1 - HEX. SOCKET HD. BOLT (W/FLANGE) M6X45
HIT-883509.A3
883509
|
-
|
|
|
|
2 - TOP COVER
HIT-877330.A4
877330
|
£4.78
|
£5.73
|
|
|
3 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M6X25
HIT-883507.A1
883507
|
-
|
|
|
|
4 - EXHAUST COVER
HIT-877324.A1
877324
|
-
|
|
|
|
5 - GASKET (B)
HIT-877325.A3
877325
|
£4.24
|
£5.09
|
|
|
6 - GASKET (F)
HIT-877329.A0
877329
|
£1.67
|
£2.00
|
|
|
7 - EXHAUST PIECE
HIT-877328.A4
877328
|
-
|
|
|
|
8 - GASKET (C)
HIT-877854.A2
877854
|
£1.67
|
£2.00
|
|
|
9 - EXHAUST VALVE (ORANGE)
HIT-884110.A0
884110
|
-
|
|
|
|
9A - EXHAUST VALVE FOR MODEL (Y)
HIT-887774.A1
887774
|
-
|
|
|
|
10 - HEAD CAP AND GASKET SET INCLUD.8
HIT-877307.A0
877307
|
-
|
|
|
|
10A - HEAD CAP AND GASKET SET INCLUD.8 FOR MODEL (Y)
HIT-887769.A0
887769
|
-
|
|
|
|
11 - O-RING (1AP-48)
HIT-877368.A4
877368
|
£1.67
|
£2.00
|
|
|
12A - PISTON ASS'Y INCLUD.11
HIT-885915.A0
885915
|
-
|
|
|
|
13 - O-RING (S-90)
HIT-877316.A0
877316
|
£1.67
|
£2.00
|
|
|
14 - CYLINDER O-RING (I.D 63.1)
HIT-877312.A0
877312
|
£1.67
|
£2.00
|
|
|
15 - CYLINDER PLATE
HIT-877318.A4
877318
|
£26.09
|
£31.31
|
|
|
16 - CYLINDER O-RING (I.D 79.3)
HIT-877313.A1
877313
|
-
|
|
|
|
17 - CYLINDER
HIT-884068.A0
884068
|
-
|
|
|
|
17A - CYLINDER FOR MODEL (Y)
HIT-887762.A1
887762
|
-
|
|
|
|
18 - CYLINDER O-RING (I.D 69.3)
HIT-877314.A0
877314
|
£1.67
|
£2.00
|
|
|
18A - O-RING (S-70) FOR MODEL (Y)
HIT-878863.A4
878863
|
£1.67
|
£2.00
|
|
|
19A - CYLINDER RING
HIT-886483.A10
886483
|
-
|
|
|
|
20 - CYLINDER SPRING
HIT-877321.A0
877321
|
-
|
|
|
|
21 - BASE WASHER
HIT-877322.A4
877322
|
-
|
|
|
|
22 - CYLINDER GUIDE
HIT-877310.A0
877310
|
-
|
|
|
|
22B - CYLINDER GUIDE (B) FOR MODEL (Y)
HIT-887763.A0
887763
|
-
|
|
|
|
23 - GASKET (G)
HIT-877327.A0
877327
|
-
|
|
|
|
24B - WARNING LABEL
HIT-888957.A10
888957
|
-
|
|
|
|
25 - BODY ASS'Y INCLUD.38
HIT-883506.A0
883506
|
-
|
|
|
|
25A - BODY ASS'Y INCLUD.38 FOR MODEL (Y)
HIT-887773.A0
887773
|
-
|
|
|
|
26 - CYLINDER O-RING (I.D 63.9)
HIT-877315.A7
877315
|
-
|
|
|
|
27 - PISTON BUMPER (B)
HIT-883511.A2
883511
|
£19.17
|
£23.00
|
|
|
28 - GASKET (A)
HIT-877334.A4
877334
|
£1.67
|
£2.00
|
|
|
29A - NYLOCK HEX. SOCKET HD. BOLT M6X18
HIT-888245.A0
888245
|
-
|
|
|
|
30 - SPRING WASHER M6 (10 PCS.)
