Hitachi / Hikoki HTD-2522PF Engine Hedge Trimmer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki HTD-2522PF Engine Hedge Trimmer

	Ex VAT	Inc VAT
1 - PLUG CAP HIT-6684894.A3 6684894	£7.75	£9.30
2 - SPARK PLUG ASS'Y BPM6A HIT-6699317.A0 6699317	-
3 - SPARK PLUG RUBBER COVER HIT-6688334.A0 6688334	-
4 - CYLINDER SET HIT-6685462.A4 6685462	£93.84	£112.61
5 - HEX.HOLE BOLT M5X18/S HIT-6684586.A103 6684586	-
6 - CYLINDER GASKET HIT-6685728.A0 6685728	-
7 - PISTON RING HIT-6684588.A22 6684588	£6.38	£7.66
8 - PISTON SET HIT-6685877.A1 6685877	-
9 - CIRCLIP HIT-6685078.A9 6685078	-
10 - PISTON PIN HIT-6686016.A11 6686016	-
11 - CRANK SHAFT COMP. HIT-6686176.A3 6686176	-
12 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A76 6684899	-
13 - CORD 1 HIT-6687840.A1 6687840	-
14 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A18 6684599	-
15 - WASHER T1.6 HIT-6684600.A55 6684600	-
16 - IGNITION COIL ASS'Y HIT-6687704.A1 6687704	-
17 - INSULATOR TUBE HIT-6688316.A4 6688316	-
*31 - GEAR SHAFT SHIM 0.10 HIT-6689177.A23 6689177	-
*31 - GEAR SHAFT SHIM 0.15 HIT-6689178.A12 6689178	-
*31 - GEAR SHAFT SHIM 0.20 HIT-6684604.A74 6684604	-
*31 - GEAR SHAFT SHIM 0.30 HIT-6684605.A7 6684605	-
32 - GROMMET HIT-6688047.A4 6688047	-
33 - CRANK CASE ASS'Y HIT-6686529.A2 6686529	-
34 - OIL SEAL TB 12227 HIT-6684607.A39 6684607	£4.07	£4.88
35 - BALL BEARING 6001 C3 HIT-6684608.A158 6684608	£5.70	£6.84
36 - CRANK CASE GASKET HIT-6686705.A4 6686705	-
37 - STUD BOLT 6X22 HIT-6686771.A14 6686771	-
38 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A88 6684786	£1.67	£2.00
39 - HEX. HOLE BOLT 5X45 HIT-6695055.A11 6695055	£1.67	£2.00
40 - SPRING WASHER 5 HIT-6684834.A10 6684834	£1.67	£2.00
41 - MAGNETO ROTOR COMP. HIT-6687418.A1 6687418	-
42 - S.WASHER 8 HIT-6684971.A38 6684971	-
43 - BOLT WASHER M8 HIT-6684611.A113 6684611	-
44 - HEX. NUT M8 HIT-6684612.A2 6684612	-
51 - INTAKE MANIFOLD GASKET HIT-6689874.A0 6689874	-
52 - INSULATOR SET 1 HIT-6689937.A4 6689937	-
53 - HEX. HOLE BOLT M5X25WS HIT-6695515.A0 6695515	£1.67	£2.00
54 - CARBURETOR GASKET HIT-6689828.A1 6689828	-
55 - O-RING P-15 HIT-6698966.A3 6698966	£1.67	£2.00
56 - CLEANER BODY COMP. HIT-6690119.A7 6690119	£8.95	£10.74
57 - COLLAR 7.5 HIT-6690804.A22 6690804	£1.67	£2.00
58 - CHOKE VALVE HIT-6691261.A0 6691261	-
59 - WAVE WASHER 8 HIT-6684658.A11 6684658	£1.67	£2.00
60 - BLOW OVER CHECK BOARD HIT-6690843.A38 6690843	£1.67	£2.00
61 - S.WASHER 5 HIT-6684662.A15 6684662	£1.67	£2.00
62 - SCREW M5X60 HIT-6684660.A1 6684660	-
63 - CLEANER SPONGE HIT-6690364.A9 6690364	£1.67	£2.00
64 - CLEANER COVER ASS'Y HIT-6690415.A7 6690415	£5.70	£6.84
65 - SPECIAL SCREW HIT-6689737.A32 6689737	-
66 - CARBURETOR SET WYL139A HIT-6690461.A0 6690461	-
67 - SHIELD TUBE HIT-6688174.A3 6688174	-
