Hitachi / Hikoki TBC-4200DX Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-4200DX Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A75 6687468	£3.64	£4.37
*2 - SPARK PLUG ASS'Y BPMR6A FOR EUROPE HIT-6699319.A4 6699319	-
*2 - SPARK PLUG ASS'Y BPM6A FOR SOUTH AMERICA HIT-6699317.A1 6699317	-
3 - CYLINDER SET HIT-6685474.A1 6685474	£106.65	£127.98
4 - HEX.HOLE BOLT M5X20/S HIT-6684668.A26 6684668	-
5 - CYLINDER GASKET HIT-6685740.A2 6685740	£2.81	£3.37
6 - PISTON RING HIT-6686123.A7 6686123	-
7 - PISTON SET HIT-6685888.A2 6685888	£34.65	£41.58
8 - PISTON PIN 10X30 HIT-6686007.A26 6686007	£3.52	£4.23
9 - PISTON PIN CIRCLIP HIT-6686032.A14 6686032	£1.67	£2.00
10 - CRANK SHAFT COMP. HIT-6686191.A2 6686191	£121.17	£145.40
11 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A31 6686457	£1.67	£2.00
12 - IGNITION COIL COMP. HIT-6687655.A1 6687655	£32.83	£39.40
13 - RUBBER CAP HIT-6684602.A2 6684602	-
14 - HIGH TENSION CORD HIT-6687885.A6 6687885	£1.67	£2.00
15 - LEAD WIRE ASS'Y HIT-6687970.A6 6687970	-
16 - IGNITION COIL ASS'Y HIT-6687657.A12 6687657	£33.12	£39.74
17 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A12 6684599	-
18 - CORD CLAMP COMP. HIT-6688011.A15 6688011	-
31 - SMALL NUT 10 HIT-6695139.A33 6695139	-
32 - CRANK CASE ASS'Y HIT-6686556.A2 6686556	-
33 - NO LONGER AVAILABLE HIT-6686714.A4 6686714	-
34 - OIL SEAL UD15257 HIT-6695637.A15 6695637	£3.66	£4.39
35 - BALL BEARING #6202 2 HIT-6695557.A13 6695557	-
*36 - CRANK SHAFT SHIM 0.20 HIT-6686472.A5 6686472	£1.67	£2.00
*36 - CRANK SHAFT SHIM 0.30 HIT-6686473.A26 6686473	£1.67	£2.00
37 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A77 6684786	£1.67	£2.00
38 - MAGNETO ROTOR COMP. HIT-6687372.A9 6687372	-
39 - WASHER 10 HIT-6695198.A10 6695198	-
40 - NUT 10 HIT-6695138.A4 6695138	-
41 - SPARK PLUG COVER HIT-6688346.A7 6688346	£5.01	£6.01
42 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A77 6684634	£1.67	£2.00
43 - FAN CASE HIT-6686982.A6 6686982	-
44 - HEX.HOLE BOLT M5X20/S HIT-6684668.A25 6684668	-
45 - PRIMARY CORD GROMMET HIT-6688057.A3 6688057	-
46 - WASHER M5 (BLACK) SINCE K075001 HIT-6685226.A11 6685226	-
61 - INLET MANIFOLD GASKET HIT-6689885.A2 6689885	£2.81	£3.37
62 - CARB.INSULATOR SET 1 HIT-6689955.A2 6689955	£16.19	£19.43
63 - CARBURETOR GASKET HIT-6689833.A8 6689833	£1.67	£2.00
65 - COLLAR HIT-6690802.A1 6690802	£2.81	£3.37
66 - CLEANER BODY COMP. HIT-6690099.A5 6690099	£13.72	£16.47
67 - CHOKE VALVE HIT-6691258.A12 6691258	£3.62	£4.35
