Hitachi / Hikoki SUM500DX Engine Brush Cutter Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki SUM500DX Engine Brush Cutter

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A68 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPMR6A HIT-6699319.A7 6699319	-
3 - CYLINDER SET HIT-6685474.A0 6685474	£106.65	£127.98
4 - HEX.HOLE BOLT M5X20/S HIT-6684668.A24 6684668	-
5 - CYLINDER GASKET HIT-6685740.A0 6685740	£2.81	£3.37
6 - PISTON RING HIT-6686123.A9 6686123	-
7 - PISTON SET HIT-6685888.A0 6685888	£34.65	£41.58
8 - PISTON PIN 10X30 HIT-6686007.A24 6686007	£3.52	£4.23
9 - PISTON PIN CIRCLIP HIT-6686032.A12 6686032	£1.67	£2.00
10 - CRANK SHAFT COMP. HIT-6686191.A0 6686191	£121.17	£145.40
11 - WOOD-RUFF KEY 3X13X5 HIT-6686457.A26 6686457	£1.67	£2.00
12 - IGNITION COIL COMP. HIT-6687655.A2 6687655	£32.83	£39.40
13 - RUBBER CAP HIT-6684602.A7 6684602	-
14 - HIGH TENSION CORD HIT-6687885.A4 6687885	£1.67	£2.00
15 - SPECIAL CORD B190M HIT-6687853.A2 6687853	-
16 - IGNITION COIL ASS'Y HIT-6687657.A11 6687657	£33.12	£39.74
17 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A16 6684599	-
18 - CORD CLAMP COMP. HIT-6688011.A13 6688011	-
31 - SMALL NUT 10 HIT-6695139.A37 6695139	-
32 - CRANK CASE ASS'Y HIT-6686556.A0 6686556	-
33 - NO LONGER AVAILABLE HIT-6686714.A2 6686714	-
34 - OIL SEAL UD15257 HIT-6695637.A12 6695637	£3.66	£4.39
35 - BALL BEARING #6202 2 HIT-6695557.A8 6695557	-
*36 - CRANK SHAFT SHIM 0.10 HIT-6686470.A11 6686470	-
*36 - CRANK SHAFT SHIM 0.20 HIT-6686472.A6 6686472	£1.67	£2.00
*36 - CRANK SHAFT SHIM 0.30 HIT-6686473.A25 6686473	£1.67	£2.00
37 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A74 6684786	£1.67	£2.00
38 - MAGNETO ROTOR COMP. HIT-6687372.A7 6687372	-
39 - WASHER 10 HIT-6695198.A8 6695198	-
40 - NUT 10 HIT-6695138.A1 6695138	-
41 - SPARK PLUG COVER HIT-6688346.A5 6688346	£5.01	£6.01
42 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A71 6684634	£1.67	£2.00
43 - FAN CASE HIT-6686982.A7 6686982	-
44 - HEX.HOLE BOLT M5X20/S HIT-6684668.A23 6684668	-
45 - PRIMARY CORD GROMMET HIT-6688057.A0 6688057	-
46 - WASHER M5 (BLACK) HIT-6685226.A10 6685226	-
61 - INLET MANIFOLD GASKET HIT-6689885.A0 6689885	£2.81	£3.37
62 - CARB.INSULATOR SET 1 HIT-6689955.A0 6689955	£16.19	£19.43
63 - CARBURETOR GASKET HIT-6689833.A7 6689833	£1.67	£2.00
65 - COLLAR HIT-6690802.A2 6690802	£2.81	£3.37
66 - CLEANER BODY COMP. HIT-6690099.A6 6690099	£13.72	£16.47
67 - CHOKE VALVE HIT-6691258.A11 6691258	£3.62	£4.35
68 - BLOW OVER CHECK BOARD HIT-6690843.A33 6690843	£1.67	£2.00
69 - CLEANER ELEMENT 6T HIT-6690352.A9 6690352	£1.67	£2.00
70 - WAVE WASHER 8 HIT-6684658.A3 6684658	£1.67	£2.00
71 - CLEANER COVER ASS'Y HIT-6690397.A13 6690397	£6.61	£7.93
72 - SPECIAL SCREW HIT-6689737.A25 6689737	-
73 - SCREW 5X57/S HIT-6695353.A29 6695353	£1.67	£2.00
