1 - SPARK PLUG CAP ASS'Y
HIT-6687468.A83
6687468
|
£3.64
|
£4.37
|
|
|
*2 - SPARK PLUG ASS'Y BPMR7A FOR EUROPE
HIT-6699320.A34
6699320
|
-
|
|
|
|
*2 - SPARK PLUG ASS'Y BPM7A FOR SAUTH AMERICA
HIT-6699318.A4
6699318
|
-
|
|
|
|
*2 - SPARK PLUG ASS'Y CJ6Y FOR USA
HIT-6699323.A8
6699323
|
-
|
|
|
|
3 - CYLINDER SET
HIT-6685465.A3
6685465
|
£87.92
|
£105.51
|
|
|
4 - CYLINDER PACKING
HIT-6685732.A3
6685732
|
£1.67
|
£2.00
|
|
|
5 - HEX. HOLE BOLT 5X20S
HIT-6695491.A14
6695491
|
£1.67
|
£2.00
|
|
|
6 - DECOMP. VALVE GASKET
HIT-6685860.A10
6685860
|
£1.67
|
£2.00
|
|
|
7 - DECOMPRESSION COMP.
HIT-6685589.A7
6685589
|
£37.61
|
£45.13
|
|
|
8 - DECOMP. COVER
HIT-6685800.A0
6685800
|
£1.67
|
£2.00
|
|
|
9 - DUST COVER
HIT-6690808.A7
6690808
|
-
|
|
|
|
10 - PISTON PIN CIRCLIP
HIT-6686026.A6
6686026
|
£1.67
|
£2.00
|
|
|
11 - PISTON RING 2
HIT-6686125.A1
6686125
|
£8.45
|
£10.14
|
|
|
12 - PISTON SET 1
HIT-6685884.A2
6685884
|
£29.28
|
£35.14
|
|
|
13 - PISTON PIN 10X30
HIT-6686007.A29
6686007
|
£3.52
|
£4.23
|
|
|
14 - PISTON PIN COLLAR
HIT-6685993.A6
6685993
|
£5.70
|
£6.84
|
|
|
15 - NEEDLE BEARING 1
HIT-6695602.A8
6695602
|
-
|
|
|
|
16 - CRANK SHAFT COMP.
HIT-6686183.A3
6686183
|
-
|
|
|
|
17 - WOODRUFF KEY 3X13X4.5
HIT-6684899.A66
6684899
|
-
|
|
|
|
20 - CYLINDER SET FOR USA
HIT-6685467.A0
6685467
|
-
|
|
|
|
21 - CYLINDER PK 1.0T FOR USA
HIT-6685733.A0
6685733
|
-
|
|
|
|
31 - SIDE DUMPER
HIT-6688164.A5
6688164
|
-
|
|
|
|
32 - HEX HOLE SCREW 5X35
HIT-6695076.A8
6695076
|
-
|
|
|
|
33 - OIL PIPE A
HIT-6691219.A0
6691219
|
-
|
|
|
|
34 - CLIP 7
HIT-6692312.A4
6692312
|
-
|
|
|
|
35 - OIL FILTER BODY COMP.
