Hitachi / Hikoki TBC-550 Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-550 Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687479.A6 6687479	-
2 - SPARK PLUG RUBBER COVER HIT-6688336.A3 6688336	£3.56	£4.27
3 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A23 6699319	-
4 - CYLINDER SET HIT-6685470.A2 6685470	£85.28	£102.33
5 - HEX.HOLE BOLT M5X18/S HIT-6684586.A10 6684586	-
6 - CYLINDER GASKET HIT-6685738.A0 6685738	£1.67	£2.00
7 - PISTON RING HIT-6686126.A6 6686126	£9.27	£11.12
8 - PISTON SET HIT-6685887.A2 6685887	£35.58	£42.69
9 - PISTON PIN 10X35 HIT-6686019.A11 6686019	£4.12	£4.94
10 - PISTON PIN CIRCLIP HIT-6686026.A15 6686026	£1.67	£2.00
11 - PISTON PIN COLLAR HIT-6685993.A18 6685993	£5.70	£6.84
12 - CRANK SHAFT COMP. HIT-6686190.A0 6686190	£123.58	£148.29
13 - NEEDLE BEARING 1 HIT-6695602.A14 6695602	-
14 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A1 6686457	£1.67	£2.00
31 - SMALL NUT 10 HIT-6695139.A14 6695139	-
32 - CRANK CASE ASS'Y HIT-6686553.A0 6686553	£60.99	£73.19
33 - CRANK CASE GASKET HIT-6686713.A2 6686713	£1.67	£2.00
34 - OIL SEAL UD15257 HIT-6695637.A17 6695637	£3.66	£4.39
35 - BALL BEARING #6202 2 HIT-6695557.A32 6695557	-
36 - CRANK SHAFT WASHER 15.2X22 HIT-6686463.A3 6686463	-
*37 - CRANK SHAFT SHIM 0.10 HIT-6686470.A5 6686470	-
*37 - CRANK SHAFT SHIM 0.20 HIT-6686472.A19 6686472	£1.67	£2.00
*37 - CRANK SHAFT SHIM 0.30 HIT-6686473.A12 6686473	£1.67	£2.00
38 - SCREW 6X45/S TILL A188600 HIT-6695367.A0 6695367	-
38A - HEX HOLE BUTTON SCREW 6X45 SINCE A188601 HIT-6695084.A8 6695084	-
39 - S.WASHER 6 SINCE A188601 HIT-6684826.A32 6684826	£1.67	£2.00
40 - HEX.HOLE BOLT 6X30/S TILL A188600 HIT-6695499.A5 6695499	-
40A - HEX. SOCKET HD. BOLT (W/BUTTON) M6 SINCE A188601 HIT-6684825.A1 6684825	£1.67	£2.00
41 - LOCK NUT M6 HIT-6684872.A61 6684872	-
42 - OUTER RECEIVER HIT-6694043.A9 6694043	-
43 - MAGNETO ROTOR COMP. HIT-6687371.A5 6687371	£59.76	£71.71
44 - SMALL WASHER 10 HIT-6695185.A3 6695185	-
45 - NUT 10 HIT-6695138.A18 6695138	-
46 - IGNITION COIL COMP. HIT-6687649.A4 6687649	£38.26	£45.91
47 - SCREW 5X18/S HIT-6695339.A26 6695339	-
48 - SMALL WASHER 5 HIT-6684864.A82 6684864	-
49 - PRIMARY CORD GROMMET HIT-6688049.A9 6688049	-
50 - CORD CLAMP COMP. HIT-6688004.A5 6688004	-
51 - FAN CASE HIT-6686972.A0 6686972	-
52 - SCREW 6X20/S HIT-6695361.A1 6695361	-
53 - PRIMARY CORD GROMMET HIT-6688055.A3 6688055	-
55 - LEAD WIRE ASS'Y HIT-6687966.A2 6687966	-
