Hitachi / Hikoki TBC-420PF Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-420PF Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG RUBBER COVER HIT-6688336.A11 6688336	£3.56	£4.27
2 - SPARK PLUG CAP ASS'Y HIT-6687479.A1 6687479	-
*3A - SPARK PLUG ASS'Y RCJ8Y FOR EUROPE HIT-6699328.A5 6699328	£5.70	£6.84
*3A - SPARK PLUG ASS'Y BPM6A FOR USA HIT-6699317.A8 6699317	-
4 - CYLINDER SET FOR EUROPE HIT-6685476.A5 6685476	-
5 - HEX.HOLE BOLT M5X20/S HIT-6684668.A9 6684668	-
6 - CYLINDER GASKET HIT-6685741.A4 6685741	-
7 - PISTON RING HIT-6686123.A11 6686123	-
8 - PISTON SET FOR EUROPE HIT-6685889.A5 6685889	-
9 - PISTON PIN 10X30 HIT-6686007.A19 6686007	£3.52	£4.23
10 - PISTON PIN CIRCLIP HIT-6686032.A16 6686032	£1.67	£2.00
11 - CRANK SHAFT COMP. HIT-6686192.A4 6686192	-
13 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A19 6686457	£1.67	£2.00
14 - IGNITION COIL COMP. HIT-6687655.A5 6687655	£32.83	£39.40
15 - RUBBER CAP HIT-6684602.A25 6684602	-
16 - HIGH TENSION CORD HIT-6687885.A2 6687885	£1.67	£2.00
17 - IGNITION COIL ASS'Y HIT-6687657.A8 6687657	£33.12	£39.74
*18 - LEAD WIRE ASS'Y FOR EUROPE HIT-6687970.A8 6687970	-
*18 - STOP CORD 1 HIT-6687924.A2 6687924	-
19 - SCREW 4X18/WS HIT-6695406.A1 6695406	-
20 - WASHER T1.6 HIT-6684600.A42 6684600	-
21 - CORD CLAMP COMP. HIT-6688011.A0 6688011	-
22 - CYLINDER SET TILL C308050 FOR USA HIT-6685476.A6 6685476	-
22A - CYLINDER SET PN SINCE C308051 FOR USA HIT-6685477.A0 6685477	-
23 - PISTON SET TILL C308050 FOR USA HIT-6685889.A6 6685889	-
23A - PISTON SET SINCE C308051 FOR USA HIT-6685888.A4 6685888	£34.65	£41.58
41 - PROTECTOR HIT-6688348.A0 6688348	-
42 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A55 6684634	£1.67	£2.00
45 - SMALL NUT 10 HIT-6695139.A29 6695139	-
48 - CRANK CASE ASS'Y TILL U194486 HIT-6686558.A0 6686558	-
48A - CRANK CASE ASS'Y SINCE U194487 HIT-6686559.A0 6686559	-
49 - CRANK CASE GASKET HIT-6686715.A4 6686715	-
50 - OIL SEAL UD15257 HIT-6695637.A3 6695637	£3.66	£4.39
51 - BALL BEARING #6202 2 HIT-6695557.A0 6695557	-
*52 - CRANK SHAFT SHIM 0.10 HIT-6686470.A10 6686470	-
*52 - CRANK SHAFT SHIM 0.20 HIT-6686472.A9 6686472	£1.67	£2.00
*52 - CRANK SHAFT SHIM 0.30 HIT-6686473.A22 6686473	£1.67	£2.00
53 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A58 6684786	£1.67	£2.00
54 - MAGNETO ROTOR COMP. HIT-6687372.A11 6687372	-
55 - WASHER 10 HIT-6695198.A1 6695198	-
56 - NUT 10 HIT-6695138.A5 6695138	-
59 - FAN CASE HIT-6686982.A4 6686982	-
60 - HEX.HOLE BOLT M5X20/S HIT-6684668.A8 6684668	-
61 - PRIMARY CORD GROMMET HIT-6688057.A12 6688057	-
62 - WASHER M5 (BLACK) HIT-6685226.A6 6685226	-
81 - INLET MANIFOLD GASKET HIT-6689885.A4 6689885	£2.81	£3.37
82 - CARB.INSULATOR SET 1 HIT-6689955.A5 6689955	£16.19	£19.43
