Hitachi / Hikoki ECS-3500 Engine Chain Saw Spare Parts

Home Details Reviews Delivery

An exploded diagram and spare parts listing for the Hitachi / Hikoki ECS-3500 Engine Chain Saw

	Ex VAT	Inc VAT
1 - SPARK PLUG CAP ASS'Y HIT-6687468.A13 6687468	£3.64	£4.37
2 - SPARK PLUG ASS'Y BPM6A HIT-6699317.A24 6699317	-
3 - HEX. HOLE BOLT 5X22S HIT-6695493.A2 6695493	-
4 - HEX. HOLE BOLT 5X22S HIT-6695493.A3 6695493	-
5 - WASHER M5 (BLACK) HIT-6685226.A13 6685226	-
6 - CYLINDER HIT-6695830.A0 6695830	-
7 - CYLINDER GASKET HIT-6685734.A1 6685734	-
8 - PISTON RING HIT-6686122.A3 6686122	-
9 - PISTON SET HIT-6685882.A0 6685882	-
10 - PISTON PIN HIT-6686008.A23 6686008	£3.64	£4.37
11 - CIRCLIP HIT-6685078.A23 6685078	-
12 - CRANK SHAFT COMP. HIT-6686186.A0 6686186	-
13 - WOODRUFF KEY 3X13X4.5 HIT-6684899.A41 6684899	-
14 - IGNITION COIL ASS'Y HIT-6695941.A1 6695941	-
15 - WASHER T1.6 HIT-6684600.A36 6684600	-
16 - SCREW 4X22/WS HIT-6695410.A12 6695410	-
*31 - CRANK SHAFT SHIM 0.10 HIT-6686470.A1 6686470	-
*31 - CRANK SHAFT SHIM 0.20 HIT-6686472.A29 6686472	£1.67	£2.00
*31 - CRANK SHAFT SHIM 0.30 HIT-6686473.A2 6686473	£1.67	£2.00
32 - CRANK SHAFT WASHER 15.2X22 HIT-6686463.A0 6686463	-
33 - CRANK CASE ASSY HIT-6686544.A1 6686544	-
34 - VLAVE HOLDER ASSY HIT-6692168.A0 6692168	-
35 - AIR VENT VALVE (B) HIT-6685173.A25 6685173	-
36 - OIL SEAL UD15257 HIT-6695637.A27 6695637	£3.66	£4.39
37 - BALL BEARING #6202 2 HIT-6695557.A18 6695557	-
38 - CRANK CASE GASKET HIT-6686708.A1 6686708	-
39 - OIL SEAL TB 12227 HIT-6684607.A178 6684607	£4.07	£4.88
40 - HEX. HOLE BOLT 5X30 HIT-6695052.A4 6695052	-
41 - OIL ADJUST GROMMET HIT-6690953.A1 6690953	-
42 - OIL PIPE B HIT-6691117.A1 6691117	-
43 - CLIP 7 HIT-6692312.A24 6692312	-
44 - OIL FILTER BODY ASS'Y HIT-6685249.A21 6685249	£1.67	£2.00
45 - MAGNETO ROTOR ASS'Y HIT-6687408.A1 6687408	-
47 - STARTER PAWL SPRING HIT-6693347.A0 6693347	-
48 - STARTER PAWL HIT-6693297.A1 6693297	-
49 - STARTER PAWL SHIM 0.6T HIT-6693562.A1 6693562	-
50 - STEP BOLT HIT-6693366.A0 6693366	-
51 - BOLT WASHER M7 HIT-6685103.A5 6685103	-
52 - S.WASHER 7 HIT-6695222.A5 6695222	-
53 - FLYWHEEL NUT HIT-6686442.A0 6686442	-
71 - CLEANER KNOB COMP. HIT-6687794.A0 6687794	-
72 - CLEANER COVER HIT-6686296.A1 6686296	-
73 - O-RING P-3 HIT-6695658.A1 6695658	-
74 - CLEANER ELEMENT COMP. HIT-6690068.A1 6690068	-
75 - CHOKE BUTTON COMP. HIT-6692508.A0 6692508	-
76 - SCREW 5X40/S HIT-6695348.A6 6695348	-
77 - BLOW OVER CHECK BOARD HIT-6690846.A1 6690846	-
78 - CHOKE VALVE HIT-6692404.A0 6692404	-
79 - CHOKE SHIM 0.8 HIT-6692596.A2 6692596	-
80 - INLET MANIFOLD GASKET HIT-6689877.A1 6689877	-
81 - INLET MANIFOLD HIT-6689797.A1 6689797	-
82 - MANIFOLD FLANG HIT-6689790.A1 6689790	-
83 - AIR DEFLECTOR A HIT-6687292.A1 6687292	-
