1 - COVER FIXING BOLT
HIT-6684655.A8
6684655
|
£7.78
|
£9.34
|
|
|
2 - O-RING (S-4)
HIT-981317.A31
981317
|
£1.67
|
£2.00
|
|
|
3 - AIR CLEANER COVER
HIT-6601540.A0
6601540
|
-
|
|
|
|
4 - AIR CLEANER ELEMENT
HIT-6601539.A8
6601539
|
-
|
|
|
|
5 - SWIVEL
HIT-6684697.A13
6684697
|
-
|
|
|
|
6 - STOP RING
HIT-6684696.A206
6684696
|
-
|
|
|
|
7 - O-RING
HIT-6684695.A11
6684695
|
£1.67
|
£2.00
|
|
|
8 - MAIN JET
HIT-000000.A4552
000000
|
-
|
|
|
|
9 - PUMP GASKET
HIT-6684692.A7
6684692
|
£17.28
|
£20.73
|
|
|
10 - PUMP BODY
HIT-000000.A4553
000000
|
-
|
|
|
|
11 - DIAPHRAGM COVER-METERING
HIT-6685222.A82
6685222
|
£5.70
|
£6.84
|
|
|
12 - SET SCREW
HIT-6691312.A48
6691312
|
-
|
|
|
|
13 - THROTTLE SET SCREW
HIT-6684698.A62
6684698
|
-
|
|
|
|
14 - THROTTLE VALVE
HIT-000000.A4554
000000
|
-
|
|
|
|
15 - PUMP DIAPHRAGM
HIT-6684693.A193
6684693
|
£5.70
|
£6.84
|
|
|
16 - INLET SCREEN
HIT-6684700.A239
6684700
|
-
|
|
|
|
17 - DIAPHRAGM PACKING-METERING
HIT-6685220.A97
6685220
|
£2.81
|
£3.37
|
|
|
18 - METERING DIAPHRAGM
HIT-6684690.A6
6684690
|
£24.05
|
£28.86
|
|
|
19 - SCREW M5X55
HIT-6694914.A25
6694914
|
-
|
|
|
|
20 - BOLT WASHER D5
HIT-6685407.A23
6685407
|
-
|
|
|
|
21 - WAVE WASHER 8
HIT-334242.A28
334242
|
-
|
|
|
|
22 - COLLAR M5
HIT-6601538.A0
6601538
|
-
|
|
|
|
23 - CHOKE VALVE
HIT-6601537.A8
6601537
|
-
|
|
|
|
24 - PRIMING PUMP COMP.
HIT-6685139.A30
6685139
|
£10.67
|
£12.80
|
|
|
25 - FUEL PIPE
HIT-6601607.A2
6601607
|
-
|
|
|
|
26 - CARBURETOR ASS'Y (WYL-367) INCLUD.5-18
HIT-6601535.A8
6601535
|
-
|
|
|
|
27 - AIR CLEANER BASE
HIT-6601536.A0
6601536
|
-
|
|
|
|
28 - LOCK NUT M6 (10 PCS.)
