An exploded diagram and spare parts listing for the Hitachi / Hikoki ECV-3801 Engine Chain Saw
Ex VAT Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A46 6687468 £3.64 £4.37
2 - SPARK PLUG ASS'Y BPMR7A HIT-6699320.A24 6699320 -
3 - CYLINDER SET 1 HIT-6685464.A3 6685464 £62.56 £75.07
4 - CYLINDER GASKET HIT-6685731.A6 6685731 £1.67 £2.00
5 - HEX. HOLE BOLT 5X20S HIT-6695491.A1 6695491 £1.67 £2.00
6 - DECOMP. VALVE GASKET HIT-6685860.A4 6685860 £1.67 £2.00
7 - DECOMPRESSION COMP. HIT-6685589.A5 6685589 £37.61 £45.13
8 - DECOMP. COVER HIT-6685800.A6 6685800 £1.67 £2.00
9 - DUST COVER HIT-6690808.A5 6690808 -
10 - PISTON PIN CIRCLIP HIT-6686026.A10 6686026 £1.67 £2.00
11 - PISTON RING 2 HIT-6686124.A1 6686124 £8.45 £10.14
12 - PISTON SET 1 HIT-6685883.A4 6685883 £20.98 £25.18
13 - PISTON PIN 10X30 HIT-6686007.A14 6686007 £3.52 £4.23
14 - PISTON PIN COLLAR HIT-6685993.A12 6685993 £5.70 £6.84
15 - NEEDLE BEARING 1 HIT-6695602.A2 6695602 -
16 - CRANKSHAFT COMP. HIT-6686182.A3 6686182 -
17 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A81 6684899 -
31 - SIDE DUMPER HIT-6688164.A11 6688164 -
32 - HEX HOLE SCREW 5X35 HIT-6695076.A1 6695076 -
33 - OIL PIPE A HIT-6691219.A7 6691219 -
34 - CLIP 7 HIT-6692312.A9 6692312 -
35 - OIL FILTER BODY COMP. HIT-6697651.A3 6697651 -
*36 - SHIM 0.1 HIT-6686474.A9 6686474 -
*36 - SHIM S T0.2 HIT-6685098.A1 6685098 -
*36 - SHIM S T0.3 HIT-6685099.A33 6685099 -
*36 - SHIM 0.4 HIT-6686475.A14 6686475 -
37 - CRANK CASE ASS'Y HIT-6697589.A2 6697589 -
38 - KNOCK PIN 4X12 HIT-6695521.A36 6695521 -
39 - OIL SEAL ISMX12325.5 HIT-6695633.A20 6695633 £6.18 £7.41
40 - STOP RING C-32 1 HIT-6695295.A47 6695295 £1.67 £2.00
41 - BALL BEARING 6201 A2C3 HIT-6685096.A18 6685096 -
42 - BALL BEARING 6201 A2C3 HIT-6685096.A19 6685096 -
43 - STOP RING C-32 1 HIT-6695295.A48 6695295 £1.67 £2.00
44 - OIL SEAL ISMX12325.5 HIT-6695633.A10 6695633 £6.18 £7.41
45 - CRANKCASE GASKET HIT-6686710.A9 6686710 £1.67 £2.00
46 - AIR VENT VALVE (B) HIT-6685173.A9 6685173 -
47 - AIR VENT COVER HIT-6691399.A7 6691399 £4.72 £5.66
48 - HEX.HOLE BOLT M5X18/S HIT-6684586.A84 6684586 -
49 - HEX. SOCKET HD. BOLT M5X30 S HIT-6684786.A83 6684786 £1.67 £2.00
50 - AIR DEFLECTOR HIT-6687207.A5 6687207 -
51 - BOLT WASHER M8 HIT-6684611.A95 6684611 -
52 - HEX. NUT M8 HIT-6684612.A17 6684612 -
53 - MAGNETO ROTOR ASS'Y HIT-6687395.A1 6687395 £52.30 £62.76
54 - SPECIAL WASHER HIT-6687942.A11 6687942 -
55 - PAWL SPRING HIT-6693348.A3 6693348 -
56 - STARTER PAWL HIT-6693304.A6 6693304 £3.89 £4.67
57 - STEP BOLT HIT-6693366.A20 6693366 -
58 - HANDLE DAMPER HIT-6688107.A8 6688107 -
72 - CLUTCH SET ASS'Y 1 HIT-6695959.A0 6695959 -