71 - FUEL TANK CUSHION RUBBER HIT-6692225.A5 6692225	£1.67	£2.00
72 - INLET MANUFOLD GASKET HIT-6689883.A2 6689883	£1.67	£2.00
73 - CARB. INSULATOR SET HIT-6689950.A2 6689950	-
74 - CARBURETOR GASKET HIT-6689826.A1 6689826	£1.67	£2.00
75 - CARBURETOR SET HDA305 TILL B031700 HIT-6690467.A1 6690467	£95.09	£114.11
75A - CARBURETOR SET HDA306 SINCE B031701 HIT-6690468.A4 6690468	£104.42	£125.30
76 - SCREW 5X24WS HIT-6695423.A2 6695423	-
77 - CHOKE LEVER HIT-6691004.A4 6691004	£2.98	£3.57
78 - FUEL PIPE 2.5X4X90 HIT-6685267.A13 6685267	£1.67	£2.00
79 - SMALL NUT 10 HIT-6695139.A12 6695139	-
80 - INNER TOOTHED WASHER 10 HIT-6695235.A1 6695235	-
81 - PRIMING PUMP COMP. HIT-6690080.A3 6690080	£11.79	£14.15
82 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A12 6688166	£5.17	£6.20
83 - CLIP 1 HIT-6684619.A17 6684619	£1.67	£2.00
84 - PUMP FILTER BODY ASS'Y HIT-6692273.A12 6692273	£9.60	£11.52
85 - FUEL TANK 1 HIT-6691526.A4 6691526	£14.33	£17.20
86 - RETURN GROMMET HIT-6697846.A89 6697846	£2.08	£2.50
87 - TANK CAP D ASS'Y.ORANGE HIT-6691716.A1 6691716	£9.00	£10.80
88 - TANK HOLDING BAND HIT-6691927.A4 6691927	£14.69	£17.63
89 - CUSHION RUBBER HIT-6692193.A0 6692193	£12.50	£15.00
90 - SCREW 5X16/PS HIT-6695386.A26 6695386	£1.67	£2.00
92 - TANK CAP CHAIN HIT-6684625.A42 6684625	-
111 - MUFFLER PROTECTOR HIT-6692777.A6 6692777	-
112 - SCREW 5X12/PS HIT-6695383.A7 6695383	£1.67	£2.00
113 - HEX.HOLE BOLT M5X12/S HIT-6684667.A45 6684667	£1.67	£2.00
114 - WASHER M5 (BLACK) HIT-6684918.A97 6684918	£1.67	£2.00
115 - HEX. HOLE BUTTON SCREW 6X65 HIT-6695088.A5 6695088	£3.72	£4.46
116 - BOLT WASHER 6 HIT-6684639.A112 6684639	£1.67	£2.00
117 - MUFFLER SET 1 HIT-6692465.A4 6692465	£36.60	£43.92
118 - MUFFLER SPECIAL GASKET HIT-6692883.A22 6692883	-
119 - TAIL PIPE SET 1 HIT-6692648.A3 6692648	-
120 - SCREW 4X8/S HIT-6695325.A18 6695325	-
121 - MUFFLER GASKET HIT-6692741.A6 6692741	£3.89	£4.67
122 - HEAT SHIELD HIT-6687242.A0 6687242	£4.81	£5.77
123 - SCREW 5X18/PS HIT-6695389.A6 6695389	£1.67	£2.00
124 - TANK BRACKET HIT-6692205.A5 6692205	£10.50	£12.60
125 - FUEL TANK CUSHION RUBBER HIT-6692227.A2 6692227	£1.67	£2.00
126 - CLUTCH WASHER B HIT-6689645.A2 6689645	£1.67	£2.00
127 - CLUTCH ARM HIT-6688615.A0 6688615	£20.95	£25.14
128 - CLUTCH SPRING HIT-6689429.A4 6689429	£4.26	£5.11
129 - WAVE WASHER 10 HIT-6695203.A15 6695203	£1.67	£2.00
130 - CLUTCH STEP BOLT HIT-6689628.A10 6689628	£3.29	£3.95
131 - CLUTCH SET ASS'Y HIT-6699561.A6 6699561	£25.82	£30.99
