Hitachi / Hikoki TBC-430PFLV Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-430PFLV Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG RUBBER COVER HIT-6688336.A2 6688336	£3.56	£4.27
2 - SPARK PLUG CAP ASS'Y HIT-6687479.A7 6687479	-
3A - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A17 6699328	£5.70	£6.84
4 - CYLINDER SET HIT-6685476.A2 6685476	-
5 - HEX.HOLE BOLT M5X20/S HIT-6684668.A48 6684668	-
6 - CYLINDER GASKET HIT-6685741.A2 6685741	-
7 - PISTON RING HIT-6686123.A6 6686123	-
8 - PISTON SET HIT-6685889.A4 6685889	-
9 - PISTON PIN 10X30 HIT-6686007.A4 6686007	£3.52	£4.23
10 - PISTON PIN CIRCLIP HIT-6686032.A0 6686032	£1.67	£2.00
11 - CRANK SHAFT COMP. HIT-6686192.A2 6686192	-
13 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A0 6686457	£1.67	£2.00
14 - IGNITION COIL COMP. HIT-6687655.A9 6687655	£32.83	£39.40
15 - RUBBER CAP HIT-6684602.A39 6684602	-
16 - HIGH TENSION CORD HIT-6687885.A12 6687885	£1.67	£2.00
17 - IGNITION COIL ASS'Y HIT-6687657.A4 6687657	£33.12	£39.74
18 - LEAD WIRE ASS'Y HIT-6687970.A1 6687970	-
19 - SCREW 4X18/WS HIT-6695406.A3 6695406	-
20 - WASHER T1.6 HIT-6684600.A10 6684600	-
21 - CORD CLAMP COMP. HIT-6688011.A31 6688011	-
41 - CRANK CASE ASS'Y HIT-6686559.A4 6686559	-
42 - CRANK CASE GASKET HIT-6686715.A2 6686715	-
43 - OIL SEAL UD15257 HIT-6695637.A18 6695637	£3.66	£4.39
44 - BALL BEARING #6202 2 HIT-6695557.A33 6695557	-
*45 - CRANK SHAFT SHIM 0.10 HIT-6686470.A6 6686470	-
*45 - CRANK SHAFT SHIM 0.20 HIT-6686472.A18 6686472	£1.67	£2.00
*45 - CRANK SHAFT SHIM 0.30 HIT-6686473.A13 6686473	£1.67	£2.00
46 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A14 6684786	£1.67	£2.00
47 - MAGNETO ROTOR COMP. HIT-6687372.A2 6687372	-
48 - WASHER 10 HIT-6695198.A24 6695198	-
49 - NUT 10 HIT-6695138.A17 6695138	-
50 - SMALL NUT 10 HIT-6695139.A13 6695139	-
81 - INLET MANIFOLD GASKET HIT-6689885.A10 6689885	£2.81	£3.37
82 - CARB.INSULATOR SET 1 HIT-6689955.A10 6689955	£16.19	£19.43
83 - CARBURETOR GASKET HIT-6689833.A2 6689833	£1.67	£2.00
85 - COLLAR HIT-6690802.A12 6690802	£2.81	£3.37
86 - CLEANER BODY COMP. HIT-6690099.A12 6690099	£13.72	£16.47
87 - CHOKE VALVE HIT-6691258.A4 6691258	£3.62	£4.35
88 - BLOW OVER CHECK BOARD HIT-6690843.A4 6690843	£1.67	£2.00
89A - CLEANER ELEMENT 6T HIT-6690352.A3 6690352	£1.67	£2.00
90 - WAVE WASHER 8 HIT-6684658.A42 6684658	£1.67	£2.00
91 - CLEANER COVER ASS'Y HIT-6690397.A5 6690397	£6.61	£7.93
92 - SPECIAL SCREW HIT-6689737.A6 6689737	-
93 - SCREW M5X60 HIT-6684660.A20 6684660	-
94 - S.WASHER 5 HIT-6684662.A75 6684662	£1.67	£2.00