HIT-949455.A25
949455
|
£1.67
|
£2.00
|
|
|
31 - GUARD (A)
HIT-884061.A0
884061
|
-
|
|
|
|
32 - NOSE FOR WITH DEPTH ADJUSTMENT TYPE
HIT-884060.A0
884060
|
-
|
|
|
|
32A - NOSE FOR MODEL (Y)
HIT-887770.A0
887770
|
-
|
|
|
|
33 - NYLOCK HEX. SOCKET HD. BOLT M8X22
HIT-883492.A2
883492
|
-
|
|
|
|
34 - ROLL PIN D3X18 (10 PCS.) FOR WITH DEPTH ADJUSTMENT TYPE
HIT-949518.A5
949518
|
£1.67
|
£2.00
|
|
|
35 - NYLOCK BOLT (W/FLANGE) M8X16
HIT-883505.A2
883505
|
-
|
|
|
|
36 - NYLON NUT M6
HIT-963837.A3
963837
|
£1.67
|
£2.00
|
|
|
37 - HANDLE ARM (B)
HIT-884066.A1
884066
|
-
|
|
|
|
38 - GRIP RUBBER
HIT-000000.A4822
000000
|
-
|
|
|
|
39 - GASKET (D)
HIT-877331.A0
877331
|
£1.67
|
£2.00
|
|
|
40 - CAP
HIT-878311.A0
878311
|
£15.42
|
£18.51
|
|
|
41 - HEX. SOCKET HD. BOLT M5X18 (10 PCS.)
HIT-949658.A4
949658
|
£3.28
|
£3.93
|
|
|
42 - DUST CAP
HIT-872035.A1
872035
|
-
|
|
|
|
44 - GUARD (B)
HIT-884119.A0
884119
|
-
|
|
|
|
45 - ROLL PIN D3X45
HIT-884025.A3
884025
|
-
|
|
|
|
46 - SPRING FOR WITH DEPTH ADJUSTMENT TYPE
HIT-884067.A0
884067
|
-
|
|
|
|
46A - SPRING FOR MODEL (Y)
HIT-887841.A0
887841
|
-
|
|
|
|
47 - PUSHING LEVER (B) FOR WITH DEPTH ADJUSTMENT TYPE
HIT-884063.A0
884063
|
-
|
|
|
|
48A - ADJUSTER FOR WITH DEPTH ADJUSTMENT TYPE
HIT-326799.A3
326799
|
-
|
|
|
|
49 - ADJUSTER SPRING FOR WITH DEPTH ADJUSTMENT TYPE
HIT-880175.A6
880175
|
£1.67
|
£2.00
|
|
|
50 - STEEL BALL D3.175 (10 PCS.) FOR WITH DEPTH ADJUSTMENT TYPE
HIT-959148.A65
959148
|
£1.67
|
£2.00
|
|
|
51A - PUSHING LEVER (A) FOR WITH DEPTH ADJUSTMENT TYPE
HIT-888256.A1
888256
|
-
|
|
|
|
52 - WASHER FOR WITH DEPTH ADJUSTMENT TYPE
HIT-880081.A6
880081
|
-
|
|
|
|
53 - HEX. SOCKET HD. BOLT M6X12 (10 PCS.) FOR WITH DEPTH ADJUSTMENT TYPE
HIT-949657.A10
949657
|
-
|
|
|
|
*53 - HEX. SOCKET HD. BOLT M6X12 (10 PCS.) FOR WITHOUT DEPTH ADJUSTMENT TYPE
HIT-949657.A11
949657
|
-
|
|
|
|
54 - PLUNGER SPRING
HIT-875643.A1
875643
|
£1.67
|
£2.00
|
|
|
55 - O-RING (P-4)
HIT-874436.A10
874436
|
£1.67
|
£2.00
|
|
|
56 - PLUNGER (A)