68 - CLIP 1 HIT-6684619.A50 6684619	£1.67	£2.00
69A - PUMP FILTER BODY COMP HIT-66A3864.A43 66A3864	-
70 - TANK TILL D014150 HIT-6699738.A2 6699738	-
70A - TANK F T SINCE D014151 HIT-6699335.A1 6699335	-
71 - TANK CAP D ASS'Y HIT-6691748.A20 6691748	£6.04	£7.25
72 - COLLAR 5.8 HIT-6692244.A74 6692244	£1.67	£2.00
73 - HEX. HOLE BOLT 5X18PS HIT-6695505.A30 6695505	-
76 - SWIVEL CAP SINCE A098701 HIT-6691337.A81 6691337	£1.67	£2.00
77 - PRIMING PUMP COMP. HIT-6685139.A28 6685139	£10.67	£12.80
78 - FUEL PIPE 2.5X4X80 HIT-6692347.A11 6692347	£1.67	£2.00
79 - FUEL PIPE 2.5X4X70 HIT-6692346.A10 6692346	£1.67	£2.00
80 - RETURN GROMMET HIT-6697846.A77 6697846	£2.08	£2.50
91 - MUFFLER PROTECTOR HIT-6692772.A1 6692772	-
92A - MUFFLER ASS'Y HIT-6601160.A2 6601160	-
94A - CLUTCH WASHER (B) HIT-6696547.A39 6696547	£1.67	£2.00
95 - HEX. HOLE SCREW 6X55 HIT-6695086.A3 6695086	-
97 - FAN CASE COMP. HIT-6686957.A4 6686957	£38.90	£46.68
98 - RECOIL SPRING HIT-6684675.A147 6684675	£8.82	£10.58
99 - STARTER ROPE REEL HIT-6693066.A16 6693066	£5.17	£6.20
100 - SET SCREW HIT-6693633.A39 6693633	£1.67	£2.00
101 - STARTER PULLEY ASS'Y HIT-6693405.A1 6693405	£7.75	£9.30
102 - PRIMARY CORD GROMMET HIT-6688049.A0 6688049	-
103 - ROPE HIT-6693168.A7 6693168	£2.82	£3.39
104 - STARTER HANDLE HIT-6693237.A1 6693237	£4.55	£5.46
105 - HEX. HOLE BOLT 4X15/PS HIT-6684682.A54 6684682	£1.67	£2.00
106 - MUFFLER COVER A COMP. HIT-6692718.A3 6692718	-
108 - WASHER 5 HIT-6684661.A98 6684661	£1.67	£2.00
110 - SCREW 5X8/S HIT-6695332.A2 6695332	-
111 - CLUTCH HIT-6688494.A10 6688494	£14.82	£17.78
112 - TAPPING SCREW 4.5X10 HIT-6695104.A1 6695104	-
113 - BOLT 4X12PS HIT-6695441.A10 6695441	-
114 - STARTER PAWL SPRING HIT-6684684.A112 6684684	£3.29	£3.95
115 - STARTER PAWL HIT-6693319.A8 6693319	£3.29	£3.95
121 - THROTTLE SET SCREW HIT-6684698.A64 6684698	-
122 - SWIVEL HIT-6684697.A11 6684697	-
123 - STOP RING HIT-6684696.A208 6684696	-
124 - O-RING HIT-6684695.A9 6684695	£1.67	£2.00
125 - MAIN JET #35 HIT-6691873.A1 6691873	-
126 - PUMP GASKET HIT-6691457.A88 6691457	£8.48	£10.18
127 - PUMP DIAPHRAGM HIT-6684693.A195 6684693	£5.70	£6.84
128 - INLET SCREEN HIT-6684700.A237 6684700	-
129 - PUMP BODY COMP. HIT-6691435.A1 6691435	-
130 - DIAPHRAGM PACKING-METERING HIT-6685220.A98 6685220	£2.81	£3.37
131 - METERING DIAPHRAGM COMP. HIT-6690830.A60 6690830	£14.58	£17.50
132 - DIAPHRAGM COVER-METERING HIT-6685222.A81 6685222	£5.70	£6.84
133 - SET SCREW HIT-6691312.A46 6691312	-
151 - GEAR CASE COMP. TILL C230890 HIT-6688671.A0 6688671	-
151A - NO LONGER AVAILABLE HIT-6688828.A0 6688828	-
152 - STOP RING C-15 1 HIT-6695285.A53 6695285	£1.67	£2.00
153 - BALL BEARING #6002Z 2 HIT-6695538.A14 6695538	£12.57	£15.08
154 - CLUTCH DRUM COMP. HIT-6688570.A17 6688570	£22.90	£27.48
