Hitachi / Hikoki TBC-230BS Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-230BS Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y TILL G147200 HIT-6687468.A40 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y RCJ8Y HIT-6699328.A22 6699328	£5.70	£6.84
3 - CYLINDER SET HIT-6685489.A10 6685489	£62.25	£74.70
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A17 6684586	-
5 - CYLINDER GASKET HIT-6685709.A5 6685709	£1.67	£2.00
6 - PISTON RING HIT-6686118.A11 6686118	£6.94	£8.33
7 - PISTON ASS'Y HIT-6685869.A3 6685869	£28.00	£33.60
8 - CIR CLIP HIT-6684590.A131 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6696944.A30 6696944	£5.61	£6.73
10 - CRANK SHAFT COMP. HIT-6686217.A14 6686217	£42.70	£51.24
11 - HIGH TENSION CORD 140L TILL G147200 HIT-6687888.A20 6687888	£3.89	£4.67
13 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A24 6684682	£1.67	£2.00
14 - IGNITION COIL ASS'Y TILL G147200 HIT-6699772.A7 6699772	-
14A - IGNITION COIL ASS'Y SINCE G147201 HIT-6697638.A9 6697638	-
15 - RUBBER CAP TILL G147200 HIT-6684602.A51 6684602	-
*18 - STOP CORD COMP. FOR EUROPE HIT-6687826.A9 6687826	-
*18 - STOP CORD COMP. TILL D089600 FOR AUS HIT-6687826.A10 6687826	-
19 - LEAD WIRE ASS'Y SINCE D089601 FOR AUS HIT-6697836.A18 6697836	-
*31 - GEAR SHAFT SHIM 0.10 HIT-6689177.A12 6689177	-
*31 - GEAR SHAFT SHIM 0.15 HIT-6689178.A23 6689178	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A0 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A81 6684605	-
32 - CRANK CASE ASS'Y TILL A249800 HIT-6695806.A3 6695806	£38.60	£46.32
32A - CRANK CASE ASS'Y SINCE A249801 HIT-6686585.A3 6686585	£78.55	£94.26
33 - OIL SEAL TB 12227 HIT-6684607.A151 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6684608.A54 6684608	£5.70	£6.84
35 - CRANK CASE GASKET HIT-6686719.A11 6686719	£1.67	£2.00
36 - HEX.HOLE BOLT M5X18/S HIT-6684586.A16 6684586	-
37 - MAGNETO ROTOR COMP TILL B021000 HIT-6687376.A8 6687376	-
37A - MAGNETO ASS'Y TILL G147200 HIT-6601171.A10 6601171	-
37B - MAGNETO ROTOR COMP. SINCE G147201 HIT-6696928.A17 6696928	£50.30	£60.36
38 - BOLT WASHER M8 HIT-6684611.A18 6684611	-
39 - HEX. NUT M8 HIT-6684612.A101 6684612	-
51 - INLET MANIFOLD GASKET HIT-6689890.A3 6689890	£1.67	£2.00
52 - CARB INSULATOR SET HIT-6689914.A11 6689914	£8.34	£10.01
53 - CARBURETOR GASKET HIT-6684615.A7 6684615	£1.67	£2.00
54 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A8 6695514	-
55 - SCREW 5X60/S HIT-6695354.A14 6695354	£1.67	£2.00
56 - WASHER 5 HIT-6684661.A36 6684661	£1.67	£2.00
57 - SHIELD TUBE HIT-6688174.A14 6688174	-
58 - CLIP D6 HIT-6685198.A51 6685198	-
