Hitachi / Hikoki TBC-290D Engine Brush Cutter Spare Parts

Hitachi / Hikoki TBC-290D Engine Brush Cutter Spare Parts
Home Details Reviews Delivery
An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-290D Engine Brush Cutter
Ex VAT Inc VAT
1 - SPARK PLUG ASS'Y RCJ6Y HIT-6699326.A3 6699326 £5.70 £6.84
2 - CYLINDER SET HIT-6685484.A1 6685484 -
3 - HEX. HOLE BOLT M5X16/S HIT-6684903.A30 6684903 -
4 - CYLINDER GASKET HIT-6685746.A7 6685746 £2.86 £3.43
5 - PISTON RING 34.5 HIT-6686130.A1 6686130 -
6 - PISTON SET HIT-6685896.A3 6685896 -
7 - PISTON PIN HIT-6686016.A6 6686016 -
8 - CIRCLIP HIT-6685078.A6 6685078 -
9 - CRANK SHAFT COMP HIT-6696499.A4 6696499 -
10 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A104 6684899 -
11 - HIGH TENSION SCREW 4X18WS HIT-6695407.A35 6695407 -
12 - INSULATOR TUBE 1 HIT-6688319.A9 6688319 £1.67 £2.00
14A - IGNITION COIL ASS'Y HIT-6699772.A21 6699772 -
15 - HIGH TENSION CORD 140L HIT-6687888.A8 6687888 £3.89 £4.67
16 - RUBBER CAP HIT-6684602.A21 6684602 -
17 - LEAD WIRE ASS'Y HIT-6697836.A3 6697836 -
18 - WASHER T1.6 HIT-6684600.A45 6684600 -
31 - CRANK CASE ASS'Y HIT-6686580.A0 6686580 -
32 - OIL SEAL TB 12227 HIT-6684607.A61 6684607 £4.07 £4.88
33 - BALL BEARING 6001 C3 HIT-6684608.A137 6684608 £5.70 £6.84
34 - CRANK CASE GASKET HIT-6686721.A0 6686721 £1.67 £2.00
*35 - GEAR SHAFT SHIM 0.10 HIT-6689177.A26 6689177 -
*35 - GEAR SHAFT SHIM 0.15 HIT-6689178.A9 6689178 -
*35 - GEAR SHAFT SHIM 0.20 HIT-6684604.A52 6684604 -
*35 - GEAR SHAFT SHIM 0.30 HIT-6684605.A29 6684605 -
36 - MAGNETO ROTOR COMP. HIT-6687374.A1 6687374 -
37 - HEX. NUT M8 HIT-6684612.A56 6684612 -
38 - SMALL WASHER 8 HIT-6695184.A7 6695184 -
39 - HEX. HOLE BOLT M5X16/S HIT-6684903.A31 6684903 -
40 - CLUTCH WASHER B HIT-6689645.A38 6689645 £1.67 £2.00
51 - INLET MANIFOLD GASKET HIT-6689895.A2 6689895 £1.67 £2.00
52 - INSULATOR SET HIT-6689972.A1 6689972 £6.59 £7.91
53 - HEX. HOLE BOLT M5X25WS HIT-6695515.A21 6695515 £1.67 £2.00
54 - CARBURETOR PACKING HIT-6684616.A17 6684616 £1.67 £2.00
55 - CARBURETOR SET WYJ392 HIT-6690500.A1 6690500 -
56 - CHOKE PLATE 1.0 HIT-6691278.A8 6691278 £1.67 £2.00
57 - CLEANER BODY COMP. HIT-6690120.A29 6690120 £12.32 £14.78
58 - CLEANER SPONGE HIT-6690365.A44 6690365 £1.67 £2.00
59 - CLEANER COVER ASS'Y HIT-6690421.A15 6690421 £14.48 £17.38
60 - COVER FIXING BOLT COMP. HIT-6698730.A35 6698730 £5.52 £6.63
61 - SCREW M5X55 HIT-6694914.A33 6694914 -
62 - SMALL WASHER 5 HIT-6684864.A5 6684864 -
63 - CHOKE CONTROL LEVER HIT-6691239.A31 6691239 £2.98 £3.57
