Hitachi / Hikoki TBC-290 Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-290 Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG ASS'Y RCJ6Y HIT-6699326.A2 6699326	£5.70	£6.84
2 - CYLINDER SET HIT-6685484.A0 6685484	-
3 - HEX. HOLE BOLT M5X16/S HIT-6684903.A28 6684903	-
4 - CYLINDER GASKET HIT-6685746.A8 6685746	£2.86	£3.43
5 - PISTON RING 34.5 HIT-6686130.A0 6686130	-
6 - PISTON SET HIT-6685896.A2 6685896	-
7 - PISTON PIN HIT-6686016.A7 6686016	-
8 - CIRCLIP HIT-6685078.A5 6685078	-
9 - CRANK SHAFT COMP HIT-6696499.A3 6696499	-
10 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A105 6684899	-
11 - HIGH TENSION SCREW 4X18WS HIT-6695407.A34 6695407	-
12 - INSULATOR TUBE 1 HIT-6688319.A8 6688319	£1.67	£2.00
14A - IGNITION COIL ASS'Y HIT-6699772.A22 6699772	-
15 - HIGH TENSION CORD 140L HIT-6687888.A9 6687888	£3.89	£4.67
16 - RUBBER CAP HIT-6684602.A20 6684602	-
17 - LEAD WIRE ASS'Y HIT-6697836.A2 6697836	-
18 - WASHER T1.6 HIT-6684600.A46 6684600	-
31 - CRANK CASE ASS'Y HIT-6686580.A1 6686580	-
32 - OIL SEAL TB 12227 HIT-6684607.A62 6684607	£4.07	£4.88
33 - BALL BEARING 6001 C3 HIT-6684608.A136 6684608	£5.70	£6.84
34 - CRANK CASE GASKET HIT-6686721.A1 6686721	£1.67	£2.00
*35 - GEAR SHAFT SHIM 0.10 HIT-6689177.A27 6689177	-
*35 - GEAR SHAFT SHIM 0.15 HIT-6689178.A8 6689178	-
*35 - GEAR SHAFT SHIM 0.20 HIT-6684604.A53 6684604	-
*35 - GEAR SHAFT SHIM 0.30 HIT-6684605.A28 6684605	-
36 - MAGNETO ROTOR COMP. HIT-6687374.A0 6687374	-
37 - HEX. NUT M8 HIT-6684612.A57 6684612	-
38 - SMALL WASHER 8 HIT-6695184.A8 6695184	-
39 - HEX. HOLE BOLT M5X16/S HIT-6684903.A29 6684903	-
40 - CLUTCH WASHER B HIT-6689645.A39 6689645	£1.67	£2.00
51 - INLET MANIFOLD GASKET HIT-6689895.A1 6689895	£1.67	£2.00
52 - INSULATOR SET HIT-6689972.A2 6689972	£6.59	£7.91
53 - HEX. HOLE BOLT M5X25WS HIT-6695515.A24 6695515	£1.67	£2.00
54 - CARBURETOR PACKING HIT-6684616.A16 6684616	£1.67	£2.00
55 - CARBURETOR SET WYJ392 FOR EUROPE HIT-6690500.A0 6690500	-
56 - CHOKE PLATE 1.0 HIT-6691278.A9 6691278	£1.67	£2.00
57 - CLEANER BODY COMP. HIT-6690120.A28 6690120	£12.32	£14.78
58 - CLEANER SPONGE HIT-6690365.A43 6690365	£1.67	£2.00
59 - CLEANER COVER ASS'Y HIT-6690421.A16 6690421	£14.48	£17.38
60 - COVER FIXING BOLT COMP. HIT-6698730.A34 6698730	£5.52	£6.63
61 - SCREW M5X55 HIT-6694914.A32 6694914	-
62 - SMALL WASHER 5 HIT-6684864.A4 6684864	-
