Hitachi / Hikoki TBC-290S Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-290S Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG ASS'Y RCJ6Y HIT-6699326.A7 6699326	£5.70	£6.84
2 - CYLINDER SET HIT-6685484.A2 6685484	-
3 - HEX. HOLE BOLT M5X16/S HIT-6684903.A72 6684903	-
4 - CYLINDER GASKET HIT-6685746.A4 6685746	£2.86	£3.43
5 - PISTON RING 34.5 HIT-6686130.A2 6686130	-
6 - PISTON SET HIT-6685896.A0 6685896	-
7 - PISTON PIN HIT-6686016.A1 6686016	-
8 - CIRCLIP HIT-6685078.A28 6685078	-
9 - CRANK SHAFT COMP HIT-6696499.A10 6696499	-
10 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A17 6684899	-
11 - HIGH TENSION SCREW 4X18WS HIT-6695407.A2 6695407	-
12 - INSULATOR TUBE 1 HIT-6688319.A4 6688319	£1.67	£2.00
14A - IGNITION COIL ASS'Y HIT-6699772.A2 6699772	-
15 - HIGH TENSION CORD 140L HIT-6687888.A18 6687888	£3.89	£4.67
16 - RUBBER CAP HIT-6684602.A44 6684602	-
17 - LEAD WIRE ASS'Y HIT-6697836.A14 6697836	-
18 - WASHER T1.6 HIT-6684600.A3 6684600	-
31 - CRANK CASE ASS'Y HIT-6686580.A7 6686580	-
32 - OIL SEAL TB 12227 HIT-6684607.A139 6684607	£4.07	£4.88
33 - BALL BEARING 6001 C3 HIT-6684608.A66 6684608	£5.70	£6.84
34 - CRANK CASE GASKET HIT-6686721.A4 6686721	£1.67	£2.00
*35 - GEAR SHAFT SHIM 0.10 HIT-6689177.A6 6689177	-
*35 - GEAR SHAFT SHIM 0.15 HIT-6689178.A29 6689178	-
*35 - GEAR SHAFT SHIM 0.20 HIT-6684604.A7 6684604	-
*35 - GEAR SHAFT SHIM 0.30 HIT-6684605.A74 6684605	-
36 - MAGNETO ROTOR COMP. HIT-6687374.A2 6687374	-
37 - HEX. NUT M8 HIT-6684612.A111 6684612	-
38 - SMALL WASHER 8 HIT-6695184.A18 6695184	-
39 - HEX. HOLE BOLT M5X16/S HIT-6684903.A69 6684903	-
40 - CLUTCH WASHER B HIT-6689645.A20 6689645	£1.67	£2.00
51 - INLET MANIFOLD GASKET HIT-6689895.A14 6689895	£1.67	£2.00
52 - INSULATOR SET HIT-6689972.A14 6689972	£6.59	£7.91
53 - HEX. HOLE BOLT M5X25WS HIT-6695515.A59 6695515	£1.67	£2.00
54 - CARBURETOR PACKING HIT-6684616.A43 6684616	£1.67	£2.00
55 - CARBURETOR SET WYJ392 HIT-6690500.A3 6690500	-
56 - CHOKE PLATE 1.0 HIT-6691278.A3 6691278	£1.67	£2.00
57 - CLEANER BODY COMP. HIT-6690120.A16 6690120	£12.32	£14.78
58 - CLEANER SPONGE HIT-6690365.A25 6690365	£1.67	£2.00
59 - CLEANER COVER ASS'Y HIT-6690421.A5 6690421	£14.48	£17.38
60 - COVER FIXING BOLT COMP. HIT-6698730.A12 6698730	£5.52	£6.63
61 - SCREW M5X55 HIT-6694914.A11 6694914	-
62 - SMALL WASHER 5 HIT-6684864.A79 6684864	-
63 - CHOKE CONTROL LEVER HIT-6691239.A2 6691239	£2.98	£3.57
64 - TANK COMP. WHT HIT-6691588.A5 6691588	£11.68	£14.02
65 - COLLAR C HIT-6684623.A28 6684623	£1.67	£2.00
66 - FUEL PIPE GROMMET HIT-6688156.A17 6688156	-
67 - FUEL PIPE 3X5X85 HIT-6684880.A39 6684880	-
68A - PUMP FILTER BODY COMP HIT-66A3864.A60 66A3864	-
69 - CLIP D6 HIT-6685198.A42 6685198	-
70 - FUEL PIPE ASS'Y HIT-6688169.A5 6688169	£4.32	£5.19
71 - HEX. HOLE BOLT 5X20PS HIT-6695506.A9 6695506	-