HIT-884113.A0
884113
|
-
|
|
|
|
57 - VALVE BUSHING
HIT-884111.A0
884111
|
-
|
|
|
|
58 - O-RING (I.D 10.7)
HIT-884112.A0
884112
|
-
|
|
|
|
59 - TRIGGER
HIT-876203.A1
876203
|
£1.67
|
£2.00
|
|
|
60 - O-RING (P-9)
HIT-872645.A9
872645
|
£1.67
|
£2.00
|
|
|
61A - VALVE PACKING
HIT-888151.A2
888151
|
-
|
|
|
|
62 - URETHANE BALL (C) D7.14
HIT-875645.A2
875645
|
£3.70
|
£4.44
|
|
|
63 - O-RING (S-12)
HIT-875638.A7
875638
|
£1.67
|
£2.00
|
|
|
64 - VALVE PLATE
HIT-875644.A6
875644
|
£1.67
|
£2.00
|
|
|
64A - VALVE PLATE FOR MODEL (Y)
HIT-887771.A2
887771
|
-
|
|
|
|
65 - TRIGGER VALVE BUSHING
HIT-877335.A0
877335
|
£14.66
|
£17.59
|
|
|
65A - TRIGGER VALVE BUSHING FOR MODEL (Y)
HIT-887839.A0
887839
|
-
|
|
|
|
66 - TRIGGER PLUNGER
HIT-878121.A8
878121
|
£9.96
|
£11.95
|
|
|
66A - TRIGGER PLUNGER
HIT-000000.A4825
000000
|
-
|
|
|
|
67 - PLUNGER O-RING
HIT-874820.A1
874820
|
£1.67
|
£2.00
|
|
|
67B - O-RING (I.D. 2.8) FOR MODEL (Y)
HIT-890032.A2
890032
|
-
|
|
|
|
68 - ROLL PIN D3X30 (10 PCS.)
HIT-949866.A13
949866
|
£4.33
|
£5.20
|
|
|
69 - VALVE SLEEVE (A)
HIT-884116.A0
884116
|
-
|
|
|
|
70 - O-RING (S-7)
HIT-876316.A2
876316
|
-
|
|
|
|
71 - PLUNGER O-RING
HIT-878723.A0
878723
|
-
|
|
|
|
72 - WASHER M5 (10 PCS.)
HIT-949424.A7
949424
|
£1.67
|
£2.00
|
|
|
73 - PLUNGER (B) SPRING
HIT-884115.A0
884115
|
-
|
|
|
|
74 - PLUNGER (B)
HIT-884114.A0
884114
|
-
|
|
|
|
75 - NAIL FEEDER
HIT-877393Z.A0
877393Z
|
-
|
|
|
|
76 - RIBBON SPRING
HIT-878422.A1
878422
|
-
|
|
|
|
77 - NEEDLE ROLLER
HIT-878418.A0
878418
|
£1.67
|
£2.00
|
|
|
78 - NYLON NUT M4
HIT-876465.A3
876465
|
£1.67
|
£2.00
|
|
|
79 - SPRING WASHER M4 (10 PCS.)
HIT-949453.A12
949453
|
£1.67
|
£2.00
|
|
|
80 - NYLON NUT M5
HIT-877371.A9
877371
|
£1.67
|
£2.00
|
|
|
81A - SPRING WASHER M5
HIT-889083.A1
889083
|
-
|
|
|
|
82 - MAGAZINE
HIT-884065.A0
884065
|
-
|
|
|
|
83 - SLEEVE
HIT-876550.A1
876550
|
-
|
|
|
|
84 - HEX. SOCKET HD. BOLT M5X45 (10 PCS.)
HIT-949824.A0
949824
|
-
|
|
|
|
85 - HEX. SOCKET HD. BOLT M4X15 (10 PCS.)