HIT-949567.A5
949567
|
£1.67
|
£2.00
|
|
|
29 - CARBURETOR PACKING
HIT-6698405.A23
6698405
|
£3.12
|
£3.74
|
|
|
30 - HEX. SOCKET HD. BOLT (W/WASHERS) M4X18
HIT-6698388.A69
6698388
|
£1.67
|
£2.00
|
|
|
31 - CORD
HIT-6696544.A11
6696544
|
-
|
|
|
|
32 - SEAL LOCK HEX. SOCKET HD. BOLT M6X27
HIT-6601358.A22
6601358
|
-
|
|
|
|
33 - SPRING WASHER D6
HIT-6600910.A21
6600910
|
-
|
|
|
|
34 - CARBURETOR INSULATOR
HIT-6601491.A14
6601491
|
-
|
|
|
|
35 - INTAKE PACKING
HIT-6601534.A1
6601534
|
-
|
|
|
|
36 - CYLINDER N24
HIT-6600902.A10
6600902
|
-
|
|
|
|
37 - PLUG CAP
HIT-6601421.A46
6601421
|
£1.67
|
£2.00
|
|
|
38 - PLUG CAP METAL
HIT-6699186.A10
6699186
|
£1.67
|
£2.00
|
|
|
39 - IGNITION PLUG (TORCH L7RTC)
HIT-6600542.A6
6600542
|
-
|
|
|
|
40 - HEX. SOCKET HD. BOLT (W/WASHERS) M5
HIT-6600372.A21
6600372
|
-
|
|
|
|
41 - CYLINDER COVER
HIT-6601541.A8
6601541
|
-
|
|
|
|
42 - MUFFLER COVER
HIT-6601544.A1
6601544
|
-
|
|
|
|
43 - WASHER 5
HIT-6685408.A23
6685408
|
£3.49
|
£4.19
|
|
|
44 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X18
HIT-6698386.A61
6698386
|
-
|
|
|
|
45 - GLASS WASHER
HIT-6698700.A17
6698700
|
£1.67
|
£2.00
|
|
|
46 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X22
HIT-6601339.A20
6601339
|
-
|
|
|
|
47 - IGNITION COIL
HIT-6601612.A8
6601612
|
-
|
|
|
|
48 - CYLINDER PACKING
HIT-6601527.A0
6601527
|
-
|
|
|
|
49 - PISTON RING
HIT-6698404.A22
6698404
|
£7.03
|
£8.44
|
|
|
50 - PISTON N24
HIT-6601429.A1
6601429
|
-
|
|
|
|
51 - CIR CLIP
HIT-6684590.A1
6684590
|
£1.67
|
£2.00
|
|
|
52 - WOODRUFF KEY 3X13X4.5
HIT-6601343.A23
6601343
|
-
|
|
|
|
53 - SHIM
HIT-6600909.A4
6600909
|
-
|
|
|
|
54 - PISTON PIN
HIT-6601344.A4
6601344
|
-
|
|
|
|
55 - HEAT PROTECTION PANEL
HIT-6601531.A0
6601531
|
-
|
|
|
|
56 - MUFFLER ASS'Y INCLUD.57-60
HIT-6601530.A2
6601530
|
-
|
|
|
|
57 - EXHAUST PIPE PACKING
HIT-6601606.A7
6601606
|
-
|
|
|
|
58 - SPARK ARRESTER
HIT-6601605.A1
6601605
|
-
|
|
|
|
59 - EXHAUST PIPE
HIT-6601604.A7
6601604
|
-
|
|
|
|
60 - MACHINE SCREW (W/SP. WASHER) M4X12
HIT-6685068.A35
6685068
|
-
|
|
|
|
61 - SEAL LOCK HEX. SOCKET HD. BOLT M6X16
HIT-6600518.A21
6600518
|
-
|
|
|
|
62 - FLYWHEEL NUT M7
HIT-6696879.A23
6696879
|
-
|
|
|
|
63 - BOLT WASHER D7
HIT-6696880.A3
6696880
|
-
|
|
|
|
64 - STARTER PAWL
HIT-6685334.A25
6685334
|
£2.84
|
£3.41
|
|
|
65 - STARTER PAWL SPRING
HIT-6685335.A8
6685335
|
£2.84
|
£3.41
|
|
|
66 - MAGNETO ROTOR COMP.
HIT-6600053.A11
6600053
|
-
|
|
|
|
67 - RETAINING RING D4
HIT-6685336.A27
6685336
|
£3.49
|
£4.19
|
|
|
68 - CRANK CASE (F) ASS'Y INCLUD.69
HIT-6601602.A8
6601602
|
-
|
|
|
|
69 - OIL SEAL TB 12227
HIT-6684607.A41
6684607
|
£4.07
|
£4.88
|
|
|
70 - BALL BEARING 6001 C3
HIT-6684608.A156
6684608
|
£5.70
|
£6.84
|
|
|
71 - CRANK SHAFT
HIT-6601528.A8
6601528
|
-
|
|
|
|
72 - CRANK CASE (G) ASS'Y INCLUD.69
HIT-6601603.A0
6601603
|
-
|
|
|
|
73 - CRANK CASE PACKING
HIT-6600514.A5
6600514
|
-
|
|
|
|
74 - KNOCK PIN 4X12
HIT-6696947.A20
6696947
|
-
|
|
|
|
75 - CLUTCH (B)
HIT-6699173.A15
6699173
|
£11.61
|
£13.93
|
|
|
76 - CLUTCH DRUM
HIT-6601548.A1
6601548
|
-
|
|
|
|
77 - BALL BEARING 6002ZC3
HIT-6698740.A15
6698740
|
£6.94
|
£8.33
|
|
|
78 - RETAINING RING FOR D15 SHAFT (10 PCS.)