151 - RECOIL STARTER BODY ASS'Y HIT-6692970.A1 6692970	£38.87	£46.64
152 - RECOIL STARTER BODY COMP. HIT-6693025.A24 6693025	£14.11	£16.93
153 - STARTER ROPE REEL HIT-6693007.A13 6693007	£12.57	£15.08
154 - RECOIL SPRING HIT-6693114.A11 6693114	£9.02	£10.82
155 - STARTER ROPE HIT-6693165.A10 6693165	-
156 - STARTER HANDLE CAP HIT-6693607.A24 6693607	-
157 - STARTER HANDLE HIT-6693232.A10 6693232	-
158 - SET SCREW HIT-6693634.A25 6693634	-
159 - STARTER PAWL HIT-6693302.A23 6693302	£3.89	£4.67
160 - STOP RING E-5 HIT-6684683.A13 6684683	-
161 - SCREW 5X25PS HIT-6695395.A1 6695395	-
162 - STARTER PAWL SPRING HIT-6693345.A34 6693345	£3.89	£4.67
163 - STARTER PULLEY HIT-6693395.A3 6693395	£11.02	£13.22
181 - CLEANER BODY SET HIT-6699506.A1 6699506	-
182 - COLLAR 5.8 HIT-6692244.A4 6692244	£1.67	£2.00
183 - BLOW OVER CHECK BOARD COMP. HIT-6690848.A1 6690848	-
184 - CLEANER ELEMENT HIT-6690357.A2 6690357	£3.38	£4.06
185 - CLEANER COVER ASS'Y HIT-6690149.A0 6690149	£16.05	£19.26
186 - COVER FIXING BOLT HIT-6690383.A1 6690383	-
187 - SCREW 5X60/S HIT-6695354.A20 6695354	£1.67	£2.00
201 - SCREW HIT-6685210.A60 6685210	-
202 - PUMP BODY HIT-6691420.A3 6691420	-
203 - PUMP GASKET HIT-6691455.A11 6691455	-
204 - PUMP DIAPHRAGM HIT-6691446.A3 6691446	-
205 - INLET SCREEN HIT-6684700.A70 6684700	-
206 - IDLE ADJUST SPRING HIT-6690766.A29 6690766	-
207 - IDLE ADJUST SCREW HIT-6690736.A20 6690736	-
208 - NEEDLE VALVE HIT-6685215.A77 6685215	£6.79	£8.15
209 - VALVE SPRING TILL B031700 HIT-6690871.A3 6690871	-
209A - VALVE SPRING SINCE B031701 HIT-6690874.A1 6690874	-
210 - CONTROL LEVER HIT-6690819.A4 6690819	-
211 - HINGE PIN HIT-6685219.A74 6685219	-
212 - HINGE PIN SET SCREW HIT-6685218.A14 6685218	-
213 - DIAPHRAGM GASKET HIT-6690840.A2 6690840	-
214 - METERING DIAPHRAGM COMP. HIT-6690829.A7 6690829	-
215 - AIR PURGE COMP. HIT-6690434.A6 6690434	£28.14	£33.77
216 - DIAPHRAGM COVER HIT-6690860.A7 6690860	-
217 - SET SCREW HIT-6691310.A0 6691310	-
218 - ADJUST SPRING TILL B031700 HIT-6692049.A0 6692049	-
219 - LOW ADJUST SCREW TILL B031700 HIT-6690715.A0 6690715	-
220 - HIGH ADJUST SCREW TILL B031700 HIT-6690692.A0 6690692	-
231 - CLUTCH SHAFT COMP. HIT-6688582.A1 6688582	-
232 - BALL BEARING #6202Z 2 HIT-6695559.A20 6695559	£12.76	£15.31
233 - STOP RING C-15 1 HIT-6695285.A26 6695285	£1.67	£2.00
234 - CLUTCH FLANGE HIT-6689506.A0 6689506	-
235 - SCREW 5X16/S HIT-6695337.A9 6695337	-
236 - CUSHION RUBBER COMP. HIT-6691828.A0 6691828	-
