Hitachi / Hikoki TBC-430PF Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-430PF Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG RUBBER COVER HIT-6688336.A4 6688336	£3.56	£4.27
2 - SPARK PLUG CAP ASS'Y HIT-6687479.A4 6687479	-
3A - SPARK PLUG ASS'Y BPM6A HIT-6699317.A16 6699317	-
4 - CYLINDER SET TILL C224500 HIT-6685476.A1 6685476	-
4A - CYLINDER SET PN SINCE C224501 HIT-6685477.A3 6685477	-
5 - HEX.HOLE BOLT M5X20/S HIT-6684668.A62 6684668	-
6 - CYLINDER GASKET HIT-6685741.A1 6685741	-
7 - PISTON RING HIT-6686123.A5 6686123	-
8 - PISTON SET TILL C224500 HIT-6685889.A2 6685889	-
8A - PISTON SET SINCE C224501 HIT-6685888.A7 6685888	£34.65	£41.58
9 - PISTON PIN 10X30 HIT-6686007.A9 6686007	£3.52	£4.23
10 - PISTON PIN CIRCLIP HIT-6686032.A3 6686032	£1.67	£2.00
11 - CRANK SHAFT COMP. HIT-6686192.A1 6686192	-
13 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A5 6686457	£1.67	£2.00
14 - IGNITION COIL COMP. HIT-6687655.A12 6687655	£32.83	£39.40
15 - RUBBER CAP HIT-6684602.A42 6684602	-
16 - HIGH TENSION CORD HIT-6687885.A9 6687885	£1.67	£2.00
17 - IGNITION COIL ASS'Y HIT-6687657.A1 6687657	£33.12	£39.74
18 - LEAD WIRE ASS'Y HIT-6687970.A2 6687970	-
19 - SCREW 4X18/WS HIT-6695406.A5 6695406	-
20 - WASHER T1.6 HIT-6684600.A5 6684600	-
21 - CORD CLAMP COMP. HIT-6688011.A29 6688011	-
41 - PROTECTOR HIT-6688348.A3 6688348	-
42 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A1 6684634	£1.67	£2.00
43 - CRANK CASE ASS'Y HIT-6686559.A3 6686559	-
45 - CRANK CASE GASKET HIT-6686715.A1 6686715	-
46 - OIL SEAL UD15257 HIT-6695637.A22 6695637	£3.66	£4.39
47 - BALL BEARING #6202 2 HIT-6695557.A28 6695557	-
*48 - CRANK SHAFT SHIM 0.10 HIT-6686470.A4 6686470	-
*48 - CRANK SHAFT SHIM 0.20 HIT-6686472.A20 6686472	£1.67	£2.00
*48 - CRANK SHAFT SHIM 0.30 HIT-6686473.A11 6686473	£1.67	£2.00
49 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A9 6684786	£1.67	£2.00
50 - MAGNETO ROTOR COMP. HIT-6687372.A5 6687372	-
51 - WASHER 10 HIT-6695198.A23 6695198	-
52 - NUT 10 HIT-6695138.A16 6695138	-
53 - FAN CASE HIT-6686982.A1 6686982	-
54 - HEX.HOLE BOLT M5X20/S HIT-6684668.A63 6684668	-
55 - PRIMARY CORD GROMMET HIT-6688057.A24 6688057	-
56 - WASHER M5 (BLACK) HIT-6685226.A23 6685226	-
57 - SMALL NUT 10 HIT-6695139.A15 6695139	-
81 - INLET MANIFOLD GASKET HIT-6689885.A9 6689885	£2.81	£3.37
82 - CARB.INSULATOR SET 1 HIT-6689955.A9 6689955	£16.19	£19.43
83 - CARBURETOR GASKET HIT-6689833.A5 6689833	£1.67	£2.00
85 - COLLAR HIT-6690802.A9 6690802	£2.81	£3.37
