Hitachi / Hikoki TBC-230D Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-230D Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y TILL G165670 HIT-6687468.A21 6687468	£3.64	£4.37
*2 - SPARK PLUG ASS'Y RCJ8Y FOR EUROPE HIT-6699328.A20 6699328	£5.70	£6.84
*2 - SPARK PLUG ASS'Y BPM6A FOR VEN HIT-6699317.A15 6699317	-
3 - CYLINDER SET HIT-6685489.A8 6685489	£62.25	£74.70
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A8 6684586	-
5 - CYLINDER GASKET HIT-6685709.A3 6685709	£1.67	£2.00
6 - PISTON RING HIT-6686118.A10 6686118	£6.94	£8.33
7 - PISTON ASS'Y HIT-6685869.A1 6685869	£28.00	£33.60
8 - CIR CLIP HIT-6684590.A142 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6696944.A28 6696944	£5.61	£6.73
10 - CRANK SHAFT COMP. HIT-6686217.A12 6686217	£42.70	£51.24
11 - HIGH TENSION CORD 140L TILL G165670 HIT-6687888.A14 6687888	£3.89	£4.67
13 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A17 6684682	£1.67	£2.00
14 - IGNITION COIL ASS'Y TILL G165670 HIT-6699772.A5 6699772	-
14A - IGNITION COIL ASS'Y SINCE G165671 HIT-6697638.A6 6697638	-
15 - RUBBER CAP TILL G165670 HIT-6684602.A50 6684602	-
16 - LEAD WIRE ASS'Y HIT-6697836.A12 6697836	-
17 - WOODRUFF KEY 3X13X4.5 TILL B021000 HIT-6684899.A19 6684899	-
*31 - GEAR SHAFT SHIM 0.10 HIT-6689177.A4 6689177	-
*31 - GEAR SHAFT SHIM 0.15 HIT-6689178.A31 6689178	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A5 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A76 6684605	-
32 - CRANK CASE ASS'Y TILL A249800 HIT-6695806.A2 6695806	£38.60	£46.32
32A - CRANK CASE ASS'Y SINCE A249801 HIT-6686585.A1 6686585	£78.55	£94.26
33 - OIL SEAL TB 12227 HIT-6684607.A137 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6684608.A68 6684608	£5.70	£6.84
35 - CRANK CASE GASKET HIT-6686719.A8 6686719	£1.67	£2.00
36 - HEX.HOLE BOLT M5X18/S HIT-6684586.A5 6684586	-
37 - MAGNETO ROTOR COMP TILL B021000 HIT-6687376.A5 6687376	-
37A - MAGNETO ROTOR COMP. TILL G165670 HIT-6687377.A0 6687377	£28.22	£33.86
37B - MAGNETO ROTOR COMP. SINCE G165671 HIT-6696928.A15 6696928	£50.30	£60.36
38 - BOLT WASHER M8 HIT-6684611.A6 6684611	-
39 - HEX. NUT M8 HIT-6684612.A108 6684612	-
51 - INLET MANIFOLD GASKET HIT-6689890.A1 6689890	£1.67	£2.00
52 - CARB INSULATOR SET HIT-6689914.A10 6689914	£8.34	£10.01
53 - CARBURETOR GASKET HIT-6684615.A3 6684615	£1.67	£2.00
54 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A4 6695514	-
55 - SCREW 5X60/S FOR EUROPE HIT-6695354.A16 6695354	£1.67	£2.00
56 - WASHER 5 FOR EUROPE HIT-6684661.A34 6684661	£1.67	£2.00
57 - SHIELD TUBE HIT-6688174.A11 6688174	-
58 - CLIP D6 HIT-6685198.A40 6685198	-
59A - PUMP FILTER BODY COMP HIT-66A3864.A63 66A3864	-
60 - TANK 1 HIT-6691592.A12 6691592	£11.38	£13.66
61 - TANK CAP ASS'Y HIT-6685049.A12 6685049	£9.94	£11.93
62 - COLLAR 5.8 TILL G103905 HIT-6692244.A18 6692244	£1.67	£2.00