95 - CARBURETOR SET TILL B039000 HIT-6690477.A0 6690477	-
95A - CARBURETOR SET 1 HIT-6690476.A5 6690476	-
97 - HEX. HOLE BOLT 5X25WS HIT-6695425.A3 6695425	-
98 - TANK FIXING COLLAR HIT-6692182.A0 6692182	-
99 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A11 6688166	£5.17	£6.20
100A - CLIP D6 HIT-6685198.A50 6685198	-
101B - PUMP FILTER BODY COMP TILL TL060520 HIT-66A3864.A50 66A3864	-
102 - TANK WHT HIT-6691539.A6 6691539	-
103 - COLLAR C HIT-6684623.A22 6684623	£1.67	£2.00
104 - TANK CAP ASS'Y HIT-6691714.A9 6691714	£8.44	£10.13
105 - AIR VENT RUBBER CAP HIT-6691369.A0 6691369	-
106 - AIR VENT VALVE ASS'Y HIT-6692172.A2 6692172	-
107 - AIR VENT PIPE HIT-6691394.A0 6691394	-
108 - AIR VENT ASS'Y HIT-6691385.A0 6691385	-
109 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A14 6684634	£1.67	£2.00
110 - ENGINE BED HIT-6694785.A9 6694785	-
111 - FUEL PIPE 3X5X85 HIT-6684880.A34 6684880	-
112 - CLIP 5.5 HIT-6692305.A3 6692305	-
113 - FUEL PIPE GROMMET HIT-6688156.A15 6688156	-
114 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A15 6684786	£1.67	£2.00
115 - WASHER M5 (BLACK) HIT-6684918.A78 6684918	£1.67	£2.00
117 - TANK CAP CHAIN HIT-6684625.A14 6684625	-
118 - PUMP FILTER ASS'Y SINCE TL060521 HIT-6601175.A0 6601175	-
131 - MUFFLER PROTECTOR HIT-6692783.A4 6692783	-
132 - HEX.HOLE BOLT M5X12/S HIT-6684667.A18 6684667	£1.67	£2.00
134 - HEX. HOLE BOLT M6X65 HIT-6695067.A5 6695067	£1.67	£2.00
135 - BOLT WASHER 6 HIT-6684639.A10 6684639	£1.67	£2.00
136 - MUFFLER SET 1 HIT-6692472.A1 6692472	-
136A - MUFFLER SET 1 HIT-6692473.A2 6692473	-
137 - WASHER M5 (BLACK) HIT-6684918.A79 6684918	£1.67	£2.00
138 - TAIL PIPE HIT-6692652.A4 6692652	-
139 - MACHINE SCREW (W/SP. WASHER) M4X8 HIT-6685109.A19 6685109	-
140 - MUFFLER ARRESTOR HIT-6692696.A0 6692696	-
141 - MUFFLER GASKET HIT-6692741.A0 6692741	£3.89	£4.67
142 - HEAT SHIELD HIT-6687246.A2 6687246	-
144A - GROMMET HIT-6688050.A6 6688050	£1.67	£2.00
145 - HEX. HOLE BOLT M5X25/S HIT-6684709.A187 6684709	£1.67	£2.00
146 - WASHER M5 (BLACK) HIT-6684918.A80 6684918	£1.67	£2.00
147 - CLUTCH WASHER B HIT-6689645.A13 6689645	£1.67	£2.00
148 - CLUTCH ARM COMP. HIT-6688614.A12 6688614	£9.58	£11.50
149 - CLUTCH SPRING HIT-6689428.A0 6689428	£2.98	£3.57
150 - WAVE WASHER 10 HIT-6695203.A3 6695203	£1.67	£2.00
151 - CLUTCH STEP BOLT HIT-6689632.A3 6689632	£4.26	£5.11
152 - CLUTCH SET ASS'Y HIT-6699556.A3 6699556	-
171 - RECOIL STARTER BODY ASS'Y HIT-6697645.A15 6697645	£28.11	£33.73
172 - RECOIL STARTER BODY COMP. TILL G104480 HIT-6693025.A12 6693025	£14.11	£16.93
