1 - PLUG CAP
HIT-6684894.A24
6684894
|
£7.75
|
£9.30
|
|
|
*2 - SPARK PLUG ASS'Y RCJ8Y FOR EUROPE
HIT-6699328.A16
6699328
|
£5.70
|
£6.84
|
|
|
*2 - SPARK PLUG ASS'Y BPM6A FOR USA
HIT-6699317.A26
6699317
|
-
|
|
|
|
3 - SPARK PLUG RUBBER COVER
HIT-6688334.A2
6688334
|
-
|
|
|
|
4 - CYLINDER SET
HIT-6685462.A2
6685462
|
£93.84
|
£112.61
|
|
|
5 - HEX.HOLE BOLT M5X18/S
HIT-6684586.A52
6684586
|
-
|
|
|
|
6 - CYLINDER GASKET
HIT-6685728.A4
6685728
|
-
|
|
|
|
7 - PISTON RING
HIT-6684588.A8
6684588
|
£6.38
|
£7.66
|
|
|
8 - PISTON SET
HIT-6685877.A2
6685877
|
-
|
|
|
|
9 - CIRCLIP
HIT-6685078.A26
6685078
|
-
|
|
|
|
10 - PISTON PIN
HIT-6686016.A4
6686016
|
-
|
|
|
|
11 - CRANK SHAFT COMP.
HIT-6686176.A0
6686176
|
-
|
|
|
|
12 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A47
6684899
|
-
|
|
|
|
13 - CORD 1
HIT-6687840.A4
6687840
|
-
|
|
|
|
14 - HEX. HOLE BOLT M4X18/WS
HIT-6684599.A57
6684599
|
-
|
|
|
|
15 - WASHER T1.6
HIT-6684600.A18
6684600
|
-
|
|
|
|
16 - IGNITION COIL ASS'Y
HIT-6687704.A2
6687704
|
-
|
|
|
|
17 - INSULATOR TUBE
HIT-6688316.A0
6688316
|
-
|
|
|
|
*31 - GEAR SHAFT SHIM 0.10
HIT-6689177.A3
6689177
|
-
|
|
|
|
*31 - GEAR SHAFT SHIM 0.15
HIT-6689178.A32
6689178
|
-
|
|
|
|
*31 - GEAR SHAFT SHIM 0.20
HIT-6684604.A46
6684604
|
-
|
|
|
|
*31 - GEAR SHAFT SHIM 0.30
HIT-6684605.A35
6684605
|
-
|
|
|
|
32 - GROMMET
HIT-6688047.A0
6688047
|
-
|
|
|
|
33 - CRANK CASE ASS'Y
HIT-6601158.A1
6601158
|
-
|
|
|
|
34 - OIL SEAL TB 12227
HIT-6684607.A206
6684607
|
£4.07
|
£4.88
|
|
|
35 - BALL BEARING 6001 C3
HIT-6684608.A0
6684608
|
£5.70
|
£6.84
|
|
|
36 - CRANK CASE GASKET
HIT-6686705.A0
6686705
|
-
|
|
|
|
37 - STUD BOLT 6X22
HIT-6686771.A13
6686771
|
-
|
|
|
|
38 - HEX. SOCKET HD. BOLT M5X30 S
HIT-6684786.A36
6684786
|
£1.67
|
£2.00
|
|
|
39 - HEX. HOLE BOLT 5X45
HIT-6695055.A5
6695055
|
£1.67
|
£2.00
|
|
|
40 - SPRING WASHER 5
HIT-6684834.A39
6684834
|
£1.67
|
£2.00
|
|
|
41 - MAGNETO ROTOR COMP.
HIT-6687418.A2
6687418
|
-
|
|
|
|
42 - S.WASHER 8
HIT-6684971.A24
6684971
|
-
|
|
|
|
43 - BOLT WASHER M8
HIT-6684611.A61
6684611
|
-
|
|
|
|
44 - HEX. NUT M8
HIT-6684612.A58
6684612
|
-
|
|
|
|
51 - INTAKE MANIFOLD GASKET
HIT-6689874.A2
6689874
|
-
|
|
|
|
52 - INSULATOR SET 1
HIT-6689937.A2
6689937
|
-
|
|
|
|
53 - HEX. HOLE BOLT M5X25WS
HIT-6695515.A39
6695515
|
£1.67
|
£2.00
|
|
|
54 - CARBURETOR GASKET
HIT-6689828.A2
6689828
|
-
|
|
|
|
55 - O-RING P-15
HIT-6698966.A33
6698966
|
£1.67
|
£2.00
|
|
|
56 - CLEANER BODY COMP.