155 - GEAR SHAFT HIT-6688960.A1 6688960	£2.81	£3.37
156 - GUIDE PLATE HIT-6686612.A5 6686612	£1.67	£2.00
157 - CAM ROD HIT-6686811.A6 6686811	£15.71	£18.85
158 - GEAR 2 HIT-6688974.A0 6688974	£55.81	£66.97
159 - GEAR CASE GASKET HIT-6688909.A7 6688909	£1.67	£2.00
160 - NO LONGER AVAILABLE HIT-6692100.A2 6692100	-
161 - CUTTER GUIDE 1 HIT-6687135.A0 6687135	£27.59	£33.11
161A - CUTTER GUIDE 625.5L M6 SINCE B001501 HIT-6687137.A0 6687137	£27.59	£33.11
162 - HEX HOLE FLUSH SCREW 6X16 TILL C230890 HIT-6695073.A14 6695073	£1.67	£2.00
162A - HEX. HOLE FLUSH BOLT 6X25 SINCE C230891 HIT-6695075.A19 6695075	£1.67	£2.00
163 - CUTTER A (591.5L) HIT-6687084.A2 6687084	£42.70	£51.24
164 - GREASE SEAL A HIT-6686654.A7 6686654	£1.67	£2.00
165 - WASHER 7 BLACK HIT-6687187.A15 6687187	£1.67	£2.00
166 - CUTTER FIXING BOLT A TILL B001500 HIT-6687160.A3 6687160	£1.67	£2.00
166A - FIXING BOLT A M6 SINCE B001501 HIT-6687158.A17 6687158	£1.67	£2.00
*167A - FLANGE NUT 6 TILL C230890 HIT-6695170.A73 6695170	£1.67	£2.00
*167A - FLANGE NUT 6 SINCE C230891 HIT-6695170.A74 6695170	£1.67	£2.00
168 - HEX. HOLE BOLT 4X10S TILL C230890 HIT-6695484.A2 6695484	£1.67	£2.00
168A - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 SINCE C230891 HIT-6684595.A5 6684595	£1.67	£2.00
169 - GREASE NIPPLE COMP. HIT-6688643.A25 6688643	£1.67	£2.00
170 - HEX. HOLE BOLT 6X14 TILL A091200 HIT-6695058.A0 6695058	-
170A - HEX. HOLE BOLT 6X18/S SINCE A091201 HIT-6695495.A2 6695495	-
171 - SUPPORT PLATE SINCE C230891 HIT-6690764.A3 6690764	£4.72	£5.66
172 - SPECIAL WASHER B SINCE C230891 HIT-6684822.A11 6684822	£1.67	£2.00
173 - LOCK NUT 6 UPS-P SINCE C230891 HIT-6695175.A49 6695175	£1.67	£2.00
174 - BOLT WASHER 6 SINCE C230891 HIT-6684639.A174 6684639	£1.67	£2.00
175 - GEAR CASE B SINCE C230891 HIT-6688844.A2 6688844	-
176 - CUTTER COVER HIT-6687301.A0 6687301	-
177 - SPRING NUT 6 HIT-6695475.A25 6695475	-
178 - HEX. HOLE BOLT 4X10S SINCE C230891 HIT-6695484.A1 6695484	£1.67	£2.00
179 - PROTECTION PLATE TILL B001500 HIT-6687285.A0 6687285	-
180 - S.WASHER 6 TILL A091200 HIT-6695219.A85 6695219	£1.67	£2.00
181 - CORD CLAMP COMP. HIT-6688008.A7 6688008	-
*182 - BOLT WASHER 6 SINCE W177951 HIT-6684639.A175 6684639	£1.67	£2.00
*182 - BOLT WASHER 6 TILL B001500 HIT-6684639.A176 6684639	£1.67	£2.00
201 - HANDLE A TILL C023890 HIT-6686270.A0 6686270	-
202 - STOP SWITCH COMP. TILL C023890 HIT-6687764.A0 6687764	-
203 - BUTTON STOP TILL C023890 HIT-6688366.A23 6688366	£1.67	£2.00
204 - SCREW 3X10 TILL C023890 HIT-6684913.A9 6684913	£1.67	£2.00
205 - THROTTLE LEVER TILL C023890 HIT-6688226.A1 6688226	£4.12	£4.94
206 - SAFETY LEVER TILL C023890 HIT-6688235.A0 6688235	£1.67	£2.00
207 - THROTTLE LEVER SPRING TILL C023890 HIT-6688243.A1 6688243	-
