Hitachi / Hikoki TBC255PF Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC255PF Engine Brush Cutter

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A25 6684894	£7.75	£9.30
2A - SPARK PLUG ASS'Y CJ6 HIT-6699322.A38 6699322	£3.73	£4.48
3 - CYLINDER ASS'Y HIT-6684897.A1 6684897	£79.58	£95.50
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A32 6684586	-
5 - CYLINDER GASKET HIT-6684896.A7 6684896	£1.67	£2.00
6 - PISTON RING HIT-6684588.A11 6684588	£6.38	£7.66
7 - PISTON ASS'Y HIT-6684898.A3 6684898	£40.45	£48.54
8 - CIR CLIP HIT-6684590.A69 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6684591.A43 6684591	£3.29	£3.95
10 - CRANK SHAFT COMP. HIT-6686219.A6 6686219	£121.07	£145.28
11 - STOP CORD B 190M HIT-6687836.A5 6687836	-
12 - EARTH CORD B 165M HIT-6688443.A2 6688443	-
13 - HEX. HOLE BOLT M4X18/WS TILL H100550 HIT-6684599.A42 6684599	-
13A - HIGH TENSION SCREW 4X18WS SINCE H100551 HIT-6695407.A32 6695407	-
14 - WASHER T1.6 HIT-6684600.A31 6684600	-
15 - IGNITION COIL ASS'Y MB-55 HIT-6687684.A5 6687684	£35.79	£42.95
*21 - GEAR SHAFT SHIM 0.20 HIT-6684604.A29 6684604	-
*21 - GEAR SHAFT SHIM 0.30 HIT-6684605.A52 6684605	-
22 - CRANK CASE ASS'Y HIT-6684905.A13 6684905	£30.92	£37.11
23 - OIL SEAL TB 12227 HIT-6684607.A159 6684607	£4.07	£4.88
24 - BALL BEARING 6001 C3 HIT-6684608.A46 6684608	£5.70	£6.84
25 - CRANK CASE GASKET HIT-6684904.A8 6684904	£1.67	£2.00
26 - HEX. HOLE BOLT M5X16/S HIT-6684903.A59 6684903	-
27 - MAGNETO ROTOR COMP. HIT-6687384.A4 6687384	-
28 - BOLT WASHER M8 HIT-6684611.A48 6684611	-
29 - HEX. NUT M8 HIT-6684612.A78 6684612	-
41 - INLET MANIFOLD GASKET HIT-6689895.A26 6689895	£1.67	£2.00
42 - INSULATOR SET HIT-6689972.A26 6689972	£6.59	£7.91
43 - HEX. HOLE BOLT 5X25/WS HIT-6684617.A5 6684617	-
44 - SWIVEL CAP HIT-6691337.A4 6691337	£1.67	£2.00
45 - CARBURETOR PACKING HIT-6684616.A28 6684616	£1.67	£2.00
46 - THROTTLE WIRE FIXING PLATE HIT-6684629.A3 6684629	-
47 - CABLE ADJUSTER HIT-6684871.A9 6684871	-
48 - LOCK NUT M6 HIT-6684872.A71 6684872	-
49 - CARBURETOR GASKET HIT-6684615.A14 6684615	£1.67	£2.00
50 - O-RING P-15 HIT-6698966.A34 6698966	£1.67	£2.00
51 - SCREW M5X60 HIT-6684660.A12 6684660	-
52 - S.WASHER 5 HIT-6684662.A44 6684662	£1.67	£2.00
53 - WASHER 5 HIT-6684661.A60 6684661	£1.67	£2.00
54 - CARBURETOR SET WYL222 HIT-6690466.A0 6690466	-
55A - TANK HIT-6697951.A5 6697951	-
56 - STAND HIT-6694787.A39 6694787	£3.56	£4.27
57 - COLLAR C HIT-6684623.A14 6684623	£1.67	£2.00
58A - RETURN GROMMET HIT-6697846.A93 6697846	£1.68	£2.01
59 - FUEL PIPE 3X5X65 HIT-6684626.A17 6684626	£1.67	£2.00
60A - PUMP FILTER BODY COMP HIT-66A3864.A86 66A3864	-
61 - CLIP D6 HIT-6685198.A67 6685198	-
62A - SHIELD TUBE SET HIT-6698970.A7 6698970	-
63 - HEX. HOLE BOLT 5X25/WS HIT-6684617.A6 6684617	-
64 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A30 6684634	£1.67	£2.00
65 - TANK CAP D ASS'Y HIT-6691748.A7 6691748	£6.04	£7.25
81 - CYLINDER COVER (BLK) HIT-6685693.A12 6685693	-
82 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A30 6695504	£1.67	£2.00
83 - HEX. HOLE BOLT M6X65 HIT-6695067.A13 6695067	£1.67	£2.00
