1 - MACHINE SCREW (W/WASHERS) M4X8 (BLACK)
HIT-6601439.A3
6601439
|
-
|
|
|
|
2 - SEAL LOCK HEX. SOCKET HD. BOLT M6X16
HIT-6600518.A9
6600518
|
-
|
|
|
|
3 - MUFFLER ASS'Y INCLUD.1
HIT-6601489.A0
6601489
|
-
|
|
|
|
4 - SPARK ARRESTER
HIT-6601438.A15
6601438
|
-
|
|
|
|
5 - HEAT PROTECTION PANEL
HIT-6601492.A2
6601492
|
-
|
|
|
|
6 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X22
HIT-6601339.A6
6601339
|
-
|
|
|
|
7 - IGNITION PLUG (TORCH L7RTC)
HIT-6600542.A22
6600542
|
-
|
|
|
|
8 - CYLINDER N27
HIT-6600903.A11
6600903
|
-
|
|
|
|
9 - INSULATOR GASKET
HIT-6684865.A2
6684865
|
£1.67
|
£2.00
|
|
|
10 - AIR DEFLECTOR
HIT-6601490.A2
6601490
|
-
|
|
|
|
11 - DEFLECTOR PACKING
HIT-6601593.A1
6601593
|
-
|
|
|
|
12 - CARBURETOR INSULATOR
HIT-6601491.A8
6601491
|
-
|
|
|
|
13 - SPRING WASHER D6
HIT-6600910.A2
6600910
|
-
|
|
|
|
14 - SEAL LOCK HEX. SOCKET HD. BOLT M6X27
HIT-6601358.A9
6601358
|
-
|
|
|
|
15 - CARBURETOR PACKING
HIT-6698405.A38
6698405
|
£3.12
|
£3.74
|
|
|
16 - SWIVEL CAP
HIT-6691337.A3
6691337
|
£1.67
|
£2.00
|
|
|
17 - CARBURETOR ASS'Y INCLUD.18-33
HIT-6601487.A1
6601487
|
-
|
|
|
|
18 - CABLE ADJUST STAY
HIT-6699287.A29
6699287
|
-
|
|
|
|
19 - SWIVEL
HIT-6696830.A48
6696830
|
-
|
|
|
|
20 - STOP RING
HIT-6684696.A73
6684696
|
-
|
|
|
|
21 - PUMP GASKET
HIT-6684692.A79
6684692
|
£17.28
|
£20.73
|
|
|
22 - PUMP DIAPHRAGM
HIT-6684693.A70
6684693
|
£5.70
|
£6.84
|
|
|
23 - PUMP PLATE
HIT-6691242.A43
6691242
|
-
|
|
|
|
24 - DIAPHRAGM COVER-METERING
HIT-6685222.A141
6685222
|
£5.70
|
£6.84
|
|
|
25 - SET SCREW
HIT-6691312.A87
6691312
|
-
|
|
|
|
26 - SET SCREW M3X12
HIT-6696829.A4
6696829
|
-
|
|
|
|
27 - O-RING
HIT-6684695.A125
6684695
|
£1.67
|
£2.00
|
|
|
28 - JET
HIT-000000.A582
000000
|
-
|
|
|
|
29 - CIRCUIT PLATE
HIT-6691234.A18
6691234
|
-
|
|
|
|
30 - INLET SCREEN
HIT-6684700.A88
6684700
|
-
|
|
|
|
31 - PUMP BODY COMP.