63 - CARBURETOR SET WYL189 TILL B021000 FOR EUROPE HIT-6690513.A2 6690513	£43.64	£52.37
63A - CARBURETOR SET WYL182 SINCE B021001 FOR EUROPE HIT-6690512.A14 6690512	£69.17	£83.00
64 - SWIVEL CAP HIT-6691337.A37 6691337	£1.67	£2.00
65 - HEX. HOLE BOLT 5X16/PS TILL G103905 HIT-6695504.A39 6695504	£1.67	£2.00
65A - BOLT (W/FLANGE) L17.8 SINCE G103906 HIT-6696574.A44 6696574	£1.67	£2.00
66 - SCREW 5X20WS TILL G103905 HIT-6695516.A0 6695516	-
66A - BOLT (W/FLANGE) L 17.8 SINCE G103906 HIT-6698511.A2 6698511	-
67 - TANK CAP CHAIN HIT-6684625.A7 6684625	-
68 - FUEL PIPE 3X5X85 HIT-6684880.A37 6684880	-
69 - RETURN GROMMET HIT-6697846.A149 6697846	£2.08	£2.50
70 - CARBURETOR SET WYL-177 FOR IRL HIT-6690510.A0 6690510	£68.05	£81.66
71 - PLUS SCREW 5X60WS FOR IRL HIT-6695431.A16 6695431	-
72 - O-RING P-15 FOR IRL HIT-6698966.A27 6698966	£1.67	£2.00
91 - MUFFLER PROTECTOR TILL B290400 HIT-6692798.A5 6692798	-
91A - MUFFLER PROTECTOR BLACK SINCE B290401 HIT-6692809.A10 6692809	£8.45	£10.14
92 - SCREW 4X15PS HIT-6695373.A16 6695373	-
94 - TAPPING SCREW D4.5X12 HIT-6684637.A5 6684637	£1.67	£2.00
95 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A39 6685114	£1.67	£2.00
96 - WASHER M5 (BLACK) HIT-6684918.A62 6684918	£1.67	£2.00
98 - MUFFLER SET HIT-6692487.A12 6692487	£29.28	£35.14
100 - MUFFLER GASKET HIT-6692745.A15 6692745	-
101 - HEAT SHIELD HIT-6687253.A11 6687253	£2.81	£3.37
102 - SPARK PLUG COVER 1 HIT-6688350.A0 6688350	-
103 - CLUTCH WASHER B HIT-6697619.A23 6697619	£1.67	£2.00
104 - CLUTCH SHOE COMP. 2 HIT-6688616.A17 6688616	£12.82	£15.38
104A - CLUTCH ARM COMP 54 SINCE F112701 FOR EUROPE HIT-6697161.A1 6697161	-
105 - CLUTCH SPRING TILL F112700 FOR EUROPE HIT-6689430.A2 6689430	£3.89	£4.67
105A - CLUTCH SPRING SINCE F112701 FOR EUROPE HIT-6697618.A1 6697618	-
106 - CLUTCH PLATE (A) HIT-6689528.A8 6689528	£1.67	£2.00
107 - STEP BOLT TILL F112700 FOR EUROPE HIT-6689627.A2 6689627	£1.67	£2.00
107A - STEP BOLT SINCE F112701 FOR EUROPE HIT-6684646.A31 6684646	£3.72	£4.46
108 - BENT WASHER 8 HIT-6684648.A89 6684648	£1.67	£2.00
109 - CLUTCH ASS'Y SINCE F112701 FOR EUROPE HIT-6696932.A1 6696932	-
110 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A6 6684647	£1.67	£2.00
111 - TAPPING SCREW D4.5X20 TILL B290400 HIT-6685191.A33 6685191	-
112 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A21 6684973	-
113 - CORD CLAMP COMP. HIT-6688011.A30 6688011	-
114 - GROMMET TILL B290400 HIT-6688040.A11 6688040	-
115 - CLUTCH SHOE FOR IRL HIT-6697656.A11 6697656	-
116 - CLUTCH SPRING FOR IRL HIT-6697657.A2 6697657	-
117 - CLUTCH SET FOR IRL HIT-6697655.A2 6697655	£9.68	£11.62
118 - STEP BOLT FOR IRL HIT-6689627.A3 6689627	£1.67	£2.00
151 - RECOIL STARTER BODY ASS'Y HIT-6684938.A5 6684938	£18.59	£22.31
152 - RECOIL STARTER BODY COMP. HIT-6684944.A5 6684944	-