HIT-6697651.A7
6697651
|
-
|
|
|
|
*36 - SHIM 0.1
HIT-6686474.A4
6686474
|
-
|
|
|
|
*36 - SHIM S T0.2
HIT-6685098.A15
6685098
|
-
|
|
|
|
*36 - SHIM S T0.3
HIT-6685099.A19
6685099
|
-
|
|
|
|
*36 - SHIM 0.4
HIT-6686475.A22
6686475
|
-
|
|
|
|
37 - CRANK CASE ASS'Y
HIT-6686542.A4
6686542
|
-
|
|
|
|
38 - KNOCK PIN 4X12
HIT-6695521.A24
6695521
|
-
|
|
|
|
39 - OIL SEAL ISMX12325.5
HIT-6695633.A6
6695633
|
£6.18
|
£7.41
|
|
|
40 - STOP RING C-32 1
HIT-6695295.A41
6695295
|
£1.67
|
£2.00
|
|
|
41 - BALL BEARING 6201 A2C3
HIT-6685096.A20
6685096
|
-
|
|
|
|
42 - BALL BEARING 6201 A2C3
HIT-6685096.A21
6685096
|
-
|
|
|
|
43 - STOP RING C-32 1
HIT-6695295.A42
6695295
|
£1.67
|
£2.00
|
|
|
44 - OIL SEAL ISMX12325.5
HIT-6695633.A7
6695633
|
£6.18
|
£7.41
|
|
|
45 - CRANKCASE GASKET
HIT-6686710.A10
6686710
|
£1.67
|
£2.00
|
|
|
46 - AIR VENT VALVE (B)
HIT-6685173.A5
6685173
|
-
|
|
|
|
47 - AIR VENT COVER
HIT-6691399.A9
6691399
|
£4.72
|
£5.66
|
|
|
48 - HEX.HOLE BOLT M5X18/S
HIT-6684586.A86
6684586
|
-
|
|
|
|
49 - HEX. SOCKET HD. BOLT M5X30 S
HIT-6684786.A87
6684786
|
£1.67
|
£2.00
|
|
|
50 - AIR DEFLECTOR
HIT-6687207.A7
6687207
|
-
|
|
|
|
51 - BOLT WASHER M8
HIT-6684611.A97
6684611
|
-
|
|
|
|
52 - HEX. NUT M8
HIT-6684612.A15
6684612
|
-
|
|
|
|
53 - MAGNETO ROTOR ASS'Y
HIT-6687395.A3
6687395
|
£52.30
|
£62.76
|
|
|
54 - SPECIAL WASHER
HIT-6687942.A7
6687942
|
-
|
|
|
|
55 - PAWL SPRING
HIT-6693348.A6
6693348
|
-
|
|
|
|
56 - STARTER PAWL
HIT-6693304.A4
6693304
|
£3.89
|
£4.67
|
|
|
57 - STEP BOLT
HIT-6693366.A18
6693366
|
-
|
|
|
|
58 - HANDLE DAMPER SINCE V181601
HIT-6688107.A7
6688107
|
-
|
|
|
|
72 - CLUTCH SET ASS'Y 1
HIT-6695959.A1
6695959
|
-
|
|
|
|
72A - CLUTCH ASS'Y 1
HIT-6688489.A7
6688489
|
-
|
|
|
|
73 - CLUTCH HOUSING COMP.7T
HIT-6689009.A5
6689009
|
£35.35
|
£42.42
|
|
|
74 - NEEDLE BEARING KT111410G
HIT-6695606.A5
6695606
|
£14.19
|
£17.03
|
|
|
75 - OIL PUMP COVER
HIT-6686755.A5
6686755
|
-
|
|
|
|
76 - SCREW GEAR COMP.
HIT-6686640.A2
6686640
|
£38.15
|
£45.78
|
|
|
77 - OIL PUMP COMP.
HIT-6687331.A7
6687331
|
-
|
|
|
|
78 - PINION WASHER 1T
HIT-6686452.A7
6686452
|
£3.38
|
£4.06
|
|
|
79 - SMALL SCREW 4X12WS
HIT-6695403.A2
6695403
|
-
|
|
|
|
80 - HIGH TENSION SCREW 4X18WS
HIT-6695407.A54
6695407
|
-
|
|
|
|
81 - RELEASE VALVE
HIT-6686661.A6
6686661
|
£1.67
|
£2.00
|
|
|
82 - O-RING S-3
HIT-6695659.A8
6695659
|
£1.67
|
£2.00
|
|
|
83 - O-RING P-5
HIT-6695661.A4
6695661
|
£1.67
|
£2.00
|
|
|
84 - CLUTCH SPRING SINCE V181601
HIT-6689426.A3
6689426
|
£2.98
|
£3.57
|
|
|
85 - CLUTCH SHOE SINCE V181601
HIT-6689493.A9
6689493
|
-
|
|
|
|
86 - CLUTCH BOSS SINCE V181601
HIT-6689497.A2
6689497
|
-
|
|
|
|
87 - CLUTCH WASHER B SINCE V181601
HIT-6689642.A0
6689642
|
-
|
|
|
|
101 - AIRCLEANER ELEMENT B COMP.
HIT-6690335.A5
6690335
|
£9.60
|
£11.52
|
|
|
102 - AIRCLEANER ELEMENT A COMP.