*74 - CARBURETOR SET WYJ168 TILL B044000 HIT-6690470.A4 6690470	£67.33	£80.80
*74 - CARBURETOR SET WYJ389 SINCE B044001 HIT-6690474.A4 6690474	£91.62	£109.95
75 - HEX. HOLE BOLT M5X25WS HIT-6695515.A6 6695515	£1.67	£2.00
76 - FUEL PIPE ASS'Y 3X5X230 HIT-6688166.A6 6688166	£5.17	£6.20
77A - CLIP D6 HIT-6685198.A7 6685198	-
78B - PUMP FILTER BODY COMP SINCE TL044141 HIT-66A3864.A37 66A3864	-
79 - TANK HIT-6691533.A5 6691533	£13.82	£16.59
80 - COLLAR 5.8 HIT-6692244.A66 6692244	£1.67	£2.00
81 - TANK CAP D ASS'Y 1 HIT-6691763.A31 6691763	£13.46	£16.15
82 - HEX. HOLE BOLT 5X18PS HIT-6695505.A32 6695505	-
83 - FUEL PIPE 3X5X85 HIT-6684880.A13 6684880	-
84 - FUEL PIPE GROMMET HIT-6688156.A0 6688156	-
85 - TANK CAP CHAIN HIT-6684625.A90 6684625	-
90 - PUMP FILTER ASS'Y TILL TL044140 HIT-6601175.A9 6601175	-
101 - MUFFLER PROTECTOR HIT-6692780.A5 6692780	-
102 - WASHER M5 (BLACK) HIT-6684918.A5 6684918	£1.67	£2.00
103 - HEX.HOLE BOLT M5X12/S HIT-6684667.A85 6684667	£1.67	£2.00
104 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A0 6695512	-
105 - HEX. HOLE BOLT M6X65 HIT-6695067.A41 6695067	£1.67	£2.00
106 - BOLT WASHER 6 HIT-6684639.A200 6684639	£1.67	£2.00
*107 - MUFFLER SET FOR EUROPE HIT-6692469.A0 6692469	-
*107 - MUFFLER SET FOR AUS HIT-6601185.A0 6601185	-
108 - MUFFLER GASKET HIT-6692741.A21 6692741	£3.89	£4.67
109 - HEAT SHIELD HIT-6687243.A2 6687243	-
110 - TAIL PIPE COMP. HIT-6692593.A0 6692593	-
111 - SCREW 4X12 HIT-6694865.A4 6694865	-
112 - NUT M4 HIT-6685069.A22 6685069	-
113 - CLUTCH WASHER B HIT-6689645.A49 6689645	£1.67	£2.00
114 - CLUTCH ARM COMP. HIT-6688614.A6 6688614	£9.58	£11.50
115 - CLUTCH SPRING HIT-6689428.A13 6689428	£2.98	£3.57
116 - WAVE WASHER 10 HIT-6695203.A22 6695203	£1.67	£2.00
117 - CLUTCH STEP BOLT HIT-6689632.A12 6689632	£4.26	£5.11
118 - CLUTCH SET ASS'Y HIT-6699556.A9 6699556	-
119 - MUFFLER SPECIAL GASKET FOR AUS HIT-6692883.A1 6692883	-
120 - TAIL PIPE SET FOR AUS HIT-6601184.A0 6601184	-
121 - MACHINE SCREW (W/SP. WASHER) M4X8 FOR AUS HIT-6685109.A3 6685109	-
131A - RECOIL STARTER BODY ASS'Y HIT-6697645.A7 6697645	£28.11	£33.73
132 - RECOIL STARTER BODY COMP. TILL G103210 HIT-6693025.A1 6693025	£14.11	£16.93
132A - RECOIL STARTER BODY COMP SINCE G103211 HIT-6697646.A16 6697646	-
133 - STARTER ROPE REEL TILL G103210 HIT-6693007.A9 6693007	£12.57	£15.08
133A - STARTER ROPE REEL SINCE G103211 HIT-6697647.A7 6697647	-
134 - RECOIL SPRING TILL G103210 HIT-6693114.A25 6693114	£9.02	£10.82
134A - RECOIL SPRING SINCE G103211 HIT-6697648.A16 6697648	-
135 - STARTER ROPE TILL G103210 HIT-6693165.A23 6693165	-
135A - STARTER ROPE SINCE G103211 HIT-6697649.A8 6697649	-
136 - STARTER HANDLE CAP TILL G103210 HIT-6693607.A1 6693607	-
137 - STARTER HANDLE TILL G103210 HIT-6693232.A25 6693232	-
