Hitachi / Hikoki PU100F Universal Woodworking Machine Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki PU100F Universal Woodworking Machine

	Ex VAT	Inc VAT
1 - BASE HIT-972540.A0 972540	-
2 - BOLT W3/8X115 TILL 6.1985 HIT-972573.A0 972573	-
2A - SPECIAL SCREW W3/8X75 SINCE 7.1985 HIT-973854.A0 973854	-
3 - NUT W3/8 (10 PCS.) TILL 6.1985 HIT-949559.A0 949559	-
4 - SPRING WASHER M10 (10 PCS.) TILL 6.1985 HIT-949458.A3 949458	£1.67	£2.00
5 - WASHER W3/8 HIT-976351.A1 976351	-
6 - JOINTER FRAME HIT-968553.A0 968553	-
7 - FRAME FOR AUTOMATIC FEED HIT-968554.A0 968554	-
8 - HOISTING FRAME HIT-968555.A0 968555	-
9 - BOLT M10X35 (10 PCS.) HIT-949695.A1 949695	-
10 - SPRING WASHER M10 (10 PCS.) HIT-949458.A4 949458	£1.67	£2.00
11 - CONNECTING BAR HIT-968556.A0 968556	-
12 - NUT M12 (10 PCS.) HIT-949561.A5 949561	-
13 - SPRING WASHER M12 (10 PCS.) HIT-949463.A12 949463	£1.67	£2.00
14 - ROLL PIN D4X25 (10 PCS.) HIT-949548.A0 949548	-
15 - COUNTER SHAFT HIT-968557.A0 968557	-
16 - COUNTER GEAR HIT-968558.A0 968558	-
17 - BALL BEARING 6004VVCMPS2L HIT-6004VV.A2 6004VV	£9.03	£10.84
18 - RETAINING RING FOR D20 SHAFT (10 PCS.) HIT-939547.A9 939547	£4.61	£5.53
19 - BEARING COVER (E) HIT-968559.A0 968559	-
20 - MACHINE SCREW M5X12 (10 PCS.) HIT-949237.A22 949237	£1.67	£2.00
21 - SPRING WASHER M5 (10 PCS.) HIT-949454.A116 949454	£1.67	£2.00
22 - NUT (A) HIT-948006.A0 948006	-
23 - SPRING WASHER M20 (10 PCS.) HIT-949745.A0 949745	-
24 - SECOND PINION HIT-968560.A0 968560	-
25 - FIRST GEAR HIT-968561.A0 968561	-
26 - WOODRUFF KEY 3X13 HIT-932815.A2 932815	£1.67	£2.00
27 - BALL BEARING 6201VV HIT-6201VV.A24 6201VV	£8.30	£9.96
28 - BEARING HOLDER HIT-968562.A0 968562	-
29 - METAL (C) HIT-948010.A0 948010	-
30 - BOLT M8X30 (10 PCS.) HIT-949628.A7 949628	-
31 - SPRING WASHER M8 (10 PCS.) HIT-949457.A69 949457	£1.67	£2.00
32 - FIRST PINION HIT-968563.A0 968563	-
33 - BALL BEARING 6203VVCMPS2L HIT-6203VV.A12 6203VV	£9.32	£11.19
34 - SLEEVE (A) HIT-948013.A0 948013	-
35 - BEARING COVER (E) HIT-968559.A1 968559	-
36 - MACHINE SCREW M5X12 (10 PCS.) HIT-949237.A21 949237	£1.67	£2.00
37 - SPRING WASHER M5 (10 PCS.) HIT-949454.A117 949454	£1.67	£2.00
38 - FEATHER KEY 5X5X15 HIT-945072.A1 945072	-
39 - PULLEY (B) TILL 6.1984 HIT-968565.A0 968565	-
39A - PULLEY (B) SINCE 7.1984 HIT-976857.A0 976857	-
40 - HEX. SOCKET SET SCREW M5X12 HIT-966292.A0 966292	£1.67	£2.00
41 - RETAINING RING FOR D17 SHAFT HIT-967261.A0 967261	£1.67	£2.00
42 - HANDLE HOLDER (A) HIT-972542.A0 972542	-
43 - FEED SCREW (A) HIT-972543.A0 972543	-
44 - BEVEL GEAR HIT-948021.A0 948021	-
45 - ROLL PIN D4X28 (10 PCS.) HIT-949506.A4 949506	£3.88	£4.66
46 - THRUST BEARING (51103) HIT-939286.A2 939286	-
47 - SPECIAL WASHER HIT-965077.A2 965077	£1.67	£2.00
48 - NUT M10 (10 PCS.) HIT-949560.A0 949560	£2.98	£3.57
49 - LOCK NUT M10 (10 PCS.) HIT-949572.A3 949572	-
50 - SPRING WASHER M6 (10 PCS.) HIT-949455.A19 949455	£1.67	£2.00
51 - BEVEL PINION HIT-948023.A1 948023	-
52 - HANDLE SHAFT (A) HIT-972544.A0 972544	-
53 - ROLL PIN D4X36 (10 PCS.) HIT-949547.A4 949547	-
54 - HANDLE HOLDER (B) HIT-972545.A0 972545	-
55A - ROUND HANDLE HIT-972052.A1 972052	-
56 - ROLL PIN D5X30 (10 PCS.) HIT-949502.A2 949502	-
57 - FEMALE SCREW (B) HIT-968570.A0 968570	-
58 - BOLT M10X25 (10 PCS.) HIT-949639.A1 949639	-
59 - SPRING WASHER M10 (10 PCS.) HIT-949458.A5 949458	£1.67	£2.00
60 - TABLE FOR AUTOMATIC FEED HIT-972546.A0 972546	-
61 - BOLT M8X25 (10 PCS.) HIT-949626.A0 949626	-
62 - SPRING WASHER M8 (10 PCS.) HIT-949457.A64 949457	£1.67	£2.00
63 - BASE ROLLER HIT-972004.A0 972004	-
65 - ROLLER SHAFT HIT-972005.A0 972005	-
66 - SPECIAL BOLT M6 HIT-947512.A0 947512	-
67 - NUT M6 (10 PCS.) HIT-949556.A4 949556	£1.67	£2.00
68 - ROLLER SCREW HIT-972547.A0 972547	-