HIT-6690119.A20
6690119
|
£8.95
|
£10.74
|
|
|
57 - COLLAR 7.5
HIT-6690804.A13
6690804
|
£1.67
|
£2.00
|
|
|
58 - CHOKE VALVE
HIT-6691261.A2
6691261
|
-
|
|
|
|
59 - WAVE WASHER 8
HIT-6684658.A34
6684658
|
£1.67
|
£2.00
|
|
|
60 - BLOW OVER CHECK BOARD
HIT-6690843.A19
6690843
|
£1.67
|
£2.00
|
|
|
61 - S.WASHER 5
HIT-6684662.A51
6684662
|
£1.67
|
£2.00
|
|
|
62 - SCREW M5X60
HIT-6684660.A14
6684660
|
-
|
|
|
|
63 - CLEANER SPONGE
HIT-6690364.A22
6690364
|
£1.67
|
£2.00
|
|
|
64 - CLEANER COVER ASS'Y
HIT-6690415.A2
6690415
|
£5.70
|
£6.84
|
|
|
65 - SPECIAL SCREW
HIT-6689737.A5
6689737
|
-
|
|
|
|
66 - CARBURETOR SET WYL139A
HIT-6690461.A3
6690461
|
-
|
|
|
|
67 - SHIELD TUBE FOR EUROPE
HIT-6688174.A10
6688174
|
-
|
|
|
|
67A - SHIELD TUBE ASS'Y FOR USA
HIT-6601195.A2
6601195
|
-
|
|
|
|
68 - CLIP D6
HIT-6685198.A82
6685198
|
-
|
|
|
|
69A - PUMP FILTER BODY COMP
HIT-66A3864.A99
66A3864
|
-
|
|
|
|
*70A - TANK FOR EUROPE
HIT-6699738.A0
6699738
|
-
|
|
|
|
*70A - TANK F T FOR USA
HIT-6699335.A0
6699335
|
-
|
|
|
|
71 - TANK CAP ASS'Y FOR EUROPE
HIT-6685049.A6
6685049
|
£9.94
|
£11.93
|
|
|
72 - TANK CAP D ASS'Y FOR USA
HIT-6691748.A11
6691748
|
£6.04
|
£7.25
|
|
|
73 - COLLAR 5.8
HIT-6692244.A15
6692244
|
£1.67
|
£2.00
|
|
|
74 - TANK CAP CHAIN FOR EUROPE
HIT-6684625.A54
6684625
|
-
|
|
|
|
75 - HEX. HOLE BOLT 5X18PS
HIT-6695505.A15
6695505
|
-
|
|
|
|
76 - SWIVEL CAP SINCE A086531
HIT-6691337.A12
6691337
|
£1.67
|
£2.00
|
|
|
77 - PRIMING PUMP COMP.
HIT-6685139.A139
6685139
|
£10.67
|
£12.80
|
|
|
78 - FUEL PIPE 2.5X4X80
HIT-6692347.A14
6692347
|
£1.67
|
£2.00
|
|
|
79 - FUEL PIPE 2.5X4X70
HIT-6692346.A9
6692346
|
£1.67
|
£2.00
|
|
|
80 - RETURN GROMMET
HIT-6697846.A123
6697846
|
£2.08
|
£2.50
|
|
|
91 - MUFFLER PROTECTOR
HIT-6692772.A4
6692772
|
-
|
|
|
|
92 - MUFFLER SET FOR EUROPE
HIT-6692455.A1
6692455
|
-
|
|
|
|
93 - MUFFLER ASS'Y FOR USA
HIT-6601160.A1
6601160
|
-
|
|
|
|
94 - BOLT WASHER 6 FOR EUROPE
HIT-6684639.A88
6684639
|
£1.67
|
£2.00
|
|
|
94A - CLUTCH WASHER (B) FOR USA
HIT-6696547.A9
6696547
|
£1.67
|
£2.00
|
|
|
95 - HEX. HOLE SCREW 6X55
HIT-6695086.A2
6695086
|
-
|
|
|
|
96 - TAIL PIPE FOR EUROPE
HIT-6692646.A1
6692646
|
-
|
|
|
|
97 - FAN CASE COMP.