68 - BLOW OVER CHECK BOARD HIT-6690843.A35 6690843	£1.67	£2.00
69A - CLEANER ELEMENT 6T HIT-6690352.A7 6690352	£1.67	£2.00
70 - WAVE WASHER 8 HIT-6684658.A8 6684658	£1.67	£2.00
71 - CLEANER COVER ASS'Y HIT-6690397.A12 6690397	£6.61	£7.93
72 - SPECIAL SCREW HIT-6689737.A30 6689737	-
73 - SCREW 5X57/S HIT-6695353.A32 6695353	£1.67	£2.00
*74 - CARBURETOR SET WYJ389 FOR EUROPE HIT-6690474.A3 6690474	£91.62	£109.95
*74 - CARBURETOR SET WYJ168 FOR SOUTH AMERICA HIT-6690470.A7 6690470	£67.33	£80.80
75 - HEX. HOLE BOLT M5X25WS HIT-6695515.A5 6695515	£1.67	£2.00
76 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A10 6688166	£5.17	£6.20
77A - CLIP D6 HIT-6685198.A6 6685198	-
78B - PUMP FILTER BODY COMP SINCE TL044161 HIT-66A3864.A35 66A3864	-
79 - TANK HIT-6691533.A7 6691533	£13.82	£16.59
80 - COLLAR C HIT-6684623.A2 6684623	£1.67	£2.00
81 - TANK CAP D ASS'Y 1 HIT-6691763.A30 6691763	£13.46	£16.15
82 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A76 6684634	£1.67	£2.00
83 - FUEL PIPE 3X5X85 HIT-6684880.A12 6684880	-
84 - FUEL PIPE GROMMET HIT-6688156.A1 6688156	-
85 - TANK CAP CHAIN HIT-6684625.A83 6684625	-
86 - ENGINE BED HIT-6694785.A3 6694785	-
87 - WASHER M5 (BLACK) HIT-6684918.A17 6684918	£1.67	£2.00
88 - HEX. HOLE BOLT 5X22/S HIT-6695492.A40 6695492	-
90 - PUMP FILTER ASS'Y TILL TL044160 HIT-6601175.A8 6601175	-
101 - MUFFLER PROTECTOR HIT-6692780.A7 6692780	-
102 - WASHER M5 (BLACK) HIT-6684918.A18 6684918	£1.67	£2.00
103 - HEX.HOLE BOLT M5X12/S HIT-6684667.A76 6684667	£1.67	£2.00
104 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A2 6695512	-
105 - HEX. HOLE BOLT M6X65 HIT-6695067.A40 6695067	£1.67	£2.00
106 - BOLT WASHER 6 HIT-6684639.A194 6684639	£1.67	£2.00
*107 - MUFFLER SET P/N FOR EUROPE HIT-6692468.A3 6692468	-
*107 - MUFFLER SET FOR AUS HIT-6698164.A0 6698164	-
108 - MUFFLER GASKET HIT-6692741.A18 6692741	£3.89	£4.67
109 - HEAT SHIELD HIT-6687243.A4 6687243	-
113 - CLUTCH WASHER B HIT-6689645.A52 6689645	£1.67	£2.00
114 - CLUTCH ARM COMP. HIT-6688614.A5 6688614	£9.58	£11.50
115 - CLUTCH SPRING HIT-6689428.A11 6689428	£2.98	£3.57
116 - WAVE WASHER 10 HIT-6695203.A19 6695203	£1.67	£2.00
117 - CLUTCH STEP BOLT HIT-6689632.A11 6689632	£4.26	£5.11
118 - CLUTCH SET ASS'Y HIT-6699556.A8 6699556	-
119 - MUFFLER SPECIAL GASKET FOR AUS HIT-6692883.A5 6692883	-
120 - TAIL PIPE SET FOR AUS HIT-6692649.A4 6692649	-
121 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR AUS HIT-6685109.A4 6685109	-