137A - STARTER HANDLE SINCE G103211 HIT-6697650.A15 6697650	-
138 - SET SCREW HIT-6693634.A4 6693634	-
139 - STARTER PAWL TILL G103210 HIT-6693302.A3 6693302	£3.89	£4.67
139A - STARTER PAWL SINCE G103211 HIT-6697643.A8 6697643	-
*140 - D4E RETAINING RING TILL G103210 HIT-6685101.A53 6685101	-
*140 - D4E RETAINING RING SINCE G103211 HIT-6685101.A54 6685101	-
141 - HEX.HOLE BOLT 5X20/PS HIT-6684634.A70 6684634	£1.67	£2.00
142 - STARTER PAWL SPRING TILL G103210 HIT-6693345.A12 6693345	£3.89	£4.67
142A - STARTER PAWL SPRING SINCE G103211 HIT-6697642.A15 6697642	-
143 - STARTER PULLEY TILL G103210 HIT-6693395.A24 6693395	£11.02	£13.22
143A - STARTER PULLEY ASS'Y SINCE G103211 HIT-6697644.A15 6697644	£12.94	£15.53
161 - PUMP BODY COMP. HIT-6684879.A62 6684879	£35.37	£42.44
162 - PRIMING PUMP COMP. HIT-6684687.A84 6684687	£9.27	£11.12
163 - DIAPHRAGM COVER HIT-6684688.A15 6684688	£5.70	£6.84
164 - PRIMING BODY HIT-6684689.A86 6684689	£5.87	£7.04
165 - METERING DIAPHRAGM COMP. HIT-6690827.A0 6690827	£14.02	£16.83
166 - DIAPHRAGM GASKET HIT-6684691.A84 6684691	£5.70	£6.84
167 - PUMP DIAPHRAGM HIT-6684693.A167 6684693	£5.70	£6.84
168 - PUMP GASKET HIT-6691457.A72 6691457	£8.48	£10.18
169 - MAIN JET #51 HIT-6696382.A2 6696382	-
170 - O-RING HIT-6684695.A36 6684695	£1.67	£2.00
171 - STOP RING HIT-6684696.A181 6684696	-
172 - SWIVEL HIT-6684697.A26 6684697	-
173 - THROTTLE VALVE COMP. TILL B044000 HIT-6690944.A1 6690944	-
174 - THROTTLE SET SCREW HIT-6684870.A5 6684870	-
175 - CABLE ADJUSTER STAY HIT-6684873.A68 6684873	-
176 - LOCK NUT M6 HIT-6684872.A5 6684872	-
177 - CABLE ADJUSTER HIT-6684871.A59 6684871	-
178 - CLEANER PACKING HIT-6684875.A70 6684875	-
179 - SET SCREW HIT-6684699.A17 6684699	-
180 - THRUST WASHER HIT-6684874.A5 6684874	-
181 - INLET SCREEN HIT-6684700.A210 6684700	-
201 - SHOULDER FRAME COMP HIT-6688276.A2 6688276	-
202 - SHOULDER BELT ASS'Y HIT-6697909.A2 6697909	-
203 - SCREW 5X10/PS HIT-6695380.A1 6695380	-
205 - CUSHION RUBBER COMP. HIT-6689125.A1 6689125	-
206 - FLANGE NUT 6 HIT-6695170.A83 6695170	£1.67	£2.00
207 - BOLT WASHER M8 HIT-6684611.A101 6684611	-
208 - BALL BEARING #6202ZZ 1 HIT-6695558.A9 6695558	-
209 - BEARING HOLDER HIT-6697907.A1 6697907	-
210 - BOLT 5X10/S HIT-6695438.A0 6695438	-
211 - NUT M5 HIT-6684965.A30 6684965	£1.67	£2.00
212 - ENGINE BASE COMP. HIT-6688131.A1 6688131	-
213 - SHOULDER PLATE HOLDER B. HIT-6688304.A0 6688304	£2.81	£3.37
214 - BOLT 6X25 HIT-6696295.A1 6696295	-
215 - FLANGE NUT 6 HIT-6695170.A82 6695170	£1.67	£2.00
216 - HEX.HOLE BOLT M5X20/S HIT-6684668.A22 6684668	-
217 - NYLON LOCK NUT 8 HIT-6695165.A7 6695165	-
218 - ENGINE BASE B ASS'Y HIT-6697935.A1 6697935	-
231 - CLUTCH DRUM COMP HIT-6689232.A2 6689232	-
232 - BALL BEARING #6202ZZ 1 HIT-6695558.A8 6695558	-
233 - STOP RING C-15 1 HIT-6695285.A49 6695285	£1.67	£2.00