HIT-939544.A36
939544
|
£3.64
|
£4.37
|
|
|
79 - GREASE NIPPLE COMP.
HIT-6688643.A28
6688643
|
£1.67
|
£2.00
|
|
|
80 - MACHINE SCREW (W/WASHERS) M5X20 (BLACK)
HIT-995096.A9
995096
|
£1.67
|
£2.00
|
|
|
81 - FIXATION PLATE (B)
HIT-6699048.A12
6699048
|
-
|
|
|
|
82 - FIXATION PLATE (A)
HIT-6699047.A13
6699047
|
-
|
|
|
|
83 - TAIL PIPE COVER
HIT-6601564.A4
6601564
|
-
|
|
|
|
84 - TAIL PIPE
HIT-6601563.A2
6601563
|
-
|
|
|
|
85 - BRAND LABEL
HIT-000000.A2599
000000
|
-
|
|
|
|
86 - TANK MARK LABEL (25:1)
HIT-6698922.A0
6698922
|
-
|
|
|
|
87 - TAPPING SCREW D4.5X16
HIT-6698878.A31
6698878
|
£1.67
|
£2.00
|
|
|
88 - AIR DEFLECTOR
HIT-6601543.A5
6601543
|
-
|
|
|
|
89 - STARTER ASS'Y INCLUD.90-97
HIT-6601542.A3
6601542
|
-
|
|
|
|
90 - PLATE
HIT-6685189.A12
6685189
|
-
|
|
|
|
91 - STARTER HANDLE
HIT-6693227.A19
6693227
|
-
|
|
|
|
92 - STARTER ROPE
HIT-000000.A2600
000000
|
-
|
|
|
|
93 - SPIRAL SPRING
HIT-000000.A2601
000000
|
-
|
|
|
|
94 - REEL
HIT-000000.A2602
000000
|
-
|
|
|
|
95 - DAMPER SPRING
HIT-6685183.A13
6685183
|
£5.70
|
£6.84
|
|
|
96 - CAM PLATE
HIT-000000.A2603
000000
|
-
|
|
|
|
97 - SET SCREW
HIT-6684679.A163
6684679
|
£2.98
|
£3.57
|
|
|
98 - FUEL TANK CAP ASS'Y INCLUD.99
HIT-6698402.A98
6698402
|
-
|
|
|
|
99 - TANK CAP CHAIN
HIT-6698732.A9
6698732
|
-
|
|
|
|
100 - CUSHION RUBBER
HIT-6698615.A7
6698615
|
£3.56
|
£4.27
|
|
|
101 - TANK (FT)
HIT-6601533.A6
6601533
|
-
|
|
|
|
102 - FUEL GROMMET
HIT-6600358.A40
6600358
|
£1.67
|
£2.00
|
|
|
103 - FUEL PIPE
HIT-6698716.A21
6698716
|
£5.61
|
£6.73
|
|
|
104 - FUEL PIPE
HIT-6601399.A19
6601399
|
£3.02
|
£3.63
|
|
|
105 - CLIP
HIT-6696949.A54
6696949
|
£1.67
|
£2.00
|
|
|
106 - PUMP FILTER
HIT-6600351.A47
6600351
|
£4.45
|
£5.34
|
|
|
131 - NAME PLATE
HIT-000000.A2604
000000
|
-
|
|
|
|
132 - HANDLE
HIT-6699079.A11
6699079
|
£8.55
|
£10.26
|
|
|
133 - SEAL LOCK HEX. SOCKET HD. BOLT M5X40
HIT-6698885.A13
6698885
|
£2.84
|
£3.41
|
|
|
134 - SPRING WASHER M5
HIT-6698884.A2
6698884
|
-
|
|
|
|
135 - BRAKE AXIS WASHER
HIT-6698749.A8
6698749
|
-
|
|
|
|
136 - CAUTION LABEL
HIT-000000.A2605
000000
|
-
|
|
|
|
137 - REAR HANDLE (A)
HIT-6601545.A6
6601545
|
-
|
|
|
|
138 - SPRING (A)
HIT-6696348.A28
6696348
|
-
|
|
|
|
139 - LOCK BUTTON
HIT-6601546.A2
6601546
|
-
|
|
|
|
140 - THROTTLE LEVER
HIT-6699053.A20
6699053
|
-