64 - TANK COMP. WHT HIT-6691588.A7 6691588 £11.68 £14.02
65 - COLLAR C HIT-6684623.A8 6684623 £1.67 £2.00
66 - FUEL PIPE GROMMET HIT-6688156.A5 6688156 -
67 - FUEL PIPE 3X5X85 HIT-6684880.A18 6684880 -
68A - PUMP FILTER BODY COMP HIT-66A3864.A11 66A3864 -
69 - CLIP D6 HIT-6685198.A21 6685198 -
70 - FUEL PIPE ASS'Y HIT-6688169.A8 6688169 £4.32 £5.19
71 - HEX. HOLE BOLT 5X20PS HIT-6695506.A1 6695506 -
72 - TANK CAP ASS'Y HIT-6685049.A38 6685049 £9.94 £11.93
73 - TANK CAP CHAIN HIT-6684625.A56 6684625 -
74 - STAND HIT-6694793.A6 6694793 -
75 - TAP SCREW 4X14 P HIT-6695280.A29 6695280 £1.67 £2.00
76 - BOLT WASHER M4 HIT-6685070.A3 6685070 £1.67 £2.00
77 - S.WASHER 5 HIT-6684662.A26 6684662 £1.67 £2.00
91 - CLUTCH SHOE COMP. 2 HIT-6688616.A0 6688616 £12.82 £15.38
92 - CLUTCH SPRING HIT-6689430.A9 6689430 £3.89 £4.67
93 - CLUTCH WASHER B HIT-6684642.A12 6684642 £1.67 £2.00
94 - CLUTCH PLATE A 0.5 HIT-6684645.A22 6684645 £1.67 £2.00
95 - STEP BOLT HIT-6689627.A22 6689627 £1.67 £2.00
96 - CLUTCH SET ASSY HIT-6688484.A6 6688484 -
97 - FAN CASE COMP. HIT-6687019.A1 6687019 -
98 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A26 6695512 -
99 - ANTI-VIBE RUBBER HIT-6691838.A7 6691838 -
100 - TAPPING SCREW D5X14 HIT-6685275.A14 6685275 -
101 - PIPE HOLDER HIT-6689656.A1 6689656 -
102 - STOP RING C-12 OUTER HIT-6684664.A25 6684664 £1.67 £2.00
103 - HEX. HOLE BOLT M5X25/S HIT-6684709.A61 6684709 £1.67 £2.00
104A - HEX. HOLE BOLT 4X12WS HIT-6695507.A12 6695507 -
105 - CLUTCH SHAFT COMP HIT-6688597.A1 6688597 £20.11 £24.13
106 - STOP RING R-32 INNER HIT-6695304.A1 6695304 -
107 - BEARING CASE HIT-6686667.A2 6686667 -
108 - BALL BEARING #6201ZZ 1 HIT-6695553.A6 6695553 -
109 - PRIMARY CORD GROMMET HIT-6688057.A14 6688057 -
110 - MUFFLER PROTECTOR HIT-6692803.A0 6692803 £13.79 £16.55
111 - SPARK PLUG CAP ASS'Y HIT-6687468.A59 6687468 £3.64 £4.37
112 - TAPPING SCREW D4.5X12 HIT-6684637.A14 6684637 £1.67 £2.00
113 - MUFFLER GASKET HIT-6692732.A6 6692732 £1.67 £2.00
114 - HEAT SHIELD HIT-6687260.A0 6687260 £5.77 £6.92
115 - MUFFLER SET HIT-6692489.A7 6692489 -
116 - HEX. HOLE BOLT M6X55 HIT-6684638.A11 6684638 £1.67 £2.00
117 - BOLT WASHER 6 HIT-6684639.A128 6684639 £1.67 £2.00
118 - MUFFLER SPECIAL GASKET HIT-6692887.A2 6692887 -
119 - TAIL PIPE SET HIT-6692669.A0 6692669 -
120 - SCREW 4X8/S HIT-6695325.A3 6695325 -
123 - BENT WASHER 8 HIT-6684648.A40 6684648 £1.67 £2.00
151 - RECOIL STARTER ASS'Y HIT-6692969.A0 6692969 £25.30 £30.36