59A - PUMP FILTER BODY COMP HIT-66A3864.A47 66A3864	-
60 - TANK 1 HIT-6691592.A16 6691592	£11.38	£13.66
61 - TANK CAP ASS'Y FOR EUROPE HIT-6685049.A22 6685049	£9.94	£11.93
62 - COLLAR 5.8 TILL G147200 HIT-6692244.A25 6692244	£1.67	£2.00
*63 - CARBURETOR SET WYL182 FOR EUROPE HIT-6690512.A16 6690512	£69.17	£83.00
*63 - CARBURETOR SET WYL189 FOR AUS HIT-6690513.A0 6690513	-
64 - SWIVEL CAP HIT-6691337.A39 6691337	£1.67	£2.00
65 - HEX. HOLE BOLT 5X16/PS TILL G147200 HIT-6695504.A50 6695504	£1.67	£2.00
65A - BOLT (W/FLANGE) L17.8 SINCE G147201 HIT-6696574.A37 6696574	£1.67	£2.00
66 - SCREW 5X20WS TILL G147200 HIT-6695516.A3 6695516	-
66A - BOLT (W/FLANGE) L17.8 SINCE G147201 HIT-6696574.A36 6696574	£1.67	£2.00
67 - TANK CAP CHAIN HIT-6684625.A18 6684625	-
68 - FUEL PIPE 3X5X85 HIT-6684880.A46 6684880	-
69 - RETURN GROMMET HIT-6697846.A169 6697846	£2.08	£2.50
*71 - AIR VENT ASS'Y SINCE C243901 FOR AUS HIT-6691389.A16 6691389	£16.64	£19.97
*71 - AIR VENT ASS'Y TILL G150750 FOR AUS HIT-6691389.A17 6691389	£16.64	£19.97
*72 - AIR VENT PIPE SINCE C243901 FOR AUS HIT-6697800.A8 6697800	-
*72 - AIR VENT PIPE TILL G150750 FOR AUS HIT-6697800.A9 6697800	-
*73 - AIR VENT VALVE ASS'Y SINCE C243901 FOR AUS HIT-6692171.A20 6692171	-
*73 - AIR VENT VALVE ASS'Y TILL G150750 FOR AUS HIT-6692171.A21 6692171	-
74 - TANK 1 HIT-6691592.A15 6691592	£11.38	£13.66
74A - TANK WHT TILL G150750 FOR AUS HIT-6696380.A0 6696380	-
74B - TANK 1 HIT-6691592.A17 6691592	£11.38	£13.66
75 - TANK CAP ASS'Y TILL C243900 FOR AUS HIT-6685049.A21 6685049	£9.94	£11.93
75A - TANK CAP ASS'Y TILL G150750 FOR AUS HIT-6691747.A3 6691747	-
75B - TANK CAP ASS'Y SINCE G150751 FOR AUS HIT-6685049.A20 6685049	£9.94	£11.93
91 - MUFFLER PROTECTOR TILL B290400 HIT-6692798.A8 6692798	-
91A - MUFFLER PROTECTOR BLACK SINCE B290401 HIT-6692809.A12 6692809	£8.45	£10.14
92 - SCREW 4X15PS HIT-6695373.A12 6695373	-
94 - TAPPING SCREW D4.5X12 HIT-6684637.A0 6684637	£1.67	£2.00
95 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A38 6685114	£1.67	£2.00
96 - WASHER M5 (BLACK) HIT-6684918.A56 6684918	£1.67	£2.00
98 - MUFFLER SET FOR EUROPE HIT-6692487.A14 6692487	£29.28	£35.14
100 - MUFFLER GASKET HIT-6692745.A16 6692745	-
101 - HEAT SHIELD HIT-6687253.A13 6687253	£2.81	£3.37
102 - SPARK PLUG COVER 1 HIT-6688350.A2 6688350	-
103 - CLUTCH WASHER B HIT-6697619.A26 6697619	£1.67	£2.00
104 - CLUTCH SHOE COMP. 2 HIT-6688616.A18 6688616	£12.82	£15.38
104A - CLUTCH ARM COMP 54 SINCE F112901 HIT-6697161.A2 6697161	-
105 - CLUTCH SPRING TILL F112900 HIT-6689430.A3 6689430	£3.89	£4.67
105A - CLUTCH SPRING SINCE F112901 HIT-6697618.A0 6697618	-