HIT-6696828.A48
6696828
|
£13.28
|
£15.93
|
|
|
32 - DIAPHRAGM PACKING-METERING
HIT-6685220.A38
6685220
|
£2.81
|
£3.37
|
|
|
33 - METERING DIAPHRAGM
HIT-6684690.A74
6684690
|
£24.05
|
£28.86
|
|
|
34 - FUEL PIPE
HIT-6601444.A24
6601444
|
-
|
|
|
|
35 - CORD
HIT-6601505.A0
6601505
|
-
|
|
|
|
36 - PLUG CAP COVER
HIT-6601598.A4
6601598
|
-
|
|
|
|
37 - IGNITION COIL ASS'Y INCLUD.38
HIT-6698397.A6
6698397
|
£24.24
|
£29.09
|
|
|
38 - CORD
HIT-6696833.A3
6696833
|
-
|
|
|
|
39 - HEX. SOCKET HD. BOLT (W/WASHERS) M4X18
HIT-6698388.A34
6698388
|
£1.67
|
£2.00
|
|
|
40 - GLASS WASHER
HIT-6698700.A47
6698700
|
£1.67
|
£2.00
|
|
|
41 - CYLINDER PACKING
HIT-6600510.A10
6600510
|
-
|
|
|
|
42 - PISTON RING
HIT-6601353.A4
6601353
|
-
|
|
|
|
43 - PISTON (M)
HIT-6600905.A0
6600905
|
-
|
|
|
|
44 - CIR CLIP
HIT-6684590.A77
6684590
|
£1.67
|
£2.00
|
|
|
45 - SHIM
HIT-6600909.A19
6600909
|
-
|
|
|
|
46 - WOODRUFF KEY 3X13X4.5
HIT-6601343.A5
6601343
|
-
|
|
|
|
47 - PISTON PIN
HIT-6601344.A22
6601344
|
-
|
|
|
|
48 - FEATHER KEY 3X3X12
HIT-937177.A8
937177
|
£1.67
|
£2.00
|
|
|
49 - SPECIAL BOLT (A)
HIT-6601594.A5
6601594
|
-
|
|
|
|
50 - BOLT WASHER M8 (BLACK)
HIT-323212.A48
323212
|
£1.67
|
£2.00
|
|
|
51 - MAGNETO ROTOR
HIT-6699289.A12
6699289
|
£24.52
|
£29.43
|
|
|
52 - CRANK CASE (F) ASS'Y INCLUD.54
HIT-6601619.A4
6601619
|
-
|
|
|
|
53 - CRANK CASE PACKING
HIT-6600514.A16
6600514
|
-
|
|
|
|
54 - OIL SEAL TB 12227
HIT-6684607.A168
6684607
|
£4.07
|
£4.88
|
|
|
55 - BALL BEARING 6001 C3
HIT-6684608.A37
6684608
|
£5.70
|
£6.84
|
|
|
56 - CRANK CASE GUARD
HIT-6600924.A8
6600924
|
-
|
|
|
|
57 - CRANK SHAFT
HIT-6601624.A0
6601624
|
-
|
|
|
|
58 - KNOCK PIN 4X12
HIT-6696947.A59
6696947
|
-
|
|
|
|
59 - CRANK CASE (R) ASS'Y INCLUD.54
HIT-6601620.A2
6601620
|
-
|
|
|
|
60 - AIR CLEANER BASE ASS'Y INCLUD.61-63
HIT-6600911.A14
6600911
|
-
|
|
|
|
61 - COLLAR M5
HIT-6601340.A16
6601340
|
-
|
|
|
|
62 - CHOKE VALVE
HIT-6601341.A1
6601341
|
-
|
|
|
|
63 - PRIMING PUMP COMP.
HIT-6685139.A125
6685139
|
£10.67
|
£12.80
|
|
|
64 - WAVE WASHER 8
HIT-334242.A5
334242
|
-
|
|
|
|
65 - BOLT WASHER D5
HIT-6685407.A48
6685407
|
-
|
|
|
|
66 - SCREW M5X55
HIT-6601592.A3
6601592
|
-
|
|
|
|
67 - COVER SETTING BOLT
HIT-6601509.A1
6601509
|
-
|
|
|
|
68 - AIR CLEANER ELEMENT
HIT-6600529.A6
6600529
|
-
|
|
|
|
69 - AIR CLEANER COVER
HIT-6601484.A3
6601484
|
-
|
|
|
|
70 - RECOIL FAN (A)
HIT-6601625.A5
6601625
|
-
|
|
|
|
71 - RECOIL FAN (B)
HIT-6601626.A1
6601626
|
-
|
|
|
|
72 - RECOIL STARTER ASS'Y INCLUD.73
HIT-6600408.A3
6600408
|
£12.85
|
£15.42
|
|
|
73 - RECOIL ASS'Y INCLUD.75-79
HIT-6600406.A3
6600406
|
£18.74
|
£22.49
|
|
|
74 - STARTER PULLEY
HIT-6600407.A7
6600407
|
£1.67
|
£2.00
|
|
|
75 - RECOIL SET SCREW
HIT-6600404.A3
6600404
|
-
|
|
|
|
76 - SWING ARM HOLDER
HIT-6600402.A3
6600402
|
-
|
|
|
|
77 - SWING ARM
HIT-6600401.A7
