Hitachi / Hikoki TBC-225S Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki TBC-225S Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A56 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPM6A HIT-6699317.A10 6699317	-
3 - CYLINDER SET HIT-6685489.A3 6685489	£62.25	£74.70
4 - HEX.HOLE BOLT M5X18/S HIT-6684586.A58 6684586	-
5 - CYLINDER GASKET HIT-6685709.A13 6685709	£1.67	£2.00
6 - PISTON RING HIT-6686118.A32 6686118	£6.94	£8.33
7 - PISTON ASS'Y HIT-6685869.A17 6685869	£28.00	£33.60
8 - CIR CLIP HIT-6684590.A63 6684590	£1.67	£2.00
9 - PISTON PIN HIT-6696944.A40 6696944	£5.61	£6.73
10 - CRANK SHAFT COMP. HIT-6686217.A1 6686217	£42.70	£51.24
11 - HIGH TENSION CORD 140L HIT-6687888.A5 6687888	£3.89	£4.67
13 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A40 6684682	£1.67	£2.00
14 - IGNITION COIL ASS'Y HIT-6699772.A18 6699772	-
15 - RUBBER CAP HIT-6684602.A23 6684602	-
18 - STOP CORD COMP. HIT-6687826.A1 6687826	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A50 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A31 6684605	-
32 - CRANK CASE ASS'Y HIT-6686585.A11 6686585	£78.55	£94.26
33 - OIL SEAL TB 12227 HIT-6684607.A59 6684607	£4.07	£4.88
34 - BALL BEARING 6001 C3 HIT-6684608.A139 6684608	£5.70	£6.84
35 - CRANK CASE GASKET HIT-6686719.A0 6686719	£1.67	£2.00
36 - HEX.HOLE BOLT M5X18/S HIT-6684586.A57 6684586	-
37 - MAGNETO ASS'Y HIT-6601171.A1 6601171	-
38 - BOLT WASHER M8 HIT-6684611.A68 6684611	-
39 - HEX. NUT M8 HIT-6684612.A53 6684612	-
51 - INLET MANIFOLD GASKET HIT-6689890.A10 6689890	£1.67	£2.00
52 - CARB INSULATOR SET HIT-6689914.A1 6689914	£8.34	£10.01
53 - CARBURETOR GASKET HIT-6684615.A26 6684615	£1.67	£2.00
54 - HEX.HOLE BOLT 5X22/WS HIT-6695514.A17 6695514	-
57 - SHIELD TUBE HIT-6688174.A5 6688174	-
58 - CLIP D6 HIT-6685198.A19 6685198	-
59A - PUMP FILTER BODY COMP HIT-66A3864.A7 66A3864	-
60 - TANK 1 HIT-6691592.A9 6691592	£11.38	£13.66
60A - TANK(EVAPO) SINCE D001001 HIT-6691595.A0 6691595	-
62 - COLLAR 5.8 HIT-6692244.A42 6692244	£1.67	£2.00
63 - CARBURETOR SET WYL182 HIT-6690512.A7 6690512	£69.17	£83.00
64 - SWIVEL CAP HIT-6691337.A49 6691337	£1.67	£2.00
65 - HEX. HOLE BOLT 5X16/PS HIT-6695504.A20 6695504	£1.67	£2.00
66 - SCREW 5X20WS HIT-6695516.A5 6695516	-
68 - FUEL PIPE 3X5X85 HIT-6684880.A19 6684880	-
69 - RETURN GROMMET HIT-6697846.A13 6697846	£2.08	£2.50
71 - PLUS SCREW 5X60WS HIT-6695431.A11 6695431	-
72 - O-RING P-15 HIT-6698966.A10 6698966	£1.67	£2.00
74 - TANK CAP D ASS'Y HIT-6691748.A22 6691748	£6.04	£7.25
91 - MUFFLER PROTECTOR BLACK HIT-6692809.A6 6692809	£8.45	£10.14
92 - SCREW 4X15PS HIT-6695373.A2 6695373	-
94 - TAPPING SCREW D4.5X12 HIT-6684637.A13 6684637	£1.67	£2.00
95 - HEX. SOCKET HD. BOLT M5X50 HIT-6685114.A6 6685114	£1.67	£2.00