172A - RECOIL STARTER BODY COMP SINCE G104481 HIT-6697646.A8 6697646	-
173 - STARTER ROPE REEL TILL G104480 HIT-6693007.A25 6693007	£12.57	£15.08
173A - STARTER ROPE REEL SINCE G104481 HIT-6697647.A15 6697647	-
174 - RECOIL SPRING TILL G104480 HIT-6693114.A9 6693114	£9.02	£10.82
174A - RECOIL SPRING SINCE G104481 HIT-6697648.A8 6697648	-
175 - STARTER ROPE TILL G104480 HIT-6693165.A0 6693165	-
175A - STARTER ROPE SINCE G104481 HIT-6697649.A15 6697649	-
176 - STARTER HANDLE CAP TILL G104480 HIT-6693607.A18 6693607	-
177 - STARTER HANDLE TILL G104480 HIT-6693232.A0 6693232	-
177A - STARTER HANDLE SINCE G104481 HIT-6697650.A8 6697650	-
178 - SET SCREW HIT-6693634.A14 6693634	-
179 - STARTER PAWL TILL G104480 HIT-6693302.A21 6693302	£3.89	£4.67
179A - STARTER PAWL SINCE G104481 HIT-6697643.A15 6697643	-
*180 - D4E RETAINING RING TILL G104480 HIT-6685101.A85 6685101	-
*180 - D4E RETAINING RING SINCE G104481 HIT-6685101.A86 6685101	-
181 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A15 6684634	£1.67	£2.00
182 - STARTER PAWL SPRING TILL G104480 HIT-6693345.A23 6693345	£3.89	£4.67
182A - STARTER PAWL SPRING SINCE G104481 HIT-6697642.A8 6697642	-
183 - STARTER PULLEY TILL G104480 HIT-6693395.A13 6693395	£11.02	£13.22
183A - STARTER PULLEY ASS'Y SINCE G104481 HIT-6697644.A8 6697644	£12.94	£15.53
191 - THROTTLE SET SCREW HIT-6684870.A56 6684870	-
192 - CABLE ADJUSTER STAY HIT-6684873.A22 6684873	-
193 - SWIVEL HIT-6684697.A115 6684697	-
194 - THRUST WASHER HIT-6684874.A57 6684874	-
195 - STOP RING HIT-6684696.A53 6684696	-
196 - CABLE ADJUSTER HIT-6684871.A19 6684871	-
197 - O-RING HIT-6684695.A144 6684695	£1.67	£2.00
198 - MAIN JET 1 HIT-6696131.A1 6696131	-
199 - LOCK NUT M6 HIT-6684872.A60 6684872	-
200 - PUMP GASKET HIT-6691457.A27 6691457	£8.48	£10.18
201 - PUMP DIAPHRAGM HIT-6684693.A48 6684693	£5.70	£6.84
202 - INLET SCREEN HIT-6684700.A35 6684700	-
203 - PUMP BODY COMP. HIT-6684879.A30 6684879	£35.37	£42.44
204 - DIAPHRAGM GASKET HIT-6684691.A17 6684691	£5.70	£6.84
205 - METERING DIAPHRAGM COMP. HIT-6690827.A58 6690827	£14.02	£16.83
206 - DIAPHRAGM COVER HIT-6684688.A81 6684688	£5.70	£6.84
207 - SET SCREW HIT-6684699.A91 6684699	-
208 - CLEANER PACKING HIT-6684875.A23 6684875	-
209 - PRIMING PUMP COMP. HIT-6684687.A19 6684687	£9.27	£11.12
210 - PRIMING BODY HIT-6684689.A18 6684689	£5.87	£7.04
241 - CLUTCH SHAFT COMP. HIT-6688585.A4 6688585	£31.85	£38.22
242 - BALL BEARING #6202ZZ 1 HIT-6695558.A0 6695558	-
243 - STOP RING C-35 1 HIT-6695296.A24 6695296	-
244 - STOP RING C-15 1 HIT-6695285.A0 6695285	£1.67	£2.00
245 - PROTECTOR HIT-6688348.A4 6688348	-