131A - RECOIL STARTER BODY ASS'Y HIT-6697645.A11 6697645	£28.11	£33.73
132 - RECOIL STARTER BODY COMP. TILL H001950 HIT-6693025.A4 6693025	£14.11	£16.93
132A - RECOIL STARTER BODY COMP SINCE H001951 HIT-6697646.A12 6697646	-
133 - STARTER ROPE REEL TILL H001950 HIT-6693007.A11 6693007	£12.57	£15.08
133A - STARTER ROPE REEL SINCE H001951 HIT-6697647.A11 6697647	-
134 - RECOIL SPRING TILL H001950 HIT-6693114.A21 6693114	£9.02	£10.82
134A - RECOIL SPRING SINCE H001951 HIT-6697648.A12 6697648	-
135 - STARTER ROPE TILL H001950 HIT-6693165.A21 6693165	-
135A - STARTER ROPE SINCE H001951 HIT-6697649.A4 6697649	-
136 - STARTER HANDLE CAP TILL H001950 HIT-6693607.A11 6693607	-
137 - STARTER HANDLE TILL H001950 HIT-6693232.A14 6693232	-
137A - STARTER HANDLE SINCE H001951 HIT-6697650.A19 6697650	-
138 - SET SCREW HIT-6693634.A9 6693634	-
139 - STARTER PAWL TILL H001950 HIT-6693302.A5 6693302	£3.89	£4.67
139A - STARTER PAWL SINCE H001951 HIT-6697643.A4 6697643	-
*140 - D4E RETAINING RING TILL H001950 HIT-6685101.A9 6685101	-
*140 - D4E RETAINING RING SINCE H001951 HIT-6685101.A10 6685101	-
141 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A52 6684634	£1.67	£2.00
142 - STARTER PAWL SPRING TILL H001950 HIT-6693345.A2 6693345	£3.89	£4.67
142A - STARTER PAWL SPRING SINCE H001951 HIT-6697642.A19 6697642	-
143 - STARTER PULLEY TILL H001950 HIT-6693395.A14 6693395	£11.02	£13.22
143A - STARTER PULLEY ASS'Y SINCE H001951 HIT-6697644.A19 6697644	£12.94	£15.53
161 - PUMP BODY COMP. HIT-6684879.A51 6684879	£35.37	£42.44
162 - PRIMING PUMP COMP. HIT-6684687.A65 6684687	£9.27	£11.12
163 - DIAPHRAGM COVER HIT-6684688.A34 6684688	£5.70	£6.84
164 - PRIMING BODY HIT-6684689.A65 6684689	£5.87	£7.04
165 - METERING DIAPHRAGM COMP. HIT-6690827.A27 6690827	£14.02	£16.83
166 - DIAPHRAGM GASKET HIT-6684691.A60 6684691	£5.70	£6.84
167 - PUMP DIAPHRAGM HIT-6684693.A129 6684693	£5.70	£6.84
168 - PUMP GASKET HIT-6691457.A53 6691457	£8.48	£10.18
169 - MAIN JET #51 HIT-6696382.A4 6696382	-
170 - O-RING HIT-6684695.A70 6684695	£1.67	£2.00
171 - STOP RING HIT-6684696.A143 6684696	-
172 - SWIVEL HIT-6684697.A46 6684697	-
174 - THROTTLE SET SCREW HIT-6684870.A23 6684870	-
175 - CABLE ADJUSTER STAY HIT-6684873.A50 6684873	-
176 - LOCK NUT M6 HIT-6684872.A29 6684872	-
177 - CABLE ADJUSTER HIT-6684871.A42 6684871	-
178 - CLEANER PACKING HIT-6684875.A53 6684875	-
179 - SET SCREW HIT-6684699.A35 6684699	-
180 - THRUST WASHER HIT-6684874.A24 6684874	-
