1 - DEFLECTOR
HIT-882270.A2
882270
|
-
|
|
|
|
2 - BOLT M5X20
HIT-882271.A0
882271
|
-
|
|
|
|
3 - CAP
HIT-882350.A0
882350
|
-
|
|
|
|
4 - SEAL
HIT-882273.A1
882273
|
-
|
|
|
|
5 - SPRING
HIT-882274.A1
882274
|
-
|
|
|
|
6 - O-RING (I.D 13.8)
HIT-882275.A1
882275
|
-
|
|
|
|
7 - HD. VALVE PISTON
HIT-882276.A1
882276
|
-
|
|
|
|
8 - O-RING (I.D 31.8)
HIT-882277.A1
882277
|
-
|
|
|
|
9 - O-RING (I.D 23)
HIT-882278.A1
882278
|
-
|
|
|
|
10 - GASKET
HIT-882279.A1
882279
|
-
|
|
|
|
11 - COLLAR
HIT-882280.A1
882280
|
-
|
|
|
|
12 - O-RING (I.D 43)
HIT-882281.A0
882281
|
-
|
|
|
|
13 - O-RING (I.D 21.7)
HIT-882282.A2
882282
|
-
|
|
|
|
14 - DRIVER UNIT
HIT-882351.A0
882351
|
-
|
|
|
|
14A - DRIVER UNIT WITH FUNCTION OF ADJUSTING THE NAILING
HIT-882372.A0
882372
|
-
|
|
|
|
*14A - DRIVER UNIT DEPTH
HIT-882372.A1
882372
|
-
|
|
|
|
15 - O-RING (I.D 29.87)
HIT-882284.A1
882284
|
-
|
|
|
|
16 - CYLINDER TILL 7.2003
HIT-882352.A0
882352
|
-
|
|
|
|
16A - CYLINDER SINCE 8.2003
HIT-882367.A0
882367
|
-
|
|
|
|
17 - CYLINDER RING
HIT-882286.A1
882286
|
-
|
|
|
|
18 - BUMPER
HIT-882353.A0
882353
|
-
|
|
|
|
19 - LABEL
HIT-000000.A295
000000
|
-
|
|
|
|
20 - RING
HIT-882296.A2
882296
|
-
|
|
|
|
21A - WARNING LABEL
HIT-881128.A1
881128
|
-
|
|
|
|
22 - JOINT GUIDE
HIT-882288.A2
882288
|
-
|
|
|
|
23 - SAFETY GUIDE
HIT-882305.A0
882305
|
-
|
|
|
|
24 - SPRING PIN D3X25
HIT-882306.A3
882306
|
-
|
|
|
|
24A - SPRING PIN D3X25 WITH FUNCTION OF ADJUSTING THE NAILING
HIT-882306.A4
882306
|
-
|
|
|
|
*24A - SPRING PIN D3X25 DEPTH
HIT-882306.A5
882306
|
-
|
|
|
|
25 - SPRING
HIT-882307.A1
882307
|
-
|
|
|
|
26 - SAFETY
HIT-882354.A0
882354
|
-
|
|
|
|
26A - SAFETY WITH FUNCTION OF ADJUSTING THE NAILING
HIT-882373.A0
882373
|
-
|
|
|
|
*26A - SAFETY DEPTH
HIT-882373.A1
882373
|
-
|
|
|
|
27 - HEX. SOCKET HD. BOLT M4X16
HIT-882314.A0
882314
|
-
|
|
|
|
28 - GUN BODY UNIT TILL 7.2003
HIT-882301.A0
882301
|
-
|
|
|
|
28A - GUN BODY UNIT MARK:P SINCE 8.2003
HIT-882339.A0
882339
|
-
|
|
|
|
28B - BODY WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885049.A1
885049
|
-
|
|
|
|
*28B - BODY DEPTH
HIT-885049.A2
885049
|
-
|
|
|
|
29 - NAME PLATE
HIT-000000.A294
000000
|
-
|
|
|
|
30 - O-RING (I.D 37)
HIT-882302.A1
882302
|
-
|
|
|
|
31 - END CAP
HIT-882303.A1
882303
|
-
|
|
|
|
32 - AIR PLUG
HIT-882304.A1
882304
|
-
|
|
|
|
33 - SAFETY
HIT-882297.A0
882297
|
-
|
|
|
|
34 - TRIGGER
HIT-882298.A2
882298
|
-
|
|
|
|
35 - SPRING PIN D2.5X16
HIT-882299.A0
882299
|
-
|
|
|
|
36 - STEPPED PIN
HIT-882300.A2
882300
|
-
|
|
|
|
37 - SEAL
HIT-882289.A0
882289
|
-
|
|
|
|
38 - TRIGGER VALVE HEAD
HIT-882290.A2
882290
|
-
|
|
|
|
39 - SPRING
HIT-882291.A0
882291
|
-
|
|
|
|
40 - O-RING (I.D 2.5)
HIT-882293.A0
882293
|
-
|
|
|
|
41 - TRIGGER VALVE STEM
HIT-882292.A2
882292
|
-
|
|
|
|
42 - O-RING (I.D 13)
HIT-882294.A2
882294
|
-
|
|
|
|
43 - TRIGGER VALVE GUIDE
HIT-882295.A0
882295
|
-
|
|
|
|
44 - DRIVER GUIDE COVER (B) TILL 7.2003
HIT-882356.A0
882356
|
-
|
|
|
|
44A - DRIVER GUIDE COVER (B) SINCE 8.2003
HIT-882368.A0
882368
|
-
|
|
|
|
45 - DRIVER GUIDE TILL 7.2003
HIT-882355.A0
882355
|
-
|
|
|
|
45A - DRIVER GUIDE SINCE 8.2003
HIT-882369.A0
882369
|
-
|
|
|
|
46 - BOLT M4X12
HIT-882315.A1