152 - STARTER HANDLE HIT-6693227.A8 6693227 -
153 - ROPE GUIDE HIT-6693135.A6 6693135 -
154 - RECOIL STARTER BODY HIT-6693036.A1 6693036 -
155 - RECOIL SPRING HIT-6693111.A2 6693111 £15.16 £18.19
156 - ROPE 3.5X890 HIT-6693157.A2 6693157 -
157 - STARTER ROPE REEL HIT-6693057.A1 6693057 £8.18 £9.81
158 - ROPE REEL WASHER HIT-6693419.A1 6693419 -
159 - SET SCREW HIT-6693632.A1 6693632 -
160 - HEX.HOLE BOLT 4X18PS HIT-6695502.A0 6695502 £1.67 £2.00
161 - STARTER PULLEY ASS'Y HIT-6693394.A2 6693394 £9.42 £11.30
162 - STARTER PAWL HIT-6693299.A6 6693299 £3.29 £3.95
163 - STARTER PAWL SPRING HIT-6693345.A3 6693345 £3.89 £4.67
191 - PUMP BODY COMP. HIT-6684879.A50 6684879 £35.37 £42.44
192 - PRIMING PUMP COMP. HIT-6684687.A66 6684687 £9.27 £11.12
193 - DIAPHRAGM COVER HIT-6684688.A33 6684688 £5.70 £6.84
194 - PRIMING BODY HIT-6684689.A66 6684689 £5.87 £7.04
195 - METERING DIAPHRAGM COMP. HIT-6690827.A26 6690827 £14.02 £16.83
196 - DIAPHRAGM GASKET HIT-6684691.A59 6684691 £5.70 £6.84
197 - PUMP DIAPHRAGM HIT-6684693.A130 6684693 £5.70 £6.84
198 - PUMP GASKET HIT-6691457.A52 6691457 £8.48 £10.18
201 - STOP RING HIT-6684696.A144 6684696 -
202 - SWIVEL HIT-6684697.A45 6684697 -
203 - THROTTLE SET SCREW HIT-6684870.A22 6684870 -
204 - CABLE ADJUSTER STAY HIT-6684873.A51 6684873 -
205 - LOCK NUT M6 HIT-6684872.A28 6684872 -
206 - CABLE ADJUSTER HIT-6684871.A43 6684871 -
207 - CLEANER PACKING HIT-6684875.A54 6684875 -
208 - SET SCREW HIT-6684699.A36 6684699 -
209 - THRUST WASHER HIT-6684874.A23 6684874 -
210 - INLET SCREEN HIT-6684700.A157 6684700 -
216 - O-RING HIT-6684695.A69 6684695 £1.67 £2.00
217 - MAIN JET #43 HIT-6691848.A1 6691848 £8.77 £10.52
231 - DRIVE SHAFT 1533L HIT-6689478.A0 6689478 £28.76 £34.51
232 - DRAIVE SHAFT PIPE COMP. HIT-6689407.A0 6689407 £53.33 £64.00
233 - BUSHING ASS'Y HIT-6697866.A1 6697866 -
234 - LIFTING METAL 1 HIT-6689274.A2 6689274 -
235 - LIFTING METAL COLLAR 26 TILL J034790 HIT-6689258.A2 6689258 -
236 - HEX. HOLE BOLT 5X30.P TILL J034790 HIT-6695501.A3 6695501 -
237 - SPECIAL NUT TILL J034790 HIT-6689100.A1 6689100 -
238 - HANDLE GRIP HIT-6684708.A14 6684708 £3.56 £4.27
239 - HEX. HOLE BOLT M5X25/S HIT-6684709.A60 6684709 £1.67 £2.00
240 - HANDLE BRACKET A HIT-6684710.A8 6684710 -
241 - HANDLE BRACKET B HIT-6684711.A2 6684711 £17.88 £21.45
242 - CUSHION RUBBER HIT-6691187.A0 6691187 -
243 - HANDLE BRACKET C HIT-6684713.A3 6684713 £8.22 £9.87
244 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A72 6684714 £1.67 £2.00
