Hitachi / Hikoki TBC-340 Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-340 Engine Brush Cutter

	Ex VAT	Inc VAT
*1 - SPARK PLUG ASS'Y RCJ6Y FOR EUROPE HIT-6699326.A6 6699326	£5.70	£6.84
*1 - SPARK PLUG ASS'Y CJ6Y FOR CRC HIT-6699323.A0 6699323	-
2 - CYLINDER SET HIT-6685487.A2 6685487	£43.64	£52.37
3 - HEX. HOLE BOLT M5X16/S HIT-6684903.A70 6684903	-
4 - CYLINDER GASKET HIT-6685746.A5 6685746	£2.86	£3.43
5 - PISTON RING (XR1-1856) HIT-6685331.A32 6685331	£12.57	£15.08
6 - PISTON SET HIT-6685898.A6 6685898	£37.49	£44.99
7 - PISTON PIN HIT-6686008.A14 6686008	£3.64	£4.37
8 - CIRCLIP HIT-6685078.A27 6685078	-
9 - CRANK SHAFT COMP HIT-6696499.A9 6696499	-
10 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A16 6684899	-
11 - HIGH TENSION SCREW 4X18WS HIT-6695407.A1 6695407	-
12 - INSULATOR TUBE 1 HIT-6688319.A5 6688319	£1.67	£2.00
14A - IGNITION COIL ASS'Y HIT-6699772.A1 6699772	-
15 - HIGH TENSION CORD 140L HIT-6687888.A17 6687888	£3.89	£4.67
16 - RUBBER CAP HIT-6684602.A45 6684602	-
17 - LEAD WIRE ASS'Y HIT-6697836.A13 6697836	-
18 - WASHER T1.6 HIT-6684600.A2 6684600	-
31 - CRANK CASE ASS'Y HIT-6686580.A6 6686580	-
32 - OIL SEAL TB 12227 HIT-6684607.A138 6684607	£4.07	£4.88
33 - BALL BEARING 6001 C3 HIT-6684608.A67 6684608	£5.70	£6.84
34 - CRANK CASE GASKET HIT-6686721.A5 6686721	£1.67	£2.00
*35 - GEAR SHAFT SHIM 0.10 HIT-6689177.A7 6689177	-
*35 - GEAR SHAFT SHIM 0.15 HIT-6689178.A28 6689178	-
*35 - GEAR SHAFT SHIM 0.20 HIT-6684604.A6 6684604	-
*35 - GEAR SHAFT SHIM 0.30 HIT-6684605.A75 6684605	-
36 - MAGNETO ROTOR COMP. HIT-6687375.A2 6687375	-
37 - HEX. NUT M8 HIT-6684612.A110 6684612	-
38 - SMALL WASHER 8 HIT-6695184.A19 6695184	-
39 - HEX. HOLE BOLT M5X16/S HIT-6684903.A71 6684903	-
40 - CLUTCH WASHER B HIT-6689645.A22 6689645	£1.67	£2.00
51 - INLET MANIFOLD GASKET HIT-6689864.A3 6689864	£1.67	£2.00
52 - CARBURETOR INSULATOR SET 1 HIT-6689924.A3 6689924	-
53 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A2 6695514	-
54 - CARBURETOR PACKING HIT-6684616.A44 6684616	£1.67	£2.00
55 - CARBURETOR SET WYJ296 HIT-6690503.A1 6690503	-
56 - CHOKE PLATE 1.0 HIT-6691278.A2 6691278	£1.67	£2.00
57 - CLEANER BODY COMP. HIT-6690120.A17 6690120	£12.32	£14.78
58 - CLEANER SPONGE HIT-6690365.A24 6690365	£1.67	£2.00
59 - CLEANER COVER ASS'Y HIT-6690421.A4 6690421	£14.48	£17.38
60 - COVER FIXING BOLT COMP. HIT-6698730.A11 6698730	£5.52	£6.63
61 - SCREW 5X57/S HIT-6695353.A14 6695353	£1.67	£2.00
62 - SMALL WASHER 5 HIT-6684864.A80 6684864	-
63 - CHOKE CONTROL LEVER HIT-6691239.A3 6691239	£2.98	£3.57
