1 - DEFLECTOR
HIT-882270.A1
882270
|
-
|
|
|
|
2 - BOLT M5X20
HIT-882271.A1
882271
|
-
|
|
|
|
3 - CAP
HIT-882272.A1
882272
|
-
|
|
|
|
4 - SEAL
HIT-882273.A0
882273
|
-
|
|
|
|
5 - SPRING
HIT-882274.A2
882274
|
-
|
|
|
|
6 - O-RING (I.D 13.8)
HIT-882275.A0
882275
|
-
|
|
|
|
7 - HD. VALVE PISTON
HIT-882276.A2
882276
|
-
|
|
|
|
8 - O-RING (I.D 31.8)
HIT-882277.A0
882277
|
-
|
|
|
|
9 - O-RING (I.D 23)
HIT-882278.A2
882278
|
-
|
|
|
|
10 - GASKET
HIT-882279.A0
882279
|
-
|
|
|
|
11 - O-RING (I.D 21.7)
HIT-882282.A1
882282
|
-
|
|
|
|
12 - DRIVER UNIT
HIT-885048.A0
885048
|
-
|
|
|
|
13 - O-RING (I.D 43)
HIT-882281.A1
882281
|
-
|
|
|
|
14 - CYLINDER
HIT-882333.A0
882333
|
-
|
|
|
|
15 - CYLINDER RING
HIT-882286.A2
882286
|
-
|
|
|
|
16 - BUMPER
HIT-882287.A0
882287
|
-
|
|
|
|
17 - STEPPED PIN
HIT-882300.A1
882300
|
-
|
|
|
|
18 - WARNING LABEL
HIT-000000.A91
000000
|
-
|
|
|
|
19 - BODY
HIT-885049.A0
885049
|
-
|
|
|
|
20 - JOINT GUIDE
HIT-882288.A1
882288
|
-
|
|
|
|
21 - SAFETY GUIDE
HIT-885065.A4
885065
|
-
|
|
|
|
22 - SPRING
HIT-885064.A0
885064
|
-
|
|
|
|
23 - SAFETY (B)
HIT-885071.A0
885071
|
-
|
|
|
|
24 - RING
HIT-885072.A4
885072
|
-
|
|
|
|
25 - ADJUSTER
HIT-885073.A0
885073
|
-
|
|
|
|
26 - PUSHING LEVER
HIT-885063.A0
885063
|
-
|
|
|
|
27 - NOSE CAP
HIT-885062.A0
885062
|
-
|
|
|
|
28 - LOCK NUT M4
HIT-882316.A1
882316
|
-
|
|
|
|
29 - O-RING (I.D 37)
HIT-882302.A2
882302
|
-
|
|
|
|
30 - END CAP
HIT-882303.A0
882303
|
-
|
|
|
|
31 - DUST COVER
HIT-885050.A4
885050
|
-
|
|
|
|
32 - AIR PLUG
HIT-882304.A2
882304
|
-
|
|
|
|
33 - RING
HIT-882296.A1
882296
|
-
|
|
|
|
34 - SAFETY
HIT-882297.A1
882297
|
-
|
|
|
|
35 - TRIGGER
HIT-882298.A1
882298
|
-
|
|
|
|
36 - SPRING PIN D2.5X16
HIT-882299.A1
882299
|
-
|
|
|
|
37 - SPRING PIN D3X25
HIT-882306.A6
882306
|
-
|
|
|
|
38 - NAME PLATE
HIT-000000.A92
000000
|
-
|
|
|
|
39 - SEAL
HIT-882289.A1
882289
|
-
|
|
|
|
40 - TRIGGER VALVE HEAD
HIT-882290.A1
882290
|
-
|
|
|
|
41 - SPRING
HIT-882291.A1
882291
|
-
|
|
|
|
42 - O-RING (I.D 2.5)
HIT-882293.A1
882293
|
-
|
|
|
|
43 - TRIGGER VALVE STEM
HIT-882292.A1
882292
|
-
|
|
|
|
44 - O-RING (I.D 13)
HIT-882294.A1
882294
|
-
|
|
|
|
45 - TRIGGER VALVE GUIDE
HIT-882295.A1
882295
|
-
|
|
|
|
46 - SPRING
HIT-882307.A0
882307
|
-
|
|
|
|
47 - MOUNTING BRACKET
HIT-885058.A0
885058
|
-
|
|
|
|
48 - LATCH PIN
HIT-885059.A0
885059
|
-
|
|
|
|
49 - BRACKET
HIT-885061.A0
885061
|
-
|
|
|
|
50 - HEX. SOCKET HD. BOLT M4X16
HIT-882314.A1
882314
|
-
|
|
|
|
51 - E-RING D2.5
HIT-885060.A0
885060
|
-
|
|
|
|
52 - BOLT M5X20
HIT-882271.A2
882271
|
-
|
|
|
|
53 - DRIVER GUIDE COVER (B)
HIT-885053.A0
885053
|
-
|
|
|
|
54 - RIBBON SPRING
HIT-885056.A0
885056
|
-
|
|
|
|
55 - SPRING RETAINER
HIT-885057.A0
885057
|
-
|
|
|
|
56 - STAPLE FEEDER
HIT-885055.A0
885055
|
-
|
|
|
|
57 - E-RING D3
HIT-885068.A0
885068
|
-
|
|
|
|
58 - SNAP RING
HIT-885070.A0
885070
|
-
|
|
|
|
59 - DOOR LATCH COVER
HIT-885069.A0
885069
|
-
|
|
|
|
60 - LATCH SPRING
HIT-885066.A0
885066
|
-
|
|
|
|
61 - LOCK BUTTON
HIT-885067.A0
885067
|
-
|
|
|
|
62 - LOCK LEVER
HIT-882338.A1
882338
|
-
|
|
|
|
63 - GUIDE PLATE
HIT-885051.A0
885051
|
-
|
|
|
|
64 - FIXED PIN
HIT-885052.A0
885052
|
-
|
|
|
|
65 - MAGAZINE
HIT-885054.A0
885054
|
-
|
|
|
|
66 - BOLT M4X10
HIT-882366.A1
882366
|
-
|
|
|
|
501 - HEX. BAR WRENCH 3MM
HIT-943277.A12
943277
|
£1.67
|
£2.00
|
|
|
502 - HEX. BAR WRENCH 4MM
HIT-944458.A142
944458
|
£1.67
|
£2.00
|
|
|
503 - PROTECTIVE GLASSES
HIT-875769.A84
875769
|
-
|
|
|
|
504 - CASE
HIT-885074.A0
885074
|
-
|
|
|
|
505 - CAUTION TAG
HIT-885075.A0
885075
|
-
|
|
|
|
506 - LEAFLET
HIT-885076.A4
885076
|
-
|
|
|
|
601 - SEQUENTIAL FIRE PARTS SET INCLUD.602-604
HIT-882332.A2
882332
|
-
|
|
|
|
602 - TRIGGER
HIT-882329.A2
882329
|
-
|
|
|
|
603 - SPRING
HIT-882330.A0
882330
|
-
|
|
|
|
604 - SPRING PIN D2.5X16
HIT-882299.A2
882299
|
-
|
|
|
