Hitachi / Hikoki TBC-230DS Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-230DS Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y TILL H005710 HIT-6687468.A27 6687468	£3.64	£4.37
*2 - SPARK PLUG ASS'Y RCJ8Y FOR EU HIT-6699328.A18 6699328	£5.70	£6.84
*2 - SPARK PLUG ASS'Y BPM6A FOR USA HIT-6699317.A17 6699317	-
3 - CYLINDER SET HIT-6685489.A7 6685489	£62.25	£74.70
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A4 6684586	-
5 - CYLINDER GASKET HIT-6685709.A4 6685709	£1.67	£2.00
6 - PISTON RING HIT-6686118.A8 6686118	£6.94	£8.33
7 - PISTON ASS'Y HIT-6685869.A0 6685869	£28.00	£33.60
8 - CIR CLIP HIT-6684590.A144 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6696944.A29 6696944	£5.61	£6.73
10 - CRANK SHAFT COMP. HIT-6686217.A11 6686217	£42.70	£51.24
11 - HIGH TENSION CORD 140L TILL H005710 HIT-6687888.A16 6687888	£3.89	£4.67
13 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A14 6684682	£1.67	£2.00
14 - IGNITION COIL ASS'Y TILL H005710 HIT-6699772.A0 6699772	-
14A - IGNITION COIL ASS'Y SINCE H005711 HIT-6697638.A7 6697638	-
15 - RUBBER CAP TILL H005710 HIT-6684602.A46 6684602	-
16 - LEAD WIRE ASS'Y HIT-6697836.A15 6697836	-
17 - WOODRUFF KEY 3X13X4.5 TILL B021000 HIT-6684899.A15 6684899	-
*31 - GEAR SHAFT SHIM 0.10 FOR EU HIT-6689177.A8 6689177	-
*31 - GEAR SHAFT SHIM 0.15 FOR EU HIT-6689178.A27 6689178	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A4 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A77 6684605	-
32 - CRANK CASE ASS'Y TILL A249800 HIT-6695806.A1 6695806	£38.60	£46.32
32A - CRANK CASE ASS'Y SINCE A249801 HIT-6686585.A0 6686585	£78.55	£94.26
33 - OIL SEAL TB 12227 HIT-6684607.A136 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6684608.A69 6684608	£5.70	£6.84
35 - CRANK CASE GASKET HIT-6686719.A9 6686719	£1.67	£2.00
36 - HEX.HOLE BOLT M5X18/S HIT-6684586.A3 6684586	-
37 - MAGNETO ROTOR COMP TILL B021000 HIT-6687376.A6 6687376	-
37A - MAGNETO ASS'Y TILL H005710 HIT-6601171.A8 6601171	-
37B - MAGNETO ROTOR COMP. SINCE H005711 HIT-6696928.A16 6696928	£50.30	£60.36
38 - BOLT WASHER M8 HIT-6684611.A5 6684611	-
39 - HEX. NUT M8 HIT-6684612.A109 6684612	-
51 - INLET MANIFOLD GASKET HIT-6689890.A0 6689890	£1.67	£2.00
52 - CARB INSULATOR SET HIT-6689914.A9 6689914	£8.34	£10.01
53 - CARBURETOR GASKET HIT-6684615.A2 6684615	£1.67	£2.00
54 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A3 6695514	-
55 - SCREW 5X60/S HIT-6695354.A15 6695354	£1.67	£2.00
56 - WASHER 5 HIT-6684661.A35 6684661	£1.67	£2.00