64 - TANK COMP. WHT HIT-6691588.A6 6691588	£11.68	£14.02
65 - COLLAR C HIT-6684623.A27 6684623	£1.67	£2.00
66 - FUEL PIPE GROMMET HIT-6688156.A18 6688156	-
67 - FUEL PIPE 3X5X85 HIT-6684880.A40 6684880	-
68A - PUMP FILTER BODY COMP HIT-66A3864.A61 66A3864	-
69 - CLIP D6 HIT-6685198.A43 6685198	-
70 - FUEL PIPE ASS'Y HIT-6688169.A4 6688169	£4.32	£5.19
71 - HEX. HOLE BOLT 5X20PS HIT-6695506.A10 6695506	-
72 - TANK CAP ASS'Y HIT-6685049.A15 6685049	£9.94	£11.93
73 - TANK CAP CHAIN HIT-6684625.A6 6684625	-
74 - STAND HIT-6694793.A5 6694793	-
75 - TAP SCREW 4X14 P HIT-6695280.A4 6695280	£1.67	£2.00
76 - BOLT WASHER M4 HIT-6685070.A38 6685070	£1.67	£2.00
91 - CLUTCH ARM COMP. HIT-6688610.A3 6688610	£13.94	£16.73
92 - CLUTCH SPRING HIT-6689420.A7 6689420	£2.81	£3.37
93 - CLUTCH WASHER B HIT-6689645.A21 6689645	£1.67	£2.00
94 - WAVE WASHER 10 HIT-6695203.A6 6695203	£1.67	£2.00
95 - CLUTCH STEP BOLT HIT-6689628.A15 6689628	£3.29	£3.95
96 - CLUTCH SET ASS'Y HIT-6688482.A5 6688482	-
97 - FAN CASE COMP. HIT-6687019.A6 6687019	-
98 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A51 6695512	-
99 - ANTI-VIBE RUBBER HIT-6691838.A1 6691838	-
100 - TAPPING SCREW D5X14 HIT-6685275.A60 6685275	-
101 - PIPE HOLDER HIT-6689656.A3 6689656	-
102 - STOP RING C-12 OUTER HIT-6684664.A55 6684664	£1.67	£2.00
103 - HEX. HOLE BOLT M5X25/S HIT-6684709.A171 6684709	£1.67	£2.00
104 - HEX. HOLE BOLT 4X12WS HIT-6695507.A0 6695507	-
105 - CLUTCH SHAFT COMP. 78 HIT-6688598.A2 6688598	£20.11	£24.13
106 - STOP RING R-32 INNER HIT-6695304.A4 6695304	-
107 - BEARING CASE HIT-6686667.A5 6686667	-
108 - BALL BEARING #6201ZZ 1 HIT-6695553.A2 6695553	-
109 - PRIMARY CORD GROMMET HIT-6688057.A25 6688057	-
110 - MUFFLER PROTECTOR HIT-6692803.A3 6692803	£13.79	£16.55
111 - SPARK PLUG CAP ASS'Y HIT-6687468.A25 6687468	£3.64	£4.37
112 - TAPPING SCREW D4.5X12 HIT-6684637.A3 6684637	£1.67	£2.00
113 - MUFFLER GASKET HIT-6692732.A10 6692732	£1.67	£2.00
114 - HEAT SHIELD HIT-6687260.A6 6687260	£5.77	£6.92
115 - MUFFLER SET HIT-6692489.A1 6692489	-
116 - HEX. HOLE BOLT M6X55 HIT-6684638.A31 6684638	£1.67	£2.00
117 - BOLT WASHER 6 HIT-6684639.A24 6684639	£1.67	£2.00
118 - MUFFLER SPECIAL GASKET HIT-6692887.A10 6692887	-
*119 - TAIL PIPE SET FOR EUROPE HIT-6692669.A4 6692669	-
*119 - TAIL PIPE SET FOR AUS HIT-6692712.A0 6692712	-
*120 - SCREW 4X8/S FOR EUROPE HIT-6695325.A9 6695325	-
*120 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR AUS HIT-6685109.A23 6685109	-
121 - SPARK ARRESTOR FOR AUS HIT-6692699.A0 6692699	-