72A - CLUTCH ASS'Y 1 HIT-6688489.A8 6688489 -
73 - CLUTCH HOUSING COMP.7T HIT-6689009.A9 6689009 £35.35 £42.42
74 - NEEDLE BEARING KT111410G HIT-6695606.A3 6695606 £14.19 £17.03
75 - OIL PUMP COVER HIT-6686755.A6 6686755 -
76 - SCREW GEAR COMP. HIT-6686640.A6 6686640 £38.15 £45.78
77 - OIL PUMP COMP. HIT-6687331.A9 6687331 £46.36 £55.63
78 - PINION WASHER 1T HIT-6686452.A10 6686452 £3.38 £4.06
79 - SMALL SCREW 4X12WS HIT-6695403.A0 6695403 -
80 - HIGH TENSION SCREW 4X18WS HIT-6695407.A57 6695407 -
81 - RELEASE VALVE HIT-6686661.A2 6686661 £1.67 £2.00
82 - O-RING S-3 HIT-6695659.A6 6695659 £1.67 £2.00
83 - O-RING P-5 HIT-6695661.A6 6695661 £1.67 £2.00
84 - CLUTCH SPRING SINCE V188401 HIT-6689426.A6 6689426 £2.98 £3.57
85 - CLUTCH SHOE SINCE V188401 HIT-6689493.A6 6689493 -
86 - CLUTCH BOSS SINCE V188401 HIT-6689497.A5 6689497 -
87 - CLUTCH WASHER B SINCE V188401 HIT-6689642.A4 6689642 -
101 - AIRCLEANER ELEMENT B COMP. HIT-6690335.A8 6690335 £9.60 £11.52
102 - AIRCLEANER ELEMENT A COMP. HIT-6690325.A1 6690325 £5.97 £7.16
103 - AIRCLEANER BASE COMP. HIT-6690198.A8 6690198 £7.75 £9.30
104 - HEX. HOLE BOLT 5X45 HIT-6695055.A17 6695055 £1.67 £2.00
105 - S.WASHER 5 HIT-6684662.A7 6684662 £1.67 £2.00
106 - SMALL WASHER 5 HIT-6684864.A56 6684864 -
107 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A22 6695512 -
109 - IDLE ADJUSTMENT SCREW TILL H126320 HIT-6687993.A5 6687993 -
109A - IDLE ADJUST SCREW SINCE H126321 HIT-6685298.A28 6685298 £1.67 £2.00
110 - SPECIAL WASHER HIT-6687943.A5 6687943 £1.67 £2.00
111 - CARB. INSULATOR 1 HIT-6690004.A3 6690004 -
112 - INSULATOR COMP. HIT-6689941.A0 6689941 -
113 - INLET MANIFOLD COMP. HIT-6689789.A8 6689789 -
114 - INLET MANIFOLD GASKET HIT-6689876.A3 6689876 -
115 - HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 HIT-6684595.A16 6684595 £1.67 £2.00
116 - IDLE ADJUST SPRING HIT-6690766.A6 6690766 -
117 - INLET MANIFOLD SPACER HIT-6685202.A11 6685202 -
118 - MUFFLER GASKET HIT-6692737.A5 6692737 -
119 - MUFFLER SET HIT-6692459.A6 6692459 -
120 - MUFFLER STAY HIT-6692942.A10 6692942 -
121 - HEX. HOLE BOLT M5X16/S HIT-6684903.A11 6684903 -
122 - HEX. HOLE BOLT 4X10 HIT-6695036.A6 6695036 -
141 - RECOIL STARTER ASS'Y HIT-6692916.A6 6692916 £30.63 £36.76
142 - SET SCREW HIT-6693633.A34 6693633 £1.67 £2.00
143 - STARTER ROPE REEL HIT-6693059.A2 6693059 £13.29 £15.95
144 - RECOIL SPRING CASE HIT-6693096.A6 6693096 £11.90 £14.28
145 - FAN CASE COMP. HIT-6686963.A9 6686963 -
146 - PLATE HIT-6685189.A44 6685189 -
147 - STARTER HANDLE HIT-6693230.A0 6693230 -
148 - STARTER ROPE HIT-6693158.A12 6693158 £4.26 £5.11
150 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A23 6695512 -