69 - COLLAR (D) HIT-972548.A0 972548	-
70 - LOCK NUT M6 (10 PCS.) HIT-949567.A4 949567	£1.67	£2.00
71 - LINER (A) HIT-972549.A0 972549	-
72 - COLLAR (D) HIT-972550.A0 972550	-
73 - HEX. BOLT HIT-972551.A0 972551	-
74 - NUT M6 (10 PCS.) HIT-949556.A3 949556	£1.67	£2.00
75 - SCALE (A) HIT-948034.A0 948034	-
76 - RIVET D2.5X4.8 (10 PCS.) HIT-949510.A11 949510	£1.67	£2.00
77 - INDICATOR HIT-948035.A0 948035	-
78 - MACHINE SCREW M6X12 (10 PCS.) HIT-949255.A12 949255	£1.67	£2.00
79 - WASHER M6 (10 PCS.) HIT-949425.A45 949425	£1.67	£2.00
80 - GUIDE PIECE FOR SINGLE-PHASE HIT-967808.A0 967808	-
80A - GUIDE PIECE FOR THREE-PHASE HIT-976940.A0 976940	-
81 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A53 949216	£1.67	£2.00
82 - SPRING WASHER M4 (10 PCS.) HIT-949453.A8 949453	£1.67	£2.00
83 - JOINTER BASE ASS'Y INCLUD.84-100 HIT-968572.A0 968572	-
*83 - JOINTER BASE ASS'Y 458 HIT-968572.A1 968572	-
84 - SCREW BOSS HIT-947589.A0 947589	-
85 - BOLT M8X22 (10 PCS.) HIT-949625.A2 949625	-
86 - SPRING WASHER M8 (10 PCS.) HIT-949457.A63 949457	£1.67	£2.00
87 - FEED SCREW (C) HIT-948169.A0 948169	-
88 - KNOB HIT-967731.A0 967731	-
89 - ROLL PIN D4X25 (10 PCS.) HIT-949548.A1 949548	-
90 - HOLDER HIT-948159.A0 948159	-
91 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A0 949256	£1.67	£2.00
92 - SPRING WASHER M6 (10 PCS.) HIT-949455.A22 949455	£1.67	£2.00
93 - ROLL PIN D4X18 (10 PCS.) HIT-949498.A4 949498	-
94 - WASHER (A) HIT-947585.A0 947585	-
95 - LINER (C) HIT-948173.A0 948173	-
96 - NUT M12 (10 PCS.) HIT-949561.A6 949561	-
97 - SCALE (B) HIT-947588.A0 947588	-
98 - RIVET D2.5X4.8 (10 PCS.) HIT-949510.A10 949510	£1.67	£2.00
99 - ROLL PIN D5X25 (10 PCS.) HIT-949681.A4 949681	-
100 - THRUST WASHER HIT-968688.A0 968688	-
102 - STUD BOLT HIT-967817.A0 967817	-
103 - WASHER M12 HIT-976244.A0 976244	-
109 - SLOTTED PIN D5X32 HIT-948155.A0 948155	-
110 - COVER HOLDER (A) HIT-967740.A0 967740	-
110 - COVER HOLDER (B) FOR NZL HIT-972590.A0 972590	-
111 - BOLT M6X30 (10 PCS.) HIT-949607.A0 949607	-
112 - SPRING WASHER M6 (10 PCS.) HIT-949455.A21 949455	£1.67	£2.00
113 - ROLLER BASE (SINGLE-PHASE) FOR NZL HIT-000000.A4854 000000	-
113 - ROLLER BASE (FOR SINGLE-PHASE) HIT-972553.A0 972553	-
113 - ROLLER BASE (FOR THREE-PHASE) HIT-972554.A0 972554	-
113 - ROLLER BASE (THREE-PHASE) FOR NZL HIT-000000.A4855 000000	-
114 - WOOD BASE HIT-000000.A4856 000000	-
115 - BOLT M8X30 (10 PCS.) HIT-949628.A6 949628	-
116 - SPRING WASHER M8 (10 PCS.) HIT-949457.A65 949457	£1.67	£2.00
117 - BOLT M12X50 (10 PCS.) HIT-949674.A0 949674	-
118 - SPRING WASHER M12 (10 PCS.) HIT-949463.A11 949463	£1.67	£2.00
119 - BOLT M12X35 (10 PCS.) HIT-949672.A1 949672	-
120 - CAUTION LABEL (J) F0R NZL HIT-000000.A4857 000000	-
120 - CAUTION LABEL (I) SINGLE-PHASE HIT-972578Z.A0 972578Z	-
121 - RIVET D2.5X4.8 (10 PCS.) EXCEPT FOR NZL HIT-949510.A12 949510	£1.67	£2.00
122 - CUTTER BLOCK HIT-972556.A0 972556	-
123 - BALL BEARING 6205VVCMPS2L HIT-6205VV.A0 6205VV	£10.95	£13.14
124 - BALL BEARING 6004VVCMPS2L HIT-6004VV.A1 6004VV	£9.03	£10.84
125 - BEARING COVER (A) HIT-968577.A0 968577	-
126 - MACHINE SCREW M5X12 (10 PCS.) HIT-949237.A19 949237	£1.67	£2.00
127 - SPRING WASHER M5 (10 PCS.) HIT-949454.A114 949454	£1.67	£2.00
128 - BEARING COVER (G) HIT-966295.A0 966295	-
129 - MACHINE SCREW M6X12 (10 PCS.) HIT-949255.A11 949255	£1.67	£2.00
130 - SPRING WASHER M6 (10 PCS.) HIT-949455.A20 949455	£1.67	£2.00
131 - WOODRUFF KEY 3X10 HIT-932819.A1 932819	£1.67	£2.00
132 - LOCK RING (B) HIT-966061.A0 966061	-
133 - RETAINING RING FOR D12 SHAFT (10 PCS.) HIT-939542.A66 939542	£2.98	£3.57
134 - LOCK HIT-946345.A0 946345	-
135 - PIN D3X8 (10 PCS.) HIT-949473.A0 949473	-
136 - MACHINE SCREW M4X20 (10 PCS.) HIT-949221.A6 949221	£1.67	£2.00