151 - RECOIL STARTER ASS'Y HIT-6692969.A6 6692969	£25.30	£30.36
152 - STARTER HANDLE HIT-6693227.A10 6693227	-
153 - ROPE GUIDE HIT-6693135.A2 6693135	-
154 - RECOIL STARTER BODY HIT-6693036.A3 6693036	-
155 - RECOIL SPRING HIT-6693111.A5 6693111	£15.16	£18.19
156 - ROPE 3.5X890 HIT-6693157.A5 6693157	-
157 - STARTER ROPE REEL HIT-6693057.A4 6693057	£8.18	£9.81
158 - ROPE REEL WASHER HIT-6693419.A4 6693419	-
159 - SET SCREW HIT-6693632.A3 6693632	-
160 - HEX.HOLE BOLT 4X18PS HIT-6695502.A16 6695502	£1.67	£2.00
161 - STARTER PULLEY ASS'Y HIT-6693394.A3 6693394	£9.42	£11.30
162 - STARTER PAWL HIT-6693299.A3 6693299	£3.29	£3.95
163 - STARTER PAWL SPRING HIT-6693345.A16 6693345	£3.89	£4.67
191 - PUMP BODY COMP. HIT-6684879.A27 6684879	£35.37	£42.44
192 - PRIMING PUMP COMP. HIT-6684687.A18 6684687	£9.27	£11.12
193 - DIAPHRAGM COVER HIT-6684688.A82 6684688	£5.70	£6.84
194 - PRIMING BODY HIT-6684689.A17 6684689	£5.87	£7.04
195 - METERING DIAPHRAGM COMP. HIT-6690830.A18 6690830	£14.58	£17.50
196 - DIAPHRAGM GASKET HIT-6684691.A9 6684691	£5.70	£6.84
197 - PUMP DIAPHRAGM HIT-6684693.A44 6684693	£5.70	£6.84
198 - PUMP GASKET HIT-6691457.A24 6691457	£8.48	£10.18
199 - MAIN JET #43 HIT-6691848.A8 6691848	£8.77	£10.52
200 - O-RING HIT-6684695.A148 6684695	£1.67	£2.00
201 - STOP RING HIT-6684696.A49 6684696	-
202 - SWIVEL HIT-6684697.A116 6684697	-
203 - THROTTLE SET SCREW HIT-6684870.A53 6684870	-
204 - CABLE ADJUSTER STAY HIT-6684873.A25 6684873	-
205 - LOCK NUT M6 HIT-6684872.A58 6684872	-
206 - CABLE ADJUSTER HIT-6684871.A21 6684871	-
207 - CLEANER PACKING HIT-6684875.A26 6684875	-
208 - SET SCREW HIT-6684699.A84 6684699	-
209 - THRUST WASHER HIT-6684874.A54 6684874	-
210 - INLET SCREEN HIT-6684700.A57 6684700	-
231 - DRIVE SHAFT 1533L HIT-6689478.A10 6689478	£28.76	£34.51
232 - DRAIVE SHAFT PIPE COMP. HIT-6689407.A10 6689407	£53.33	£64.00
233 - BUSHING ASS'Y HIT-6697866.A6 6697866	-
234 - HEX.NUT 6 HIT-6684835.A0 6684835	£1.67	£2.00
235 - HANDLE TILL B155000 HIT-6691036.A0 6691036	-
235A - LOOP HANDLE BLACK HIT-6691049.A0 6691049	-
236 - BARRIER BLACK HIT-6691231.A3 6691231	-
237 - BOLT 6X43/P (BLACK) HIT-6684838.A33 6684838	£1.67	£2.00
238 - TAPPING SCREW 5X20 SINCE B155001 HIT-6695255.A16 6695255	-
239 - BRAKE SHAFT WASHER SINCE B155001 HIT-6689681.A30 6689681	£1.67	£2.00
240 - HANDLE GRIP SINCE B155001 HIT-6691098.A22 6691098	£10.90	£13.08
241 - LIFTING METAL ASS'Y HIT-6689275.A7 6689275	-
242 - THROTTLE LEVER ASS'Y 1 HIT-6693748.A3 6693748	£42.08	£50.49