57 - SHIELD TUBE HIT-6688174.A12 6688174	-
58 - CLIP D6 HIT-6685198.A41 6685198	-
59A - PUMP FILTER BODY COMP HIT-66A3864.A62 66A3864	-
60 - TANK 1 HIT-6691592.A13 6691592	£11.38	£13.66
61 - TANK CAP ASS'Y HIT-6685049.A13 6685049	£9.94	£11.93
62 - COLLAR 5.8 TILL G103905 HIT-6692244.A19 6692244	£1.67	£2.00
63 - CARBURETOR SET WYL189 TILL B021000 HIT-6690513.A1 6690513	£43.64	£52.37
63A - CARBURETOR SET WYL182 SINCE B021001 HIT-6690512.A15 6690512	£69.17	£83.00
64 - SWIVEL CAP SINCE B049701 HIT-6691337.A38 6691337	£1.67	£2.00
65 - HEX. HOLE BOLT 5X16/PS TILL G103905 HIT-6695504.A40 6695504	£1.67	£2.00
65A - BOLT (W/FLANGE) L17.8 SINCE G103906 HIT-6696574.A43 6696574	£1.67	£2.00
66 - SCREW 5X20WS TILL G103905 HIT-6695516.A1 6695516	-
66A - BOLT (W/FLANGE) L17.8 SINCE G103906 HIT-6696574.A42 6696574	£1.67	£2.00
67 - TANK CAP CHAIN HIT-6684625.A8 6684625	-
68 - FUEL PIPE 3X5X85 HIT-6684880.A38 6684880	-
69 - RETURN GROMMET HIT-6697846.A148 6697846	£1.68	£2.01
91 - MUFFLER PROTECTOR TILL B290400 HIT-6692798.A6 6692798	-
91A - MUFFLER PROTECTOR BLACK SINCE B290401 HIT-6692809.A9 6692809	£8.45	£10.14
92 - SCREW 4X15PS HIT-6695373.A17 6695373	-
94 - TAPPING SCREW D4.5X12 HIT-6684637.A4 6684637	£1.67	£2.00
95 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A21 6685114	£1.67	£2.00
96 - WASHER M5 (BLACK) HIT-6684918.A6 6684918	£1.67	£2.00
98 - MUFFLER SET HIT-6692487.A4 6692487	£29.28	£35.14
100 - MUFFLER GASKET HIT-6692745.A8 6692745	-
101 - HEAT SHIELD HIT-6687253.A7 6687253	£2.81	£3.37
102 - SPARK PLUG COVER 1 HIT-6688350.A8 6688350	-
103 - CLUTCH WASHER B HIT-6697619.A0 6697619	£1.67	£2.00
104 - CLUTCH SHOE COMP. 2 HIT-6688616.A11 6688616	£12.82	£15.38
104A - CLUTCH ARM COMP 54 SINCE F112701 HIT-6697161.A9 6697161	-
105 - CLUTCH SPRING TILL F112700 HIT-6689430.A16 6689430	£3.89	£4.67
105A - CLUTCH SPRING SINCE F112701 HIT-6697618.A13 6697618	-
106 - CLUTCH PLATE (A) HIT-6689528.A16 6689528	£1.67	£2.00
107 - STEP BOLT TILL F112700 HIT-6689627.A33 6689627	£1.67	£2.00
107A - STEP BOLT SINCE F112701 HIT-6684646.A8 6684646	£3.72	£4.46
108 - BENT WASHER 8 HIT-6684648.A12 6684648	£1.67	£2.00
109 - CLUTCH ASS'Y SINCE F112701 HIT-6696932.A11 6696932	-
110 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A23 6684647	£1.67	£2.00
111 - TAPPING SCREW D4.5X20 TILL B290400 HIT-6685191.A18 6685191	-
112 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A4 6684973	-
113 - CORD CLAMP COMP. HIT-6688011.A18 6688011	-
114 - GROMMET TILL B290400 HIT-6688040.A7 6688040	-