246 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A16 6684634	£1.67	£2.00
247 - HEX.HOLE BOLT 6X25 HIT-6695093.A4 6695093	-
248 - FAN CASE HIT-6686980.A3 6686980	-
249 - HEX.HOLE BOLT M5X20/S HIT-6684668.A49 6684668	-
250 - PRIMARY CORD GROMMET SINCE TL003741 HIT-6688057.A19 6688057	-
251 - WASHER M5 (BLACK) HIT-6685226.A18 6685226	-
271 - DRIVE SHAFT 1 HIT-6689476.A4 6689476	£25.99	£31.19
272 - DRIVE SHAFT PIPE HIT-6689403.A5 6689403	-
273 - BUSHING ASS'Y HIT-6689515.A7 6689515	-
274 - KNOB BOLT HIT-6691207.A1 6691207	£8.77	£10.52
275 - HANDLE BRACKET A HIT-6691143.A3 6691143	£9.68	£11.62
276 - HANDLE BRACKET B HIT-6691159.A4 6691159	-
277 - SUPPORT HOLDER HIT-6691237.A5 6691237	-
278 - HANDLE SUPPORT COMP. HIT-6691232.A5 6691232	£31.02	£37.23
279 - SPECIAL NUT M6X1.0 HIT-6689102.A2 6689102	£10.03	£12.04
280 - ANTI-VIBE RUBBER HIT-6689165.A0 6689165	£6.12	£7.35
281 - LOCK NUT 6 UPS-P HIT-6695175.A2 6695175	£1.67	£2.00
282 - HEX. HOLE BOLT 6X30 HIT-6695094.A1 6695094	-
283 - CORD CLAMP HIT-6688016.A2 6688016	-
284 - HANDLE GRIP HIT-6687627.A4 6687627	-
285 - CORD CLAMP HIT-6688025.A5 6688025	-
286 - HANDLE HIT-6691079.A1 6691079	-
287 - THROTTLE LEVER ASS'Y 22 HIT-6693762.A3 6693762	-
288 - PROTECTION TUBE 1 HIT-6687547.A3 6687547	-
289 - TRIGGER LOCK OUT HIT-6684721.A9 6684721	£5.17	£6.20
290 - RETURN SPRING HIT-6684722.A38 6684722	£1.67	£2.00
291 - THROTTLE LEVER HIT-6684723.A4 6684723	-
292 - BLIND PLUG TILL D021300 HIT-6684724.A27 6684724	-
293 - SCREW M4X20 (BLACK) HIT-6684725.A13 6684725	-
294 - SCREW 5X30 (BLACK) HIT-6684726.A16 6684726	£1.67	£2.00
295 - CONTAL NUT 5 HIT-6684727.A9 6684727	£1.67	£2.00
296A - STOP SWITCH COMP. SINCE D021301 HIT-6687458.A1 6687458	-
297 - THROTTLE WIRE 1 HIT-6694021.A1 6694021	£20.95	£25.14
298 - THROTTLE WIRE COMP. TILL D021300 HIT-6693974.A0 6693974	-
298A - THROTTLE WIRE COMP. SINCE D021301 HIT-6693975.A0 6693975	£18.81	£22.57
311 - GEAR CASE ASS'Y 1 HIT-6688801.A7 6688801	£145.24	£174.29
312 - HEX. HOLE BOLT M5X25/S HIT-6684709.A186 6684709	£1.67	£2.00
313 - STOP RING C-28 1 HIT-6684741.A2 6684741	-
314 - STOP RING C-12 OUTER HIT-6684664.A51 6684664	£1.67	£2.00
315 - BALL BEARING #6001Z 1 HIT-6695532.A6 6695532	£15.01	£18.01
316 - BALL BEARING 6001 C3 HIT-6684608.A77 6684608	£5.70	£6.84
317 - GEARCASE 1 HIT-6688703.A1 6688703	-
318 - SPRING WASHER 5 HIT-6684834.A62 6684834	£1.67	£2.00
319 - HEX. SOCKET HD. BOLT M5X12 HIT-6684829.A8 6684829	-
320 - PLUS HEAD BOLT 8X10 HIT-6695437.A3 6695437	-
321 - BALL BEARING #6000 1 HIT-6695524.A20 6695524	-