83 - CARBURETOR GASKET HIT-6689833.A12 6689833	£1.67	£2.00
85 - COLLAR HIT-6690802.A4 6690802	£2.81	£3.37
86 - CLEANER BODY COMP. HIT-6690099.A1 6690099	£13.72	£16.47
87 - CHOKE VALVE HIT-6691258.A8 6691258	£3.62	£4.35
88 - BLOW OVER CHECK BOARD HIT-6690843.A21 6690843	£1.67	£2.00
89A - CLEANER ELEMENT 6T SINCE Z249601 HIT-6690352.A13 6690352	£1.67	£2.00
90 - WAVE WASHER 8 HIT-6684658.A18 6684658	£1.67	£2.00
91 - CLEANER COVER ASS'Y HIT-6690397.A7 6690397	£6.61	£7.93
92 - SPECIAL SCREW HIT-6689737.A39 6689737	-
93 - SCREW M5X60 HIT-6684660.A5 6684660	-
94 - S.WASHER 5 HIT-6684662.A28 6684662	£1.67	£2.00
95 - CARBURETOR SET TILL B043450 FOR EUROPE HIT-6690477.A2 6690477	-
95A - CARBURETOR SET 1 HIT-6690476.A0 6690476	-
97 - HEX. HOLE BOLT 5X25WS HIT-6695425.A1 6695425	-
98 - TANK FIXING COLLAR HIT-6692182.A4 6692182	-
*99 - FUEL PIPE ASS'Y 3X5X230 FOR EUROPE HIT-6688166.A0 6688166	£5.17	£6.20
*99 - SHIELD TUBE ASS'Y FOR USA HIT-6697939.A0 6697939	-
100A - CLIP D6 HIT-6685198.A22 6685198	-
101B - PUMP FILTER BODY COMP SINCE TL060521 HIT-66A3864.A5 66A3864	-
102 - TANK WHT FOR EUROPE HIT-6691539.A1 6691539	-
103 - COLLAR C HIT-6684623.A6 6684623	£1.67	£2.00
104 - TANK CAP ASS'Y FOR EUROPE HIT-6691714.A2 6691714	£8.44	£10.13
105 - AIR VENT RUBBER CAP FOR EUROPE HIT-6691369.A2 6691369	-
106 - AIR VENT VALVE ASS'Y FOR EUROPE HIT-6692172.A13 6692172	-
107 - AIR VENT PIPE FOR EUROPE HIT-6691394.A2 6691394	-
108 - AIR VENT ASS'Y FOR EUROPE HIT-6691385.A2 6691385	-
109 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A54 6684634	£1.67	£2.00
110 - ENGINE BED HIT-6694785.A1 6694785	-
111 - FUEL PIPE 3X5X85 HIT-6684880.A23 6684880	-
112 - CLIP 5.5 FOR EUROPE HIT-6692305.A1 6692305	-
113 - FUEL PIPE GROMMET HIT-6688156.A7 6688156	-
114 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A57 6684786	£1.67	£2.00
115 - WASHER M5 (BLACK) HIT-6684918.A44 6684918	£1.67	£2.00
117 - TANK CAP CHAIN FOR EUROPE HIT-6684625.A58 6684625	-
118 - PUMP FILTER ASS'Y TILL TL060520 HIT-6601175.A10 6601175	-
119 - CARBURETOR SET 1 HIT-6690476.A1 6690476	-
120 - TANK WHT TILL E043900 FOR USA HIT-6691539.A0 6691539	-
120A - TANK F T SINCE E043901 FOR USA HIT-6699337.A2 6699337	-
121A - TANK CAP D ASS'Y 1 HIT-6691715.A6 6691715	£8.55	£10.26
122 - AIR VENT VALVE ASS'Y FOR USA HIT-6692171.A2 6692171	-
123 - AIR VENT PIPE FOR USA HIT-6697800.A0 6697800	-
124 - AIR VENT ASS'Y FOR USA HIT-6691389.A4 6691389	£16.64	£19.97
131 - MUFFLER PROTECTOR HIT-6692783.A0 6692783	-
132 - HEX.HOLE BOLT M5X12/S HIT-6684667.A99 6684667	£1.67	£2.00
134 - HEX. HOLE BOLT M6X65 HIT-6695067.A26 6695067	£1.67	£2.00
135 - BOLT WASHER 6 HIT-6684639.A133 6684639	£1.67	£2.00
136 - MUFFLER SET 1 HIT-6692472.A3 6692472	-
136A - MUFFLER SET 1 HIT-6692473.A0 6692473	-
