Hitachi / Hikoki TBC260PF Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC260PF Engine Brush Cutter

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A26 6684894	£7.75	£9.30
2A - SPARK PLUG ASS'Y CJ6 HIT-6699322.A36 6699322	£3.73	£4.48
3 - CYLINDER ASS'Y HIT-6684897.A2 6684897	£79.58	£95.50
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A34 6684586	-
5 - CYLINDER GASKET HIT-6684896.A6 6684896	£1.67	£2.00
6 - PISTON RING HIT-6684588.A9 6684588	£6.38	£7.66
7 - PISTON ASS'Y HIT-6684898.A2 6684898	£40.45	£48.54
8 - CIR CLIP HIT-6684590.A71 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A41 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A7 6686219	£121.07	£145.28
11 - STOP CORD B 190M HIT-6687836.A4 6687836	-
12 - EARTH CORD B 165M HIT-6688443.A1 6688443	-
13 - HEX. HOLE BOLT M4X18/WS TILL H100550 HIT-6684599.A44 6684599	-
13A - HIGH TENSION SCREW 4X18WS SINCE H100551 HIT-6695407.A31 6695407	-
14 - WASHER T1.6 HIT-6684600.A29 6684600	-
15 - IGNITION COIL ASS'Y MB-55 HIT-6687684.A4 6687684	£35.79	£42.95
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A31 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A50 6684605	-
22 - CRANK CASE ASS'Y HIT-6684905.A14 6684905	£30.92	£37.11
23 - OIL SEAL TB 12227 HIT-6684607.A160 6684607	£4.07	£4.88
24 - BALL BEARING 6001 C3 HIT-6684608.A45 6684608	£5.70	£6.84
25 - CRANK CASE GASKET HIT-6684904.A7 6684904	£1.67	£2.00
26 - HEX. HOLE BOLT M5X16/S HIT-6684903.A60 6684903	-
27 - MAGNETO ROTOR COMP. HIT-6687384.A5 6687384	-
28 - BOLT WASHER M8 HIT-6684611.A49 6684611	-
29 - HEX. NUT M8 HIT-6684612.A77 6684612	-
41 - INLET MANIFOLD GASKET HIT-6689895.A28 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A28 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT 5X25/WS HIT-6684617.A3 6684617	-
44 - CARBURETOR PACKING HIT-6684616.A30 6684616	£1.67	£2.00
45 - CHOKE PLATE 2.0 HIT-6691276.A12 6691276	£1.67	£2.00
46 - CLEANER BODY COMP. HIT-6690120.A7 6690120	£12.32	£14.78
47 - CLEANER SPONGE HIT-6690365.A12 6690365	£1.67	£2.00
48 - CLEANER COVER ASS'Y HIT-6690402.A13 6690402	£12.16	£14.59
49 - COVER FIXING BOLT COMP. HIT-6698730.A27 6698730	£5.52	£6.63
50 - SCREW M5X55 HIT-6694914.A0 6694914	-
51 - S.WASHER 5 HIT-6684662.A46 6684662	£1.67	£2.00
52 - SMALL WASHER 5 HIT-6684864.A129 6684864	-
53 - CARBURETOR SET WYJ318 HIT-6690465.A2 6690465	-
54 - CHOKE CONTROL LEVER HIT-6691239.A13 6691239	£2.98	£3.57
55A - TANK HIT-6697951.A6 6697951	-
56 - STAND HIT-6694787.A40 6694787	£3.56	£4.27
57 - COLLAR C HIT-6684623.A16 6684623	£1.67	£2.00
58A - RETURN GROMMET HIT-6697846.A94 6697846	£2.08	£2.50
59 - FUEL PIPE 3X5X65 HIT-6684626.A18 6684626	£1.67	£2.00
60A - PUMP FILTER BODY COMP HIT-66A3864.A87 66A3864	-