106 - CLUTCH PLATE (A) HIT-6689528.A9 6689528	£1.67	£2.00
107 - STEP BOLT TILL F112900 HIT-6689627.A7 6689627	£1.67	£2.00
107A - STEP BOLT SINCE F112901 HIT-6684646.A37 6684646	£3.72	£4.46
108 - BENT WASHER 8 HIT-6684648.A102 6684648	£1.67	£2.00
109 - CLUTCH ASS'Y SINCE F112900 HIT-6696932.A0 6696932	-
110 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A0 6684647	£1.67	£2.00
111 - TAPPING SCREW D4.5X20 TILL B290400 HIT-6685191.A35 6685191	-
112 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A22 6684973	-
113 - CORD CLAMP COMP. HIT-6688011.A25 6688011	-
114 - GROMMET TILL B290400 HIT-6688040.A12 6688040	-
120 - MUFFLER SET TILL D089600 FOR AUS HIT-6692487.A13 6692487	£29.28	£35.14
120A - MUFFLER SET SINCE D089601 FOR AUS HIT-6692496.A0 6692496	-
121 - MUFFLER SPECIAL GASKET SINCE D089601 FOR AUS HIT-6692883.A21 6692883	-
122 - EXHAUST PIPE SET 1 HIT-6692709.A6 6692709	-
123 - MACHINE SCREW (W/SP. WASHER) M4X8 SINCE D089601 FOR AUS HIT-6685109.A24 6685109	-
124 - MUFFLER WIRE NET SET SINCE D089601 FOR AUS HIT-6692688.A7 6692688	-
131 - RECOIL STARTER BODY ASS'Y TILL B290100 FOR EUROPE HIT-6692986.A0 6692986	-
132 - STARTER HANDLE TILL B290100 FOR EUROPE HIT-6693240.A4 6693240	£16.35	£19.62
133 - RECOIL STARTER BODY COMP TILL B290100 FOR EUROPE HIT-6693038.A4 6693038	-
134 - ROPE TILL B290100 FOR EUROPE HIT-6693168.A55 6693168	£2.82	£3.39
135 - RECOIL SPRING TILL B290100 FOR EUROPE HIT-6693138.A11 6693138	£12.10	£14.52
137 - SPRING CASE ASS'Y TILL B290100 FOR EUROPE HIT-6693101.A9 6693101	-
139 - STARTER PULLEY TILL B290100 FOR EUROPE HIT-6693079.A5 6693079	-
140 - SPECIAL WASHER 5.2X15 TILL B290100 FOR EUROPE HIT-6687947.A19 6687947	-
141 - TAPPING SCREW D5X14 TILL B290100 FOR EUROPE HIT-6685275.A75 6685275	-
142 - STARTER BASE TILL B290100 FOR EUROPE HIT-6693470.A4 6693470	-
143 - HEX. HOLE BOLT 4X12WS TILL B290100 FOR EUROPE HIT-6695507.A4 6695507	-
144 - SQUARE NUT 5 TILL B290100 FOR EUROPE HIT-6695176.A8 6695176	-
145 - TAPPING SCREW D4.5X14 TILL B290100 FOR EUROPE HIT-6685153.A6 6685153	-
146 - STARTER PULLEY ASS'Y TILL B290100 FOR EUROPE HIT-6693408.A14 6693408	£35.37	£42.44
151 - RECOIL STARTER BODY ASS'Y SINCE B290101 TILL G035040 FOR EUROPE HIT-6692988.A7 6692988	£53.19	£63.83
152 - STARTER HANDLE SINCE B290101 TILL G035040 FOR EUROPE HIT-6693240.A3 6693240	£16.35	£19.62
153 - RECOIL STARTER BODY COMP. SINCE B290101 TILL G035040 FOR EUROPE HIT-6693039.A7 6693039	-
154 - ROPE 2.6X830 SINCE B290101 TILL G035040 FOR EUROPE HIT-6693175.A8 6693175	-
155 - RECOIL SPRING SINCE B290101 TILL G035040 FOR EUROPE HIT-6693139.A1 6693139	-
156 - SPRING CASE ASS'Y SINCE B290101 TILL G035040 FOR EUROPE HIT-6693102.A0 6693102	-