131 - RECOIL STARTER BODY ASS'Y TILL B290400 HIT-6692986.A5 6692986	-
132 - STARTER HANDLE TILL B290400 HIT-6693240.A23 6693240	£16.35	£19.62
133 - RECOIL STARTER BODY COMP TILL B290400 HIT-6693038.A7 6693038	-
134 - ROPE TILL B290400 HIT-6693168.A3 6693168	£2.82	£3.39
135 - RECOIL SPRING TILL B290400 HIT-6693138.A5 6693138	£12.10	£14.52
137 - SPRING CASE ASS'Y TILL B290400 HIT-6693101.A2 6693101	-
139 - STARTER PULLEY TILL B290400 HIT-6693079.A3 6693079	-
140 - SPECIAL WASHER 5.2X15 TILL B290400 HIT-6687947.A8 6687947	-
141 - TAPPING SCREW D5X14 TILL B290400 HIT-6685275.A35 6685275	-
142 - STARTER BASE TILL B290400 HIT-6693470.A0 6693470	-
143 - HEX. HOLE BOLT 4X12WS TILL B290400 HIT-6695507.A17 6695507	-
144 - SQUARE NUT 5 TILL B290400 HIT-6695176.A1 6695176	-
145 - TAPPING SCREW D4.5X14 TILL B290400 HIT-6685153.A12 6685153	-
146 - STARTER PULLEY ASS'Y TILL B290400 HIT-6693408.A10 6693408	£35.37	£42.44
151 - RECOIL STARTER BODY ASS'Y TILL F024695 SINCE B290401 HIT-6692988.A0 6692988	£53.19	£63.83
152 - STARTER HANDLE TILL F024695 SINCE B290401 HIT-6693240.A22 6693240	£16.35	£19.62
153 - RECOIL STARTER BODY COMP. TILL F024695 SINCE B290401 HIT-6693039.A4 6693039	-
154 - ROPE 2.6X830 TILL F024695 SINCE B290401 HIT-6693175.A4 6693175	-
155 - RECOIL SPRING TILL F024695 SINCE B290401 HIT-6693139.A3 6693139	-
156 - SPRING CASE ASS'Y TILL F024695 SINCE B290401 HIT-6693102.A5 6693102	-
157 - STARTER ROPE REEL TILL F024695 SINCE B290401 HIT-6693080.A2 6693080	-
158 - SPECIAL WASHER 5.2X15 TILL F024695 SINCE B290401 HIT-6687947.A9 6687947	-
159 - TAPPING SCREW D5X14 TILL F024695 SINCE B290401 HIT-6685275.A36 6685275	-
160 - HEX. HOLE BOLT 4X18WS TILL F024695 SINCE B290401 HIT-6695508.A9 6695508	£1.67	£2.00
161 - FLUNGE NUT 5 TILL F024695 SINCE B290401 HIT-6695169.A1 6695169	£1.67	£2.00
162 - STARTER PULLEY ASS'Y TILL F024695 SINCE B290401 HIT-6693408.A11 6693408	£35.37	£42.44
171B - RECOIL STARTER BODY ASS'Y INCLUD.173-179 SINCE F024696 HIT-6601570.A51 6601570	£23.15	£27.78
173 - STARTER ROPE 3.5X860 SINCE F024696 HIT-6684674.A4 6684674	£5.70	£6.84
174 - RECOIL SPRING SINCE F024696 HIT-6684675.A137 6684675	£8.82	£10.58
175A - STARTER ROPE REEL SINCE TL025481 HIT-6699997.A87 6699997	-
176 - DAMPER SPRING SINCE F024696 HIT-6684677.A9 6684677	£5.70	£6.84
177A - CAM PLATE SINCE TL025481 HIT-6699996.A2 6699996	£4.28	£5.13
178 - SET SCREW SINCE F024696 HIT-6684679.A34 6684679	£2.98	£3.57
179 - STARTER HANDLE SINCE F024696 HIT-6684680.A88 6684680	£5.87	£7.04
