154.A33
6685154
|
-
|
|
|
|
171 - CHAIN CATCHER
HIT-6685155.A0
6685155
|
-
|
|
|
|
172 - MUFFLER COVER
HIT-6692753.A2
6692753
|
-
|
|
|
|
173 - TAPPING SCREW D4.5X14
HIT-6685152.A37
6685152
|
-
|
|
|
|
174 - TAPPING SCREW D5X14
HIT-6685275.A43
6685275
|
-
|
|
|
|
175 - GUIDE PLATE A
HIT-6696077.A2
6696077
|
£4.26
|
£5.11
|
|
|
176 - TAPPING SCREW D4X10
HIT-6685161.A26
6685161
|
£1.67
|
£2.00
|
|
|
200 - NUT
HIT-6685166.A12
6685166
|
£3.62
|
£4.35
|
|
|
201 - CLUTCH COMP.
HIT-6688560.A2
6688560
|
-
|
|
|
|
202 - NEEDLE BEARING
HIT-6685143.A22
6685143
|
£4.72
|
£5.66
|
|
|
203 - CLUTCH HOUSING COMP.
HIT-6689037.A3
6689037
|
-
|
|
|
|
204 - CLUTCH WASHER
HIT-6689635.A2
6689635
|
-
|
|
|
|
205 - CLUTCH WASHER
HIT-6689641.A2
6689641
|
-
|
|
|
|
206 - TAPPING SCREW D4X10
HIT-6685161.A27
6685161
|
£1.67
|
£2.00
|
|
|
207 - SIDE CASE COMP.
HIT-6686113.A0
6686113
|
-
|
|
|
|
208 - GUIDE PLATE B
HIT-6690765.A2
6690765
|
-
|
|
|
|
209 - TENTION ADJUST BOLT COMP.
HIT-6687074.A4
6687074
|
-
|
|
|
|
210 - GEAR (A)
HIT-6685168.A9
6685168
|
£3.45
|
£4.14
|
|
|
211 - SIDE CASE ASS'Y
HIT-6686114.A0
6686114
|
-
|
|
|
|
212 - CRANK SHAFT COLLAR 6
HIT-6691198.A4
6691198
|
-
|
|
|
|
250 - TAPPING SCREW 5X35
HIT-6695107.A31
6695107
|
£1.67
|
£2.00
|
|
|
251 - CLEANER FIXING COLLAR
HIT-6690805.A22
6690805
|
£2.69
|
£3.23
|
|
|
252 - TAPPING SCREW 5X40
HIT-6695108.A6
6695108
|
-
|
|
|
|
253 - DAMPER COLLAR A
HIT-6688480.A3
6688480
|
-
|
|
|
|
254 - DAMPER A
HIT-6688117.A3
6688117
|
-
|
|
|
|
255 - TAPPING SCREW D5X14
HIT-6685275.A44
6685275
|
-
|
|
|
|
256 - TAPPING SCREW D5X16
HIT-6685074.A6
6685074
|
-
|
|
|
|
257 - REAR HANDLE B
HIT-6685653.A2
6685653
|
-
|
|
|
|
258 - TRIGGER LOCKOUT VERMILION
HIT-6688363.A0
6688363
|
-
|
|
|
|
259 - THROTTLE LEVER
HIT-6686395.A6
6686395
|
-
|
|
|
|
260 - THROTTLE LEVER SPRING
HIT-6686416.A0
6686416
|
£2.71
|
£3.25
|
|
|
261 - REAR HANDLE A
HIT-6685628.A4
6685628
|
-
|
|
|
|
262 - TAPPING SCREW D4X15
HIT-6685148.A29
6685148
|
-
|
|
|
|
263 - FRONT HANDLE
HIT-6688088.A4
6688088
|
-
|
|
|
|
264 - THROTTLE WIRE COMP.
HIT-6693875.A2
6693875
|
-
|
|
|
|
265 - DAMPER COMP.
HIT-6688262.A2
6688262
|
-
|
|
|
|
266 - HAND GUARD
HIT-6693467.A0
6693467
|
-
|
|
|
|
267 - HAND GUARD SHAFT
HIT-6693446.A0
6693446
|
-
|
|
|
|
268 - HAND GUARD SPRING
HIT-6693449.A0
6693449
|
-
|
|
|
|
269 - WASHER 6
HIT-6695194.A7
6695194
|
-
|
|
|
|
270 - D4E RETAINING RING
HIT-6685101.A132
6685101
|
-
|
|
|
|
501 - COMBI BOX SPANNER 10/19MM
HIT-6685257.A10
6685257
|
-
|
|
|
|
502 - GUIDE BAR COVER 1
HIT-6694796.A11
6694796
|
£11.79
|
£14.15
|
|
|
504A - CHAIN COVER 12
HIT-6685401.A11
6685401
|
-
|
|
|
|
505 - SAW CHAIN (3/8X12) 91PX-45XJ
HIT-781122.A11
781122
|
£12.41
|
£14.89
|
|
|
506 - BAR 12 INCH 3/8 SPROCKET
HIT-6685159.A5
6685159
|
£38.61
|
£46.33
|
|
|
508 - SAW CHAIN (3/8X10) 91PX-40XJ
HIT-6697853.A1
6697853
|
-
|
|
|
|
509 - CHAIN BAR 10 3/8
HIT-6686878.A1
6686878
|
£27.59
|
£33.11
|
|
|
510 - BAR 14 INCH 3/8 SPROCKET
HIT-6685160.A0
6685160
|
£21.92
|
£26.30
|
|
|
511 - SAW CHAIN (3/8X14) 91PX-52XJ
HIT-781124.A13
781124
|
£13.99
|
£16.79
|
|
|
512 - SAW CHAIN (3/8X16) 91PX-57XJ
HIT-781126.A6
781126
|
£19.00
|
£22.80
|
|
|
513 - CHAIN BAR 16
HIT-6686854.A4
6686854
|
-
|
|
|
|
514 - CHAIN COVER 14
HIT-6685256.A6
6685256
|
-
|
|
|