157 - STARTER ROPE REEL SINCE B290101 TILL G035040 FOR EUROPE HIT-6693080.A0 6693080	-
158 - SPECIAL WASHER 5.2X15 SINCE B290101 TILL G035040 FOR EUROPE HIT-6687947.A18 6687947	-
159 - TAPPING SCREW D5X14 SINCE B290101 TILL G035040 FOR EUROPE HIT-6685275.A76 6685275	-
160 - HEX. HOLE BOLT 4X18WS SINCE B290101 TILL G035040 FOR EUROPE HIT-6695508.A54 6695508	£1.67	£2.00
161 - FLUNGE NUT 5 SINCE B290101 TILL G035040 FOR EUROPE HIT-6695169.A10 6695169	£1.67	£2.00
162 - STARTER PULLEY ASS'Y SINCE B290101 TILL G035040 FOR EUROPE HIT-6693408.A15 6693408	£35.37	£42.44
*171B - RECOIL STARTER BODY ASS'Y INCLUD.173-179 SINCE G035041 FOR EUROPE HIT-6601570.A39 6601570	£23.15	£27.78
*171B - RECOIL STARTER BODY ASS'Y (SINCE C242201 FOR AUS) HIT-6601570.A40 6601570	£23.15	£27.78
*173 - STARTER ROPE 3.5X860 SINCE G035041 FOR EUROPE HIT-6684674.A74 6684674	£5.70	£6.84
*174 - RECOIL SPRING SINCE G035041 FOR EUROPE HIT-6684675.A36 6684675	£8.82	£10.58
175A - STARTER ROPE REEL SINCE TL025481 HIT-6699997.A9 6699997	-
*176 - DAMPER SPRING SINCE G035041 FOR EUROPE HIT-6684677.A92 6684677	£6.66	£7.99
177A - CAM PLATE SINCE TL025481 HIT-6699996.A80 6699996	£4.28	£5.13
*178 - SET SCREW SINCE G035041 FOR EUROPE HIT-6684679.A127 6684679	£2.98	£3.57
*179 - STARTER HANDLE SINCE G035041 FOR EUROPE HIT-6684680.A24 6684680	£5.87	£7.04
*180 - STARTER PULLEY ASS'Y SINCE G035041 FOR EUROPE HIT-6684681.A92 6684681	£18.16	£21.79
*181 - HEX. HOLE BOLT 4X18WS SINCE G035041 FOR EUROPE HIT-6695508.A55 6695508	£1.67	£2.00
*182 - D4E RETAINING RING SINCE G035041 FOR EUROPE HIT-6685101.A108 6685101	-
*183 - STARTER PAWL SPRING SINCE G035041 FOR EUROPE HIT-6684684.A30 6684684	£3.29	£3.95
*184 - STARTER PAWL SINCE G035041 FOR EUROPE HIT-6684685.A81 6684685	£5.07	£6.08
*185 - CAMPLATE ASS'Y SINCE G035040 TILL TL025480 FOR EUROPE HIT-6699691.A43 6699691	£7.75	£9.30
191 - RECOIL STARTER BODY ASS'Y TILL C242200 FOR AUS HIT-6684938.A7 6684938	£18.59	£22.31
192 - RECOIL STARTER BODY COMP. TILL C242200 FOR AUS HIT-6684944.A7 6684944	-
193 - STARTER ROPE REEL TILL C242200 FOR AUS HIT-6684941.A9 6684941	£7.41	£8.89
194 - RECOIL SPRING TILL C242200 FOR AUS HIT-6684942.A7 6684942	£5.17	£6.20
195 - SWING ARM TILL C242200 FOR AUS HIT-6684940.A7 6684940	£1.67	£2.00
196 - SET SCREW TILL C242200 FOR AUS HIT-6684679.A128 6684679	£2.98	£3.57
197 - PULLEY STAY TILL C242200 FOR AUS HIT-6684939.A8 6684939	-
198 - ROPE 3.0X800 TILL C242200 FOR AUS HIT-6684943.A8 6684943	-
199 - STARTER HANDLE TILL C242200 FOR AUS HIT-6684680.A23 6684680	£5.87	£7.04
200 - SPECIAL NUT M5 TILL C242200 FOR AUS HIT-6685000.A19 6685000	-