HIT-6690325.A4
6690325
|
£5.97
|
£7.16
|
|
|
103 - AIRCLEANER BASE COMP.
HIT-6690198.A5
6690198
|
£7.75
|
£9.30
|
|
|
104 - HEX. HOLE BOLT 5X45
HIT-6695055.A14
6695055
|
£1.67
|
£2.00
|
|
|
105 - S.WASHER 5
HIT-6684662.A4
6684662
|
£1.67
|
£2.00
|
|
|
106 - SMALL WASHER 5
HIT-6684864.A52
6684864
|
-
|
|
|
|
107 - HEX. HOLE BOLT 5X15 WS
HIT-6695512.A15
6695512
|
-
|
|
|
|
109 - IDLE ADJUSTMENT SCREW TILL H126320
HIT-6687993.A9
6687993
|
-
|
|
|
|
109A - IDLE ADJUST SCREW SINCE H126321
HIT-6685298.A31
6685298
|
£1.67
|
£2.00
|
|
|
110 - SPECIAL WASHER
HIT-6687943.A9
6687943
|
£1.67
|
£2.00
|
|
|
111 - CARB. INSULATOR 1
HIT-6690004.A5
6690004
|
-
|
|
|
|
112 - INSULATOR COMP.
HIT-6689941.A4
6689941
|
-
|
|
|
|
113 - INLET MANIFOLD COMP.
HIT-6689789.A7
6689789
|
-
|
|
|
|
114 - INLET MANIFOLD GASKET
HIT-6689876.A5
6689876
|
-
|
|
|
|
115 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12
HIT-6684595.A14
6684595
|
£1.67
|
£2.00
|
|
|
116 - IDLE ADJUST SPRING
HIT-6690766.A2
6690766
|
-
|
|
|
|
117 - INLET MANIFOLD SPACER SINCE B014101
HIT-6685202.A13
6685202
|
-
|
|
|
|
118 - MUFFLER GASKET
HIT-6692737.A7
6692737
|
-
|
|
|
|
119 - MUFFLER SET
HIT-6692459.A3
6692459
|
-
|
|
|
|
120 - MUFFLER STAY
HIT-6692942.A6
6692942
|
-
|
|
|
|
121 - HEX. HOLE BOLT M5X16/S
HIT-6684903.A6
6684903
|
-
|
|
|
|
122 - HEX. HOLE BOLT 4X10
HIT-6695036.A11
6695036
|
-
|
|
|
|
123 - MUFFLER SET 1
HIT-6692460.A1
6692460
|
-
|
|
|
|
124 - TAIL PIPE FOR USA
HIT-6692647.A1
6692647
|
-
|
|
|
|
125 - MUFFLER STEEL NET FOR USA
HIT-6692694.A1
6692694
|
-
|
|
|
|
126 - HEX. HOLE BOLT 4X10 FOR USA
HIT-6695036.A12
6695036
|
-
|
|
|
|
141 - RECOIL STARTER ASS'Y
HIT-6692916.A3
6692916
|
£30.63
|
£36.76
|
|
|
142 - SET SCREW
HIT-6693633.A31
6693633
|
£1.67
|
£2.00
|
|
|
143 - STARTER ROPE REEL
HIT-6693059.A6
6693059
|
£13.29
|
£15.95
|
|
|
144 - RECOIL SPRING CASE
HIT-6693096.A8
6693096
|
£11.90
|
£14.28
|
|
|
145 - FAN CASE COMP.
HIT-6686963.A5
6686963
|
-
|
|
|
|
146 - PLATE
HIT-6685189.A41
6685189
|
-
|
|
|
|
147 - STARTER HANDLE
HIT-6693230.A2
6693230
|
-
|
|
|
|
148 - STARTER ROPE
HIT-6693158.A10
6693158
|
£4.26
|
£5.11
|
|
|
150 - HEX. HOLE BOLT 5X15 WS
HIT-6695512.A16
6695512
|
-
|
|
|
|
201 - CARBURETOR ASS'Y WT-497A
HIT-6690606.A2
6690606
|
£93.28
|
£111.94
|
|
|
202 - INLET SCREEN
HIT-6684700.A205
6684700
|
-
|
|
|
|
203 - PUMP BODY
HIT-6691416.A8
6691416
|
£16.36
|
£19.63
|
|
|
204 - SCREW
HIT-6685210.A24
6685210
|
-
|
|
|
|
205 - PUMP GASKET
HIT-6685212.A22
6685212
|
£3.29
|
£3.95
|
|
|
206 - PUMP DIAPHRAGM
HIT-6685213.A33
6685213
|
£8.44
|
£10.13
|
|
|
207 - NEEDLE VALVE
HIT-6685215.A33
6685215
|
£6.79
|
£8.15
|
|
|
208 - DIAPHRAGM PACKING-METERING
HIT-6685220.A116
6685220
|
£2.81
|
£3.37
|
|
|
209 - METERING DIAPHRAGM COMP.