153 - STARTER ROPE REEL HIT-6684941.A11 6684941	£7.41	£8.89
154 - RECOIL SPRING HIT-6684942.A5 6684942	£5.17	£6.20
155 - SWING ARM HIT-6684940.A5 6684940	£1.67	£2.00
156 - SET SCREW HIT-6684679.A141 6684679	£2.98	£3.57
157 - PULLEY STAY HIT-6684939.A10 6684939	-
158 - ROPE 3.0X800 HIT-6684943.A10 6684943	-
159 - STARTER HANDLE HIT-6684680.A13 6684680	£5.87	£7.04
160 - SPECIAL NUT M5 HIT-6685000.A17 6685000	-
161 - STARTER PULLEY HIT-6684937.A10 6684937	£3.56	£4.27
162 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A13 6684682	£1.67	£2.00
201 - CLEANER ASSY FOR EUROPE HIT-6690048.A1 6690048	£11.61	£13.93
202 - CLEANER COVER SET FOR EUROPE HIT-6690391.A12 6690391	£7.48	£8.97
203 - AIR CLEANER ELEMENT FOR EUROPE HIT-6684654.A13 6684654	£1.67	£2.00
204 - SPECIAL SCREW FOR EUROPE HIT-6689737.A8 6689737	-
205 - CLEANER BODY COMP. FOR EUROPE HIT-6684656.A13 6684656	£7.64	£9.17
206 - CHOKE VALVE FOR EUROPE HIT-6684657.A1 6684657	£2.81	£3.37
207 - WAVE WASHER 8 FOR EUROPE HIT-6684658.A36 6684658	£1.67	£2.00
208 - COLLAR 8 FOR EUROPE HIT-6684659.A1 6684659	-
211 - CLEANER ASS'Y FOR IRL HIT-6690006.A1 6690006	£12.48	£14.97
212A - CLEANER CAP ASS'Y FOR IRL HIT-6699771.A3 6699771	-
213 - CLEANER ELEMENT FOR IRL HIT-6690347.A33 6690347	£7.15	£8.58
214 - AIRCLEANER BODY FOR IRL HIT-6690086.A5 6690086	£6.86	£8.23
215 - COLLAR FOR IRL HIT-6690801.A1 6690801	-
221 - PUMP BODY COMP. HIT-6684879.A25 6684879	£35.37	£42.44
222 - PRIMING PUMP COMP. HIT-6684687.A16 6684687	£9.27	£11.12
223 - DIAPHRAGM COVER HIT-6684688.A84 6684688	£5.70	£6.84
224 - PRIMING BODY HIT-6684689.A15 6684689	£5.87	£7.04
225 - METERING DIAPHRAGM COMP. HIT-6690830.A17 6690830	£14.58	£17.50
226 - DIAPHRAGM GASKET HIT-6684691.A11 6684691	£5.70	£6.84
227 - PUMP DIAPHRAGM HIT-6684693.A42 6684693	£5.70	£6.84
228 - PUMP GASKET HIT-6691457.A25 6691457	£8.48	£10.18
229 - MAIN JET #40 TILL B021000 FOR EUROPE HIT-6691845.A1 6691845	-
229A - MAIN JET #38 SINCE B021001 HIT-6691844.A14 6691844	-
230 - O-RING HIT-6684695.A150 6684695	£1.67	£2.00
231 - STOP RING HIT-6684696.A47 6684696	-
232 - SWIVEL HIT-6684697.A118 6684697	-
233 - THROTTLE SET SCREW HIT-6684698.A19 6684698	-
234 - SET SCREW HIT-6684699.A81 6684699	-
235 - INLET SCREEN HIT-6684700.A60 6684700	-
236 - THROTTLE VALVE TILL B021000 FOR EUROPE HIT-6684883.A1 6684883	£32.24	£38.69
251 - CLUTCH SHAFT COMP. HIT-6695969.A8 6695969	£16.69	£20.03
252 - STOP RING C-12 OUTER HIT-6684664.A57 6684664	-
253 - ANTI-VIBE RUBBER HIT-6691839.A10 6691839	£5.92	£7.11
254 - HEX. HOLE BOLT 5X16 HIT-6695046.A29 6695046	£1.67	£2.00
255 - HEX. HOLE BOLT M5X25/S HIT-6684709.A177 6684709	£1.67	£2.00
256 - FAN CASE 1 HIT-6687029.A0 6687029	£26.97	£32.36
257 - PIPE HOLDER 1 HIT-6689651.A14 6689651	£8.88	£10.66
258 - WASHER M5 (BLACK) HIT-6684918.A61 6684918	£1.67	£2.00
259 - GEAR CASE WASHER HIT-6689159.A34 6689159	-