180 - STARTER PULLEY ASS'Y SINCE F024696 HIT-6684681.A26 6684681	£18.16	£21.79
181 - HEX. HOLE BOLT 4X18WS SINCE F024696 HIT-6695508.A8 6695508	£1.67	£2.00
182 - D4E RETAINING RING SINCE F024696 HIT-6685101.A50 6685101	-
183 - STARTER PAWL SPRING SINCE F024696 HIT-6684684.A97 6684684	£3.29	£3.95
184 - STARTER PAWL SINCE F024696 HIT-6684685.A20 6684685	£5.07	£6.08
*185 - CAMPLATE ASS'Y SINCE F024696 HIT-6699691.A12 6699691	£7.75	£9.30
*185 - CAMPLATE ASS'Y TILL TL025480 HIT-6699691.A13 6699691	£7.75	£9.30
201 - CLEANER ASSY HIT-6690048.A12 6690048	£11.61	£13.93
202 - CLEANER COVER SET HIT-6690391.A1 6690391	£7.48	£8.97
203 - AIR CLEANER ELEMENT HIT-6684654.A0 6684654	£1.67	£2.00
204 - SPECIAL SCREW HIT-6689737.A26 6689737	-
205 - CLEANER BODY COMP. HIT-6684656.A3 6684656	£7.64	£9.17
206 - CHOKE VALVE HIT-6684657.A11 6684657	£2.81	£3.37
207 - WAVE WASHER 8 HIT-6684658.A6 6684658	£1.67	£2.00
208 - COLLAR 8 HIT-6684659.A11 6684659	-
221 - PUMP BODY COMP. HIT-6684879.A66 6684879	£35.37	£42.44
222 - PRIMING PUMP COMP. HIT-6684687.A86 6684687	£9.27	£11.12
223 - DIAPHRAGM COVER HIT-6684688.A13 6684688	£5.70	£6.84
224 - PRIMING BODY HIT-6684689.A88 6684689	£5.87	£7.04
225 - METERING DIAPHRAGM COMP. HIT-6690830.A54 6690830	£14.58	£17.50
226 - DIAPHRAGM GASKET HIT-6684691.A87 6684691	£5.70	£6.84
227 - PUMP DIAPHRAGM HIT-6684693.A174 6684693	£5.70	£6.84
228 - PUMP GASKET HIT-6691457.A78 6691457	£8.48	£10.18
229 - MAIN JET #40 TILL B021000 HIT-6691845.A9 6691845	-
229A - MAIN JET #38 SINCE B021001 HIT-6691844.A10 6691844	-
230 - O-RING HIT-6684695.A30 6684695	£1.67	£2.00
231 - STOP RING HIT-6684696.A187 6684696	-
232 - SWIVEL HIT-6684697.A24 6684697	-
233 - THROTTLE SET SCREW HIT-6684698.A57 6684698	-
234 - SET SCREW HIT-6684699.A7 6684699	-
235 - INLET SCREEN HIT-6684700.A225 6684700	-
236 - THROTTLE VALVE TILL B021000 HIT-6684883.A18 6684883	£32.24	£38.69
251 - CLUTCH SHAFT COMP. HIT-6695969.A2 6695969	£16.69	£20.03
252 - STOP RING C-12 OUTER HIT-6684664.A14 6684664	£1.67	£2.00
253 - ANTI-VIBE RUBBER HIT-6691839.A0 6691839	£5.92	£7.11
254 - HEX. HOLE BOLT 5X16 HIT-6695046.A5 6695046	£1.67	£2.00
255 - HEX. HOLE BOLT M5X25/S HIT-6684709.A29 6684709	£1.67	£2.00
256 - FAN CASE 1 HIT-6687029.A11 6687029	£26.97	£32.36
257 - PIPE HOLDER 1 HIT-6689651.A6 6689651	£8.88	£10.66
258 - WASHER M5 (BLACK) HIT-6684918.A16 6684918	£1.67	£2.00
259 - GEAR CASE WASHER HIT-6689159.A9 6689159	-
260 - METAL FITTING HIT-6689664.A25 6689664	£6.12	£7.35
281 - DRIVE SHAFT 1480L HIT-6696009.A7 6696009	£16.15	£19.38