243 - THROTTLE WIRE COMP. HIT-6693978.A7 6693978	£22.29	£26.75
244 - THROTTLE WIRE HIT-6694022.A3 6694022	-
245 - STOP SWITCH COMP. HIT-6687459.A4 6687459	£17.33	£20.80
246 - PROTECTION TUBE 7X175 HIT-6687526.A3 6687526	-
247 - TRIGGER LOCK OUT HIT-6684721.A8 6684721	£5.17	£6.20
248 - RETURN SPRING HIT-6684722.A39 6684722	£1.67	£2.00
249 - BLIND PLUG HIT-6684724.A29 6684724	-
250 - SCREW M5X20 HIT-6684803.A17 6684803	-
251 - CONTAL NUT 5 HIT-6684727.A8 6684727	£1.67	£2.00
252 - SCREW M4X20 (BLACK) HIT-6684725.A11 6684725	-
253 - THROTTLE LEVER HIT-6684804.A13 6684804	£6.86	£8.23
281 - GEAR CASE SET PN TILL J032080 FOR EUROPE HIT-6696497.A4 6696497	£60.35	£72.42
281A - GEAR CASE ASS'Y TILL TL028330 FOR EUROPE HIT-6697660.A2 6697660	-
281B - GEAR CASE SET PN SINCE TL028331 FOR EUROPE HIT-6696497.A3 6696497	£60.35	£72.42
282 - HEX. HOLE BOLT M5X25/S TILL J032080 FOR EUROPE HIT-6684709.A173 6684709	£1.67	£2.00
282A - HEX. SOCKET HD. BOLT M5X12 TILL TL028330 FOR EUROPE HIT-6684829.A5 6684829	-
282B - HEX. HOLE BOLT M5X25/S SINCE TL028331 FOR EUROPE HIT-6684709.A172 6684709	£1.67	£2.00
*283 - SPRING WASHER 5 SINCE J032081 FOR EUROPE HIT-6684834.A60 6684834	£1.67	£2.00
*283 - SPRING WASHER 5 TILL TL028330 FOR EUROPE HIT-6684834.A61 6684834	£1.67	£2.00
284 - RETAINING RING C-TYPE D26 FOR EUROPE HIT-6695294.A49 6695294	-
285 - STOP RING OUTER 10 TILL J032080 FOR EUROPE HIT-6695315.A2 6695315	-
285A - STOP RING C-10 1 HIT-6684821.A1 6684821	£1.67	£2.00
285B - STOP RING OUTER 10 SINCE TL028331 FOR EUROPE HIT-6695315.A3 6695315	-
286 - BALL BEARING #6000Z 1 HIT-6695526.A14 6695526	-
*287 - BALL BEARING #6000 1 HIT-6695524.A26 6695524	-
*287 - BALL BEARING #6000 2 HIT-6695524.A27 6695524	-
*287 - BALL BEARING #6000 1 HIT-6695524.A28 6695524	-
288 - GEAR CASE 26 DIA TILL J032080 FOR EUROPE HIT-6688770.A10 6688770	-
288A - GEAR CASE TILL TL028330 FOR EUROPE HIT-6697738.A7 6697738	-
288B - GEAR CASE 26 DIA SINCE TL028331 FOR EUROPE HIT-6688770.A11 6688770	-
289 - HEX.HOLE BOLT M5X12/S TILL J032080 FOR EUROPE HIT-6684667.A9 6684667	£1.67	£2.00
289A - HEX. SOCKET HD. BOLT M5X30 S TILL TL028330 FOR EUROPE HIT-6684786.A8 6684786	£1.67	£2.00
289B - HEX.HOLE BOLT M5X12/S SINCE TL028331 FOR EUROPE HIT-6684667.A10 6684667	£1.67	£2.00
290 - OILING BOLT TILL J032080 FOR EUROPE HIT-6689109.A3 6689109	-
290A - BOLT (W/PLUS) M6X8 TILL TL028330 FOR EUROPE HIT-6684737.A8 6684737	-
290B - OILING BOLT SINCE TL028331 FOR EUROPE HIT-6689109.A2 6689109	-
*291 - BALL BEARING 609 TILL J032080 FOR EUROPE HIT-6684734.A23 6684734	-