86 - CLEANER BODY COMP. HIT-6690099.A9 6690099	£13.72	£16.47
87 - CHOKE VALVE HIT-6691258.A1 6691258	£3.62	£4.35
88 - BLOW OVER CHECK BOARD HIT-6690843.A3 6690843	£1.67	£2.00
89A - CLEANER ELEMENT 6T HIT-6690352.A4 6690352	£1.67	£2.00
90 - WAVE WASHER 8 HIT-6684658.A37 6684658	£1.67	£2.00
91 - CLEANER COVER ASS'Y HIT-6690397.A2 6690397	£6.61	£7.93
92 - SPECIAL SCREW HIT-6689737.A9 6689737	-
93 - SCREW M5X60 HIT-6684660.A17 6684660	-
94 - S.WASHER 5 HIT-6684662.A63 6684662	£1.67	£2.00
95 - CARBURETOR SET 1 HIT-6690476.A4 6690476	-
97 - HEX. HOLE BOLT 5X25WS HIT-6695425.A5 6695425	-
98 - TANK FIXING COLLAR HIT-6692182.A2 6692182	-
99 - FUEL PIPE ASS'Y 3X5X230 FOR CRC HIT-6688166.A16 6688166	£5.17	£6.20
99A - SHIELD TUBE ASS'Y FOR USA HIT-6697939.A2 6697939	-
100A - CLIP D6 HIT-6685198.A45 6685198	-
101B - PUMP FILTER BODY COMP SINCE TL060521 HIT-66A3864.A58 66A3864	-
102 - TANK WHT TILL D217600 FOR USA HIT-6691539.A5 6691539	-
102A - TANK F T SINCE D217601 FOR USA HIT-6699337.A0 6699337	-
103 - COLLAR C HIT-6684623.A26 6684623	£1.67	£2.00
109 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A0 6684634	£1.67	£2.00
110 - ENGINE BED HIT-6694785.A8 6694785	-
111 - FUEL PIPE 3X5X85 HIT-6684880.A36 6684880	-
113 - FUEL PIPE GROMMET HIT-6688156.A19 6688156	-
114 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A10 6684786	£1.67	£2.00
115 - WASHER M5 (BLACK) HIT-6684918.A63 6684918	£1.67	£2.00
118 - PUMP FILTER ASS'Y TILL TL060520 HIT-6601175.A3 6601175	-
119A - TANK CAP D ASS'Y 1 HIT-6691715.A4 6691715	£8.55	£10.26
122 - AIR VENT VALVE ASS'Y HIT-6692171.A19 6692171	-
123 - AIR VENT PIPE HIT-6697800.A6 6697800	-
124 - AIR VENT ASS'Y HIT-6691389.A13 6691389	£16.64	£19.97
125 - TANK WHT FOR CRC HIT-6691539.A4 6691539	-
131 - MUFFLER PROTECTOR HIT-6692783.A3 6692783	-
132 - HEX.HOLE BOLT M5X12/S HIT-6684667.A13 6684667	£1.67	£2.00
134 - HEX. HOLE BOLT M6X65 HIT-6695067.A4 6695067	£1.67	£2.00
135 - BOLT WASHER 6 HIT-6684639.A25 6684639	£1.67	£2.00
*136 - MUFFLER SET 1 HIT-6692472.A0 6692472	-
*136 - MUFFLER SET 1 HIT-6692473.A3 6692473	-
137 - WASHER M5 (BLACK) HIT-6684918.A64 6684918	£1.67	£2.00
138 - TAIL PIPE HIT-6692652.A3 6692652	-
139 - MACHINE SCREW (W/SP. WASHER) M4X8 HIT-6685109.A22 6685109	-
140 - MUFFLER ARRESTOR HIT-6692696.A1 6692696	-
141 - MUFFLER GASKET HIT-6692741.A1 6692741	£3.89	£4.67
142 - HEAT SHIELD HIT-6687246.A1 6687246	-
144A - GROMMET HIT-6688050.A8 6688050	£1.67	£2.00
145 - HEX. HOLE BOLT M5X25/S HIT-6684709.A170 6684709	£1.67	£2.00