72 - TANK CAP ASS'Y HIT-6685049.A14 6685049	£9.94	£11.93
73 - TANK CAP CHAIN HIT-6684625.A5 6684625	-
74 - STAND HIT-6694793.A4 6694793	-
75 - TAP SCREW 4X14 P HIT-6695280.A3 6695280	£1.67	£2.00
76 - BOLT WASHER M4 HIT-6685070.A37 6685070	£1.67	£2.00
77 - S.WASHER 5 HIT-6684662.A62 6684662	£1.67	£2.00
91 - CLUTCH SHOE COMP. 2 HIT-6688616.A16 6688616	£12.82	£15.38
92 - CLUTCH SPRING HIT-6689430.A1 6689430	£3.89	£4.67
93 - CLUTCH WASHER B HIT-6684642.A35 6684642	£1.67	£2.00
94 - CLUTCH PLATE A 0.5 HIT-6684645.A4 6684645	£1.67	£2.00
95 - STEP BOLT HIT-6689627.A4 6689627	£1.67	£2.00
96 - CLUTCH SET ASSY HIT-6688484.A0 6688484	-
97 - FAN CASE COMP. HIT-6687019.A7 6687019	-
98 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A50 6695512	-
99 - ANTI-VIBE RUBBER HIT-6691838.A2 6691838	-
100 - TAPPING SCREW D5X14 HIT-6685275.A61 6685275	-
101 - PIPE HOLDER HIT-6689656.A4 6689656	-
102 - STOP RING C-12 OUTER HIT-6684664.A56 6684664	-
103 - HEX. HOLE BOLT M5X25/S HIT-6684709.A179 6684709	£1.67	£2.00
104A - HEX. HOLE BOLT 4X12WS HIT-6695507.A1 6695507	-
105 - CLUTCH SHAFT COMP HIT-6688597.A2 6688597	£20.11	£24.13
106 - STOP RING R-32 INNER HIT-6695304.A5 6695304	-
107 - BEARING CASE HIT-6686667.A4 6686667	-
108 - BALL BEARING #6201ZZ 1 HIT-6695553.A1 6695553	-
109 - PRIMARY CORD GROMMET HIT-6688057.A26 6688057	-
110 - MUFFLER PROTECTOR HIT-6692803.A2 6692803	£13.79	£16.55
111 - SPARK PLUG CAP ASS'Y HIT-6687468.A26 6687468	£3.64	£4.37
112 - TAPPING SCREW D4.5X12 HIT-6684637.A6 6684637	£1.67	£2.00
113 - MUFFLER GASKET HIT-6692732.A11 6692732	£1.67	£2.00
114 - HEAT SHIELD HIT-6687260.A5 6687260	£5.77	£6.92
115 - MUFFLER SET HIT-6692489.A0 6692489	-
116 - HEX. HOLE BOLT M6X55 HIT-6684638.A30 6684638	£1.67	£2.00
117 - BOLT WASHER 6 HIT-6684639.A26 6684639	£1.67	£2.00
118 - MUFFLER SPECIAL GASKET HIT-6692887.A11 6692887	-
119 - TAIL PIPE SET HIT-6692669.A5 6692669	-
120 - SCREW 4X8/S HIT-6695325.A10 6695325	-
123 - BENT WASHER 8 HIT-6684648.A90 6684648	£1.67	£2.00
151 - RECOIL STARTER ASS'Y TILL F024130 REPLACED PART HIT-6692992.A2 6692992	£50.78	£60.93
151A - RECOIL STARTER BODY ASS'Y SINCE F024131 HIT-6692991.A3 6692991	£33.01	£39.61
152 - STARTER HANDLE TILL F024130 HIT-6693240.A1 6693240	£16.35	£19.62
153 - RECOIL STARTER BODY COMP TILL F024130 HIT-6693038.A3 6693038	-
154 - ROPE TILL F024130 HIT-6693168.A52 6693168	£2.82	£3.39
155 - RECOIL SPRING TILL F024130 HIT-6693138.A9 6693138	£12.10	£14.52
156 - SPRING CASE ASS'Y TILL F024130 ORIGINAL PART HIT-6693101.A8 6693101	-
158 - STARTER PULLEY TILL F024130 HIT-6693075.A0 6693075	£6.86	£8.23
159 - SPECIAL WASHER 5.2X15 TILL F024130 HIT-6687947.A17 6687947	-
160 - TAPPING SCREW D5X14 TILL F024130 HIT-6685275.A62 6685275	-
161 - HEX. NUT M8 TILL F024130 HIT-6684612.A112 6684612	-
162 - STARTER BASE TILL F024130 HIT-6693468.A2 6693468	-