137 - WASHER M5 (BLACK) HIT-6684918.A46 6684918	£1.67	£2.00
138 - TAIL PIPE HIT-6692652.A0 6692652	-
139 - MACHINE SCREW (W/SP. WASHER) M4X8 HIT-6685109.A11 6685109	-
140 - MUFFLER ARRESTOR HIT-6692696.A6 6692696	-
141 - MUFFLER GASKET HIT-6692741.A11 6692741	£3.89	£4.67
142 - HEAT SHIELD HIT-6687246.A4 6687246	-
144A - GROMMET HIT-6688050.A23 6688050	£1.67	£2.00
145 - HEX. HOLE BOLT M5X25/S HIT-6684709.A71 6684709	£1.67	£2.00
146 - WASHER M5 (BLACK) HIT-6684918.A45 6684918	£1.67	£2.00
147 - CLUTCH WASHER B HIT-6689645.A36 6689645	£1.67	£2.00
148 - CLUTCH ARM COMP. HIT-6688614.A2 6688614	£9.58	£11.50
149 - CLUTCH SPRING HIT-6689428.A7 6689428	£2.98	£3.57
150 - WAVE WASHER 10 HIT-6695203.A31 6695203	£1.67	£2.00
151 - CLUTCH STEP BOLT HIT-6689632.A7 6689632	£4.26	£5.11
152 - CLUTCH SET ASS'Y HIT-6699556.A11 6699556	-
153 - MUFFLER SET 1 HIT-6692472.A4 6692472	-
171 - RECOIL STARTER BODY ASS'Y HIT-6697645.A3 6697645	£28.11	£33.73
172 - RECOIL STARTER BODY COMP. TILL G104480 HIT-6693025.A9 6693025	£14.11	£16.93
172A - RECOIL STARTER BODY COMP SINCE G104481 HIT-6697646.A20 6697646	-
173 - STARTER ROPE REEL TILL G104480 HIT-6693007.A2 6693007	£12.57	£15.08
173A - STARTER ROPE REEL SINCE G104481 HIT-6697647.A3 6697647	-
174 - RECOIL SPRING TILL G104480 HIT-6693114.A15 6693114	£9.02	£10.82
174A - RECOIL SPRING SINCE G104481 HIT-6697648.A20 6697648	-
175 - STARTER ROPE TILL G104480 HIT-6693165.A14 6693165	-
175A - STARTER ROPE SINCE G104481 HIT-6697649.A3 6697649	-
176 - STARTER HANDLE CAP TILL G104480 HIT-6693607.A9 6693607	-
177 - STARTER HANDLE TILL G104480 HIT-6693232.A16 6693232	-
177A - STARTER HANDLE SINCE G104481 HIT-6697650.A20 6697650	-
178 - SET SCREW HIT-6693634.A11 6693634	-
179 - STARTER PAWL TILL G104480 HIT-6693302.A6 6693302	£3.89	£4.67
179A - STARTER PAWL SINCE G104481 HIT-6697643.A3 6697643	-
180 - D4E RETAINING RING TILL G104480 HIT-6685101.A14 6685101	-
180A - D4E RETAINING RING SINCE G104481 HIT-6685101.A15 6685101	-
181 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A53 6684634	£1.67	£2.00
182 - STARTER PAWL SPRING TILL G104480 HIT-6693345.A0 6693345	£3.89	£4.67
182A - STARTER PAWL SPRING SINCE G104481 HIT-6697642.A20 6697642	-
183 - STARTER PULLEY TILL G104480 HIT-6693395.A16 6693395	£11.02	£13.22
183A - STARTER PULLEY ASS'Y SINCE G104481 HIT-6697644.A20 6697644	£12.94	£15.53
191 - THROTTLE SET SCREW HIT-6684870.A19 6684870	-
192 - CABLE ADJUSTER STAY HIT-6684873.A54 6684873	-
193 - SWIVEL HIT-6684697.A51 6684697	-
194 - THRUST WASHER HIT-6684874.A20 6684874	-
195 - STOP RING HIT-6684696.A138 6684696	-
196 - CABLE ADJUSTER HIT-6684871.A46 6684871	-
197 - O-RING HIT-6684695.A75 6684695	£1.67	£2.00
198 - MAIN JET 1 HIT-6696131.A4 6696131	-
199 - LOCK NUT M6 HIT-6684872.A25 6684872	-