84 - MACHINE SCREW (W/SP. WASHER) M4X14 HIT-6685149.A1 6685149	-
85 - INLET MANIFOLD SPACER HIT-6689813.A0 6689813	-
86 - SECONDARY CORD GROMMET HIT-6688037.A0 6688037	-
87 - THROTTLE GUIDE HIT-6690981.A0 6690981	-
88 - FUEL PIPE HIT-6692372.A0 6692372	-
89 - CLIP 1 HIT-6684619.A15 6684619	£1.67	£2.00
90 - CYLINDER COVER COMP. HIT-6685684.A1 6685684	-
91 - PRIMARY CORD GROMMET HIT-6688055.A1 6688055	-
92 - PRIMARY CORD GROMMET HIT-6688049.A11 6688049	-
93 - EARTH CORD 1 HIT-6688449.A0 6688449	-
94 - SCREW 5X16/S HIT-6695338.A0 6695338	-
95 - SCREW 5X16/PS HIT-6695386.A28 6695386	£1.67	£2.00
96 - COLLAR HIT-6685853.A0 6685853	-
101 - MUFFLER ASSY HIT-6692528.A0 6692528	-
102 - MUFFLER BODY B COMP. HIT-6692629.A1 6692629	-
103 - MUFFLER COLLAR HIT-6692840.A1 6692840	-
104 - MUFFLER GASKET HIT-6692739.A0 6692739	-
105 - WASHER 5 HIT-6684661.A57 6684661	£1.67	£2.00
106 - HEX.HOLE BOLT M5X35 HIT-6684934.A13 6684934	-
107 - SMALL WASHER 5 HIT-6684864.A142 6684864	-
108 - HEX. SOCKET HD. BOLT M5X35 HIT-6685057.A0 6685057	-
109 - MUFFLER BODY COMP. HIT-6692598.A0 6692598	-
121 - RECOIL STARTER ASSY HIT-6692919.A1 6692919	-
122 - BINDING HEAD SCREW 5X12 HIT-6694966.A0 6694966	-
123 - STARTER WASHER HIT-6693250.A1 6693250	-
124 - STARTER ROPE REEL COMP. HIT-6693063.A0 6693063	-
125 - RECOIL SPRING CASE ASS'Y HIT-6693090.A1 6693090	£9.00	£10.80
126 - PLATE HIT-6685189.A14 6685189	-
127 - STARTER HANDLE HIT-6693230.A17 6693230	-
128 - STARTER ROPE HIT-6693162.A0 6693162	-
129 - FAN CASE COMP. HIT-6686966.A1 6686966	-
130 - SCREW 5X16/WS HIT-6695418.A0 6695418	-
151 - CARBURETOR ASS'Y 1 HIT-6690597.A0 6690597	-
152 - PUMP BODY COMP. HIT-6691421.A1 6691421	-
153 - PUMP GASKET HIT-6685212.A49 6685212	£3.29	£3.95
154 - PUMP DIAPHRAGM HIT-6685213.A7 6685213	£8.44	£10.13
155 - DIAPHRAGM GASKET HIT-6690837.A7 6690837	£3.29	£3.95
156 - METERING DIAPHRAGM COMP. HIT-6690827.A79 6690827	£14.02	£16.83
157 - DIAPHRAGM COVER-METERING HIT-6685222.A165 6685222	£5.70	£6.84
158 - HIGH ADJUST SCREW HIT-6690691.A4 6690691	-
159 - HIGH ADJUSTMENT SPRING HIT-6690897.A6 6690897	-
160 - LOW ADJUST SCREW HIT-6697669.A0 6697669	-
161 - HIGH/LOW ADJUST SPRING HIT-6692048.A14 6692048	-
162 - IDLE ADJUST SCREW HIT-6685298.A1 6685298	£1.67	£2.00
163 - IDLE ADJUST SPRING HIT-6685297.A29 6685297	-
164 - VALVE SPRING HIT-6690870.A1 6690870	-
165 - NEEDLE VALVE HIT-6691943.A1 6691943	-
166 - CONTROL LEVER HIT-6685217.A64 6685217	-
167 - HINGE PIN HIT-6685219.A88 6685219	-
168 - INLET SCREEN HIT-6684700.A78 6684700	-
169 - SCREW HIT-6685210.A67 6685210	-
170 - HINGE PIN SET SCREW HIT-6685218.A0 6685218	-
171 - SET SCREW HIT-6685223.A0 6685223	-
191 - FUEL TANK CAP ASS'Y HIT-6692115.A0 6692115	-
192 - TANK CAP GASKET HIT-6692153.A0 6692153	-
193 - REAR HANDLE A COMP HIT-6601144.A0 6601144	-