163 - TAPPING SCREW D4.5X14 TILL F024130 HIT-6685153.A5 6685153	-
164 - HEX. HOLE BOLT 4X18WS TILL F024130 HIT-6695508.A57 6695508	£1.67	£2.00
165 - STARTER PULLEY ASS'Y TILL F024130 HIT-6693408.A12 6693408	£35.37	£42.44
167 - SPRING PLATE TILL F024130 REPLACED PART HIT-6693252.A0 6693252	-
168 - SPRING CASE ASS'Y TILL F024130 REPLACED PART HIT-6693099.A0 6693099	-
169 - STARTER BUSH TILL F024130 REPLACED PART HIT-6689170.A2 6689170	-
170 - STARTER HANDLE SINCE F024131 HIT-6684680.A14 6684680	£5.87	£7.04
171 - RECOIL STARTER BODY COMP. SINCE F024131 HIT-6693040.A3 6693040	£11.14	£13.37
172 - STARTER ROPE 3.5X860 SINCE F024131 HIT-6684674.A80 6684674	£5.70	£6.84
173 - RECOIL SPRING SINCE F024131 HIT-6684675.A27 6684675	£8.82	£10.58
174 - STARTER PULLEY SINCE F024131 HIT-6693081.A7 6693081	-
175 - DAMPER SPRING SINCE F024131 HIT-6684677.A98 6684677	£6.66	£7.99
176 - CAM PLATE SINCE F024131 HIT-6692938.A5 6692938	£5.64	£6.77
177 - SET SCREW SINCE F024131 HIT-6684679.A140 6684679	£2.98	£3.57
178 - HEX. HOLE BOLT 4X20 PS SINCE F024131 HIT-6695503.A1 6695503	-
179 - STARTER PULLEY ASS'Y SINCE F024131 HIT-6684681.A100 6684681	£18.16	£21.79
180 - STARTER PAWL SINCE F024131 HIT-6684685.A88 6684685	£5.07	£6.08
181 - STARTER PAWL SPRING SINCE F024131 HIT-6684684.A23 6684684	£3.29	£3.95
182 - D4E RETAINING RING SINCE F024131 HIT-6685101.A98 6685101	-
191 - PUMP BODY COMP. HIT-6684879.A24 6684879	£35.37	£42.44
192 - PRIMING PUMP COMP. HIT-6684687.A15 6684687	£9.27	£11.12
193 - DIAPHRAGM COVER HIT-6684688.A85 6684688	£5.70	£6.84
194 - PRIMING BODY HIT-6684689.A14 6684689	£5.87	£7.04
195 - METERING DIAPHRAGM COMP. HIT-6690827.A52 6690827	£14.02	£16.83
196 - DIAPHRAGM GASKET HIT-6684691.A12 6684691	£5.70	£6.84
197 - PUMP DIAPHRAGM HIT-6684693.A41 6684693	£5.70	£6.84
198 - PUMP GASKET HIT-6691457.A26 6691457	£8.48	£10.18
201 - STOP RING HIT-6684696.A46 6684696	-
202 - SWIVEL HIT-6684697.A119 6684697	-
203 - THROTTLE SET SCREW HIT-6684870.A51 6684870	-
204 - CABLE ADJUSTER STAY HIT-6684873.A27 6684873	-
205 - LOCK NUT M6 HIT-6684872.A56 6684872	-
206 - CABLE ADJUSTER HIT-6684871.A23 6684871	-
207 - CLEANER PACKING HIT-6684875.A28 6684875	-
208 - SET SCREW HIT-6684699.A82 6684699	-
209 - THRUST WASHER HIT-6684874.A52 6684874	-
210 - INLET SCREEN HIT-6684700.A59 6684700	-
216 - O-RING HIT-6684695.A151 6684695	£1.67	£2.00
217 - MAIN JET #43 HIT-6691848.A7 6691848	£8.77	£10.52
231 - DRIVE SHAFT 1533L HIT-6689478.A11 6689478	£28.76	£34.51
232 - DRAIVE SHAFT PIPE COMP. HIT-6689407.A9 6689407	£53.33	£64.00
233 - BUSHING ASS'Y HIT-6697866.A7 6697866	-
234 - HEX.NUT 6 HIT-6684835.A1 6684835	£1.67	£2.00
235 - LOOP HANDLE BLACK HIT-6691049.A1 6691049	-
236 - BARRIER BLACK HIT-6691231.A4 6691231	-
237 - BOLT 6X43/P (BLACK) HIT-6684838.A32 6684838	£1.67	£2.00
238 - TAPPING SCREW 5X20 HIT-6695255.A15 6695255	-
239 - BRAKE SHAFT WASHER HIT-6689681.A31 6689681	£1.67	£2.00