200 - PUMP GASKET HIT-6691457.A46 6691457	£8.48	£10.18
201 - PUMP DIAPHRAGM HIT-6684693.A123 6684693	£5.70	£6.84
202 - INLET SCREEN HIT-6684700.A155 6684700	-
203 - PUMP BODY COMP. HIT-6684879.A44 6684879	£35.37	£42.44
204 - DIAPHRAGM GASKET HIT-6684691.A58 6684691	£5.70	£6.84
205 - METERING DIAPHRAGM COMP. HIT-6690827.A24 6690827	£14.02	£16.83
206 - DIAPHRAGM COVER HIT-6684688.A40 6684688	£5.70	£6.84
207 - SET SCREW HIT-6684699.A38 6684699	-
208 - CLEANER PACKING HIT-6684875.A57 6684875	-
209 - PRIMING PUMP COMP. HIT-6684687.A59 6684687	£9.27	£11.12
210 - PRIMING BODY HIT-6684689.A59 6684689	£5.87	£7.04
231 - CLUTCH SHAFT COMP. HIT-6688584.A2 6688584	-
232 - BALL BEARING #6202Z 2 HIT-6695559.A1 6695559	£12.76	£15.31
233 - STOP RING C-15 1 HIT-6695285.A30 6695285	£1.67	£2.00
234 - CLUTCH CASE HIT-6689194.A5 6689194	-
236 - CUSHION RUBBER HIT-6691829.A2 6691829	-
238A - HEX. HOLE BOLT 5X16 HIT-6695046.A11 6695046	£1.67	£2.00
239 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A2 6685064	-
240 - HEX HOLE BOLT 5X25 HIT-6695091.A3 6695091	-
242A - PIPE HOLDER HIT-6689655.A5 6689655	-
244 - WASHER M5 (BLACK) HIT-6684918.A43 6684918	£1.67	£2.00
245 - METAL FITTING HIT-6689664.A32 6689664	£6.12	£7.35
261 - DRIVE SHAFT HIT-6689471.A2 6689471	-
262 - MAIN PIPE COMP HIT-6699277.A5 6699277	-
263 - BUSHING ASS'Y HIT-6699278.A0 6699278	-
265 - TAPPING SCREW 5X20 HIT-6695255.A28 6695255	-
266 - BRAKE SHAFT WASHER HIT-6689681.A18 6689681	£1.67	£2.00
267 - HANDLE GRIP HIT-6691098.A2 6691098	£10.90	£13.08
268 - BOLT 6X43/P (BLACK) HIT-6684838.A14 6684838	£1.67	£2.00
269 - LOOP HANDLE BLACK HIT-6691049.A6 6691049	-
270 - BARRIER BLACK HIT-6691231.A11 6691231	-
271 - HEX.NUT 6 HIT-6684835.A29 6684835	£1.67	£2.00
272 - THROTTLE LEVER ASS'Y FOR EUROPE HIT-6693760.A1 6693760	-
273 - THROTTLE WIRE COMP. FOR EUROPE HIT-6693973.A1 6693973	-
274 - THROTTLE WIRE FOR EUROPE HIT-6694020.A0 6694020	-
275 - STOP SWITCH COMP. FOR EUROPE HIT-6687456.A0 6687456	-
276 - PROTECTION TUBE 200L FOR EUROPE HIT-6687529.A0 6687529	-
277 - TRIGGER LOCK OUT FOR EUROPE HIT-6684721.A30 6684721	£5.17	£6.20
278 - RETURN SPRING FOR EUROPE HIT-6684722.A18 6684722	£1.67	£2.00
279 - BLIND PLUG FOR EUROPE HIT-6684724.A12 6684724	-
280 - SCREW M5X20 FOR EUROPE HIT-6684803.A3 6684803	-
281 - CONTAL NUT 5 FOR EUROPE HIT-6684727.A30 6684727	£1.67	£2.00
282 - SCREW M4X20 (BLACK) FOR EUROPE HIT-6684725.A31 6684725	-
283 - THROTTLE LEVER FOR EUROPE HIT-6684804.A27 6684804	£6.86	£8.23
291 - NUT M5 HIT-6684965.A0 6684965	£1.67	£2.00
292 - LIFTING METAL HIT-6689264.A1 6689264	-
293 - HEX. HOLE BOLT M5X16/S HIT-6684903.A33 6684903	-
296 - THROTTLE LEVER ASS'Y 26MM FOR USA HIT-6693739.A0 6693739	-
297 - STOP SWITCH FOR USA HIT-6687515.A8 6687515	£1.67	£2.00