HIT-6686957.A0
6686957
|
£38.90
|
£46.68
|
|
|
98 - RECOIL SPRING
HIT-6684675.A78
6684675
|
£8.82
|
£10.58
|
|
|
99 - STARTER ROPE REEL
HIT-6693066.A9
6693066
|
£5.17
|
£6.20
|
|
|
100 - SET SCREW
HIT-6693633.A4
6693633
|
£1.67
|
£2.00
|
|
|
101 - STARTER PULLEY ASS'Y
HIT-6693405.A12
6693405
|
£7.75
|
£9.30
|
|
|
102 - PRIMARY CORD GROMMET
HIT-6688049.A10
6688049
|
-
|
|
|
|
103 - ROPE
HIT-6693168.A38
6693168
|
£2.82
|
£3.39
|
|
|
104 - STARTER HANDLE
HIT-6693237.A20
6693237
|
£4.55
|
£5.46
|
|
|
105 - HEX. HOLE BOLT 4X15/PS
HIT-6684682.A33
6684682
|
£1.67
|
£2.00
|
|
|
106 - MUFFLER COVER A COMP.
HIT-6692718.A2
6692718
|
-
|
|
|
|
107 - MUFFLER ARRESTOR FOR EUROPE
HIT-6692696.A5
6692696
|
-
|
|
|
|
108 - WASHER 5
HIT-6684661.A48
6684661
|
£1.67
|
£2.00
|
|
|
109 - SCREW 4X8PS FOR EUROPE
HIT-6695471.A0
6695471
|
-
|
|
|
|
110 - SCREW 5X8/S
HIT-6695332.A5
6695332
|
-
|
|
|
|
111 - CLUTCH
HIT-6688494.A11
6688494
|
£14.82
|
£17.78
|
|
|
112 - TAPPING SCREW 4.5X10
HIT-6695104.A2
6695104
|
-
|
|
|
|
113 - BOLT 4X12PS
HIT-6695441.A12
6695441
|
-
|
|
|
|
114 - STARTER PAWL SPRING
HIT-6684684.A120
6684684
|
£3.29
|
£3.95
|
|
|
115 - STARTER PAWL
HIT-6693319.A10
6693319
|
£3.29
|
£3.95
|
|
|
121 - THROTTLE SET SCREW
HIT-6684698.A73
6684698
|
-
|
|
|
|
122 - SWIVEL
HIT-6684697.A0
6684697
|
-
|
|
|
|
123 - STOP RING
HIT-6684696.A219
6684696
|
-
|
|
|
|
124 - O-RING
HIT-6684695.A0
6684695
|
£1.67
|
£2.00
|
|
|
125 - MAIN JET #35
HIT-6691873.A2
6691873
|
-
|
|
|
|
126 - PUMP GASKET
HIT-6691457.A87
6691457
|
£8.48
|
£10.18
|
|
|
127 - PUMP DIAPHRAGM
HIT-6684693.A204
6684693
|
£5.70
|
£6.84
|
|
|
128 - INLET SCREEN
HIT-6684700.A241
6684700
|
-
|
|
|
|
129 - PUMP BODY COMP.
HIT-6691435.A2
6691435
|
-
|
|
|
|
130 - DIAPHRAGM PACKING-METERING
HIT-6685220.A100
6685220
|
£2.81
|
£3.37
|
|
|
131 - METERING DIAPHRAGM COMP.
HIT-6690830.A63
6690830
|
£14.58
|
£17.50
|
|
|
132 - DIAPHRAGM COVER-METERING
HIT-6685222.A79
6685222
|
£5.70
|
£6.84
|
|
|
133 - SET SCREW
HIT-6691312.A50
6691312
|
-
|
|
|
|
141 - NO LONGER AVAILABLE
HIT-6688672.A0
6688672
|
-
|
|
|
|
142 - RETAINING RING C-TYPE D26
HIT-6695294.A14
6695294
|
-
|
|
|
|
143 - BALL BEARING #6000 1
HIT-6695524.A47
6695524
|
-
|
|
|
|
144 - BALL BEARING #6000Z 1
HIT-6695526.A17
6695526
|
-
|
|
|
|
145 - CLUTCH HOUSING COMP.
