Hitachi / Hikoki TBC-340PFD Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-340PFD Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A72 6687468	£3.64	£4.37
*2 - SPARK PLUG ASS'Y BPMR7A FOR EUROPE HIT-6699320.A29 6699320	-
*2 - SPARK PLUG ASS'Y CJ6Y FOR USA HIT-6699323.A6 6699323	-
3 - CYLINDER SET HIT-6685491.A3 6685491	-
4 - HEX. HOLE BOLT M5X16/S HIT-6684903.A3 6684903	-
5 - CYLINDER GASKET HIT-6685749.A1 6685749	-
6 - PISTON RING (XR1-1856) HIT-6685331.A14 6685331	£12.57	£15.08
7 - PISTON SET HIT-6685898.A1 6685898	£37.49	£44.99
8 - CIRCLIP HIT-6685078.A10 6685078	-
9 - PISTON PIN HIT-6686008.A3 6686008	£3.64	£4.37
10 - CRANK SHAFT COMP HIT-6696499.A0 6696499	-
11 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A53 6684899	-
14 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A14 6684599	-
15 - WASHER T1.6 HIT-6684600.A64 6684600	-
16 - IGNITION COIL ASS'Y HIT-6699773.A0 6699773	-
17 - HIGH TENSION CORD 180L HIT-6687889.A2 6687889	-
18 - RUBBER CAP HIT-6684602.A3 6684602	-
19 - LEAD WIRE ASS'Y HIT-6697836.A5 6697836	-
*31 - GEAR SHAFT SHIM 0.10 HIT-6689177.A20 6689177	-
*31 - GEAR SHAFT SHIM 0.15 HIT-6689178.A15 6689178	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A79 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A2 6684605	-
32 - MAGNETO ROTOR COMP. HIT-6687375.A7 6687375	-
33 - HEX. NUT M8 HIT-6684612.A11 6684612	-
34 - SMALL WASHER 8 HIT-6695184.A0 6695184	-
35 - CRANK CASE ASS'Y TILL J001000 HIT-6686586.A0 6686586	-
35A - CRANK CASE ASS'Y SINCE J001001 HIT-6699279.A3 6699279	-
36 - OIL SEAL TB 12227 HIT-6684607.A5 6684607	£4.07	£4.88
37 - BALL BEARING 6001 C3 HIT-6684608.A190 6684608	£5.70	£6.84
38 - CRANK CASE GASKET TILL J001000 HIT-6686723.A3 6686723	-
38A - CRANK CASE GASKET SINCE J001001 HIT-6699280.A1 6699280	-
39 - HEX. HOLE BOLT M5X16/S TILL J001000 HIT-6684903.A1 6684903	-
39A - HEX. HOLE BOLT M5X16/S SINCE J001001 HIT-6684903.A2 6684903	-
40 - BOLT WASHER M8 HIT-6684611.A104 6684611	-
61 - INLET MANIFOLD GASKET HIT-6689895.A9 6689895	£1.67	£2.00
62 - INSULATOR SET HIT-6689972.A9 6689972	£6.59	£7.91
63 - HEX. HOLE BOLT M5X25WS HIT-6695515.A4 6695515	£1.67	£2.00
65 - CARBURETOR PACKING HIT-6684616.A5 6684616	£1.67	£2.00
66 - CHOKE PLATE 2.0 HIT-6691276.A6 6691276	£1.67	£2.00
67 - CLEANER BODY COMP. HIT-6690120.A21 6690120	£12.32	£14.78
68 - CLEANER SPONGE HIT-6690365.A30 6690365	£1.67	£2.00
69 - CLEANER COVER ASS'Y HIT-6690402.A0 6690402	£12.16	£14.59
70 - COVER FIXING BOLT COMP. HIT-6698730.A41 6698730	£5.52	£6.63
71 - SCREW 5X57/S HIT-6695353.A30 6695353	£1.67	£2.00
72 - SMALL WASHER 5 HIT-6684864.A43 6684864	-
73 - CARBURETOR SET WYJ318 HIT-6690465.A0 6690465	-
