1 - HEX. SOCKET HD. BOLT M6X12 (10 PCS.)
HIT-949657.A9
949657
|
-
|
|
|
|
2 - PLATE
HIT-882919.A0
882919
|
-
|
|
|
|
3A - TOP COVER
HIT-882917.A0
882917
|
-
|
|
|
|
4 - MUFFLER
HIT-882918.A1
882918
|
-
|
|
|
|
5 - PROTECTOR (A)
HIT-882916.A0
882916
|
-
|
|
|
|
6 - HEX. SOCKET HD. BOLT M5X25 (10 PCS.)
HIT-949662.A10
949662
|
£3.64
|
£4.37
|
|
|
7 - EXHAUST COVER
HIT-882911.A0
882911
|
-
|
|
|
|
8 - GASKET (A)
HIT-882915.A0
882915
|
-
|
|
|
|
9 - HEAD BUMPER
HIT-882914.A6
882914
|
£9.32
|
£11.19
|
|
|
10 - HEAD VALVE SPRING
HIT-882913.A0
882913
|
-
|
|
|
|
11A - O-RING (I.D. 20.8)
HIT-883992.A7
883992
|
-
|
|
|
|
12A - HEAD VALVE (A)
HIT-882927.A0
882927
|
-
|
|
|
|
13 - O-RING (S-70)
HIT-878863.A0
878863
|
£1.67
|
£2.00
|
|
|
14 - CYLINDER PLATE
HIT-882910.A1
882910
|
-
|
|
|
|
15 - O-RING (S-46)
HIT-882874.A1
882874
|
-
|
|
|
|
16 - O-RING (1AP-48)
HIT-877368.A2
877368
|
£1.67
|
£2.00
|
|
|
17 - CYLINDER
HIT-882909.A0
882909
|
-
|
|
|
|
18 - PISTON O-RING
HIT-882871.A0
882871
|
-
|
|
|
|
19 - PISTON RING
HIT-882872.A1
882872
|
-
|
|
|
|
20 - PISTON (H)
HIT-882870.A0
882870
|
-
|
|
|
|
21A - FEEDER SHAFT RING SINCE 12.2008
HIT-886669.A0
886669
|
-
|
|
|
|
22 - NAME PLATE
HIT-000000.A5349
000000
|
-
|
|
|
|
23 - BODY
HIT-883857.A0
883857
|
-
|
|
|
|
24 - BRAND LABEL
HIT-000000.A5350
000000
|
-
|
|
|
|
25 - PISTON BUMPER
HIT-882873.A0
882873
|
-
|
|
|
|
26 - O-RING (P-4)
HIT-874436.A6
874436
|
£1.67
|
£2.00
|
|
|
27 - NOSE
HIT-882875.A0
882875
|
-
|
|
|
|
28 - NYLOCK HIGH TENSION BOLT M6X20
HIT-880675.A0
880675
|
-
|
|
|
|
29 - ROLL PIN D4X16 (10 PCS.)
HIT-949497.A0
949497
|
£3.28
|
£3.93
|
|
|
30 - NEEDLE ROLLER
HIT-880659.A2
880659
|
-
|
|
|
|
31 - FEEDER ARM
HIT-878132.A8
878132
|
-
|
|
|
|
32 - FEEDER SPRING
HIT-882924.A0
882924
|
-
|
|
|
|
33 - FEEDER
HIT-883785.A0
883785
|
-
|
|
|
|
34 - PUSHING LEVER COVER (B)
HIT-882900.A1
882900
|
-
|
|
|
|
35 - PUSHING LEVER
HIT-882884.A0
882884
|
-
|
|
|
|
36 - NYLON NUT M5
HIT-877371.A17
877371
|
£1.67
|
£2.00
|
|
|
37 - O-RING (I.D 37.2)
HIT-880183.A2
880183
|
£1.67
|
£2.00
|
|
|
38 - CAP
HIT-883177.A0
883177
|
-
|
|
|
|
39 - DUST CAP
HIT-877914.A0
877914
|
-
|
|
|
|
40A - AIR PLUG PT 1/4
HIT-874782.A1
874782
|
-
|
|
|
|
41 - TRIGGER PIECE TILL 4.2008
HIT-882896.A0
882896
|
-
|
|
|
|
41A - TRIGGER PIECE (C) SINCE 5.2008
HIT-886626.A2
886626
|
-
|
|
|
|
42 - SPRING TILL 4.2008
HIT-882897.A2
882897
|
-
|
|
|
|
42A - TRIGGER SPRING SINCE 5.2008
HIT-886627.A2
886627
|
-
|
|
|
|
43 - TRIGGER ARM (B) TILL 4.2008
HIT-882895.A2
882895
|
-
|
|
|
|
43A - TRIGGER ARM (C) SINCE 5.2008
HIT-886625.A0
886625
|
-
|
|
|
|