282 - DRIVE SHAFT PIPE COMP. HIT-6689386.A6 6689386	£52.12	£62.54
283 - BUSH ASS'Y HIT-6684831.A30 6684831	-
284 - HANGER COLLAR HIT-6689260.A4 6689260	-
285 - HANGER HIT-6689281.A5 6689281	-
286 - HANGER FIXING BRACKET HIT-6689294.A6 6689294	-
287 - MACHINE SCREW (W/WASHERS) M5X25 (BLACK) HIT-6696988.A3 6696988	-
288 - HANDLE GRIP HIT-6684708.A17 6684708	£3.56	£4.27
289 - HEX. HOLE BOLT M5X25/S HIT-6684709.A28 6684709	£1.67	£2.00
290 - HANDLE BRACKET A HIT-6684710.A9 6684710	-
291 - HANDLE BRACKET B HIT-6684711.A1 6684711	£17.88	£21.45
292 - HANDLE BRACKET RUBBER HIT-6684712.A2 6684712	£3.37	£4.04
293 - HANDLE BRACKET C HIT-6684713.A0 6684713	£8.22	£9.87
294 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A118 6684714	£1.67	£2.00
295 - CLAMP B. HIT-6684715.A1 6684715	-
296 - LEFT HANDLE HIT-6696093.A6 6696093	£17.80	£21.36
297 - RIGHT HANDLE HIT-6691080.A4 6691080	£16.15	£19.38
298 - THROTTLE LEVER ASS'Y HIT-6693768.A2 6693768	-
299 - TRIGGER LOCK OUT HIT-6684721.A42 6684721	£5.17	£6.20
300 - RETURN SPRING HIT-6684722.A7 6684722	£1.67	£2.00
301 - THROTTLE LEVER HIT-6684723.A17 6684723	-
302 - BLIND PLUG HIT-6684724.A3 6684724	-
303 - SCREW M4X20 (BLACK) HIT-6684725.A43 6684725	-
304 - SCREW 5X30 (BLACK) HIT-6684726.A3 6684726	£1.67	£2.00
305 - CONTAL NUT 5 HIT-6684727.A42 6684727	£1.67	£2.00
306 - STOP BUTTON COMP. HIT-6687453.A1 6687453	-
307 - THROTTLE WIRE HIT-6694024.A0 6694024	£14.98	£17.98
308 - PROTECTION 7X825L HIT-6687543.A0 6687543	-
309 - THROTTLE WIRE COMP. HIT-6693981.A1 6693981	-
321 - GEAR CASE ASS'Y 24 HIT-6688817.A5 6688817	£76.90	£92.28
322 - HEX. HOLE BOLT M5X25/S HIT-6684709.A30 6684709	£1.67	£2.00
323 - STOP RING C-24 1 HIT-6684732.A14 6684732	£1.67	£2.00
324 - STOP RING C-9 1 HIT-6695281.A1 6695281	-
325 - BALL BEARING 609Z ST HIT-6684735.A21 6684735	£15.48	£18.57
326 - GEAR CASE 24 HIT-6688815.A3 6688815	-
327 - SCREW 5X12/W.S HIT-6695414.A9 6695414	£1.67	£2.00
328 - OILING BOLT HIT-6689109.A36 6689109	-
329 - BALL BEARING 626 1 HIT-6695567.A5 6695567	-
330 - GEAR SHAFT HIT-6688948.A3 6688948	-
331 - BALL BEARING 6000D 1 HIT-6695527.A3 6695527	£12.50	£15.00
332 - RETAINING RING C-TYPE D26 HIT-6695294.A22 6695294	-
333 - CUTTER HOLDER HIT-6689033.A4 6689033	£11.61	£13.93
334 - CUTTER HOLDER CAP HIT-6689056.A2 6689056	£4.65	£5.58
335 - PROTECTION COVER HIT-6688996.A3 6688996	£5.87	£7.04
336 - FIXING NUT L/H HIT-6689075.A5 6689075	£1.67	£2.00
337 - GEAR CASE COVER HIT-6688917.A5 6688917	£1.67	£2.00