882315
|
-
|
|
|
|
47 - FIXED PLATE
HIT-882317.A1
882317
|
-
|
|
|
|
48 - LOCK NUT M4
HIT-882316.A0
882316
|
-
|
|
|
|
49 - STOPPER
HIT-882318.A0
882318
|
-
|
|
|
|
50 - STOPPER
HIT-882358.A0
882358
|
-
|
|
|
|
51 - MAGAZINE (A)
HIT-882359.A0
882359
|
-
|
|
|
|
51A - MAGAZINE (A) WITH FUNCTION OF ADJUSTING THE NAILING
HIT-882374.A0
882374
|
-
|
|
|
|
*51A - MAGAZINE (A) DEPTH
HIT-882374.A1
882374
|
-
|
|
|
|
52 - FLAT BAR
HIT-882321.A1
882321
|
-
|
|
|
|
53 - HEX. SOCKET HD. BOLT M4X14
HIT-882311.A1
882311
|
-
|
|
|
|
54 - DRIVER GUIDE COVER (A) TILL 7.2003
HIT-882357.A0
882357
|
-
|
|
|
|
54A - GUIDE PLATE (A) SINCE 8.2003
HIT-882370.A0
882370
|
-
|
|
|
|
55 - HEX. SOCKET HD. BOLT M4X10
HIT-882313.A1
882313
|
-
|
|
|
|
56 - STOPPER
HIT-882364.A0
882364
|
-
|
|
|
|
57 - MAGAZINE (B)
HIT-882363.A0
882363
|
-
|
|
|
|
58 - STOPPER
HIT-882365.A0
882365
|
-
|
|
|
|
59 - BOLT M4X10
HIT-882366.A0
882366
|
-
|
|
|
|
60 - PUSHER
HIT-882361.A0
882361
|
-
|
|
|
|
61 - SHAFT
HIT-882360.A0
882360
|
-
|
|
|
|
62 - SPRING
HIT-882322.A1
882322
|
-
|
|
|
|
63 - REAR PLATE
HIT-882362.A0
882362
|
-
|
|
|
|
64 - BOLT M4X8
HIT-882328.A0
882328
|
-
|
|
|
|
65 - LOCK LEVER
HIT-882371.A0
882371
|
-
|
|
|
|
66 - SPRING PIN D2.5X12
HIT-882327.A1
882327
|
-
|
|
|
|
67 - WARNING LABEL
HIT-000000.A2756
000000
|
-
|
|
|
|
68 - DUST COVER WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885050.A0
885050
|
-
|
|
|
|
*68 - DUST COVER DEPTH
HIT-885050.A1
885050
|
-
|
|
|
|
69 - NAME PLATE
HIT-000000.A2759
000000
|
-
|
|
|
|
70 - SAFETY GUIDE WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885065.A0
885065
|
-
|
|
|
|
*70 - SAFETY GUIDE DEPTH
HIT-885065.A1
885065
|
-
|
|
|
|
71 - SPRING WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885064.A3
885064
|
-
|
|
|
|
*71 - SPRING DEPTH
HIT-885064.A4
885064
|
-
|
|
|
|
72 - RING WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885072.A0
885072
|
-
|
|
|
|
*72 - RING DEPTH
HIT-885072.A1
885072
|
-
|
|
|
|
73 - SAFETY (B) WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885071.A3
885071
|
-
|
|
|
|
*73 - SAFETY (B) DEPTH
HIT-885071.A4
885071
|
-
|
|
|
|
74 - ADJUSTER WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885073.A3
885073
|
-
|
|
|
|
*74 - ADJUSTER DEPTH
HIT-885073.A4
885073
|
-
|
|
|
|
501 - HEX. BAR WRENCH 4MM
HIT-944458.A84
944458
|
£1.67
|
£2.00
|
|
|
502 - HEX. BAR WRENCH 3MM
HIT-943277.A7
943277
|
£1.67
|
£2.00
|
|
|
503A - PROTECTIVE GLASSES
HIT-875769.A162
875769
|
-
|
|
|
|
504 - PLASTIC CASE
HIT-882331.A1
882331
|
-
|
|
|
|
504A - PLASTIC CASE WITH FUNCTION OF ADJUSTING THE NAILING
HIT-882343.A2
882343
|
-
|
|
|
|
*504A - PLASTIC CASE DEPTH
HIT-882343.A3
882343
|
-
|
|
|
|
505 - LEAFLET WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885076.A2
885076
|
-
|
|
|
|
*505 - LEAFLET DEPTH
HIT-885076.A3
885076
|
-
|
|
|
|
506 - CAUTION TAG WITH FUNCTION OF ADJUSTING THE NAILING
HIT-885075.A1
885075
|
-
|
|
|
|
*506 - CAUTION TAG DEPTH
HIT-885075.A2
885075
|
-
|
|
|
|
601 - SEQUENTIAL FIRE PARTS SET INCLUD.602-604
HIT-882332.A0
882332
|
-
|
|
|
|
602 - TRIGGER
HIT-882329.A1
882329
|
-
|
|
|
|
603 - SPRING
HIT-882330.A1
882330
|
-
|
|
|
|
604 - SPRING PIN D2.5X16
HIT-882299.A4
882299
|
-
|
|
|