96 - WASHER M5 (BLACK) HIT-6684918.A42 6684918	£1.67	£2.00
98 - MUFFLER SET HIT-6692496.A2 6692496	-
100 - MUFFLER GASKET HIT-6692745.A4 6692745	-
101 - HEAT SHIELD HIT-6687253.A1 6687253	£2.81	£3.37
103 - CLUTCH WASHER B HIT-6684642.A9 6684642	£1.67	£2.00
104 - CLUTCH SHOE COMP. 2 HIT-6688616.A3 6688616	£12.82	£15.38
105 - CLUTCH SPRING HIT-6689430.A6 6689430	£3.89	£4.67
106 - CLUTCH PLATE A 0.5 HIT-6684645.A21 6684645	£1.67	£2.00
107 - STEP BOLT HIT-6689627.A23 6689627	£1.67	£2.00
108 - BENT WASHER 8 HIT-6684648.A36 6684648	£1.67	£2.00
110 - HEX. HOLE BOLT M5X18/WS HIT-6684647.A16 6684647	£1.67	£2.00
112 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A6 6684973	-
113 - CORD CLAMP COMP. HIT-6688011.A4 6688011	-
114 - MUFFLER SPECIAL GASKET HIT-6692883.A9 6692883	-
115 - EXHAUST PIPE SET 1 HIT-6692709.A1 6692709	-
116 - MACHINE SCREW (W/SP. WASHER) M4X8 HIT-6685109.A13 6685109	-
117 - MUFFLER WIRE NET SET HIT-6692688.A5 6692688	-
131B - RECOIL STARTER BODY ASS'Y INCLUD.133-139 HIT-6601570.A69 6601570	£23.15	£27.78
133 - STARTER ROPE 3.5X860 HIT-6684674.A31 6684674	£5.70	£6.84
134 - RECOIL SPRING HIT-6684675.A108 6684675	£8.82	£10.58
135A - STARTER ROPE REEL SINCE TL025481 HIT-6699997.A48 6699997	-
136 - DAMPER SPRING HIT-6684677.A38 6684677	£6.66	£7.99
137A - CAM PLATE SINCE TL025481 HIT-6699996.A41 6699996	£4.28	£5.13
138 - SET SCREW HIT-6684679.A57 6684679	£2.98	£3.57
139 - STARTER HANDLE HIT-6684680.A71 6684680	£5.87	£7.04
140 - STARTER PULLEY ASS'Y HIT-6684681.A43 6684681	£18.16	£21.79
141 - HEX. HOLE BOLT 4X18WS HIT-6695508.A18 6695508	£1.67	£2.00
142 - STOP RING E-5 HIT-6684683.A7 6684683	-
143 - STARTER PAWL SPRING HIT-6684684.A70 6684684	£3.29	£3.95
144 - STARTER PAWL HIT-6684685.A45 6684685	£5.07	£6.08
145 - CAMPLATE ASS'Y TILL TL025480 HIT-6699691.A29 6699691	£7.75	£9.30
171 - AIR CLEANER ASS'Y HIT-6690005.A1 6690005	-
172 - AIR CLEANER CAP HIT-6690139.A6 6690139	£7.15	£8.58
173 - CLEANER ELEMENT HIT-6690347.A14 6690347	£7.15	£8.58
175 - COLLAR HIT-6690801.A9 6690801	-
176 - CLEANER BODY COMP. HIT-6690085.A1 6690085	-
191 - PUMP BODY COMP. HIT-6684879.A49 6684879	£35.37	£42.44
192 - PRIMING PUMP COMP. HIT-6684687.A60 6684687	£9.27	£11.12
193 - DIAPHRAGM COVER HIT-6684688.A39 6684688	£5.70	£6.84
194 - PRIMING BODY HIT-6684689.A60 6684689	£5.87	£7.04
195 - METERING DIAPHRAGM COMP. HIT-6690830.A33 6690830	£14.58	£17.50
196 - DIAPHRAGM GASKET HIT-6684691.A64 6684691	£5.70	£6.84
197 - PUMP DIAPHRAGM HIT-6684693.A125 6684693	£5.70	£6.84
198 - PUMP GASKET HIT-6691457.A49 6691457	£8.48	£10.18
199 - MAIN JET #38 HIT-6691844.A1 6691844	-
200 - O-RING HIT-6684695.A73 6684695	£1.67	£2.00
201 - STOP RING HIT-6684696.A140 6684696	-
