Hitachi / Hikoki GFN1664K Gas Finish Nailer Spare Parts

An exploded diagram and spare parts listing for the Hitachi / Hikoki GFN1664K Gas Finish Nailer

	Ex VAT	Inc VAT
1A - FILTER COVER B#9R192230 HIT-886664.A2 886664	£1.67	£2.00
2 - FILTER MESH B#9R192231 HIT-886344.A1 886344	£14.48	£17.38
3 - HEX. SOCKET HD. BOLT (W/FLANGE) M5X10 B#9R192232 HIT-886347.A4 886347	£1.67	£2.00
4A - TOP COVER B#9R192353 HIT-887389.A1 887389	-
5 - SPARK PLUG (A) B#9R192234 HIT-885333.A3 885333	£4.33	£5.20
6 - NYLOCK HEX. SOCKET HD. BOLT M4X12 B#9R192235 HIT-880630.A3 880630	£1.67	£2.00
7A - CYLINDER HEAD B#9R192236 HIT-886661.A5 886661	£25.60	£30.72
8 - NUT M3 (10 PCS.) B#9R192237 HIT-949553.A1 949553	£1.67	£2.00
9 - SPRING WASHER M3 (10 PCS.) B#9R192238 HIT-887376.A0 887376	-
10 - WASHER M3 (10 PCS.) B#9R192239 HIT-949422.A8 949422	£1.67	£2.00
11 - FAN B#9R192240 HIT-886309.A5 886309	£4.88	£5.85
12 - RUBBER PLATE B#9R192241 HIT-886568.A1 886568	£1.67	£2.00
13 - HEX. SOCKET HD. BOLT M4X16 (10 PCS.) B#9R192242 HIT-949754.A16 949754	£2.98	£3.57
14 - CHAMBER HEAD B#9R192243 HIT-886295.A4 886295	£11.83	£14.20
15 - GASKET B#9R192244 HIT-886296.A2 886296	£1.67	£2.00
16 - CHAMBER B#9R192245 HIT-886297.A5 886297	£15.78	£18.93
17 - PISTON RING (B) B#9R192246 HIT-886312.A1 886312	£3.23	£3.88
18 - RETAINING RING FOR D40 HOLE B#9R192247 HIT-886298.A2 886298	£1.67	£2.00
19A - MOTOR ASS'Y B#9R192254 INCLUD.22 HIT-887446.A6 887446	£111.00	£133.20
20 - PACKING B#9R192248 HIT-886315.A6 886315	£1.67	£2.00
21 - ADAPTER B#9R192249 HIT-886313.A9 886313	£3.51	£4.21
22 - HEX. SOCKET SET SCREW M4X5 B#9R192250 HIT-886314.A2 886314	£1.67	£2.00
23 - SHAFT RUBBER WASHER B#9R192251 HIT-886567.A6 886567	£1.67	£2.00
24A - SHAFT COVER B#9R192252 HIT-886663.A0 886663	£3.04	£3.65
25 - PISTON RING (A) SOLD SINGLY HIT-886286.A0 886286	£6.38	£7.66
26 - PISTON B#9R192149 HIT-886291.A1 886291	£29.63	£35.56
27 - PISTON BUMPER B#9R192257 HIT-886289.A3 886289	£3.04	£3.65
*28 - PRODUCT LABEL (GFN1664K) B#189793 FOR USA HIT-887412.A0 887412	-
*28 - PRODUCT LABEL (GFN1664K) B#FT71695-16 FOR EU HIT-887639.A0 887639	-
29A - HOUSING B#9R192162 HIT-887447.A0 887447	-
30 - PIN B#9R192167 HIT-886310.A2 886310	£1.67	£2.00
31 - BLADE GUIDE B#9R192173 HIT-886302.A2 886302	£23.10	£27.72
32 - SEAL LOCK HEX. SOCKET HD. BOLT M4X12 B#9R192262 HIT-886311.A9 886311	£1.67	£2.00
33 - LOCK PLATE B#9R192174 HIT-886304.A2 886304	£1.67	£2.00
34 - LOCK LEVER COVER B#9R192204 HIT-886570.A4 886570	£2.91	£3.49
35 - ROLL PIN D3X16 (10 PCS.) B#9R192261 HIT-887459.A3 887459	-
36 - LOCK LEVER B#9R192213 HIT-887453.A0 887453	£5.29	£6.35
37 - ROLL PIN D3X16 (10 PCS.) B#9R192261 HIT-887459.A2 887459	-
38 - LOCK SPRING B#9R192233 HIT-886305.A0 886305	£1.67	£2.00