137 - SPRING WASHER M4 (10 PCS.) HIT-949453.A9 949453	£1.67	£2.00
138 - CAUTION LABEL (E) HIT-973950.A0 973950	-
139 - LOCK COVER HIT-966277.A0 966277	-
140 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A54 949216	£1.67	£2.00
141 - SPRING WASHER M4 (10 PCS.) HIT-949453.A10 949453	£1.67	£2.00
142 - CAUTION LABEL (D) HIT-968677Z.A0 968677Z	-
143 - CAUTION PLATE HIT-968678Z.A0 968678Z	-
144 - PLANER BLADES (A) 317MM (1 PAIR) HIT-972011.A0 972011	£104.88	£125.85
145 - BOLT (10 PCS.) HIT-976754.A0 976754	-
147 - BLADE HOLDER ASS'Y (1 PAIR) INCLUD.148 HIT-948046.A0 948046	-
148 - CUTTER SPRING HIT-947525.A0 947525	-
149 - PIN HIT-946363.A0 946363	-
150 - PLANER BLADES 160MM (1 PAIR) HIT-879208.A0 879208	-
151 - BOLT (10 PCS.) HIT-976755.A0 976755	-
152 - BOLT (10 PCS.) HIT-976754.A1 976754	-
154 - SAFETY COVER ASS'Y INCLUD.158 EXCEPT FOR NZL HIT-973843Z.A0 973843Z	-
158 - SPRING (B) EXCEPT FOR NZL HIT-947603.A0 947603	-
160 - BOLT M8X16 (10 PCS.) HIT-949622.A10 949622	-
160A - KNOB BOLT M8X15 FOR NZL HIT-966509.A0 966509	-
161 - GUIDE HIT-972032.A0 972032	-
162 - GUIDE ARM (A) HIT-972033.A0 972033	-
163 - FLAT HD. SCREW M6X12 (10 PCS.) HIT-949355.A0 949355	-
165 - GUIDE HOLDER (A) HIT-972557.A0 972557	-
166 - BOLT M10X30 (10 PCS.) HIT-949698.A5 949698	-
167 - SPRING WASHER M10 (10 PCS.) HIT-949458.A6 949458	£1.67	£2.00
168 - GUIDE SHAFT HIT-972035.A0 972035	-
169 - HIGH TENSION BOLT M8X25 HIT-967594.A2 967594	-
170 - BOLT WASHER M8 (10 PCS.) HIT-949433.A10 949433	£1.67	£2.00
171 - SPRING WASHER M8 (10 PCS.) HIT-949457.A68 949457	£1.67	£2.00
172 - WING BOLT M6X20 (10 PCS.) HIT-949404.A0 949404	£9.03	£10.84
173 - WASHER (H) HIT-967329.A1 967329	£1.67	£2.00
175 - FEED ROLLER (A) HIT-972558.A0 972558	-
177 - METAL HIT-948914.A0 948914	-
178 - METAL HOLDER (B) HIT-972017.A0 972017	-
179 - METAL HOLDER (C) HIT-968582.A0 968582	-
180 - METAL HOLDER (A) HIT-972016.A0 972016	-
182 - METAL SPRING (A) HIT-968584.A0 968584	-
183 - METAL SPRING (B) HIT-968585.A0 968585	-
184 - METAL SPRING (C) HIT-968586.A0 968586	-
185 - FEED GEAR HIT-968587.A0 968587	-
186 - FEATHER KEY 4X4X12 HIT-931008.A9 931008	-
187 - RETAINING RING FOR D16 SHAFT (10 PCS.) HIT-939545.A0 939545	-
188 - PULLEY (A) HIT-968588.A0 968588	-
189 - FEATHER KEY 7X7X25 HIT-948081.A0 948081	£1.67	£2.00
190 - HEX. SOCKET SET SCREW M6X10 HIT-968247.A8 968247	-
191 - CHIP COVER HIT-972559.A0 972559	-
192 - ROLL PIN D8X32 (10 PCS.) HIT-949882.A0 949882	-
193 - WING BOLT M6X15 (10 PCS.) HIT-949402.A4 949402	-
194 - NAME PLATE HIT-000000.A4858 000000	-
195 - MACHINE SCREW M5X12 (10 PCS.) HIT-949237.A20 949237	£1.67	£2.00
196 - SPRING WASHER M5 (10 PCS.) HIT-949454.A115 949454	£1.67	£2.00
197 - RIVET D2.5X4.8 (10 PCS.) HIT-949510.A9 949510	£1.67	£2.00
198 - HOISTING SLIDE FRAME HIT-968593.A0 968593	-
199 - BOSS (B) HIT-948063.A0 948063	-
200 - BOLT M8X25 (10 PCS.) HIT-949626.A1 949626	-
201 - SPRING WASHER M8 (10 PCS.) HIT-949457.A66 949457	£1.67	£2.00
202 - FEED SCREW (B) HIT-968692.A0 968692	-
203 - BEVEL GEAR HIT-948021.A1 948021	-
204 - ROLL PIN D4X28 (10 PCS.) HIT-949506.A5 949506	£3.88	£4.66
205 - THRUST BEARING (51103) HIT-939286.A1 939286	-
206 - WASHER (B) HIT-948022.A0 948022	-
207 - ROLL PIN D6X30 (10 PCS.) HIT-949515.A0 949515	-
208 - BEVEL PINION HIT-948023.A0 948023	-
209 - HANDLE SHAFT (B) HIT-968594.A0 968594	-
210 - ROLL PIN D4X36 (10 PCS.) HIT-949547.A3 949547	-
211 - ROLL PIN D5X30 (10 PCS.) HIT-949502.A0 949502	-
212A - ROUND HANDLE HIT-972052.A0 972052	-
213 - ROLL PIN D5X30 (10 PCS.) HIT-949502.A1 949502	-
217 - HOISTING TABLE HIT-972587.A0 972587	-
218 - BOLT M10X35 (10 PCS.) HIT-949695.A0 949695	-
219 - SPRING WASHER M10 (10 PCS.) HIT-949458.A7 949458	£1.67	£2.00
220 - HINGE (A) HIT-972562.A0 972562	-
221 - HINGE (B) HIT-968598.A0 968598	-