63 - CHOKE CONTROL LEVER HIT-6691239.A30 6691239	£2.98	£3.57
64 - TANK COMP. WHT HIT-6691588.A8 6691588	£11.68	£14.02
65 - COLLAR C HIT-6684623.A9 6684623	£1.67	£2.00
66 - FUEL PIPE GROMMET HIT-6688156.A4 6688156	-
67 - FUEL PIPE 3X5X85 HIT-6684880.A17 6684880	-
68A - PUMP FILTER BODY COMP HIT-66A3864.A10 66A3864	-
69 - CLIP D6 HIT-6685198.A20 6685198	-
70 - FUEL PIPE ASS'Y HIT-6688169.A9 6688169	£4.32	£5.19
71 - HEX. HOLE BOLT 5X20PS HIT-6695506.A0 6695506	-
72 - TANK CAP ASS'Y HIT-6685049.A37 6685049	£9.94	£11.93
73 - TANK CAP CHAIN HIT-6684625.A55 6684625	-
74 - STAND HIT-6694793.A7 6694793	-
75 - TAP SCREW 4X14 P HIT-6695280.A28 6695280	£1.67	£2.00
76 - BOLT WASHER M4 HIT-6685070.A2 6685070	£1.67	£2.00
77 - S.WASHER 5 HIT-6684662.A27 6684662	£1.67	£2.00
78 - CARBURETOR SET WYK131 FOR AUS HIT-6690499.A0 6690499	-
91 - CLUTCH SHOE COMP. 2 HIT-6688616.A1 6688616	£12.82	£15.38
92 - CLUTCH SPRING HIT-6689430.A8 6689430	£3.89	£4.67
93 - CLUTCH WASHER B HIT-6684642.A11 6684642	£1.67	£2.00
94 - CLUTCH PLATE A 0.5 HIT-6684645.A23 6684645	£1.67	£2.00
95 - STEP BOLT HIT-6689627.A21 6689627	£1.67	£2.00
96 - CLUTCH SET ASSY HIT-6688484.A7 6688484	-
97 - FAN CASE COMP. HIT-6687019.A0 6687019	-
98 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A25 6695512	-
99 - ANTI-VIBE RUBBER HIT-6691838.A6 6691838	-
100 - TAPPING SCREW D5X14 HIT-6685275.A15 6685275	-
101 - PIPE HOLDER HIT-6689656.A0 6689656	-
102 - STOP RING C-12 OUTER HIT-6684664.A24 6684664	-
103 - HEX. HOLE BOLT M5X25/S HIT-6684709.A65 6684709	£1.67	£2.00
104A - HEX. HOLE BOLT 4X12WS HIT-6695507.A13 6695507	-
105 - CLUTCH SHAFT COMP HIT-6688597.A0 6688597	£20.11	£24.13
106 - STOP RING R-32 INNER HIT-6695304.A0 6695304	-
107 - BEARING CASE HIT-6686667.A1 6686667	-
108 - BALL BEARING #6201ZZ 1 HIT-6695553.A7 6695553	-
109 - PRIMARY CORD GROMMET HIT-6688057.A15 6688057	-
110 - MUFFLER PROTECTOR HIT-6692803.A1 6692803	£13.79	£16.55
111 - SPARK PLUG CAP ASS'Y HIT-6687468.A60 6687468	£3.64	£4.37
112 - TAPPING SCREW D4.5X12 HIT-6684637.A15 6684637	£1.67	£2.00
113 - MUFFLER GASKET HIT-6692732.A5 6692732	£1.67	£2.00
114 - HEAT SHIELD HIT-6687260.A1 6687260	£5.77	£6.92
115 - MUFFLER SET HIT-6692489.A6 6692489	-
116 - HEX. HOLE BOLT M6X55 HIT-6684638.A10 6684638	£1.67	£2.00
117 - BOLT WASHER 6 HIT-6684639.A129 6684639	£1.67	£2.00
118 - MUFFLER SPECIAL GASKET HIT-6692887.A1 6692887	-