298 - TAPPING SCREW 3X8 FOR USA HIT-6695274.A7 6695274	-
299 - STOP SWITCH BASE FOR USA HIT-6688374.A4 6688374	-
300 - STOP SWITCH SPRING FOR USA HIT-6688385.A0 6688385	-
301 - EARTH TERMINAL B FOR USA HIT-6687805.A4 6687805	-
302 - EARTH TERMINAL A FOR USA HIT-6687801.A3 6687801	-
303 - SPECIAL NUT M5 FOR USA HIT-6685000.A3 6685000	-
304 - STOP RING E-6 FOR USA HIT-6695311.A0 6695311	£1.67	£2.00
305 - RETURN SPRING FOR USA HIT-6693601.A1 6693601	-
306 - THROTTLE ARM FOR USA HIT-6693804.A6 6693804	-
307 - SCREW 5X20 FOR USA HIT-6695453.A6 6695453	-
308 - LOCK BUTTON SHAFT FOR USA HIT-6693653.A0 6693653	-
309 - LOCK BUTTON SPRING FOR USA HIT-6694834.A3 6694834	-
310 - LOCK BUTTON FOR USA HIT-6694829.A4 6694829	-
311 - STOP CORD 2 HIT-6687915.A7 6687915	-
313 - SHAFT GRIP FOR USA HIT-6691110.A0 6691110	-
314 - THROTTLE WIRE COMP. FOR USA HIT-6693952.A0 6693952	-
*331 - GEAR CASE ASS'Y 1 HIT-6688813.A2 6688813	-
*331 - GEAR CASE ASSY 1 HIT-6688784.A0 6688784	-
332 - HEX. HOLE BOLT M5X25/S HIT-6684709.A72 6684709	£1.67	£2.00
333 - STOP RING C-24 1 HIT-6684732.A5 6684732	£1.67	£2.00
334 - STOP RING C-9 1 HIT-6695281.A9 6695281	-
335 - BALL BEARING 609Z ST HIT-6684735.A27 6684735	£15.48	£18.57
336 - BALL BEARING 609 HIT-6684734.A7 6684734	-
337 - GEAR CASE 1 HIT-6688685.A0 6688685	-
338 - HEX. HOLE BOLT 5X10 HIT-6695042.A39 6695042	£1.67	£2.00
339 - PLUS HEAD BOLT 8X10 HIT-6695437.A8 6695437	-
340 - BALL BEARING 628 ST HIT-6695569.A4 6695569	-
*341 - GEAR SHAFT FOR EUROPE HIT-6688947.A2 6688947	-
*341 - GEAR SHAFT FOR USA HIT-6688945.A1 6688945	-
342 - BALL BEARING 6201D 1 HIT-6695554.A11 6695554	-
343 - STOP RING C-32 1 HIT-6695295.A68 6695295	£1.67	£2.00
344 - CUTTER HOLDER. 12X10X1 HIT-6689031.A2 6689031	-
345 - CUTTER HOLDER CAP. 12X10X1 HIT-6689050.A2 6689050	-
346 - PROTECTION COVER B TILL TL082740 HIT-6688994.A1 6688994	£3.85	£4.62
347 - CUTTER FIXING NUT 1 HIT-6689072.A7 6689072	£6.61	£7.93
348 - GEAR CASE WASHER HIT-6689159.A23 6689159	-
349 - SPECIAL WASHER 1.0 HIT-6686453.A0 6686453	-
350 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A84 6684714	£1.67	£2.00
*351 - COVER BRACKET 1 HIT-6690294.A10 6690294	-
*351A - COVER BRACKET 26 SINCE D085851 FOR EUROPE HIT-6690315.A23 6690315	-
*352 - BLADE GUARD 26 CE TILL D168500 FOR EUROPE HIT-6690242.A17 6690242	£18.84	£22.61
*352A - BLADE GUARD 26CE SINCE D168501 FOR EUROPE HIT-6690276.A16 6690276	£20.01	£24.01
353 - GUARD HOLDER HIT-6684748.A35 6684748	-
*354 - COVER GUARD TILL D168500 FOR EUROPE HIT-6690372.A20 6690372	£2.81	£3.37
*354A - BLADE GUARD SINCE D168501 FOR EUROPE HIT-6690376.A17 6690376	£9.34	£11.21
*355 - KNIFE TILL D168500 FOR EUROPE HIT-6693386.A3 6693386	£8.53	£10.24