245 - HIP PAD HIT-6689291.A1 6689291 -
246 - CLAMP B. HIT-6684715.A4 6684715 -
247 - LEFT HANDLE HIT-6696093.A8 6696093 £17.80 £21.36
248 - RIGHT HANDLE HIT-6691080.A2 6691080 £16.15 £19.38
249 - THROTTLE LEVER ASS'Y 19 HIT-6693766.A6 6693766 £42.70 £51.24
250 - TRIGGER LOCK OUT HIT-6684721.A28 6684721 £5.17 £6.20
251 - RETURN SPRING HIT-6684722.A20 6684722 £1.67 £2.00
252 - THROTTLE LEVER HIT-6684723.A11 6684723 -
253 - BLIND PLUG TILL D034100 HIT-6684724.A13 6684724 -
254 - SCREW M4X20 (BLACK) HIT-6684725.A30 6684725 -
255 - SCREW 5X30 (BLACK) HIT-6684726.A9 6684726 £1.67 £2.00
256 - CONTAL NUT 5 HIT-6684727.A27 6684727 £1.67 £2.00
257 - STOP SWITCH TILL D034100 HIT-6687460.A3 6687460 -
257A - STOP SWITCH SINCE D034101 HIT-6687461.A3 6687461 -
258 - THROTTLE WIRE HIT-6694023.A5 6694023 £15.11 £18.13
259 - PROTECTION TUBE HIT-6687546.A6 6687546 -
260 - THROTTLE WIRE COMP. TILL D034100 HIT-6693979.A0 6693979 -
260A - THROTTLE WIRE COMP. SINCE D034101 HIT-6693980.A8 6693980 £30.92 £37.11
261 - LIFTING METAL ASS'Y SINCE J034791 HIT-6689275.A0 6689275 -
281 - GEAR CASE SET PN TILL J035780 HIT-6696497.A15 6696497 £60.35 £72.42
281B - GEAR CASE ASS'Y SINCE J035871 HIT-6601215.A0 6601215 -
282 - HEX. HOLE BOLT M5X25/S TILL J035780 HIT-6684709.A62 6684709 £1.67 £2.00
282A - HEX. SOCKET HD. BOLT M5X12 SINCE J035781 HIT-6684829.A32 6684829 -
283 - SPRING WASHER 5 SINCE J035781 HIT-6684834.A24 6684834 £1.67 £2.00
284 - RETAINING RING C-TYPE D26 HIT-6695294.A2 6695294 -
285 - STOP RING OUTER 10 TILL J035780 HIT-6695315.A23 6695315 -
285A - STOP RING C-10 1 HIT-6684821.A25 6684821 £1.67 £2.00
286 - BALL BEARING #6000Z 1 HIT-6695526.A24 6695526 -
*287 - BALL BEARING #6000 1 HIT-6695524.A53 6695524 -
*287 - BALL BEARING #6000 2 HIT-6695524.A54 6695524 -
288 - GEAR CASE 26 DIA TILL J035780 HIT-6688770.A24 6688770 -
288A - GEAR CASE SINCE J035781 HIT-6697738.A10 6697738 -
289 - HEX.HOLE BOLT M5X12/S TILL J035780 HIT-6684667.A92 6684667 £1.67 £2.00
289A - HEX. SOCKET HD. BOLT M5X30 S SINCE J035781 HIT-6684786.A55 6684786 £1.67 £2.00
290 - OILING BOLT TILL J035780 HIT-6689109.A23 6689109 -
290A - BOLT (W/PLUS) M6X8 SINCE J035781 HIT-6684737.A39 6684737 -
291 - BALL BEARING 609 TILL J035780 HIT-6684734.A6 6684734 -
292 - GEAR SHAFT TILL J035780 HIT-6688924.A19 6688924 -
292A - GEAR SHAFT SINCE J035781 HIT-6697739.A1 6697739 -
293 - BALL BEARING 6201D 1 HIT-6695554.A9 6695554 -
293A - BALL BEARING #6201DD 1 HIT-6695555.A9 6695555 -
294 - STOP RING C-32 1 HIT-6695295.A62 6695295 £1.67 £2.00