119 - TAIL PIPE SET FOR EUROPE HIT-6692669.A2 6692669	-
*120 - SCREW 4X8/S FOR EUROPE HIT-6695325.A1 6695325	-
*120 - SCREW 4X8/S TILL D090550 FOR AUS HIT-6695325.A2 6695325	-
120A - MACHINE SCREW (W/SP. WASHER) M4X8 SINCE D090551 FOR AUS HIT-6685109.A12 6685109	-
121 - TAIL PIPE SET TILL D090550 FOR AUS HIT-6692669.A1 6692669	-
121A - TAIL PIPE SET SINCE D090551 FOR AUS HIT-6692712.A6 6692712	-
122 - SPARK ARRESTOR SINCE D090551 FOR AUS HIT-6692699.A7 6692699	-
123 - BENT WASHER 8 HIT-6684648.A39 6684648	£1.67	£2.00
151 - RECOIL STARTER ASS'Y HIT-6692969.A1 6692969	£25.30	£30.36
152 - STARTER HANDLE HIT-6693227.A9 6693227	-
153 - ROPE GUIDE HIT-6693135.A7 6693135	-
154 - RECOIL STARTER BODY HIT-6693036.A0 6693036	-
155 - RECOIL SPRING HIT-6693111.A1 6693111	£15.16	£18.19
156 - ROPE 3.5X890 HIT-6693157.A1 6693157	-
157 - STARTER ROPE REEL HIT-6693057.A2 6693057	£8.18	£9.81
158 - ROPE REEL WASHER HIT-6693419.A2 6693419	-
159 - SET SCREW HIT-6693632.A2 6693632	-
160 - HEX.HOLE BOLT 4X18PS HIT-6695502.A1 6695502	£1.67	£2.00
161 - STARTER PULLEY ASS'Y HIT-6693394.A1 6693394	£9.42	£11.30
162 - STARTER PAWL HIT-6693299.A7 6693299	£3.29	£3.95
163 - STARTER PAWL SPRING HIT-6693345.A4 6693345	£3.89	£4.67
191 - PUMP BODY COMP. HIT-6684879.A52 6684879	£35.37	£42.44
192 - PRIMING PUMP COMP. HIT-6684687.A64 6684687	£9.27	£11.12
193 - DIAPHRAGM COVER HIT-6684688.A35 6684688	£5.70	£6.84
194 - PRIMING BODY HIT-6684689.A64 6684689	£5.87	£7.04
195 - METERING DIAPHRAGM COMP. HIT-6690827.A25 6690827	£14.02	£16.83
196 - DIAPHRAGM GASKET HIT-6684691.A61 6684691	£5.70	£6.84
197 - PUMP DIAPHRAGM HIT-6684693.A128 6684693	£5.70	£6.84
198 - PUMP GASKET HIT-6691457.A51 6691457	£8.48	£10.18
201 - STOP RING HIT-6684696.A142 6684696	-
202 - SWIVEL HIT-6684697.A47 6684697	-
203 - THROTTLE SET SCREW HIT-6684870.A24 6684870	-
204 - CABLE ADJUSTER STAY HIT-6684873.A49 6684873	-
205 - LOCK NUT M6 HIT-6684872.A30 6684872	-
206 - CABLE ADJUSTER FOR EUROPE HIT-6684871.A41 6684871	-
207 - CLEANER PACKING HIT-6684875.A52 6684875	-
208 - SET SCREW HIT-6684699.A34 6684699	-
209 - THRUST WASHER HIT-6684874.A25 6684874	-
210 - INLET SCREEN HIT-6684700.A159 6684700	-
211 - HIGH ADJUST SCREW FOR AUS HIT-6690700.A0 6690700	-
212 - HIGH/LOW ADJUST SPRING FOR AUS HIT-6692048.A6 6692048	-
213 - WASHER FOR AUS HIT-6691317.A3 6691317	-
