Hitachi / Hikoki TBC-340DS Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-340DS Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG ASS'Y RCJ6Y HIT-6699326.A11 6699326	£5.70	£6.84
2 - CYLINDER SET HIT-6685487.A1 6685487	£43.64	£52.37
3 - HEX. HOLE BOLT M5X16/S HIT-6684903.A52 6684903	-
4 - CYLINDER GASKET HIT-6685746.A0 6685746	£2.86	£3.43
5 - PISTON RING (XR1-1856) HIT-6685331.A20 6685331	£12.57	£15.08
6 - PISTON SET HIT-6685898.A5 6685898	£37.49	£44.99
7 - PISTON PIN HIT-6686008.A22 6686008	£3.64	£4.37
8 - CIRCLIP HIT-6685078.A24 6685078	-
9 - CRANK SHAFT COMP HIT-6696499.A8 6696499	-
10 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A37 6684899	-
11 - HIGH TENSION SCREW 4X18WS HIT-6695407.A27 6695407	-
12 - INSULATOR TUBE 1 HIT-6688319.A0 6688319	£1.67	£2.00
14A - IGNITION COIL ASS'Y HIT-6699772.A13 6699772	-
15 - HIGH TENSION CORD 140L HIT-6687888.A24 6687888	£3.89	£4.67
16 - RUBBER CAP HIT-6684602.A29 6684602	-
17 - LEAD WIRE ASS'Y HIT-6697836.A11 6697836	-
18 - WASHER T1.6 HIT-6684600.A37 6684600	-
31 - CRANK CASE ASS'Y HIT-6686580.A8 6686580	-
32 - OIL SEAL TB 12227 HIT-6684607.A169 6684607	£4.07	£4.88
33 - BALL BEARING 6001 C3 HIT-6684608.A35 6684608	£5.70	£6.84
34 - CRANK CASE GASKET HIT-6686721.A8 6686721	£1.67	£2.00
*35 - GEAR SHAFT SHIM 0.10 HIT-6689177.A0 6689177	-
*35 - GEAR SHAFT SHIM 0.15 HIT-6689178.A35 6689178	-
*35 - GEAR SHAFT SHIM 0.20 HIT-6684604.A33 6684604	-
*35 - GEAR SHAFT SHIM 0.30 HIT-6684605.A48 6684605	-
36 - MAGNETO ROTOR COMP. HIT-6687375.A1 6687375	-
37 - HEX. NUT M8 HIT-6684612.A74 6684612	-
38 - SMALL WASHER 8 HIT-6695184.A10 6695184	-
39 - HEX. HOLE BOLT M5X16/S HIT-6684903.A51 6684903	-
40 - CLUTCH WASHER B HIT-6689645.A4 6689645	£1.67	£2.00
51 - INLET MANIFOLD GASKET HIT-6689864.A2 6689864	£1.67	£2.00
52 - CARBURETOR INSULATOR SET 1 HIT-6689924.A2 6689924	-
53 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A14 6695514	-
54 - CARBURETOR PACKING HIT-6684616.A34 6684616	£1.67	£2.00
55A - CARBURETOR SET WYJ296 HIT-6690503.A0 6690503	-
56 - CHOKE PLATE 1.0 HIT-6691278.A6 6691278	£1.67	£2.00
57 - CLEANER BODY COMP. HIT-6690120.A5 6690120	£12.32	£14.78
58 - CLEANER SPONGE HIT-6690365.A10 6690365	£1.67	£2.00
59 - CLEANER COVER ASS'Y HIT-6690421.A11 6690421	£14.48	£17.38
60 - COVER FIXING BOLT COMP. HIT-6698730.A24 6698730	£5.52	£6.63
61 - SCREW 5X57/S HIT-6695353.A3 6695353	£1.67	£2.00
62 - SMALL WASHER 5 HIT-6684864.A135 6684864	-
63 - CHOKE CONTROL LEVER HIT-6691239.A11 6691239	£2.98	£3.57
64 - TANK COMP. WHT HIT-6691588.A2 6691588	£11.68	£14.02
