Hitachi / Hikoki TCP-210 1inch Water Pump Spare Parts

Home Details Reviews Delivery

An exploded diagram and spare parts listing for the Hitachi / Hikoki TCP-210 1inch Water Pump

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP HIT-6687476.A10 6687476	-
2A - SPARK PLUG ASS'Y BPM7A HIT-6699318.A0 6699318	-
3 - CYLINDER ASS'Y HIT-6685480.A7 6685480	£47.88	£57.46
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A29 6684586	-
5 - CYLINDER GASKET HIT-6685744.A10 6685744	£1.67	£2.00
6 - PISTON RING HIT-6686118.A17 6686118	£6.94	£8.33
*7 - PISTON SET 1 HIT-6685891.A0 6685891	-
*7 - PISTON SET SINCE S256171 HIT-6685892.A0 6685892	£33.09	£39.71
8A - PISTON PIN HIT-6696944.A26 6696944	£5.61	£6.73
9 - PISTON PIN CIRCLIP HIT-6686028.A1 6686028	-
10 - CRANK SHAFT COMP. HIT-6686206.A2 6686206	-
12 - IGNITION COIL COMP HIT-6695939.A7 6695939	£34.64	£41.57
13 - HIGH TENSION SCREW 4X18WS HIT-6695407.A14 6695407	-
14 - INSULATOR TUBE 50L HIT-6684597.A2 6684597	-
31 - CRANK CASE ASS'Y HIT-6686576.A2 6686576	-
32 - CRANK CASE GASKET HIT-6686720.A12 6686720	-
33 - OIL SEAL TB 12227 HIT-6684607.A121 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6695535.A1 6695535	£5.70	£6.84
*35 - GEAR SHAFT SHIM 0.10 HIT-6689177.A13 6689177	-
*35 - GEAR SHAFT SHIM 0.15 HIT-6689178.A22 6689178	-
*35 - GEAR SHAFT SHIM 0.20 HIT-6684604.A16 6684604	-
*35 - GEAR SHAFT SHIM 0.30 HIT-6684605.A65 6684605	-
37 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A30 6684786	£1.67	£2.00
38 - MAGNETO ROTOR COMP. HIT-6687389.A13 6687389	-
39 - BOLT WASHER M8 HIT-6684611.A43 6684611	-
40 - S.WASHER 8 HIT-6684971.A7 6684971	-
41 - HEX. NUT M8 HIT-6684612.A82 6684612	-
61 - INTAKE PIPE GASKET HIT-6689891.A22 6689891	£3.38	£4.06
62 - CARB. INSULATOR SET 1 HIT-6689966.A10 6689966	£13.22	£15.87
63 - MACHINE SCREW (W/WASHERS) M5X25 HIT-317751.A2 317751	-
64 - CARBURETOR GASKET HIT-6689839.A0 6689839	£2.98	£3.57
65 - O-RING P-15 HIT-6695670.A5 6695670	-
66 - CLEANER BODY COMP. HIT-6690119.A9 6690119	£8.95	£10.74
67 - COLLAR 7.5 HIT-6690804.A0 6690804	£1.67	£2.00
68 - CHOKE VALVE HIT-6691272.A13 6691272	£1.67	£2.00
69 - WAVE WASHER 8 HIT-6684658.A53 6684658	£1.67	£2.00
70 - BLOW OVER CHECK BOARD HIT-6690843.A15 6690843	£1.67	£2.00
71 - S.WASHER 5 HIT-6684662.A76 6684662	£1.67	£2.00
72 - SCREW M5X60 HIT-6684660.A21 6684660	-
73 - CLEANER SPONGE HIT-6690364.A7 6690364	£1.67	£2.00
74 - CLEANER COVER ASS'Y HIT-6690415.A15 6690415	£5.70	£6.84
75 - SPECIAL SCREW HIT-6689737.A43 6689737	-
76 - CARBURETOR SET WYL81 SINCE T008951 HIT-6690483.A0 6690483	-
77 - FUEL PIPE 3X5X135 TILL R078200 HIT-6692417.A0 6692417	-
78 - SHIELD TUBE SINCE R078201 HIT-6685247.A22 6685247	£4.32	£5.19