181 - INLET SCREEN HIT-6684700.A158 6684700	-
201 - CLUTCH SHAFT COMP. HIT-6688607.A0 6688607	£27.26	£32.71
202 - STOP RING C-32 1 HIT-6695295.A63 6695295	£1.67	£2.00
203 - BALL BEARING #6002ZZ 1 HIT-6695537.A1 6695537	£13.81	£16.57
204 - WASHER HIT-6689185.A1 6689185	-
205 - STOP RING C-15 1 HIT-6695285.A32 6695285	£1.67	£2.00
206 - STOP RING C-45 1 HIT-6695305.A3 6695305	-
207 - CLUCH CASE HIT-6689229.A0 6689229	-
208 - CUSHION RUBBER HIT-6691905.A1 6691905	-
209 - PIPE HOLDER HIT-6689663.A0 6689663	-
210 - HEX. HOLE BOLT 5X10 HIT-6695042.A40 6695042	£1.67	£2.00
213 - HEX.HOLE BOLT 6X30/S HIT-6695499.A11 6695499	-
231 - DRIVE SHAFT 1542L HIT-6689474.A2 6689474	£32.24	£38.69
232 - DRIVE SHAFT PIPE COMP.1500L HIT-6689404.A3 6689404	£41.72	£50.07
233 - BUSH ASS'Y HIT-6689524.A0 6689524	-
234 - HANGER HIT-6689278.A0 6689278	-
235 - LIFTING METAL ASS'Y HIT-6689279.A5 6689279	£12.10	£14.52
236 - HANGER FIXING BRACKET HIT-6689293.A1 6689293	-
237 - HEX. HOLE BOLT M5X25WS HIT-6695515.A22 6695515	£1.67	£2.00
238 - HANDLE GRIP HIT-6684708.A13 6684708	£3.56	£4.27
239 - HANDLE KNOB COMP. FOR EUROPE HIT-6691208.A2 6691208	£4.89	£5.87
*240 - MOUNTING WASHER 1.0 FOR EUROPE HIT-6692955.A0 6692955	£1.67	£2.00
241 - HANDLE BRACKET A FOR EUROPE HIT-6691144.A4 6691144	£13.82	£16.59
242 - HANDLE BRACKET B FOR EUROPE HIT-6691150.A3 6691150	£12.10	£14.52
243 - CUSHION RUBBER FOR EUROPE HIT-6691190.A1 6691190	-
244 - HANDLE BRACKET C FOR EUROPE HIT-6691175.A5 6691175	£5.17	£6.20
*245 - HANDLE BRACKET B FOR EUROPE HIT-6691160.A1 6691160	£7.75	£9.30
246 - HEX. HOLE BOLT M5X25WS HIT-6695515.A23 6695515	£1.67	£2.00
247 - HIP PAD HIT-6689291.A0 6689291	-
248 - CORD CLAMP HIT-6688024.A3 6688024	-
*249 - HANDLE LEFT ASS'Y FOR EUROPE HIT-6691089.A0 6691089	£20.01	£24.01
*249 - HANDLE LEFT ASS'Y FOR SOUTH AMERICA HIT-6699554.A1 6699554	-
*250 - RIGHT HANDLE FOR EUROPE HIT-6691080.A1 6691080	£16.15	£19.38
*250 - HANDLE(R) FOR SOUTH AMERICA HIT-6699560.A1 6699560	-
251 - THROTTLE LEVER ASS'Y 19 HIT-6693766.A5 6693766	£42.70	£51.24
252 - TRIGGER LOCK OUT HIT-6684721.A31 6684721	£5.17	£6.20
253 - RETURN SPRING HIT-6684722.A17 6684722	£1.67	£2.00
254 - THROTTLE LEVER HIT-6684723.A12 6684723	-
255 - BLIND PLUG TILL C294400 HIT-6684724.A11 6684724	-
256 - SCREW M4X20 (BLACK) HIT-6684725.A32 6684725	-
257 - SCREW 5X30 (BLACK) HIT-6684726.A8 6684726	£1.67	£2.00
258 - CONTAL NUT 5 HIT-6684727.A29 6684727	£1.67	£2.00