222 - BOLT M8X22 (10 PCS.) HIT-949625.A0 949625	-
223 - SPRING WASHER M8 (10 PCS.) HIT-949457.A67 949457	£1.67	£2.00
224 - GUIDE SHAFT (B) HIT-968599.A0 968599	-
225 - GUIDE (B) HIT-968600.A0 968600	-
226 - ADJUSTING NUT HIT-968689.A0 968689	-
227 - WING BOLT M6X15 (10 PCS.) HIT-949402.A2 949402	-
228 - BOLT WASHER M8 (10 PCS.) HIT-949433.A13 949433	£1.67	£2.00
229 - BOLT M8X22 (10 PCS.) HIT-949625.A1 949625	-
230 - SPRING WASHER M8 (10 PCS.) HIT-949457.A47 949457	£1.67	£2.00
233 - LINER (B) HIT-948033.A0 948033	-
234 - BOLT M6X35 (10 PCS.) HIT-949803.A0 949803	-
235 - NUT M6 (10 PCS.) HIT-949556.A10 949556	£1.67	£2.00
236 - FEMALE SCREW HIT-948018.A0 948018	-
237 - BOLT M8X30 (10 PCS.) HIT-949628.A2 949628	-
238 - SPRING WASHER M8 (10 PCS.) HIT-949457.A48 949457	£1.67	£2.00
239 - GUIDE HOLDER (A) HIT-968690.A0 968690	-
240 - WING BOLT M6X15 (10 PCS.) HIT-949402.A3 949402	-
241 - SPINDLE CASE HIT-968602.A0 968602	-
242 - BOLT M8X35 (10 PCS.) HIT-949678.A5 949678	£3.45	£4.14
243 - SPRING WASHER M8 (10 PCS.) HIT-949457.A49 949457	£1.67	£2.00
244 - SPINDLE HIT-968603.A0 968603	-
245 - BALL BEARING 6205VVCMPS2L HIT-6205VV.A1 6205VV	£10.95	£13.14
246 - BALL BEARING 6206VVCMPS2S HIT-6206VV.A0 6206VV	£16.21	£19.45
247 - BEARING COVER (F) HIT-968604.A0 968604	-
248 - MACHINE SCREW M6X10 (10 PCS.) HIT-949254.A5 949254	-
249 - PULLEY (E) HIT-968605.A0 968605	-
250 - FEATHER KEY 7X7X25 HIT-948081.A2 948081	£1.67	£2.00
251 - HEX. SOCKET SET SCREW M6X10 HIT-968247.A4 968247	-
252 - SPRING WASHER M6 (10 PCS.) HIT-949455.A54 949455	£1.67	£2.00
253 - SAW COVER (A) HIT-968606.A0 968606	-
254 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A35 949216	£1.67	£2.00
255 - SPRING WASHER M4 (10 PCS.) HIT-949453.A29 949453	£1.67	£2.00
256 - WING BOLT M6X15 (10 PCS.) HIT-949402.A1 949402	-
257 - BRAND LABEL HIT-988113.A0 988113	-
258 - SAW GUARD HOLDER (B) THREE-PHASE HIT-968607.A0 968607	-
258 - SAW GUARD HOLDER SINGLE-PHASE HIT-972588Z.A0 972588Z	-
259 - BOLT M8X16 (10 PCS.) HIT-949622.A7 949622	-
260 - SPRING WASHER M8 (10 PCS.) HIT-949457.A46 949457	£1.67	£2.00
261 - SAW GUARD SINGLE-PHASE HIT-316861.A0 316861	-
261 - SAW GUARD (B) THREE-PHASE HIT-316862.A0 316862	-
262 - BOLT M6X14 (10 PCS.) SINGLE-PHASE HIT-949612.A0 949612	-
262 - BOLT M8X16 (10 PCS.) THREE-PHASE HIT-949622.A6 949622	-
263 - NUT M6 (10 PCS.) SINGLE-PHASE HIT-949556.A9 949556	£1.67	£2.00
263 - NUT M8 (10 PCS.) THREE-PHASE HIT-949558.A19 949558	£1.67	£2.00
264 - SUPER LOCK WASHER M6 SINGLE-PHASE HIT-948167.A2 948167	£1.67	£2.00
264 - SUPER LOCK WASHER M8 THREE-PHASE HIT-957042.A1 957042	£1.67	£2.00
265 - WASHER (A) HIT-968609.A0 968609	-
266A - SPACER HIT-972384.A0 972384	-
267 - SPACER 19MM HIT-968611.A0 968611	-
268 - WASHER (B) HIT-968612.A0 968612	-
269 - NUT (B) HIT-966260.A0 966260	-
270 - TENSIONER HOLDER (A) HIT-968613.A0 968613	-
271 - BOLT M8X30 (10 PCS.) HIT-949628.A3 949628	-
272 - SPRING WASHER M8 (10 PCS.) HIT-949457.A50 949457	£1.67	£2.00
273 - TENSIONER RING HIT-968614.A0 968614	-
274 - TENSIONER RING HIT-976863.A0 976863	-
275 - TENSIONER SHAFT HIT-968616.A0 968616	-
276 - TENSIONER SHAFT HIT-968617.A0 968617	-
278 - BOLT WASHER M12 (10 PCS.) HIT-949437.A2 949437	£1.67	£2.00
279 - DISTANCE SLEEVE HIT-968618.A0 968618	-
280 - NUT M12 (10 PCS.) HIT-949561.A4 949561	-
281 - SPRING WASHER M12 (10 PCS.) HIT-949463.A4 949463	£1.67	£2.00
282 - TENSIONER BOLT HIT-968619.A0 968619	-
283 - BALL BEARING 6201VV HIT-6201VV.A33 6201VV	£8.30	£9.96
284 - MOTOR BASE HIT-968620.A0 968620	-
285 - LINK HOLDER (A) HIT-972563.A0 972563	-
286 - BOLT M10X30 (10 PCS.) HIT-949698.A2 949698	-
287 - SPRING WASHER M10 (10 PCS.) HIT-949458.A15 949458	£1.67	£2.00
288 - LINK PIN HIT-968622.A0 968622	-
289 - HEX. SOCKET SET SCREW M5X12 HIT-966292.A1 966292	£1.67	£2.00