84 - BOLT WASHER 6 HIT-6684639.A106 6684639	£1.67	£2.00
85 - MUFFLER COMP. HIT-6692576.A3 6692576	£58.68	£70.42
86 - TAIL PIPE GASKET HIT-6692888.A3 6692888	-
87 - TAIL PIPE SET HIT-6692715.A3 6692715	-
88 - SCREW M4X8/WS HIT-6684651.A16 6684651	-
89 - SPARK ARRESTER HIT-6692701.A3 6692701	-
90 - HEAT SHIELD HIT-6687265.A5 6687265	£5.70	£6.84
91 - MUFFLER PROTECTOR BLK HIT-6692818.A2 6692818	£16.09	£19.31
92 - HEX. HOLE BOLT 4X18WS TILL H100550 HIT-6695508.A40 6695508	£1.67	£2.00
92A - SCREW 4X18/PS SINCE H100551 HIT-6695375.A23 6695375	-
93 - PLUG COVER HIT-6688344.A0 6688344	-
94 - CLUTCH WASHER B HIT-6684642.A18 6684642	£1.67	£2.00
95 - CLUTCH SHOE COMP. HIT-6684643.A12 6684643	£12.01	£14.41
96 - CLUTCH SPRING HIT-6684644.A12 6684644	£3.12	£3.74
97 - CLUTCH PLATE A 0.5 HIT-6684645.A13 6684645	£1.67	£2.00
98 - STEP BOLT HIT-6684646.A22 6684646	£3.72	£4.46
99 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A31 6684634	£1.67	£2.00
100 - BENT WASHER 8 HIT-6684648.A67 6684648	£1.67	£2.00
101 - TAPPING SCREW D4.5X16 HIT-6684636.A28 6684636	£1.67	£2.00
102 - CORD CLAMP COMP. HIT-6688011.A23 6688011	-
111 - RECOIL STARTER BODY ASS'Y HIT-6684938.A4 6684938	£18.59	£22.31
112 - RECOIL STARTER BODY COMP. HIT-6684944.A4 6684944	-
113 - STARTER ROPE REEL HIT-6684941.A12 6684941	£7.41	£8.89
114 - RECOIL SPRING HIT-6684942.A4 6684942	£5.17	£6.20
115 - SWING ARM HIT-6684940.A4 6684940	£1.67	£2.00
116 - SET SCREW HIT-6684679.A116 6684679	£2.98	£3.57
117 - PULLEY STAY HIT-6684939.A11 6684939	-
118 - ROPE 3.0X800 HIT-6684943.A11 6684943	-
119 - STARTER HANDLE HIT-6684680.A35 6684680	£5.87	£7.04
121 - STARTER PULLEY HIT-6684937.A11 6684937	£3.56	£4.27
122 - HEX. HOLE BOLT 4X18WS TILL H100550 HIT-6695508.A41 6695508	£1.67	£2.00
122A - SCREW 4X18/PS SINCE H100551 HIT-6695375.A24 6695375	-
131 - AIR CLEANER ASS'Y HIT-6690005.A2 6690005	-
132 - AIR CLEANER CAP HIT-6690139.A3 6690139	£7.15	£8.58
133 - CLEANER ELEMENT HIT-6690347.A25 6690347	£7.15	£8.58
134 - COLLAR HIT-6690801.A2 6690801	-
135 - CLEANER BODY COMP. HIT-6690085.A0 6690085	-
141 - PUMP BODY COMP. HIT-6684879.A9 6684879	£35.37	£42.44
142 - PRIMING PUMP COMP. HIT-6684687.A28 6684687	£9.27	£11.12
143 - DIAPHRAGM COVER HIT-6684688.A72 6684688	£5.70	£6.84
144 - PRIMING BODY HIT-6684689.A27 6684689	£5.87	£7.04
145 - METERING DIAPHRAGM COMP. HIT-6690830.A5 6690830	£14.58	£17.50
146 - DIAPHRAGM GASKET HIT-6684691.A27 6684691	£5.70	£6.84
147 - PUMP DIAPHRAGM HIT-6684693.A68 6684693	£5.70	£6.84
148 - PUMP GASKET HIT-6691457.A3 6691457	£8.48	£10.18
149 - LONG MAIN JET #33.5 HIT-6691887.A0 6691887	-
150 - O-RING HIT-6684695.A127 6684695	£1.67	£2.00
151 - STOP RING HIT-6684696.A71 6684696	-
152 - SWIVEL HIT-6684697.A103 6684697	-
153 - THROTTLE SET SCREW HIT-6684698.A23 6684698	-
154 - SET SCREW HIT-6684699.A68 6684699	-
155 - INLET SCREEN HIT-6684700.A95 6684700	-
161 - CLUTCH DRUM COMP. HIT-6688580.A7 6688580	£16.79	£20.15
162 - STOP RING C-12 OUTER HIT-6684664.A44 6684664	£1.67	£2.00
163 - CUSHION RUBBER HIT-6691823.A5 6691823	£3.56	£4.27
164 - HEX. HOLE BOLT 5X16 HIT-6695046.A20 6695046	£1.67	£2.00