79 - CLIP 1 HIT-6684619.A44 6684619	£1.67	£2.00
80A - PUMP FILTER BODY COMP SINCE P003586 HIT-66A3864.A27 66A3864	-
*82 - FUEL TANK SINCE V169301 HIT-6691567.A0 6691567	-
*83 - TANK CAP D ASS'Y.ORANGE TILL V169300 HIT-6691716.A0 6691716	£9.00	£10.80
83A - TANK CAP D ASS'Y 1 HIT-6691715.A5 6691715	£8.55	£10.26
84 - COLLAR 5.8 HIT-6692244.A62 6692244	£1.67	£2.00
85 - HEX. HOLE BOLT 5X18PS HIT-6695505.A24 6695505	-
86 - AIR VENT ASS'Y SINCE V169301 HIT-6691389.A3 6691389	£16.64	£19.97
88 - AIR VENT VALVE ASS'Y SINCE V169301 HIT-6692171.A6 6692171	-
89 - PUMP FILTER BODY ASS'Y TILL P003585 HIT-6692279.A0 6692279	£9.30	£11.16
91 - TANK CAP CHAIN TILL V169300 HIT-6684625.A82 6684625	-
101 - MUFFLER PROTECTOR HIT-6692796.A2 6692796	£12.98	£15.57
102 - MUFFLER GASKET HIT-6692744.A20 6692744	£1.67	£2.00
103 - HEAT SHIELD HIT-6687252.A13 6687252	£2.82	£3.39
104 - MUFFLER COMP. HIT-6692571.A0 6692571	-
105 - WASHER 5 HIT-6684661.A75 6684661	£1.67	£2.00
106 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A8 6685114	£1.67	£2.00
107 - MUFFLER SPECIAL GASKET HIT-6692883.A13 6692883	-
108 - TAIL PIPE COMP. HIT-6692661.A0 6692661	-
109 - MACHINE SCREW (W/SP. WASHER) M4X8 HIT-6685109.A18 6685109	-
110 - TAPPING SCREW D4.5X16 HIT-6684636.A12 6684636	£1.67	£2.00
111 - BOLT 4X12PS HIT-6695441.A0 6695441	-
131 - FANCASE COMP. 1 HIT-6687012.A0 6687012	£28.22	£33.86
132 - RECOIL SPRING HIT-6684675.A93 6684675	£8.82	£10.58
133 - STARTER ROPE REEL HIT-6693066.A14 6693066	£5.17	£6.20
134 - ROPE REEL WASHER TILL Q014231 HIT-6693422.A0 6693422	-
135 - SET SCREW HIT-6693633.A27 6693633	£1.67	£2.00
136 - STARTER PULLEY ASS'Y HIT-6693405.A4 6693405	£7.75	£9.30
137 - GROMMET HIT-6688050.A26 6688050	£1.67	£2.00
138 - ROPE HIT-6693168.A10 6693168	£2.82	£3.39
139 - STARTER HANDLE HIT-6693237.A2 6693237	£4.55	£5.46
140 - SCREW 4X16/PS HIT-6695374.A5 6695374	£1.67	£2.00
141 - STARTER PAWL SPRING HIT-6684684.A57 6684684	£3.29	£3.95
142 - STARTER PAWL HIT-6693319.A11 6693319	£3.29	£3.95
162 - THROTTLE SET SCREW HIT-6684698.A45 6684698	-
163 - SWIVEL HIT-6684697.A53 6684697	-
164 - STOP RING HIT-6684696.A133 6684696	-
165 - THROTTLE VALVE COMP. TILL T008950 HIT-6690935.A1 6690935	-
166 - O-RING HIT-6684695.A80 6684695	£1.67	£2.00
*167 - MAIN JET #41.5 TILL T008950 HIT-6691885.A0 6691885	-
*167 - MAIN JET #40 SINCE T008951 HIT-6691845.A15 6691845	-
168 - PUMP GASKET HIT-6691457.A60 6691457	£8.48	£10.18
169 - PUMP DIAPHRAGM HIT-6684693.A118 6684693	£5.70	£6.84
170 - PUMP PLATE TILL T008950 HIT-6691242.A17 6691242	-
171 - CIRCUIT PLATE TILL T008950 HIT-6691234.A43 6691234	-
172 - INLET SCREEN HIT-6684700.A147 6684700	-
173 - PUMP BODY COMP. HIT-6691432.A0 6691432	-