208 - HANDLE B TILL C023890 HIT-6686307.A0 6686307	-
209 - CAP TILL C023890 HIT-6693002.A3 6693002	£1.67	£2.00
210 - TAPPING SCREW 4X18 TILL C023890 HIT-6695246.A0 6695246	-
211 - THROTTLE WIRE COMP. 1 HIT-6693912.A0 6693912	£6.52	£7.82
212 - STOP BUTTON MARK TILL C023890 HIT-6694585.A1 6694585	-
213 - SCREW 5X45S TILL C023890 HIT-6695350.A10 6695350	-
214 - NYLON NUT M5 TILL C023890 HIT-6696987.A6 6696987	-
216 - SMALL WASHER 5 TILL C023890 HIT-6684864.A63 6684864	-
217 - HANDLE TILL C023890 HIT-6688097.A1 6688097	-
218 - BRAKE SHAFT WASHER TILL C023890 HIT-6689680.A17 6689680	£1.67	£2.00
219 - SPRING WASHER 5 TILL C023890 HIT-6684834.A7 6684834	£1.67	£2.00
220 - HEX. HOLE BOLT 5X40 TILL C023890 HIT-6695054.A5 6695054	£1.67	£2.00
221 - PROTECTION TUBE 1 HIT-6687522.A0 6687522	-
222 - COLLAR 5.8 TILL C023890 HIT-6692244.A73 6692244	£1.67	£2.00
231 - HANDLE B SINCE C023891 HIT-6686314.A0 6686314	£9.67	£11.60
232 - HANDLE A SINCE C023891 HIT-6686279.A1 6686279	£9.67	£11.60
233 - THROTTLE LEVER SINCE C023891 HIT-6688230.A1 6688230	-
234 - SAFETY LEVER OR SINCE C023891 HIT-6688240.A0 6688240	£1.67	£2.00
235 - THROTTLE LEVER SPRING SINCE C023891 HIT-6688244.A0 6688244	£3.51	£4.21
236 - STOP SWITCH COMP. SINCE C023891 HIT-6687769.A0 6687769	-
237 - LOCK LEVER SINCE C023891 HIT-6688246.A1 6688246	-
238 - SPRING SINCE C023891 HIT-6688279.A1 6688279	-
239 - BOLT WASHER M4 SINCE C023891 HIT-6685070.A22 6685070	£1.67	£2.00
240 - TAPPING SCREW D4X10 SINCE C023891 HIT-6685161.A51 6685161	£1.67	£2.00
241 - TAPPING SCREW D4.5X16 SINCE C023891 HIT-6684636.A3 6684636	£1.67	£2.00
242 - THROTTLE WIRE COMP SINCE C023891 HIT-6693993.A0 6693993	-
243 - BUTTON STOP SINCE C023891 HIT-6688366.A22 6688366	£1.67	£2.00
244 - SCREW 3X10 SINCE C023891 HIT-6684913.A8 6684913	£1.67	£2.00
245 - STOP BUTTON MARK SINCE C023891 HIT-6694588.A21 6694588	£2.98	£3.57
246 - CRANK CASE PACKING SINCE C023891 HIT-6696539.A3 6696539	£1.67	£2.00
247 - HANDLE SINCE C023891 HIT-6688097.A2 6688097	-
248 - BRAKE SHAFT WASHER SINCE C023891 HIT-6689680.A16 6689680	£1.67	£2.00
249 - SPRING WASHER 5 SINCE C023891 HIT-6684834.A6 6684834	£1.67	£2.00
250 - HEX. HOLE BOLT 5X40 SINCE C023891 HIT-6695054.A4 6695054	£1.67	£2.00
251 - PROTECTION TUBE 130L SINCE C023891 HIT-6687521.A1 6687521	£1.67	£2.00
501 - HEX. BAR WRENCH 4MM HIT-6684813.A82 6684813	-
502 - COMBI. BOX SPANNER 10X19 1 HIT-6685997.A4 6685997	-
601 - NAME PLATE HTD2522PF HIT-6694122.A0 6694122	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki HTD-2522PF Engine Hedge Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki HTD-2522PF Engine Hedge Trimmer Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki HTD-2522PF Engine Hedge Trimmer Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