146 - WASHER M5 (BLACK) HIT-6684918.A66 6684918	£1.67	£2.00
147 - CLUTCH WASHER B HIT-6689645.A17 6689645	£1.67	£2.00
148 - CLUTCH ARM COMP. HIT-6688614.A9 6688614	£9.58	£11.50
149 - CLUTCH SPRING HIT-6689428.A1 6689428	£2.98	£3.57
150 - WAVE WASHER 10 HIT-6695203.A5 6695203	£1.67	£2.00
151 - CLUTCH STEP BOLT HIT-6689632.A2 6689632	£4.26	£5.11
152 - CLUTCH SET ASS'Y HIT-6699556.A0 6699556	-
171A - RECOIL STARTER BODY ASS'Y HIT-6697645.A18 6697645	£28.11	£33.73
172 - RECOIL STARTER BODY COMP. TILL G104480 HIT-6693025.A16 6693025	£14.11	£16.93
172A - RECOIL STARTER BODY COMP SINCE G104481 HIT-6697646.A5 6697646	-
173 - STARTER ROPE REEL TILL G104480 HIT-6693007.A21 6693007	£12.57	£15.08
173A - STARTER ROPE REEL SINCE G104481 HIT-6697647.A18 6697647	-
174 - RECOIL SPRING TILL G104480 HIT-6693114.A6 6693114	£9.02	£10.82
174A - RECOIL SPRING SINCE G104481 HIT-6697648.A5 6697648	-
175 - STARTER ROPE TILL G104480 HIT-6693165.A4 6693165	-
175A - STARTER ROPE SINCE G104481 HIT-6697649.A18 6697649	-
176 - STARTER HANDLE CAP TILL G104480 HIT-6693607.A15 6693607	-
177 - STARTER HANDLE TILL G104480 HIT-6693232.A3 6693232	-
177A - STARTER HANDLE SINCE G104481 HIT-6697650.A5 6697650	-
178 - SET SCREW HIT-6693634.A20 6693634	-
179 - STARTER PAWL TILL G104480 HIT-6693302.A15 6693302	£3.89	£4.67
179A - STARTER PAWL SINCE G104481 HIT-6697643.A18 6697643	-
*180 - D4E RETAINING RING TILL G104480 HIT-6685101.A96 6685101	-
*180 - D4E RETAINING RING SINCE G104481 HIT-6685101.A97 6685101	-
181 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A2 6684634	£1.67	£2.00
182 - STARTER PAWL SPRING TILL G104480 HIT-6693345.A15 6693345	£3.89	£4.67
182A - STARTER PAWL SPRING SINCE G104481 HIT-6697642.A5 6697642	-
183 - STARTER PULLEY TILL G104480 HIT-6693395.A10 6693395	£11.02	£13.22
183A - STARTER PULLEY ASS'Y SINCE G104481 HIT-6697644.A5 6697644	£12.94	£15.53
191 - THROTTLE SET SCREW HIT-6684870.A52 6684870	-
192 - CABLE ADJUSTER STAY HIT-6684873.A26 6684873	-
193 - SWIVEL HIT-6684697.A117 6684697	-
194 - THRUST WASHER HIT-6684874.A53 6684874	-
195 - STOP RING HIT-6684696.A48 6684696	-
196 - CABLE ADJUSTER HIT-6684871.A22 6684871	-
197 - O-RING HIT-6684695.A149 6684695	£1.67	£2.00
198 - MAIN JET 1 HIT-6696131.A3 6696131	-
199 - LOCK NUT M6 HIT-6684872.A57 6684872	-
200 - PUMP GASKET HIT-6691457.A23 6691457	£8.48	£10.18
201 - PUMP DIAPHRAGM HIT-6684693.A43 6684693	£5.70	£6.84
202 - INLET SCREEN HIT-6684700.A58 6684700	-
203 - PUMP BODY COMP. HIT-6684879.A26 6684879	£35.37	£42.44