65 - COLLAR C HIT-6684623.A13 6684623	£1.67	£2.00
66 - FUEL PIPE GROMMET HIT-6688156.A14 6688156	-
67 - FUEL PIPE 3X5X85 HIT-6684880.A48 6684880	-
68A - PUMP FILTER BODY COMP HIT-66A3864.A80 66A3864	-
69 - CLIP D6 HIT-6685198.A75 6685198	-
70 - FUEL PIPE ASS'Y HIT-6688169.A2 6688169	£4.32	£5.19
71 - HEX. HOLE BOLT 5X20PS HIT-6695506.A5 6695506	-
72 - TANK CAP ASS'Y HIT-6685049.A2 6685049	£9.94	£11.93
73 - TANK CAP CHAIN HIT-6684625.A41 6684625	-
74 - STAND HIT-6694793.A0 6694793	-
75 - TAP SCREW 4X14 P HIT-6695280.A17 6695280	£1.67	£2.00
76 - BOLT WASHER M4 HIT-6685070.A28 6685070	£1.67	£2.00
91 - CLUTCH ARM COMP. HIT-6688610.A0 6688610	£13.94	£16.73
92 - CLUTCH SPRING HIT-6689420.A5 6689420	£2.81	£3.37
93 - CLUTCH WASHER B HIT-6689645.A3 6689645	£1.67	£2.00
94 - WAVE WASHER 10 HIT-6695203.A14 6695203	£1.67	£2.00
95 - CLUTCH STEP BOLT HIT-6689628.A9 6689628	£3.29	£3.95
96 - CLUTCH SET ASS'Y HIT-6688482.A7 6688482	-
97 - FAN CASE COMP. HIT-6687019.A4 6687019	-
98 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A36 6695512	-
99 - ANTI-VIBE RUBBER HIT-6691838.A4 6691838	-
100 - TAPPING SCREW D5X14 HIT-6685275.A38 6685275	-
101 - PIPE HOLDER HIT-6689656.A8 6689656	-
102 - STOP RING C-12 OUTER HIT-6684664.A40 6684664	£1.67	£2.00
103 - HEX. HOLE BOLT M5X25/S HIT-6684709.A102 6684709	£1.67	£2.00
104 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A31 6684595	£1.67	£2.00
105 - CLUTCH SHAFT COMP. 78 HIT-6688598.A1 6688598	£20.11	£24.13
106 - STOP RING R-32 INNER HIT-6695304.A8 6695304	-
107 - BEARING CASE HIT-6686667.A6 6686667	-
108 - BALL BEARING #6201ZZ 1 HIT-6695553.A5 6695553	-
109 - PRIMARY CORD GROMMET HIT-6688057.A32 6688057	-
110 - MUFFLER PROTECTOR HIT-6692803.A7 6692803	£13.79	£16.55
111 - SPARK PLUG CAP ASS'Y HIT-6687468.A8 6687468	£3.64	£4.37
112 - TAPPING SCREW D4.5X12 HIT-6684637.A10 6684637	£1.67	£2.00
113 - MUFFLER GASKET HIT-6692732.A14 6692732	£1.67	£2.00
114 - HEAT SHIELD HIT-6687260.A10 6687260	£5.77	£6.92
115 - MUFFLER SET HIT-6692489.A5 6692489	-
116 - HEX. HOLE BOLT M6X55 HIT-6684638.A15 6684638	£1.67	£2.00
117 - BOLT WASHER 6 HIT-6684639.A111 6684639	£1.67	£2.00
118 - MUFFLER SPECIAL GASKET HIT-6692887.A8 6692887	-
*119 - TAIL PIPE SET FOR EUROPE HIT-6692669.A6 6692669	-
*119 - TAIL PIPE SET FOR AUS HIT-6692712.A3 6692712	-
*120 - SCREW 4X8/S FOR EUROPE HIT-6695325.A19 6695325	-
*120 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR AUS HIT-6685109.A29 6685109	-
121 - SPARK ARRESTOR FOR AUS HIT-6692699.A6 6692699	-