HIT-6688571.A0
6688571
|
-
|
|
|
|
146 - GEAR 1 FOR EUROPE
HIT-6688968.A1
6688968
|
-
|
|
|
|
147 - GEAR 2 FOR EUROPE
HIT-6688978.A0
6688978
|
£29.02
|
£34.82
|
|
|
148 - CAM-ROD COMP.
HIT-6686810.A0
6686810
|
£31.02
|
£37.23
|
|
|
149 - CAM SHAFT
HIT-6686791.A4
6686791
|
-
|
|
|
|
150 - GEAR CASE GASKET
HIT-6688910.A4
6688910
|
-
|
|
|
|
151 - BALL BEARING #608 2
HIT-6684738.A0
6684738
|
-
|
|
|
|
152 - GREASE SEAL A
HIT-6686655.A4
6686655
|
-
|
|
|
|
153 - COLLAR
HIT-6688293.A4
6688293
|
-
|
|
|
|
154 - HEX. HOLE BOLT M5X25/S
HIT-6684709.A10
6684709
|
£1.67
|
£2.00
|
|
|
155 - GREASE NIPPLE COMP.
HIT-6688643.A30
6688643
|
£1.67
|
£2.00
|
|
|
156 - HEX. HOLE BOLT 6X18/S
HIT-6695495.A4
6695495
|
-
|
|
|
|
157 - HEX HOLE BUTTON SCREW 6X15
HIT-6695079.A7
6695079
|
£1.67
|
£2.00
|
|
|
158 - SMALL WASHER 6
HIT-6695183.A23
6695183
|
-
|
|
|
|
159 - FIXING PLATE
HIT-6686467.A4
6686467
|
-
|
|
|
|
160 - SUPPORT PLATE
HIT-6690758.A4
6690758
|
-
|
|
|
|
161 - HEX. SOCKET HD. BOLT M4X10
HIT-6685093.A0
6685093
|
£1.67
|
£2.00
|
|
|
162 - SPRING NUT 6
HIT-6695475.A26
6695475
|
-
|
|
|
|
164 - SPRING NUT 6
HIT-6695475.A27
6695475
|
-
|
|
|
|
165 - GEAR 1 TILL G005200 FOR USA
HIT-6688967.A2
6688967
|
-
|
|
|
|
165A - GEAR 1 SINCE G005201 FOR USA
HIT-6688968.A0
6688968
|
-
|
|
|
|
166A - GEAR 2 SINCE G005201 FOR USA
HIT-6688978.A1
6688978
|
£29.02
|
£34.82
|
|
|
181 - CUTTER GUIDE TILL A047350
HIT-6687142.A1
6687142
|
-
|
|
|
|
181A - CUTTER GUIDE 830L M6 SINCE A047351
HIT-6687151.A0
6687151
|
-
|
|
|
|
182 - PROTECTION PLATE TILL B028600 FOR EUROPE
HIT-6687288.A4
6687288
|
-
|
|
|
|
183 - HEX. HOLE SCREW 6X25
HIT-6695074.A0
6695074
|
-
|
|
|
|
184 - SPECIAL WASHER B SINCE B028600 FOR EUROPE
HIT-6684822.A5
6684822
|
£1.67
|
£2.00
|
|
|
185 - SPECIAL WASHER B FOR USA
HIT-6684822.A6
6684822
|
£1.67
|
£2.00
|
|
|
186 - CUTTER B 852L
HIT-6687113.A2
6687113
|
-
|
|
|
|
187 - CUTTER A
HIT-6687091.A2
6687091
|
-
|
|
|
|
188 - WASHER 7 BLACK
HIT-6687187.A12
6687187
|
£1.67
|
£2.00
|
|
|
189 - CUTTER FIXING BOLT A TILL A047350
HIT-6687160.A2
6687160
|
£1.67
|
£2.00
|
|
|
189A - FIXING BOLT A M6 SINCE A047351
HIT-6687158.A20
6687158
|
£1.67
|
£2.00
|
|
|
190 - BLADE HOLDER TILL B028600 FOR EUROPE
HIT-6687181.A0
6687181
|
-
|
|
|
|
190A - BLADE HOLDER SINCE B028601 FOR EUROPE
HIT-6687180.A7
6687180
|
-
|
|
|
|
191 - BLADE HOLDER FOR USA
HIT-6687180.A8
6687180
|
-
|
|
|
|
192 - CUTTER FIXING BOLT B TILL A047350
HIT-6687167.A2
6687167
|
£1.67
|
£2.00
|
|
|
192A - FIXING BOLT B M6 SINCE A047351
HIT-6687168.A0
6687168
|
£1.67
|
£2.00
|
|
|
193 - HANDLE B COMP.