214 - O-RING FOR AUS HIT-6691322.A0 6691322	-
215 - CABLE ADJUSTER FOR AUS HIT-6697616.A1 6697616	-
216 - O-RING FOR EUROPE HIT-6684695.A71 6684695	£1.67	£2.00
217 - MAIN JET #43 FOR EUROPE HIT-6691848.A2 6691848	£8.77	£10.52
231 - DRIVE SHAFT 1533L HIT-6689478.A1 6689478	£28.76	£34.51
232 - DRAIVE SHAFT PIPE COMP. HIT-6689407.A1 6689407	£53.33	£64.00
233 - BUSHING ASS'Y HIT-6697866.A2 6697866	-
234 - HEX.NUT 6 HIT-6684835.A27 6684835	£1.67	£2.00
235 - LOOP HANDLE BLACK HIT-6691049.A5 6691049	-
236 - BARRIER BLACK HIT-6691231.A12 6691231	-
237 - BOLT 6X43/P (BLACK) HIT-6684838.A16 6684838	£1.67	£2.00
238 - TAPPING SCREW 5X20 HIT-6695255.A30 6695255	-
239 - BRAKE SHAFT WASHER HIT-6689681.A17 6689681	£1.67	£2.00
240 - HANDLE GRIP HIT-6691098.A0 6691098	£10.90	£13.08
241 - LIFTING METAL ASS'Y HIT-6689275.A1 6689275	-
242 - THROTTLE LEVER ASS'Y 1 HIT-6693748.A0 6693748	£42.08	£50.49
243 - THROTTLE WIRE COMP. HIT-6693978.A10 6693978	£22.29	£26.75
244 - THROTTLE WIRE HIT-6694022.A0 6694022	-
245 - STOP SWITCH COMP. HIT-6687459.A1 6687459	£17.33	£20.80
246 - PROTECTION TUBE 7X175 HIT-6687526.A13 6687526	-
247 - TRIGGER LOCK OUT HIT-6684721.A29 6684721	£5.17	£6.20
248 - RETURN SPRING HIT-6684722.A19 6684722	£1.67	£2.00
249 - BLIND PLUG HIT-6684724.A14 6684724	-
250 - SCREW M5X20 HIT-6684803.A2 6684803	-
251 - CONTAL NUT 5 HIT-6684727.A28 6684727	£1.67	£2.00
252 - SCREW M4X20 (BLACK) HIT-6684725.A29 6684725	-
253 - THROTTLE LEVER HIT-6684804.A28 6684804	£6.86	£8.23
281 - GEAR CASE SET PN TILL J035780 FOR EUROPE HIT-6696497.A17 6696497	£60.35	£72.42
281B - GEAR CASE ASS'Y SINCE J035781 FOR EUROPE HIT-6601215.A1 6601215	-
282 - HEX. HOLE BOLT M5X25/S TILL J035780 FOR EUROPE HIT-6684709.A63 6684709	£1.67	£2.00
282A - HEX. SOCKET HD. BOLT M5X12 SINCE J035781 FOR EUROPE HIT-6684829.A33 6684829	-
283 - SPRING WASHER 5 SINCE J035781 FOR EUROPE HIT-6684834.A23 6684834	£1.67	£2.00
284 - RETAINING RING C-TYPE D26 FOR EUROPE HIT-6695294.A0 6695294	-
285 - STOP RING OUTER 10 TILL J035780 FOR EUROPE HIT-6695315.A25 6695315	-
285A - STOP RING C-10 1 HIT-6684821.A24 6684821	£1.67	£2.00
286 - BALL BEARING #6000Z 1 HIT-6695526.A25 6695526	-
*287 - BALL BEARING #6000 1 HIT-6695524.A51 6695524	-
*287 - BALL BEARING #6000 2 HIT-6695524.A52 6695524	-
288 - GEAR CASE 26 DIA TILL J035780 FOR EUROPE HIT-6688770.A22 6688770	-