151 - RECOIL STARTER ASS'Y TILL F024130 REPIACED PART HIT-6692992.A3 6692992	£50.78	£60.93
151A - RECOIL STARTER BODY ASS'Y SINCE F024131 HIT-6692991.A2 6692991	£33.01	£39.61
152 - STARTER HANDLE TILL F024130 HIT-6693240.A7 6693240	£16.35	£19.62
153 - RECOIL STARTER BODY COMP TILL F024130 HIT-6693038.A1 6693038	-
154 - ROPE TILL F024130 HIT-6693168.A28 6693168	£2.82	£3.39
155 - RECOIL SPRING TILL F024130 HIT-6693138.A14 6693138	£12.10	£14.52
156 - SPRING CASE ASS'Y TILL F024130 ORIGINAL PART HIT-6693101.A7 6693101	-
158 - STARTER PULLEY TILL F024130 HIT-6693075.A2 6693075	£6.86	£8.23
159 - SPECIAL WASHER 5.2X15 TILL F024130 HIT-6687947.A21 6687947	-
160 - TAPPING SCREW D5X14 TILL F024130 HIT-6685275.A39 6685275	-
161 - HEX. NUT M8 TILL F024130 HIT-6684612.A75 6684612	-
162 - STARTER BASE TILL F024130 HIT-6693468.A0 6693468	-
163 - TAPPING SCREW D4.5X14 TILL F024130 HIT-6685153.A0 6685153	-
164 - HEX. HOLE BOLT 4X18WS TILL F024130 HIT-6695508.A42 6695508	£1.67	£2.00
165 - STARTER PULLEY ASS'Y TILL F024130 HIT-6693408.A16 6693408	£35.37	£42.44
167 - SPRING PLATE TILL F024130 REPIACED PART HIT-6693252.A2 6693252	-
168 - SPRING CASE ASS'Y TILL F024130 REPIACED PART HIT-6693099.A2 6693099	-
169 - STARTER BUSH TILL F024130 REPIACED PART HIT-6689170.A4 6689170	-
170 - STARTER HANDLE SINCE F024131 HIT-6684680.A42 6684680	£5.87	£7.04
171 - RECOIL STARTER BODY COMP. SINCE F024131 HIT-6693040.A2 6693040	£11.14	£13.37
172 - STARTER ROPE 3.5X860 SINCE F024131 HIT-6684674.A68 6684674	£5.70	£6.84
173 - RECOIL SPRING SINCE F024131 HIT-6684675.A42 6684675	£8.82	£10.58
174 - STARTER PULLEY SINCE F024131 HIT-6693081.A5 6693081	-
175 - DAMPER SPRING SINCE F024131 HIT-6684677.A86 6684677	£5.70	£6.84
176 - CAM PLATE SINCE F024131 HIT-6692938.A2 6692938	£5.64	£6.77
177 - SET SCREW SINCE F024131 HIT-6684679.A107 6684679	£2.98	£3.57
178 - HEX. HOLE BOLT 4X20 PS SINCE F024131 HIT-6695503.A4 6695503	-
179 - STARTER PULLEY ASS'Y SINCE F024131 HIT-6684681.A76 6684681	£18.16	£21.79
180 - STARTER PAWL SINCE F024131 HIT-6684685.A79 6684685	£5.07	£6.08
181 - STARTER PAWL SPRING SINCE F024131 HIT-6684684.A32 6684684	£3.29	£3.95
182 - D4E RETAINING RING SINCE F024131 HIT-6685101.A122 6685101	-
191 - PUMP BODY COMP. HIT-6684879.A14 6684879	£35.37	£42.44
192 - PRIMING PUMP COMP. HIT-6684687.A25 6684687	£9.27	£11.12
193 - DIAPHRAGM COVER HIT-6684688.A75 6684688	£5.70	£6.84
194 - PRIMING BODY HIT-6684689.A24 6684689	£5.87	£7.04
195 - METERING DIAPHRAGM COMP. HIT-6690830.A0 6690830	£14.58	£17.50
196 - DIAPHRAGM GASKET HIT-6684691.A23 6684691	£5.70	£6.84