61 - CLIP D6 HIT-6685198.A68 6685198	-
62A - SHIELD TUBE SET HIT-6698970.A8 6698970	-
63 - HEX. HOLE BOLT 5X25/WS HIT-6684617.A4 6684617	-
64 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A32 6684634	£1.67	£2.00
65 - TANK CAP D ASS'Y HIT-6691748.A8 6691748	£6.04	£7.25
66 - TAP SCREW 4X14 P HIT-6695280.A14 6695280	£1.67	£2.00
67 - BOLT WASHER M4 HIT-6685070.A26 6685070	£1.67	£2.00
81 - CYLINDER COVER (BLK) HIT-6685693.A13 6685693	-
82 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A31 6695504	£1.67	£2.00
83 - HEX. HOLE BOLT M6X65 HIT-6695067.A14 6695067	£1.67	£2.00
84 - BOLT WASHER 6 HIT-6684639.A108 6684639	£1.67	£2.00
85 - MUFFLER COMP. HIT-6692576.A2 6692576	£58.68	£70.42
86 - TAIL PIPE GASKET HIT-6692888.A4 6692888	-
87 - TAIL PIPE SET HIT-6692715.A2 6692715	-
88 - SCREW M4X8/WS HIT-6684651.A15 6684651	-
89 - SPARK ARRESTER HIT-6692701.A2 6692701	-
90 - HEAT SHIELD HIT-6687265.A4 6687265	£5.70	£6.84
91 - MUFFLER PROTECTOR BLK HIT-6692818.A3 6692818	£16.09	£19.31
92 - HEX. HOLE BOLT 4X18WS TILL H100550 HIT-6695508.A35 6695508	£1.67	£2.00
92A - SCREW 4X18/PS SINCE H100551 HIT-6695375.A25 6695375	-
93 - PLUG COVER HIT-6688344.A1 6688344	-
94 - CLUTCH WASHER B HIT-6684642.A17 6684642	£1.67	£2.00
95 - CLUTCH SHOE COMP. HIT-6684643.A13 6684643	£12.01	£14.41
96 - CLUTCH SPRING HIT-6684644.A11 6684644	£3.12	£3.74
97 - CLUTCH PLATE A 0.5 HIT-6684645.A15 6684645	£1.67	£2.00
98 - STEP BOLT HIT-6684646.A21 6684646	£3.72	£4.46
99 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A33 6684634	£1.67	£2.00
100 - BENT WASHER 8 HIT-6684648.A69 6684648	£1.67	£2.00
101 - TAPPING SCREW D4.5X16 HIT-6684636.A27 6684636	£1.67	£2.00
111 - RECOIL STARTER BODY ASS'Y HIT-6684938.A2 6684938	£18.59	£22.31
112 - RECOIL STARTER BODY COMP. HIT-6684944.A2 6684944	-
113 - STARTER ROPE REEL HIT-6684941.A14 6684941	£7.41	£8.89
114 - RECOIL SPRING HIT-6684942.A2 6684942	£5.17	£6.20
115 - SWING ARM HIT-6684940.A2 6684940	£1.67	£2.00
116 - SET SCREW HIT-6684679.A117 6684679	£2.98	£3.57
117 - PULLEY STAY HIT-6684939.A13 6684939	-
118 - ROPE 3.0X800 HIT-6684943.A13 6684943	-
119 - STARTER HANDLE HIT-6684680.A34 6684680	£5.87	£7.04
121 - STARTER PULLEY HIT-6684937.A14 6684937	£3.56	£4.27
122 - HEX. HOLE BOLT 4X18WS TILL H100550 HIT-6695508.A36 6695508	£1.67	£2.00
122A - SCREW 4X18/PS SINCE H100551 HIT-6695375.A26 6695375	-
131 - PUMP BODY COMP. HIT-6684879.A6 6684879	£35.37	£42.44
132 - PRIMING PUMP COMP. HIT-6684687.A29 6684687	£9.27	£11.12
133 - DIAPHRAGM COVER HIT-6684688.A71 6684688	£5.70	£6.84
134 - PRIMING BODY HIT-6684689.A28 6684689	£5.87	£7.04
135 - METERING DIAPHRAGM COMP. HIT-6690830.A3 6690830	£14.58	£17.50
136 - DIAPHRAGM GASKET HIT-6684691.A26 6684691	£5.70	£6.84