288A - GEAR CASE SINCE J035781 FOR EUROPE HIT-6697738.A11 6697738	-
289 - HEX.HOLE BOLT M5X12/S TILL J035780 FOR EUROPE HIT-6684667.A97 6684667	£1.67	£2.00
289A - HEX. SOCKET HD. BOLT M5X30 S SINCE J035781 FOR EUROPE HIT-6684786.A56 6684786	£1.67	£2.00
290 - OILING BOLT TILL J035780 FOR EUROPE HIT-6689109.A24 6689109	-
290A - BOLT (W/PLUS) M6X8 SINCE J035781 FOR EUROPE HIT-6684737.A40 6684737	-
291 - BALL BEARING 609 TILL J035780 FOR EUROPE HIT-6684734.A3 6684734	-
292 - GEAR SHAFT TILL J035780 FOR EUROPE HIT-6688924.A18 6688924	-
292A - GEAR SHAFT SINCE J035781 FOR EUROPE HIT-6697739.A0 6697739	-
293 - BALL BEARING 6201D 1 HIT-6695554.A8 6695554	-
293A - BALL BEARING #6201DD 1 HIT-6695555.A10 6695555	-
294 - STOP RING C-32 1 HIT-6695295.A65 6695295	£1.67	£2.00
295 - CUTTER HOLDER TILL J035780 FOR EUROPE HIT-6689032.A1 6689032	£15.16	£18.19
296 - CUTTER HOLDER CAP TILL J035780 FOR EUROPE HIT-6689055.A19 6689055	£12.10	£14.52
296A - CUTTER HOLDER CAP SINCE J035781 FOR EUROPE HIT-6699009.A11 6699009	-
297 - NUT COVER SINCE J035781 FOR EUROPE HIT-6697792.A13 6697792	£4.28	£5.13
298 - FIXING NUT M10X1.25 TILL J035780 FOR EUROPE HIT-6689073.A11 6689073	£8.32	£9.99
298A - LEFT HAND NYLON NUT M10 SINCE J035781 FOR EUROPE HIT-6698658.A1 6698658	£8.59	£10.31
299 - GEAR CASE WASHER TILL J035780 FOR EUROPE HIT-6689159.A21 6689159	-
300 - HEX. HOLE BUTTON BOLT M6X25 FOR EUROPE HIT-6684714.A75 6684714	£1.67	£2.00
301 - COVER BRACKET 1 HIT-6690294.A12 6690294	-
301A - COVER BRACKET 26 TILL J035780 FOR EUROPE HIT-6690315.A24 6690315	-
301B - COVER BRACKET D26 SINCE J035781 FOR EUROPE HIT-6697867.A9 6697867	-
302 - BLADE GUARD 26 CE TILL D291600 FOR EUROPE HIT-6690242.A16 6690242	£18.84	£22.61
302A - BLADE GUARD 26CE SINCE D291601 FOR EUROPE HIT-6690276.A13 6690276	£20.01	£24.01
303 - GUARD HOLDER FOR EUROPE HIT-6684748.A37 6684748	-
304 - COVER GUARD TILL D291600 FOR EUROPE HIT-6690372.A19 6690372	£2.81	£3.37
304A - BLADE GUARD SINCE D261601 FOR EUROPE HIT-6690376.A18 6690376	£9.34	£11.21
305 - KNIFE TILL D291600 FOR EUROPE HIT-6693386.A1 6693386	£8.53	£10.24
305A - KNIFE SINCE D291601 FOR EUROPE HIT-6684750.A74 6684750	£3.64	£4.37
306 - SCREW 5X12/S TILL D291600 FOR EUROPE HIT-6695334.A2 6695334	£1.67	£2.00
306A - TAPPING SCREW 4X14 SINCE D291601 FOR EUROPE HIT-6684751.A19 6684751	£1.67	£2.00
307 - GEAR/PINION SET 1 HIT-6688875.A15 6688875	-