260 - METAL FITTING HIT-6689664.A12 6689664	£6.12	£7.35
281 - DRIVE SHAFT 1480L HIT-6696009.A1 6696009	£16.15	£19.38
282 - DRIVE SHAFT PIPE COMP. HIT-6689386.A0 6689386	£52.12	£62.54
283 - BUSH ASS'Y HIT-6684831.A1 6684831	-
284 - HANGER COLLAR HIT-6689260.A6 6689260	-
285 - HANGER HIT-6689281.A9 6689281	-
286 - HANGER FIXING BRACKET HIT-6689294.A4 6689294	-
287 - MACHINE SCREW (W/WASHERS) M5X25 (BLACK) HIT-6696988.A12 6696988	-
288 - HANDLE GRIP FOR EUROPE HIT-6684708.A4 6684708	£3.56	£4.27
289 - HEX. HOLE BOLT M5X25/S HIT-6684709.A176 6684709	£1.67	£2.00
290 - HANDLE BRACKET A HIT-6684710.A0 6684710	-
291 - HANDLE BRACKET B HIT-6684711.A8 6684711	£17.88	£21.45
292 - HANDLE BRACKET RUBBER HIT-6684712.A0 6684712	£3.37	£4.04
293 - HANDLE BRACKET C HIT-6684713.A4 6684713	£8.22	£9.87
294 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A44 6684714	£1.67	£2.00
295 - CLAMP B. HIT-6684715.A8 6684715	-
296 - LEFT HANDLE HIT-6696093.A0 6696093	£17.80	£21.36
297 - RIGHT HANDLE HIT-6691080.A8 6691080	£16.15	£19.38
298 - THROTTLE LEVER ASS'Y HIT-6693768.A0 6693768	-
299 - TRIGGER LOCK OUT HIT-6684721.A5 6684721	£5.17	£6.20
300 - RETURN SPRING HIT-6684722.A42 6684722	£1.67	£2.00
301 - THROTTLE LEVER HIT-6684723.A2 6684723	-
302 - BLIND PLUG HIT-6684724.A30 6684724	-
303 - SCREW M4X20 (BLACK) HIT-6684725.A10 6684725	-
304 - SCREW 5X30 (BLACK) HIT-6684726.A18 6684726	£1.67	£2.00
305 - CONTAL NUT 5 HIT-6684727.A5 6684727	£1.67	£2.00
306 - STOP BUTTON COMP. HIT-6687453.A2 6687453	-
307 - THROTTLE WIRE HIT-6694024.A2 6694024	£14.98	£17.98
308 - PROTECTION 7X825L HIT-6687543.A2 6687543	-
309 - THROTTLE WIRE COMP. HIT-6693981.A2 6693981	-
310 - HANDLE GRIP FOR IRL HIT-6601164.A0 6601164	-
321 - GEAR CASE ASS'Y 24 HIT-6688817.A2 6688817	£76.90	£92.28
322 - HEX. HOLE BOLT M5X25/S HIT-6684709.A178 6684709	£1.67	£2.00
323 - STOP RING C-24 1 HIT-6684732.A49 6684732	£1.67	£2.00
324 - STOP RING C-9 1 HIT-6695281.A23 6695281	-
325 - BALL BEARING 609Z ST HIT-6684735.A15 6684735	£15.48	£18.57
326 - GEAR CASE 24 HIT-6688815.A6 6688815	-
327 - SCREW 5X12/W.S HIT-6695414.A43 6695414	£1.67	£2.00
328 - OILING BOLT HIT-6689109.A0 6689109	-
329 - BALL BEARING 626 1 HIT-6695567.A1 6695567	-
330 - GEAR SHAFT HIT-6688948.A7 6688948	-
331 - BALL BEARING 6000D 1 HIT-6695527.A7 6695527	£12.50	£15.00
332 - RETAINING RING C-TYPE D26 HIT-6695294.A52 6695294	-
333 - CUTTER HOLDER HIT-6689033.A3 6689033	£11.61	£13.93
334 - CUTTER HOLDER CAP HIT-6689056.A4 6689056	£4.65	£5.58
335 - PROTECTION COVER HIT-6688996.A6 6688996	£5.87	£7.04
336 - FIXING NUT L/H HIT-6689075.A1 6689075	£1.67	£2.00
337 - GEAR CASE COVER HIT-6688917.A2 6688917	£1.67	£2.00
338 - SCREW 5X12/W.S HIT-6695414.A42 6695414	£1.67	£2.00
339 - GEAR/PINION SET HIT-6688883.A9 6688883	£24.88	£29.85