|
|
|
|
141 - TRIGGER LOCKOUT
HIT-6696344.A28
6696344
|
£2.84
|
£3.41
|
|
|
142 - THROTTLE LEVER SPRING
HIT-6696345.A4
6696345
|
£2.84
|
£3.41
|
|
|
143 - STOP SWITCH
HIT-6601275.A42
6601275
|
£1.67
|
£2.00
|
|
|
144 - REAR HANDLE (B)
HIT-6601547.A6
6601547
|
-
|
|
|
|
145 - TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
HIT-305812.A13
305812
|
£1.67
|
£2.00
|
|
|
146 - THROTTLE WIRE
HIT-6601613.A4
6601613
|
-
|
|
|
|
147 - PROTECTION TUBE
HIT-6698738.A15
6698738
|
£1.67
|
£2.00
|
|
|
148 - STOP SWITCH CORD (B)
HIT-6699059.A15
6699059
|
-
|
|
|
|
149 - STOP SWITCH CORD
HIT-6696491.A5
6696491
|
-
|
|
|
|
150 - NYLON NUT M5
HIT-305491.A4
305491
|
-
|
|
|
|
151 - SMALL WASHER 5
HIT-6684864.A110
6684864
|
-
|
|
|
|
152 - U-NUT M5
HIT-6699108.A12
6699108
|
£2.94
|
£3.53
|
|
|
153 - SUPPORT PLATE
HIT-6601558.A0
6601558
|
-
|
|
|
|
154 - GUIDE PLATE (EA)
HIT-6601615.A1
6601615
|
-
|
|
|
|
155 - BLADE ASS'Y (500MM) INCLUD.152
HIT-6601553.A1
6601553
|
-
|
|
|
|
156 - BLADE GUIDE
HIT-6600009.A5
6600009
|
£13.28
|
£15.93
|
|
|
157 - HEX. SOCKET HD. BOLT (W/BUTTON) M5X25
HIT-6699110.A5
6699110
|
£2.75
|
£3.30
|
|
|
158 - WASHER (B)
HIT-6699112.A20
6699112
|
£1.67
|
£2.00
|
|
|
159 - BLADE LINER
HIT-6600359.A4
6600359
|
-
|
|
|
|
160 - HEDGE TRIMMER BLADE (A)
HIT-6600010.A2
6600010
|
£25.61
|
£30.73
|
|
|
161 - HEDGE TRIMMER BLADE (B)
HIT-6600011.A5
6600011
|
£25.76
|
£30.91
|
|
|
162 - WASHER M7
HIT-6699111.A4
6699111
|
£1.67
|
£2.00
|
|
|
163 - SHOULDER BUTTON BOLT M5X25
HIT-000000.A2606
000000
|
-
|
|
|
|
164 - BLADE CASE (A)
HIT-6698731.A4
6698731
|
-
|
|
|
|
165 - HANDLE BRACKET
HIT-6601565.A2
6601565
|
-
|
|
|
|
166 - CLIP
HIT-6696359.A17
6696359
|
£2.84
|
£3.41
|
|
|
167 - SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5
HIT-6699044.A2
6699044
|
-
|
|
|
|
168 - GEAR CASE (A)
HIT-6601608.A1
6601608
|
-
|
|
|
|
169 - GUIDE PLATE (C)
HIT-6601549.A2
6601549
|
-
|
|
|
|
170 - GEAR 2 (EA)
HIT-6699038.A7
6699038
|
-
|
|
|
|
171 - FELT PACKING (A)
HIT-6601559.A3
6601559
|
-
|
|
|
|
172 - GEAR CASE PACKING
HIT-6601561.A7
6601561
|
-
|
|
|
|
173 - WASHER (EA)
HIT-6601618.A3
6601618
|
-
|
|
|
|
174 - GEAR CASE COVER
HIT-6601562.A1
6601562
|
-
|
|
|
|
175 - HEX. SOCKET HD. BOLT M4X12
HIT-6698385.A39
6698385
|
-
|
|
|
|
501 - BOX WRENCH 10/19MM
HIT-6698756.A11
6698756
|
-
|
|
|