74 - CHOKE CONTROL LEVER HIT-6691239.A20 6691239	£2.98	£3.57
75 - TANK F T HIT-6699336.A0 6699336	£31.02	£37.23
76 - COLLAR C HIT-6684623.A0 6684623	£1.67	£2.00
77 - RETURN GROMMET HIT-6697846.A58 6697846	£2.08	£2.50
78 - FUEL PIPE 3X5X85 HIT-6684880.A11 6684880	-
79A - PUMP FILTER BODY COMP HIT-66A3864.A33 66A3864	-
80 - CLIP D6 HIT-6685198.A4 6685198	-
*81 - SHIELD TUBE 3X5X180 FOR EUROPE HIT-6684618.A1 6684618	£6.12	£7.35
*81 - SHIELD TUBE SET FOR USA HIT-6698970.A1 6698970	-
82 - HEX HOLE BOLT 5X30S HIT-6695494.A1 6695494	-
83 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A72 6684634	£1.67	£2.00
84 - TANK CAP ASS'Y FOR EUROPE HIT-6685049.A30 6685049	£9.94	£11.93
85 - TAP SCREW 4X14 P HIT-6695280.A52 6695280	£1.67	£2.00
86 - BOLT WASHER M4 HIT-6685070.A14 6685070	£1.67	£2.00
87 - WASHER M5 (BLACK) HIT-6684918.A11 6684918	£1.67	£2.00
88 - TANK FIXING COLLAR HIT-6692183.A0 6692183	-
89 - S.WASHER 5 TILL J034790 HIT-6684662.A12 6684662	£1.67	£2.00
90 - TANK CAP CHAIN FOR EUROPE HIT-6684625.A85 6684625	-
91 - TANK CAP D ASS'Y FOR USA HIT-6691748.A13 6691748	£6.04	£7.25
92 - ENGINE BED HIT-6694786.A1 6694786	-
101 - CYLINDER COVER BLK HIT-6685689.A0 6685689	-
102 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A1 6695504	£1.67	£2.00
103 - HEX. HOLE BOLT M6X65 HIT-6695067.A38 6695067	£1.67	£2.00
104 - BOLT WASHER 6 HIT-6684639.A195 6684639	£1.67	£2.00
*105 - MUFFLER COMP FOR EUROPE HIT-6699282.A4 6699282	-
*105 - MUFFLER COMP. FOR USA HIT-6692576.A0 6692576	£58.68	£70.42
106 - TAIL PIPE SET HIT-6692715.A7 6692715	-
107 - SCREW M4X8/WS HIT-6684651.A0 6684651	-
108 - SPARK ARRESTER HIT-6692701.A0 6692701	-
109 - TAIL PIPE GASKET HIT-6692888.A8 6692888	-
110 - MUFFLER PROTECTOR BLK HIT-6692811.A0 6692811	-
111 - SCREW 4X18/PS HIT-6695375.A10 6695375	-
112 - PLUG COVER HIT-6688351.A0 6688351	-
113 - CLUTCH WASHER B HIT-6689645.A54 6689645	£1.67	£2.00
114 - CLUTCH ARM COMP. HIT-6688610.A7 6688610	£13.94	£16.73
115 - CLUTCH SPRING HIT-6689420.A1 6689420	£2.81	£3.37
116 - CLUTCH STEP BOLT HIT-6689628.A2 6689628	£3.29	£3.95
117 - WAVE WASHER 10 HIT-6695203.A21 6695203	£1.67	£2.00
118 - CLUTCH SET ASS'Y HIT-6688482.A0 6688482	-
119 - TAPPING SCREW D4.5X14 HIT-6685153.A14 6685153	-
120 - STOP RING C-12 OUTER HIT-6684664.A12 6684664	-
121 - FAN CASE COMP. HIT-6687019.A2 6687019	-
123 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A26 6684647	£1.67	£2.00
124 - ANTI-VIBE RUBBER HIT-6691838.A8 6691838	-
125 - TAPPING SCREW D5X14 HIT-6685275.A32 6685275	-
126 - PIPE HOLDER HIT-6689656.A2 6689656	-
127 - HEX. HOLE BOLT M5X25/S HIT-6684709.A24 6684709	£1.67	£2.00
*128 - SCREW 4X12/WS FOR EUROPE HIT-6695402.A1 6695402	-
*128 - HEX. HOLE BOLT 4X12WS FOR USA HIT-6695507.A18 6695507	-