HIT-6690827.A17
6690827
|
£14.02
|
£16.83
|
|
|
210 - DIAPHRAGM COVER-METERING
HIT-6685222.A60
6685222
|
£5.70
|
£6.84
|
|
|
211 - VALVE SPRING
HIT-6690872.A12
6690872
|
-
|
|
|
|
212 - HINGE PIN SET SCREW
HIT-6685218.A46
6685218
|
-
|
|
|
|
213 - HINGE PIN
HIT-6685219.A27
6685219
|
-
|
|
|
|
214 - CONTROL LEVER
HIT-6685217.A22
6685217
|
-
|
|
|
|
215 - SET SCREW
HIT-6685223.A46
6685223
|
-
|
|
|
|
216 - CARBURETOR ASS'Y WT484 FOR SAUTH AMERICA
HIT-6690605.A1
6690605
|
-
|
|
|
|
217 - HIGH/LOW ADJUST SPRING FOR SAUTH AMERICA
HIT-6692048.A5
6692048
|
-
|
|
|
|
218 - LOW ADJUSTMENT SCREW FOR SAUTH AMERICA
HIT-6690719.A1
6690719
|
-
|
|
|
|
219 - HIGH ADJUSTMENT SPRING FOR SAUTH AMERICA
HIT-6690897.A15
6690897
|
-
|
|
|
|
220 - HIGH ADJUST SCREW FOR SAUTH AMERICA
HIT-6690696.A0
6690696
|
-
|
|
|
|
231 - AIRCLEANER KNOB COMP.
HIT-6687793.A2
6687793
|
£5.92
|
£7.11
|
|
|
232 - CLEANER COVER SET 1
HIT-6690404.A9
6690404
|
£8.88
|
£10.66
|
|
|
233 - IDLE GROMMET
HIT-6687974.A6
6687974
|
-
|
|
|
|
234 - ADJUSTER CAP
HIT-6687954.A4
6687954
|
-
|
|
|
|
235 - CYLINDER COVER
HIT-6685681.A2
6685681
|
-
|
|
|
|
236 - CYLINDR SUPPORT RUBBER
HIT-6691825.A6
6691825
|
-
|
|
|
|
237 - CLEANER PACKING
HIT-6690056.A4
6690056
|
-
|
|
|
|
238 - HEX. HOLE BOLT 5X15 WS
HIT-6695512.A17
6695512
|
-
|
|
|
|
239 - INSULATOR TUBE 1
HIT-6688315.A4
6688315
|
-
|
|
|
|
240 - CHOKE BUTTON COMP.
HIT-6692507.A3
6692507
|
-
|
|
|
|
241 - CHOKE ROD HOLDING RUBBER
HIT-6692587.A17
6692587
|
-
|
|
|
|
242 - STOP SWITCH COMP.
HIT-6687506.A4
6687506
|
£7.12
|
£8.54
|
|
|
243 - CONTROL PLATE
HIT-6691192.A8
6691192
|
-
|
|
|
|
244 - SHUTTER PLATE
HIT-6687952.A8
6687952
|
-
|
|
|
|
245 - STOP CORD 1
HIT-6687929.A9
6687929
|
-
|
|
|
|
246 - HEX.HOLE BOLT M5X12/S
HIT-6684667.A71
6684667
|
£1.67
|
£2.00
|
|
|
247 - BUMPER SPIKE
HIT-6690705.A5
6690705
|
£5.59
|
£6.71
|
|
|
248 - CHAIN CATCHER
HIT-6687163.A9
6687163
|
-
|
|
|
|
249 - SPECIAL BOLT
HIT-6689734.A3
6689734
|
-
|
|
|
|
250 - FUEL PIPE
HIT-6685154.A16
6685154
|
-
|
|
|
|
251 - DAMPER COMP.