237 - CLUTCH CASE HIT-6689193.A1 6689193	-
238 - HEX.HOLE BOLT M5X12/S HIT-6684667.A48 6684667	£1.67	£2.00
239 - HEX. HOLE BOLT 5X10 HIT-6695042.A14 6695042	£1.67	£2.00
240 - PIPE HOLDER HIT-6688541.A1 6688541	-
241 - HEX HOLE BUTTON SCREW 6X45 HIT-6695084.A6 6695084	-
242 - S.WASHER 6 HIT-6684826.A28 6684826	£1.67	£2.00
243 - WASHER 6 HIT-6695194.A6 6695194	-
244 - SQUARE NUT 6 HIT-6696512.A1 6696512	-
261 - DRIVE SHAFT HIT-6689464.A1 6689464	-
262 - DRIVE SHAFT PIPE COMP. 1 HIT-6689356.A1 6689356	-
263 - BUSHING ASS'Y HIT-6689515.A4 6689515	-
264 - LIFTING METAL HIT-6689271.A1 6689271	-
265 - LIFTING METAL COLLAR HIT-6689252.A1 6689252	-
266 - HEX. HOLE BOLT 5X30.P HIT-6695501.A1 6695501	-
267 - SPECIAL NUT HIT-6689100.A4 6689100	-
268 - HANDLE GRIP HIT-6684708.A10 6684708	£3.56	£4.27
269 - HEX. HOLE BOLT 5X22/S HIT-6695492.A2 6695492	-
270 - HANDLE BRACKET A 1 HIT-6691132.A1 6691132	-
271 - HANDLE BRACKET B 1 HIT-6691148.A0 6691148	-
272 - HANDLE BRACKET C 1 HIT-6691167.A0 6691167	-
273 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A1 6684714	£1.67	£2.00
274 - CLAMP B. HIT-6684715.A14 6684715	-
275 - LEFT HANDLE HIT-6684716.A0 6684716	-
276 - PROTECTION TUBE 7X790L HIT-6687542.A1 6687542	-
278 - RIGHT HANDLE SK HIT-6691075.A0 6691075	-
279 - THROTTLE LEVER ASS'Y 19 HIT-6693728.A2 6693728	£42.70	£51.24
280 - TRIGGER LOCK OUT HIT-6684721.A14 6684721	£5.17	£6.20
281 - RETURN SPRING HIT-6684722.A34 6684722	£1.67	£2.00
282 - THROTTLE LEVER HIT-6684723.A5 6684723	-
283 - BLIND PLUG TILL D030000 HIT-6684724.A24 6684724	-
284 - SCREW M4X20 (BLACK) HIT-6684725.A19 6684725	-
285 - SCREW 5X30 (BLACK) HIT-6684726.A15 6684726	£1.67	£2.00
286 - CONTAL NUT 5 HIT-6684727.A13 6684727	£1.67	£2.00
287 - STOP SWITCH TILL D030000 HIT-6687438.A0 6687438	-
287A - STOP SWITCH COMP. SINCE D030001 HIT-6687439.A1 6687439	-
289 - THROTTLT WIRE HIT-6694008.A1 6694008	£14.80	£17.76
290 - THROTTLE WIRE COMP. TILL D030000 HIT-6693953.A0 6693953	-
290A - THROTTLE WIRE COMP. SINCE D030001 HIT-6693954.A1 6693954	-
301 - GEAR CASE ASS'Y 1 HIT-6688801.A5 6688801	£145.24	£174.29
302 - HEX. HOLE BOLT M5X25/S HIT-6684709.A103 6684709	£1.67	£2.00
303 - STOP RING C-28 1 HIT-6684741.A15 6684741	-
304 - STOP RING C-12 OUTER HIT-6684664.A39 6684664	£1.67	£2.00
305 - BALL BEARING #6001Z 1 HIT-6695532.A2 6695532	£15.01	£18.01
306 - BALL BEARING 6001 C3 HIT-6684608.A36 6684608	£5.70	£6.84
307 - GEARCASE 1 HIT-6688703.A3 6688703	-