*355A - KNIFE SINCE D168501 FOR EUROPE HIT-6684750.A75 6684750	£3.64	£4.37
*356 - SCREW 5X12/S TILL D168500 FOR EUROPE HIT-6695334.A4 6695334	£1.67	£2.00
*356A - TAPPING SCREW 4X14 SINCE D168501 FOR EUROPE HIT-6684751.A18 6684751	£1.67	£2.00
357 - GEAR-PINION SET 1 HIT-6688868.A2 6688868	£27.94	£33.53
358 - NUT M5 TILL D168500 FOR EUROPE HIT-6684965.A1 6684965	£1.67	£2.00
*359 - TAPPING SCREW 5X20 SINCE D168501 FOR EUROPE HIT-6684753.A14 6684753	£1.67	£2.00
*359 - TAPPING SCREW 5X20 TILL J034870 FOR EUROPE HIT-6684753.A15 6684753	£1.67	£2.00
*360 - KNIFE SINCE D168501 FOR EUROPE HIT-6684754.A62 6684754	£6.64	£7.97
*360 - KNIFE TILL J034870 FOR EUROPE HIT-6684754.A63 6684754	£6.64	£7.97
361 - SPLIT PIN SET(10 PCS/PACK) FOR USA HIT-6689168.A2 6689168	-
501 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A59 6684764	£7.64	£9.17
502 - HEX. BAR WRENCH 4MM HIT-6684813.A54 6684813	-
503 - CUTTER COVER TILL TL016250 FOR EUROPE HIT-6699555.A1 6699555	-
*503B - CUTTER COVER SINCE TL016251 FOR EUROPE HIT-6684768.A22 6684768	-
504 - SAFETY GLASSES FOR EUROPE HIT-6699542.A0 6699542	-
505 - SHOULDER BELT ASS'Y HIT-6692874.A2 6692874	-
506 - BLADE B3/10/2.0 TILL TL082740 FOR EUROPE HIT-6695791.A1 6695791	£20.11	£24.13
507A - NYLON HEAD TH-97LM FOR USA HIT-6695781.A1 6695781	-
508 - CUTTING BODY ASS'Y FOR USA HIT-6693271.A0 6693271	-
509 - EYELET FOR USA HIT-6693328.A3 6693328	-
510 - ADJUSTMENT BASE FOR USA HIT-6693247.A4 6693247	-
511 - SPRING (SILVER) FOR USA HIT-6693377.A2 6693377	-
512 - ADJUSTMENT WASHER FOR USA HIT-6693362.A4 6693362	-
513 - CORD REEL BK FOR USA HIT-6693292.A1 6693292	-
514 - STEEL BALL FOR USA HIT-6692271.A8 6692271	£1.67	£2.00
515 - REEL SLIDER FOR USA HIT-6693358.A1 6693358	-
516 - CUTTING BODY CAP FOR USA HIT-6693338.A4 6693338	-
517 - MOUNTING NUT. L-M10X1.25 FOR USA HIT-6689098.A3 6689098	-
518 - WINDING PROTECTOR COVER FOR USA HIT-6688986.A2 6688986	-
521 - NYLON CORD CUTTER SINCE TL082741 FOR EUROPE HIT-6601148.A4 6601148	£25.68	£30.81
522 - CASE SINCE TL082741 FOR EUROPE HIT-6601149.A13 6601149	-
523 - NUT SINCE TL082741 FOR EUROPE HIT-6601150.A4 6601150	-
524 - REEL SPRING SINCE TL082741 FOR EUROPE HIT-6693380.A8 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL082741 FOR EUROPE HIT-6601151.A13 6601151	-
526 - COVER SINCE TL082741 FOR EUROPE HIT-6601152.A4 6601152	-
527 - EYELET SINCE TL082741 FOR EUROPE HIT-6684810.A21 6684810	£3.29	£3.95
601 - NAME PLATE 1 HIT-6694350.A0 6694350	-
602 - SYMBOL MARK 1 HIT-6694625.A0 6694625	-
603 - SYMBOL MARK HIT-6694741.A3 6694741	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-420PF Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TBC-420PF Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TBC-420PF Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