197 - PUMP DIAPHRAGM HIT-6684693.A60 6684693	£5.70	£6.84
198 - PUMP GASKET HIT-6691457.A8 6691457	£8.48	£10.18
199 - MAIN JET #43 HIT-6691848.A18 6691848	£8.77	£10.52
200 - O-RING HIT-6684695.A134 6684695	£1.67	£2.00
201 - STOP RING HIT-6684696.A63 6684696	-
202 - SWIVEL HIT-6684697.A109 6684697	-
203 - THROTTLE SET SCREW HIT-6684870.A71 6684870	-
204 - CABLE ADJUSTER STAY HIT-6684873.A7 6684873	-
205 - LOCK NUT M6 HIT-6684872.A78 6684872	-
206 - CABLE ADJUSTER HIT-6684871.A6 6684871	-
207 - CLEANER PACKING HIT-6684875.A9 6684875	-
208 - SET SCREW HIT-6684699.A76 6684699	-
209 - THRUST WASHER HIT-6684874.A70 6684874	-
210 - INLET SCREEN HIT-6684700.A69 6684700	-
231 - DRIVE SHAFT 1533L HIT-6689478.A7 6689478	£28.76	£34.51
232 - DRAIVE SHAFT PIPE COMP. HIT-6689407.A3 6689407	£53.33	£64.00
233 - BUSHING ASS'Y HIT-6697866.A8 6697866	-
238 - HANDLE GRIP HIT-6684708.A11 6684708	£3.56	£4.27
239 - HEX. HOLE BOLT M5X25/S HIT-6684709.A100 6684709	£1.67	£2.00
240 - HANDLE BRACKET A HIT-6684710.A6 6684710	-
241 - HANDLE BRACKET B HIT-6684711.A4 6684711	£17.88	£21.45
242 - CUSHION RUBBER HIT-6691187.A4 6691187	-
243 - HANDLE BRACKET C HIT-6684713.A8 6684713	£8.22	£9.87
244 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A0 6684714	£1.67	£2.00
245 - HIP PAD HIT-6689291.A11 6689291	-
246 - CLAMP B. HIT-6684715.A15 6684715	-
247 - LEFT HANDLE HIT-6696093.A3 6696093	£17.80	£21.36
248 - RIGHT HANDLE HIT-6691080.A11 6691080	£16.15	£19.38
249 - THROTTLE LEVER ASS'Y 19 HIT-6693766.A2 6693766	£42.70	£51.24
250 - TRIGGER LOCK OUT HIT-6684721.A16 6684721	£5.17	£6.20
251 - RETURN SPRING HIT-6684722.A32 6684722	£1.67	£2.00
252 - THROTTLE LEVER HIT-6684723.A7 6684723	-
253 - BLIND PLUG TILL C294000 HIT-6684724.A22 6684724	-
254 - SCREW M4X20 (BLACK) HIT-6684725.A21 6684725	-
255 - SCREW 5X30 (BLACK) HIT-6684726.A13 6684726	£1.67	£2.00
256 - CONTAL NUT 5 HIT-6684727.A15 6684727	£1.67	£2.00
257 - STOP SWITCH TILL C294000 HIT-6687460.A1 6687460	-
257A - STOP SWITCH SINCE C294001 HIT-6687461.A6 6687461	-
258 - THROTTLE WIRE HIT-6694023.A2 6694023	£15.11	£18.13
259 - PROTECTION TUBE HIT-6687546.A2 6687546	-
260 - THROTTLE WIRE COMP. TILL C294000 HIT-6693979.A5 6693979	-
260A - THROTTLE WIRE COMP. SINCE C294001 HIT-6693980.A0 6693980	£30.92	£37.11
261 - LIFTING METAL ASS'Y HIT-6689275.A14 6689275	-
281 - GEAR CASE SET PN TILL J032080 FOR EUROPE HIT-6696497.A6 6696497	£60.35	£72.42
281B - GEAR CASE ASS'Y SINCE J032081 FOR EUROPE HIT-6601215.A2 6601215	-
282 - HEX. HOLE BOLT M5X25/S TILL J032080 FOR EUROPE HIT-6684709.A101 6684709	£1.67	£2.00