204 - DIAPHRAGM GASKET HIT-6684691.A10 6684691	£5.70	£6.84
205 - METERING DIAPHRAGM COMP. HIT-6690827.A51 6690827	£14.02	£16.83
206 - DIAPHRAGM COVER HIT-6684688.A83 6684688	£5.70	£6.84
207 - SET SCREW HIT-6684699.A83 6684699	-
208 - CLEANER PACKING HIT-6684875.A27 6684875	-
209 - PRIMING PUMP COMP. HIT-6684687.A17 6684687	£9.27	£11.12
210 - PRIMING BODY HIT-6684689.A16 6684689	£5.87	£7.04
231 - CLUTCH SHAFT COMP. HIT-6688584.A0 6688584	-
232 - BALL BEARING #6202Z 2 HIT-6695559.A26 6695559	£12.76	£15.31
233 - STOP RING C-15 1 HIT-6695285.A4 6695285	£1.67	£2.00
234 - CLUTCH CASE HIT-6689194.A2 6689194	-
236 - CUSHION RUBBER HIT-6691829.A5 6691829	-
238 - HEX. HOLE BOLT 5X16 HIT-6695046.A28 6695046	£1.67	£2.00
239 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A41 6685064	-
240 - HEX HOLE BOLT 5X25 HIT-6695091.A2 6695091	-
242 - PIPE HOLDER HIT-6689655.A0 6689655	-
243 - WASHER M5 (BLACK) HIT-6684918.A65 6684918	£1.67	£2.00
245 - METAL FITTING HIT-6689664.A13 6689664	£6.12	£7.35
261 - DRIVE SHAFT HIT-6689471.A0 6689471	-
262 - MAIN PIPE COMP HIT-6699277.A2 6699277	-
263 - BUSHING ASS'Y HIT-6699278.A3 6699278	-
264 - LIFTING METAL 1 HIT-6689274.A1 6689274	-
265 - LIFTING METAL COLLAR 26 TILL J034870 FOR USA HIT-6689258.A1 6689258	-
266 - HEX. HOLE BOLT 5X30.P TILL J034870 FOR USA HIT-6695501.A0 6695501	-
267 - SPECIAL NUT TILL J034870 FOR USA HIT-6689100.A2 6689100	-
268 - HANDLE GRIP HIT-6684708.A5 6684708	£3.56	£4.27
269 - HEX. HOLE BOLT M5X25/S HIT-6684709.A168 6684709	£1.67	£2.00
270 - HANDLE BRACKET A HIT-6684710.A1 6684710	-
271 - HANDLE BRACKET HIT-6691158.A0 6691158	-
272 - HANDLE BRACKET C 1 HIT-6691174.A2 6691174	-
273 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A47 6684714	£1.67	£2.00
274 - HIP PAD HIT-6689291.A12 6689291	-
275 - CLAMP B. HIT-6684715.A7 6684715	-
276 - LEFT HANDLE HIT-6696093.A1 6696093	£17.80	£21.36
277 - PROTECTION TUBE HIT-6687546.A0 6687546	-
278 - RIGHT HANDLE HIT-6691080.A9 6691080	£16.15	£19.38
279 - THROTTLE LEVER ASS'Y 19 HIT-6693766.A4 6693766	£42.70	£51.24
280 - TRIGGER LOCK OUT HIT-6684721.A7 6684721	£5.17	£6.20
281 - RETURN SPRING HIT-6684722.A40 6684722	£1.67	£2.00
282 - THROTTLE LEVER HIT-6684723.A3 6684723	-
283 - BLIND PLUG TILL C308150 HIT-6684724.A28 6684724	-
284 - SCREW M4X20 (BLACK) HIT-6684725.A12 6684725	-
285 - SCREW 5X30 (BLACK) HIT-6684726.A17 6684726	£1.67	£2.00
286 - CONTAL NUT 5 HIT-6684727.A7 6684727	£1.67	£2.00
287 - STOP SWITCH TILL C308150 HIT-6687460.A2 6687460	-