308 - SPRING WASHER 5 SINCE A188601 HIT-6684834.A37 6684834	£1.67	£2.00
309 - HEX.HOLE BOLT M5X12/S TILL A188600 HIT-6684667.A47 6684667	£1.67	£2.00
309A - HEX. SOCKET HD. BOLT M5X12 SINCE A188601 HIT-6684829.A10 6684829	-
310 - PLUS HEAD BOLT 8X10 HIT-6695437.A7 6695437	-
311 - BALL BEARING #6000 1 HIT-6695524.A17 6695524	-
312 - GEAR SHAFT 6X11X14 HIT-6688942.A1 6688942	-
313A - BALL BEARING #6203DD 1 HIT-6695564.A4 6695564	-
314 - STOP RING C-40 1 HIT-6695298.A5 6695298	-
315 - CUTTER HOLDER HIT-6689022.A3 6689022	-
316 - CUTTER HOLDER CAP.6X11X14 HIT-6689052.A1 6689052	£7.22	£8.66
317 - PROTECTION COVER A COMP. HIT-6688982.A3 6688982	£8.45	£10.14
318 - SCREW 5X16/WS HIT-6695418.A3 6695418	-
319 - CUTTER FIXING NUT 1 HIT-6689072.A4 6689072	£6.61	£7.93
320 - GEAR CASE WASHER HIT-6689157.A0 6689157	-
321 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A2 6684714	£1.67	£2.00
322 - COVER BRACKET TILL D113950 HIT-6690299.A2 6690299	-
322A - COVER BRACKET 30 SINCE D113951 HIT-6690312.A5 6690312	-
323 - BLADE GUARD 30 CE TILL E047000 HIT-6690230.A7 6690230	-
323A - BLADE GUARD 30 CE SINCE E047001 HIT-6690264.A6 6690264	£20.67	£24.80
324 - GUARD HOLDER HIT-6684748.A8 6684748	-
325 - COVER GUARD TILL E047000 HIT-6690372.A5 6690372	£2.81	£3.37
325A - BLADE GUARD SINCE E047001 HIT-6690376.A7 6690376	£9.34	£11.21
326 - KNIFE TILL E047000 HIT-6693386.A36 6693386	£8.53	£10.24
326A - KNIFE SINCE E047001 HIT-6684750.A12 6684750	£3.64	£4.37
327 - SCREW 5X12/S TILL E047000 HIT-6695334.A31 6695334	£1.67	£2.00
327A - TAPPING SCREW 4X14 SINCE E047001 HIT-6684751.A91 6684751	£1.67	£2.00
328 - GEAR-PINION SET 1 HIT-6688866.A6 6688866	-
329 - NUT M5 TILL E047000 HIT-6684965.A34 6684965	£1.67	£2.00
330 - KNIFE SINCE E047001 HIT-6684754.A3 6684754	£6.64	£7.97
331 - TAPPING SCREW 5X20 SINCE E047001 HIT-6684753.A96 6684753	£1.67	£2.00
501 - HEX. BAR WRENCH 4MM HIT-6684813.A32 6684813	-
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A40 6684764	£7.64	£9.17
503 - PROTECTION COVER B HIT-6688994.A6 6688994	£3.85	£4.62
504A - PROTECTIVE GLASSES HIT-875769.A112 875769	-
505 - CUTTER COVER HIT-6692016.A1 6692016	-
506 - BLADE B3/12/3.0 HIT-6695792.A2 6695792	£18.81	£22.57
507 - SHOULDER HARNESS D3X HIT-6695796.A12 6695796	£25.30	£30.36

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-550 Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TBC-550 Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TBC-550 Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