259 - STOP SWITCH TILL C294400 HIT-6687460.A4 6687460	-
259A - STOP SWITCH SINCE C294401 HIT-6687461.A2 6687461	-
260 - THROTTLE WIRE HIT-6694023.A6 6694023	£15.11	£18.13
261 - THROTTLE WIRE COMP. TILL C294400 HIT-6693979.A1 6693979	-
261A - THROTTLE WIRE COMP. SINCE C294401 HIT-6693980.A7 6693980	£30.92	£37.11
262 - HANDLE KNOB COMP. TILL K023240 FOR SOUTH AMERICA HIT-6691208.A3 6691208	£4.89	£5.87
262A - HEX. HOLE BOLT M5X25/S SINCE K023241 FOR SOUTH AMERICA HIT-6684709.A70 6684709	£1.67	£2.00
263 - HANDLE BRACKET A TILL K023240 FOR SOUTH AMERICA HIT-6691144.A5 6691144	£13.82	£16.59
263A - HANDLE BRACKET A SINCE K023241 FOR SOUTH AMERICA HIT-6691145.A0 6691145	-
264 - HANDLE BRACKET B TILL K023240 FOR SOUTH AMERICA HIT-6691150.A2 6691150	£12.10	£14.52
264A - HANDLE BRACKET B SINCE K023241 FOR SOUTH AMERICA HIT-6691163.A1 6691163	-
265 - CUSHION RUBBER TILL K023240 FOR SOUTH AMERICA HIT-6691190.A0 6691190	-
265A - HANDLE BRACKET 1.0T SINCE K023241 FOR SOUTH AMERICA HIT-6691189.A3 6691189	-
266 - HANDLE BRACKET C TILL K023240 FOR SOUTH AMERICA HIT-6691175.A4 6691175	£5.17	£6.20
266A - HANDLE BRACKET C SINCE K023241 FOR SOUTH AMERICA HIT-6691177.A0 6691177	-
267 - HEX. HOLE BOLT M5X25WS TILL K023240 FOR SOUTH AMERICA HIT-6695515.A25 6695515	£1.67	£2.00
267A - HEX.HOLE BOLT M5X30/WS SINCE K023241 FOR SOUTH AMERICA HIT-6684973.A10 6684973	-
268 - PROTECTION TUBE HIT-6687546.A5 6687546	-
301A - GEAR CASE 28 DIA HIT-6601268.A1 6601268	£225.52	£270.62
302 - HEX.HOLE BOLT 6X25S HIT-6695497.A1 6695497	-
303 - STOP RING C-28 1 HIT-6684741.A19 6684741	-
304 - STOP RING C-12 OUTER HIT-6684664.A22 6684664	-
305 - BALL BEARING #6001Z 1 HIT-6695532.A16 6695532	£15.01	£18.01
306 - BALL BEARING 6001 C3 HIT-6684608.A144 6684608	£5.70	£6.84
307 - GEAR CASE HIT-6688798.A1 6688798	-
308 - HEX HOLE BOLT 5X12 HIT-6695510.A1 6695510	-
309 - BOLT 6X8 HIT-6694979.A1 6694979	£1.67	£2.00
310 - BALL BEARING 6001 C3 HIT-6684608.A143 6684608	£5.70	£6.84
311 - GEAR SHAFT L-M10X1.25 TILL 9.2015 HIT-6688943.A0 6688943	£18.87	£22.64
311A - GEAR SHAFT L-M12X1.75 SINCE 10.2015 HIT-6601269.A2 6601269	-
312 - BALL BEARING #6202DD 1 HIT-6696297.A4 6696297	£14.26	£17.11
313 - STOP RING C-35 1 HIT-6695296.A1 6695296	-
314 - CUTTER HOLDER HIT-6689029.A1 6689029	£18.87	£22.64
315 - CUTTER HOLDER CAP HIT-6689051.A1 6689051	£8.67	£10.41
316 - PROTECTION COVER B TILL 9.2015 HIT-6688995.A16 6688995	£4.81	£5.77
316A - NUT COVER SINCE 10.2015 HIT-6601271.A2 6601271	-