129 - CLUTCH SHAFT COMP. 78 HIT-6688598.A4 6688598	£20.11	£24.13
130 - STOP RING R-32 INNER HIT-6695304.A2 6695304	-
131 - BEARING CASE HIT-6686667.A0 6686667	-
132 - BALL BEARING #6201ZZ 1 HIT-6695553.A8 6695553	-
133 - PRIMARY CORD GROMMET HIT-6688057.A1 6688057	-
134 - HEAT SHIELD HIT-6687263.A5 6687263	-
141 - RECOIL STARTER ASS'Y HIT-6692969.A2 6692969	£25.30	£30.36
142 - STARTER HANDLE HIT-6693227.A0 6693227	-
143 - ROPE GUIDE HIT-6693135.A5 6693135	-
144 - RECOIL STARTER BODY HIT-6693036.A2 6693036	-
145 - RECOIL SPRING HIT-6693111.A0 6693111	£15.16	£18.19
146 - ROPE 3.5X890 HIT-6693157.A0 6693157	-
147 - STARTER ROPE REEL HIT-6693057.A0 6693057	£8.18	£9.81
148 - ROPE REEL WASHER HIT-6693419.A0 6693419	-
149 - SET SCREW HIT-6693632.A0 6693632	-
150 - SCREW 4X18/PS HIT-6695375.A9 6695375	-
151 - STARTER PULLEY ASS'Y HIT-6693394.A0 6693394	£9.42	£11.30
152 - STARTER PAWL HIT-6693299.A8 6693299	£3.29	£3.95
153 - STARTER PAWL SPRING HIT-6693345.A14 6693345	£3.89	£4.67
171 - PUMP BODY COMP. HIT-6684879.A63 6684879	£35.37	£42.44
172 - PRIMING PUMP COMP. HIT-6684687.A88 6684687	£9.27	£11.12
173 - DIAPHRAGM COVER HIT-6684688.A11 6684688	£5.70	£6.84
174 - PRIMING BODY HIT-6684689.A90 6684689	£5.87	£7.04
175 - METERING DIAPHRAGM COMP. HIT-6690830.A52 6690830	£14.58	£17.50
176 - DIAPHRAGM GASKET HIT-6684691.A85 6684691	£5.70	£6.84
177 - PUMP DIAPHRAGM HIT-6684693.A176 6684693	£5.70	£6.84
178 - PUMP GASKET HIT-6691457.A79 6691457	£8.48	£10.18
179 - MAIN JET #38.5 HIT-6696130.A0 6696130	-
180 - O-RING HIT-6684695.A28 6684695	£1.67	£2.00
181 - STOP RING HIT-6684696.A189 6684696	-
182 - SWIVEL HIT-6684697.A22 6684697	-
183 - THROTTLE SET SCREW HIT-6684870.A6 6684870	-
184 - CABLE ADJUSTER STAY HIT-6684873.A67 6684873	-
185 - LOCK NUT M6 HIT-6684872.A8 6684872	-
186 - CABLE ADJUSTER HIT-6684871.A58 6684871	-
187 - CLEANER PACKING HIT-6684875.A69 6684875	-
188 - SET SCREW HIT-6684699.A10 6684699	-
189 - THRUST WASHER HIT-6684874.A6 6684874	-
190 - INLET SCREEN HIT-6684700.A222 6684700	-
201 - DRIVE SHAFT 1533L HIT-6689478.A2 6689478	£28.76	£34.51
202 - DRAIVE SHAFT PIPE COMP. HIT-6689407.A2 6689407	£53.33	£64.00
203 - BUSHING ASS'Y HIT-6697866.A0 6697866	-
204 - HANDLE GRIP HIT-6684708.A18 6684708	£3.56	£4.27
205 - HEX. HOLE BOLT M5X25/S HIT-6684709.A23 6684709	£1.67	£2.00
206 - HANDLE BRACKET A HIT-6684710.A10 6684710	-
*207 - HANDLE BRACKET B FOR EU HIT-6684711.A0 6684711	£17.88	£21.45
*207 - HANDLE BRACKET FOR USA HIT-6691158.A1 6691158	-
208 - CUSHION RUBBER HIT-6691187.A1 6691187	-
*209 - HANDLE BRACKET C FOR EU HIT-6684713.A1 6684713	£8.22	£9.87
*209 - HANDLE BRACKET C 1 HIT-6691174.A0 6691174	-