HIT-949650.A1
949650
|
£2.98
|
£3.57
|
|
|
86 - WASHER
HIT-877402.A0
877402
|
-
|
|
|
|
87 - STOP LEVER
HIT-877396Z.A1
877396Z
|
-
|
|
|
|
88 - COLLAR
HIT-877398.A1
877398
|
£2.89
|
£3.47
|
|
|
89 - STOPPER SPRING
HIT-877397.A0
877397
|
£3.40
|
£4.08
|
|
|
90 - NOSE FOR WITHOUT DEPTH ADJUSTMENT TYPE
HIT-884076.A0
884076
|
-
|
|
|
|
90A - NOSE FOR MODEL (S1)
HIT-887772.A0
887772
|
-
|
|
|
|
91 - SPRING (A) FOR WITHOUT DEPTH ADJUSTMENT TYPE
HIT-884077.A0
884077
|
-
|
|
|
|
92 - PUSHING LEVER FOR WITHOUT DEPTH ADJUSTMENT TYPE
HIT-884074.A0
884074
|
-
|
|
|
|
93 - GUARD FOR WITHOUT DEPTH ADJUSTMENT TYPE
HIT-884075.A0
884075
|
-
|
|
|
|
94 - MAGAZINE ASS'Y INCLUD.36
HIT-885827.A0
885827
|
-
|
|
|
|
95 - LABEL
HIT-887864.A4
887864
|
-
|
|
|
|
96A - VALVE GUARD FOR MODEL (Y)
HIT-887862.A4
887862
|
-
|
|
|
|
97 - PUSHING LEVER (B)
HIT-000000.A4828
000000
|
-
|
|
|
|
98 - PUSHING LEVER (C)
HIT-000000.A4831
000000
|
-
|
|
|
|
99 - PLUNGER SPRING FOR MODEL (Y)
HIT-887724.A2
887724
|
-
|
|
|
|
101 - PLUNGER FOR MODEL (Y)
HIT-887725.A2
887725
|
-
|
|
|
|
102 - VALVE BUSHING
HIT-000000.A4834
000000
|
-
|
|
|
|
103 - TRIGGER SPRING FOR MODEL (Y)
HIT-887727.A2
887727
|
-
|
|
|
|
104 - ROD SPRING FOR MODEL (Y)
HIT-887728.A2
887728
|
-
|
|
|
|
105 - ROD (B) FOR MODEL (Y)
HIT-887729.A2
887729
|
-
|
|
|
|
106 - ROD (A)
HIT-000000.A4836
000000
|
-
|
|
|
|
107 - RATCHET SPRING FOR MODEL (Y)
HIT-886331.A16
886331
|
£1.67
|
£2.00
|
|
|
108 - CHANGE KNOB FOR MODEL (Y)
HIT-887766.A1
887766
|
-
|
|
|
|
109 - ROD (C) FOR MODEL (Y)
HIT-887732.A2
887732
|
-
|
|
|
|
110 - O-RING (I.D 59.6/W2.4) FOR MODEL (Y)
HIT-878376.A6
878376
|
-
|
|
|
|
111 - GUIDE SLEEVE FOR MODEL (Y)
HIT-887767.A0
887767
|
-
|
|
|
|
112 - PIN FOR MODEL (Y)
HIT-887768.A2
887768
|
-
|
|
|
|
113 - O-RING (S3) FOR MODEL (Y)
HIT-881715.A5
881715
|
-
|
|
|
|
504 - PROTECTIVE GLASSES
HIT-875769.A37
875769
|
-
|
|
|
|
505 - CAUTION TAG
HIT-882413.A5
882413
|
-
|
|
|
|
506 - LEAFLET
HIT-882414.A0
882414
|
-
|
|
|
|
601 - GRIP TAPE (A)
HIT-881768.A12
881768
|
-
|
|
|
|
602A - TAPE (2 PCS.)
HIT-888213.A24
888213
|
-
|
|
|
|
603 - PNEUMATIC TOOL LUBRICANT (30CC)
HIT-877153.A24
877153
|
-
|
|
|
|
604 - PNEUMATIC TOOL LUBRICANT (120CC)
HIT-874042.A4
874042
|
-
|
|
|
|
605 - PNEUMATIC TOOL LUBRICANT (1L)
HIT-876212.A3
876212
|
-
|
|
|
|
606 - GREASE (ATTOLUB NO.2) 500G
HIT-317918.A11
317918
|
£37.06
|
£44.47
|
|
|
608 - NOSE CAP
HIT-884080.A1
884080
|
-
|
|
|