234 - CLUTCH CASE HIT-6689216.A3 6689216	-
235 - S.WASHER 6 HIT-6684826.A1 6684826	£1.67	£2.00
236 - HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 HIT-6685064.A18 6685064	-
237 - LOCK PIN COMP. HIT-6689817.A1 6689817	-
238 - PROTECTION TUBE 10X700L HIT-6687586.A0 6687586	-
239 - PROTECTION TUBE 7X130L SINCE D024331 HIT-6687632.A2 6687632	-
240 - O-RING P-18 FKM HIT-6697780.A8 6697780	-
241 - CORD CLAMP TILL D024330 HIT-6688020.A0 6688020	-
241A - CORD CLAMP SINCE D024331 HIT-6688016.A4 6688016	-
242 - FLEXIBLE SHAFT ASS'Y HIT-6689591.A1 6689591	£99.12	£118.95
243 - FLEXIBLE SHAFT COMP. HIT-6689589.A2 6689589	£18.81	£22.57
244 - FLEXIBLE LINNER COMP. 1 HIT-6689554.A1 6689554	-
261 - JOINT PIPE ASS'Y HIT-6688537.A1 6688537	-
262 - HEX. HOLE BOLT M5X25/S HIT-6684709.A18 6684709	£1.67	£2.00
263 - HEX. HOLE BOLT 5X22/S HIT-6695492.A36 6695492	-
264 - SPACER HIT-6689138.A2 6689138	-
265 - SPACER HIT-6684819.A17 6684819	-
266 - CLUTCH WASHER A HIT-6689638.A0 6689638	£1.67	£2.00
267 - HEX. HOLE BOLT 5X10 HIT-6695042.A52 6695042	£1.67	£2.00
268 - PROTECTION TUBE 1 HIT-6687599.A1 6687599	-
269 - HANDLE HIT-6691036.A4 6691036	-
270 - BARRIER BLACK HIT-6691231.A9 6691231	-
271 - BOLT 6X43/P (BLACK) HIT-6684838.A3 6684838	£1.67	£2.00
272 - STOP RING C-10 1 HIT-6684821.A28 6684821	£1.67	£2.00
273 - HEX.NUT 6 HIT-6684835.A45 6684835	£1.67	£2.00
274 - DRIVE SHAFT COMP. HIT-6689346.A3 6689346	-
275 - BUSHING ASS'Y HIT-6689513.A2 6689513	-
276 - DRIVE SHAFT 1 HIT-6689459.A2 6689459	-
277 - CHOKE SHIM 0.8 HIT-6692596.A6 6692596	-
278 - CONNECTOR CASE HIT-6694031.A1 6694031	-
279 - THROTTLE WIRE HIT-6693905.A0 6693905	-
280 - TAPPING SCREW D4.5X20 HIT-6685191.A16 6685191	-
281 - JOINT COVER HIT-6688550.A2 6688550	-
301 - THROTTLE LEVER ASSY 26 HIT-6693759.A2 6693759	-
302 - THROTTLE WIRE HIT-6694019.A2 6694019	£14.66	£17.59
303 - STOP SWITCH HIT-6687455.A2 6687455	-
304 - TRIGGER LOCK OUT HIT-6684721.A48 6684721	£5.17	£6.20
305 - RETURN SPRING HIT-6693599.A2 6693599	-
306 - BLIND PLUG HIT-6684724.A1 6684724	-
307 - SCREW M5X20 HIT-6684803.A11 6684803	-
308 - CONTAL NUT 5 HIT-6684727.A48 6684727	£1.67	£2.00
309 - SCREW M4X20 (BLACK) HIT-6684725.A46 6684725	-
310 - THROTTLE LEVER HIT-6684804.A19 6684804	£6.86	£8.23
331 - GEAR CASE SET PN HIT-6696497.A21 6696497	£60.35	£72.42
332 - HEX. HOLE BOLT M5X25/S HIT-6684709.A19 6684709	£1.67	£2.00
333 - RETAINING RING C-TYPE D26 HIT-6695294.A16 6695294	-
334 - STOP RING OUTER 10 HIT-6695315.A20 6695315	-
335 - BALL BEARING #6000Z 1 HIT-6695526.A19 6695526	-
336 - BALL BEARING #6000 1 HIT-6695524.A42 6695524	-
337 - GEAR CASE 26 DIA HIT-6688770.A16 6688770	-
338 - HEX.HOLE BOLT M5X12/S HIT-6684667.A86 6684667	£1.67	£2.00
339 - OILING BOLT HIT-6689109.A33 6689109	-
340 - BALL BEARING 609 HIT-6684734.A14 6684734	-