290 - LINK HIT-968623.A0 968623	-
291 - BOLT M12X25 (10 PCS.) HIT-949671.A0 949671	-
292 - BOLT M16X25 HIT-948120.A0 948120	-
293 - BOLT WASHER M16 (10 PCS.) HIT-949438.A1 949438	-
294 - SPRING WASHER M16 (10 PCS.) HIT-949464.A0 949464	-
295 - MOTOR BASE SINGLE-PHASE HIT-968624.A0 968624	-
296 - MOTOR (SINGLE-PHASE) 230V FOR NZL HIT-976731.A0 976731	-
296A - MOTOR (220V/380V) THREE-PHASE HIT-000000.A4859 000000	-
296A - MOTOR (SINGLE-PHASE) 110V SINCE 7.1984 HIT-976864.A0 976864	-
296A - MOTOR (SINGLE-PHASE) 115V SINCE 7.1984 HIT-976865.A0 976865	-
296A - MOTOR (SINGLE-PHASE) 120V SINCE 7.1984 HIT-976866.A0 976866	-
296A - MOTOR (SINGLE-PHASE) 127V SINCE 7.1984 HIT-976867.A0 976867	-
296A - MOTOR (SINGLE-PHASE) 220V SINCE 7.1984 HIT-976868.A0 976868	-
296A - MOTOR (SINGLE-PHASE) 240V SINCE 7.1984 FOR HKG HIT-976869.A0 976869	-
296A - MOTOR (SINGLE-PHASE) 220V SINCE 7.1984 FOR HKG HIT-977170.A0 977170	-
296A - MOTOR (THREE-PHASE) 220V SINCE 7.1984 HIT-977171.A0 977171	-
296A - MOTOR (THREE-PHASE) 230V SINCE 7.1984 HIT-977172.A0 977172	-
296A - MOTOR (THREE-PHASE) 240V SINCE 7.1984 HIT-977173.A0 977173	-
296A - MOTOR (THREE-PHASE) 380V SINCE 7.1984 HIT-977174.A0 977174	-
296A - MOTOR (THREE-PHASE) 440V SINCE 7.1984 HIT-977175.A0 977175	-
296A - MOTOR (THREE-PHASE) 415V SINCE 7.1984 HIT-977176.A0 977176	-
296A - MOTOR (THREE-PHASE) 400V SINCE 7.1984 HIT-977177.A0 977177	-
296A - MOTOR (SINGLE-PHASE) 230V SINCE 7.1984 HIT-977178.A0 977178	-
296A - MOTOR (SINGLE-PHASE) 240V SINCE 7.1984 FOR KUW HIT-977179.A0 977179	-
297 - FEATHER KEY 7X7X50 TILL 6.1984 HIT-948122.A0 948122	-
297A - FEATHER KEY 8X7X48 SINCE 7.1984 HIT-964870.A0 964870	-
298 - BOLT M8X20 (10 PCS.) SINGLE-PHASE HIT-949624.A5 949624	-
299 - SPRING WASHER M8 (10 PCS.) SINGLE-PHASE HIT-949457.A45 949457	£1.67	£2.00
300 - PULLEY ASS'Y FOR MOTOR INCLUD.301-310 TILL 6.1984 HIT-968625.A0 968625	-
300A - PULLEY (B) ASS'Y FOR MOTOR SINGLE-PHASE SINCE 7.1984 HIT-976861.A0 976861	-
300B - PULLEY (B) ASS'Y FOR MOTOR THREE-PHASE SINCE 7.1984 HIT-976855.A0 976855	-
301 - PULLEY (C) TILL 6.1984 HIT-968626.A0 968626	-
301A - PULLEY (F) SINGLE-PHASE SINCE 7.1984 HIT-976862.A0 976862	-
301B - PULLEY (F) THREE-PHASE SINCE 7.1984 HIT-976856.A0 976856	-
302 - HEX. SOCKET SET SCREW M8X10 HIT-944744.A0 944744	-
303 - PULLEY (D) TILL 6.1984 HIT-968627.A0 968627	-
303A - PULLEY (G) SINCE 7.1984 HIT-976858.A0 976858	-
304 - PIN (B) HIT-968628.A0 968628	-
305 - SPRING HIT-948129.A0 948129	-
306 - GRIP HIT-948130.A0 948130	-
307 - ROLL PIN D5X25 (10 PCS.) HIT-949681.A6 949681	-
308 - BALL BEARING 6007ZZCMAV2S TILL 6.1984 HIT-6007ZZ.A0 6007ZZ	£15.57	£18.68
308A - BALL BEARING 6008ZZCMPS2L SINCE 7.1984 HIT-6008ZZ.A0 6008ZZ	-
309 - RETAINING RING FOR D35 SHAFT TILL 6.1984 HIT-948131.A0 948131	£1.67	£2.00
309A - RETAINING RING FOR D40 SHAFT SINCE 7.1984 HIT-948453.A0 948453	-
310 - RETAINING RING FOR D62 HOLE TILL 6.1984 HIT-977717.A1 977717	-
310A - RETAINING RING FOR D68 HOLE SINCE 7.1984 HIT-976860.A0 976860	-
313 - BOLT M10X30 (10 PCS.) HIT-949698.A1 949698	-
314 - SPRING WASHER M10 (10 PCS.) HIT-949458.A16 949458	£1.67	£2.00
315 - V-BELT (A-29) TILL 6.1984 HIT-968629.A0 968629	-
315A - V-BELT (A-30) SINCE 7.1984 HIT-965524.A0 965524	-
316 - V-BELT (3V-560) HIT-968630.A0 968630	-
317 - HAND BRAKE ASS'Y INCLUD.318-326 HIT-968631.A0 968631	-
318 - STAND HIT-968632.A0 968632	-
319 - BRAKE HOLDER HIT-968633.A0 968633	-
320 - BRAKE LINING HIT-968634.A0 968634	-
321 - SCREW M4.1X20 (10 PCS.) FOR WOOD HIT-949542.A0 949542	-
322 - BRAKE HANDLE HIT-968635.A0 968635	-
323 - GRIP (B) HIT-968636.A0 968636	-
324 - WASHER M14 HIT-968637.A0 968637	-
325 - ROLL PIN D5X25 (10 PCS.) HIT-949681.A5 949681	-
326 - ROLL PIN D6X28 (10 PCS.) HIT-949505.A0 949505	-