287A - STOP SWITCH SINCE C308151 HIT-6687461.A4 6687461	-
288 - THROTTLE WIRE HIT-6694023.A3 6694023	£15.11	£18.13
289 - THROTTLE WIRE COMP. TILL C308150 HIT-6693979.A3 6693979	-
289A - THROTTLE WIRE COMP. SINCE C308151 HIT-6693980.A3 6693980	£30.92	£37.11
290 - LIFTING METAL ASS'Y SINCE J034871 FOR USA HIT-6689275.A5 6689275	-
291 - LIFTING METAL ASS'Y FOR CRC HIT-6689275.A6 6689275	-
*331 - GEAR CASE ASSY 1 HIT-6688784.A1 6688784	-
*331 - GEAR CASE ASS'Y 1 HIT-6688813.A1 6688813	-
332 - HEX. HOLE BOLT M5X25/S HIT-6684709.A169 6684709	£1.67	£2.00
333 - STOP RING C-24 1 HIT-6684732.A48 6684732	£1.67	£2.00
334 - STOP RING C-9 1 HIT-6695281.A24 6695281	-
335 - BALL BEARING 609Z ST HIT-6684735.A14 6684735	£15.48	£18.57
336 - BALL BEARING 609 HIT-6684734.A22 6684734	-
337 - GEAR CASE 1 HIT-6688685.A1 6688685	-
338 - HEX. HOLE BOLT 5X10 HIT-6695042.A1 6695042	£1.67	£2.00
339 - PLUS HEAD BOLT 8X10 HIT-6695437.A0 6695437	-
340 - BALL BEARING 628 ST HIT-6695569.A0 6695569	-
*341 - GEAR SHAFT FOR USA HIT-6688945.A0 6688945	-
*341 - GEAR SHAFT FOR CRC HIT-6688947.A0 6688947	-
342 - BALL BEARING 6201D 1 HIT-6695554.A30 6695554	-
343 - STOP RING C-32 1 HIT-6695295.A6 6695295	£1.67	£2.00
344 - CUTTER HOLDER. 12X10X1 HIT-6689031.A1 6689031	-
345 - CUTTER HOLDER CAP. 12X10X1 HIT-6689050.A0 6689050	-
346 - PROTECTION COVER B HIT-6688994.A10 6688994	£3.85	£4.62
347 - CUTTER FIXING NUT 1 HIT-6689072.A2 6689072	£6.61	£7.93
348 - GEAR CASE WASHER HIT-6689159.A32 6689159	-
349 - SPECIAL WASHER 1.0 HIT-6686453.A1 6686453	-
350 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A48 6684714	£1.67	£2.00
351 - COVER BRACKET 1 HIT-6690294.A0 6690294	-
351A - COVER BRACKET 26 SINCE F006011 HIT-6690315.A15 6690315	-
352 - BLADE GUARD 26 CE TILL F006010 HIT-6690242.A8 6690242	£18.84	£22.61
352A - BLADE GUARD 26CE SINCE F006011 HIT-6690276.A12 6690276	£20.01	£24.01
353 - GUARD HOLDER HIT-6684748.A14 6684748	-
354 - COVER GUARD TILL F006010 HIT-6690372.A10 6690372	£2.81	£3.37
354A - BLADE GUARD SINCE F006011 HIT-6690376.A14 6690376	£9.34	£11.21
355 - KNIFE TILL F006010 HIT-6693386.A24 6693386	£8.53	£10.24
355A - KNIFE SINCE F006011 HIT-6684750.A24 6684750	£3.64	£4.37
356 - SCREW 5X12/S TILL F006010 HIT-6695334.A28 6695334	£1.67	£2.00
356A - TAPPING SCREW 4X14 SINCE F006011 HIT-6684751.A77 6684751	£1.67	£2.00
357 - GEAR-PINION SET 1 HIT-6688868.A1 6688868	£27.94	£33.53
358 - NUT M5 TILL F006010 HIT-6684965.A56 6684965	£1.67	£2.00
359 - SPLIT PIN SET(10 PCS/PACK) FOR USA HIT-6689168.A0 6689168	-