*291 - BALL BEARING 609 SINCE TL028331 FOR EUROPE HIT-6684734.A24 6684734	-
292 - GEAR SHAFT TILL J032080 FOR EUROPE HIT-6688924.A4 6688924	-
292A - GEAR SHAFT TILL TL028330 FOR EUROPE HIT-6697739.A4 6697739	-
292B - GEAR SHAFT SINCE TL028331 FOR EUROPE HIT-6688924.A5 6688924	-
293 - BALL BEARING 6201D 1 HIT-6695554.A27 6695554	-
293A - BALL BEARING #6201DD 1 HIT-6695555.A3 6695555	-
293B - BALL BEARING 6201D 1 HIT-6695554.A26 6695554	-
294 - STOP RING C-32 1 HIT-6695295.A5 6695295	£1.67	£2.00
295 - CUTTER HOLDER TILL J032080 FOR EUROPE HIT-6689032.A15 6689032	£15.16	£18.19
295A - CUTTER HOLDER TILL TL028330 FOR EUROPE HIT-6699008.A2 6699008	-
295B - CUTTER HOLDER SINCE TL028331 FOR EUROPE HIT-6689032.A16 6689032	£15.16	£18.19
296 - CUTTER HOLDER CAP TILL J032080 FOR EUROPE HIT-6689055.A11 6689055	£12.10	£14.52
296A - CUTTER HOLDER CAP TILL TL028330 FOR EUROPE HIT-6699009.A0 6699009	-
296B - CUTTER HOLDER CAP SINCE TL028331 FOR EUROPE HIT-6689055.A12 6689055	£12.10	£14.52
*297 - NUT COVER SINCE J032081 FOR EUROPE HIT-6697792.A10 6697792	£4.28	£5.13
*297 - NUT COVER TILL TL028330 FOR EUROPE HIT-6697792.A11 6697792	£4.28	£5.13
298 - FIXING NUT M10X1.25 TILL J032080 FOR EUROPE HIT-6689073.A30 6689073	£8.32	£9.99
298A - LEFT HAND NYLON NUT M10 TILL TL028330 FOR EUROPE HIT-6698658.A7 6698658	£8.59	£10.31
298B - FIXING NUT M10X1.25 SINCE TL028331 FOR EUROPE HIT-6689073.A31 6689073	£8.32	£9.99
*299 - GEAR CASE WASHER TILL J032080 FOR EUROPE HIT-6689159.A30 6689159	-
*299 - GEAR CASE WASHER SINCE TL028331 FOR EUROPE HIT-6689159.A31 6689159	-
300 - HEX. HOLE BUTTON BOLT M6X25 FOR EUROPE HIT-6684714.A51 6684714	£1.67	£2.00
301 - COVER BRACKET 1 HIT-6690294.A1 6690294	-
301A - COVER BRACKET 26 TILL J032080 FOR EUROPE HIT-6690315.A14 6690315	-
301B - COVER BRACKET D26 TILL TL028330 FOR EUROPE HIT-6697867.A6 6697867	-
301C - COVER BRACKET 26 SINCE TL028331 FOR EUROPE HIT-6690315.A12 6690315	-
302 - BLADE GUARD 26 CE TILL D172860 FOR EUROPE HIT-6690242.A9 6690242	£18.84	£22.61
302A - BLADE GUARD 26CE SINCE D172861 FOR EUROPE HIT-6690276.A11 6690276	£20.01	£24.01
303 - GUARD HOLDER FOR EUROPE HIT-6684748.A12 6684748	-
304 - COVER GUARD TILL D172860 FOR EUROPE HIT-6690372.A11 6690372	£2.81	£3.37
304A - BLADE GUARD SINCE D172861 FOR EUROPE HIT-6690376.A12 6690376	£9.34	£11.21
305 - KNIFE TILL D172860 FOR EUROPE HIT-6693386.A25 6693386	£8.53	£10.24
305A - KNIFE SINCE D172861 FOR EUROPE HIT-6684750.A26 6684750	£3.64	£4.37
306 - SCREW 5X12/S TILL D172860 FOR EUROPE HIT-6695334.A27 6695334	£1.67	£2.00