327 - BOLT M8X30 (10 PCS.) HIT-949628.A4 949628	-
328 - SPRING WASHER M8 (10 PCS.) HIT-949457.A44 949457	£1.67	£2.00
329 - MACHINE SCREW M6X45 (10 PCS.) HIT-949265.A0 949265	-
330 - NUT M6 (10 PCS.) HIT-949556.A8 949556	£1.67	£2.00
331 - MOTOR COVER HIT-968638.A0 968638	-
332 - MACHINE SCREW M6X12 (10 PCS.) HIT-949255.A7 949255	£1.67	£2.00
333 - SPRING WASHER M6 (10 PCS.) HIT-949455.A56 949455	£1.67	£2.00
334 - CAUTION PLATE (C) HIT-968682Z.A0 968682Z	-
335 - STOPPER HIT-966275.A0 966275	-
336 - SPRING ARM HIT-968640.A0 968640	-
337 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A13 949256	£1.67	£2.00
338 - SPRING WASHER M6 (10 PCS.) HIT-949455.A55 949455	£1.67	£2.00
339 - BRAKE SPRING HIT-966064.A0 966064	-
340 - BELT COVER ASS'Y INCLUD.342-344 HIT-972579Z.A0 972579Z	-
342 - WING BOLT M5X10 (10 PCS.) HIT-949397.A0 949397	£5.61	£6.73
343 - RETAINING RING (E-TYPE) FOR D4 SHAFT HIT-968643.A0 968643	£1.67	£2.00
344 - CAUTION LABEL (E) HIT-972577Z.A0 972577Z	-
345 - MACHINE SCREW M6X12 (10 PCS.) HIT-949255.A8 949255	£1.67	£2.00
346 - SPRING WASHER M6 (10 PCS.) HIT-949455.A52 949455	£1.67	£2.00
347 - PULLEY COVER HIT-968645.A0 968645	-
348 - CAUTION PLATE (A) HIT-968686Z.A0 968686Z	-
349 - WING BOLT M5X10 (10 PCS.) HIT-949397.A1 949397	£5.61	£6.73
350 - FRAME COVER HIT-968647.A0 968647	-
350 - FRAME COVER THREE-PHASE HIT-972599.A0 972599	-
351 - MACHINE SCREW M5X10 (10 PCS.) HIT-949236.A26 949236	£1.67	£2.00
352 - SPRING WASHER M5 (10 PCS.) HIT-949454.A95 949454	£1.67	£2.00
353 - SWITCH ASS'Y (K-TYPE) THREE-PHASE HIT-317858.A0 317858	-
353 - SWITCH (1P SCREW TYPE) SINGLE-PHASE HIT-937218.A0 937218	-
353 - SWITCH (B) K-TYPE SK5-T THREE-PHASE HIT-974975Z.A0 974975Z	-
354 - SWITCH INSULATOR SINGLE-PHASE HIT-937297.A0 937297	-
355 - SWITCH COVER SINGLE-PHASE HIT-968648.A0 968648	-
356 - CORD ARMOR D10.0 HIT-948613.A1 948613	-
357 - SWITCH PROTECTOR (A) SINGLE-PHASE HIT-973715.A0 973715	-
358 - MACHINE SCREW M5X10 (10 PCS.) SINGLE-PHASE HIT-949236.A25 949236	£1.67	£2.00
359 - SPRING WASHER M5 (10 PCS.) SINGLE-PHASE HIT-949454.A94 949454	£1.67	£2.00
360 - CORD THREE-PHASE HIT-968649.A0 968649	-
362 - CORD CLIP HIT-965378.A0 965378	-
363 - MACHINE SCREW M6X12 (10 PCS.) HIT-949255.A9 949255	£1.67	£2.00
364 - SPRING WASHER M6 (10 PCS.) HIT-949455.A53 949455	£1.67	£2.00
365 - CONNECTOR 50092 (10 PCS.) THREE-PHASE HIT-959141.A41 959141	£7.12	£8.54
365S - CONNECTOR 50092 (10 PCS.) 220V/380V HIT-959141.A42 959141	£7.12	£8.54
366 - CORD THREE-PHASE HIT-968650.A0 968650	-
367 - SWITCH HOLDER THREE-PHASE HIT-317919.A0 317919	-
367 - SWITCH HOLDER THREE-PHASE HIT-968687Z.A0 968687Z	-
368 - MACHINE SCREW M4X8 (10 PCS.) THREE-PHASE HIT-949215.A11 949215	£1.67	£2.00
369 - SPRING WASHER M4 (10 PCS.) THREE-PHASE HIT-949453.A30 949453	£1.67	£2.00
370 - SAW COVER ASS'Y (FOR SINGLE-PHASE) INCLUD.371 HIT-972580Z.A0 972580Z	-
370 - SAW COVER ASS'Y (FOR THREE-PHASE) INCLUD.371 HIT-972581Z.A0 972581Z	-
371 - CAUTION PLATE HIT-968684Z.A0 968684Z	-
372 - CAUTION PLATE HIT-968685Z.A0 968685Z	-
373 - BOLT M8X20 (10 PCS.) HIT-949624.A4 949624	-
374 - GOVERNOR SPRING HIT-873923.A0 873923	£1.67	£2.00
375 - LINER (A) T0.1 HIT-966511.A0 966511	-
376 - LINER (A) T0.2 HIT-966512.A1 966512	-
377 - LINER (B) HIT-968655.A0 968655	-
378 - SIDE GRIP HIT-967589.A0 967589	-
379 - SCREW (M) M8X90 HIT-968656.A0 968656	-
380 - WASHER W3/8 HIT-968552.A0 968552	-
381 - SPRING WASHER M8 (10 PCS.) TILL 2.1984 HIT-949457.A51 949457	£1.67	£2.00
382 - NUT M8 (10 PCS.) HIT-949558.A21 949558	£1.67	£2.00
383 - MITER GAUGE HIT-972448.A0 972448	-
384 - BOX WRENCH 10MM HIT-940543.A7 940543	£7.34	£8.81
385 - WRENCH 10/13MM HIT-972043.A0 972043	£7.22	£8.66
386 - WRENCH 19/24MM HIT-948163.A0 948163	-
387 - SCREWDRIVER NO.2 HIT-945882.A0 945882	-