201 - STARTER PULLEY TILL C242200 FOR AUS HIT-6684937.A8 6684937	£3.56	£4.27
202 - HEX. HOLE BOLT 4X15/PS TILL C242200 FOR AUS HIT-6684682.A23 6684682	£1.67	£2.00
231 - CLEANER ASSY HIT-6690048.A2 6690048	£11.61	£13.93
232 - CLEANER COVER SET HIT-6690391.A13 6690391	£7.48	£8.97
233 - AIR CLEANER ELEMENT HIT-6684654.A14 6684654	£1.67	£2.00
234 - SPECIAL SCREW HIT-6689737.A13 6689737	-
235 - CLEANER BODY COMP. HIT-6684656.A12 6684656	£7.64	£9.17
236 - CHOKE VALVE HIT-6684657.A2 6684657	£2.81	£3.37
237 - WAVE WASHER 8 HIT-6684658.A35 6684658	£1.67	£2.00
238 - COLLAR 8 HIT-6684659.A2 6684659	-
281 - PUMP BODY COMP. HIT-6684879.A17 6684879	£35.37	£42.44
282 - PRIMING PUMP COMP. HIT-6684687.A22 6684687	£9.27	£11.12
283 - DIAPHRAGM COVER HIT-6684688.A77 6684688	£5.70	£6.84
284 - PRIMING BODY HIT-6684689.A22 6684689	£5.87	£7.04
285 - METERING DIAPHRAGM COMP. HIT-6690830.A14 6690830	£14.58	£17.50
286 - DIAPHRAGM GASKET HIT-6684691.A20 6684691	£5.70	£6.84
287 - PUMP DIAPHRAGM HIT-6684693.A53 6684693	£5.70	£6.84
288 - PUMP GASKET HIT-6691457.A28 6691457	£8.48	£10.18
*289 - MAIN JET #38 FOR EUROPE HIT-6691844.A11 6691844	-
*289 - MAIN JET #40 FOR AUS HIT-6691845.A2 6691845	-
290 - O-RING HIT-6684695.A140 6684695	£1.67	£2.00
291 - STOP RING HIT-6684696.A57 6684696	-
292 - SWIVEL HIT-6684697.A111 6684697	-
293 - THROTTLE SET SCREW HIT-6684698.A20 6684698	-
294 - SET SCREW HIT-6684699.A79 6684699	-
295 - INLET SCREEN HIT-6684700.A62 6684700	-
301 - CLUTCH SHAFT COMP. HIT-6688602.A1 6688602	-
303 - ANTI-VIBE RUBBER HIT-6691839.A13 6691839	£5.92	£7.11
304 - HEX. HOLE BOLT 5X16 HIT-6695046.A38 6695046	£1.67	£2.00
305 - HEX. HOLE BOLT M5X25/S HIT-6684709.A190 6684709	£1.67	£2.00
306 - FAN CASE 1 HIT-6687029.A3 6687029	£26.97	£32.36
307 - PIPE HOLDER 1 HIT-6689651.A15 6689651	£8.88	£10.66
308 - WASHER M5 (BLACK) HIT-6684918.A57 6684918	£1.67	£2.00
309 - GEAR CASE WASHER HIT-6689159.A35 6689159	-
310 - METAL FITTING HIT-6689664.A19 6689664	£6.12	£7.35
321 - DRIVE SHAFT PIPE ASS'Y HIT-6689372.A4 6689372	-
322 - CUTTER CASE ASS'Y HIT-6684770.A0 6684770	-
323 - MAIN PIPE HIT-6689369.A0 6689369	-
324 - FLEXIBLE LINER HIT-6684772.A4 6684772	-
325 - FLEXIBLE SHAFT HIT-6684773.A0 6684773	£19.43	£23.32
326 - CUTTER SHAFT HIT-6684774.A4 6684774	-
327 - BALL BEARING 608DD HIT-6684775.A0 6684775	-
328 - COLLAR HIT-6684776.A4 6684776	-
329 - SCREW 5X12 HIT-6694885.A4 6694885	-
330 - CUTTER CASE HIT-6684778.A0 6684778	-
331 - HEX. SOCKET HD. BOLT (W/WASHERS) M5X30 HIT-6684779.A4 6684779	-
332 - SPECIAL NUT HIT-6684780.A0 6684780	-
333 - STOP RING R-22 1 HIT-6684781.A4 6684781	-