44 - ROLL PIN D2.5X16
HIT-881951.A18
881951
|
-
|
|
|
|
45 - TRIGGER TILL 4.2008
HIT-882894.A0
882894
|
-
|
|
|
|
45A - TRIGGER SINCE 5.2008
HIT-886623.A0
886623
|
-
|
|
|
|
46 - TRIGGER SPRING
HIT-883759.A3
883759
|
-
|
|
|
|
47 - PUSHING LEVER GUIDE
HIT-882885.A0
882885
|
-
|
|
|
|
48 - PUSHING LEVER SPRING
HIT-882892.A4
882892
|
-
|
|
|
|
49 - PUSHING LEVER (C)
HIT-882891.A0
882891
|
-
|
|
|
|
50 - ADJUSTER
HIT-882889.A0
882889
|
-
|
|
|
|
51 - ROLL PIN D2X16
HIT-880093.A0
880093
|
-
|
|
|
|
52 - ADJUSTER SPRING
HIT-882890.A9
882890
|
-
|
|
|
|
53 - ADJUSTER PLATE (B)
HIT-882887.A0
882887
|
-
|
|
|
|
54 - ADJUSTER PLATE (A)
HIT-882886.A9
882886
|
-
|
|
|
|
55 - O-RING (S-4)
HIT-981317.A34
981317
|
£1.67
|
£2.00
|
|
|
56 - PUSHING LEVER (B)
HIT-882888.A6
882888
|
-
|
|
|
|
57 - O-RING (S-5)
HIT-872822.A1
872822
|
£3.19
|
£3.83
|
|
|
58 - RETAINING RING (E-TYPE) FOR D3 SHAFT
HIT-872971.A34
872971
|
£1.67
|
£2.00
|
|
|
59 - ROLL PIN D3X22 (10 PCS.)
HIT-949864.A7
949864
|
£3.28
|
£3.93
|
|
|
60 - ROLL PIN D3X28 (10 PCS.)
HIT-949865.A0
949865
|
£3.28
|
£3.93
|
|
|
61A - LOCK KNOB SINCE 12.2008
HIT-886727.A1
886727
|
-
|
|
|
|
62 - STEEL BALL D3.175 (10 PCS.)
HIT-959148.A69
959148
|
£1.67
|
£2.00
|
|
|
63 - LOCK SPRING
HIT-882923.A0
882923
|
-
|
|
|
|
64 - HOOK
HIT-883763.A1
883763
|
-
|
|
|
|
65 - MACHINE SCREW M5X35 (BLACK)
HIT-302197.A0
302197
|
£1.67
|
£2.00
|
|
|
66 - HEAD VALVE O-RING (I.D 16.8)
HIT-877699.A9
877699
|
£1.67
|
£2.00
|
|
|
67 - VALVE BUSHING (B)
HIT-882925.A0
882925
|
-
|
|
|
|
68 - O-RING (S-18)
HIT-878885.A0
878885
|
£1.67
|
£2.00
|
|
|
69 - O-RING (I.D 8.8)
HIT-878925.A13
878925
|
£1.67
|
£2.00
|
|
|
70 - VALVE PISTON (B)
HIT-880672.A11
880672
|
£25.41
|
£30.49
|
|
|
71 - O-RING (I.D 11)
HIT-878887.A13
878887
|
£1.67
|
£2.00
|
|
|
72 - PLUNGER SPRING
HIT-878884.A12
878884
|
£1.67
|
£2.00
|
|
|
73 - PLUNGER (A) TILL 4.2008
HIT-882921.A2
882921
|
-
|
|
|
|
73A - PLUNGER (A) SINCE 5.2008
HIT-886622.A0
886622
|
-
|
|
|
|
74 - O-RING (I.D. 1.8)
HIT-878888.A0
878888
|
£1.67
|
£2.00
|
|
|
75 - VALVE BUSHING (A)
HIT-882920.A0
882920
|
-
|
|
|
|
76 - SHAFT RING
HIT-880319.A21
880319
|
£1.67
|
£2.00
|
|
|
77 - O-RING (P-9)
HIT-872645.A15
872645
|
£1.67
|
£2.00
|
|
|
78 - O-RING (P-21)
HIT-880330.A0
880330
|
£1.67
|
£2.00
|
|
|
79 - FEED PISTON
HIT-882673.A1
882673
|
-
|
|
|
|
80 - FEED SPRING
HIT-882883.A2
882883
|
-
|
|
|
|
81 - BUMPER
HIT-877711.A6
877711
|
£1.67
|
£2.00
|
|
|
82 - FEED PISTON COVER
HIT-880331.A8
880331
|
£3.76
|
£4.51
|
|
|
83 - MAGAZINE BUSHING
HIT-878305.A6
878305
|
£1.67
|
£2.00
|
|
|
84 - RETAINING RING FOR D28 HOLE (10 PCS.)