306A - TAPPING SCREW 4X14 SINCE D172861 FOR EUROPE HIT-6684751.A75 6684751	£1.67	£2.00
307 - GEAR/PINION SET 1 HIT-6688875.A10 6688875	-
307A - GEAR PINION SET 1 HIT-6697741.A6 6697741	-
307B - GEAR/PINION SET 1 HIT-6688875.A9 6688875	-
308 - NUT M5 TILL D172860 FOR EUROPE HIT-6684965.A58 6684965	£1.67	£2.00
*309 - TAPPING SCREW 5X20 SINCE D172861 FOR EUROPE HIT-6684753.A62 6684753	£1.67	£2.00
*309 - TAPPING SCREW 5X20 TILL H126130 FOR EUROPE HIT-6684753.A63 6684753	£1.67	£2.00
*310 - KNIFE SINCE D172861 FOR EUROPE HIT-6684754.A29 6684754	£6.64	£7.97
*310 - KNIFE TILL H126160 FOR EUROPE HIT-6684754.A30 6684754	£6.64	£7.97
321 - GEAR CASE SET PN FOR AUS HIT-6696497.A2 6696497	£60.35	£72.42
322 - HEX. HOLE BOLT M5X25/S FOR AUS HIT-6684709.A174 6684709	£1.67	£2.00
323 - RETAINING RING C-TYPE D26 FOR AUS HIT-6695294.A51 6695294	-
325 - STOP RING OUTER 10 FOR AUS HIT-6695315.A4 6695315	-
326 - BALL BEARING #6000Z 1 HIT-6695526.A13 6695526	-
327 - BALL BEARING #6000 1 HIT-6695524.A29 6695524	-
328 - GEAR CASE 26 DIA FOR AUS HIT-6688770.A12 6688770	-
329 - HEX.HOLE BOLT M5X12/S FOR AUS HIT-6684667.A12 6684667	£1.67	£2.00
330 - OILING BOLT FOR AUS HIT-6689109.A4 6689109	-
331 - BALL BEARING 609 FOR AUS HIT-6684734.A25 6684734	-
332 - GEAR SHAFT FOR AUS HIT-6688924.A2 6688924	-
333 - BALL BEARING 6201D 1 HIT-6695554.A28 6695554	-
334 - STOP RING C-32 1 HIT-6695295.A3 6695295	£1.67	£2.00
335 - CUTTER HOLDER FOR AUS HIT-6689032.A14 6689032	£15.16	£18.19
336 - CUTTER HOLDER CAP FOR AUS HIT-6689055.A13 6689055	£12.10	£14.52
338 - FIXING NUT M10X1.25 FOR AUS HIT-6689073.A29 6689073	£8.32	£9.99
339 - GEAR CASE WASHER FOR AUS HIT-6689159.A28 6689159	-
340 - HEX. HOLE BUTTON BOLT M6X25 FOR AUS HIT-6684714.A49 6684714	£1.67	£2.00
341 - COVER BRACKET 1 HIT-6690294.A2 6690294	-
341A - COVER BRACKET 26 SINCE D089601 FOR AUS HIT-6690315.A11 6690315	-
342 - BLADE GUARD 26 CE TILL E173050 FOR AUS HIT-6690242.A10 6690242	£18.84	£22.61
342A - BLADE GUARD 26CE SINCE E173051 FOR AUS HIT-6690276.A9 6690276	£20.01	£24.01
343 - GUARD HOLDER FOR AUS HIT-6684748.A11 6684748	-
344 - COVER GUARD TILL E173050 FOR AUS HIT-6690372.A12 6690372	£2.81	£3.37
344A - BLADE GUARD SINCE E173051 FOR AUS HIT-6690376.A11 6690376	£9.34	£11.21
345 - KNIFE TILL E173050 FOR AUS HIT-6693386.A26 6693386	£8.53	£10.24
345A - KNIFE SINCE E173051 FOR AUS HIT-6684750.A27 6684750	£3.64	£4.37
346 - SCREW 5X12/S TILL E173050 FOR AUS HIT-6695334.A26 6695334	£1.67	£2.00
346A - TAPPING SCREW 4X14 SINCE E173051 FOR AUS HIT-6684751.A74 6684751	£1.67	£2.00