HIT-6686311.A5
6686311
|
£24.92
|
£29.91
|
|
|
194 - HANDLE GRIP
HIT-6684708.A21
6684708
|
£3.56
|
£4.27
|
|
|
195 - CUTTER FIXING NUT TILL A047350 FOR EUROPE
HIT-6687156.A1
6687156
|
£1.67
|
£2.00
|
|
|
195A - FLANGE NUT 6 SINCE A047351 FOR EUROPE
HIT-6695170.A79
6695170
|
£1.67
|
£2.00
|
|
|
196A - FLANGE NUT 6 SINCE A302051 FOR USA
HIT-6695170.A78
6695170
|
£1.67
|
£2.00
|
|
|
197 - BOLT WASHER 6
HIT-6684639.A187
6684639
|
£1.67
|
£2.00
|
|
|
198 - S.WASHER 6
HIT-6695219.A86
6695219
|
£1.67
|
£2.00
|
|
|
199 - BOLT WASHER 6 TILL A047350
HIT-6684639.A188
6684639
|
£1.67
|
£2.00
|
|
|
200 - CUTTER COVER 1
HIT-6687308.A3
6687308
|
-
|
|
|
|
201 - GATHERING PLATE 1
HIT-6689539.A5
6689539
|
£32.99
|
£39.59
|
|
|
211 - HANDLE GRIP A
HIT-6686338.A7
6686338
|
-
|
|
|
|
212 - HANDLE GRIP B
HIT-6686349.A4
6686349
|
-
|
|
|
|
213 - THROTTLE LEVER
HIT-6688229.A1
6688229
|
£4.12
|
£4.94
|
|
|
214 - SAFETY LEVER
HIT-6688238.A6
6688238
|
-
|
|
|
|
215 - THROTTLE LEVER SPRING
HIT-6686414.A5
6686414
|
-
|
|
|
|
216 - STOP SWITCH COMP.
HIT-6687766.A0
6687766
|
-
|
|
|
|
217 - STOP BUTTON MARK
HIT-6694585.A2
6694585
|
-
|
|
|
|
218 - CAP
HIT-6693002.A4
6693002
|
£1.67
|
£2.00
|
|
|
219 - SCREW 4X30/WS
HIT-6695412.A1
6695412
|
-
|
|
|
|
220 - SCREW 4X25/WS
HIT-6695411.A8
6695411
|
-
|
|
|
|
221 - HANDLE GRIP ASS'Y
HIT-6686356.A1
6686356
|
-
|
|
|
|
222 - HANDLE A COMP.
HIT-6686275.A1
6686275
|
-
|
|
|
|
223 - THROTTLE WIRE 270+49
HIT-6693877.A5
6693877
|
£6.61
|
£7.93
|
|
|
224 - PROTECTION TUBE 10X150L
HIT-6687558.A5
6687558
|
-
|
|
|
|
225 - SCREW 4X16WS
HIT-6695404.A7
6695404
|
-
|
|
|
|
226 - NYLON LOCK NUT 4
HIT-6695163.A13
6695163
|
-
|
|
|
|
227 - SCREW 3X10
HIT-6684913.A11
6684913
|
£1.67
|
£2.00
|
|
|
228 - BUTTON STOP
HIT-6688366.A26
6688366
|
£1.67
|
£2.00
|
|
|
229 - CORD CLAMP
HIT-6688015.A16
6688015
|
-
|
|
|
|
230 - HEX.HOLE BOLT M5X12/S
HIT-6684667.A63
6684667
|
£1.67
|
£2.00
|
|
|
231 - HANDLE BRACKET
HIT-6686370.A0
6686370
|
-
|
|
|
|
232 - HANDLE DUMPER RUBBER
HIT-6686396.A4
6686396
|
-
|
|
|
|
501 - COMBI BOX SPANNER 10/19MM
HIT-6685257.A21
6685257
|
-
|
|
|
|
502 - HEX. BAR WRENCH 4MM
HIT-6684813.A90
6684813
|
-
|
|
|
|
601 - NAME PLATE HTS2530PF
HIT-6694125.A0
6694125
|
-
|
|
|