174 - DIAPHRAGM PACKING-METERING HIT-6685220.A139 6685220	£2.81	£3.37
175 - METERING DIAPHRAGM COMP. HIT-6690827.A38 6690827	£14.02	£16.83
176 - DIAPHRAGM COVER-METERING HIT-6685222.A36 6685222	£5.70	£6.84
177 - SET SCREW HIT-6691312.A27 6691312	-
191 - END-PLATE HIT-6688639.A0 6688639	-
193 - HANDLE A HIT-6686732.A1 6686732	-
194 - HEX. HOLE BOLT 5X25 HIT-6695051.A2 6695051	-
195 - WASHER A HIT-6689684.A1 6689684	-
196 - FLANGE NUT 8 HIT-6695171.A0 6695171	-
197 - COUPLING FLANGE HIT-6689247.A3 6689247	-
198 - SCREW 6X16/S HIT-6695358.A3 6695358	-
199 - THROTTLE WIRE COMP. 4T HIT-6693909.A1 6693909	-
200 - THROTTLE LEVER 1 HIT-6693683.A1 6693683	-
221 - END PLATE A HIT-6688640.A0 6688640	-
222 - O-RING G140 HIT-6695688.A2 6695688	-
223 - HANDLE A HIT-6686732.A0 6686732	-
224 - BOLT 5X25 HIT-6694976.A0 6694976	-
225 - WASHER A HIT-6689684.A0 6689684	-
226 - FLANGE NUT 8 HIT-6695171.A1 6695171	-
227 - COUPLING FLANGE HIT-6689247.A2 6689247	-
228 - SCREW 5X16/S HIT-6695337.A0 6695337	-
229 - THROTTLE WIRE COMP. 4T HIT-6693909.A0 6693909	-
230 - THROTTLE LEVER 1 HIT-6693683.A0 6693683	-
251 - CASING HIT-6689179.A0 6689179	-
253 - NO LONGER AVAILABLE HIT-000000.A4348 000000	-
256 - VOLUTE CHAMBER GASKET A HIT-6689039.A1 6689039	-
260 - TAPPING BOLT 8X40P HIT-6695517.A0 6695517	-
261 - BOLT 6X20S HIT-6695440.A0 6695440	-
*265 - IMPELLER SHAFT SHIM A 0.3 HIT-6685978.A0 6685978	-
281 - CASING A HIT-6689180.A0 6689180	£81.32	£97.59
282 - VOLUTE CHAMBER A HIT-6689002.A1 6689002	-
283 - IMPELLER A HIT-6685958.A0 6685958	-
284 - SUCTION PLATE A HIT-6689132.A1 6689132	£15.03	£18.04
285 - MECHANICAL SEAL ASS'Y A HIT-6687496.A2 6687496	-
286 - VOLUTE CHAMBER GASKET A HIT-6689039.A2 6689039	-
287 - SUCTION PLATE PACKING HIT-6689535.A1 6689535	£18.04	£21.65
288 - PRIMING PLUG ASS'Y HIT-6689660.A2 6689660	-
290 - FLANGE BOLT 8X35 HIT-6695480.A1 6695480	-
291 - FLANGE BOLT 6X16 HIT-6695477.A0 6695477	-
292 - WATER COUPLING ASS'Y A HIT-6686258.A0 6686258	£25.96	£31.15
293 - COUPLING PACKING HIT-6686340.A0 6686340	-
294 - IMPELLER SHAFT SHIM A 0.3 HIT-6685978.A1 6685978	-
311 - NO LONGER AVAILABLE HIT-000000.A4349 000000	-
*311 - BED A SINCE Y081576 HIT-6686629.A2 6686629	-
*312 - CUSHION RUBBER TILL Y081575 HIT-6689059.A0 6689059	-
*312 - CUSHION RUBBER A SINCE Y081576 HIT-6689060.A0 6689060	-
*313 - TAPPING SCREW 5X14 TILL Y081575 HIT-6695260.A0 6695260	-
*313 - TAPPING SCREW 5X14 SINCE Y081576 HIT-6695251.A0 6695251	-
*314 - WIRE BAND 33 TILL Y081575 HIT-6687218.A1 6687218	-
*314 - WIRE BAND 33 SINCE Y081576 HIT-6687218.A2 6687218	-
315A - FILTER COMP. A HIT-6686782.A0 6686782	-
316 - SUCTION HOSE A 3M HIT-6687937.A2 6687937	-
317 - COMBI BOX SPANNER 13X19 PLUS HIT-6684979.A14 6684979	-