295 - CUTTER HOLDER TILL J035780 HIT-6689032.A3 6689032 £15.16 £18.19
295B - CUTTER HOLDER ASS'Y SINCE J035871 HIT-6601216.A8 6601216 -
296 - CUTTER HOLDER CAP TILL J035780 HIT-6689055.A18 6689055 £12.10 £14.52
296A - CUTTER HOLDER CAP SINCE J035781 HIT-6699009.A10 6699009 -
297 - NUT COVER SINCE J035781 HIT-6697792.A14 6697792 £4.28 £5.13
298 - FIXING NUT M10X1.25 TILL J035780 HIT-6689073.A12 6689073 £8.32 £9.99
298A - LEFT HAND NYLON NUT M10 SINCE J035781 HIT-6698658.A0 6698658 £8.59 £10.31
299 - GEAR CASE WASHER TILL J035780 HIT-6689159.A22 6689159 -
300 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A73 6684714 £1.67 £2.00
301 - COVER BRACKET 1 HIT-6690294.A11 6690294 -
301A - COVER BRACKET 26 TILL J035780 HIT-6690315.A25 6690315 -
301B - COVER BRACKET D26 SINCE J035781 HIT-6697867.A10 6697867 -
302 - BLADE GUARD 26 CE TILL D291600 HIT-6690242.A14 6690242 £18.84 £22.61
302A - BLADE GUARD 26CE SINCE D291601 HIT-6690276.A14 6690276 £20.01 £24.01
303 - GUARD HOLDER HIT-6684748.A38 6684748 -
304 - COVER GUARD TILL D291600 HIT-6690372.A17 6690372 £2.81 £3.37
304A - BLADE GUARD SINCE D261601 HIT-6690376.A19 6690376 £9.34 £11.21
305 - KNIFE TILL D291600 HIT-6693386.A0 6693386 £8.53 £10.24
305A - KNIFE SINCE D291601 HIT-6684750.A73 6684750 £3.64 £4.37
306 - SCREW 5X12/S TILL D291600 HIT-6695334.A1 6695334 £1.67 £2.00
306A - TAPPING SCREW 4X14 SINCE D291601 HIT-6684751.A20 6684751 £1.67 £2.00
307 - GEAR/PINION SET 1 HIT-6688875.A17 6688875 -
307A - GEAR PINION SET 1 HIT-6697741.A9 6697741 -
308 - NUT M5 TILL D291600 HIT-6684965.A4 6684965 £1.67 £2.00
*309 - TAPPING SCREW 5X20 SINCE D291601 HIT-6684753.A8 6684753 £1.67 £2.00
*309 - TAPPING SCREW 5X20 TILL H122650 HIT-6684753.A9 6684753 £1.67 £2.00
*310 - KNIFE SINCE D291601 HIT-6684754.A66 6684754 £6.64 £7.97
*310 - KNIFE TILL H122650 HIT-6684754.A67 6684754 £6.64 £7.97
501 - HEX. BAR WRENCH 4MM HIT-6684813.A51 6684813 -
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A54 6684764 £7.64 £9.17
503B - CUTTER COVER HIT-6684768.A28 6684768 -
504A - PROTECTIVE GLASSES HIT-875769.A71 875769 -
505 - HEX. WRENCH 3 HIT-6693520.A1 6693520 -
506 - BLADE B3/10/2.0 HIT-6695791.A4 6695791 £20.11 £24.13
507 - SHOULDER HARNESS D3X HIT-6695796.A2 6695796 £25.30 £30.36
508 - PROTECTION COVER B TILL J035780 HIT-6688995.A4 6688995 £4.81 £5.77
601 - NAME PLATE 1 HIT-6694203.A0 6694203 -
602 - SYMBOL MARK 1 HIT-6694631.A0 6694631 -
603 - CAUTION MARK TANAKA HIT-6697851.A1 6697851 -

Recently Viewed


x
Powered by kartris