HIT-6688113.A8
6688113
|
£5.70
|
£6.84
|
|
|
252 - TAPPING SCREW 5X35
HIT-6695107.A18
6695107
|
£1.67
|
£2.00
|
|
|
253 - COLLAR 15
HIT-6692248.A7
6692248
|
£1.67
|
£2.00
|
|
|
254 - OIL TANK CAP ASS'Y
HIT-6697756.A11
6697756
|
£5.87
|
£7.04
|
|
|
255 - OIL TANK CAP PACKING
HIT-6697888.A16
6697888
|
£1.67
|
£2.00
|
|
|
256 - IGNITION COIL COMP.
HIT-6687695.A8
6687695
|
£73.85
|
£88.62
|
|
|
257 - HEX. HOLE BOLT M4X18/WS
HIT-6684599.A6
6684599
|
-
|
|
|
|
271 - NUT M4
HIT-6685069.A14
6685069
|
-
|
|
|
|
272 - CHAIN BAR CLAMP NUT
HIT-6687105.A8
6687105
|
£1.67
|
£2.00
|
|
|
273 - TAP SCREW 4X14 P
HIT-6695280.A48
6695280
|
£1.67
|
£2.00
|
|
|
274 - FRONT HAND GUARD
HIT-6693454.A9
6693454
|
£7.57
|
£9.08
|
|
|
275 - MACHINE SCREW (W/SP. WASHER) M4X12
HIT-6685068.A30
6685068
|
-
|
|
|
|
276 - HAND GUARD WEIGHT
HIT-6693481.A1
6693481
|
-
|
|
|
|
277 - SIDE CASE ASS'Y
HIT-6686095.A1
6686095
|
£92.02
|
£110.42
|
|
|
278 - TAPPING SCREW D4X10
HIT-6685161.A42
6685161
|
£1.67
|
£2.00
|
|
|
279 - BRAKE BAND HOLDER
HIT-6689715.A1
6689715
|
-
|
|
|
|
280 - SIDE COVER COMP.
HIT-6686043.A4
6686043
|
-
|
|
|
|
281 - CLEANER FIXING COLLAR
HIT-6690805.A34
6690805
|
£2.69
|
£3.23
|
|
|
282 - BRAKE SUPPORT FITTING COMP.
HIT-6689777.A6
6689777
|
-
|
|
|
|
283 - BRAKE LEVER SPRING
HIT-6689781.A9
6689781
|
-
|
|
|
|
284 - BRAKE LINK COMP.
HIT-6685121.A7
6685121
|
£18.38
|
£22.05
|
|
|
285 - BRAKE SPRING
HIT-6689700.A6
6689700
|
£3.56
|
£4.27
|
|
|
286 - BRAKE BAND
HIT-6689724.A5
6689724
|
£15.38
|
£18.45
|
|
|
287 - NEEDLE ROLLER 3X9.8
HIT-6685141.A15
6685141
|
-
|
|
|
|
288 - BRAKE LINK COVER
HIT-6689709.A2
6689709
|
-
|
|
|
|
289 - TAPPING SCREW D4X10
HIT-6685161.A6
6685161
|
£1.67
|
£2.00
|
|
|
290 - GUIDE PLATE B
HIT-6697598.A10
6697598
|
£3.56
|
£4.27
|
|
|
291 - SCREW 4X8
HIT-6694861.A3
6694861
|
-
|
|
|
|
292 - GUIDE PLATE A
HIT-6697597.A2
6697597
|
£3.56
|
£4.27
|
|
|
293 - CHAIN BAR STUD BOLT
HIT-6686804.A11
6686804
|
-
|
|
|
|
294 - CHAIN TENSION BOLT ASSY EXCEPT FOR ASIA
HIT-6687067.A6
6687067
|
£5.70
|
£6.84
|
|
|
295 - CHAIN TENSION BOLT ASSY FOR ASIA
HIT-6687073.A0
6687073
|
£4.26
|
£5.11
|
|
|
311 - TAPPING SCREW 5X18
HIT-6695106.A5
6695106
|
-
|
|
|
|
312 - REAR HANDLE GRIP
HIT-6688212.A9
6688212
|
-
|
|
|
|
313 - TRIGGER LOCKOUT BLACK
HIT-6688352.A2
6688352
|
-
|
|
|
|
314 - THROTTLE ROD COMP.