202 - SWIVEL HIT-6684697.A49 6684697	-
203 - THROTTLE SET SCREW HIT-6684698.A47 6684698	-
204 - SET SCREW HIT-6684699.A31 6684699	-
205 - INLET SCREEN HIT-6684700.A162 6684700	-
221 - CLUTCH DRUM COMP. HIT-6688604.A0 6688604	-
222 - TAPPING SCREW D4.5X14 HIT-6685152.A11 6685152	-
223 - HEX.HOLE BOLT M5X30/WS HIT-6684973.A8 6684973	-
224 - FAN CASE COMP OR HIT-6687031.A1 6687031	-
225 - SQUARE NUT 5 HIT-6695176.A4 6695176	-
226 - SPACER HIT-6688311.A1 6688311	-
227 - STOP RING C-10 1 HIT-6684821.A26 6684821	£1.67	£2.00
251 - DRIVE SHAFT 1480L HIT-6696009.A6 6696009	£16.15	£19.38
252 - DRIVE SHAFT PIPE COMP.1450L HIT-6689410.A4 6689410	£27.59	£33.11
253 - BUSH ASS'Y HIT-6684831.A22 6684831	-
254 - NUT M5 (BLACK) HIT-6685075.A4 6685075	-
255 - FRONT HANDLE 24 HIT-6691057.A2 6691057	-
256 - HEX.HOLE BOLT 5X30S HIT-6695426.A3 6695426	-
257 - THROTTLE WIRE HIT-6693983.A1 6693983	-
258 - THROTTLE LEVER ASS'Y 24 HIT-6693770.A2 6693770	-
259 - THROTTLE LEVER HIT-6685006.A4 6685006	-
260 - RETURN SPRING HIT-6684998.A5 6684998	-
261 - STOP SWITCH HIT-6685009.A4 6685009	-
262 - SWITCH MARK HIT-6685003.A1 6685003	-
263 - STOP SWITCH COMP. HIT-6687462.A3 6687462	-
264 - MACHINE SCREW M5X30 HIT-6685076.A3 6685076	-
265 - NUT M5 HIT-6684965.A2 6684965	£1.67	£2.00
266 - PROTECTION TUBE D7X170 HIT-6685007.A1 6685007	-
267 - SHAFT GRIP HIT-6691183.A2 6691183	-
301 - GEAR CASE ASS'Y HIT-6688822.A0 6688822	-
302 - HEX. HOLE BOLT M5X25/S HIT-6684709.A67 6684709	£1.67	£2.00
303 - STOP RING C-24 1 HIT-6684732.A6 6684732	£1.67	£2.00
304 - STOP RING C-9 1 HIT-6695281.A8 6695281	-
305 - BALL BEARING 609Z ST HIT-6684735.A28 6684735	£15.48	£18.57
306 - GEAR CASE 24 HIT-6688815.A0 6688815	-
307 - SCREW 5X12/W.S HIT-6695414.A23 6695414	£1.67	£2.00
308 - OILING BOLT HIT-6689109.A27 6689109	-
309 - BALL BEARING 626 1 HIT-6695567.A7 6695567	-
310 - GEAR SHAFT HIT-6688948.A0 6688948	-
311 - BALL BEARING 6000D 1 HIT-6695527.A0 6695527	£12.50	£15.00
312 - RETAINING RING C-TYPE D26 HIT-6695294.A3 6695294	-
313 - CUTTER HOLDER HIT-6689033.A7 6689033	£11.61	£13.93
314 - GEAR/PINION SET HIT-6688883.A0 6688883	£24.88	£29.85
315 - GEAR CASE COVER HIT-6688917.A9 6688917	£1.67	£2.00
341 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A3 6685064	-
342 - S.WASHER 6 HIT-6684826.A11 6684826	£1.67	£2.00
343 - GUARD BRACKET HIT-6685065.A6 6685065	-
344 - SAFETY COVER COMP. HIT-6685066.A0 6685066	-
345 - MACHINE SCREW (W/SP. WASHER) M4X12 HIT-6685068.A0 6685068	-
346 - BOLT WASHER M4 HIT-6685070.A0 6685070	£1.67	£2.00
347 - KNIFE HIT-6685067.A3 6685067	-
348 - NUT M4 HIT-6685069.A30 6685069	-
501 - HEX. BAR WRENCH 4MM HIT-6684813.A50 6684813	-
502 - COMBI BOX SPANNER 13X19 HIT-6693588.A0 6693588	-