201 - CARBURETOR ASS'Y WT-497A HIT-6690606.A4 6690606 £93.28 £111.94
202 - INLET SCREEN HIT-6684700.A209 6684700 -
203 - PUMP BODY HIT-6691416.A11 6691416 £16.36 £19.63
204 - SCREW HIT-6685210.A27 6685210 -
205 - PUMP GASKET HIT-6685212.A19 6685212 £3.29 £3.95
206 - PUMP DIAPHRAGM HIT-6685213.A36 6685213 £8.44 £10.13
207 - NEEDLE VALVE HIT-6685215.A30 6685215 £6.79 £8.15
208 - DIAPHRAGM PACKING-METERING HIT-6685220.A113 6685220 £2.81 £3.37
209 - METERING DIAPHRAGM COMP. HIT-6690827.A13 6690827 £14.02 £16.83
210 - DIAPHRAGM COVER-METERING HIT-6685222.A63 6685222 £5.70 £6.84
211 - VALVE SPRING HIT-6690872.A16 6690872 -
212 - HINGE PIN SET SCREW HIT-6685218.A44 6685218 -
213 - HINGE PIN HIT-6685219.A29 6685219 -
214 - CONTROL LEVER HIT-6685217.A24 6685217 -
215 - SET SCREW HIT-6685223.A43 6685223 -
231 - AIRCLEANER KNOB COMP. HIT-6687793.A1 6687793 £5.92 £7.11
232 - CLEANER COVER SET 1 HIT-6690404.A5 6690404 £8.88 £10.66
233 - IDLE GROMMET HIT-6687974.A4 6687974 -
234 - ADJUSTER CAP HIT-6687954.A6 6687954 -
235 - CYLINDER COVER HIT-6685681.A6 6685681 -
236 - CYLINDR SUPPORT RUBBER HIT-6691825.A10 6691825 -
237 - CLEANER PACKING HIT-6690056.A6 6690056 -
238 - HEX. HOLE BOLT 5X15 WS HIT-6695512.A21 6695512 -
239 - INSULATOR TUBE 1 HIT-6688315.A3 6688315 -
240 - CHOKE BUTTON COMP. HIT-6692507.A8 6692507 -
241 - CHOKE ROD HOLDING RUBBER HIT-6692587.A12 6692587 -
242 - STOP SWITCH COMP. HIT-6687506.A3 6687506 £7.12 £8.54
243 - CONTROL PLATE HIT-6691192.A3 6691192 -
244 - SHUTTER PLATE HIT-6687952.A5 6687952 -
245 - STOP CORD 1 HIT-6687929.A4 6687929 -
246 - HEX.HOLE BOLT M5X12/S HIT-6684667.A68 6684667 £1.67 £2.00
247 - BUMPER SPIKE HIT-6690705.A6 6690705 £5.59 £6.71
248 - CHAIN CATCHER HIT-6687163.A4 6687163 -
249 - SPECIAL BOLT HIT-6689734.A6 6689734 -
250 - FUEL PIPE HIT-6685154.A12 6685154 -
251 - DAMPER COMP. HIT-6688113.A7 6688113 £5.70 £6.84
252 - TAPPING SCREW 5X35 HIT-6695107.A14 6695107 £1.67 £2.00
253 - COLLAR 15 HIT-6692248.A12 6692248 £1.67 £2.00
254 - OIL TANK CAP ASS'Y HIT-6697756.A13 6697756 £5.87 £7.04
255 - OIL TANK CAP PACKING HIT-6697888.A12 6697888 £1.67 £2.00
256 - IGNITION COIL COMP. HIT-6687695.A9 6687695 £73.85 £88.62
257 - HEX. HOLE BOLT M4X18/WS HIT-6684599.A3 6684599 -
271 - NUT M4 HIT-6685069.A18 6685069 -
272 - CHAIN BAR CLAMP NUT HIT-6687105.A13 6687105 £1.67 £2.00
273 - TAP SCREW 4X14 P HIT-6695280.A45 6695280 £1.67 £2.00
274 - FRONT HAND GUARD HIT-6693454.A6 6693454 £7.57 £9.08
275 - MACHINE SCREW (W/SP. WASHER) M4X12 HIT-6685068.A26 6685068 -
276 - HAND GUARD WEIGHT HIT-6693481.A4 6693481 -
277 - SIDE CASE ASS'Y HIT-6686095.A4 6686095 £92.02 £110.42