HIT-6690967.A11
6690967
|
-
|
|
|
|
315 - THROTTLE LEVER
HIT-6686381.A0
6686381
|
-
|
|
|
|
316 - THROTTLE LEVER SPRING
HIT-6686412.A10
6686412
|
-
|
|
|
|
317 - REAR HANDLE ASS'Y
HIT-6685663.A0
6685663
|
£50.06
|
£60.07
|
|
|
318 - SPRING PIN 5X25
HIT-6685282.A14
6685282
|
£1.67
|
£2.00
|
|
|
319 - NO LONGER AVAILABLE
HIT-6688079.A10
6688079
|
-
|
|
|
|
320 - TAPPING SCREW 5X18
HIT-6695106.A4
6695106
|
-
|
|
|
|
*321 - AIR VENT VALVE ASS'Y EXCEPT FOR USA
HIT-6692172.A1
6692172
|
-
|
|
|
|
*321 - AIR VENT VALVE ASS'Y FOR USA
HIT-6692171.A16
6692171
|
-
|
|
|
|
322 - AIRVENT PIPE
HIT-6691391.A3
6691391
|
-
|
|
|
|
323 - FRONT DAMPER
HIT-6688241.A0
6688241
|
-
|
|
|
|
324 - DAMPER COMP.
HIT-6688261.A0
6688261
|
-
|
|
|
|
325 - DAPMPER COLLAR
HIT-6688478.A1
6688478
|
-
|
|
|
|
326 - HEX. HOLE BOLT 4X20
HIT-6695039.A12
6695039
|
-
|
|
|
|
327 - CLIP 5.2
HIT-6692311.A4
6692311
|
-
|
|
|
|
328 - FUEL PIPE ASS'Y L=195
HIT-6688173.A3
6688173
|
-
|
|
|
|
329 - CLIP 1
HIT-6684619.A2
6684619
|
£1.67
|
£2.00
|
|
|
330 - PUMP FILTER BODY
HIT-6692285.A10
6692285
|
£10.40
|
£12.48
|
|
|
331 - TANK CAP ASS'Y
HIT-6692111.A10
6692111
|
£5.87
|
£7.04
|
|
|
332 - TANK CAP PACKING
HIT-6685179.A22
6685179
|
£1.67
|
£2.00
|
|
|
501 - CHAIN BAR 1
HIT-6686886.A0
6686886
|
-
|
|
|
|
502 - CHAIN BAR 18
HIT-6686832.A0
6686832
|
£42.70
|
£51.24
|
|
|
503 - SAW CHAIN 13 INCH
HIT-6687270.A3
6687270
|
-
|
|
|
|
504 - CHAIN BAR 15
HIT-6687333.A1
6687333
|
£40.62
|
£48.75
|
|
|
505 - SAW CHAIN 15 INCH
HIT-6687335.A5
6687335
|
£30.92
|
£37.11
|
|
|
506 - SAW CHAIN 18 INCH
HIT-6687284.A4
6687284
|
£35.37
|
£42.44
|
|
|
507 - CHAIN COVER 20
HIT-6694804.A6
6694804
|
-
|
|
|
|
508A - CHAIN COVER 16
HIT-6685440.A22
6685440
|
£13.86
|
£16.63
|
|
|
509 - CHAIN COVER 14
HIT-6685256.A7
6685256
|
-
|
|
|
|
510 - COMBI. BOX SPANNER 13X19 MINUS
HIT-6693809.A26
6693809
|
-
|
|
|
|
601 - NAME PLATE
HIT-6694282.A0
6694282
|
-
|
|
|
|
602 - STARTER MARK
HIT-6694493.A0
6694493
|
-
|
|
|
|
603 - NAME PLATE 1
HIT-6694281.A0
6694281
|
-
|
|
|
|
604 - STARTER MARK 1
HIT-6694492.A0
6694492
|
-
|
|
|