165 - HEX. HOLE BOLT M5X25/S HIT-6684709.A121 6684709	£1.67	£2.00
166 - FAN CASE COMP. HIT-6686959.A8 6686959	£25.96	£31.15
167 - PIPE HOLDER 1 HIT-6689651.A17 6689651	£8.88	£10.66
168 - WASHER M5 (BLACK) HIT-6684918.A102 6684918	£1.67	£2.00
169 - GEAR CASE WASHER HIT-6689159.A40 6689159	-
170 - METAL FITTING HIT-6689664.A1 6689664	£6.12	£7.35
191 - DRIVE SHAFT 1480L HIT-6696009.A2 6696009	£16.15	£19.38
192 - DRIVE SHAFT PIPE COMP.1450L HIT-6689410.A1 6689410	£27.59	£33.11
193 - BUSH ASS'Y HIT-6684831.A18 6684831	-
194 - NUT M5 (BLACK) HIT-6685075.A9 6685075	-
195 - FRONT HANDLE 24 HIT-6691057.A0 6691057	-
196 - HEX.HOLE BOLT 5X30S HIT-6695426.A2 6695426	-
197 - THROTTLE WIRE 335+70 HIT-6693977.A0 6693977	-
198 - THROTTLE LEVER ASS'Y 24 HIT-6693770.A1 6693770	-
199 - THROTTLE LEVER HIT-6685006.A1 6685006	-
200 - RETURN SPRING HIT-6684998.A2 6684998	-
201 - STOP SWITCH HIT-6685009.A1 6685009	-
202 - SWITCH MARK HIT-6685003.A4 6685003	-
203 - STOP SWITCH COMP. HIT-6687462.A1 6687462	-
204 - MACHINE SCREW M5X30 HIT-6685076.A2 6685076	-
205 - NUT M5 HIT-6684965.A37 6684965	£1.67	£2.00
206 - PROTECTION TUBE D7X170 HIT-6685007.A4 6685007	-
207 - SHAFT GRIP HIT-6691183.A0 6691183	-
221 - GEAR CASE ASS'Y 1 HIT-6688819.A1 6688819	£66.07	£79.28
222 - HEX. HOLE BOLT M5X25/S HIT-6684709.A118 6684709	£1.67	£2.00
223 - STOP RING C-24 1 HIT-6684732.A36 6684732	£1.67	£2.00
224 - STOP RING C-9 1 HIT-6695281.A17 6695281	-
225 - BALL BEARING 609Z ST HIT-6684735.A7 6684735	£15.48	£18.57
226 - GEAR CASE 24 HIT-6688815.A8 6688815	-
227 - HEX.HOLE BOLT M5X12/S HIT-6684667.A31 6684667	£1.67	£2.00
228 - OILING BOLT HIT-6689109.A13 6689109	-
229 - BALL BEARING 626 1 HIT-6695567.A2 6695567	-
230 - GEAR SHAFT HIT-6688949.A1 6688949	-
231 - BALL BEARING 6000D 1 HIT-6695527.A8 6695527	£12.50	£15.00
232 - RETAINING RING C-TYPE D26 HIT-6695294.A31 6695294	-
233 - CUTTER HOLDER HIT-6689033.A0 6689033	£11.61	£13.93
234 - GEAR CASE COVER HIT-6688917.A0 6688917	£1.67	£2.00
235 - GEAR/PINION SET HIT-6688883.A6 6688883	£24.88	£29.85
236 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A28 6685064	-
237 - S.WASHER 6 HIT-6684826.A23 6684826	£1.67	£2.00
238 - GUARD BRACKET HIT-6685065.A1 6685065	-
239 - SAFETY COVER COMP. HIT-6685066.A4 6685066	-
240 - KNIFE HIT-6685067.A0 6685067	-
241 - MACHINE SCREW (W/SP. WASHER) M4X12 HIT-6685068.A38 6685068	-
242 - NUT M4 HIT-6685069.A12 6685069	-
243 - BOLT WASHER M4 HIT-6685070.A25 6685070	£1.67	£2.00
501 - HEX. BAR WRENCH 4MM HIT-6684813.A27 6684813	-
502 - COMBI BOX SPANNER 13X19 HIT-6693588.A6 6693588	-
503 - NYLON HEAD/SURE TAP 1 HIT-6693221.A1 6693221	-
504 - MOUNTING NUT L-M8X1.25 HIT-6689624.A12 6689624	-
505 - CUTTING BODY HIT-6684757.A11 6684757	£15.38	£18.45
506 - SPECIAL NUT HIT-6684758.A5 6684758	£6.18	£7.41
507 - REEL SPRING HIT-6684759.A11 6684759	£3.56	£4.27
508 - SPOOL HIT-6684760.A5 6684760	£13.48	£16.18
509 - CUTTING BODY CAP HIT-6684761.A11 6684761	£21.34	£25.61
510 - EYELET HIT-6684762.A5 6684762	£3.56	£4.27
601 - NAME PLATE HIT-6694245.A1 6694245	-
602 - SYMBOL MARK TBC255PF HIT-6694691.A0 6694691	-
603 - SYMBOL MARK HIT-6694741.A0 6694741	-