278 - TAPPING SCREW D4X10 HIT-6685161.A49 6685161 £1.67 £2.00
279 - BRAKE BAND HOLDER HIT-6689715.A2 6689715 -
280 - SIDE COVER COMP. HIT-6686043.A5 6686043 -
281 - CLEANER FIXING COLLAR HIT-6690805.A5 6690805 £2.69 £3.23
282 - BRAKE SUPPORT FITTING COMP. HIT-6689777.A1 6689777 -
283 - BRAKE LEVER SPRING HIT-6689781.A6 6689781 -
284 - BRAKE LINK COMP. HIT-6685121.A1 6685121 £18.38 £22.05
285 - BRAKE SPRING HIT-6689700.A1 6689700 £3.56 £4.27
286 - BRAKE BAND HIT-6689724.A4 6689724 £15.38 £18.45
287 - NEEDLE ROLLER 3X9.8 HIT-6685141.A2 6685141 -
288 - BRAKE LINK COVER HIT-6689709.A7 6689709 -
289 - TAPPING SCREW D4X10 HIT-6685161.A50 6685161 £1.67 £2.00
290 - GUIDE PLATE B HIT-6697598.A8 6697598 £3.56 £4.27
291 - SCREW 4X8 HIT-6694861.A17 6694861 -
292 - GUIDE PLATE A HIT-6697597.A4 6697597 £3.56 £4.27
293 - CHAIN BAR STUD BOLT HIT-6686804.A4 6686804 -
294 - CHAIN TENSION BOLT ASSY HIT-6687067.A2 6687067 £5.70 £6.84
311 - TAPPING SCREW 5X18 HIT-6695106.A15 6695106 -
312 - REAR HANDLE GRIP HIT-6688212.A6 6688212 -
313 - TRIGGER LOCKOUT BLACK HIT-6688352.A6 6688352 -
314 - THROTTLE ROD COMP. HIT-6690967.A5 6690967 -
315 - THROTTLE LEVER HIT-6686381.A9 6686381 -
316 - THROTTLE LEVER SPRING HIT-6686412.A6 6686412 -
317 - REAR HANDLE ASS'Y HIT-6685663.A7 6685663 £50.06 £60.07
318 - SPRING PIN 5X25 HIT-6685282.A8 6685282 £1.67 £2.00
319 - NO LONGER AVAILABLE HIT-6688079.A5 6688079 -
320 - TAPPING SCREW 5X18 HIT-6695106.A14 6695106 -
321 - AIR VENT VALVE ASS'Y HIT-6692172.A6 6692172 -
322 - AIRVENT PIPE HIT-6691391.A6 6691391 -
323 - FRONT DAMPER HIT-6688241.A6 6688241 -
324 - DAMPER COMP. HIT-6688261.A7 6688261 -
325 - DAPMPER COLLAR HIT-6688478.A10 6688478 -
326 - HEX. HOLE BOLT 4X20 HIT-6695039.A5 6695039 -
327 - CLIP 5.2 HIT-6692311.A11 6692311 -
328 - FUEL PIPE ASS'Y L=195 HIT-6688173.A10 6688173 -
329 - CLIP 1 HIT-6684619.A57 6684619 £1.67 £2.00
330 - PUMP FILTER BODY HIT-6692285.A0 6692285 £10.40 £12.48
331 - TANK CAP ASS'Y HIT-6692111.A5 6692111 £5.87 £7.04
332 - TANK CAP PACKING HIT-6685179.A7 6685179 £1.67 £2.00
501 - CHAIN BAR 15 HIT-6687333.A0 6687333 £40.62 £48.75
502 - CHAIN BAR 1 HIT-6686855.A1 6686855 £52.85 £63.42
503 - CHAIN BAR 18 HIT-6686832.A2 6686832 £42.70 £51.24
504 - SAW CHAIN 15 INCH HIT-6687335.A2 6687335 £30.92 £37.11
505 - SAW CHAIN 16 INCH HIT-6687296.A8 6687296 -
506 - SAW CHAIN 18 INCH HIT-6687284.A11 6687284 £35.37 £42.44
507 - CHAIN COVER 20 HIT-6694804.A3 6694804 -
508A - CHAIN COVER 16 HIT-6685440.A2 6685440 £13.86 £16.63
510 - COMBI. BOX SPANNER 13X19 MINUS HIT-6693809.A4 6693809 -
601 - NAME PLATE HIT-6696240.A0 6696240 -
602 - STARTER MARK ECV3801 HIT-6696247.A0 6696247 -