307A - GEAR PINION SET 1 HIT-6697741.A10 6697741	-
308 - NUT M5 TILL D291600 FOR EUROPE HIT-6684965.A6 6684965	£1.67	£2.00
*309 - TAPPING SCREW 5X20 SINCE D291601 FOR EUROPE HIT-6684753.A10 6684753	£1.67	£2.00
*309 - TAPPING SCREW 5X20 TILL H122650 FOR EUROPE HIT-6684753.A11 6684753	£1.67	£2.00
*310 - KNIFE SINCE D291601 FOR EUROPE HIT-6684754.A64 6684754	£6.64	£7.97
*310 - KNIFE TILL H122650 FOR EUROPE HIT-6684754.A65 6684754	£6.64	£7.97
321 - GEAR CASE SET PN FOR AUS HIT-6696497.A16 6696497	£60.35	£72.42
322 - HEX. HOLE BOLT M5X25/S FOR AUS HIT-6684709.A64 6684709	£1.67	£2.00
323 - RETAINING RING C-TYPE D26 FOR AUS HIT-6695294.A1 6695294	-
324 - STOP RING OUTER 10 FOR AUS HIT-6695315.A26 6695315	-
325 - BALL BEARING #6000Z 1 HIT-6695526.A26 6695526	-
326 - BALL BEARING #6000 1 HIT-6695524.A50 6695524	-
327 - GEAR CASE 26 DIA FOR AUS HIT-6688770.A23 6688770	-
328 - HEX.HOLE BOLT M5X12/S FOR AUS HIT-6684667.A96 6684667	£1.67	£2.00
329 - OILING BOLT FOR AUS HIT-6689109.A25 6689109	-
330 - BALL BEARING 609 FOR AUS HIT-6684734.A4 6684734	-
331 - GEAR SHAFT FOR AUS HIT-6688924.A17 6688924	-
332 - BALL BEARING 6201D 1 HIT-6695554.A7 6695554	-
333 - STOP RING C-32 1 HIT-6695295.A64 6695295	£1.67	£2.00
334 - CUTTER HOLDER FOR AUS HIT-6689032.A0 6689032	£15.16	£18.19
335 - CUTTER HOLDER CAP FOR AUS HIT-6689055.A20 6689055	£12.10	£14.52
336 - FIXING NUT M10X1.25 FOR AUS HIT-6689073.A10 6689073	£8.32	£9.99
337 - GEAR CASE WASHER FOR AUS HIT-6689159.A20 6689159	-
338 - HEX. HOLE BUTTON BOLT M6X25 FOR AUS HIT-6684714.A76 6684714	£1.67	£2.00
340 - COVER BRACKET 1 HIT-6690294.A13 6690294	-
340A - COVER BRACKET 1 HIT-6690303.A4 6690303	-
341 - BLADE GUARD 26 CE TILL Z351500 FOR AUS HIT-6690242.A15 6690242	£18.84	£22.61
341A - SAFETY COVER 1 HIT-6690255.A0 6690255	-
342 - GUARD HOLDER TILL Z351500 FOR AUS HIT-6684748.A36 6684748	-
342A - GUARD HOLDER SINCE Z351501 FOR AUS HIT-6690343.A0 6690343	-
343 - COVER GUARD TILL Z351500 FOR AUS HIT-6690372.A18 6690372	£2.81	£3.37
344 - KNIFE TILL Z351500 FOR AUS HIT-6693386.A2 6693386	£8.53	£10.24
345 - SCREW 5X12/S TILL Z351500 FOR AUS HIT-6695334.A3 6695334	£1.67	£2.00
346 - GEAR/PINION SET 1 HIT-6688875.A16 6688875	-
347 - NUT M5 TILL Z351500 FOR AUS HIT-6684965.A5 6684965	£1.67	£2.00
348 - TAPPING SCREW 5X20 SINCE Z351501 FOR AUS HIT-6684753.A12 6684753	£1.67	£2.00