39 - GUIDE PLATE B#9R192256 HIT-886303.A0 886303	£16.66	£19.99
40 - HEX. SHOULDER BOLT M5 B#9R192253 HIT-886566.A0 886566	£1.67	£2.00
41 - SEAL LOCK HEX. SOCKET HD. BOLT M4X8 B#9R192274 HIT-886307.A7 886307	£1.67	£2.00
42 - CONICAL SPRING H8 B#9R192275 HIT-886319.A2 886319	£1.67	£2.00
43 - BUFFER COVER B#9R192276 HIT-886287.A4 886287	£6.45	£7.74
44 - MUFFLER B#9R192277 HIT-886288.A3 886288	£2.91	£3.49
45 - REED VALVE B#9R192278 HIT-886290.A1 886290	£4.31	£5.17
46 - BUFFER PLATE B#9R192279 HIT-886293.A7 886293	£2.91	£3.49
47 - O-RING B#9R192280 HIT-886294.A0 886294	£1.67	£2.00
48 - MESH B#9R192281 HIT-886292.A0 886292	£4.40	£5.28
49 - TAPPING SCREW (W/FLANGE) D4X16 (BLACK) B#9R192267 HIT-305812.A79 305812	£1.67	£2.00
50A - HANDLE (B) B#9R192357 HIT-887390.A0 887390	-
51 - HEX. SHOULDER BOLT M4X32 B#9R192269 HIT-886565.A7 886565	£1.67	£2.00
52A - CYLINDER B#9R192258 HIT-886284.A1 886284	£38.60	£46.32
53 - CHAMBER STOP RUBBER B#9R192270 HIT-886285.A4 886285	£1.67	£2.00
54 - NYLON NUT M5 B#9R192271 HIT-877371.A62 877371	£1.67	£2.00
55 - PROTECTOR (A) B#9R192359 HIT-887391.A1 887391	-
56 - CELL PIN B#9R192282 HIT-886332.A7 886332	£1.67	£2.00
57 - PIPE RUBBER B#9R192283 HIT-886333.A0 886333	£1.67	£2.00
58 - ACTUATOR B#9R192284 HIT-886326.A1 886326	£3.21	£3.85
59 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK) B#9R192273 HIT-302086.A46 302086	£1.67	£2.00
*60A - BATTERY EBM 315 (USA CAN) B#9B12070R FOR USA HIT-332413.A0 332413	-
*60A - BATTERY EBM 315 (EU) B#9B12070R-EU FOR EU HIT-332414.A1 332414	-
61 - SUPPORT (B) B#9R192286 HIT-886316.A0 886316	£1.67	£2.00
62 - INTERNAL WIRE (A) B#9R192287 HIT-887635.A0 887635	£76.75	£92.10
63 - WASHER M4 (10 PCS.) B#9R192288 HIT-949423.A0 949423	£1.67	£2.00
64 - MACHINE SCREW M4X10 (10 PCS.) B#9R192289 HIT-887460.A2 887460	-
65 - LOCK NUT M4 (BLACK) B#9R192290 HIT-886330.A7 886330	£1.67	£2.00
66 - O-RING (S-12) B#9R192331 HIT-875638.A16 875638	£1.67	£2.00
67 - HOOK B#9R192312 HIT-886345.A7 886345	£4.86	£5.83
68A - WASHER B#9R192313 HIT-887036.A2 887036	£1.67	£2.00
69A - TRUSS HD. SCREW M4X25 (BLACK) B#9R192314 HIT-887034.A2 887034	£1.67	£2.00
70A - HANDLE (A) B#9R192358 HIT-887392.A0 887392	-
71 - TERMINAL SUPPORT B#9R192292 HIT-326316.A2 326316	£1.67	£2.00
72 - TRIGGER STOPPER B#9R192298 HIT-886552.A5 886552	£4.84	£5.81
73 - TRIGGER B#9R192294 HIT-886327.A7 886327	£1.67	£2.00
74 - TRIGGER SPRING B#9R192293 HIT-886328.A0 886328	£1.67	£2.00
75 - CORD COVER PLATE B#9R192296 HIT-886324.A7 886324	£1.67	£2.00
76 - CHAMBER SPRING B#9R192297 HIT-886301.A0 886301	£1.67	£2.00
77 - SEAL LOCK HEX. SOCKET HD. BOLT M4X10 B#9R192299 HIT-886308.A0 886308	£1.67	£2.00