334 - CUTTER HOLDER HIT-6684782.A0 6684782	-
335A - GUARD SINCE D085851 HIT-6684783.A4 6684783	£14.02	£16.83
336 - SAFETY GUARD BRACKET TILL D085850 HIT-6690310.A1 6690310	-
336A - COVER BRACKET22 SINCE D085851 HIT-6684784.A0 6684784	-
337 - S.WASHER 6 TILL D085850 HIT-6695219.A22 6695219	£1.67	£2.00
338 - PLUS BOLT 6X18 TILL D085850 HIT-6695020.A4 6695020	-
339 - GUARD HOLDER SINCE D085851 HIT-6684785.A5 6684785	-
340 - HEX. SOCKET HD. BOLT M5X30 S SINCE D085851 HIT-6684786.A0 6684786	£1.67	£2.00
341 - KNIFE TILL D085850 HIT-6684750.A39 6684750	£3.64	£4.37
341A - KNIFE SINCE D085851 HIT-6684754.A36 6684754	£6.64	£7.97
343 - SCREW 4X8/S TILL D085850 HIT-6695325.A7 6695325	-
343A - TAPPING SCREW 5X20 SINCE D085851 HIT-6684753.A56 6684753	£1.67	£2.00
344 - SCREW TILL D085850 HIT-6684967.A0 6684967	£1.67	£2.00
345 - HOLDER 2 HIT-6689501.A5 6689501	-
346 - SHAFT GRIP FOR EUROPE HIT-6697837.A0 6697837	-
347 - SPACER HIT-6684789.A4 6684789	-
348 - FLANGE FOR AUS HIT-6684969.A0 6684969	-
349 - HANGER FOR AUS HIT-6684966.A0 6684966	-
350 - SCREW 5X16/S FOR AUS HIT-6695337.A8 6695337	-
351 - NUT M5 FOR AUS HIT-6684965.A59 6684965	£1.67	£2.00
352 - S.WASHER 8 FOR AUS HIT-6684971.A8 6684971	-
353 - BOLT WASHER M8 FOR AUS HIT-6684611.A19 6684611	-
354 - HEX. NUT M8 FOR AUS HIT-6684612.A100 6684612	-
361 - THROTTLE WIRE COMP. FOR EUROPE (TILL D089600 FOR AUS) HIT-6693819.A4 6693819	£6.12	£7.35
362 - LOOP HANDLE HIT-6684791.A0 6684791	-
363 - NUT M6 HIT-6684792.A29 6684792	-
364 - HANDLE BRACKET (A) HIT-6684793.A0 6684793	-
365 - BOLT WASHER 6 HIT-6684639.A2 6684639	£1.67	£2.00
366 - PLUS BOLT 6X40 HIT-6684795.A1 6684795	-
367 - STOP CORD 2 HIT-6687915.A1 6687915	-
368 - PROTECTION TUBE 10X170L FOR EUROPE(TILL D089600 FOR AUS) HIT-6687562.A4 6687562	£1.67	£2.00
369 - THROTTLE LEVER ASS'Y FOR EUROPE (TILL D089600 FOR AUS) HIT-6693755.A1 6693755	-
370 - STOP SWITCH FOR EUROPE (TILL D089600 FOR AUS) HIT-6687515.A0 6687515	£1.67	£2.00
371 - TAPPING SCREW 3X8 FOR EUROPE (TILL D089600 FOR AUS) HIT-6695274.A2 6695274	-
372 - STOP SWITCH BASE FOR EUROPE (TILL D089600 FOR AUS) HIT-6688374.A8 6688374	-
373 - STOP SWITCH SPRING FOR EUROPE (TILL D089600 FOR AUS) HIT-6688385.A5 6688385	-
374 - EARTH TERMINAL B FOR EUROPE (TILL D089600 FOR AUS) HIT-6687805.A1 6687805	-
375 - EARTH TERMINAL A FOR EUROPE (TILL D089600 FOR AUS) HIT-6687801.A6 6687801	-
376 - SPECIAL NUT M5 FOR EUROPE (TILL D089600 FOR AUS) HIT-6685000.A18 6685000	-
377 - STOP RING E-6 FOR EUROPE (TILL D089600 FOR AUS) HIT-6695311.A14 6695311	£1.67	£2.00
378 - RETURN SPRING FOR EUROPE (TILL D089600 FOR AUS) HIT-6693601.A7 6693601	-