210 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A115 6684714	£1.67	£2.00
211 - HIP PAD HIT-6689291.A3 6689291	-
212 - CLAMP B. HIT-6684715.A2 6684715	-
213 - LEFT HANDLE HIT-6696093.A7 6696093	£17.80	£21.36
214 - RIGHT HANDLE HIT-6691080.A3 6691080	£16.15	£19.38
215 - THROTTLE LEVER ASS'Y 19 HIT-6693766.A8 6693766	£42.70	£51.24
216 - PROTECTION TUBE HIT-6687546.A7 6687546	-
217 - TRIGGER LOCK OUT HIT-6684721.A40 6684721	£5.17	£6.20
218 - RETURN SPRING HIT-6684722.A9 6684722	£1.67	£2.00
219 - THROTTLE LEVER HIT-6684723.A15 6684723	-
220 - BLIND PLUG TILL C207450 HIT-6684724.A6 6684724	-
221 - SCREW M4X20 (BLACK) HIT-6684725.A40 6684725	-
222 - SCREW 5X30 (BLACK) HIT-6684726.A5 6684726	£1.67	£2.00
223 - CONTAL NUT 5 HIT-6684727.A40 6684727	£1.67	£2.00
224 - STOP SWITCH TILL C270450 HIT-6687460.A5 6687460	-
224A - STOP SWITCH SINCE C270451 HIT-6687461.A0 6687461	-
225 - THROTTLE WIRE HIT-6694023.A7 6694023	£15.11	£18.13
226 - THROTTLE WIRE COMP. TILL C270450 HIT-6693979.A2 6693979	-
226A - THROTTLE WIRE COMP. SINCE C270451 HIT-6693980.A5 6693980	£30.92	£37.11
227A - LIFTING METAL ASS'Y HIT-6689275.A4 6689275	-
*241 - GEAR CASE SET PN FOR EUROPE HIT-6696497.A19 6696497	£60.35	£72.42
*241 - GEAR CASE ASS'Y 1 HIT-6688771.A0 6688771	£73.77	£88.52
242 - HEX. HOLE BOLT M5X25/S HIT-6684709.A27 6684709	£1.67	£2.00
245 - RETAINING RING C-TYPE D26 HIT-6695294.A20 6695294	-
246 - STOP RING OUTER 10 HIT-6695315.A22 6695315	-
247 - BALL BEARING #6000Z 1 HIT-6695526.A22 6695526	-
248 - BALL BEARING #6000 1 HIT-6695524.A37 6695524	-
249 - GEAR CASE 26 DIA HIT-6688770.A19 6688770	-
250 - HEX.HOLE BOLT M5X12/S HIT-6684667.A74 6684667	£1.67	£2.00
251 - OILING BOLT HIT-6689109.A38 6689109	-
252 - BALL BEARING 609 HIT-6684734.A12 6684734	-
*253 - GEAR SHAFT FOR EUROPE HIT-6688924.A27 6688924	-
*253 - GEAR SHAFT FOR USA HIT-6688946.A1 6688946	-
254 - BALL BEARING 6201D 1 HIT-6695554.A1 6695554	-
255 - STOP RING C-32 1 HIT-6695295.A32 6695295	£1.67	£2.00
256 - CUTTER HOLDER HIT-6689032.A11 6689032	£15.16	£18.19
257 - CUTTER HOLDER CAP HIT-6689055.A22 6689055	£12.10	£14.52
258 - FIXING NUT M10X1.25 HIT-6689073.A6 6689073	£8.32	£9.99
259 - GEAR CASE WASHER HIT-6689159.A5 6689159	-
260 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A116 6684714	£1.67	£2.00
261 - COVER BRACKET 26 HIT-6690315.A20 6690315	-
262 - BLADE GUARD 26 CE TILL F004700 HIT-6690242.A20 6690242	£18.84	£22.61
262A - BLADE GUARD 26CE SINCE F004701 HIT-6690276.A17 6690276	£20.01	£24.01
263 - GUARD HOLDER HIT-6684748.A24 6684748	-
264 - COVER GUARD TILL F004700 HIT-6690372.A25 6690372	£2.81	£3.37
264A - BLADE GUARD SINCE F004701 HIT-6690376.A29 6690376	£9.34	£11.21
265 - KNIFE TILL F004700 HIT-6693386.A14 6693386	£8.53	£10.24