282A - HEX. SOCKET HD. BOLT M5X12 SINCE J032081 FOR EUROPE HIT-6684829.A11 6684829	-
283 - SPRING WASHER 5 SINCE J032081 FOR EUROPE HIT-6684834.A36 6684834	£1.67	£2.00
284 - RETAINING RING C-TYPE D26 FOR EUROPE HIT-6695294.A40 6695294	-
285 - STOP RING OUTER 10 TILL J032080 FOR EUROPE HIT-6695315.A15 6695315	-
285A - STOP RING C-10 1 HIT-6684821.A6 6684821	£1.67	£2.00
286 - BALL BEARING #6000Z 1 HIT-6695526.A0 6695526	-
*287 - BALL BEARING #6000 1 HIT-6695524.A18 6695524	-
*287 - BALL BEARING #6000 2 HIT-6695524.A19 6695524	-
288 - GEAR CASE 26 DIA TILL J032080 FOR EUROPE HIT-6688770.A0 6688770	-
288A - GEAR CASE SINCE J032081 FOR EUROPE HIT-6697738.A5 6697738	-
289 - HEX.HOLE BOLT M5X12/S TILL J032080 FOR EUROPE HIT-6684667.A46 6684667	£1.67	£2.00
289A - HEX. SOCKET HD. BOLT M5X30 S SINCE J032080 FOR EUROPE HIT-6684786.A38 6684786	£1.67	£2.00
290 - OILING BOLT TILL J032080 FOR EUROPE HIT-6689109.A19 6689109	-
290A - BOLT (W/PLUS) M6X8 SINCE J032081 FOR EUROPE HIT-6684737.A23 6684737	-
291 - BALL BEARING 609 TILL J032080 FOR EUROPE HIT-6684734.A41 6684734	-
292 - GEAR SHAFT TILL J032080 FOR EUROPE HIT-6688924.A14 6688924	-
292A - GEAR SHAFT SINCE J032081 FOR EUROPE HIT-6697739.A6 6697739	-
293 - BALL BEARING 6201D 1 HIT-6695554.A14 6695554	-
293A - BALL BEARING #6201DD 1 HIT-6695555.A8 6695555	-
294 - STOP RING C-32 1 HIT-6695295.A12 6695295	£1.67	£2.00
295 - CUTTER HOLDER TILL J032080 FOR EUROPE HIT-6689032.A28 6689032	£15.16	£18.19
295B - CUTTER HOLDER ASS'Y SINCE J032081 FOR EUROPE HIT-6601216.A6 6601216	-
296 - CUTTER HOLDER CAP TILL J032080 FOR EUROPE HIT-6689055.A8 6689055	£12.10	£14.52
296A - CUTTER HOLDER CAP SINCE J032081 FOR EUROPE HIT-6699009.A9 6699009	-
297 - NUT COVER SINCE J032081 FOR EUROPE HIT-6697792.A7 6697792	£4.28	£5.13
298 - FIXING NUT M10X1.25 TILL J032080 FOR EUROPE HIT-6689073.A17 6689073	£8.32	£9.99
298A - LEFT HAND NYLON NUT M10 SINCE J032081 FOR EUROPE HIT-6698658.A8 6698658	£8.59	£10.31
299 - GEAR CASE WASHER TILL J032080 FOR EUROPE HIT-6689159.A7 6689159	-
300 - HEX. HOLE BUTTON BOLT M6X25 FOR EUROPE HIT-6684714.A114 6684714	£1.67	£2.00
301 - COVER BRACKET 1 HIT-6690294.A8 6690294	-
301A - COVER BRACKET 26 TILL J032080 FOR EUROPE HIT-6690315.A22 6690315	-
301B - COVER BRACKET D26 SINCE J032081 FOR EUROPE HIT-6697867.A11 6697867	-
302 - BLADE GUARD 26 CE TILL D085850 FOR EUROPE HIT-6690242.A21 6690242	£18.84	£22.61
302A - BLADE GUARD 26CE SINCE D085851 FOR EUROPE HIT-6690276.A19 6690276	£20.01	£24.01
303 - GUARD HOLDER FOR EUROPE HIT-6684748.A26 6684748	-