194 - CLIP 7 HIT-6692312.A25 6692312	-
195A - RUBBER PIPE HIT-6697912.A0 6697912	-
196A - PUMP FILTER BODY COMP HIT-66A3864.A81 66A3864	-
197 - SCREW 3X10 HIT-6684913.A42 6684913	£1.67	£2.00
198 - BUTTON STOP HIT-6688366.A36 6688366	£1.67	£2.00
199 - STOP BUTTON MARK HIT-6694585.A11 6694585	-
200 - STOP BUTTON COMP. HIT-6687741.A1 6687741	-
201 - THROTTLE TRIGGER LOCKOUT HIT-6688359.A0 6688359	-
202 - THROTTLE LEVER HIT-6686388.A0 6686388	-
203 - THROTTLE LEVER SPRING HIT-6686418.A1 6686418	-
204 - THROTTLE ROD HIT-6690973.A0 6690973	-
205 - PUSH PIN HIT-6686430.A5 6686430	£1.67	£2.00
206 - STOPPER SPRING HIT-6686447.A14 6686447	£1.67	£2.00
207 - PUSH PIN CAP HIT-6692681.A0 6692681	£1.67	£2.00
208 - REAR HANDLE B COMP. HIT-6685644.A0 6685644	-
209 - REAR HANDLE B HIT-6685643.A1 6685643	-
210 - SCREW 4X30/WS HIT-6695412.A10 6695412	-
211 - SCREW 4X22/WS HIT-6695410.A13 6695410	-
212 - NUT M4 HIT-6685069.A5 6685069	-
213 - SPECIAL NUT HIT-6693659.A0 6693659	-
214 - ADJUSTER CAP HIT-6687955.A0 6687955	-
215 - GROMMET HIT-6687976.A6 6687976	-
216 - GROMMET A TILL TL040520 HIT-6686327.A0 6686327	-
231 - SCREW 5X25PS HIT-6695395.A6 6695395	-
232 - DAMPER COMP. HIT-6688111.A1 6688111	-
233 - SCREW 5X12/S HIT-6695334.A9 6695334	£1.67	£2.00
234 - DAMPER SET BOLT A HIT-6688630.A0 6688630	-
235 - DAMPER CAP HIT-6688182.A1 6688182	-
236 - SCREW 4X8/W HIT-6695432.A1 6695432	-
237 - OIL TANK CAP ASS'Y HIT-6692157.A1 6692157	-
238 - TANK CAP CHAIN ASSY HIT-6692052.A1 6692052	-
239 - O RING HIT-6697898.A8 6697898	-
240 - CHAIN CATCHER HIT-6687164.A1 6687164	-
241 - COLLAR HIT-6690877.A1 6690877	-
242 - SMALL WASHER 5 HIT-6684864.A19 6684864	-
243 - HEX. HOLE BOLT 5X25 HIT-6695051.A1 6695051	-
244 - OIL LEVEL CAP ASS'Y HIT-6691249.A0 6691249	-
245 - O RING HIT-6697898.A7 6697898	-
246 - ENGINE BASE COMP. HIT-6685584.A1 6685584	-
247 - DAMPER COMP. HIT-6688113.A0 6688113	£5.70	£6.84
248 - DAMPER B COMP. HIT-6688410.A1 6688410	-
249 - FRONT HANDLE COMP. HIT-6688078.A0 6688078	-
250 - SCREW 5X14/PS HIT-6695384.A8 6695384	-
251 - SCREW 5X12/S HIT-6695334.A8 6695334	£1.67	£2.00
252 - FRONT HAND GUARD FOR WITHOUT CHAIN BRAKE HIT-6693462.A3 6693462	-
253 - SCREW 5X25PS HIT-6695395.A5 6695395	-
254 - SCREW 5X16/PS HIT-6695386.A1 6695386	£1.67	£2.00
255 - SCREW 5X25PS FOR WITHOUT CHAIN BRAKE HIT-6695395.A4 6695395	-
256 - U-NUT 5 FOR WITHOUT CHAIN BRAKE HIT-6695157.A12 6695157	£1.67	£2.00
271 - NUT HIT-6685166.A8 6685166	£3.62	£4.35
272 - SIDE CASE COMP. FOR WITHOUT CHAIN BRAKE HIT-6686086.A0 6686086	-
273 - GUIDE PLATE B HIT-6690749.A0 6690749	-
274 - TAPPING SCREW D4X10 FOR WITHOUT CHAIN BRAKE HIT-6685161.A68 6685161	£1.67	£2.00
275 - SCREW 4X8 HIT-6694861.A11 6694861	-
276 - GUIDE PLATE A HIT-6690729.A1 6690729	-
277 - PLATE HIT-6690787.A0 6690787	-