338 - SCREW 5X12/W.S HIT-6695414.A8 6695414	£1.67	£2.00
339 - GEAR/PINION SET HIT-6688883.A4 6688883	£24.88	£29.85
340 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A119 6684714	£1.67	£2.00
341 - COVER BRACKET 24 TILL D241600 HIT-6690317.A1 6690317	-
341A - COVER BRACKET SINCE D241601 HIT-6690318.A5 6690318	£6.52	£7.82
342 - BLADE GUARD 26 CE TILL D241600 HIT-6690242.A24 6690242	£18.84	£22.61
342A - BLADE GUARD 24 CE SINCE D241601 HIT-6684747.A3 6684747	-
343 - GUARD HOLDER HIT-6684748.A21 6684748	-
344 - COVER GUARD TILL D241600 HIT-6690372.A28 6690372	£2.81	£3.37
344A - COVER GUARD SINCE D241601 HIT-6684749.A3 6684749	£8.52	£10.22
345 - KNIFE TILL D241600 HIT-6693386.A18 6693386	£8.53	£10.24
345A - KNIFE SINCE D241601 HIT-6684750.A43 6684750	£3.64	£4.37
346 - SCREW 5X12/S TILL D241600 HIT-6695334.A19 6695334	£1.67	£2.00
346A - TAPPING SCREW 4X14 SINCE D241601 HIT-6684751.A56 6684751	£1.67	£2.00
347 - NUT M5 TILL D241600 HIT-6684965.A22 6684965	£1.67	£2.00
348 - BRACKET SPACER TILL D241600 HIT-6690332.A1 6690332	-
*349 - TAPPING SCREW 5X20 SINCE D241601 HIT-6684753.A25 6684753	£1.67	£2.00
*349 - TAPPING SCREW 5X20 TILL H124328 HIT-6684753.A26 6684753	£1.67	£2.00
*350 - KNIFE SINCE D241601 HIT-6684754.A58 6684754	£6.64	£7.97
*350 - KNIFE TILL H124328 HIT-6684754.A59 6684754	£6.64	£7.97
501 - HEX. BAR WRENCH 4MM HIT-6684813.A78 6684813	-
502 - COMBI BOX SPANNER 13X19 HIT-6693588.A4 6693588	-
503 - CUTTER COVER TILL TL010810 HIT-6699555.A7 6699555	-
503B - CUTTER COVER SINCE TL010811 HIT-6684768.A7 6684768	-
504A - PROTECTIVE GLASSES HIT-875769.A34 875769	-
506 - BLADE B4/9/1.6 HIT-6695789.A1 6695789	£15.17	£18.20
507 - SHOULDER HARNESS D3X HIT-6695796.A14 6695796	£25.30	£30.36
521 - NYLON HEAD Z-5 HIT-6695783.A4 6695783	£39.71	£47.65
522 - CUTTING BODY HIT-6693273.A3 6693273	-
523 - SPECIAL NUT HIT-6689103.A2 6689103	£11.71	£14.05
524 - REEL SPRING HIT-6693380.A19 6693380	£6.47	£7.76
525 - EYELET HIT-6684810.A9 6684810	£3.29	£3.95
526 - SPOOL HIT-6693294.A6 6693294	£11.02	£13.22
527 - NO LONGER AVAILABLE HIT-6693340.A5 6693340	-
528 - MANUAL NYLON HEAD Z5 HIT-6697932.A2 6697932	-
601 - SYMBOL MARK TBC-230DS HIT-6694643.A0 6694643	-
602 - S?START MARK HIT-6694472.A8 6694472	-
603 - CAUTION MARK TANAKA HIT-6697851.A9 6697851	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-230DS Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TBC-230DS Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TBC-230DS Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