322 - GEAR SHAFT 6X11X14 HIT-6688942.A3 6688942	-
323A - BALL BEARING #6203DD 1 HIT-6695564.A7 6695564	-
324 - STOP RING C-40 1 HIT-6695298.A8 6695298	-
325 - CUTTER HOLDER HIT-6689022.A1 6689022	-
326 - CUTTER HOLDER CAP.6X11X14 HIT-6689052.A3 6689052	£7.22	£8.66
327 - PROTECTION COVER A COMP. HIT-6688982.A1 6688982	£8.45	£10.14
328 - SCREW 5X16/WS HIT-6695418.A4 6695418	-
329 - CUTTER FIXING NUT 1 HIT-6689072.A3 6689072	£6.61	£7.93
330 - GEAR CASE WASHER HIT-6689157.A3 6689157	-
331 - GEAR-PINION SET 1 HIT-6688866.A5 6688866	-
332 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A56 6684714	£1.67	£2.00
333 - COVER BRACKET TILL E030600 HIT-6690299.A3 6690299	-
333A - COVER BRACKET 30 SINCE E030601 HIT-6690312.A7 6690312	-
334 - BLADE GUARD 30 CE TILL E030600 HIT-6690230.A5 6690230	-
334A - BLADE GUARD 30 CE SINCE E030601 HIT-6690264.A5 6690264	£20.67	£24.80
335 - GUARD HOLDER HIT-6684748.A19 6684748	-
336 - COVER GUARD TILL E030600 HIT-6690372.A7 6690372	£2.81	£3.37
336A - BLADE GUARD SINCE E030601 HIT-6690376.A16 6690376	£9.34	£11.21
337 - KNIFE TILL E030600 HIT-6693386.A29 6693386	£8.53	£10.24
337A - KNIFE SINCE E030601 HIT-6684750.A34 6684750	£3.64	£4.37
338 - SCREW 5X12/S TILL E030600 HIT-6695334.A29 6695334	£1.67	£2.00
338A - TAPPING SCREW 4X14 SINCE E030601 HIT-6684751.A66 6684751	£1.67	£2.00
339 - NUT M5 TILL E030600 HIT-6684965.A44 6684965	£1.67	£2.00
*340 - TAPPING SCREW 5X20 SINCE E030601 HIT-6684753.A77 6684753	£1.67	£2.00
*340 - TAPPING SCREW 5X20 TILL J034870 HIT-6684753.A78 6684753	£1.67	£2.00
*341 - KNIFE SINCE E030601 HIT-6684754.A16 6684754	£6.64	£7.97
*341 - KNIFE TILL J034870 HIT-6684754.A17 6684754	£6.64	£7.97
342 - SPLIT PIN SET(10 PCS/PACK) TILL W254355 HIT-6689168.A1 6689168	-
501 - HEX. BAR WRENCH 4MM HIT-6684813.A13 6684813	-
502 - HEX. WRENCH 5 HIT-6693529.A7 6693529	-
503 - CUTTER COVER HIT-6692016.A3 6692016	-
504 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A16 6684764	£7.64	£9.17
505A - PROTECTIVE GLASSES HIT-875769.A145 875769	-
506 - BLADE B3/12/3.0 HIT-6695792.A1 6695792	£18.81	£22.57
507 - PROTECTION COVER B HIT-6688994.A7 6688994	£3.85	£4.62
508 - SHOULDER HARNESS D5 HIT-6695797.A5 6695797	£38.32	£45.99
601 - NAME PLATE TBC-430PFLV HIT-6696243.A0 6696243	-
602 - SYMBOL MARK 1 HIT-6694625.A2 6694625	-
603 - SYMBOL MARK HIT-6694741.A4 6694741	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-430PFLV Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TBC-430PFLV Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TBC-430PFLV Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