137 - PUMP DIAPHRAGM HIT-6684693.A65 6684693	£5.70	£6.84
138 - PUMP GASKET HIT-6691457.A7 6691457	£8.48	£10.18
139 - MAIN JET #38.5 HIT-6696130.A8 6696130	-
140 - STARTER PULLEY HIT-6684937.A13 6684937	£3.56	£4.27
141 - STOP RING HIT-6684696.A68 6684696	-
142 - SWIVEL HIT-6684697.A106 6684697	-
143 - THROTTLE SET SCREW HIT-6684870.A67 6684870	-
144 - CABLE ADJUSTER STAY HIT-6684873.A13 6684873	-
145 - LOCK NUT M6 HIT-6684872.A69 6684872	-
146 - CABLE ADJUSTER HIT-6684871.A11 6684871	-
147 - CLEANER PACKING HIT-6684875.A15 6684875	-
148 - SET SCREW HIT-6684699.A72 6684699	-
149 - THRUST WASHER HIT-6684874.A64 6684874	-
150 - INLET SCREEN HIT-6684700.A91 6684700	-
161 - CLUTCH DRUM COMP. HIT-6688580.A8 6688580	£16.79	£20.15
162 - STOP RING C-12 OUTER HIT-6684664.A42 6684664	£1.67	£2.00
163 - CUSHION RUBBER HIT-6691823.A4 6691823	£3.56	£4.27
164 - HEX. HOLE BOLT 5X16 HIT-6695046.A19 6695046	£1.67	£2.00
165 - HEX. HOLE BOLT M5X25/S HIT-6684709.A115 6684709	£1.67	£2.00
166 - FAN CASE COMP. HIT-6686959.A9 6686959	£25.96	£31.15
167 - PIPE HOLDER 1 HIT-6689651.A19 6689651	£8.88	£10.66
168 - WASHER M5 (BLACK) HIT-6684918.A101 6684918	£1.67	£2.00
169 - GEAR CASE WASHER HIT-6689159.A42 6689159	-
170 - METAL FITTING HIT-6689664.A2 6689664	£6.12	£7.35
181 - DRIVE SHAFT 1487L HIT-6689477.A0 6689477	£21.52	£25.82
182 - DRIVE SHAFT PIPE COMP. HIT-6689386.A3 6689386	£52.12	£62.54
183 - BUSH ASS'Y HIT-6684831.A17 6684831	-
184 - HEX.NUT 6 HIT-6684835.A24 6684835	£1.67	£2.00
185 - LOOP HANDLE BLACK HIT-6691046.A6 6691046	£16.30	£19.56
186 - HANDLE BRACKET A HIT-6691134.A0 6691134	£3.10	£3.72
187 - HANDLE GRIP HIT-6691098.A14 6691098	£10.90	£13.08
188 - BOLT 6X43/P (BLACK) HIT-6684838.A20 6684838	£1.67	£2.00
189 - THROTTLE WIRE COMP. 1 HIT-6693963.A0 6693963	-
190 - TAPPING SCREW 5X20 HIT-6695255.A7 6695255	-
191 - BRAKE SHAFT WASHER HIT-6689681.A43 6689681	£1.67	£2.00
192 - THROTTLE LEVER ASS'Y HIT-6693736.A0 6693736	-
193 - STOP SWITCH HIT-6687515.A4 6687515	£1.67	£2.00
194 - TAPPING SCREW 3X8 HIT-6695274.A0 6695274	-
195 - STOP SWITCH BASE HIT-6688374.A9 6688374	-
196 - STOP SWITCH SPRING HIT-6688385.A9 6688385	-
197 - EARTH TERMINAL B HIT-6687805.A2 6687805	-
198 - EARTH TERMINAL A HIT-6687801.A7 6687801	-
199 - SPECIAL NUT M5 HIT-6685000.A11 6685000	-
200 - STOP RING E-6 HIT-6695311.A19 6695311	£1.67	£2.00
201 - RETURN SPRING HIT-6693601.A5 6693601	-
202 - THROTTLE ARM HIT-6693804.A2 6693804	-
203 - SCREW 5X20 HIT-6695453.A2 6695453	-
204 - LOCK BUTTON SHAFT HIT-6693653.A7 6693653	-
205 - LOCK BUTTON SPRING HIT-6694834.A0 6694834	-
206 - LOCK BUTTON HIT-6694829.A7 6694829	-
207 - STOP CORD 2 HIT-6687915.A2 6687915	-
208 - PROTECTION TUBE 10X190L HIT-6687563.A0 6687563	-