HIT-939555.A7
939555
|
-
|
|
|
|
85 - SLEEVE
HIT-882907.A0
882907
|
£5.09
|
£6.11
|
|
|
86 - PUSHING LEVER COVER (A)
HIT-882899.A0
882899
|
-
|
|
|
|
87 - PROTECTOR (B)
HIT-882901.A0
882901
|
-
|
|
|
|
88A - WARNING LABEL
HIT-884070.A1
884070
|
-
|
|
|
|
89 - PIN
HIT-881825.A0
881825
|
£1.67
|
£2.00
|
|
|
90 - MAGAZINE
HIT-882903.A1
882903
|
-
|
|
|
|
91A - FEEDER SHAFT RING
HIT-877826.A17
877826
|
£1.67
|
£2.00
|
|
|
92 - MAGAZINE COVER
HIT-882904.A0
882904
|
-
|
|
|
|
93 - CAUTION PLATE (B)
HIT-000000.A5351
000000
|
-
|
|
|
|
94 - CAUTION PLATE (A)
HIT-000000.A5352
000000
|
-
|
|
|
|
95 - HOLDER CAP (A)
HIT-881003.A7
881003
|
£1.67
|
£2.00
|
|
|
96 - RATCHET SPRING
HIT-880398.A7
880398
|
£5.87
|
£7.04
|
|
|
97A - NAIL HOLDER
HIT-885683.A2
885683
|
-
|
|
|
|
98 - ROLL PIN D2.5X12
HIT-878791.A10
878791
|
£1.67
|
£2.00
|
|
|
99A - HOLDER SHAFT
HIT-889509.A1
889509
|
-
|
|
|
|
100 - SPRING
HIT-881826.A4
881826
|
£1.67
|
£2.00
|
|
|
101 - HEX. SOCKET HD. BOLT M5X20 (10 PCS.)
HIT-949757.A35
949757
|
£3.64
|
£4.37
|
|
|
102 - NAIL GUIDE SHAFT
HIT-880658.A1
880658
|
-
|
|
|
|
103 - NAIL STOPPER (A)
HIT-883783.A2
883783
|
-
|
|
|
|
104 - NAIL STOPPER SPRING
HIT-882878.A0
882878
|
-
|
|
|
|
105 - NAIL GUIDE
HIT-883786.A0
883786
|
-
|
|
|
|
106 - GUIDE LOCK
HIT-886107.A5
886107
|
£8.59
|
£10.31
|
|
|
107 - SPRING
HIT-880446.A3
880446
|
£1.67
|
£2.00
|
|
|
108 - NAIL STOPPER (B)
HIT-882680.A1
882680
|
£4.22
|
£5.07
|
|
|
109 - STOPPER SPRING
HIT-880494.A4
880494
|
£1.67
|
£2.00
|
|
|
110 - NYLOCK HEX. SOCKET HD. BOLT M4X10
HIT-880413.A17
880413
|
£1.67
|
£2.00
|
|
|
111 - COVER
HIT-882880.A1
882880
|
-
|
|
|
|
112 - NAIL GUIDE COVER
HIT-883784.A0
883784
|
-
|
|
|
|
113 - SLEEVE (B)
HIT-882881.A0
882881
|
-
|
|
|
|
114 - NYLOCK HEX. SOCKET HD. BOLT M4X12
HIT-880630.A9
880630
|
£1.67
|
£2.00
|
|
|
115 - MAGAZINE ASS'Y INCLUD.88-100
HIT-882926.A0
882926
|
-
|
|
|
|
116 - ROLL PIN D1.6X10 SINCE 5.2008
HIT-886228.A3
886228
|
-
|
|
|
|
117 - TRIGGER ARM ASS'Y INCLUD.41A
HIT-886624.A1
886624
|
-
|
|
|
|
118 - LOCK KNOB SET TILL 11.2008 INCLUD.21A
HIT-888728.A0
888728
|
-
|
|
|
|
501 - PNEUMATIC TOOL LUBRICANT (30CC)
HIT-877153.A20
877153
|
-
|
|
|
|
502 - PROTECTIVE GLASSES
HIT-875769.A9
875769
|
-
|
|
|
|
503 - NOSE CAP (A)
HIT-880678.A1
880678
|
-
|
|
|
|
504B - CASE
HIT-888666.A3
888666
|
-
|
|
|
|
601 - GRIP TAPE
HIT-880408.A2
880408
|
£10.98
|
£13.17
|
|
|
602A - TAPE (2 PCS.)
HIT-888213.A26
888213
|
-
|
|
|