317 - SCREW 5X16/WS HIT-6695418.A7 6695418	-
318 - FIXING NUT M10X1.25 TILL 9.2015 HIT-6689073.A8 6689073	£8.32	£9.99
318A - U-NUT L-M12X1.75 SINCE 10.2015 HIT-6601270.A1 6601270	£20.47	£24.56
319 - GEAR CASE COVER COMP HIT-6697604.A3 6697604	£8.28	£9.94
320 - HEX HOLE SCREW 6X30 FOR EUROPE HIT-6695082.A10 6695082	£1.67	£2.00
321 - COVER BRACKET FOR EUROPE HIT-6690313.A3 6690313	£3.10	£3.72
322 - GUARD FOR EUROPE HIT-6690265.A3 6690265	£16.77	£20.12
323 - GUARD HOLDER FOR EUROPE HIT-6690342.A3 6690342	£4.32	£5.19
*324 - COVER GUARD FOR EUROPE HIT-6690374.A2 6690374	£14.26	£17.11
*325 - KNIFE FOR EUROPE HIT-6693386.A5 6693386	£8.53	£10.24
*326 - TAPPING SCREW 5X20 FOR EUROPE HIT-6684753.A17 6684753	£1.67	£2.00
*327 - HEX. HOLE BOLT 5X10 FOR EUROPE HIT-6695042.A38 6695042	£1.67	£2.00
328 - GEAR PINION SET 1 HIT-6688879.A3 6688879	£19.28	£23.14
329 - HEX HOLE SCREW 6X30 FOR SOUTH AMERICA HIT-6695082.A9 6695082	£1.67	£2.00
330 - S.WASHER 6 TILL K023240 FOR SOUTH AMERICA HIT-6684826.A13 6684826	£1.67	£2.00
331 - COVER BRACKET TILL K023240 FOR SOUTH AMERICA HIT-6690311.A1 6690311	-
331A - COVER BRACKET SINCE K023241 FOR SOUTH AMERICA HIT-6690313.A2 6690313	£3.10	£3.72
332 - GUARD TILL K023240 FOR SOUTH AMERICA HIT-6690266.A1 6690266	£12.48	£14.97
332A - GUARD SINCE K023241 FOR SOUTH AMERICA HIT-6690265.A4 6690265	£16.77	£20.12
333 - GUARD HOLDER TILL K023240 FOR SOUTH AMERICA HIT-6690345.A5 6690345	-
333A - GUARD HOLDER SINCE K023241 FOR SOUTH AMERICA HIT-6690342.A2 6690342	£4.32	£5.19
501 - HEX. BAR WRENCH 4MM HIT-6684813.A55 6684813	-
502 - COMBI 1 HIT-6693575.A1 6693575	-
503 - CUTTER COVER TILL TL011020 FOR SOUTH AMERICA HIT-6692016.A10 6692016	-
503B - CUTTER COVER SINCE TL011021 FOR SOUTH AMERICA HIT-6684768.A20 6684768	-
504 - WRENCH 8X10 HIT-6684766.A13 6684766	-
505A - PROTECTIVE GLASSES HIT-875769.A75 875769	-
506 - BLADE B4/10/1.6 FOR SOUTH AMERICA HIT-6695790.A3 6695790	£17.08	£20.49
507 - SHOULDER HARNESS D3X HIT-6695796.A24 6695796	£25.30	£30.36
508 - BLADE B3/12/3.0 FOR EUROPE HIT-6695792.A4 6695792	£18.81	£22.57
509 - CUTTER COVER FOR EUROPE HIT-6692016.A9 6692016	-
601 - NAME PLATE TBC-4200DX HIT-6696384.A0 6696384	-
602 - SYMBOL MARK TBC-4200DX HIT-6696385.A0 6696385	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-4200DX Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TBC-4200DX Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TBC-4200DX Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