347 - GEAR/PINION SET 1 HIT-6688875.A8 6688875	-
348 - NUT M5 TILL E173050 FOR AUS HIT-6684965.A57 6684965	£1.67	£2.00
*349 - TAPPING SCREW 5X20 SINCE E173051 FOR AUS HIT-6684753.A64 6684753	£1.67	£2.00
*349 - TAPPING SCREW 5X20 TILL H124410 FOR AUS HIT-6684753.A65 6684753	£1.67	£2.00
*350 - KNIFE SINCE E173051 FOR AUS HIT-6684754.A27 6684754	£6.64	£7.97
*350 - KNIFE TILL H124410 FOR AUS HIT-6684754.A28 6684754	£6.64	£7.97
361 - GEAR CASE SET PN TILL J032080 FOR CRC HIT-6696497.A1 6696497	£60.35	£72.42
361B - GEAR CASE ASS'Y SINCE J032081 FOR CRC HIT-6601215.A6 6601215	-
362 - HEX. HOLE BOLT M5X25/S TILL J032080 FOR CRC HIT-6684709.A175 6684709	£1.67	£2.00
362A - HEX. SOCKET HD. BOLT M5X12 SINCE J032081 FOR CRC HIT-6684829.A6 6684829	-
363 - SPRING WASHER 5 FOR CRC HIT-6684834.A59 6684834	£1.67	£2.00
364 - RETAINING RING C-TYPE D26 FOR CRC HIT-6695294.A50 6695294	-
365 - STOP RING OUTER 10 TILL J032080 FOR CRC HIT-6695315.A5 6695315	-
365A - STOP RING C-10 1 HIT-6684821.A0 6684821	£1.67	£2.00
366 - BALL BEARING #6000Z 1 HIT-6695526.A12 6695526	-
*367 - BALL BEARING #6000 1 HIT-6695524.A30 6695524	-
*367 - BALL BEARING #6000 2 HIT-6695524.A31 6695524	-
368 - GEAR CASE 26 DIA TILL J032080 FOR CRC HIT-6688770.A13 6688770	-
368A - GEAR CASE SINCE J032081 FOR CRC HIT-6697738.A8 6697738	-
369 - HEX.HOLE BOLT M5X12/S TILL J032080 FOR CRC HIT-6684667.A11 6684667	£1.67	£2.00
369A - HEX. SOCKET HD. BOLT M5X30 S SINCE J032081 FOR CRC HIT-6684786.A7 6684786	£1.67	£2.00
370 - OILING BOLT TILL J032080 FOR CRC HIT-6689109.A5 6689109	-
370A - BOLT (W/PLUS) M6X8 SINCE J032081 FOR CRC HIT-6684737.A7 6684737	-
371 - BALL BEARING 609 TILL J032080 FOR CRC HIT-6684734.A26 6684734	-
372 - GEAR SHAFT TILL J032080 FOR CRC HIT-6688924.A3 6688924	-
372A - GEAR SHAFT SINCE J032081 FOR CRC HIT-6697739.A3 6697739	-
373 - BALL BEARING 6201D 1 HIT-6695554.A29 6695554	-
373A - BALL BEARING #6201DD 1 HIT-6695555.A2 6695555	-
374 - STOP RING C-32 1 HIT-6695295.A4 6695295	£1.67	£2.00
375 - CUTTER HOLDER TILL J032080 FOR CRC HIT-6689032.A13 6689032	£15.16	£18.19
375B - CUTTER HOLDER ASS'Y SINCE J032081 FOR CRC HIT-6601216.A2 6601216	-
376 - CUTTER HOLDER CAP TILL J032080 FOR CRC HIT-6689055.A14 6689055	£12.10	£14.52
376A - CUTTER HOLDER CAP SINCE J032081 FOR CRC HIT-6699009.A1 6699009	-
377 - NUT COVER SINCE J032081 FOR CRC HIT-6697792.A9 6697792	£4.28	£5.13
378 - FIXING NUT M10X1.25 TILL J032080 FOR CRC HIT-6689073.A28 6689073	£8.32	£9.99
378A - LEFT HAND NYLON NUT M10 SINCE J032081 FOR CRC HIT-6698658.A6 6698658	£8.59	£10.31