209A - SHAFT GRIP HIT-6697902.A0 6697902	-
221 - GEAR CASE ASSY 24 HIT-6688812.A1 6688812	-
222 - HEX. HOLE BOLT M5X25/S HIT-6684709.A116 6684709	£1.67	£2.00
223 - RETAINING RING C-TYPE D22 HIT-6695293.A5 6695293	£1.67	£2.00
224 - STOP RING OUTER 10 HIT-6695315.A6 6695315	-
225 - BALL BEARING HIT-6695579.A1 6695579	-
226 - BALL BEARING 6900 1 HIT-6695577.A4 6695577	-
227 - GEAR CASE 24 HIT-6688808.A0 6688808	-
228 - HEX.HOLE BOLT M5X12/S HIT-6684667.A30 6684667	£1.67	£2.00
229 - OILING BOLT HIT-6689109.A14 6689109	-
230 - BALL BEARING 609 HIT-6684734.A32 6684734	-
231 - GEAR SHAFT HIT-6688946.A2 6688946	-
232 - BALL BEARING 6201D 1 HIT-6695554.A15 6695554	-
233 - STOP RING C-32 1 HIT-6695295.A23 6695295	£1.67	£2.00
234 - CUTTER HOLDER HIT-6689032.A23 6689032	£15.16	£18.19
235 - GEAR CASE WASHER HIT-6689159.A41 6689159	-
236 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A15 6684714	£1.67	£2.00
237 - GUARD BRACKET HIT-6685065.A2 6685065	-
238 - GUARD 24 DIA. HIT-6690272.A0 6690272	-
239 - GUARD HOLDER HIT-6690343.A4 6690343	-
240 - KNIFE HIT-6693388.A1 6693388	-
241 - TAPPING SCREW 5X20 HIT-6684753.A89 6684753	£1.67	£2.00
242 - HEX.HOLE BOLT M5X12/S HIT-6684667.A29 6684667	£1.67	£2.00
243 - GEAR PINION SET SPARE HIT-6688882.A0 6688882	£41.72	£50.07
501 - HEX. BAR WRENCH 4MM HIT-6684813.A26 6684813	-
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A32 6684764	£7.64	£9.17
510 - NYLON HEAD BF-5 TILL TL060520 HIT-6695784.A7 6695784	£27.81	£33.37
511 - MOUNTING NUT L-M10X1.25 TILL TL060520 HIT-6684756.A4 6684756	£10.80	£12.96
512 - CUTTING BODY TILL TL060520 HIT-6684757.A10 6684757	£15.38	£18.45
513 - SPECIAL NUT TILL TL060520 HIT-6684758.A6 6684758	£6.18	£7.41
514 - REEL SPRING TILL TL060520 HIT-6684759.A10 6684759	£3.56	£4.27
515 - SPOOL TILL TL060520 HIT-6684760.A6 6684760	£13.48	£16.18
516 - CUTTING BODY CAP TILL TL060520 HIT-6684761.A10 6684761	£21.34	£25.61
517 - EYELET TILL TL060520 HIT-6684762.A6 6684762	£3.56	£4.27
518 - MOUNTING NUT L-M8X1.25 TILL TL060520 HIT-6689624.A11 6689624	-
519 - BOLT WASHER M12 TILL TL060520 HIT-6685072.A4 6685072	-
520 - SURE TAP MANUAL P/L 9 TILL TL060520 HIT-6697805.A3 6697805	-
521 - NYLON CORD CUTTER SINCE TL060521 HIT-6601148.A0 6601148	£25.68	£30.81
522 - CASE SINCE TL060521 HIT-6601149.A17 6601149	-
523 - NUT SINCE TL060521 HIT-6601150.A0 6601150	-
524 - REEL SPRING SINCE TL060521 HIT-6693380.A1 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL060521 HIT-6601151.A17 6601151	-
526 - COVER SINCE TL060521 HIT-6601152.A0 6601152	-
527 - EYELET SINCE TL060521 HIT-6684810.A30 6684810	£3.29	£3.95
601 - NAME PLATE HIT-6694245.A0 6694245	-
602 - SYMBOL MARK TBC260PF HIT-6694686.A0 6694686	-
603 - SYMBOL MARK HIT-6694741.A1 6694741	-