341 - GEAR SHAFT HIT-6688924.A25 6688924	-
342 - BALL BEARING 6201D 1 HIT-6695554.A5 6695554	-
343 - STOP RING C-32 1 HIT-6695295.A37 6695295	£1.67	£2.00
344 - CUTTER HOLDER HIT-6689032.A10 6689032	£15.16	£18.19
345 - CUTTER HOLDER CAP HIT-6689055.A25 6689055	£12.10	£14.52
346 - FIXING NUT M10X1.25 HIT-6689073.A1 6689073	£8.32	£9.99
347 - GEAR CASE WASHER HIT-6689159.A1 6689159	-
351 - GEAR/PINION SET 1 HIT-6688875.A20 6688875	-
361 - HEX. HOLE BUTTON BOLT M6X25 HIT-6684714.A135 6684714	£1.67	£2.00
362 - COVER BRACKET 1 HIT-6690294.A7 6690294	-
362A - COVER BRACKET 26 SINCE D085851 HIT-6690315.A18 6690315	-
363 - BLADE GUARD 26 CE TILL D175400 HIT-6690242.A18 6690242	£18.84	£22.61
363A - BLADE GUARD 26CE SINCE D175401 HIT-6690276.A22 6690276	£20.01	£24.01
364 - GUARD HOLDER HIT-6684748.A29 6684748	-
365 - COVER GUARD TILL D175400 HIT-6690372.A31 6690372	£2.81	£3.37
365A - BLADE GUARD SINCE D175401 HIT-6690376.A25 6690376	£9.34	£11.21
366 - KNIFE TILL D175400 HIT-6693386.A9 6693386	£8.53	£10.24
366A - KNIFE SINCE D175401 HIT-6684750.A60 6684750	£3.64	£4.37
367 - SCREW 5X12/S TILL D175400 HIT-6695334.A11 6695334	£1.67	£2.00
367A - TAPPING SCREW 4X14 SINCE D175401 HIT-6684751.A39 6684751	£1.67	£2.00
368 - NUT M5 TILL D175400 HIT-6684965.A29 6684965	£1.67	£2.00
*369 - TAPPING SCREW 5X20 SINCE D175401 HIT-6684753.A51 6684753	£1.67	£2.00
*369 - TAPPING SCREW 5X20 TILL H013400 HIT-6684753.A52 6684753	£1.67	£2.00
*370 - KNIFE SINCE D175401 HIT-6684754.A40 6684754	£6.64	£7.97
*370 - KNIFE TILL H013400 HIT-6684754.A41 6684754	£6.64	£7.97
501 - BOX WRENCH (HEX. SOCKET 17/19) HIT-6684764.A91 6684764	£7.64	£9.17
502 - HEX. BAR WRENCH 4MM HIT-6684813.A71 6684813	-
*503B - CUTTER COVER FOR AUS (TILL TL059250 FOR EUROPE) HIT-6684768.A11 6684768	-
*504 - BLADE B4/10/1.6 FOR AUS HIT-6695790.A6 6695790	£17.08	£20.49
505 - PROTECTION COVER B FOR AUS HIT-6688995.A11 6688995	£4.81	£5.77
506A - PROTECTIVE GLASSES FOR EUROPE HIT-875769.A20 875769	-
521 - NYLON CORD CUTTER SINCE TL059251 HIT-6601148.A13 6601148	£25.68	£30.81
522 - CASE SINCE TL059251 HIT-6601149.A4 6601149	-
523 - NUT SINCE TL059251 HIT-6601150.A13 6601150	-
524 - REEL SPRING SINCE TL059251 HIT-6693380.A23 6693380	£6.47	£7.76
525 - LINE HOLDER SINCE TL059251 HIT-6601151.A4 6601151	-
526 - COVER SINCE TL059251 HIT-6601152.A13 6601152	-
527 - EYELET SINCE TL059251 HIT-6684810.A14 6684810	£3.29	£3.95
601 - NAME PLATE SUM-500DX HIT-6697164.A0 6697164	-
602 - SYMBOL MARK SUM-500DX HIT-6697165.A0 6697165	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki SUM500DX Engine Brush Cutter Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki SUM500DX Engine Brush Cutter Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki SUM500DX Engine Brush Cutter Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