78 - PIN D3X20 (10 PCS.) B#9R192295 HIT-949890.A2 949890	£2.78	£3.34
79 - PUSHING LEVER ARM B#9R192300 HIT-886299.A3 886299	£9.47	£11.36
80A - PUSHING LEVER PIECE B#9R192301 HIT-887035.A5 887035	£4.10	£4.92
81 - O-RING (S-8) B#9R192302 HIT-992912.A1 992912	£1.67	£2.00
82 - ADJUSTER B#9R192375 HIT-887377.A0 887377	-
83 - RATCHET SPRING B#9R192304 HIT-886331.A0 886331	£1.67	£2.00
84 - PUSHING LEVER (A) B#9R192260 HIT-886337.A2 886337	£5.80	£6.96
85 - MAG. WARNING LABEL B#FT71695-12 FOR EU HIT-887634.A0 887634	-
*86 - CLEAN LABEL B#189787 FOR USA HIT-887408.A0 887408	-
*86 - MAG. BATTERY LABEL B#FT71695-11 FOR EU HIT-887633.A0 887633	-
*87 - WARNING LABEL B#189786 FOR USA HIT-887407.A0 887407	-
*87 - WARNING LABEL B#FT71695-10 FOR EU HIT-887636.A1 887636	-
88 - MAGAZINE COVER B#9R192263 HIT-886318.A2 886318	£8.85	£10.62
89 - BOLT WASHER M5 (BLACK)(10 PCS.) B#9R192310 HIT-887454.A1 887454	-
90 - MACHINE SCREW M5X15 (BLACK) B#9R192311 HIT-885997.A1 885997	£1.67	£2.00
91 - ROLL PIN D3X16 (10 PCS.) B#9R192261 HIT-887459.A4 887459	-
92 - RIBBON SPRING B#9R192316 HIT-881755.A7 881755	£4.62	£5.55
93 - NAIL FEEDER (B) B#9R192363 HIT-887378.A0 887378	-
94 - PRISM B#9R192321 HIT-886322.A0 886322	£1.67	£2.00
95 - CONTROLLER B#9R192322 HIT-886320.A7 886320	£64.50	£77.40
96 - TAPPING SCREW (W/FLANGE) D4X12 (BLACK) B#9R192323 HIT-325083.A3 325083	£1.67	£2.00
97 - NAIL RAIL B#9R192324 HIT-886341.A2 886341	£9.47	£11.36
98 - STOPPER SPRING (C) B#9R192325 HIT-886604.A1 886604	£1.67	£2.00
99 - NAIL FEEDER (A) B#9R192326 HIT-886339.A2 886339	£3.21	£3.85
100 - ROLL PIN D2.5X26 B#9R192327 HIT-886605.A3 886605	£1.67	£2.00
101 - MAGAZINE B#9R192328 HIT-887379.A0 887379	-
102A - CYLINDER ASS'Y (A) B#9R192329 INCLUD.41-48 HIT-886550.A0 886550	£51.93	£62.32
104 - SHAFT WASHER B#9R192352 HIT-887411.A0 887411	-
105 - CYLINDER HEAD ASS'Y B#9R192330 INCLUD.7A HIT-887451.A0 887451	£181.88	£218.26
106 - TAPE HIT-887452.A0 887452	-
*501 - CHARGER (MODEL UC 3SML) USA B#9B12071R FOR USA HIT-887311.A1 887311	-
*501 - CHARGER (MODEL UC 3SML) EU B#9B12071R-E FOR EU HIT-887312.A0 887312	-
*501 - CHARGER (MODEL UC 3SML) UK B#9B12071R-U FOR UK HIT-887313.A1 887313	-
503 - HEX. BAR WRENCH 3MM B#106167 HIT-887462.A3 887462	-
504 - HEX. BAR WRENCH 4MM B#166038 HIT-887463.A0 887463	-
505 - NOSE CAP (A) B#9R192333 HIT-886349.A1 886349	£2.49	£2.99
506 - CASE B#9R192364 HIT-887393.A1 887393	-
*507 - B#9R192226 FOR USA HIT-887487.A0 887487	-
*507 - LUBRICANT OILER (B) B#SB-20CL FOR EU HIT-887487.A1 887487	-
*509 - CLEANING GUIDE B#9R192674-1RA FOR USA HIT-887413.A0 887413	-
*509 - CLEANING GUIDE B#9R192674-2RB FOR USA HIT-887413.A1 887413	-
*509 - MANUAL ILLUSTRATIONS B#FT71695-47 FOR EU HIT-887638.A0 887638	-