240 - HANDLE GRIP HIT-6691098.A23 6691098	£10.90	£13.08
241 - LIFTING METAL ASS'Y HIT-6689275.A8 6689275	-
242 - THROTTLE LEVER ASS'Y 1 HIT-6693748.A4 6693748	£42.08	£50.49
243 - THROTTLE WIRE COMP. HIT-6693978.A6 6693978	£22.29	£26.75
244 - THROTTLE WIRE HIT-6694022.A2 6694022	-
245 - STOP SWITCH COMP. HIT-6687459.A3 6687459	£17.33	£20.80
246 - PROTECTION TUBE 7X175 HIT-6687526.A4 6687526	-
247 - TRIGGER LOCK OUT HIT-6684721.A6 6684721	£5.17	£6.20
248 - RETURN SPRING HIT-6684722.A41 6684722	£1.67	£2.00
249 - BLIND PLUG HIT-6684724.A31 6684724	-
250 - SCREW M5X20 HIT-6684803.A18 6684803	-
251 - CONTAL NUT 5 HIT-6684727.A6 6684727	£1.67	£2.00
252 - SCREW M4X20 (BLACK) HIT-6684725.A9 6684725	-
253 - THROTTLE LEVER HIT-6684804.A12 6684804	£6.86	£8.23
281 - GEAR CASE SET PN TILL J035780 HIT-6696497.A5 6696497	£60.35	£72.42
281B - GEAR CASE ASS'Y SINCE J035871 HIT-6601215.A7 6601215	-
282 - HEX. HOLE BOLT M5X25/S TILL J035780 HIT-6684709.A180 6684709	£1.67	£2.00
282A - HEX. SOCKET HD. BOLT M5X12 SINCE J035781 HIT-6684829.A4 6684829	-
283 - SPRING WASHER 5 SINCE J035781 HIT-6684834.A58 6684834	£1.67	£2.00
284 - RETAINING RING C-TYPE D26 HIT-6695294.A53 6695294	-
285 - STOP RING OUTER 10 TILL J035780 HIT-6695315.A1 6695315	-
285A - STOP RING C-10 1 HIT-6684821.A2 6684821	£1.67	£2.00
286 - BALL BEARING #6000Z 1 HIT-6695526.A15 6695526	-
*287 - BALL BEARING #6000 1 HIT-6695524.A24 6695524	-
*287 - BALL BEARING #6000 2 HIT-6695524.A25 6695524	-
288 - GEAR CASE 26 DIA TILL J035780 HIT-6688770.A14 6688770	-
288A - GEAR CASE SINCE J035781 HIT-6697738.A9 6697738	-
289 - HEX.HOLE BOLT M5X12/S TILL J035780 HIT-6684667.A8 6684667	£1.67	£2.00
289A - HEX. SOCKET HD. BOLT M5X30 S SINCE J035781 HIT-6684786.A6 6684786	£1.67	£2.00
290 - OILING BOLT TILL J035780 HIT-6689109.A1 6689109	-
290A - BOLT (W/PLUS) M6X8 SINCE J035781 HIT-6684737.A6 6684737	-
291 - BALL BEARING 609 TILL J035780 HIT-6684734.A21 6684734	-
292 - GEAR SHAFT TILL J035780 HIT-6688924.A1 6688924	-
292A - GEAR SHAFT SINCE J035781 HIT-6697739.A2 6697739	-
293 - BALL BEARING 6201D 1 HIT-6695554.A31 6695554	-
293A - BALL BEARING #6201DD 1 HIT-6695555.A1 6695555	-
294 - STOP RING C-32 1 HIT-6695295.A2 6695295	£1.67	£2.00
295 - CUTTER HOLDER TILL J035780 HIT-6689032.A17 6689032	£15.16	£18.19
295B - CUTTER HOLDER ASS'Y SINCE J035871 HIT-6601216.A1 6601216	-
296 - CUTTER HOLDER CAP TILL J035780 HIT-6689055.A15 6689055	£12.10	£14.52
296A - CUTTER HOLDER CAP SINCE J035781 HIT-6699009.A2 6699009	-
297 - NUT COVER SINCE J035781 HIT-6697792.A8 6697792	£4.28	£5.13
298 - FIXING NUT M10X1.25 TILL J035780 HIT-6689073.A32 6689073	£8.32	£9.99
298A - LEFT HAND NYLON NUT M10 SINCE J035781 HIT-6698658.A5 6698658	£8.59	£10.31
299 - GEAR CASE WASHER TILL J035780 HIT-6689159.A33 6689159	-
300 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A46 6684714	£1.67	£2.00