349 - HEX.HOLE BOLT M5X12/S SINCE Z351501 FOR AUS HIT-6684667.A95 6684667	£1.67	£2.00
350 - KNIFE SINCE Z351501 FOR AUS HIT-6693388.A15 6693388	-
395B - CUTTER HOLDER ASS'Y SINCE J035781 FOR EUROPE HIT-6601216.A7 6601216	-
501 - HEX. BAR WRENCH 4MM HIT-6684813.A52 6684813	-
502 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A56 6684764	£7.64	£9.17
503 - CUTTER COVER TILL E023050 FOR AUS HIT-6684768.A27 6684768	-
504A - PROTECTIVE GLASSES FOR EUROPE HIT-875769.A72 875769	-
505 - HEX. WRENCH 3 HIT-6693520.A0 6693520	-
506 - BLADE B4/9/1.6 TILL D090550 FOR AUS HIT-6695789.A2 6695789	£15.17	£18.20
507 - SHOULDER STRAP S HIT-6695795.A0 6695795	-
*508 - PROTECTION COVER B TILL J035780 FOR EUROPE HIT-6688995.A18 6688995	£4.81	£5.77
*508 - PROTECTION COVER B FOR AUS HIT-6688995.A19 6688995	£4.81	£5.77
509 - NYLON HEAD CH-100 FOR AUS HIT-6695786.A2 6695786	-
510 - NYLON HEAD BF-5 TILL TL041840 FOR EUROPE HIT-6695784.A4 6695784	£27.81	£33.37
511 - MOUNTING NUT L-M10X1.25 TILL TL041840 FOR EUROPE HIT-6684756.A8 6684756	£10.80	£12.96
512 - MOUNTING NUT L-M8X1.25 TILL TL041840 FOR EUROPE HIT-6689624.A0 6689624	-
513 - CUTTING BODY TILL TL041840 FOR EUROPE HIT-6684757.A6 6684757	£15.38	£18.45
514 - SPECIAL NUT TILL TL041840 FOR EUROPE HIT-6684758.A10 6684758	£6.18	£7.41
515 - REEL SPRING TILL TL041840 FOR EUROPE HIT-6684759.A6 6684759	£3.56	£4.27
516 - SPOOL TILL TL041840 FOR EUROPE HIT-6684760.A10 6684760	£13.48	£16.18
517 - CUTTING BODY CAP TILL TL041840 FOR EUROPE HIT-6684761.A6 6684761	£21.34	£25.61
518 - EYELET TILL TL041840 FOR EUROPE HIT-6684762.A10 6684762	£3.56	£4.27
519 - SURE TAP MANUAL P/L 9 TILL TL041840 FOR EUROPE HIT-6697805.A10 6697805	-
520 - WINDING PROTECTOR TILL TL041840 FOR EUROPE HIT-6684763.A4 6684763	£2.98	£3.57
521 - NYLON CORD CUTTER SINCE TL041841 FOR EUROPE HIT-6601148.A10 6601148	£25.68	£30.81
522 - CASE SINCE TL041841 FOR EUROPE HIT-6601149.A7 6601149	-
523 - NUT SINCE TL041841 FOR EUROPE HIT-6601150.A10 6601150	-
524 - REEL SPRING SINCE TL041841 FOR EUROPE HIT-6693380.A15 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL041841 FOR EUROPE HIT-6601151.A7 6601151	-
526 - COVER SINCE TL041841 FOR EUROPE HIT-6601152.A10 6601152	-
527 - EYELET SINCE TL041841 FOR EUROPE HIT-6684810.A4 6684810	£3.29	£3.95

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-290 Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