379 - THROTTLE ARM FOR EUROPE (TILL D089600 FOR AUS) HIT-6693804.A1 6693804	-
380 - SCREW 5X20 FOR EUROPE (TILL D089600 FOR AUS) HIT-6695453.A1 6695453	-
381 - LOCK BUTTON SHAFT FOR EUROPE (TILL D089600 FOR AUS) HIT-6693653.A6 6693653	-
382 - LOCK BUTTON SPRING FOR EUROPE (TILL D089600 FOR AUS) HIT-6694834.A1 6694834	-
383 - LOCK BUTTON FOR EUROPE (TILL D089600 FOR AUS) HIT-6694829.A6 6694829	-
384 - SPACER SINCE D089601 FOR AUS HIT-6684794.A0 6684794	-
385 - PLUS BOLT 6X40 FOR AUS HIT-6684795.A0 6684795	-
386 - WING BOLT M6 FOR AUS HIT-6684968.A0 6684968	-
387 - THROTTLE LEVER ASS'Y SINCE D089601 FOR AUS HIT-6693769.A6 6693769	-
388 - THROTTLE WIRE COMP. SINCE D089601 FOR AUS HIT-6693982.A1 6693982	£36.27	£43.52
389 - THROTTLE WIRE 4T SINCE D089601 FOR AUS HIT-6694025.A1 6694025	£14.47	£17.36
390 - STOP BUTTON COMP. SINCE D089601 FOR AUS HIT-6687452.A3 6687452	£28.71	£34.45
391 - PROTECTION TUBE 7X145L SINCE D089601 FOR AUS HIT-6687523.A8 6687523	-
392 - TRIGGER LOCK OUT SINCE D089601 FOR AUS HIT-6684721.A10 6684721	£5.17	£6.20
393 - RETURN SPRING SINCE D089601 FOR AUS HIT-6684722.A37 6684722	£1.67	£2.00
394 - BLIND PLUG SINCE D089601 FOR AUS HIT-6684724.A34 6684724	-
395 - SCREW M5X20 SINCE D089601 FOR AUS HIT-6684803.A19 6684803	-
396 - CONTAL NUT 5 SINCE D089601 FOR AUS HIT-6684727.A10 6684727	£1.67	£2.00
397 - SCREW M4X20 (BLACK) SINCE D089601 FOR AUS HIT-6684725.A2 6684725	-
398 - THROTTLE LEVER SINCE D089601 FOR AUS HIT-6684804.A11 6684804	£6.86	£8.23
501 - HEX. BAR WRENCH 4MM HIT-6684813.A0 6684813	-
502 - COMBI BOX SPANNER 13X19 PLUS HIT-6684979.A0 6684979	-
504A - PROTECTIVE GLASSES HIT-875769.A137 875769	-
505 - NYLON HEAD CH-100 FOR AUS HIT-6695786.A1 6695786	-
506 - SHOULDER STRAP S FOR AUS HIT-6695795.A16 6695795	-
507 - NYLON HEAD BF-4 FOR EUROPE HIT-6695782.A4 6695782	£17.22	£20.66
508 - SPECIAL WASHER FOR EUROPE HIT-6684806.A4 6684806	-
509 - CUTTING BODY FOR EUROPE HIT-6684807.A0 6684807	-
510 - MOUNTING NUT M8X1.25F FOR EUROPE HIT-6684808.A4 6684808	-
511 - REEL SPRING FOR EUROPE HIT-6684809.A0 6684809	£9.10	£10.92
512 - EYELET FOR EUROPE HIT-6684810.A25 6684810	£3.29	£3.95
513 - SPOOL FOR EUROPE HIT-6684811.A0 6684811	£15.71	£18.85
514 - NYLON CORD CAP FOR EUROPE HIT-6684812.A4 6684812	-
601 - CYMBOL MARK TBC-230BS HIT-6694644.A0 6694644	-
602 - S?START MARK HIT-6694472.A0 6694472	-
603 - CAUTION MARK TANAKA HIT-6697851.A0 6697851	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki TBC-230BS Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki TBC-230BS Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki TBC-230BS Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