6600401
|
-
|
|
|
|
78 - RECOIL REEL
HIT-6600405.A7
6600405
|
-
|
|
|
|
79 - RECOIL SPRING
HIT-6600403.A7
6600403
|
-
|
|
|
|
*80 - TANK MARK LABEL (25:1)
HIT-6698922.A12
6698922
|
-
|
|
|
|
*80 - TANK MARK LABEL (50:1) FOR RUS
HIT-6698921.A34
6698921
|
-
|
|
|
|
81 - RECOIL ROPE 3X800
HIT-6600400.A3
6600400
|
-
|
|
|
|
82 - RECOIL HANDLE
HIT-6600399.A7
6600399
|
-
|
|
|
|
83 - NAME PLATE
HIT-000000.A583
000000
|
-
|
|
|
|
84 - HEX. SOCKET HD. BOLT (W/FLANGE) M4X14
HIT-6601591.A3
6601591
|
-
|
|
|
|
111 - STOP SWITCH
HIT-6601275.A10
6601275
|
£1.67
|
£2.00
|
|
|
*112 - MUFFLER PROTECTOR (VERMILION)
HIT-6601482.A5
6601482
|
-
|
|
|
|
*112 - MUFFLER PROTECTOR (GREEN) FOR KOR
HIT-6601483.A1
6601483
|
-
|
|
|
|
113 - TAPPING SCREW (W/FLANGE) D5X20 (BLACK)
HIT-302089.A40
302089
|
£1.67
|
£2.00
|
|
|
114 - HEX. SOCKET HD. BOLT (W/FLANGE) M4X14
HIT-6601591.A4
6601591
|
-
|
|
|
|
115 - SPACER
HIT-6699558.A24
6699558
|
-
|
|
|
|
116 - FUEL PIPE L70
HIT-6699014.A17
6699014
|
£2.77
|
£3.32
|
|
|
117 - FUEL GROMMET
HIT-6600358.A3
6600358
|
£1.67
|
£2.00
|
|
|
118 - FUEL PIPE L140
HIT-6600521.A9
6600521
|
£1.67
|
£2.00
|
|
|
119 - FUEL TANK CAP ASS'Y INCLUD.120
HIT-6698402.A47
6698402
|
-
|
|
|
|
120 - TANK CAP CHAIN
HIT-6698732.A42
6698732
|
-
|
|
|
|
121 - TANK
HIT-6600519.A9
6600519
|
-
|
|
|
|
122 - BOLT (W/FLANGE) L17.8
HIT-6696574.A50
6696574
|
£1.67
|
£2.00
|
|
|
123 - PUMP FILTER
HIT-6600351.A2
6600351
|
£4.45
|
£5.34
|
|
|
124 - CLIP
HIT-6696949.A66
6696949
|
£1.67
|
£2.00
|
|
|
125 - BOLT (W/FLANGE) L23.8
HIT-6698512.A18
6698512
|
£1.67
|
£2.00
|
|
|
126 - HEAT PROTECTION SPONGE
HIT-6601623.A4
6601623
|
-
|
|
|
|
127 - THROTTLE LEVER
HIT-6698391.A1
6698391
|
£1.67
|
£2.00
|
|
|
128 - THROTTLE WIRE COMP.
HIT-6698399.A4
6698399
|
£3.24
|
£3.89
|
|
|
129 - NOZZLE (B)
HIT-6698394.A4
6698394
|
£8.72
|
£10.47
|
|
|
130 - NOZZLE (A)
HIT-6601600.A1
6601600
|
-
|
|
|
|
131 - BRAND LABEL
HIT-000000.A584
000000
|
-
|
|
|
|
132 - GUARD NET (A)
HIT-6601486.A3
6601486
|
-
|
|
|
|
*133 - VOLUTE CASE (A) VERMILION
HIT-6601477.A0
6601477
|
-
|
|
|
|
*133 - VOLUTE CASE (A) GREEN FOR KOR
HIT-6601478.A1
6601478
|
-
|
|
|
|
134 - MACHINE SCREW (W/WASHERS) M5X18
HIT-6600920.A14
6600920
|
-
|
|
|
|
135 - STOPPER PLATE (A)
HIT-6601501.A1
6601501
|
-
|
|
|
|
136 - U-NUT M8
HIT-6684932.A9
6684932
|
£1.67
|
£2.00
|
|
|
137 - WASHER (A)
HIT-6601627.A2
6601627
|
-
|
|
|
|
138 - FAN
HIT-6601485.A1
6601485
|
-
|
|
|
|
*139 - FAN CASE (VERMILION)
HIT-6601479.A0
6601479
|
-
|
|
|
|
*139 - FAN CASE (GREEN) FOR KOR
HIT-6601480.A1
6601480
|
-
|
|
|
|
140 - WEIGHT (F)
HIT-6601595.A0
6601595
|
-
|
|
|
|
141 - WEIGHT (R)
HIT-6601629.A2
6601629
|
-
|
|
|
|
142 - CAUTION MARK (EU)
HIT-000000.A585
000000
|
-
|
|
|
|
501 - BOX WRENCH (HEX. SOCKET 17/19)
HIT-6684764.A38
6684764
|
£7.64
|
£9.17
|
|
|
601 - FLAT NOZZLE
HIT-6699184.A8
6699184
|
-
|
|
|