304 - COVER GUARD TILL D085850 FOR EUROPE HIT-6690372.A23 6690372	£2.81	£3.37
304A - BLADE GUARD SINCE D085851 FOR EUROPE HIT-6690376.A31 6690376	£9.34	£11.21
305 - KNIFE TILL D085850 FOR EUROPE HIT-6693386.A17 6693386	£8.53	£10.24
305A - KNIFE SINCE D085851 FOR EUROPE HIT-6684750.A45 6684750	£3.64	£4.37
306 - SCREW 5X12/S TILL D085850 FOR EUROPE HIT-6695334.A17 6695334	£1.67	£2.00
306A - TAPPING SCREW 4X14 SINCE D085851 FOR EUROPE HIT-6684751.A54 6684751	£1.67	£2.00
307 - GEAR/PINION SET 1 HIT-6688875.A24 6688875	-
307A - GEAR PINION SET 1 HIT-6697741.A11 6697741	-
308 - NUT M5 TILL D085850 FOR EUROPE HIT-6684965.A25 6684965	£1.67	£2.00
*309 - TAPPING SCREW 5X20 SINCE D085851 FOR EUROPE HIT-6684753.A30 6684753	£1.67	£2.00
*309 - TAPPING SCREW 5X20 TILL H126130 FOR EUROPE HIT-6684753.A31 6684753	£1.67	£2.00
*310 - KNIFE SINCE D085851 FOR EUROPE HIT-6684754.A53 6684754	£6.64	£7.97
*310 - KNIFE TILL H126160 FOR EUROPE HIT-6684754.A54 6684754	£6.64	£7.97
321 - GEAR CASE SET PN FOR AUS HIT-6696497.A20 6696497	£60.35	£72.42
322 - HEX. HOLE BOLT M5X25/S FOR AUS HIT-6684709.A25 6684709	£1.67	£2.00
323 - RETAINING RING C-TYPE D26 FOR AUS HIT-6695294.A21 6695294	-
325 - STOP RING OUTER 10 FOR AUS HIT-6695315.A21 6695315	-
326 - BALL BEARING #6000Z 1 HIT-6695526.A23 6695526	-
327 - BALL BEARING #6000 1 HIT-6695524.A36 6695524	-
328 - GEAR CASE 26 DIA FOR AUS HIT-6688770.A20 6688770	-
329 - HEX.HOLE BOLT M5X12/S FOR AUS HIT-6684667.A75 6684667	£1.67	£2.00
330 - OILING BOLT FOR AUS HIT-6689109.A39 6689109	-
331 - BALL BEARING 609 FOR AUS HIT-6684734.A13 6684734	-
332 - GEAR SHAFT FOR AUS HIT-6688924.A26 6688924	-
333 - BALL BEARING 6201D 1 HIT-6695554.A0 6695554	-
334 - STOP RING C-32 1 HIT-6695295.A31 6695295	£1.67	£2.00
335 - CUTTER HOLDER FOR AUS HIT-6689032.A12 6689032	£15.16	£18.19
336 - CUTTER HOLDER CAP FOR AUS HIT-6689055.A23 6689055	£12.10	£14.52
338 - FIXING NUT M10X1.25 FOR AUS HIT-6689073.A7 6689073	£8.32	£9.99
339 - GEAR CASE WASHER FOR AUS HIT-6689159.A6 6689159	-
340 - HEX. HOLE BUTTON BOLT M6X25 FOR AUS HIT-6684714.A113 6684714	£1.67	£2.00
341 - COVER BRACKET 1 HIT-6690294.A9 6690294	-
341A - COVER BRACKET 26 SINCE D089601 FOR AUS HIT-6690315.A21 6690315	-
342 - BLADE GUARD 26 CE TILL D172850 FOR AUS HIT-6690242.A22 6690242	£18.84	£22.61
342A - BLADE GUARD 26CE SINCE D172851 FOR AUS HIT-6690276.A18 6690276	£20.01	£24.01
343 - GUARD HOLDER FOR AUS HIT-6684748.A25 6684748	-
344 - COVER GUARD TILL D172850 FOR AUS HIT-6690372.A24 6690372	£2.81	£3.37