501 - BOX WRENCH (HEX. SOCKET 17/19) TILL TL010810 HIT-6684764.A4 6684764	£7.64	£9.17
502 - HEX. BAR WRENCH 4MM HIT-6684813.A10 6684813	-
503B - CUTTER COVER SINCE TL010811 HIT-6684768.A56 6684768	-
504A - PROTECTIVE GLASSES FOR CRC HIT-875769.A144 875769	-
505 - SHOULDER HARNESS D3X HIT-6695796.A7 6695796	£25.30	£30.36
506 - BLADE 80 TEETH 255 HIT-6693492.A0 6693492	-
511 - NYLON HEAD BF-5 TILL TL050750 FOR CRC HIT-6695784.A13 6695784	£27.81	£33.37
512 - MOUNTING NUT L-M10X1.25 TILL TL050750 FOR CRC HIT-6684756.A2 6684756	£10.80	£12.96
513 - CUTTING BODY TILL TL050750 FOR CRC HIT-6684757.A14 6684757	£15.38	£18.45
514 - SPECIAL NUT TILL TL050750 FOR CRC HIT-6684758.A2 6684758	£6.18	£7.41
515 - REEL SPRING TILL TL050750 FOR CRC HIT-6684759.A14 6684759	£3.56	£4.27
516 - SPOOL TILL TL050750 FOR CRC HIT-6684760.A2 6684760	£13.48	£16.18
517 - CUTTING BODY CAP TILL TL050750 FOR CRC HIT-6684761.A14 6684761	£21.34	£25.61
518 - EYELET TILL TL050750 FOR CRC HIT-6684762.A2 6684762	£3.56	£4.27
519 - WINDING PROTECTOR TILL TL050750 FOR CRC HIT-6684763.A9 6684763	£2.98	£3.57
521 - NYLON CORD CUTTER SINCE TL050751 FOR CRC HIT-6601148.A9 6601148	£25.68	£30.81
522 - CASE SINCE TL050751 FOR CRC HIT-6601149.A8 6601149	-
523 - NUT SINCE TL050751 FOR CRC HIT-6601150.A9 6601150	-
524 - REEL SPRING SINCE TL050751 FOR CRC HIT-6693380.A12 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL050751 FOR CRC HIT-6601151.A8 6601151	-
526 - COVER SINCE TL050751 FOR CRC HIT-6601152.A9 6601152	-
527 - EYELET SINCE TL050751 FOR CRC HIT-6684810.A24 6684810	£3.29	£3.95
531 - NYLON HEAD TH-97LM FOR USA HIT-6695781.A0 6695781	-
532 - CUTTING BODY ASS'Y FOR USA HIT-6693271.A4 6693271	-
533 - EYELET FOR USA HIT-6693328.A0 6693328	-
534 - ADJUSTMENT BASE FOR USA HIT-6693247.A0 6693247	-
535 - SPRING (SILVER) FOR USA HIT-6693377.A0 6693377	-
536 - ADJUSTMENT WASHER FOR USA HIT-6693362.A0 6693362	-
537 - CORD REEL BK FOR USA HIT-6693292.A0 6693292	-
538 - STEEL BALL FOR USA HIT-6692271.A0 6692271	£1.67	£2.00
539 - REEL SLIDER FOR USA HIT-6693358.A5 6693358	-
540 - CUTTING BODY CAP FOR USA HIT-6693338.A0 6693338	-
541 - MOUNTING NUT. L-M10X1.25 FOR USA HIT-6689098.A0 6689098	-
544 - WINDING PROTECTOR COVER FOR USA HIT-6688986.A6 6688986	-
601 - SYMBOL MARK 1 HIT-6694625.A1 6694625	-
602 - NAME PLATE 1 HIT-6694351.A0 6694351	-
603 - SYMBOL MARK HIT-6694741.A5 6694741	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-430PF Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