265A - KNIFE SINCE F004701 HIT-6684750.A47 6684750	£3.64	£4.37
266 - SCREW 5X12/S TILL F004700 HIT-6695334.A14 6695334	£1.67	£2.00
266A - TAPPING SCREW 4X14 HIT-6684751.A52 6684751	£1.67	£2.00
267 - NUT M5 TILL F004700 HIT-6684965.A23 6684965	£1.67	£2.00
268 - GEAR/PINION SET 1 HIT-6688875.A22 6688875	-
269 - SPLIT PIN SET(10 PCS/PACK) FOR USA HIT-6689168.A3 6689168	-
501 - HEX. BAR WRENCH 4MM HIT-6684813.A77 6684813	-
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A81 6684764	£7.64	£9.17
503B - CUTTER COVER HIT-6684768.A6 6684768	-
504A - PROTECTIVE GLASSES FOR EUROPE HIT-875769.A32 875769	-
505 - HEX. WRENCH 3 SINCE C072251 FOR USA HIT-6693520.A2 6693520	-
506 - PROTECTION COVER B HIT-6688995.A10 6688995	£4.81	£5.77
507 - SHOULDER HARNESS D3X HIT-6695796.A15 6695796	£25.30	£30.36
508 - BLADE B3/10/2.0 FOR EUROPE HIT-6695791.A0 6695791	£20.11	£24.13
509 - BLADE 80 TEETH 230 FOR USA HIT-6693493.A0 6693493	-
510 - NYLON HEAD BF-5 TILL TL041840 FOR USA HIT-6695784.A1 6695784	£27.81	£33.37
511 - MOUNTING NUT L-M10X1.25 TILL TL041840 FOR USA HIT-6684756.A13 6684756	£10.80	£12.96
512 - MOUNTING NUT L-M8X1.25 TILL TL041840 FOR USA HIT-6689624.A6 6689624	-
513 - CUTTING BODY TILL TL041840 FOR USA HIT-6684757.A1 6684757	£15.38	£18.45
514 - SPECIAL NUT TILL TL041840 FOR USA HIT-6684758.A15 6684758	£6.18	£7.41
515 - REEL SPRING TILL TL041840 FOR USA HIT-6684759.A1 6684759	£3.56	£4.27
516 - SPOOL TILL TL041840 FOR USA HIT-6684760.A15 6684760	£13.48	£16.18
517 - CUTTING BODY CAP TILL TL041840 FOR USA HIT-6684761.A1 6684761	£21.34	£25.61
518 - EYELET TILL TL041840 FOR USA HIT-6684762.A15 6684762	£3.56	£4.27
519 - SURE TAP MANUAL P/L 9 TILL TL041840 FOR USA HIT-6697805.A7 6697805	-
521 - NYLON CORD CUTTER SINCE TL041841 FOR USA HIT-6601148.A16 6601148	£25.68	£30.81
522 - CASE SINCE TL041841 FOR USA HIT-6601149.A1 6601149	-
523 - NUT SINCE TL041841 FOR USA HIT-6601150.A16 6601150	-
524 - REEL SPRING SINCE TL041841 FOR USA HIT-6693380.A21 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL041841 FOR USA HIT-6601151.A1 6601151	-
526 - COVER SINCE TL041841 FOR USA HIT-6601152.A16 6601152	-
527 - EYELET SINCE TL041841 FOR USA HIT-6684810.A10 6684810	£3.29	£3.95
528 - BOLT WASHER M12 TILL TL041840 FOR USA HIT-6685072.A5 6685072	-
601 - NAME PLATE PURE FIRE FOR USA HIT-6694117.A0 6694117	-
602 - NAME PLATE TBC-340PFD FOR USA HIT-6694362.A0 6694362	-
603 - SYMBOL MARK FOR USA HIT-6694741.A8 6694741	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-340PFD Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TBC-340PFD Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TBC-340PFD Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