344A - BLADE GUARD SINCE D172851 FOR AUS HIT-6690376.A30 6690376	£9.34	£11.21
345 - KNIFE TILL D172850 FOR AUS HIT-6693386.A16 6693386	£8.53	£10.24
345A - KNIFE SINCE D172851 FOR AUS HIT-6684750.A46 6684750	£3.64	£4.37
346 - SCREW 5X12/S TILL D172850 FOR AUS HIT-6695334.A16 6695334	£1.67	£2.00
346A - TAPPING SCREW 4X14 SINCE D172851 FOR AUS HIT-6684751.A53 6684751	£1.67	£2.00
347 - GEAR/PINION SET 1 HIT-6688875.A23 6688875	-
348 - NUT M5 TILL D172850 FOR AUS HIT-6684965.A24 6684965	£1.67	£2.00
*349 - TAPPING SCREW 5X20 SINCE D172851 FOR AUS HIT-6684753.A32 6684753	£1.67	£2.00
*349 - TAPPING SCREW 5X20 TILL H124410 FOR AUS HIT-6684753.A33 6684753	£1.67	£2.00
*350 - KNIFE SINCE D172851 FOR AUS HIT-6684754.A51 6684754	£6.64	£7.97
*350 - KNIFE TILL H124410 FOR AUS HIT-6684754.A52 6684754	£6.64	£7.97
501 - HEX. BAR WRENCH 4MM HIT-6684813.A76 6684813	-
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A80 6684764	£7.64	£9.17
504A - PROTECTIVE GLASSES HIT-875769.A33 875769	-
505 - HEX. WRENCH 3 HIT-6693520.A3 6693520	-
507 - SHOULDER HARNESS D3X HIT-6695796.A16 6695796	£25.30	£30.36
510 - NYLON HEAD BF-5 TILL TL043660 HIT-6695784.A2 6695784	£27.81	£33.37
511 - MOUNTING NUT L-M10X1.25 TILL TL043660 HIT-6684756.A12 6684756	£10.80	£12.96
512 - MOUNTING NUT L-M8X1.25 TILL TL043660 HIT-6689624.A5 6689624	-
513 - CUTTING BODY TILL TL043660 HIT-6684757.A2 6684757	£15.38	£18.45
514 - SPECIAL NUT TILL TL043660 HIT-6684758.A14 6684758	£6.18	£7.41
515 - REEL SPRING TILL TL043660 HIT-6684759.A2 6684759	£3.56	£4.27
516 - SPOOL TILL TL043660 HIT-6684760.A14 6684760	£13.48	£16.18
517 - CUTTING BODY CAP TILL TL043660 HIT-6684761.A2 6684761	£21.34	£25.61
518 - EYELET TILL TL043660 HIT-6684762.A14 6684762	£3.56	£4.27
519 - SURE TAP MANUAL P/L 9 TILL TL043660 HIT-6697805.A6 6697805	-
520 - WINDING PROTECTOR TILL TL043660 HIT-6684763.A2 6684763	£2.98	£3.57
521 - NYLON CORD CUTTER SINCE TL043661 HIT-6601148.A17 6601148	£25.68	£30.81
522 - CASE SINCE TL043661 HIT-6601149.A0 6601149	-
523 - NUT SINCE TL043661 HIT-6601150.A17 6601150	-
524 - REEL SPRING SINCE TL043661 HIT-6693380.A20 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL043661 HIT-6601151.A0 6601151	-
526 - COVER SINCE TL043661 HIT-6601152.A17 6601152	-
527 - EYELET SINCE TL043661 HIT-6684810.A11 6684810	£3.29	£3.95
601 - S?START MARK HIT-6694472.A6 6694472	-
602 - SYMBOL MARK TBC-340DS HIT-6697868.A0 6697868	-
603 - CAUTION MARK TANAKA HIT-6697851.A7 6697851	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-340DS Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