379 - GEAR CASE WASHER TILL J032080 FOR CRC HIT-6689159.A29 6689159	-
380 - HEX. HOLE BUTTON BOLT M6X25 FOR CRC HIT-6684714.A50 6684714	£1.67	£2.00
381 - COVER BRACKET 26 TILL J032080 FOR CRC HIT-6690315.A13 6690315	-
381A - COVER BRACKET D26 SINCE J032081 FOR CRC HIT-6697867.A7 6697867	-
382 - BLADE GUARD 26CE FOR CRC HIT-6690276.A10 6690276	£20.01	£24.01
383 - GUARD HOLDER FOR CRC HIT-6684748.A13 6684748	-
384 - BLADE GUARD FOR CRC HIT-6690376.A13 6690376	£9.34	£11.21
385 - KNIFE FOR CRC HIT-6684750.A25 6684750	£3.64	£4.37
386 - TAPPING SCREW 4X14 FOR CRC HIT-6684751.A76 6684751	£1.67	£2.00
387 - TAPPING SCREW 5X20 TILL H135500 FOR CRC HIT-6684753.A61 6684753	£1.67	£2.00
388 - KNIFE TILL H135500 FOR CRC HIT-6684754.A31 6684754	£6.64	£7.97
389 - GEAR/PINION SET 1 HIT-6688875.A11 6688875	-
389A - GEAR PINION SET 1 HIT-6697741.A7 6697741	-
501 - HEX. BAR WRENCH 4MM HIT-6684813.A11 6684813	-
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A5 6684764	£7.64	£9.17
503 - CUTTER COVER TILL TL010920 HIT-6699555.A12 6699555	-
*503B - CUTTER COVER SINCE TL010921 HIT-6684768.A61 6684768	-
504A - PROTECTIVE GLASSES FOR EUROPE HIT-875769.A152 875769	-
505 - HEX. WRENCH 3 HIT-6693520.A10 6693520	-
*506 - BLADE B4/9/1.6 FOR AU HIT-6695789.A4 6695789	£15.17	£18.20
507 - SHOULDER BELT ASS'Y HIT-6692874.A5 6692874	-
*508 - PROTECTION COVER B TILL J032080 FOR EUROPE HIT-6688995.A0 6688995	£4.81	£5.77
*508 - PROTECTION COVER B SINCE TL028331 FOR EUROPE HIT-6688995.A1 6688995	£4.81	£5.77
*508 - PROTECTION COVER B TILL TL058290 FOR EUROPE HIT-6688995.A2 6688995	£4.81	£5.77
509 - NYLON HEAD CH-100 TILL D089600 FOR AUS HIT-6695786.A0 6695786	-
510 - PROTECTION COVER B FOR AUS HIT-6688995.A3 6688995	£4.81	£5.77
521 - NYLON CORD CUTTER SINCE TL058291 FOR EUROPE HIT-6601148.A5 6601148	£25.68	£30.81
522 - CASE SINCE TL058291 FOR EUROPE HIT-6601149.A12 6601149	-
523 - NUT SINCE TL058291 FOR EUROPE HIT-6601150.A5 6601150	-
524 - REEL SPRING SINCE TL058291 FOR EUROPE HIT-6693380.A7 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL058291 FOR EUROPE HIT-6601151.A12 6601151	-
526 - COVER SINCE TL058291 FOR EUROPE HIT-6601152.A5 6601152	-
527 - EYELET SINCE TL058291 FOR EUROPE HIT-6684810.A20 6684810	£3.29	£3.95
601 - NAME PLATE TBC340 HIT-6694205.A0 6694205	-
602 - SYMBOL MARK TBC340 HIT-6694633.A0 6694633	-
603 - CAUTION MARK TANAKA HIT-6697851.A3 6697851	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-340 Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