340 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A45 6684714	£1.67	£2.00
341 - COVER BRACKET 24 TILL D241600 HIT-6690317.A4 6690317	-
341A - COVER BRACKET SINCE D241601 HIT-6690318.A2 6690318	£6.52	£7.82
342 - BLADE GUARD 26 CE TILL D241600 HIT-6690242.A12 6690242	£18.84	£22.61
342A - BLADE GUARD 24 CE SINCE D241601 HIT-6684747.A5 6684747	-
343 - GUARD HOLDER HIT-6684748.A9 6684748	-
344 - COVER GUARD TILL D241600 HIT-6690372.A9 6690372	£2.81	£3.37
344A - COVER GUARD SINCE D241601 HIT-6684749.A5 6684749	£8.52	£10.22
345 - KNIFE TILL D241600 HIT-6693386.A28 6693386	£8.53	£10.24
345A - KNIFE SINCE D241601 HIT-6684750.A22 6684750	£3.64	£4.37
346 - SCREW 5X12/S TILL D241600 HIT-6695334.A25 6695334	£1.67	£2.00
346A - TAPPING SCREW 4X14 SINCE D241601 HIT-6684751.A79 6684751	£1.67	£2.00
347 - NUT M5 TILL D241600 HIT-6684965.A54 6684965	£1.67	£2.00
348 - BRACKET SPACER TILL D241600 HIT-6690332.A4 6690332	-
*349 - TAPPING SCREW 5X20 SINCE D241601 FOR EUROPE HIT-6684753.A57 6684753	£1.67	£2.00
*349 - TAPPING SCREW 5X20 TILL H127280 FOR EUROPE HIT-6684753.A58 6684753	£1.67	£2.00
*350 - KNIFE SINCE D241601 FOR EUROPE HIT-6684754.A34 6684754	£6.64	£7.97
*350 - KNIFE TILL H127280 FOR EUROPE HIT-6684754.A35 6684754	£6.64	£7.97
501 - HEX. BAR WRENCH 4MM HIT-6684813.A8 6684813	-
502 - COMBI BOX SPANNER 13X19 HIT-6693588.A9 6693588	-
503B - CUTTER COVER FOR EUROPE HIT-6684768.A62 6684768	-
504A - PROTECTIVE GLASSES HIT-875769.A150 875769	-
506 - BLADE B4/9/1.6 FOR EUROPE HIT-6695789.A5 6695789	£15.17	£18.20
507 - SHOULDER HARNESS D3X HIT-6695796.A3 6695796	£25.30	£30.36
521 - NYLON HEAD Z-5 FOR EUROPE HIT-6695783.A1 6695783	£39.71	£47.65
522 - CUTTING BODY FOR EUROPE HIT-6693273.A1 6693273	-
523 - SPECIAL NUT FOR EUROPE HIT-6689103.A6 6689103	£11.71	£14.05
524 - REEL SPRING FOR EUROPE HIT-6693380.A5 6693380	£6.47	£7.76
525 - EYELET FOR EUROPE HIT-6684810.A23 6684810	£3.29	£3.95
526 - SPOOL FOR EUROPE HIT-6693294.A1 6693294	£11.02	£13.22
527 - NO LONGER AVAILABLE HIT-6693340.A2 6693340	-
528 - MANUAL NYLON HEAD Z5 FOR EUROPE HIT-6697932.A7 6697932	-
529 - NYLON HEAD/NB4 LM8X1.25 FOR IRL HIT-6693222.A1 6693222	£30.92	£37.11
531 - MOUNTING NUT L/H FOR IRL HIT-6689625.A1 6689625	-
532 - CODE REEL FOR IRL HIT-6693293.A3 6693293	-
533 - REEL SPRING FOR IRL HIT-6693379.A3 6693379	-
534 - REEL SLIDER FOR IRL HIT-6689852.A2 6689852	£2.81	£3.37
535 - EYELET FOR IRL HIT-6693329.A3 6693329	£1.67	£2.00
536 - BODY CAP FOR IRL HIT-6693339.A2 6693339	-
537 - DISK FOR IRL HIT-6689906.A1 6689906	£1.67	£2.00
538 - SCREW 5X14/S FOR IRL HIT-6695336.A1 6695336	£1.67	£2.00
601 - NAME PLATE TBC-230D HIT-6694221.A0 6694221	-
602 - SYMBOL MARK TBC-230D HIT-6694640.A0 6694640	-
603 - CAUTION MARK TANAKA HIT-6697851.A2 6697851	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-230D Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