388 - BLADE HEIGHT-ADJUSTING RULER (A) HIT-972601.A0 972601	-
390 - BLADE HEIGHT-ADJUSTING RULER (B) HIT-972568.A0 972568	-
391 - WRENCH 41MM HIT-966266.A0 966266	-
392 - WRENCH 41MM HIT-967327.A0 967327	-
393A - TOOL BOX HIT-945439.A0 945439	-
396 - FLAT HD. SCREW M6X50 (10 PCS.) HIT-949796.A0 949796	-
397 - WASHER (H) HIT-967329.A0 967329	£1.67	£2.00
398 - NUT M6 (10 PCS.) HIT-949556.A7 949556	£1.67	£2.00
399 - WING BOLT M5X15 (10 PCS.) HIT-949393.A0 949393	-
400 - FLAT HD. SCREW M6X25 (10 PCS.) HIT-949342.A13 949342	£1.67	£2.00
402 - WASHER W3/8 SINCE 10.1983 HIT-976351.A0 976351	-
405 - BOLT WASHER M6 (10 PCS.) HIT-949432.A82 949432	£1.67	£2.00
406 - SPRING WASHER M12 (10 PCS.) HIT-949463.A5 949463	£1.67	£2.00
407 - HEX. SOCKET HD. BOLT M5X15 (10 PCS.) HIT-949820.A2 949820	£3.28	£3.93
408 - SPRING WASHER M5 (10 PCS.) HIT-949454.A96 949454	£1.67	£2.00
409 - TENSIONER HOLDER (B) HIT-968663.A0 968663	-
410 - CABLE TIE THREE-PHASE HIT-975144.A12 975144	-
412 - BOLT WASHER M10 (10 PCS.) HIT-949434.A8 949434	£1.67	£2.00
414 - STOPPER HIT-968668.A0 968668	-
415 - MACHINE SCREW M6X16 (10 PCS.) HIT-949256.A12 949256	£1.67	£2.00
416 - SPRING WASHER M6 (10 PCS.) HIT-949455.A51 949455	£1.67	£2.00
417 - SCREW (D) HIT-967104.A0 967104	-
418 - NUT M8 (10 PCS.) HIT-949558.A20 949558	£1.67	£2.00
419 - CONNECTING BAR HIT-968670.A0 968670	-
420 - WING BOLT M6X20 (10 PCS.) HIT-949404.A2 949404	£9.03	£10.84
421 - SUB TABLE HIT-968601.A0 968601	-
422 - PLATE ARM HIT-968671.A0 968671	-
423 - FLAT HD. SCREW M6X14 (10 PCS.) HIT-949339.A0 949339	-
424 - EXTENSION BASE HIT-972026.A0 972026	-
425 - LINK HIT-972027.A0 972027	-
426 - PIN (A) HIT-972028.A0 972028	-
427 - ROLL PIN D4X25 (10 PCS.) HIT-949548.A2 949548	-
429 - BASE HOLDER HIT-948938.A0 948938	-
430 - HEX. SOCKET HD. BOLT M8X25 (10 PCS.) HIT-949760.A7 949760	£6.62	£7.95
431 - SPRING WASHER M8 (10 PCS.) HIT-949457.A54 949457	£1.67	£2.00
432 - PIN (B) HIT-948940.A0 948940	-
433 - LINK HOLDER HIT-972029.A0 972029	-
434 - HEX. SOCKET HD. BOLT M10X25 (10 PCS.) HIT-949845.A0 949845	£7.03	£8.44
435 - SPRING WASHER M10 (10 PCS.) HIT-949458.A14 949458	£1.67	£2.00
436 - SCREW PIN HIT-948943.A0 948943	-
437 - ROLL PIN D6X32 (10 PCS.) HIT-949576.A3 949576	-
438 - HEX. SOCKET HD. BOLT M10X30 (10 PCS.) HIT-949846.A0 949846	£8.53	£10.24
439 - GUIDE HOLDER (C) HIT-972570.A0 972570	-
440 - BOLT M8X20 (10 PCS.) HIT-949624.A3 949624	-
441 - SPRING WASHER M8 (10 PCS.) HIT-949457.A53 949457	£1.67	£2.00
442 - GUIDE HOLDER (B) HIT-967922.A0 967922	-
443 - BLADE HOLDER (1 PAIR) SINCE 5.1984 HIT-973819.A0 973819	-
444 - CUTTER SPRING TILL 4.1984 HIT-947525.A1 947525	-
445 - PIN TILL 4.1984 HIT-946363.A1 946363	-
446 - CAUTION LABEL (D) HIT-972576Z.A0 972576Z	-
447 - CAUTION LABEL (C) HIT-972582Z.A0 972582Z	-
449 - FREE BUSHING THREE-PHASE TILL 3.1992 HIT-964636.A0 964636	-
450 - LINER (B) HIT-972583.A0 972583	-
451 - LINER (B) HIT-972584.A0 972584	-
452 - WASHER (T) HIT-967115.A0 967115	-
453 - SHOOT HIT-972589.A0 972589	-
454 - BOLT M8X16 (10 PCS.) HIT-949622.A8 949622	-
455 - SPRING WASHER M8 (10 PCS.) HIT-949457.A52 949457	£1.67	£2.00
456 - BOLT WASHER M8 (10 PCS.) HIT-949433.A12 949433	£1.67	£2.00
457 - SWITCH PACKING THREE-PHASE HIT-974351.A0 974351	-
458 - REAR BASE HIT-000000.A4860 000000	-
459 - FRONT BASE HIT-000000.A4861 000000	-
460 - SWITCH NAME PLATE (E) SINGLE-PHASE HIT-932161.A1 932161	-
461 - JOINTER GUARD FOR NZL HIT-973911.A0 973911	-
463 - TERMINAL PLATE (A) THREE-PHASE HIT-966585.A0 966585	-
464 - MACHINE SCREW M4X16 (10 PCS.) THREE-PHASE HIT-949219.A5 949219	-
465 - SPRING WASHER M4 (10 PCS.) HIT-949453.A31 949453	£1.67	£2.00
466 - TERMINAL COVER (A) HIT-972600.A0 972600	-
467 - CONNECTION PLATE THREE-PHASE HIT-000000.A4862 000000	-