278 - CHAIN BAR STUD BOLT HIT-6686804.A8 6686804	-
279 - TENSION ADJUSTMENT BOLT ASS'Y HIT-6687066.A1 6687066	-
280 - CLUTCH COMP. HIT-6688561.A1 6688561	-
281 - NEEDLE BEARING HIT-6685143.A9 6685143	£4.72	£5.66
282 - CLUTCH HOUSING COMP. P-3/8 HIT-6688998.A0 6688998	-
283 - CLUTCH WASHER HIT-6685145.A8 6685145	-
284 - OIL PUMP COVER COMP. HIT-6686757.A1 6686757	-
285 - SCREW 5X22 HIT-6694893.A0 6694893	-
286 - OIL PUMP CASE ASS'Y HIT-6686672.A1 6686672	-
287 - OIL PUMP ADJUSTER HIT-6691067.A0 6691067	-
288 - ADJUSTER SPRING HIT-6691085.A1 6691085	-
289 - WASHER 5 HIT-6684661.A84 6684661	£1.67	£2.00
290 - O-RING P-5 HIT-6695661.A14 6695661	£1.67	£2.00
291 - OIL PUMP ADJUST CAP HIT-6691091.A0 6691091	-
292 - OIL PUMP COMP HIT-6687332.A1 6687332	-
293 - OIL SEAL AC13246 HIT-6695634.A1 6695634	-
294 - SCREW GEAR HIT-6686639.A0 6686639	-
295 - OIL PIPE A HIT-6691220.A1 6691220	-
296 - CLIP 6.8 HIT-6692313.A0 6692313	-
297 - SIDE CASE ASSY FOR WITH CHAIN BRAKE HIT-6686089.A0 6686089	-
298 - SCREW 5X16/S FOR WITH CHAIN BRAKE HIT-6695338.A2 6695338	-
299 - BRAKE HANDLE FOR WITH CHAIN BRAKE HIT-6689743.A0 6689743	-
300 - NUT M5 FOR WITH CHAIN BRAKE HIT-6684965.A13 6684965	£1.67	£2.00
301 - BRAKE LEVER COMP FOR WITH CHAIN BRAKE HIT-6689670.A0 6689670	-
302 - SIDE CASE COMP. FOR WITH CHAIN BRAKE HIT-6686071.A1 6686071	-
303 - TAPPING SCREW D4X10 FOR WITH CHAIN BRAKE HIT-6685161.A69 6685161	£1.67	£2.00
304 - BRAKE SPRING FOR WITH CHAIN BRAKE HIT-6689698.A1 6689698	-
305 - STEP BOLT A FOR WITH CHAIN BRAKE HIT-6689760.A1 6689760	-
306 - SPRING PIN 4X12 FOR WITH CHAIN BRAKE HIT-6695268.A0 6695268	-
307 - BRAKE ARM FOR WITH CHAIN BRAKE HIT-6689694.A0 6689694	-
308 - BRAKE BAND COMP. FOR WITH CHAIN BRAKE HIT-6689723.A1 6689723	-
309 - BRAKE SHAFT WASHER FOR WITH CHAIN BRAKE HIT-6689680.A10 6689680	£1.67	£2.00
310 - STEP BOLT B FOR WITH CHAIN BRAKE HIT-6689769.A0 6689769	-
311 - CENTER SPRING FOR WITH CHAIN BRAKE HIT-6689647.A1 6689647	-
501 - COMBI. BOX SPANNER 10X19 HIT-6685666.A1 6685666	-
502 - FILE ASS'Y 5/32 HIT-6694782.A0 6694782	-
503 - CHAIN BAR 1 HIT-6686844.A1 6686844	-
504 - CHAIN 16 FOR WITHOUT CHAIN BRAKE HIT-6697890.A1 6697890	-
505A - CHAIN COVER 16 HIT-6685440.A7 6685440	£13.86	£16.63
506 - SAW CHAIN (3/8X16) 91PX-57XJ HIT-781126.A2 781126	£19.00	£22.80
507 - CHAIN BAR 16 HIT-6686854.A5 6686854	-
601 - NAME PLATE HIT-6694271.A0 6694271	-
602 - STARTER MARK HIT-6696246.A0 6696246	-

Attribute Name	Value
Brand	Hikoki

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Hitachi / Hikoki ECS-3500 Engine Chain Saw Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Hitachi / Hikoki ECS-3500 Engine Chain Saw Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Hitachi / Hikoki ECS-3500 Engine Chain Saw Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