301 - COVER BRACKET 1 HIT-6690294.A3 6690294	-
301A - COVER BRACKET 26 TILL J035780 HIT-6690315.A10 6690315	-
301B - COVER BRACKET D26 SINCE J035781 HIT-6697867.A5 6697867	-
302 - BLADE GUARD 26 CE TILL D291600 HIT-6690242.A11 6690242	£18.84	£22.61
302A - BLADE GUARD 26CE SINCE D291601 HIT-6690276.A8 6690276	£20.01	£24.01
303 - GUARD HOLDER HIT-6684748.A10 6684748	-
304 - COVER GUARD TILL D291600 HIT-6690372.A8 6690372	£2.81	£3.37
304A - BLADE GUARD SINCE D261601 HIT-6690376.A15 6690376	£9.34	£11.21
305 - KNIFE TILL D291600 HIT-6693386.A27 6693386	£8.53	£10.24
305A - KNIFE SINCE D291601 HIT-6684750.A23 6684750	£3.64	£4.37
306 - SCREW 5X12/S TILL D291600 HIT-6695334.A24 6695334	£1.67	£2.00
306A - TAPPING SCREW 4X14 SINCE D291601 HIT-6684751.A78 6684751	£1.67	£2.00
307 - GEAR/PINION SET 1 HIT-6688875.A12 6688875	-
307A - GEAR PINION SET 1 HIT-6697741.A8 6697741	-
308 - NUT M5 TILL D291600 HIT-6684965.A55 6684965	£1.67	£2.00
*309 - TAPPING SCREW 5X20 SINCE D291601 HIT-6684753.A59 6684753	£1.67	£2.00
*309 - TAPPING SCREW 5X20 TILL H122650 HIT-6684753.A60 6684753	£1.67	£2.00
*310 - KNIFE SINCE D291601 HIT-6684754.A32 6684754	£6.64	£7.97
*310 - KNIFE TILL H122650 HIT-6684754.A33 6684754	£6.64	£7.97
501 - HEX. BAR WRENCH 4MM HIT-6684813.A9 6684813	-
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A3 6684764	£7.64	£9.17
504A - PROTECTIVE GLASSES HIT-875769.A151 875769	-
505 - HEX. WRENCH 3 HIT-6693520.A9 6693520	-
507 - SHOULDER STRAP S HIT-6695795.A13 6695795	-
510 - NYLON HEAD BF-5 TILL TL041840 HIT-6695784.A11 6695784	£27.81	£33.37
511 - MOUNTING NUT L-M10X1.25 TILL TL041840 HIT-6684756.A1 6684756	£10.80	£12.96
512 - MOUNTING NUT L-M8X1.25 TILL TL041840 HIT-6689624.A8 6689624	-
513 - CUTTING BODY TILL TL041840 HIT-6684757.A15 6684757	£15.38	£18.45
514 - SPECIAL NUT TILL TL041840 HIT-6684758.A1 6684758	£6.18	£7.41
515 - REEL SPRING TILL TL041840 HIT-6684759.A15 6684759	£3.56	£4.27
516 - SPOOL TILL TL041840 HIT-6684760.A1 6684760	£13.48	£16.18
517 - CUTTING BODY CAP TILL TL041840 HIT-6684761.A15 6684761	£21.34	£25.61
518 - EYELET TILL TL041840 HIT-6684762.A1 6684762	£3.56	£4.27
519 - SURE TAP MANUAL P/L 9 TILL TL041840 HIT-6697805.A0 6697805	-
520 - WINDING PROTECTOR TILL TL041840 HIT-6684763.A10 6684763	£2.98	£3.57
521 - NYLON CORD CUTTER SINCE TL041841 HIT-6601148.A6 6601148	£25.68	£30.81
522 - CASE SINCE TL041841 HIT-6601149.A11 6601149	-
523 - NUT SINCE TL041841 HIT-6601150.A6 6601150	-
524 - REEL SPRING SINCE TL041841 HIT-6693380.A6 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL041841 HIT-6601151.A11 6601151	-
526 - COVER SINCE TL041841 HIT-6601152.A6 6601152	-
527 - EYELET SINCE TL041841 HIT-6684810.A22 6684810	£3.29	£3.95

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-290S Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