468 - RIVET D2.5X4.8 (10 PCS.) THREE-PHASE HIT-949510.A18 949510	£1.67	£2.00
469 - MACHINE SCREW M5X10 (10 PCS.) THREE-PHASE HIT-949236.A53 949236	£1.67	£2.00
470 - SPRING WASHER M5 (10 PCS.) THREE-PHASE HIT-949454.A37 949454	£1.67	£2.00
471 - CABLE TIE HIT-975144.A1 975144	-
472 - VINYL TUBE (I.D.8XT1X25) FOR NZL HIT-000000.A2979 000000	-
473 - CORD (B) ASS'Y THREE-PHASE HIT-976854.A0 976854	-
475 - SWITCH PACKING (10X95MM) HIT-968336.A0 968336	-
476 - LINER HIT-967754.A0 967754	-
700 - MOTOR ASS'Y (WM-2) HIT-000000.A2980 000000	-
701 - HOUSING ASS'Y INCLUD.702 HIT-972730.A0 972730	-
702A - BRUSH HOLDER HIT-956984.A1 956984	£11.55	£13.86
703 - HEX. SOCKET SET SCREW M4X5 HIT-967508.A1 967508	-
704 - STATOR ASS'Y 110V-115V INCLUD.705 SINGLE-PHASE HIT-968914C.A0 968914C	-
704 - STATOR ASS'Y 120V-127V INCLUD.705 SINGLE-PHASE HIT-968914D.A0 968914D	-
704 - STATOR ASS'Y 220V-230V INCLUD.705 SINGLE-PHASE HIT-968914E.A0 968914E	-
704 - STATOR ASS'Y 240V INCLUD.705 SINGLE-PHASE HIT-968914F.A1 968914F	-
705 - BRUSH TERMINAL HIT-998744.A3 998744	£1.67	£2.00
706 - MACHINE SCREW (W/SP. WASHER) M5X80 HIT-977749.A1 977749	-
708 - STOP PLATE HIT-976307.A0 976307	-
709 - FAN GUIDE HIT-948603.A0 948603	-
710 - ARMATURE 110V-115V SINGLE-PHASE HIT-968916C.A0 968916C	-
710 - ARMATURE 120V-127V SINGLE-PHASE HIT-968916D.A0 968916D	-
710 - ARMATURE 220V-230V SINGLE-PHASE HIT-968916E.A0 968916E	-
710 - ARMATURE 240V SINGLE-PHASE HIT-968916F.A0 968916F	-
711 - BALL BEARING 6200VVCMPS2L HIT-6200VV.A21 6200VV	£7.36	£8.83
712 - BALL BEARING 6202VVCMPS2L HIT-6202VV.A7 6202VV	£7.02	£8.42
713 - BEARING LOCK HIT-976301.A0 976301	£1.67	£2.00
714 - GEAR COVER HIT-968911.A0 968911	-
715 - MACHINE SCREW M6X20 (10 PCS.) HIT-949258.A2 949258	£1.67	£2.00
716 - MACHINE SCREW M6X25 (10 PCS.) HIT-949260.A6 949260	£1.67	£2.00
717 - SPRING WASHER M6 (10 PCS.) HIT-949455.A101 949455	£1.67	£2.00
718 - GEAR HIT-968910.A0 968910	-
719 - SPINDLE TILL 6.1984 HIT-948608.A0 948608	-
719A - SPINDLE SINCE 7.1984 HIT-974729.A1 974729	-
720 - FEATHER KEY 4X4X12 HIT-931008.A4 931008	-
721 - BALL BEARING 6202VVCMPS2L HIT-6202VV.A8 6202VV	£7.02	£8.42
722 - BALL BEARING 6205VVCMPS2L HIT-6205VV.A2 6205VV	£10.95	£13.14
723 - COVER HIT-968912.A0 968912	-
724 - HEX. SOCKET HD. BOLT M6X20 (10 PCS.) HIT-949660.A0 949660	£3.97	£4.76
725 - SPRING WASHER M6 (10 PCS.) HIT-949455.A102 949455	£1.67	£2.00
726 - CAP HIT-948618.A0 948618	-
727 - CARBON BRUSH (1 PAIR) HIT-999044.A12 999044	£5.54	£6.65
728 - BRUSH CAP HIT-978445.A2 978445	£1.67	£2.00
729 - NOISE SUPPRESSOR COVER HIT-948385.A0 948385	-
730 - NOISE SUPPRESSOR HIT-930030.A0 930030	-
731 - SHIELD HIT-947346.A0 947346	-
732 - CONNECTOR 50092 (10 PCS.) HIT-959141.A73 959141	£7.12	£8.54
733 - CORD (B) HIT-948612.A0 948612	-
734 - CORD ASS'Y FOR HKG HIT-976733.A0 976733	-
734 - CORD ASS'Y FOR KUW HIT-976734.A0 976734	-
734 - CORD ASS'Y FOR OCEANIA HIT-976735.A0 976735	-
734 - CORD ASS'Y HIT-976737.A0 976737	-
735 - MACHINE SCREW (BRASS) M4X6 (10 PCS.) HIT-949292.A10 949292	-
736 - NYLON CLIP HIT-948193.A7 948193	£1.67	£2.00
737 - CORD ARMOR D10.0 HIT-948613.A0 948613	-
738 - CORD ARMOR (A) D10.0 HIT-947063.A0 947063	-
739 - NYLON CLIP HIT-967579.A0 967579	-
741 - NUT M4 (10 PCS.) HIT-949554.A42 949554	£1.67	£2.00
743 - MACHINE SCREW M4X10 (10 PCS.) HIT-949216.A5 949216	£1.67	£2.00
744 - SPRING WASHER M4 (10 PCS.) HIT-949453.A59 949453	£1.67	£2.00
746 - SPRING HIT-968919.A0 968919	-
747 - MACHINE SCREW M5X10 (10 PCS.) HIT-949236.A52 949236	£1.67	£2.00
748 - BOLT WASHER M5 (10 PCS.) HIT-949431.A20 949431	£1.67	£2.00
749 - CABLE TIE HIT-975144.A0 975144	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki PU100F Universal Woodworking Machine Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
